Burster 8661 Installation manual

OPERATION MANUAL
Torque sensor
Model 8661
Manufacturer:
© 2018
burster
praezisionsmesstechnik gmbh & co kg
burster
praezisionsmesstechnik gmbh & co kg
All rights reserved
Talstr. 1 - 5
P.O. 1432
76593 Gernsbach
76593 Gernsbach
Germany
Germany
Valid from:
22.05.2018
Tel.: [phone]
Fax.: [phone]
Email: [e-mail]
www.burster.com
2742-BA8661EN-5170-051523

2of 74
Exclusion of warranty liability for operating manuals
All information in the present documentation was prepared and compiled with great care and reproduced
subject to effective control measures. No warranty is provided for freedom from errors. We reserve the
right to make technical changes. The present information as well as the corresponding technical data can
change without notice. Reproduction of any part of this documentation or its processing or revision using
electronic systems is prohibited without the manufacturer‘s prior written approval.
Components, devices and measured value sensors made by burster praezisionsmesstechnik (hereinafter
referred to as "product") are the results of targeted development and meticulous research. As of the date
of delivery, burster provides a warranty for the proper condition and functioning of these products
covering material and production defects for the period specified in the warranty document accompanying
the product. However, burster excludes guarantee or warranty obligations as well as any liability beyond
that for consequential damage caused by improper use of the product, in particular the implied warranty
of success in the market as well as the suitability of the product for a particular purpose. Furthermore,
burster assumes no liability for direct, indirect or incidental damages as well as consequential or other
damages arising from the provision and use of the present documentation.
Trademark information
Intel Pentium® is a registered trademark of Intel Corporation. Windows®, Excel® are registered
trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
All brand or product names mentioned in this document are trademarks or registered trade-marks of their
respective trademark owners. By mentioning these trademarks burster präzisionsmesstechnik gmbh & co
kg is not laying claim to trademarks other than its own.

3of 74

4of 74
Table of contents
1Safety instructions .................................................................................................................................7
1.1 Symbols in this manual....................................................................................................................7
1.1.1 Signal words..........................................................................................................................7
1.1.2 Pictograms ............................................................................................................................7
1.2 General safety instructions ..............................................................................................................8
2Introduction.............................................................................................................................................9
2.1 Intended use ....................................................................................................................................9
2.2 Customer service .............................................................................................................................9
2.2.1 Customer service department...............................................................................................9
2.2.2 Contact person......................................................................................................................9
2.3 Environmental conditions.................................................................................................................10
2.3.1 Storage conditions ................................................................................................................10
2.3.2 Cleaning ................................................................................................................................10
2.4 Personnel.........................................................................................................................................10
2.5 Scope of delivery .............................................................................................................................11
2.6 Unpacking ........................................................................................................................................11
2.7 Warranty ..........................................................................................................................................11
2.8 Conversions and modifications........................................................................................................12
2.9 Definitions ........................................................................................................................................13
3Device design and general information ...............................................................................................15
3.1 Mechanical design ...........................................................................................................................15
3.2 Principle of operation .......................................................................................................................16
3.3 Static and quasi-static torques.........................................................................................................16
3.4 Dynamic torques ..............................................................................................................................16
3.5 Interference......................................................................................................................................17
4Installation...............................................................................................................................................18
4.1 Preparing for installation ..................................................................................................................18
4.2 Mechanical installation.....................................................................................................................19
4.2.1 Installation using mounting block ..........................................................................................19
4.2.2 Free-floating installation........................................................................................................21
5Torque sensor model 8661 with analog connection...........................................................................23
5.1 Electrical connection ........................................................................................................................23
5.1.1 Power supply.........................................................................................................................23
5.1.2 Connector pin assignments (standard sensor, 1 range).......................................................23
5.1.3 The connections in detail ......................................................................................................24
5.1.4 Running cables .....................................................................................................................26
5.1.5 Extension cables ...................................................................................................................27
5.2 Measurement ...................................................................................................................................28
5.2.1 Switching on..........................................................................................................................28
5.2.2 Status display (standard sensor, 1 range) ............................................................................28

