Burkert 8756 User manual

Type 8756
büS / CANopen - Analogue
Mass Flow Meter / Mass Flow Controller for liquids
Operating Instructions

We reserve the right to make technical changes without notice.
© Bürkert SAS, 2020 - 2022
Operating Instructions 2211/03_EU-en 00573797 / Original EN

Type 8756
Table of contents
3
TABLE OF CONTENTS
1 About this document..................................................................................................................................6
1.1 Manufacturer .................................................................................................................................... 6
1.2 Used symbols................................................................................................................................... 6
1.3 Terms and abbreviations .................................................................................................................. 7
2 Safety instructions......................................................................................................................................8
2.1 Intended use..................................................................................................................................... 8
2.2 Safety................................................................................................................................................ 8
3 Product description..................................................................................................................................10
3.1 Design............................................................................................................................................. 10
3.2 Product identification ..................................................................................................................... 12
3.2.1 Type label...........................................................................................................................12
3.2.2 Calibration label .................................................................................................................13
3.2.3 Conformity marking ...........................................................................................................13
3.3 Status indicator .............................................................................................................................. 13
3.4 Memory card .................................................................................................................................. 14
3.5 Functionality ................................................................................................................................... 15
3.5.1 Actuator is a pump ............................................................................................................15
3.5.2 Actuator is a control valve .................................................................................................15
3.5.3 Customised actuator .........................................................................................................15
4 Technical data ..........................................................................................................................................17
4.1 Standards and Directives ............................................................................................................... 17
4.2 Operating conditions ...................................................................................................................... 17
4.3 Fluidic data ..................................................................................................................................... 18
4.3.1 MFM...................................................................................................................................18
4.3.2 Pressure loss - MFM..........................................................................................................20
4.3.3 MFC with pump .................................................................................................................21
4.3.4 Pressure loss - MFC with pump ........................................................................................22
4.3.5 MFC with proportional valve..............................................................................................22
4.3.6 Pressure loss - MFC with proportional valve.....................................................................24
4.3.7 MFC for modular actuator .................................................................................................24
4.3.8 Pressure loss - MFC for modular actuator ........................................................................26
4.4 Electrical data ................................................................................................................................. 27
4.5 Mechanical data ............................................................................................................................. 30
5 Fluid connection .......................................................................................................................................31
5.1 Safety instructions .......................................................................................................................... 31
5.2 Possible fluid connections.............................................................................................................. 32
5.3 Installation procedure ..................................................................................................................... 32
5.3.1 G1/8''-internal-threaded fluid connections........................................................................33
5.3.2 NPT1/8''-internal-threaded fluid connections ...................................................................33
5.3.3 Fluid connections with external-threaded vacuum fittings................................................33
5.3.4 Fluid connections with external-threaded compression fittings........................................34
6 Electrical connection................................................................................................................................35

Type 8756
Table of contents
4
6.1 Safety instructions .......................................................................................................................... 35
6.2 Additional documentation .............................................................................................................. 35
6.3 Wire the product variant büS /CANopen........................................................................................ 36
6.3.1 With büS extension cables from Bürkert ...........................................................................36
6.3.2 With büS cables from Bürkert............................................................................................36
6.3.3 With CANopen cables........................................................................................................37
6.4 Wire the product variant Analogue ................................................................................................. 38
6.4.1 Digital input ........................................................................................................................39
6.4.2 Relay output.......................................................................................................................40
6.5 Connect the functional earth .......................................................................................................... 41
6.6 Connect the external actuator (MFC for modular actuator) ........................................................... 41
7 Commissioning.........................................................................................................................................43
7.1 Safety instructions .......................................................................................................................... 43
7.2 Commissioning procedure (MFM) .................................................................................................. 43
7.3 Commissioning procedure (MFC with pump)................................................................................. 44
7.4 Commissioning procedure (MFC with proportional valve) ............................................................. 44
7.5 Commissioning procedure (MFC for modular actuator)................................................................. 45
8 Setting and operation...............................................................................................................................46
8.1 Safety instructions .......................................................................................................................... 46
8.2 Functions ........................................................................................................................................ 47
8.2.1 Empty-pipe detection ........................................................................................................47
8.2.2 Bubble detection................................................................................................................47
8.2.3 Cut-off................................................................................................................................47
8.2.4 Flush bubbles from the pipe (MFC with pump) .................................................................48
8.2.5 Flush bubbles from the pipe (MFC with proportional valve) ..............................................48
8.2.6 Fill the pipe without damaging the pump (MFC with pump)..............................................49
8.2.7 Configure the actuator (MFC for modular actuator) ..........................................................49
8.3 Setting tools.................................................................................................................................... 49
8.4 Connect the product to the Bürkert Communicator software........................................................ 50
8.4.1 Product variant büS /CANopen .........................................................................................50
8.4.2 Product variant Analogue ..................................................................................................51
8.5 Settings specific to the product variant büS/CANopen ................................................................. 52
8.5.1 Set the CANopen communication or the büS communication..........................................52
8.5.2 Increase the data transmission speed ...............................................................................52
8.6 Operating modes of an MFC .......................................................................................................... 53
8.7 Normal operating mode (MFC) ....................................................................................................... 53
8.7.1 Product variant büS /CANopen .........................................................................................54
8.7.2 Product variant Analogue ..................................................................................................54
8.8 Optimise the closed-loop control parameters (MFC) ..................................................................... 55
8.9 Choose the source that gives the set-point value (MFC) ............................................................... 56
8.10 Set-point values without communication (MFC büS/CANopen) .................................................... 56
9 Maintenance .............................................................................................................................................57
9.1 Safety instructions .......................................................................................................................... 57
9.2 Replace the memory card .............................................................................................................. 58

