Burkert 0911 User manual

Operating Instructions
Bedienungsanleitung
Instructions de Service
Type 0911
3-stage controller
3-Punkt-Regler
3 Régulateur ponctuel
Id. No. 788 271
788 272
788 273
788 274

We reserve the right to make technical changes without notice.
Technische Änderungen vorbehalten.
Sous resérve de modification techniques.
© 2004 Bürkert Werke GmbH & Co. KG
Operating Instructions 0207/05_EU-ml_00804598

0911 - 1
1 GENERAL INFORMATION ........................................................................................................................ 2
1.1 Symbols ......................................................................................................................................................... 2
1.2 Safety notes ................................................................................................................................................ 2
1.3 Scope of delivery...................................................................................................................................... 3
1.4 Warranty provisions ............................................................................................................................... 3
2 SYSTEM DESCRIPTION ............................................................................................................................ 4
2.1 General description ................................................................................................................................. 4
2.2 Operation ...................................................................................................................................................... 4
2.3 Before the installation ............................................................................................................................. 7
2.4 SOFT-Start function ................................................................................................................................8
2.5 Proportional control ................................................................................................................................. 9
2.6 Parameters ................................................................................................................................................ 10
2.7 Controlling the loads ........................................................................................................................... 15
3 TECHNICAL DATA ................................................................................................................................... 16
4 ASSEMBLY, INSTALLATION AND COMMISSIONING .......................................................... 17
4.1 General information regarding the installation and operation ......................................... 17
4.2 Assembly .................................................................................................................................................... 17
4.3 Electrical connections .......................................................................................................................... 18
5 HOT-KEY FUNCTION ............................................................................................................................. 20
6 FACTORY SETTINGS ............................................................................................................................ 21
7 MAINTENANCE .......................................................................................................................................... 23
8 REPAIRWORK .............................................................................................................................................. 24
8.1 Faults ............................................................................................................................................................. 24
8.2 Ordering table for basic unit/accessories ................................................................................ 25
3-STAGE CONTROLLER
TYPE 0911

2 - 0911
english
Please observe the notes in these operating instructions together with the
conditions of use and permitted data that are specified in the data sheets of
the 0911 controller, so that the device will function perfectly and will have a
long service life.
• Keep to the standard engineering rules when planning and operating the
device!
• Installation and maintenance work may only be carried out by specialist
personnel using the correct tools!
• Observe the current regulations on accident prevention and the safety
regulations for electrical devices during the operation and maintenance of
the device!
• Comply with the intended usage of the device.
• Only operate the device with its housing fitted.
• Before connecting the device, check that the power supply corresponds to
the values printed on the device.
• Check that the connections are correct before switching on the device.
• Pay attention to the maximum load of the relay contacts (see Technical
data).
• Ensure that all sensors are installed with sufficient separation from voltage-
conducting lines. This will avoid incorrect temperature readings and will
protect the device from voltage interference at the sensor inputs.
• For applications in the industrial sector with critical environments, switch
an RC element in parallel (FT1).
• Always switch off the mains supply before carrying out manipulations on
the system.
• Take suitable measures to exclude unintended operation and damage by
unauthorised operation!
The following symbols are used in these operating instructions:
marks a work step that must be carried out.
ATTENTION! indicates information which, if ignored, could lead to a risk to
your health or to the functionality of the device.
NOTE indicates important additional information,
tips and recommendations.

0911 - 3
english
1.3 Scope of delivery
1.4 Warranty provisions
Bürkert provideds a guarantee of one year on the correct functioning of the
controller, under the precondition that the device is employed for its intended
use and under compliance with the specified conditions for use.
If the functions of the device are not in order, the respective device will be
repaired free of charge or will be replaced.
ATTENTION! The warranty only covers the the controller and its compo-
nents, but does not cover consequential damage of any kind
that could arise from the failure or malfunctioning of the device.
• Please observe the prescribed environmental conditions with regard to
dampness and temperature limits. Malfunctions cannot be excluded if these
conditions are not complied with.
• Call in your authorised Bürket sales centre in case of doubt or faulty
functioning.
In the case of the non-observance of these notes or of unauthorised
manipulation of the device, we will accept no liability, and the guarantee on the
device and its accessories will become void!
Immediately after receiving the delivery, ensure that the contents agree with
the scope of the delivery. This includes:
• 1 Type 0911 controller
• 1 set of operating instructions (where required, on a data carrier)
• 1 front seal
• 2 Mounting clamps
Please contact us immediately in the event of discrepancies.
Germany
Contact Adress:
Bürkert Fluid Control Systems
Sales Center
Chr.-Bürkert-Str. 13-17
D-74653 Ingelngen
Tel. : 07940 - 10 111
Fax: 07940 - 10 448
E-mail: [email protected]
International
Contact adresses are found on the final pages of this operating manual.
You can also find information on the Internet under:
www.buerkert.com Bürkert Company Locations