5of 74
5.2.3 Speed limits ..........................................................................................................................28
5.2.4 Check function ......................................................................................................................28
6USB version of the torque sensor model 8661 ...................................................................................29
6.1 Electrical connection........................................................................................................................29
6.1.1 Power supply ........................................................................................................................30
6.1.2 USB 2.0 pin assignment .......................................................................................................30
6.1.3 Ground connection................................................................................................................31
6.1.4 Wiring ....................................................................................................................................31
7Software DigiVision................................................................................................................................32
7.1 Device list / device detection ...........................................................................................................32
7.2 Device settings ................................................................................................................................33
7.2.1 Settings .................................................................................................................................34
7.2.2 Limits.....................................................................................................................................35
7.2.3 Properties..............................................................................................................................35
7.3 Properties, measurement rate etc. ..................................................................................................36
7.3.1 General information ..............................................................................................................36
7.3.2 Selecting the measurement rate...........................................................................................37
7.4 Measurement-mode settings ...........................................................................................................38
7.4.1 Basic configuration................................................................................................................39
7.4.2 Channel settings ...................................................................................................................39
7.4.3 Trigger...................................................................................................................................40
7.4.4 Documentation......................................................................................................................41
7.5 Display .............................................................................................................................................41
7.6 Start / stop a measurement .............................................................................................................43
7.7 Measurement reports ......................................................................................................................44
7.7.1 Measurement report finder ...................................................................................................44
7.7.2 Archive viewer.......................................................................................................................45
7.7.3 Exporting reports to Excel.....................................................................................................46
7.7.4 Print reports ..........................................................................................................................47
8Software DigiVision................................................................................................................................49
8.1System requirements.......................................................................................................................49
8.2 Software installation ........................................................................................................................49
8.2.1 Driver installation ..................................................................................................................53
8.2.2 Installation for the virtual COM port ......................................................................................57
8.2.3 Data storage .........................................................................................................................61
8.3 Software version & licensing ...........................................................................................................61
8.3.1 8661-P001 ............................................................................................................................61
8.3.2 8661-P100 ............................................................................................................................62
8.3.3 8661-P200 ............................................................................................................................63
8.3.4 Licensing ...............................................................................................................................64
9Options....................................................................................................................................................65
9.1 Angle / speed measurement............................................................................................................65

6of 74
9.1.1 General information ..............................................................................................................65
9.1.2 Details ...................................................................................................................................65
9.2 Dual-range sensor ...........................................................................................................................67
9.2.1 Switching between ranges (dual-range sensor) ...................................................................67
9.2.2 Possible range extension of the nominal torque...................................................................67
9.2.3 Switching between measurement range...............................................................................67
9.2.4 Connector pin assignments (dual-range sensor, not USB) ..................................................67
9.2.5 Connection diagram (dual-range sensor, not USB)..............................................................68
9.2.6 Status display (dual-range sensor) .......................................................................................69
10 Calibration and adjustment ...................................................................................................................70
10.1 Factory calibration ...........................................................................................................................70
10.2 DAkkS (DKD) calibration (DIN 51309).............................................................................................70
10.3 Recalibration ....................................................................................................................................70
11 Taking out of use....................................................................................................................................71
12 Technical data.........................................................................................................................................72
12.1 Electromagnetic compatibility ..........................................................................................................72
12.1.1 Interference immunity ...........................................................................................................72
12.1.2 Emitted interference ..............................................................................................................72
13 Accessories ............................................................................................................................................73
13.1 Software...........................................................................................................................................73
14 Disposal...................................................................................................................................................74

7of 74
1 Safety instructions
On the torque sensor model 8661 and in this manual the following symbols warn about risks.
1.1 Symbols in this manual
1.1.1 Signal words
The following signal words are used in the operation manual according to the specified hazard
classification.
DANGER
DANGER indicates a hazard with a high level of risk which, if not avoided, will result in death or serious
injury.
WARNING
WARNING indicates a hazard with a medium level of risk which, if not avoided, could result in death or
serious injury.
CAUTION
CAUTION indicates a hazard with a low level or risk which, if not avoided, could result in minor or
moderate injury.
NOTICE
Property damage to the equipment or the surroundings will result if the hazard is not avoided.
Note: It is important to heed these safety instructions in order to ensure correct handling of the torque
sensor model 8661.
IMPORTANT: Follow the information given in the operation manual.
1.1.2 Pictograms
Danger of electric shock!
Observe the safety notices for protecting the torque sensor model 8661.

