Burster DIGISTANT 4463 User manual

OPERATION MANUAL
(preliminary)
DIGISTANT®
Model 4463
Manufacturer:
© 2023
burster
praezisionsmesstechnik gmbh & co kg
burster
praezisionsmesstechnik gmbh & co kg
All rights reserved
Talstr. 1 - 5
P.O. Box 1432
76593 Gernsbach
76587 Gernsbach
Germany
Germany
Valid from: 22.08.2023
Tel.: [phone]
Fax.: [phone]
Email: [e-mail]
www.burster.com
4427-BA4463EN-5999-081531

2of 86
Warranty disclaimer
All information in the present documentation was prepared and compiled with great care and reproduced
subject to effective control measures. No warranty is provided for freedom from errors. We reserve the
right to make technical changes. The present information as well as the corresponding technical data can
change without notice. Reproduction of any part of this documentation or its processing or revision using
electronic systems is prohibited without the manufacturer‘s prior written approval.
Components, devices and measured value sensors made by burster praezisionsmesstechnik (hereinafter
referred to as "product") are the results of targeted development and meticulous research. As of the date
of delivery, burster provides a warranty for the proper condition and functioning of these products
covering material and production defects for the period specified in the warranty document accompanying
the product. However, burster excludes guarantee or warranty obligations as well as any liability beyond
that for consequential damage caused by improper use of the product, in particular the implied warranty
of success in the market as well as the suitability of the product for a particular purpose. Furthermore,
burster assumes no liability for direct, indirect or incidental damages as well as consequential or other
damages arising from the provision and use of the present documentation.

3of 86

4of 86
Contents
1For your safety ........................................................................................................................... 6
1.1 Symbols used in this manual ....................................................................................................... 6
1.1.1 Signal words .................................................................................................................... 6
1.1.2 Pictograms ....................................................................................................................... 6
1.2 Symbols on the device ................................................................................................................. 7
2Introduction ................................................................................................................................ 8
2.1 Intended use................................................................................................................................. 8
2.2 Customer service ......................................................................................................................... 8
2.2.1Customer service department.......................................................................................... 8
2.2.2 Contact person................................................................................................................. 8
2.3 Download the test certificate ........................................................................................................ 8
2.4 Ambient conditions ....................................................................................................................... 9
2.4.1 Storage conditions ........................................................................................................... 9
2.4.2 Operating conditions ........................................................................................................ 9
2.4.3 Restrictions on use .......................................................................................................... 9
2.4.4 Cleaning ........................................................................................................................... 9
2.5 Personnel ................................................................................................................................... 10
2.6 Contents of pack ........................................................................................................................ 11
2.7 Unpacking .................................................................................................................................. 11
2.8 Warranty..................................................................................................................................... 11
2.9 Maintenance............................................................................................................................... 11
2.9.1 Fuse replacing ............................................................................................................... 11
2.10 Conversions and modifications .................................................................................................. 12
3Device design ........................................................................................................................... 12
3.1 Voltage supply............................................................................................................................ 12
4Controls and connections....................................................................................................... 13
4.1 Front panel ................................................................................................................................. 13
4.2 Front terminals ........................................................................................................................... 15
4.3 Rear view ................................................................................................................................... 16
4.4 Display........................................................................................................................................ 17
5Using the instrument for the first time................................................................................... 19
5.1 Power on .................................................................................................................................... 19
5.2 Warm-up time............................................................................................................................. 20
5.3 User language ............................................................................................................................ 20
5.3.1 Device information ......................................................................................................... 20
6Manual operation of the device .............................................................................................. 21

5of 86
6.1 Main menu ................................................................................................................................. 21
6.1.1 Settings menu ................................................................................................................ 21
6.2 Setting the function .................................................................................................................... 23
6.2.1 Voltage........................................................................................................................... 23
6.2.2 Current ........................................................................................................................... 24
6.2.3 TC .................................................................................................................................. 24
6.2.4 Frequency ...................................................................................................................... 25
6.2.5 RTD................................................................................................................................ 26
6.2.6 Resistance ..................................................................................................................... 26
6.3 Preset menu............................................................................................................................... 27
6.4 Setting the value of output signal............................................................................................... 27
7Remote control of the device.................................................................................................. 29
7.1 Remote control........................................................................................................................... 29
7.1.1 RS232 Interface............................................................................................................. 29
7.1.2 GPIB Interface (option) .................................................................................................. 30
7.1.3 LAN Interface (option).................................................................................................... 30
7.1.4 USB Interface (option) ................................................................................................... 31
7.1.5 Command syntax........................................................................................................... 32
7.1.6 SCPI Command Tree .................................................................................................... 33
7.1.7 Standard Status Data Structures ................................................................................... 37
7.1.8 SCPI Standard Commands ........................................................................................... 39
7.1.9 SCPI Commands ........................................................................................................... 42
7.1.10 SCPI Error codes........................................................................................................... 77
8Calibration ................................................................................................................................ 78
8.1 Calibration menu ........................................................................................................................ 78
8.2 Calibration data .......................................................................................................................... 78
8.3 Selection of calibration point ...................................................................................................... 79
8.4 Setting the new calibration data................................................................................................. 80
9Technical data .......................................................................................................................... 81
10 Disposal .................................................................................................................................... 86

