Buffalo AirStation WXR-1900DHP User manual

AirStation
WXR-1900DHP
User Manual
www.buffaloamericas.com
35020665-01
2014.10

2
Contents
Chapter 1 - Setup ...............................................................9
Introduction .........................................................................................9
Diagrams and Layout...........................................................................9
Front Panel ......................................................................................................9
Back Panel .....................................................................................................11
Side Panel ......................................................................................................12
Bottom...........................................................................................................13
How to Set Up AirStation for the First Time .....................................14
Connect to a PC and Power On.....................................................................14
Opening Settings ..........................................................................................16
Connect Your Wireless Devices ....................................................................17
Chapter 2 - Settings.........................................................18
Easy Admin .........................................................................................18
Home..............................................................................................................18
Wireless..........................................................................................................19
AOSS/WPS......................................................................................................20
USB Storage...................................................................................................20
Guest Accounts .............................................................................................21
QoS.................................................................................................................21
Web Filtering .................................................................................................22
Network Devices ...........................................................................................23
Advanced Settings .............................................................................24
Internet..........................................................................................................24

3
PPPoE.............................................................................................................25
Dynamic DNS.................................................................................................27
VPN Server.....................................................................................................28
NAT .................................................................................................................29
IPv6 ................................................................................................................29
LAN.................................................................................................................30
DHCP Leases..................................................................................................31
Routing ..........................................................................................................31
2.4 GHz/5 GHz ...............................................................................................32
WPS ................................................................................................................34
AOSS...............................................................................................................35
MAC Filtering.................................................................................................36
Multicast Control ..........................................................................................37
Guest Accounts .............................................................................................37
Wi-Fi Settings Transfer..................................................................................38
Wireless Bridge .............................................................................................39
Firewall ..........................................................................................................40
IP Filter/IPv6 Filter ........................................................................................41
Passthrough ..................................................................................................42
Port Forwarding............................................................................................42
DMZ................................................................................................................43
UPnP...............................................................................................................43
Web Filtering .................................................................................................44
Access Control ...............................................................................................45
Disk Management.........................................................................................45
Sharing ..........................................................................................................47
WebAccess .....................................................................................................48
Media Server .................................................................................................49

4
BitTorrent ......................................................................................................49
QoS.................................................................................................................50
eco Mode .......................................................................................................51
Network USB .................................................................................................52
System ...........................................................................................................53
Syslog Settings..............................................................................................54
Reset/Reboot.................................................................................................55
Update Firmware ..........................................................................................56
System Information ......................................................................................57
Logs................................................................................................................58
Packets...........................................................................................................58
Ping ................................................................................................................59
Chapter 3 - Wireless.........................................................60
Wireless Options ................................................................................60
Advanced Wireless Configuration ....................................................61
Manual Configuration (SSID and Password)...............................................61
Automatic Secure Setup (WPS)....................................................................61
Automatic Secure Setup (AOSS) ..................................................................62
Adding an AirStation to an Existing Wireless Network as a Client ...........63
Chapter 4 - Utilities..........................................................64
How to Download Utilities ................................................................64
List of Utilities with Description of Each ..........................................64
AirStation Configuration Tool......................................................................64
Network USB Navigator ...............................................................................65
Client Manager..............................................................................................66

5
AOSS Assistant ..............................................................................................67
WLAN Monitor...............................................................................................67
Chapter 5 - Troubleshooting...........................................68
Finding Your AirStation on the Network ..........................................68
Eliminating Dead Spots in Wireless Coverage .................................68
If Your Wireless Connection Is Not Stable.........................................68
Basic Router Troubleshooting...........................................................68
Basic Router Troubleshooting from a Mac .......................................69
If All LEDs Are Blinking White ...........................................................69
Appendix A - Supplemental Information ......................70
Package Contents...............................................................................70
Factory Default Settings....................................................................70
Technical Specifications ....................................................................76
Shared Folders and USB Ports...........................................................78
GPL Information.................................................................................79
Appendix B - Tutorials .....................................................80
Configuring the AirStation for Optimal Performance and Security ...80
Performance..................................................................................................80
Security..........................................................................................................80
Sharing an USB Device.......................................................................81
Enabling Network USB on the AirStation ...................................................81