8of 74
1.2 General safety instructions
The torque sensor model 8661 uses state-of-the-art engineering and is safe to operate. However, if the
torque sensor model 8661 is not used or operated as intended, it may present a hazard.
DANGER
Danger of electric shock!
The following instructions must be followed to prevent electric shock and
injuries:
•In order to achieve high measuring characteristic value, the torque
sensor model 8661 is not designed with the usual safety factors (2…20)
for machine designs. For applicable overload factors, see the technical
data (data sheet).
•Observe accident prevention regulations, including for accessories used.
•Use torque sensor model 8661 only in non-safety-critical applications.
•Only use torque sensor model 8661 outside of potentially explosive
areas (Ex protected areas).
NOTICE
The following points must be observed to prevent injuries and damage to property:
•The limits for permissible mechanical, thermal and electrical loads are shown in the data
sheet. These limits must not be exceeded. Take these limits into account when planning
the measuring arrangement, and during installation (preferably with the display for the
torque connected) and operation.
•Impacts and shocks may damage the torque sensor model 8661 (e.g. if it is dropped).
Exercise the necessary care when transporting and fitting the sensor.
•Torque peaks in excess of the permissible overload may destroy the torsion shaft. Make
sure that such peaks do not occur, or ensure that they are absorbed.

9of 74
2 Introduction
IMPORTANT: Read the operation manual carefully before using the equipment, and keep for future
reference.
2.1 Intended use
The torque sensor model 8661 measures static and dynamic torques on rotating or stationary machine
parts in either direction of rotation. You have the option of measuring rotational speed or angular
displacement. The respective upper range value is shown on the type plate. The USB version of the 8661
torque sensor model 8661 transmits all measurement signals via USB.
Both the low mass of the torque sensor model 8661 and its high torsional rigidity are an advantage when
measuring dynamic torques. However, you need to pay attention to the torsion spring constant and the
sensor’s cut-off frequency with such measurements. You can find both of these in the data sheet. For
more information on estimating the resonant frequency and measuring dynamic torques see chapter 3.4
“Dynamic torques” on page 16.
The torque sensor model 8661 is maintenance-free thanks to its contactless transmission of the
measurement signal. The electrical measurement signals can be transmitted to remote measuring
stations where they can be displayed, recorded, processed and used for control and regulation tasks.
Use the torque sensor model 8661 only for measuring torque and rotational speed or angular
displacement.
Do not use the torque sensor model 8661 in safety-critical applications.
The torque sensor model 8661 is not intended for use as a safety device.
2.2 Customer service
2.2.1 Customer service department
If you need to ask about repairs, please telephone our Service department on [phone].
Please have the serial number to hand. The serial number is essential to establishing the definite
technical status of the torque sensor model 8661 and providing help quickly. You will find the serial
number on the type plate of the torque sensor model 8661.
2.2.2 Contact person
If you have any questions relating to the torque sensor model 8661, please contact your representative or
go directly to burster präzisionsmesstechnik gmbh & co. kg.
Headquarters
burster praezisionsmesstechnik gmbh & co kg
Talstr. 1 - 5
76593 Gernsbach
Germany
Tel: [phone]
Fax: [phone]
Email: [e-mail]

