BuzziSpace BuzziNest Pod User manual

BuzziNest Pod
INSTALLATION MANUAL
US

2
Content
Foreword......................................................................................3
Fire Safety. ........................................................................................4
Electrical Safety...................................................................................4
Installation, maintenance and disassembly...........................................5
Use...................................................................................................7
Markings......................................................................................9
Wiring Diagram..........................................................................11
Assembly instructions.................................................................12
Move Pod .................................................................................71

3
Foreword
Safety Instructions
Important safety and product instructions
Preface
This instruction manual shows the necessary information for the
installation of the product. Make sure that everyone involved in the
installation has read and understands the contents of the installation
and the safety instructions.
Review the assembly instructions to conrm that the appropriate critical
components and accessories are being used with the furnishing.
These prefabricated modules and assemblies are intended for
installation rearrangement and inspection in accessible locations in
accordance with Article 604 of the NEC. AHJs should be consulted prior
to installation.
 SAVE THESE INSTRUCTIONS
Product Information
The information in this manual is valid at the time of publication and
corresponds to the product at the time of delivery.
Intended use
BuzziNest Pod is intended for short term indoor commercial and
household use by four (4) persons at a time.
 WARNING: To reduce the risk of burns, re, electric shock or injury
to persons: Use this product only for its intended use as described in
the user instructions. Do not use attachments not recommended by the
manufacturer.

4
Fire Safety
WARNING!
To reduce the risk of burns, re, electric shock or
injury to persons, obey the following:
In case of a re inside the booth, disconnect the power cord
when it’s safe to do so.
The power cable serves as a power cut device for pluggable
equipment.
The power outlet must be near the equipment and easily
accessible.
Fire and safety devices like sprinklers or alarms can be installed in the
booth (separate instructions on demand).
The need for re and safety devices in the booth shall always be
determined by the applicable local authorities.
Electrical Safety
Input for the electrical system: 120V AC 15A 50-60Hz
The maximum load for the electrical system is 15A.
DANGER!
To reduce the risk electric shock, obey the
following:
In non-hardwired products:
Always unplug this furnishing from the electrical outlet
before cleaning or servicing.
Unplug from outlet before putting on or taking off parts
Never operate this furnishing if it has a damaged cord or
plug, if it is not working properly, if it has been dropped or
damaged.
Connect this furnishing to a properly grounded outlet only
In case of a re inside the booth, disconnect the power cord
when it’s safe to do so.
In hardwired products:
Always disconnect this furnishing from the electricity
network before disassembly, cleaning or servicing.

5
WARNING!
To reduce the risk of burns, re, electric shock or
injury to persons, obey the following:
Connect the power cord to a properly grounded outlet only.
Keep the power cord of the product away from the heated
surfaces.
Do not use the BuzziNest Booth if you notice any defects or
damage to the electrical equipment.
Do not connect any extension cords to the power outlet(s) of
the product.
Installation, maintenance and disassembly
WARNING!
To reduce the risk of burns, re, electric shock or
injury to persons, obey the following:
Use cut resistant safety gloves during the installation,
maintenance os disassembly of the product.
Use Steel toed safety boots during the installation,
maintenance or disassembly of the product.

6
Wear safety goggles when installing, maintaining or
disassembling the product.
Read and follow closely the instructions. Plan your work and
work your plan.
Local rules and regulations with regards to workplace safety
must be respected.
Keep the work area clear of debris during installation,
maintenance or disassembly.
No load allowed on top of the product, do not climb onto
the product.
Do not move or push the product without disconnecting the
power cord and activating the wheels.