Type 8756
Table of contents
5
9.3 Sterilising a product variant MFM with hot water........................................................................... 58
9.4 Sterilising a product variant MFM with steam ................................................................................ 58
10 Troubleshooting .......................................................................................................................................60
10.1 Status indicator is red..................................................................................................................... 60
10.2 Status indicator is orange............................................................................................................... 63
10.3 Status indicator is yellow................................................................................................................ 63
10.4 Status indicator is blue ................................................................................................................... 68
10.5 Status indicator is off...................................................................................................................... 68
10.6 Status indicator flashes .................................................................................................................. 68
10.7 Status indicator goes out periodically ............................................................................................ 68
10.8 Replacement product adopts none of the values from the defective product............................... 69
10.9 Replacement product does not adopt all of the values from the defective product...................... 69
10.10 No mass flow rate........................................................................................................................... 69
10.11 Unstable measured value ............................................................................................................... 70
10.12 Set-point value at 0 %, but operating fluid still flows..................................................................... 71
10.13 Set-point value at 0 %, no mass flow, but a non-zero mass flow rate is measured...................... 73
10.14 Set-point value is not reached........................................................................................................ 73
10.15 Outgassing or bubble formation at the product outlet ................................................................... 74
11 Spare parts and accessories ...................................................................................................................76
11.1 Electrical accessories ..................................................................................................................... 76
11.2 Fluidic accessories ......................................................................................................................... 77
11.3 Additional software......................................................................................................................... 77
12 Uninstallation ............................................................................................................................................78
12.1 Safety instructions .......................................................................................................................... 78
12.2 Dismantling..................................................................................................................................... 78
13 Logistic .....................................................................................................................................................80
13.1 Transport ........................................................................................................................................ 80
13.2 Storage ........................................................................................................................................... 80
13.3 Return ............................................................................................................................................. 80
13.4 Disposal .......................................................................................................................................... 80

Type 8756
About this document
6
1 ABOUT THIS DOCUMENT
The document is an important part of the product and guides the user to safe installation and operation.
The information and instructions in this document are binding for the use of the product.
Before using the product for the first time, read and observe the whole safety chapter.
Before starting any work on the product, read and observe the respective sections of the document.
Keep the document available for reference and give it to the next user.
Contact the Bürkert sales office for any questions.
Further information concerning the product at country.burkert.com.
1.1 Manufacturer
Bürkert Fluid Control Systems
Christian-Bürkert-Str. 13−17
D-74653 Ingelfingen
The contact addresses are available at country.burkert.com in the menu Contact.
1.2 Used symbols
DANGER!
Warns of a danger that leads to death or serious injuries.
WARNING!
Warns of a danger that can lead to death or serious injuries.
CAUTION!
Warns of a danger that can lead to minor injuries.
NOTICE!
Warns of property damage that can damage the product or the installation.
Indicates important additional information, tips and recommendations.
Refers to information in this document or in other documents.
Indicates a step to be carried out.
Indicates a result.
Menu Indicates a software user-interface text.