10 of 74
2.3 Environmental conditions
•Avoid radiant heat or cooling from one side.
•Protect the torque sensor model 8661 from moisture.
•The torque sensor model 8661 is not resistant to the effects of chemicals. Do not use the
torque sensor model 8661 in a corrosive environment.
•Keep the bearings and connectors free of dust, dirt and other foreign matter.
2.3.1 Storage conditions
Use clean packaging to package the torque sensor model 8661. The torque sensor model 8661 must be
stored under the following conditions:
•Dry atmosphere
•No condensation
•Temperature between +0 °C and +60 °C
2.3.2 Cleaning
DANGER
Electric shock hazard!
Disconnect the torque sensor model 8661 from the electrical supply before cleaning.
Disconnect the torque sensor model 8661 from the power supply and use a dry cloth to clean it.
CAUTION
Do not immerse the torque sensor model 8661 in water or hold it under running water.
Do not use strong cleaning agents as these may damage the torque sensor model 8661.
Use a dry cloth to clean the device.
Ensure that the shaft and mating parts are completely clean and have no traces of
lubricants at the time of fitting. Use a solvent such as acetone to clean the shafts before
fitting. Make sure there is no foreign matter on the shafts at fitting.
2.4 Personnel
Personnel must be familiar with the relevant regulations. They must follow these regulations. Only trained
personnel who are familiar with the applicable safety regulations are permitted to operate the torque
sensor model 8661.

11 of 74
2.5 Scope of delivery
•Torque sensor model 8661
•Mating connector
•Operation manual
•Data sheet
•Optional: USB cable
2.6 Unpacking
DANGER
Electric shock hazard!
Never connect up the torque sensor model 8661 if it shows signs of damage incurred
in transit. Only ever use the torque sensor model 8661 under the conditions specified
in this operation manual.
Inspect the torque sensor model 8661 carefully for damage. If you suspect that the torque sensor model
8661 has been damaged during shipping, notify the delivery company within 72 hours.
The packaging should be retained for examination by a representative of the manufacturer and/or the
delivery company.
The torque sensor model 8661 must be shipped only in its original packaging or in packaging capable of
providing an equivalent degree of protection.
2.7 Warranty
burster praezisionsmesstechnik gmbh & co kg provides a manufacturer's warranty for a period of 24
months after delivery.
Any repairs required during this time will be made without charge. This does not include damage arising
from improper use.
Please note the following when sending the torque sensor model 8661 in for repair:
•If there is a problem with the torque sensor model 8661, please attach a note to the sensor
case summarizing the fault.
•Technical specifications subject to change at any time without notice. We also state
explicitly that we do not accept liability for consequential damage.
•The torque sensor model 8661 must always be dispatched in suitable packaging.

12 of 74
2.8 Conversions and modifications
Note: If you open or dismantle the torque sensor model 8661 during the warranty period, this will void
the warranty immediately.
The torque sensor model 8661 does not contain any parts that are intended to be serviced by the user.
Only the manufacturer's own qualified personnel are permitted to open the torque sensor model 8661.
It is forbidden to make any modification to the torque sensor model 8661 without our written permission.
We cannot accept liability in the event of such action.
Our recommendations
•Check the bearings at least once a year to see that they still move freely.
•Replace the special low-friction bearings after a maximum of 20.000 hours of operation. In
continuous operation at high speeds it may be necessary to replace the bearings sooner.
•Check cables and connectors annually.
•It is up to you as the user to determine the recalibration interval. We recommend that you
check/recalibrate the torque sensor model 8661 after no longer than 12 months. Further
details are given in chapter 10 “Calibration and adjustment” on page 70.

13 of 74
2.9 Definitions
Test side
The test side is that end of the shaft at which you apply the torque being measured to the torque sensor
model 8661.
This side normally has the smallest moment of inertia. Torque sensors model 8661 with measuring
ranges up to 2 Nm have a smaller and therefore lower-friction ball bearing fitted at this end.
You will see these markings on the measurement end of the torque sensor model 8661:
Diagram 1: Test side
Drive side
The drive side is the opposite end to the measurement end. The torque sensor model 8661 is also
mechanically connected at this side.
This side normally has the larger moment of inertia.
You will see these markings on the drive side of the torque sensor model 8661:
Diagram 2: Drive side
The torque direction
A torque is clockwise (clockwise torque) if the torque is exerted clockwise when looking at the
measurement end. In this case you will get a positive electrical signal at the torque sensor model 8661
output.
Diagram 3: Torque, clockwise (looking at the test side)