7
Use
The maximum load for the BuzziNest Pod Table is 110 lbs (50 kg)
The maximum load for the BuzziNest Cube is 300 lbs (136 kg)
WARNING!
To reduce the risk of burns, re, electric shock or
injury to persons, obey the following:
Read and follow closely the instructions before using the
product.
Close supervision is necessary when this furnishing is used
by, or near children, invalids, or disabled persons.
Keep children away from extended foor support (or other
simular parts).
The air inside the product is extracted from the surrounding
area, if this surrounding area is in anyway hazardous, do
not use the product.
Do not use the product in case of a non-working
ventilation.
Do not use the product in case of blocked ventilation
channels, make sure the ventilations channels are kept
open and free from any dust uff, hair and such.
Never operate this furnishing if it has any defects in the
electrical equipment, if it is not working properly, if it has
been dropped or damaged. disconnect this furnishing from
the electricity network and contact your dealer.

8
Do not insert any objects or drop anything into any of the
unit’s openings unless it’s instructed in the manual.
Do not use outdoors
Do not use where aerosol (spray) products are being used
or where oxygen is being administered.
No load allowed on top of the product, do not climb onto
the product.
Do not lean against the product
No smoking allowed inside the product.

9
Markings
BuzziNest Pod
Label Label Text
1. Product/ Produit: BuzziNest Pod
Input/Entrée: 120V AC 15A 50-60Hz
Manufacturer/Fabricant: BuzziSpace
Web: www.buzzi.space
Email: [email protected]
Made in Lithuania / Fabriqué en Lituanie
Evaluated to ASTM E84, smoke developed index over 450. /
Évalué selon ASTM E84, indice de fumée développé supérieur
à 450. Powered
Furniture
EXXXXX
Product/ Produit: BuzziNest Pod
Input/Entrée: 120V AC 15A 50-60Hz
Manufacturer/Fabricant: BuzziSpace
Web: www.buzzi.space
Email: [email protected]
Made in Lithuania / Fabriqué en Lituanie
Evaluated to ASTM E84, smoke developed index
over 450. / Évalué selon ASTM E84, indice de
fumée développé supérieur à 450.
1
23
4

10
2. SN/N° de série: .
MANUFACTURE DATE / DATE DE FABRICATION: MM/YYYY SN/N° de série: .
MANUFACTURE DATE / DATE DE
FABRICATION: MM/YYYY
3.
WARNING
Risk of re and shock!
Use Only SJT type 16 AWG cord.
See installation manual for instruction on
how to hard wire to mains supply.
Kit Code: 881
WARNING
Risk of re and shock! Use Only SJT type 16
AWG cord. See installation manual for
instruction on how to hard wire to mains supply.
Kit Code: 881
AVERTISSEMENT
Risque d’incendie et d’électrocution !
Utilisez uniquement un cordon de type SJT 16 AWG.
Consultez le manuel d’installation pour savoir
pour savoir comment se connecter au réseau
électrique.
Code du kit : 881
AVERTISSEMENT
Risque d’incendie et d’électrocution !
Utilisez uniquement un cordon de type SJT 16
AWG. Consultez le manuel d’installation pour
savoir pour savoir comment se connecter au
réseau électrique. Code du kit : 881
4. This furnishing has not been evaluated for
ammability or cigarette ignition resistance.
L’inammabilité ou la résistance à l’allumage
d’une cigarette n’a pas été évaluée pour cette
garniture.
This furnishing has not been evaluated for
ammability or cigarette ignition resistance.
L’inammabilité ou la résistance à l’allumage
d’une cigarette n’a pas été évaluée pour cette
garniture.

11
BuzziNest Booth with optional table
Label Label Text
1. Product/ Produit: BuzziNest Pod
Input/Entrée: 120V AC 15A 50-60Hz
Manufacturer/Fabricant: BuzziSpace
Web: www.buzzi.space
Email: [email protected]
Made in Lithuania / Fabriqué en Lituanie
Evaluated to ASTM E84, smoke developed index over 450. /
Évalué selon ASTM E84, indice de fumée développé supérieur
à 450. Powered
Furniture
EXXXXX
Product/ Produit: BuzziNest Pod
Input/Entrée: 120V AC 15A 50-60Hz
Manufacturer/Fabricant: BuzziSpace
Web: www.buzzi.space
Email: [email protected]
Made in Lithuania / Fabriqué en Lituanie
Evaluated to ASTM E84, smoke developed index
over 450. / Évalué selon ASTM E84, indice de
fumée développé supérieur à 450.
4
5
1
23
6

