Build with Robots Breezy Blue Response User manual

D001102 Rev A.1 www.BuildWithRobots.com Page 1
User Manual
Model: Breezy Blue Response (SKU: BBR01)
With Bluetooth® Wireless Technology

D001102 Rev A.1 www.BuildWithRobots.com Page 2
Manufacturer and Contact
Information
Manufacturer: Build With Robots
Address: 429 Commercial Street NE
Albuquerque, NM 87102
For product information, sales, service, and technical support:
https://buildwithrobots.com/
Customer Support Phone: [phone]
Email: [e-mail]
This manual covers model: Breezy Blue Response (BBR01)
SPECIFICATIONS:
Voltage: 110-120 VAC
Watts: 1080 W
Amps: 9.0 A
Hertz: 50-60 Hz

D001102 Rev A.1 www.BuildWithRobots.com Page 3
Safety Symbols
These symbols and terms may appear on the product and in this user
manual:
Refer to the user manual for
warning information to avoid
hazard or personal injury and
prevent damage to device.
Alternating current (AC)
CAUTION
CAUTION indicates an
imminently hazardous situation
which, if not avoided, may result
in minor or moderate injury, or
product damage.
WARNING
WARNING indicates a hazardous
situation which, if not avoided,
could result in death or serious
injury.

D001102 Rev A.1 www.BuildWithRobots.com Page 4
General Safety Summary
Review the following safety precautions to avoid injury and prevent
damage to this product.
To avoid potential hazards or harm, use this product only as
specified.
Failure to comply with the precautions and warnings in this manual
violates the safety standards of the design, and the intended use of
the product. The manufacturer assumes no liability for harm of
persons or damage of property due to the customer’s failure to
comply with these requirements as the protection provided by the
product may be impaired.
To avoid fire or personal injury:
Use proper power cord. Use only the power cord specified for this
product and certified for the country of use.
Do not use the provided power cord for other products.
Ground the product. This product is grounded through the grounding
conductor of the power cord. To avoid electric shock, the grounding
conductor must be connected to earth ground.
Do not disable the power cord grounding connection.
Observe all ratings. To avoid fire or shock hazard, observe all ratings
and markings on the product.
Power disconnect. The power cord disconnects the product from the
power source. See Product Overview for the location. Do not
position equipment so that it is difficult to disconnect the power
cord; it must always remain accessible to the user to allow for quick
disconnection if needed.

D001102 Rev A.1 www.BuildWithRobots.com Page 5
Do not operate without covers. Do not operate this product with
covers or panels removed.
Avoid exposed circuitry. Do not touch exposed connections and
components when power is present.
Do not operate with suspected failures. If you suspect that there is
damage to this product, have it inspected by qualified service
personnel.
Disable the product if it is damaged. Do not use the product if it is
damaged or operates incorrectly. If there is doubt about the safety
of the product, turn it off and disconnect the power cord. Clearly
mark the product to prevent its further operation.
Examine the exterior of the product before use. Look for cracks or
missing pieces.
Do not operate in wet/damp conditions.
Do not operate in an explosive atmosphere.
Do not operate while moving. Breezy Blue is intended to be operated
in a stationary, level position.
Provide a safe working environment. Always place the product in a
location convenient for viewing the button or waist-light status
indicators.
Place the product where it would not be easily overturned.
Use care when lifting and carrying the product. This product is
provided with a handle for lifting and carrying.

D001102 Rev A.1 www.BuildWithRobots.com Page 6
Use only BWR-approved solution in the product. Read and
understand all safety and operational documentation for solution.
Consult the safety data sheet and follow the recommended safety
precautions when handling the solution and fogging.
Stay clear of area being treated while in use. Keep the room,
vehicle, or immediate area to be treated clear of people, animals,
food, etc. while device is in use and the fog is settling.
Avoid excess sound exposure. The device can produce sound levels
greater than 80dBA while fogging. Be sure to wear appropriate
hearing protection as needed and fog areas when there are no
people present.
Keep product surfaces clean and dry.
Provide proper ventilation. To ensure the product functions as
intended, keep the rear of device clear of obstructions.