14 of 74
You can use the torque sensor model 8661 to measure both clockwise and counterclockwise torques. If
the torque is exerted in an anticlockwise direction (looking at the measurement end), you will get a
negative signal at the output.
Diagram 4: Torque, anticlockwise (looking at measurement end)
Sign convention for measuring angular displacement
If the sensor shaft rotates clockwise (looking at the drive end), channel A leads channel B by 90°.
If the sensor shaft rotates anticlockwise (looking at the drive end), channel B leads channel A by 90°.
Static and quasi-static torques
Static and quasi-static torques change their value only slowly or not at all. As long as they are below the
rated torque, these torques can take any value.
Dynamic torques
A dynamic torque changes very rapidly and can even oscillate. In this case the frequency of the torque
must remain well below the resonant frequency of the mechanical structure as a whole.
We recommend that you only measure dynamic torques, if they reach a maximum 70% of the rated
torque. The characteristics of your signal analysis and control systems must be taken into account during
dynamic testing.
When measuring dynamic torques, take the characteristics of your measuring amplifier into account.
For more information on estimating the resonant frequency and measuring dynamic torques, see chapter
3.4 “Dynamic torques” on page 16.

15 of 74
3 Device design and general information
Specifications as full dimensions, mass and power depend on the version of the torque sensor model
8661. Please refer to the data sheet for specifications.
3.1 Mechanical design
Diagram 5: Design principle
The torque sensor model 8661 essentially consists of three elements:
•Measuring shaft
•Electronics box
•Sensor unit
The measuring shaft is composed of torsion bar, strain gauges, instrumentation amplifier and power and
signal transmission components. If the torque sensor model 8661 is fitted with the rotational speed or
angular displacement option, an incremental encoder disk is also fitted for measuring rotational speed or
angular displacement (see chapter 9.1 “Angle / speed measurement” on page 65).
Diagram 6: Shaft from a torque sensor model 8661 with rotational speed and angle measurement
Apart from containing the stator electronics, the electronics box also includes an electrical connecting
plug and a socket for an external supply. The sensor unit houses the rotor and two grooved ball bearings.

16 of 74
3.2 Principle of operation
Torque deforms the torsion shaft and, as it does so, also elastically and reversibly elongates the strain
gauges mounted on the shaft. The electrical resistance of these strain gauges changes proportionally to
their elongation.
The torque sensor model 8661 has a total of four strain gauges. These are arranged as a Wheatstone
bridge circuit and are supplied with a DC voltage by the electronics. The output voltage from the strain
gauges changes in direct proportion to the measured torque. This voltage is amplified before being
digitized by an analog/digital converter.
A 16-bit microprocessor processes these digital signals, encodes them and relays them to infrared LEDs,
which send the signals to the stator as a serial light signal.
The stator receives this light signal and converts it back into electrical pulses before sending it to another
microprocessor. This microprocessor controls a digital/analog converter which generates an analog
voltage again (16-bit resolution). This analog voltage is the sensor’s measurement signal. It is also
proportional to the measured torque.
3.3 Static and quasi-static torques
Static and quasi-static torques change their value only slowly or not at all. As long as they are below the
rated torque, these torques can take any value.
3.4 Dynamic torques
NOTICE
Resonance hazard!
Operating the torque sensor model 8661 or the entire test setup close to its resonant
frequency will result in permanent damage. Keep the torque frequency well below the
resonant frequency of the mechanical test setup. Limit the peak-to-peak torque variation
to 70 % of the rated torque.
Note: A calibration carried out for static torques is also valid for measuring dynamic torques, although
you must take into account the characteristics of the instrumentation amplifier you are using.

17 of 74
Determination of the resonant frequency
The resonant frequency of the entire test setup is related to the sensor’s spring constant “c” and to the
two moments of inertia “J1” and “J2”, each with the connected molding body.
Diagram 7: Resonant frequency model
f
0
:
Resonant frequency in Hz
J
1
:
Moment of inertia 1 in kg
*
m2
J
2
:
Moment of inertia 2 in kg
*
m2
c:
Spring constant in Nm / rad
The Holzer-Tolle method is another way to determine the resonant frequency.
3.5 Interference
Possible sources of interference:
•Temperature change
•Temperature gradient
•Vibration
•Spurious forces
•EMC
•Electrical interference
•Magnetic interference
•Angular, axial or radial misalignment (also see chapter 4.1 „Preparing for installation“ on
page 18).
IMPORTANT: Take suitable measures to counter these sources of interference because otherwise they
may cause an incorrect measurement result.

