Burkert 8756 BATCH User manual

Type 8756 BATCH
büS / CANopen
Mass Flow Controller for the dosing of liquids
Operating Instructions

We reserve the right to make technical changes without notice.
© Bürkert SAS, 2021 - 2023
Operating Instructions 2301/02_EU-ML 00572214 / Original EN

Type 8756 BATCH
Table of contents
3
TABLE OF CONTENTS
1 About this document..................................................................................................................................6
1.1 Manufacturer .................................................................................................................................... 6
1.2 Used symbols................................................................................................................................... 6
1.3 Terms and abbreviations .................................................................................................................. 7
2 Safety instructions......................................................................................................................................8
2.1 Intended use..................................................................................................................................... 8
2.2 Safety................................................................................................................................................ 8
3 Product description..................................................................................................................................10
3.1 Design............................................................................................................................................. 10
3.2 Product identification ..................................................................................................................... 12
3.2.1 Type label...........................................................................................................................12
3.2.2 Calibration label .................................................................................................................12
3.2.3 Conformity marking ...........................................................................................................12
3.3 Status indicator .............................................................................................................................. 13
3.4 Memory card .................................................................................................................................. 14
3.5 Functionality ................................................................................................................................... 14
3.5.1 Actuator is an on/off valve .................................................................................................14
3.5.2 Customised actuator .........................................................................................................14
3.5.3 Service life of the on/off valve............................................................................................14
4 Technical data ..........................................................................................................................................15
4.1 Standards and Directives ............................................................................................................... 15
4.2 Operating conditions ...................................................................................................................... 15
4.3 Fluidic data ..................................................................................................................................... 15
4.3.1 MFC with on/off valve ........................................................................................................15
4.3.2 Dosing volume range - MFC with on/off valve ..................................................................17
4.4 Electrical data ................................................................................................................................. 18
4.5 Mechanical data ............................................................................................................................. 18
5 Fluid connection .......................................................................................................................................20
5.1 Safety instructions .......................................................................................................................... 20
5.2 Possible fluid connections.............................................................................................................. 21
5.3 Installation procedure ..................................................................................................................... 21
5.3.1 G1/8''-internal-threaded fluid connections........................................................................21
5.3.2 NPT1/8''-internal-threaded fluid connections ...................................................................21
5.3.3 Fluid connections with external-threaded vacuum fittings................................................22
5.3.4 Fluid connections with external-threaded compression fittings........................................22
6 Electrical connection................................................................................................................................23
6.1 Safety instructions .......................................................................................................................... 23
6.2 Additional documentation .............................................................................................................. 23
6.3 Wire the product variant büS /CANopen........................................................................................ 24
6.3.1 With büS extension cables from Bürkert ...........................................................................24
6.3.2 With büS cables from Bürkert............................................................................................24