4 - 0911
english
3-point or PID controller on Output 1, 74 x 32 mm, with predefinable control
function (e.g., heating/cooling or moisten/dehumidify)
The following models are available:
2.1 General description
2 SYSTEM DESCRIPTION
2.2 Operation
BUTTONS
SET1 Display of Set-value 1
Changing and confirming a default during the programming phase
SET2 Display of Set-value 2
Type Configurable Input Parameter UDM
(Defined by display unit)
TU
Temperature
controller
PTC, NTC, Pt100
Thermoelements J, K, S
UDM = °C
UDM = °F
AU
Control device with
current / voltage
input
4 ... 20 mA
0 ... 1 V
0 ... 10 V
0 = °C; 1 = °F
2 = % RH
3 = bar
4 = PSI
5 = without units
up-
wards
down-
wards
LED 2
SET
button
ES LED
LED1
Alarm
LED
Output
LEDs

0911 - 5
english
LED Mode Meaning
on Output 1 active
on Output 2 active
LED1 blinks Programming level (blinks together with LED2)
LED2 blinks Programming level (blinks together with LED1)
E.S. on Energy-saving mode (second set-value) has
been activated by the digital input
Alarm
LED on
- Signals an Alarm state
- If you are in the lower programming level
"Pr2", which can only be accessed using
a password, the lighting up of the Alarm LED
signals that the displayed parameters can
also be accessed in the first level "Pr1"
(without password).
LED MESSAGES
BUTTON COMBINATIONS
Locking and unlocking the keypad
SET1+ Selecting the programming level
SET1+ Return to the room temperature display
+
DISPLAYING THE SET VALUE
Briefly press the SET button once. The set-value
display appears in the display.
Briefly press the SET button again, or wait 5
seconds in order to display the room temperature.
SWITCH DEVICE ON/OFF
Hold down the SET1 button for at least 4 seconds
(only for parameter OnF = yes).

6 - 0911
english
ENTER PROGRAMMING LEVEL
Hold down the SET1 + button for at least 3
seconds.
Select with Pr2 and then confirm with the SET1
button.
Enter the password 321 and then confirm with the
SET1 button.
Enter the „3“ and then 1 x SET1 button
Enter the „2“, and then 1 x the SET1 button
Enter the „2“, and then 1 x the SET1 button
You are now in the Parameter List.
USER LEVEL PR1
Hold down the SET1 + button for at least 3
seconds. PR1 contains all the parameters that can
be accessed by the user. The device shows the first
parameter that is available in the user level.
SERVICE LEVEL PR2 (PASSWORD 321)
See: Accessing the programming level
ADDING/REMOVING PARAMETERS INTHE USER LEVEL PR1
Accessing the programming level
The status can be changed with the SET1 +
buttons.
If a parameter is not visible in the PR1 level, this will
be indicated by an LED point.
CHANGING SET-VALUE 1 / SET-VALUE 2
Hold down the SET button for 2 seconds.
Change the set-value within 10 s with the or
buttons.
You can save the new set-value by briefly pressing
the SET button or by waiting 10 seconds.

0911 - 7
english
2.3 Before the installation
PREDEFINE THE SENSOR TYPE
Hold down the SET + button for at least 3
seconds.
Select the parameter Pbc (sensor type) and then
confirm with the SET button to see the current
default.
Type TU (temperature controller):
J = Thermoelement J; Pt = Pt100;
K = Thermoelement K; Ptc = PTC;
S = Thermoelement S; ntc = NTC
Type AU
(control devices with current/voltage input):
cur = 4...20 mA; 0-1 = 0...1 V; 10 = 0...10 V
Confirm the default with the SET button.
Briefly switch off the power to the device.
The configurable input type is noted on the controller
label. Enter this input type if it corresponds to the
connected sensor type.
LOCKING AND UNLOCKING THE KEYPAD
Hold down the buttons and for at least 3
seconds. The message POF appears on the
display. The keyboard is locked. You can only
view the set-value and the minimum and maximum
temperature. The POF message also appears if
you hold down a button for longer than 3 s.
The keyboard will be unlocked if you hold
down the buttons and for 3 s. POn appears
in the display for a few seconds.
CHANGINGTHE DEFAULT PARAMETERS
Enter a desired value with SET + or .
Then confirm with the SET button.
Enter a desired parameter with or .
NOTE All parameter values can be seen by repeatedly pressing the
SET buttons.