18 of 74
4 Installation
4.1 Preparing for installation
Run-in period
Before fitting the torque sensor model 8661 for the first time, we recommend turning the sensor by hand
through several revolutions. This may be needed in order to distribute the lubricant evenly around the
roller bearings of the torque sensor model 8661.
Shafts
We recommend an H7/j6 shaft fit to ensure correct assembly and good torque transfer.
Mounting surfaces
The mounting surfaces for the torque sensor model 8661 or for the optional mounting block must be free
of lubricants, particles or burrs.
Couplings and misalignments
Even if you align the torque sensor model 8661 precisely, there will always be a minimum misalignment
between the shafts. Therefore, when fitting the torque sensor model 8661, always use balanced
couplings that allow misalignment correction.
IMPORTANT: Before fitting the coupling, check its maximum rated speed.
We recommend using torsionally rigid multi-disk or bellows couplings for correcting misalignments.
Always use the full specified clamping length of the coupling.
Different kinds of misalignments
Diagram 8: Angular misalignment
Diagram 9: Axial misalignment, e.g. due to thermal expansion
Diagram 10: Radial misalignment
Both angular and axial misalignments can be corrected using “half-couplings”. Full couplings are needed,
however, to correct any radial misalignment. To find suitable couplings refer to the datasheet 8690 visit
www.burster.com.

19 of 74
4.2 Mechanical installation
4.2.1 Installation using mounting block
NOTICE
Avoid excessive torques, bending moments or axial forces!
Excessive torques, bending moments or axial forces may damage the torque sensor
model 8661. Connect the electrical cable to the torque sensor model 8661 during fitting
and monitor the measurement signal. This signal must remain within the permitted
range.
Support the torque sensor model 8661 during fitting to make sure it does not drop, and
do not resort to hammering to aid installation.
We recommend fitting the torque sensor model 8661 with an associated mounting block, model number
8661-Z00X. Mounting blocks have the advantage of an extra locating pin to help align the torque sensor
model 8661 easily. If the torque sensor model 8661 needs to be removed temporarily from the setup, the
mounting block avoids any time-consuming realignment when it is refitted.
In this case you will need to fit balanced full couplings at both shaft ends.
For suitable mounting blocks, see data sheet 8661. You'll find suitable couplings on datasheet 8690.
Diagram 11: Schematic measuring arrangement, fitted with a mounting block

20 of 74
Mounting instructions
1. Clean and de-burr the shafts and hubs and any other contact and mounting surfaces
on your components. At time of fitting, there must be no foreign matter, burrs or
lubricants on these components.
2. Fit the torque sensor model 8661 on the mounting block. Use the locating pin to centre
the torque sensor model 8661 on the mounting block then screw-fasten the sensor to
the block.
3. First roughly align the mounting block. Initially only loosely tighten the assembly bolts
on the mounting block.
4. Fit the full couplings on the shaft ends of the torque sensor model 8661. Always use
the entire clamping length of these couplings. If possible, fit the torque sensor model
8661 starting from the test side. Initially only loosely tighten the fixing screws on the
couplings.
5. Now align the mounting block precisely. This avoids any unnecessarily high reaction
forces, while also reducing the load on the coupling and any spurious forces acting on
the torque sensor model 8661. At low rotational speeds (< 2000 min-1), it is usually
sufficient to align the coupling using a straight edge in two perpendicular planes.
However, we recommend using a dial gauge or laser to align the coupling and shaft
ends.
6. Once you have fitted all shafts into the coupling hubs and correctly aligned all parts,
tighten the fixing bolts on the mounting block.
IMPORTANT: Make sure you do not move the mounting block when tightening.
7. Tighten each coupling to hold the shaft firmly, making sure you observe the following
requirements:
a. Start on the side that is easier to turn. Usually this will be the measurement
side.
b. Do not exceed the permitted torques. Use a torque wrench.
c. Hold screws from the other end when tightening.
d. Be aware of the maximum forces that you apply. The resultant torques must
lie below the rated torque of the torque sensor model 8661. The relevant
values are listed in the data sheet.