D001102 Rev A.1 www.BuildWithRobots.com Page 7
Environmental Considerations
This section provides information about the environmental impact of
the product.
Product End-of-Life Handling
Observe the following guidelines when recycling an instrument or
component:
Equipment recycling. Production of this device required the
extraction and use of natural resources. The device may contain
substances that could be harmful to the environment or human
health if improperly handled at the product’s end of life. To avoid
the release of such substances into the environment and to reduce
the use of natural resources, we encourage you to recycle this
product in an appropriate system that will ensure that most of the
materials are reused or recycled appropriately. It is recommended
that this device be taken to a certified Waste Electronic and
Electrical Equipment recycler.
Do not throw in trash at end of product life.

D001102 Rev A.1 www.BuildWithRobots.com Page 8
Contents
Manufacturer and Contact Information............................................................................................ 2
Safety Symbols ......................................................................................................................................... 3
General Safety Summary ...................................................................................................................... 4
Environmental Considerations ............................................................................................................. 7
Preface...................................................................................................................................................... 11
Where to find more information.....................................................................................................11
General Information.............................................................................................................................. 12
Service Information ...........................................................................................................................13
Before Unpacking..............................................................................................................................13
Contents Included:............................................................................................................................13
Getting Started........................................................................................................................................ 15
Operating Requirements .............................................................................................................15
Power Supply Requirements .......................................................................................................16
Cleaning...........................................................................................................................................16
Powering the Device ON and OFF ............................................................................................17
Functions and Operating Descriptions ............................................................................................ 18
Default Factory Settings ...................................................................................................................18
Push Button Operation......................................................................................................................18
BB01-WC Wireless Controller Setup (Not included with Breezy Blue Response).................. 20
Controller navigation overview .................................................................................................20
Connecting to Wi-Fi.......................................................................................................................21
Setting screen timeout (optional)..............................................................................................22
Setting lock screen PIN (optional) ............................................................................................23
Updating Android Kiosk PIN for Wi-Fi and settings (optional) ...........................................24
Log-in.................................................................................................................................................25
Main Screen Overview.................................................................................................................26
Pairing ...............................................................................................................................................27
Unpairing ..........................................................................................................................................28
Status Tab .........................................................................................................................................29
Config Tab........................................................................................................................................30

D001102 Rev A.1 www.BuildWithRobots.com Page 9
Alias Button ......................................................................................................................................30
Duration Button ...............................................................................................................................31
Schedule Button .............................................................................................................................33
Update Tab ......................................................................................................................................36
Remote Controlled Operation........................................................................................................37
Approved BWR Solutions..................................................................................................................38
Fill Port Instructions................................................................................................................................. 38
Filling the Solution Tank from Empty .............................................................................................38
Filling the Solution Tank When Solution Level is Low ................................................................39
Emptying the Solution Tank.............................................................................................................39
Troubleshooting...................................................................................................................................... 40
Maintenance........................................................................................................................................... 41
LIMITED WARRANTY (USA/CANADA)................................................................................................. 42
Keep this user manual in a readily accessible location

D001102 Rev A.1 www.BuildWithRobots.com Page 10
List of Figures
Figure 1: Overview of Breezy Blue Response device. Top/side view (left) and bottom
view (right)...............................................................................................................................................14
Figure 2: Power Breezy Blue Response on and off (electrical inputs) .....................................17
List of Tables
Table 1: General features for Breezy Blue Response ...................................................................12
Table 2: Environmental Specifications for Breezy Blue Response ............................................15
Table 3: Power Specifications for Breezy Blue Response............................................................16
Table 4: States and Status Indicators for Breezy Blue Response...............................................19
Table 5: Breezy Blue Troubleshooting...............................................................................................40
Table 6: Breezy Blue Scheduled Maintenance .............................................................................41

D001102 Rev A.1 www.BuildWithRobots.com Page 11
Preface
This manual describes the setup and operation of Build With Robots
automated fogging technology. The following device is supported
by this manual:
Breezy Blue Response
Where to find more information
Item
Purpose
Location
Safety and
Compliance
Instructions
Safety,
Compliance,
and Basic
Startup
Printed Copy in Box
https://buildwithrobots.com/breezyblue
User Manual
Unpacking,
Installation,
Settings, and
Operation
https://buildwithrobots.com/breezyblue