Type 8756 BATCH
Table of contents
4
6.3.3 With CANopen cables........................................................................................................25
6.4 Connect the functional earth .......................................................................................................... 26
7 Commissioning.........................................................................................................................................27
7.1 Safety instructions .......................................................................................................................... 27
7.2 Commissioning procedure (MFC with on/off valve) ....................................................................... 27
8 Setting and operation...............................................................................................................................29
8.1 Safety instructions .......................................................................................................................... 29
8.2 Dosing types................................................................................................................................... 30
8.2.1 Quantity based dosing.......................................................................................................30
8.2.2 Time based dosing ............................................................................................................30
8.2.3 Start the dosings................................................................................................................30
8.2.4 Cyclic data (PDOs).............................................................................................................31
8.3 Functions ........................................................................................................................................ 34
8.3.1 Bubble detection................................................................................................................34
8.3.2 Flush bubbles from the pipe (MFC with on/off valve) ........................................................34
8.3.3 Leakage detection .............................................................................................................35
8.3.4 Detect the end of dosings..................................................................................................35
8.3.5 Configure the controller .....................................................................................................36
8.4 Setting tools.................................................................................................................................... 36
8.5 Connect the product to the Bürkert Communicator software........................................................ 36
8.5.1 Product variant büS /CANopen .........................................................................................36
8.6 Settings specific to the product variant büS/CANopen ................................................................. 37
8.6.1 Set the CANopen communication or the büS communication..........................................37
8.7 Transmission speeds of cyclic data ............................................................................................... 38
8.7.1 Change the transmission speed of a single PDO ..............................................................38
8.7.2 Temporarily increase the transmission speed of all PDOs ................................................38
9 Maintenance .............................................................................................................................................39
9.1 Safety instructions .......................................................................................................................... 39
9.2 Replace the memory card .............................................................................................................. 40
9.3 Replace the on/off valve Type 6013 ............................................................................................... 40
9.4 Replace the on/off valve Type 6724 ............................................................................................... 41
10 Troubleshooting .......................................................................................................................................43
10.1 Problems shown by the PDO3, Error ID ......................................................................................... 43
10.2 Status indicator is red..................................................................................................................... 43
10.3 Status indicator is orange............................................................................................................... 44
10.4 Status indicator is yellow................................................................................................................ 44
10.5 Status indicator is blue ................................................................................................................... 45
10.6 Status indicator is off...................................................................................................................... 45
10.7 Status indicator flashes .................................................................................................................. 45
10.8 Status indicator goes out periodically ............................................................................................ 46
10.9 Replacement product adopts none of the values from the defective product............................... 46
10.10 Replacement product does not adopt all of the values from the defective product...................... 46

Type 8756 BATCH
Table of contents
5
10.11 Unstable measured value ............................................................................................................... 46
10.12 Outgassing or bubble formation at the product outlet ................................................................... 47
10.13 Dosing quantity cannot be reached ............................................................................................... 47
10.14 Quantity is not dosed precisely ...................................................................................................... 48
10.15 Drippling ......................................................................................................................................... 48
11 Spare parts and accessories ...................................................................................................................49
11.1 Electrical accessories ..................................................................................................................... 49
11.2 Additional software......................................................................................................................... 49
12 Uninstallation ............................................................................................................................................50
12.1 Safety instructions .......................................................................................................................... 50
12.2 Dismantling..................................................................................................................................... 50
13 Logistic .....................................................................................................................................................52
13.1 Transport ........................................................................................................................................ 52
13.2 Storage ........................................................................................................................................... 52
13.3 Return ............................................................................................................................................. 52
13.4 Disposal .......................................................................................................................................... 52

Type 8756 BATCH
About this document
6
1 ABOUT THIS DOCUMENT
The document is an important part of the product and guides the user to safe installation and operation.
The information and instructions in this document are binding for the use of the product.
Before using the product for the first time, read and observe the whole safety chapter.
Before starting any work on the product, read and observe the respective sections of the document.
Keep the document available for reference and give it to the next user.
Contact the Bürkert sales office for any questions.
Further information concerning the product at country.burkert.com.
1.1 Manufacturer
Bürkert Fluid Control Systems
Christian-Bürkert-Str. 13−17
D-74653 Ingelfingen
The contact addresses are available at country.burkert.com in the menu Contact.
1.2 Used symbols
DANGER!
Warns of a danger that leads to death or serious injuries.
WARNING!
Warns of a danger that can lead to death or serious injuries.
CAUTION!
Warns of a danger that can lead to minor injuries.
NOTICE!
Warns of property damage that can damage the product or the installation.
Indicates important additional information, tips and recommendations.
Refers to information in this document or in other documents.
Indicates a step to be carried out.
Indicates a result.
Menu Indicates a software user-interface text.