8 - 0911
english
Sensor Lower limit Upper limit
NTC -40 °C 110 °C
PTC -50 °C 150 °C
Pt100 -200 °C 600 °C
TcK 0 °C 1300 °C
TcJ 0 °C 600 °C
TcS 0 °C 1400 °C
MEASUREMENT LIMITS FOR THE SENSOR TYPES
2.4 SOFT-Start function
dSI = Increase the set-value in steps (in °C or °F; deactivated with 0).
dSt = Cycle time for the step-by-step increase of the set-value
(1...3600 sec).
drb = Increasing the set-value (in °C or °F); the function is deactivated with
drb = 0. This value determines the set-value increase in steps in Kelvin
or °F.
drb Soft-Start range (in °C or °F; deactivated with 0). If the temperature
is outside this range (on both sides of the set-value),
a new SOFT-Start will be initiated.
dSI Dynamic set-value increase (in °C or °F; deactivated with 0). This
value determines the step-by-step increase of the set-value of SET1.
dSt Clock time for the dynamic set-value increase (1...999 sec) or dSl
(SOFT-Start).
Ta = Measured temperature after device commissioning.
t = Time axis.

0911 - 9
english
Starting from the measured temperature Ta, the set-value is increased in steps
by dSl, but the SOFT-Start will only begin when Ta is outside the drb range:
Dynamic set-value = Ta + dSI
The clock time indicates with dSt when the dynamic set-value is increased by
dSl.
The dynamic set-value is set to Set-value 1 if the amount dynamic
set-value - Set-value < drb:
If | current dynamic set-value - set-value 1 | > drb,
automatic default: Dynamic set-value = Set-value 1
The SOFT-Start is ended.
If the measured temperature of the belt exceeds or falls below drb, the SOFT-
Start starts again.
2.5 Proportional control
In the case of unsatisfactory controller results with factory parameters, we
recommend that you proceed as follows:
1. Enter the switch hysterisis mode for Output 1 (Ft = 0)
2. Set Set-value 1 to a value that will not endanger the installation though
excessive vibration, e.g., 10% below working temperature.
3. Set the switch hysterisis setting Par. Hy1) to 3 % of the working
temperature (Set-value 1).
4. Start the system and wait until the vibration remains constant.
5. Evaluate (poss. using a plotter) the values Tp and dT
(see diagram)
6. Calculate the parameters Pb, Int, dEt, Cyt from these values -
as follows:
Pb = 2 x dT
Int = Tp / 2
dEt = Tp / 8
Cyt = Tp / 20

10 - 0911
english
2.6 Parameters
Explanation of the PID components:
• The proportional components act on changes within the band around
the set-value.
• The differential components influence the speed of temperature
changes.
• The integral components adds together all surfaces (time x tempe-
rature), that arise from the deviation of the actual value from the set-
value. The greater the deviation, the higher the effect.
NOTE • An increase of the proportional range results in a larger
remaining control deviation between the set-value and the
actual value.
• A significant reduction of the proportional range reduces
the control deviation, although the control behaviour will
become less stable.
• The derivative action time (differential time) affects the
output dependent on the speed of the temperature change.
An increase of the drivative action time reduces the
vibration tendency after system stabilisation, but can
generate higher vibration with larger deviations, however.
• An reduction of the integral range increases the effect
on the deviation between the set-value and the actual
value.
Control
Hy1 Hysteresis 1 Switch hysteresis of Set-value 1 with
positive or negative values. The default
range is dependent on the input type.
The parameter may not be entered as
zero. The control function is predefined
with S1C.
Hysteresis 2 Switch hysteresis of Set-value 2 with
positive or negative values (as Hy1).
The control function is predefined with
S2C.
Control type onF = ON/OFF db = not predefined!
Pid = PID; tt = not predefined!
Lowest set-value setting Set-value limits 1 for operator
Lowest set-value setting Set-value limits 2 for operator