D001102 Rev A.1 www.BuildWithRobots.com Page 12
General Information
The Build With Robots Breezy Blue™Response is a self-contained,
portable, and remote controlled cold fog dispensing system.
Compatible with Build With Robots approved solutions, Breezy Blue
Response can eliminate dangerous pathogens and organisms.
Breezy Blue also collects and presents data to assure that your space
has been thoroughly and properly treated.
Table 1: General features for Breezy Blue Response
Item
Specification
SKU
BBR01
Approved BWR Solutions
Breezy BioCare RTU™
Settling time
10 minutes (see solution instructions)
Tank capacity
4.7 L (1.25 gal)
Particle Diameter
20 um to 100 um
Fogger
Atomizing Cold fogger, 20 µm to 100 µm
particles
Language
English
Connectivity
Bluetooth®Low Energy v5.2
Remote controller (up to 100
ft.)
Breezy Smart Controller (BB01-WC, sold
separately)
Remote configuration
Status, Fogging Duration, Countdown Duration,
Scheduling, Fluid Level, Alias
Visual indicators
Idle, Fog Countdown, Fogging, Fog Settling,
Disabled
Audible indicator
Fog Countdown
Safety Feature
Fogger disable switch
User controls (via push
button)
Delayed Turn-On or Immediate Off
AC power
110-120VAC / 50-60 Hz, 9.0A (while fogging)
Size and Weight
Diameter - 31.8 cm (12.5 in), Height - 41.9 cm
(16.5 in), Weight - 10.9kg (24 lbs.) full of fluid
Portability
Handle for carrying and cord wrap

D001102 Rev A.1 www.BuildWithRobots.com Page 13
Service Information
The product contains no serviceable parts and should not be
disassembled, repaired, or modified by anyone other than the
manufacturer or approved technicians.
Before Unpacking
Inspect the package carton for external damage. If the carton is
damaged, notify the carrier.
Remove the device from its package and check that it has not
been damaged in transit. Verify that the carton contains the device
and contents listed below.
Contents Included:
•1 x Safety and Compliance Instructions (printed)
•1 x AC power cord
•1 x Breezy Blue Response
The appearance or components of the product may differ
depending on the model. If anything is missing, please contact Build
With Robots.

D001102 Rev A.1 www.BuildWithRobots.com Page 14
Product Overview
Figure 1: Overview of Breezy Blue Response device. Top/side view (left) and
bottom view (right).
1. Fog outlet
2. Handle
3. Fogger enable/disable button
4. Fill port cap
5. Status lights (waist and button)
6. Power connector
7. Air intake

D001102 Rev A.1 www.BuildWithRobots.com Page 15
Getting Started
Operating Requirements
Install the device in a location meeting the following guidelines:
•Rear clearance: 5 cm (2 inches) or greater
•Recommended Height from ceiling: 1.2 m (4 feet) or greater
•Place device on a solid, level surface or cart
•Device is not meant to be operated while moving
•Install equipment so that power cord is easily accessible
Table 2: Environmental Specifications for Breezy Blue Response
Product Specification
Description
SKU
BBR01
Electrical Phase
Single
Installation Location
Indoor
Temperature
Operating: 5 °C to 40 °C
Storage: 5 °C to 60 °C
Humidity
Operating: ≤80% RH: 31 °C
Storage: ≤80% RH: 31 °C
Altitude
Operating: ≤ 3000 m (9,843 ft)
Storage: ≤ 12,000 m (39,370 ft)
Flow Rate
About 13.6 L (3.6 gal) per hour of
fogging
Fuse Rating
AC250V, 10A, slow blow
Sound
Up to 116dBA while fogging
Specifications are subject to change without notice.