Type 8756 BATCH
About this document
7
1.3 Terms and abbreviations
The terms and abbreviations are used in this document to refer to following definitions.
Device / Product Type 8756 BATCH
MFC Mass Flow Controller
büS Bürkert system bus, a communication bus developed by Bürkert and based on the
CANopen protocol

Type 8756 BATCH
Safety instructions
8
2 SAFETY INSTRUCTIONS
2.1 Intended use
The MFC Type8756 BATCH is designed to measure the mass flow rate of liquids and dose liquids.
The permitted media are listed in Technical data [}15]
Only trained and qualified personnel may install, operate and maintain the device. See qualification of
persons in Safety [}8]
Use the device only in conjunction with third-party devices and components recommended and author-
ized by Bürkert.
Use the device only when it is in perfect condition.
Only use the device indoors.
Prerequisites for safe and trouble-free operation are correct proper transportation, storage, installation,
start-up, operation and maintenance.
The instructions are part of the device. The device is intended exclusively for use within the scope of these
instructions. Uses of the device that are not described in these instructions, the contractual documents or
the type label can lead to severe personal injury or death, damage to the device or property and dangers for
the surrounding area or the environment.
2.2 Safety
Qualification of personnel working with the device
Improper use of the device can lead to serious personal injury or death. To avoid accidents when working
with the device, the following minimum requirements must be met:
Carry out work on the device within the scope of these instructions in a safety-compliant manner.
Detect and avoid dangers when working on the device.
Understand the instructions and implement the information contained therein accordingly.
Responsibility of the operator
The operator is responsible for observing the location-specific safety regulations, also in relation to person-
nel.
Observe the general rules of technology.
Install the device according to the regulations applicable in the respective country.
The operator must make hazards arising from the location of the device avoidable by providing appropri-
ate operating instructions.
Operation only after proper transport, storage, installation, start-up or maintenance.
Improper transport, storage, installation, start-up or maintenance endanger the operational safety of the
device and can cause accidents. This can lead to serious personal injury or death.
Only carry out works which are described in these instructions.
Only carry out works using suitable tools.
Have all other works carried out by Bürkert only.

Type 8756 BATCH
Safety instructions
9
Electric shock due to electrical components
Touching live parts can result in severe electric shock. This can lead to serious personal injury or death.
Before working on the device or the system, switch off the power supply. Secure it against reactivation.
Observe any applicable accident prevention and safety regulations for electrical devices.
Media under pressure
Media under pressure can seriously injure people. In the event of overpressure or pressure surges, the
device or lines can burst. Pneumatic lines that are defective or not securely fastened can come loose and
swing around.
Before working on the device or system, switch off the pressure. Vent or empty the lines.
Adhere to the permitted pressure ranges of the media.
Comply with the permitted temperature ranges of the media.
Hot surfaces and fire hazard
The surface of the device can become hot with fast-switching actuators or with hot media.
Wear suitable protective gloves.
Keep highly flammable substances and media away from the device.
Technical limit values and media
Non-compliance with technical limit values or unsuitable media can damage the device and lead to leaks.
This can cause accidents and seriously injure or kill people.
Comply with limit values. See Technical data [}15] and information on the type label.
Only feed media into the media ports that are listed in the chapter Technical data [}15] .
Observe the safety data sheet for the media used.
Electrostatically sensitive components and assemblies
The device contains electronic components that are susceptible to the effects of electrostatic discharging
(ESD). Components that come into contact with electrostatically charged persons or objects are at risk. In
the worst case scenario, these components will be destroyed immediately or fail after start-up.
Meet the requirements specified by EN61340-5-1 to minimise or avoid the possibility of damage caused
by a sudden electrostatic discharge.
Do not touch electronic components when the supply voltage is connected.

Type 8756 BATCH
Product description
10
3 PRODUCT DESCRIPTION
The mass flow controller Type 8756 BATCH with integrated batch controller is especially suitable for dosing
small quantities of liquids with the highest accuracy.
This manual describes following product variant:
MFC büS/CANopen with an on/off valve
MFC büS/CANopen with an interface for a modular actuator
3.1 Design
MFC BATCH with an on/off valve
1
2345
6
7 8 9
10 11
12 13
Fig.1: MFC BATCH with an on/off valve
1 Electrical connection 2 Fluid connection
3 Functional earth connection 4 Base block
5 On/off valve 6 Not used
7 Not used 8 Not used
9 Status indicator (LED) 10 Screw
11 Cover 12 büS-interface
13 Slot for the memory card