Type 8756
About this document
7
1.3 Terms and abbreviations
The terms and abbreviations are used in this document to refer to following definitions.
Device / Product Type 8756
MFM Mass Flow Meter
MFC Mass Flow Controller
büS Bürkert system bus, a communication bus developed by Bürkert and based on the
CANopen protocol

Type 8756
Safety instructions
8
2 SAFETY INSTRUCTIONS
2.1 Intended use
The MFM Type8756 is designed to measure the mass flow rate of liquids.
The MFC Type8756 is designed to measure and regulate the mass flow rate of liquids.
The permitted media are listed in Technical data [}17]
Only trained and qualified personnel may install, operate and maintain the device. See qualification of
persons in Safety [}8]
Use the device only in conjunction with third-party devices and components recommended and author-
ized by Bürkert.
Use the device only when it is in perfect condition.
Only use the device indoors.
Prerequisites for safe and trouble-free operation are correct proper transportation, storage, installation,
start-up, operation and maintenance.
The instructions are part of the device. The device is intended exclusively for use within the scope of these
instructions. Uses of the device that are not described in these instructions, the contractual documents or
the type label can lead to severe personal injury or death, damage to the device or property and dangers for
the surrounding area or the environment.
2.2 Safety
Qualification of personnel working with the device
Improper use of the device can lead to serious personal injury or death. To avoid accidents when working
with the device, the following minimum requirements must be met:
Carry out work on the device within the scope of these instructions in a safety-compliant manner.
Detect and avoid dangers when working on the device.
Understand the instructions and implement the information contained therein accordingly.
Responsibility of the operator
The operator is responsible for observing the location-specific safety regulations, also in relation to person-
nel.
Observe the general rules of technology.
Install the device according to the regulations applicable in the respective country.
The operator must make hazards arising from the location of the device avoidable by providing appropri-
ate operating instructions.
Operation only after proper transport, storage, installation, start-up or maintenance.
Improper transport, storage, installation, start-up or maintenance endanger the operational safety of the
device and can cause accidents. This can lead to serious personal injury or death.
Only carry out works which are described in these instructions.
Only carry out works using suitable tools.

Type 8756
Safety instructions
9
Have all other works carried out by Bürkert only.
Electric shock due to electrical components
Touching live parts can result in severe electric shock. This can lead to serious personal injury or death.
Before working on the device or the system, switch off the power supply. Secure it against reactivation.
Observe any applicable accident prevention and safety regulations for electrical devices.
Media under pressure
Media under pressure can seriously injure people. In the event of overpressure or pressure surges, the
device or lines can burst. Pneumatic lines that are defective or not securely fastened can come loose and
swing around.
Before working on the device or system, switch off the pressure. Vent or empty the lines.
Adhere to the permitted pressure ranges of the media.
Comply with the permitted temperature ranges of the media.
Hot surfaces and fire hazard
The surface of the device can become hot with fast-switching actuators or with hot media.
Wear suitable protective gloves.
Keep highly flammable substances and media away from the device.
Technical limit values and media
Non-compliance with technical limit values or unsuitable media can damage the device and lead to leaks.
This can cause accidents and seriously injure or kill people.
Comply with limit values. See Technical data [}17] and information on the type label.
Only feed media into the media ports that are listed in the chapter Technical data [}17] .
Observe the safety data sheet for the media used.
Electrostatically sensitive components and assemblies
The device contains electronic components that are susceptible to the effects of electrostatic discharging
(ESD). Components that come into contact with electrostatically charged persons or objects are at risk. In
the worst case scenario, these components will be destroyed immediately or fail after start-up.
Meet the requirements specified by EN61340-5-1 to minimise or avoid the possibility of damage caused
by a sudden electrostatic discharge.
Do not touch electronic components when the supply voltage is connected.