D001102 Rev A.1 www.BuildWithRobots.com Page 16
Power Supply Requirements
WARNING. To reduce the risk of fire and shock, ensure that the main
supply voltage fluctuations don’t exceed 10% of the operating
voltage range.
Table 3: Power Specifications for Breezy Blue Response
AC Input
110-120 VAC (+/- 10%), CAT II
Frequency
50/60Hz (+/- 5%)
Power
1080 W
WARNING. This product is grounded through the grounding
conductor of the power cord. To avoid electric shock, the grounding
conductor must be connected to earth ground.
WARNING. Do not disable the power cord grounding connection.
Without the safety ground connection, all accessible conductive
parts may provide an electric shock. Failure to use a properly
grounded approved outlet and the included three-conductor AC
line power cable may result in injury or death.
Cleaning
Inspect the device as often as operating conditions require. To clean
the exterior surface, perform the following steps:
1. Unplug the device to power off.
2. Remove loose dust on the outside of the device with a lint free
cloth.
3. Use a soft cloth dampened with water to clean the device. Use
an aqueous solution of 70% isopropyl alcohol for more efficient
cleaning.
4. Inspect the air intake slots and clean as needed using a
vacuum or soft brush.

D001102 Rev A.1 www.BuildWithRobots.com Page 17
CAUTION. To avoid surface damage to the device, do not use any
abrasive or chemical cleaning agents.
CAUTION. Avoid getting moisture inside the device during external
cleaning. Use only enough water/cleaning solution to dampen the
cloth or swab.
Powering the Device ON and OFF
Figure 2: Power Breezy Blue Response on and off (electrical inputs)
The following instructions show how to apply power to the device
and turn it on and off. Refer to Figure 1 and 2.
1. Power On. Connect the power cord to the underside of the unit
and to an electrical outlet. The waist status light will turn either
blue or yellow, indicating that the device is powered on.
2. Power Off. Disconnect the power cord from the underside of
the unit or from the electrical outlet to power off.

D001102 Rev A.1 www.BuildWithRobots.com Page 18
Functions and Operating
Descriptions
Below are the default settings and instructions for using the unit
without the use of a wireless controller (sold separately). The unit will
provide the user visual and audio status using the mechanisms
shown in Table 4. Also see Fill Port Instructions –Filling the Solution
Tank when Low for more information.
Default Factory Settings
•Push-button mode ENABLED
•Countdown duration: 20 seconds
•Fogging duration: 30 seconds
•Settling duration: 10 minutes
•Alias: serial number
Push Button Operation
(Refer to Figure 1.)
1. Depress the fogger enable button (if already depressed, press
two times).
a. A 20 second countdown to fogging will begin,
accompanied by flashing red status lights and an audible
alert on Breezy Blue during which the area being treated
must be cleared of all people, animals, etc.
b. A 30 second fogging will begin when the status lights turn
solid red, and the fogger motor turns on.
c. After fogging is complete, the lower status lights will flash
yellow to indicate the fog settling phase for 10 minutes.
d. After the settling is complete the lower status light will turn
blue, and the area can be opened for fresh air
circulation.

D001102 Rev A.1 www.BuildWithRobots.com Page 19
Table 4: States and Status Indicators for Breezy Blue Response
Status
LED Ring
Button
LEDs
Audio
Status
Icon
Breezy
Controller
Icon
Out of Range
of Controller
or Off
Any
option
below or
Off
Any
Option
below
Device
Not
Found
During
Connection
to controller
Any
option
below
Any
Option
below
Not
Detected
Idle +
Enabled
Blue
Off
Ready to
Fog
Idle +
Disabled
Yellow
Yellow
Disabled
Fogging
Countdown
Red,
blinking
Red,
blinking
[Beep]
“Alert,
disinfectant
fogging will
begin soon.
Please leave
the area or
press the
disable
button.”
Fog in 8
sec
Fogging
Red
Red
Fogging
for 5, 15,
30, 45 sec
Fog Settling
Yellow,
blinking
Off
Settling
for
10 min
Firmware
updating
White
Off
Progress
bar
Error
White,
blinking
Off
Error

D001102 Rev A.1 www.BuildWithRobots.com Page 20
BB01-WC Wireless Controller Setup
(Not included with Breezy Blue
Response)
It is recommended that you charge the controller fully before use.
Controller navigation overview
Basic controls are the same as an Android phone.
1. The Home button is located at the center-bottom of the screen
(left picture above).
2. The App overview button is located at the right-bottom of the
screen (right picture above). This button can be used to close
the Breezy Blue app if problems are encountered.