Type 8756 BATCH
Product description
11
MFC BATCH for modular actuator
1
234
5
6
7 8 9
10
11
12 13
Fig.2: MFC BATCH for modular actuator
1 Electrical connection 2 Fluid connection
3 Functional earth connection 4 Base block
5 Connection of the actuator 6 Not used
7 Not used 8 Not used
9 Status indicator (LED) 10 Screw
11 Cover 12 büS-interface
13 Slot for the memory card

Type 8756 BATCH
Product description
12
3.2 Product identification
3.2.1 Type label
123
4
5
6
7
8
9
10
11
12
Fig.3: Example of type label Type 8756 BATCH
1 Type of the product 2 Supply voltage, direct current
3 Consumption according to UL 61010-1
[typical consumption]
4 Warning symbol: Observe the Operating In-
structions
5 Sealing material 6 Maximum fluid pressure
7 Manufacturing code 8 Product article number
9 Product serial number 10 Ambient temperature
11 Communication interface 12 Degree of protection
3.2.2 Calibration label
1
2
3
4
Fig.4: Description of the calibration label
1 Product variant 2 Flow direction
3 Product article-number 4 Manufacturing date
3.2.3 Conformity marking
1
2
3
Fig.5: Conformity label
1 Marking for Europe 2 Marking for USA, only for UL device
3 Warning hot surface

Type 8756 BATCH
Product description
13
3.3 Status indicator
The status indicator changes its colour based on the NAMUR recommendation NE107.
The colour of the product status indicator gives the following pieces of information:
Whether product diagnostics are active or not. Diagnostics are active on the product and cannot be de-
activated.
If product diagnostics are active, then the product status indicator shows whether diagnostics events
have been generated or not. If several diagnostics events have been generated, then the product status
indicator shows the diagnostics event with the highest priority. Refer to table [}13]
If the product status indicator flashes, then the product is selected in a man-machine interface such as the
Bürkert Communicator software.
Colour 1Colour code (for a
PLC)
Diagnostics event
Red 5 Failure, error or fault
Due to a malfunction of the product or its periphery.
MFC Batch: The measured values are not valid and the product cannot dose any
more.
Orange 4 Check function
The product is being worked on.
MFC Batch: The product cannot dose temporarily.
Yellow 3 Out of specification
The ambient conditions or process conditions for the product are outside the spe-
cified ranges.
Product internal diagnostics point to problems in the product or with the process
properties.
The yellow state is displayed for about 15 seconds after electrical power up.
The device needs this time to reach the normal operating mode. After this ini-
tialization the device will change to the green state.
MFC Batch: The product continues to dose
Blue 2 Maintenance required
Do the required maintenance operation.
MFC Batch: The product continues to dose, but a function is temporarily restric-
ted.
Green 1 -
Diagnostics are active and no diagnostics event has been generated.
MFC Batch: The product operates in the normal operating mode.
Tab.1: Product status indicator in accordance with NAMUR NE107, edition 2006-06-12, for active diagnostics
To solve a problem indicated by the product status indicator, refer to Troubleshooting [}43]
1 Colour and diagnostics according to NE107

Type 8756 BATCH
Product description
14
3.4 Memory card
If the memory card is defective or lost, then buy a new memory card from your Bürkert sales office.
The product is delivered with a memory card that is inserted in the product.
When the product is energised, there are two possibilities:
If product-specific data is stored on the inserted memory card, then the product adopts the data. At
product delivery, the memory card contains product-specific data. To get a list of the stored data, refer to
the file Device Description File that can be downloaded from country.burkert.com.
If the inserted memory card is empty, then the product loads its own data on the memory card. A new
memory card is empty.
The data on the memory card can be transferred to another product with the same article number. For ex-
ample, the data can be transferred from a defective product to a new product.
3.5 Functionality
3.5.1 Actuator is an on/off valve
The product is fitted with one of the following on/off valves:
Type 6013
Type 6724
Refer to the Type label of the on/off valve.
3.5.2 Customised actuator
An MFC for modular actuator can be combined to the following actuators:
a proportional valve
an on/off valve
When selecting the actuator, observe the following basic data of the MFC for modular actuator:
nominal flow rate
inlet pressure
3.5.3 Service life of the on/off valve
The service life of the on/off valve is reached when at least on the following problems occurs:
the product does not dose correctly any more
the on/off valve is not tight any more
the on/off valve does not open any more
If the service life of the on/off valve is reached, then replace the on/off valve with a new one. Refer to
chapter Replace the on/off valve Type 6013 [}40] or Replace the on/off valve Type 6724 [}41].