6
Installing and Using Network USB Navigator.............................................81
Configuring the Web Filter ................................................................82
Content Filter ................................................................................................82
Websites Excluded from Filter .....................................................................82
Computers Excluded from Filter..................................................................83
Finding a Computer's MAC Address ............................................................83
Configuring Access Control...............................................................84
Port Forwarding Basics......................................................................85
Common Uses................................................................................................85
Security..........................................................................................................85
UPnP...............................................................................................................85
Setting Up Port Forwarding Rules ....................................................86
Creating Port Forwarding Rules ..................................................................86
Managing Port Forwarding Rules................................................................87
Configuring a USB Drive as a NAS.....................................................87
Setting Up the NAS .......................................................................................87
Formatting the Drive ....................................................................................88
User Access ....................................................................................................88
Enable Sharing..............................................................................................89
Adding the AirStation to a Wireless Network ..................................90
Set Up the AirStation as an Extender ..........................................................90
Set Up the AirStation as a Repeater ............................................................91
Connecting Wireless Bridge Clients with MAC Filtering Enabled...93
Required Devices ..........................................................................................94
Configuration................................................................................................94
Adding Devices .......................................................................................... 101
Saving and Restoring Settings with a Backup File ....................... 102

7
Save Settings to a Backup File .................................................................. 102
Restoring Settings with a Backup File...................................................... 103
Replacing the AirStation ........................................................................... 103
Setting Up WebAccess .................................................................... 104
WebAccess Settings ................................................................................... 104
Connecting Wireless Devices Using AOSS..................................... 105
Pushbutton Method .................................................................................. 105
Setting Up a VPN Server ................................................................. 106
L2TP/IPsec Settings on the AirStation...................................................... 106
Editing Users .............................................................................................. 106
PPTP Settings on the AirStation ............................................................... 107
Editing Users .............................................................................................. 108
Using AirStations with 2Wire Residential Gateways.................... 108
How to Use QoS ............................................................................... 109
Setting a QoS Priority Policy ..................................................................... 109
Manual Entry .............................................................................................. 110
IPv6 Connections ............................................................................ 111
How to Configure TCP/IP ................................................................ 113
Windows 8 .................................................................................................. 113
Windows 7 .................................................................................................. 113
Windows Vista ............................................................................................ 114
Windows XP................................................................................................ 115
Mac OS ........................................................................................................ 115
Appendix C - Regulatory Compliance Information.....116
Company Information .................................................................... 116

8
FCC Statement................................................................................. 116
IC statement (IC déclaration).......................................................... 117

9
Chapter 1 - Setup
Introduction
Thank you for purchasing a Buffalo AirStation. The WXR-1900DHP AirStations are dual-band wireless routers with
outstanding performance and range. They combine high data transfer speeds with a robust set of extra features like
QoS, USB NAS, media server, and web filtering. This manual will help you set up and use your new wireless router. If
you're new to wireless networking, turn to chapter 2 to start configuring your wireless network.
For advanced users, use a wired Ethernet connection to access the AirStation's settings:
• Default LAN-side IP address: 192.168.11.1
• Username: admin
• Default password: password
Diagrams and Layout
Front Panel

10
1 AOSS button
To initiate AOSS, hold down this button until the wireless LED flashes (about 1 second). Then, push or click the
AOSS button on your wireless client device to complete the connection. Both devices must be powered on.
Press and hold the AOSS button for about 10 seconds to start Wi-Fi settings transfer.
2 Power LED (white or amber)
On (white):
Power is on.
Blinking (white):
Booting.
Off:
Power is off.
Blinking (amber):
An error occurred. If this occurs, turn the power off and restart the AirStation.
3 Wireless LED (white or amber)
On:
Wireless LAN is enabled or transmitting.
Double blinks:
AirStation is waiting for an AOSS or WPS security key.
Blinking (white):
AOSS/WPS error; failed to exchange security keys.
Blinking (amber):
The AirStation is in wireless bridge mode and not connected to an access point.
Off:
Wireless LAN is disabled.
4 Internet access LED (white)
On:
Internet access is available.
Off:
No Internet access.
5 Router LED (white)
On:
Router functionality is enabled.
Off:
Router functionality is disabled.
6 USB 3.0 port
You can connect a USB 3.0 drive.