Type 8756
Product description
10
3 PRODUCT DESCRIPTION
The mass flow meter Type 8756 is particularly suitable for the very precise measurement of small quantities
of liquid that also require a medium-separated sensor.
This manual describes following product variant:
MFM büS/CANopen
MFM Analogue
The mass flow controller Type 8756 is particularly suitable for the very precise control of small quantities of
liquid that also require a medium-separated sensor.
This manual describes following product variant:
MFC büS/CANopen with pump
MFC büS/CANopen with proportional valve
MFC büS/CANopen with an interface for a modular actuator
MFC Analogue with pump
MFC Analogue with proportional valve
MFC Analogue with an interface for a modular actuator
3.1 Design
MFM
1
2
3
45
6
7
8 9
10
11
12 13
Fig.1: MFM
1 Electrical connection 2 Electrical connection
3 Fluid connection 4 Functional earth connection
5 Base block 6 Status indicator (LED)
7 Not used 8 Not used
9 Not used 10 Screw
11 Cover 12 büS-interface
13 Slot for the memory card

Type 8756
Product description
11
MFC with pump
1
2
3
45
6
7
8 9 10
11
12
13 14
Fig.2: MFC with pump
1 Electrical connection 2 Electrical connection
3 Fluid connection 4 Functional earth connection
5 Base block 6 Pump
7 Not used 8 Not used
9 Not used 10 Status indicator (LED)
11 Screw 12 Cover
13 büS-interface 14 Slot for the memory card
MFC with proportional valve
1
2
3
45
6
7
8 9 10
11
12
13 14
Fig.3: MFC with proportional valve
1 Electrical connection 2 Electrical connection
3 Fluid connection 4 Functional earth connection
5 Base block 6 Proportional valve

Type 8756
Product description
12
7 Not used 8 Not used
9 Not used 10 Status indicator (LED)
11 Screw 12 Cover
13 büS-interface 14 Slot for the memory card
MFC for modular actuator
1
2
345
6
7
8 9 10
11
12
13 14
Fig.4: MFC for modular actuator
1 Electrical connection 2 Electrical connection
3 Fluid connection 4 Functional earth connection
5 Base block 6 Connection of the actuator
7 Not used 8 Not used
9 Not used 10 Status indicator (LED)
11 Screw 12 Cover
13 büS-interface 14 Slot for the memory card
3.2 Product identification
3.2.1 Type label
123
4
5
6
7
8
9
10
11
12
13
14
Fig.5: Example of type label Type 8756
1 Type of the product 2 Supply voltage, direct current

Type 8756
Product description
13
3 Consumption according to UL 61010-1
[typical consumption]
4 Warning symbol: Observe the Operating In-
structions
5 Calibration fluid 6 Sealing material
7 Burst pressure 8 Manufacturing code
9 Product article number 10 Product serial number
11 Ambient temperature 12 Communication interface
13 Nominal mass flow rate (Q nominal) 14 Degree of protection
3.2.2 Calibration label
1
2
3
4
Fig.6: Description of the calibration label
1 Product variant 2 Flow direction
3 Product article-number 4 Manufacturing date
3.2.3 Conformity marking
1
2
3
Fig.7: Conformity label
1 Marking for Europe 2 Marking for USA, only for UL device
3 Warning hot surface
3.3 Status indicator
The status indicator changes its colour based on the NAMUR recommendation NE107.
The colour of the product status indicator gives the following pieces of information:
Whether product diagnostics are active or not. Diagnostics are active on the product and cannot be de-
activated.
If product diagnostics are active, then the product status indicator shows whether diagnostics events
have been generated or not. If several diagnostics events have been generated, then the product status
indicator shows the diagnostics event with the highest priority. Refer to table [}14]
If the product status indicator flashes, then the product is selected in a man-machine interface such as the
Bürkert Communicator software.

Type 8756
Product description
14
Colour 1Colour code (for a
PLC)
Diagnostics event
Red 5 Failure, error or fault
Due to a malfunction of the product or its periphery.
MFM: The measured values are not valid.
MFC: The measured values are not valid and the product cannot regulate any
more.
Orange 4 Check function
The product is being worked on.
MFM: The output signal is temporarily invalid.
MFC: The product cannot regulate temporarily.
Yellow 3 Out of specification
The ambient conditions or process conditions for the product are outside the spe-
cified ranges.
Product internal diagnostics point to problems in the product or with the process
properties.
The yellow state is displayed for about 15 seconds after electrical power up.
The device needs this time to reach the normal operating mode. After this ini-
tialization the device will change to the green state.
Blue 2 Maintenance required
Do the required maintenance operation.
MFM: The product continues to measure.
MFC: The product continues to regulate, but a function is temporarily restricted.
Green 1 -
Diagnostics are active and no diagnostics event has been generated.
MFC: The product operates in the normal operating mode or in Stored set-point
value operating mode. Refer to Setting and operation [}46].
Tab.1: Product status indicator in accordance with NAMUR NE107, edition 2006-06-12, for active diagnostics
To solve a problem indicated by the product status indicator, refer to Troubleshooting [}60]
3.4 Memory card
If the memory card is defective or lost, then buy a new memory card from your Bürkert sales office.
The product is delivered with a memory card that is inserted in the product.
When the product is energised, there are two possibilities:
If product-specific data is stored on the inserted memory card, then the product adopts the data. At
product delivery, the memory card contains product-specific data. To get a list of the stored data, refer to
the file Device Description File that can be downloaded from country.burkert.com.
1 Colour and diagnostics according to NE107