0911 - 11
english
Control
US1 Highest set-value setting Set-value limits 1 for operator
US2 Highest set-value setting Set-value limits 2 for operator
S1C Control function 1 in = inverted (Heating, humidifying)
dir = direct (cooling, dehumidifying)
S2C Control function 2 in = inverted (heating, humidifying)
dir = direct (cooling, dehumidifying)
AC Minimum switch-off period 0 ... 250 sec relay switch-off period
ouc Dependency of the diP = dependent (SET2 = SET1 + SET2)
set-values ind = independent
on Minimum switch-on period 0...250 sec relay switch-on period
ono Minimum delay 0...120 min; minimum delay between two
activations of the control relay.
Alarms
ALC Configuration rE = relative to the set-value (in Kelvin)
Temperature alarm Ab = absolute values (in °C)
ALL Low temperature alarm If SET - ALL undershot, a low tempe-
rature alarm will be triggered after the
delay time ALd.
ALU Over-temperature alarm If SET + ALU exceeded, a high tempe-
rature alarm will be triggered after delay
time ALd.
ALH Hysteresis for the Automatic alarm acknowledgement:
Limit value alarms For high alarm, undershooting of
ALL and ALU ALU - ALH and low alarm for exceeding
ALL + ALH
ALd Alarm delay Minimum time in which the conditions for
at temperature over/ Alarm situation must be present.
Undershoot (0...999 min)
dAO Alarm delay at for Suppression of alarms after
mains ON (0...23.5 h) Commissioning
So1 Status of the control relay oFF = opened
with sensor fault on = closed
So2 S Status of the control relay oFF = opened
with sensor fault on = closed

12 - 0911
english
Alarms
tbA Status of the control relay oFF = Relay deactivated
after acknowledgement on = Relay activated
(any button) in any
alarms ituation
AS Configuration of the alarm cL = Terminal 5-6 closed
relay at an alarm oP = Terminal 5-6 closed
Measured value display
LCI Lower analog Lower display value at current input
Display value 4 mA or at voltage input 0 V
(-1999...1999) (only for the inputs 0-20 mA, 0-1V,
0-10 V)
UCI Upper analog Upper display value at current input
display value 20 mA or at voltage input 1 V or 10 V
(-1999...1999) (only for the inputs 0-20 mA, 0-1V,
0-10 V)
rES Resolution Selecting display resolution
in = integer (-99...+199)
dEC = 1 decimal point (-99.0...199.0)
cE = 2 digits after the decimal point
(-99.00...199.00)1,2
irE = large measuring range
(-999...1999)1,2
UdM Units Display of the units directly in the
illuminated display. Regardless of which
controller type is being used:
see General description
PbC Type of sensor Type of inout
Temperature sensor U): J = Thermoelement „J“; Pt = Pt100;
C = Thermoelement „K“; Ptc = PTC;
S = Thermoelement „S“; ntc = NTC
Current / voltage input cur = 4...20 mA; 0-1 = 0...1 V;
(AU) 10 = 0...10 V
1
Only for devices with an input of 4...20 mA or 0...1 V or 0...10 V
2
Only for current or voltage input
ATTENTION! If rES is changed at a later time, the following parameters must
be checked::
SET, Hy1, LS1, uS1, ALL, ALu, ALH, LCi, uCi, LAo, uAo, HES
NOTE Selecting a decimal point is not possible for thermocouples.

0911 - 13
english
Measured value display
OPb calibration of the sensor regardless of the measurement range
P3F Third terminal of a no = Pt100 2-conductor wired
Pt100 sensor yES = Pt100 3-conductor wired
(if present)
Digital inputs
HES Temperature increase/ Set-value is increased/lowered by HES
Reduction during the energy saving phase.
Activation via digital input
(i1F = Es).
i1F Function of the digital EAL = external alarm; OFF = unused;
Input bAL = serious external alarm;
Es = Energy saving mode Start/Stop;
onF = switch the device ON/OFF
externally;
C-H = reverse the control effect
i1P Polarity of the digital CL: active with closed contact
input OP: active with opened contact
did Alarm delay time For i1F = EAL or i1F = bAL.
of the digital input The corresponding alarm then takes
(0...120 min) place display or message.
Miscellaneous
Adr Serial address RS485 Address for XJ500 recording
(1...247) system. Identifies the device if it
is linked into a ModBUS-compatible
system.
OnF Set device to STAND-BY no = not possible via keyboard
yes = STAND-BY can be activated by
holding down the SET button for at least
4 sec. If you want to change the set-
value, hold down the SET button for 2
sec.
Ptb Number of the parameter- only read-out value
table
rEL Version only read-out value
Pr2 Display of the parameters
in Level Pr2 display only