11
Back Panel
1 USB eject button
To dismount a USB hard drive, hold down this button until the USB LED flashes (about 3 seconds). The USB drive
can then be unplugged safely.
2 USB LED (green)
On:
A USB drive is connected.
Blinking:
The USB drive is being dismounted; do not unplug.
Off:
The USB drive has been dismounted and safely unplugged or no USB drive is connected.
Note: Do not remove the USB drive or turn off the AirStation while LED is blinking.
3 USB 2.0 port
You can connect a USB 2.0 drive.
Note: USB 3.0 hubs are not supported. Use USB 2.0 hubs only.
4 LAN ports and LAN LEDs (green)
Connect your computer, hub, or other Ethernet devices to these ports. This switching hub supports 10 Mbps, 100
Mbps, and 1000 Mbps connections.
On:
An Ethernet device is connected.
Blinking:

12
An Ethernet device is communicating.
5 Internet port and Internet LED (green)
10 Mbps, 100 Mbps, and 1000 Mbps connections are supported.
Note: In bridge mode, the Internet port becomes a regular LAN port, for a total of 5 usable LAN ports.
On:
The Internet port is connected.
Blinking:
The Internet port is transmitting data.
6 Power button
This button turns the power on and off.
7 DC connector
Connect the included AC adapter here.
Side Panel
1 Setup card panel
This is the panel where the AirStation setup card is stored. The initial settings for the username, password, SSID,
and encryption type are provided on the card for logging in to Settings.

13
Bottom
1 Reset button
To reset all settings, hold down this button until the power LED starts blinking (about 3 seconds). The power must
be on for this to work.
2 Mode switch
This switches between router mode, access point mode, and wireless bridge mode.

14
How to Set Up AirStation for the First Time
Connect to a PC and Power On
To configure your AirStation, follow the procedure below.
1 Verify that you can connect to the Internet without the AirStation, then turn off your modem and computer.
2 Unplug the LAN cable which connects your computer and modem.
3 Plug one end of the LAN cable into your modem and the other end to the AirStation's Internet (WAN) port. Turn
on the modem.

15
4 Turn on the AirStation and wait one minute.
Note: If the power does not come on when the AC adapter is connected, press the power button on the rear of the
AirStation.
5 If using a wired LAN, connect the AirStation LAN port and computer using a LAN cable.
If using a wireless LAN, connect the computer to the wireless LAN as described in the "Adding an AirStation to an
Existing Wireless Network as a Client" section in chapter 3.
6 Once your computer has booted, the AirStation's LEDs should be lit as described below:
Power: Lit green.
Wireless: Lit green.
Internet access: Lit green.
Router: Lit green.
LAN: Lit or blinking green.
Internet: Lit or blinking green.

16
7 Launch a web browser. If the home screen is displayed, setup is complete.
If username and password fields are displayed, enter "admin" for the username and "password" for the password,
then click Log In. Step through the wizard to complete setup.
You've completed the initial setup of your AirStation.
Opening Settings
To configure the AirStation, log in to Settings as shown below.
1 Launch a web browser.
2 Enter the AirStation's LAN-side IP address in the address field and press the enter key.
Notes:
• The AirStation's default LAN-side IP address depends on the mode.
• In router mode: 192.168.11.1
• In access point mode: 192.168.11.100
• In wireless bridge mode: 192.168.11.100
• If you changed the IP address of the AirStation, then use the new IP address.
3 Enter "admin" for the username and "password" for the password, then click Log In.
Note: If you forget your password, hold down the reset button to initialize all settings. Note that all other settings
will also revert to their default values.