Type 8756
Product description
15
If the inserted memory card is empty, then the product loads its own data on the memory card. A new
memory card is empty.
The data on the memory card can be transferred to another product with the same article number. For ex-
ample, the data can be transferred from a defective product to a new product.
3.5 Functionality
3.5.1 Actuator is a pump
The pump is a micro-annular gear pump.
NOTICE!
The micro-annular gear pump is not completely tight.
To avoid possible problems that are due to leakage, make sure that no fluid flows when the pump is
switched off. Take into account the static pressure.
NOTICE!
Risk of damage to the pump due to the suction pressure.
The suction pressure must be as low as possible and always lower than 200 mbar.
The service life of the pump is approximately 8,000...10,000 hours. The value depends on the following cri-
teria:
the dry cycle time of the pump
the pump speed
the fluid used
the back pressure
3.5.2 Actuator is a control valve
The control valve is a direct-acting and normally-closed proportional valve.
The control valve provides the sealing function when the following conditions are met:
The product is used within the specified pressure range.
The product is equipped with a valve seat seal that is made of a soft material such as FKM, FFKM or
EPDM.
If the valve seat seal is made of a hard material such as PCTFE, then the control valve may not be
tight.
Products with a nominal valve diameter of 0.05mm or 0.1mm have a valve seat seal made of a
hard material.
When using an MFC with proportional valve actuator, unstable measured values may occur. Refer to
Unstable measured value [}70]
3.5.3 Customised actuator
An MFC for modular actuator can be combined to the following actuators:
a proportional valve
a pump

Type 8756
Product description
16
When selecting the actuator, observe the following basic data of the MFC for modular actuator:
nominal flow rate
inlet pressure

Type 8756
Technical data
17
4 TECHNICAL DATA
4.1 Standards and Directives
The device complies with the relevant EU harmonisation legislation. In addition, the device also complies
with the requirements of the laws of the United Kingdom.
The harmonised standards that have been applied for the conformity assessment procedure are listed in
the current version of the EU Declaration of Conformity/UK Declaration of Conformity.
4.2 Operating conditions
MFM
Ambient temperature 0°C...+50°C
Fluid temperature –10 °C...+70 °C, only in liquid state
Relative ambient humidity Max.95% at 55°C (non-condensing)
Operating altitude Up to 2000m above see level
Degree of protection IP65 according to EN60529 / IEC60529 (only with cables, plugs or
sockets connected correctly) determined by Bürkert, not evaluated
by UL
Maximum operating pressure of fluid connections
G-internal-threaded FFKM or PCTFE: max. 100 bar
Metal: max. 50 bar
NPT-internal-threaded FFKM or PCTFE: max. 100 bar
Metal: max. 50 bar
External-threaded vacuum fittings max. 50 bar
External-threaded compression fit-
tings
max. 50 bar
MFC with pump
Ambient temperature 0°C...+50°C
Fluid temperature –10 °C...+70 °C, only in liquid state
Relative ambient humidity Max.95% at 55°C (non-condensing)
Operating altitude Up to 2000m above see level
Degree of protection IP40 according to EN60529 / IEC60529 (only with cables, plugs or
sockets connected correctly) determined by Bürkert, not evaluated
by UL
Operating pressure - Inlet pressure 0 bar
Operating pressure - Outlet pres-
sure
max.10 bar