14 - 0911
english
PID control (only Output 1 at Ft = PID)
Pb Proportional range Preset possibility only for Set-value 1
(°C or °F) which affects the first control output.
This value determines the bandwidth
(on both sides of the set-value) that
exist within the proportional control.
int integral action time Determines the integral behaviour of the
(0...999 sec) controller. The greater the deviation,
the higher the effect.
dEt Derivative action time Determines the differential behaviour of
(0...999 sec) the controller. The greater the deviation,
the higher the effect.
Sr Measurement rate Time between 2 consecutive
(1...10 sec) following measurements for the
calculation of dt. A smaller value
increases the response time.
rS Manual Reset With this parameter, the proporti-
(°C or °F) onal control deviation can be moved up /
down. The value will be defined as the
same amount, but in the opposite
direction to the deviation detected.
Ar Integralband Range (on both sides of the set-value)
(°C oder °F) within which the integral action time is
effective. The higher the value,
the greater the effect.
Cyt Zykluszeit Minimum time during which the out-
(1...500 sec) put relay is switched on and off.
drb Soft-start band If the temperature is outside the band
(°C oder °F) (on both sides of the set-value), a new
Soft-Start will be initiated.
(0 = deactivated)
dSi Dynamic set-value This value determines the stepwise
control (°C or °F) set-value increase from SET1.
(0 = deactivated)
dSt Clock time for dynamic clock time for dynamic set-value-
set-value cpntrol control with regard to dSi (SOFT-Start).
(1...999 sec)
NOTE You can access hidden parameters by holding down the
buttons SET + for 3 seconds in the programming level HY.
The message Pr2 appears.

0911 - 15
english
HEATING
Parameter S1C = in; The value HY has been preset to 2 K in the factory.
If the temperature falls below the value SET-HY, the controller output will be
switched on and will be switched off again when SET is exceeded.
2.7 Controlling the loads
CONTROLLER OUTPUT
The control is dependent on the measurement temperature (= sensor
temperature). Program the control direction (heating or cooling) with the
parameters S1C and S2C.
S1C = dir Cooling SET = Set-value
S1C = in Heating Hy = Switch hysterisis
COOLING
Parameter S1C = dir; The value HY has been preset to 2K in the factory.
If the temperature exceeds the value SET + HY, the compressor is switched on
and will be switched off again when the temperature falls below SET.
t
temperature
compressor
SET
SET+HY
ON
t
ON
t
t
temperature
SET
SET-HY
heat

16 - 0911
english
3 TECHNICAL DATA
• Housing ABS, self-extinguishing
• Dimensions Front 74 x 32 mm, Depth 60 mm
• Assembly Panel-mounting unit for 29 x 71 mm cutout
• Protection class IP65 from front, only with front seal RG-C
IP20
• Connections Screw terminals
• Pipe cross-section ≤2.5 mm2
• Auxiliary energy depending on model
12...24 V AC/DC; ±10%
230 V AC; ±10%; 50/60 Hz
optional 110 V AC; ±10%; 50/60 Hz
• Power consumption max. 3 VA
• Display three digits, red LED, height 12 mm
• Inputs configurable NTC / PTC or
NTC / PTC / Pt100 / Thermoelement J, K, S
or 4...20 mA / 0...1 V / 0...10 V
• Relay outputs 2 x NO 8(3) A, 250 V AC + 1 x NC
• Other outputs acoustic alarm (optional)
• Data memory EEPROM
• Ambient temperature 0 ... +60°C / +32 ... +140°F
• Storage temperature -30 ... +85°C / -22 ... +185°F
• Air humidity 20 ... 85% (non-condensing)
• Measurement range according to sensor
• Resolution 0.1°C or 1°F
• Accuracy at + 25 °C better than 0.5% of the measurement range

0911 - 17
english
4 ASSEMBLY,INSTALLATION AND COMMISSIONING
4.1 General information regarding the installation and operation
ATTENTION! • Do not lay cables for inputs next to lines carrying voltage.
• Avoid heavy vibrations, aggressive gases, heavy soiling
and damp.
NOTE • Before connecting the device, check that the power supply
corresponds to the values shown on the rating plate.
• Observe the maximum loading of the relay contacts (see
Technical data ).
• Ensure that you install all sensors with sufficient separation
from lines carrying voltage, in order to avoid incorrect
temperature measurements and to protect the device from
voltage interference over the sensor inputs.
Panel Mounting bracket
4.2 Assembly
The device is designed for panel mounting in a cutout of 71 x 29 mm, and is
secured with mounting brackets.
In order to ensure the IP65 front protection, a rubber seal must be fitted begind
the front frame (optional with RG-C).
The ambient temperature for trouble-free operetion is in the range from
0 ... +60°C.
Ensure sufficient ventilation through the cooling slots.

18 - 0911
english
Panel Mounting bracket
Front seal
4.3 Electrical connections
Use cable with a cross-section of max. 2.5 mm2. The device is provided
with the corresponding screw terminals.
Check the auxiliary power before connection the voltage supply
(see Chapter Technical data ).
Do not load the relay contacts higher than permitted. If necessary, use a
contactor.