17
4 This is the home page of Settings, where most AirStation settings can be configured.
Connect Your Wireless Devices
For each wireless device that you want to connect to the network, use the device's built-in software to search for
available networks. Find your SSID (the name of your wireless network) on the list of detected networks and select it.
Enter the passphrase for the network and you'll be connected. Repeat for any additional wireless client devices that you
want to connect.

18
Chapter 2 - Settings
Settings is the configuration GUI for the AirStation. You can configure all settings for the AirStation from here.
Easy Admin
Home
When you first open Settings, the Easy Admin page is shown. From this page you can easily configure common settings.
The examples below assume the AirStation is in router mode.
Wireless Displays current wireless status. Click the panel to configure wireless settings.
AOSS/WPS Displays current AOSS/WPS status. Click the panel to run AOSS/WPS.
USB Storage Displays the status of USB storage connected to this product. Click the panel to
configure USB storage settings.
Guest Accounts Displays current guest accounts status. Click the slider to turn guest accounts on or off.
Click the panel to configure guest accounts settings.
QoS Displays current QoS status. Click the slider to turn QoS on or off. Click the panel to
configure priority control QoS.
Web Filtering Displays current content filter status. Click the panel to configure web filtering.
Network Devices Displays the number of devices connected to the network. Click the panel to check each
device's status.
Advanced Settings Click the panel to configure advanced settings.

19
Wireless
Configure basic wireless settings here. This is available in router and access point modes only.
2.4 GHz (11n/g/b)
5 GHz (11ac/n/a)
You may enable or disable either wireless frequency range independently. If both
wireless radios are disabled, the AirStation will not communicate wirelessly.
SSID 1 Each SSID may contain up to 32 alphanumeric characters.
Encryption
The following types of encryption are available:
WPA2-PSK AES
WPA2 authentication with AES encryption is the best system available. Highly
recommended if all your wireless clients support it.
WPA-PSK AES
WPA authentication with AES encryption is an older system, but still secure.
WPA/WPA2-mixed PSK TKIP+AES
For maximum compatibility, this system allows any combination of WPA, WPA2, TKIP, and
AES. This encryption system works with most older clients but is not very secure.
No encryption
No encryption means that anyone can log in to your wireless network, snoop on your
wireless traffic, and use your bandwidth. Not recommended for most users.
Encryption Key
The encryption key is like the "password" for your wireless network. It may contain 8 to
63 case-sensitive alphanumeric characters (ASCII) or 64 hexadecimal characters (0-9 and
a-f, not case-sensitive).
Channel For best results, select Auto Channel. The AirStation will seek and use the clearest
channel automatically. Alternately, you may choose a wireless channel manually.
Bandwidth
In rural areas with little wireless traffic, a larger bandwidth setting may improve wireless
performance significantly. However, if you are in an urban area with much wireless traffic
and interference, a smaller bandwidth is recommended.

20
AOSS/WPS
The following window appears when you click the panel. Click OK to start AOSS/WPS.
USB Storage
Configure USB storage settings here.
Attached Drive The names of USB devices connected to this product.
File Sharing Enable or disable file sharing.
BitTorrent Enable or disable BitTorrent.
DLNA Enable or disable the media server.
WebAccess Enable or disable WebAccess.
BuffaloNAS.com Name This name may contain 3 to 20 alphanumeric characters, hyphens (-), and underscores
(_). The AirStation will be registered by this name at BuffaloNAS.com.
BuffaloNAS.com Status If the status shows Registration failure, check your BuffaloNAS.com settings.
Username The WebAccess username may contain up to 20 alphanumeric characters, hyphens (-),
underscores (_), and periods (.). Don't use a symbol as the first character.
Password
The WebAccess password may contain up to 20 alphanumeric characters, hyphens (-),
underscores (_), and periods (.). It should not be blank. Don't use a symbol as the first
character.