Type 8756
Technical data
18
MFC with proportional valve
Ambient temperature 0°C...+50°C
Fluid temperature –10 °C...+60 °C, only in liquid state
Relative ambient humidity Max.95% at 55°C (non-condensing)
Operating altitude Up to 2000m above see level
Degree of protection IP65 according to EN60529 / IEC60529 (only with cables, plugs or
sockets connected correctly) determined by Bürkert, not evaluated
by UL
Operating pressure - Inlet pressure max.5 bar
MFC for modular actuator
Ambient temperature 0°C...+50°C
Fluid temperature –10 °C...+70 °C, only in liquid state
Relative ambient humidity Max.95% at 55°C (non-condensing)
Operating altitude Up to 2000m above see level
Degree of protection IP65 according to EN60529 / IEC60529 (only with cables, plugs or
sockets connected correctly) determined by Bürkert, not evaluated
by UL
Maximum operating pressure of fluid connections
G-internal-threaded FFKM or PCTFE: max. 100 bar
Metal: max. 50 bar
NPT-internal-threaded FFKM or PCTFE: max. 100 bar
Metal: max. 50 bar
External-threaded vacuum fittings max. 50 bar
External-threaded compression fit-
tings
max. 50 bar
4.3 Fluidic data
4.3.1 MFM
Calibration conditions
Calibration fluid Water
Temperature of the calibration fluid 25°C
Calibration pressure 4bar
Operating fluid
Operating fluid Liquids
Type of liquids Liquids that are clean and homogeneous

Type 8756
Technical data
19
Maximum particle size 10μm
Minimum dynamic viscosity 0.3mPa.s
Maximum dynamic viscosity 1500mPa.s
Take the pressure loss into account. Refer to chapter Pressure loss.
Density measurement
Density range 0...5kg/l
Measurement accuracy For mass flow rate values higher than 1.5kg/h
±0.01kg/l
Repeatability For mass flow rate values higher than 1.5kg/h
±0.005kg/l
Temperature measurement
Temperature range –10...70°C
Measurement accuracy For mass flow rate values higher than 1.5kg/h
±1.0K
Repeatability For mass flow rate values higher than 1.5kg/h
±0.5K
Mass flow rate measurement
Maximum mass flow rate DN1: 25kg/h
DN2: 120kg/h
Nominal mass flow rate DN1: factory setting 25kg/h (minimum reducible to Qnom=1kg/h)
DN2: factory setting 120kg/h (minimum reducible to Qnom=5kg/h)
Minimum measurable mass flow
rate
DN1: factory setting 0.05kg/h (can be reduced to 0.01kg/h)
DN2: factory setting 0.25kg/h (can be reduced to 0.05kg/h)
Measurement accuracy after
1minute warm-up time
DN1: ±0.2% of the measured value or ±1.4g/h.
Zero point applies to water at calibration conditions; for flows of
<1.4kg/h and deviating medium, please consult Bürkert.
1.4g/h = zero-point stability
DN2: ±0.1% of the measured value or ±15g/h.
Zero point applies to water at calibration conditions; for flows of
<15kg/h and deviating medium, please consult Bürkert.
15g/h = zero-point stability
Maximum measurement range 1:2500
The measurement range is defined as the ratio of Qnominal of the
product to Qmin. Qmin = 0.05kg/h. Refer to following figure.

Type 8756
Technical data
20
Repeatability DN1: ±0.1% of the measured value or ±0.7g/h
0.7g/h = zero-point stability
DN2: ±0.05% of the measured value or ±7.5g/h
7.5g/h = zero-point stability
Response time (t95%) < 750ms
The response time depends on the operating fluid used
2.500 2.400
500
480
-
250
500
750
1.000
1.250
1.500
1.750
2.000
2.250
2.500
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120
1
2
3
4
Measuring span
Nominal flow rate [kg/h]
Fig.8: Measurement range depending on nominal flow rate
1 max. measuring span DN1 2 max. measuring span DN2
3 standard measuring span DN1 4 standard measuring span DN2
4.3.2 Pressure loss - MFM
A MFM has a pressure loss that depends on the following parameters:
the flow-rate value
the size of the product fluid connections
the type of the product fluid connections
the size of the product base block
the type of operating fluid
0
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
95
100
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120
[bar]
[kg/h]
DN1 0,5mPas
DN1 1mPas
DN1 5mPas
DN1 10mPas
DN1 25mPas
DN1 50mPas
DN1 100mPas
DN1 150mPas
DN1 200mPas
DN2 1mPas
DN2 10mPas
DN2 25mPas
DN2 50mPas
DN2 100mPas
DN2 150mPas
DN2 200mPas
DN2 300mPas
Fig.9: Pressure loss diagram for water through an MFM