Type 8756 BATCH
Technical data
15
4 TECHNICAL DATA
4.1 Standards and Directives
The device complies with the relevant EU harmonisation legislation. In addition, the device also complies
with the requirements of the laws of the United Kingdom.
The harmonised standards that have been applied for the conformity assessment procedure are listed in
the current version of the EU Declaration of Conformity/UK Declaration of Conformity.
4.2 Operating conditions
MFC with on/off valve Type 6013
Ambient temperature 0°C...+55°C
Fluid temperature –10 °C...+60 °C, only in liquid state
Relative ambient humidity Max.95% at 55°C (non-condensing)
Operating altitude Up to 2000m above see level
Degree of protection IP65 according to EN60529 / IEC60529 (only with cables, plugs or
sockets connected correctly) determined by Bürkert, not evaluated
by UL
Operating pressure - Inlet pressure max.16 bar
MFC with on/off valve Type 6724
Ambient temperature 0°C...+55°C
Fluid temperature –10 °C...+50 °C, only in liquid state
Relative ambient humidity Max.95% at 55°C (non-condensing)
Operating altitude Up to 2000m above see level
Degree of protection IP40 according to EN60529 / IEC60529 (only with cables, plugs or
sockets connected correctly) determined by Bürkert, not evaluated
by UL
Operating pressure - Inlet pressure max.5 bar
4.3 Fluidic data
4.3.1 MFC with on/off valve
Calibration conditions
Calibration fluid Water
Temperature of the calibration fluid 25°C
Calibration pressure 4bar

Type 8756 BATCH
Technical data
16
Operating fluid, MFC with on/off valve Type 6013
Operating fluid Liquids
Type of liquids Liquids that are clean and homogeneous
Maximum particle size 10μm
Maximum dynamic viscosity 350mPa.s, with reduced flow-rate range.
Take the pressure loss into account. Refer to chapter Pressure loss.
Operating fluid, MFC with on/off valve Type 6724, only DN1
Operating fluid Liquids
Type of liquids Liquids that are clean and homogeneous
Maximum particle size 10μm
Maximum dynamic viscosity 50mPa.s, with reduced flow-rate range.
Take the pressure loss into account. Refer to chapter Pressure loss.
Density measurement
Density range 0...5kg/l
Measurement accuracy For mass flow rate values higher than 1.5kg/h
±0.01kg/l
Repeatability For mass flow rate values higher than 1.5kg/h
±0.005kg/l
Temperature measurement
Temperature range –10...60°C
Measurement accuracy For mass flow rate values higher than 1.5kg/h
±1.0K
Repeatability For mass flow rate values higher than 1.5kg/h
±0.5K
Mass flow rate measurement
Maximum mass flow rate DN1: 25kg/h
DN2: 120kg/h
Minimum measurable mass flow
rate
DN1: factory setting 0.05kg/h (can be reduced to 0.01kg/h)
DN2: factory setting 0.25kg/h (can be reduced to 0.05kg/h)
Mass flow rate range Factory setting 25kg/h (can be reduced to Qnom=1kg/h)
Maximum measurement range >1:300
The measurement range is defined as the ratio of Qnominal of the
product to Qmin. Qmin = 0.08kg/h. Refer to following figure.