6of 86
1 For your safety
The following symbols on the DIGISTANT®model 4463 and in this operation manual warn of hazards.
1.1 Symbols used in this manual
1.1.1 Signal words
The following signal words are used in the operation manual according to the specified hazard
classification.
DANGER
High degree of risk: indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING
Moderate degree of risk: indicates a hazardous situation which, if not avoided, may result in death or
serious injury.
CAUTION
Low degree of risk: indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
NOTICE
Property damage to the equipment or the surroundings will result if the hazard is not avoided.
Note: It is important to heed these safety notices in order to ensure you handle the DIGISTANT®
model 4463 correctly.
IMPORTANT: Follow the information given in the operation manual.
1.1.2 Pictograms
Electric shock hazard
Electrostatic discharge. Do not touch!
Take precautionary measures against static discharge.
High Voltage! Danger to Life!
Warning about dangerous electrical voltages.
Observe the advice for protecting the instrument.

7of 86
1.2 Symbols on the device
Symbol Description
Warning, reference to the documentation
Warning of electrical shock hazard
WARNING!
To prevent electrical
shock do not open
covers. Refer to
qualified personnel.
No user serviceable
parts inside.
Warning of electrical shock hazard.
Do not open covers.
CAUTION!
To prevent fire
replace only with
same type and
shown rating of fuse.
Caution of fire hazard.
Replace a fuse just with a fuse from the same type and the same nominal
capacity.

8of 86
2 Introduction
IMPORTANT: Read the operation manual carefully before using the equipment, and keep for future
reference.
2.1 Intended use
The instrument has been designed according to EN 61010-1:2011. Safety is ensured by the design and
by the use of specific component types.
2.2 Customer service
2.2.1 Customer service department
For repair inquiries, please telephone our Service department on [phone], or email:
[e-mail] (Germany only). If you are outside Germany, you should contact your burster agent
(see also www.burster.com).
Please have the serial number to hand. The serial number is essential to establishing the definite
technical status of the instrument and providing help quickly. You will find the serial number on the type
plate of the DIGISTANT®model 4463.
2.2.2 Contact person
If you have any questions relating to the DIGISTANT®model 4463, please go directly to burster
praezisionsmesstechnik gmbh & co. kg, or if outside Germany, please contact your burster agent (see
also www.burster.com).
Head office
burster praezisionsmesstechnik gmbh & co kg
Talstr. 1 - 5
76593 Gernsbach Germany
Telephone: [phone]
Fax: [phone]
Email: inf[email protected]om
2.3 Download the test certificate
You have the option to download the test certificate for your DIGISTANT®model 4463 online. To do this,
you need to register at http://www.burster.com/en/registration/. You can then download the test certificate
directly by entering the serial number.

9of 86
2.4 Ambient conditions
2.4.1 Storage conditions
The following requirements must be met when storing the DIGISTANT®model 4463:
•Store at temperatures between -10 °C and +55 °C
•The unit must be packed in clean packaging
•Store in a dry environment
•No condensation
2.4.2 Operating conditions
The following requirements must be met when operating the DIGISTANT®model 4463:
•Always operate indoors
•Operate at temperatures between +5 °C and +45 °C
•Maximal power consumption: 60 VA
•Reference temperature: +16 °C … +30 °C
•Power supply: 115/230 VAC, 47 … 63 Hz
Note: Avoid condensation after transportation or storage of the DIGISTANT®model 4463.
2.4.3 Restrictions on use
The DIGISTANT®model 4463 does not pose a hazard if used within its specification and in accordance
with the safety regulations.
The manufacturer does not accept liability for any personal injury or property damage arising from
misinterpretation of measurement results.
Note: The DIGISTANT®model 4463 is not intended as a substitute for safety devices and protective
equipment. Use safety devices and protective equipment.
2.4.4 Cleaning
DANGER
Electrical shock hazard
Disconnect the DIGISTANT®model 4463 from the power supply before cleaning.
Disconnect the DIGISTANT®model 4463 from the power supply and use a slightly damp cloth for
cleaning the unit.
CAUTION
Do not immerse the DIGISTANT®model 4463 in water or hold it under running water.
Do not use strong cleaning agents as these may damage the DIGISTANT®model 4463.
Use a slightly damp cloth to clean the DIGISTANT®model 4463.

10 of 86
External surface cleaning
To keep the device looking like new, clean the case and front panel keys using a soft cloth slightly
dampened with either water or a non-abrasive mild cleaning solution that is not harmful to plastics.
2.5 Personnel
Personnel must be familiar with the relevant regulations. They must follow these regulations. Only trained
personnel who are familiar with the applicable safety regulations are permitted to operate the
DIGISTANT®model 4463.
burster is happy to provide your operating personnel with training on the DIGISTANT®model 4463. To
find out more, please look at our range of services at www.burster.com.