Type 8756 BATCH
Technical data
17
2.500 2.400
500
480
-
250
500
750
1.000
1.250
1.500
1.750
2.000
2.250
2.500
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120
1
2
3
4
Measuring span
Nominal flow rate [kg/h]
Fig.6: Measurement range depending on nominal flow rate
1 max. measuring span DN1 2 max. measuring span DN2
3 standard measuring span DN1 4 standard measuring span DN2
4.3.2 Dosing volume range - MFC with on/off valve
Activation time [s]
Dosing amount [g]
Accuracy to reference [%]
Medium 100 mPas
Medium 1 mPas
Pressure [bar rel.]
Pressure [bar rel.]
Fig.7: DN1 variant. Dosing quantity depending on pressure and valve opening time < 50 g
The accuracy is 0,2% of the dosing weight.

Type 8756 BATCH
Technical data
18
Activation time [s]
Dosing amount [g]
Accuracy to reference [%]
Medium 100 mPas
Pressure [bar rel.]
Fig.8: DN2 variant. Dosing quantity depending on pressure and valve opening time < 100 g
4.4 Electrical data
MFC with on/off valve Type 6013
Operating voltage 24VDC ±10 %
residual ripple < 2 %
Maximum power consumption 16 W
Typical power consumption 8W for water and at a flow rate of 25kg/h
Communication interface büS and CANopen. The communication type can be chosen with the
Bürkert Communicator software.
Minimum temperature rating of the
cable to be connected to the field
wiring terminals:
75 °C
MFC with on/off valve Type 6724
Operating voltage 24VDC ±10 %
residual ripple < 2 %
Maximum power consumption 3 W
Typical power consumption 3W for water and at a flow rate of 25kg/h
Communication interface büS and CANopen. The communication type can be chosen with the
Bürkert Communicator software.
Minimum temperature rating of the
cable to be connected to the field
wiring terminals:
75 °C
4.5 Mechanical data
Dimensions Refer to data sheet

Type 8756 BATCH
Technical data
19
Base block Stainless steel 316L
Housing Painted aluminium, stainless steel
Seal Refer to the type label
Status indicator Polycarbonate
Parts in contact with the fluid
(sensor)
stainless steel 1.4404
MFC BATCH with on/off valve Type 6013
Parts in contact with the fluid Stainless steel 1.4305, 1.4113, 1.4310, 1.4303, EPDM
MFC BATCH with on/off valve Type 6724
Parts in contact with the fluid EPDM, PEEK

Type 8756 BATCH
Fluid connection
20
5 FLUID CONNECTION
5.1 Safety instructions
DANGER!
Risk of injury that is due to pressure in the installation or in the product.
Before working on the installation or product, cut the pressure. Vent and drain the pipes.
DANGER!
Risk of injury from electric shocks.
Before working on the installation or product, switch off the power supply. Make sure that nobody can
switch the power supply on.
Observe all applicable accident protection and all applicable safety regulations for electrical equipment.
WARNING!
Risk of injury that is due to escape of the fluid.
Contact with the operating fluid, its reaction products and vapours can cause injuries.
Inhaled vapours can be harmful.
Observe all applicable accident protection and all applicable safety regulations relating to the operating
fluid used.
CAUTION!
Risk of injury that is due to improper installation.
Only trained personnel can carry out the installation. Personnel must use suitable tools.
Secure the installation against unintentional actuation.
Ensure a controlled restart after installation.
NOTICE!
Malfunction that is due to contamination.
If a contaminated operating fluid is used, then install a filter upstream of the product. The filter ensures
problem-free functioning of the product. Refer to chapter: Fluidic data [}15]
NOTICE!
Cavitation of gas in the liquid and degassing must be avoided.
To avoid cavitation and degassing, make sure that the operating fluid is an homogeneous liquid and
that the pressure in the pipe is high enough.
When installing the product in the pipe, observe the flow direction that is given on the calibration plate
of the product.
NOTICE!
Avoid strong vibration that is due to the mechanical installation.
NOTICE!
Do not use any pump in the installation because the flow rate must not pulsate.