12
2. SN/N° de série: .
MANUFACTURE DATE / DATE DE FABRICATION: MM/YYYY SN/N° de série: .
MANUFACTURE DATE / DATE DE
FABRICATION: MM/YYYY
3. WARNING
Risk of re and shock!
Use Only SJT type 16 AWG cord.
See installation manual for instruction on
how to hard wire to mains supply.
Kit Code: 881
WARNING
Risk of re and shock! Use Only SJT type 16
AWG cord. See installation manual for
instruction on how to hard wire to mains supply.
Kit Code: 881
AVERTISSEMENT
Risque d’incendie et d’électrocution !
Utilisez uniquement un cordon de type SJT 16 AWG.
Consultez le manuel d’installation pour savoir
pour savoir comment se connecter au réseau
électrique.
Code du kit : 881
AVERTISSEMENT
Risque d’incendie et d’électrocution !
Utilisez uniquement un cordon de type SJT 16
AWG. Consultez le manuel d’installation pour
savoir pour savoir comment se connecter au
réseau électrique. Code du kit : 881
4. WARNING Risk of injury
The maximum load for the BuzziNest Pod Table
is 110 lbs (50kg)
L’ AVERTISSEMENT Risque de blessure
Poids maximal pour BuzziNest Pod Table
est de 110 lbs (50 kg)
WARNING Risk of injury
The maximum load for the BuzziNest Pod Table
is 110 lbs (50kg)
L’ AVERTISSEMENT Risque de blessure
Poids maximal pour BuzziNest Pod Table
est de 110 lbs (50 kg)
5. Max. 14A Max. 14A
6. This furnishing has not been evaluated for
ammability or cigarette ignition resistance.
L’inammabilité ou la résistance à l’allumage
d’une cigarette n’a pas été évaluée pour cette
garniture.
This furnishing has not been evaluated for
ammability or cigarette ignition resistance.
L’inammabilité ou la résistance à l’allumage
d’une cigarette n’a pas été évaluée pour cette
garniture.

13
Wiring Diagram
Note: Only a certied electrician compliant with all local rules and
regulations can install the same metal conduit cable.
Fan LED
AC
DC
µController
AC
AC
DC
DC
Power socket USB socket Power socket USB socket
Corded Infeed 12AWG wires in 3/4" flexible metal conduit
Female/Female/Male 3-way Jumper
Male to Male jumper
Male to Female Jumper
Fan
Dean 2 Power - USB outlet
Electrics enclosure
12Vdc <15W
Relay
14-40Vdc 40W max
L N PE
Black White Copper Red (not used)N/C
IEC C14 Infeed Assy 12AWG wires in zintec enclosure
Corded Infeed 12AWG wires in 3/4" flexible metal conduit
L N
PE
N/C
Black White Copper Red (not used)

14
2 PERS. 
BuzziNest Pod
Excluded
5 mm
5 mm
8 mm
4x
M8 x 40 mm
Black
M8 x 50 mm
16x
8x
M8 x 30 mm
16x
4 x 45 mm
4 x 16 mm
Included
Red
Yellow
Orange
Purple
8x
28x
Pink 4,8 x 19 mm
M8 x 65 mm
White
16x
M10 x 25 mm
M10 x 40 mm
Grey
Turquoise
17x
8x
M8 x 20 mm
Blue
1x
6 mm
3 mm

15
1x
3x 2x
4x 4x 1x 1x 1x
1x
2x 1x

16
2x
2x
1x
1x
2x
4x
2x
1x
1x 1x hardwired kit 881

17
O p t i o n a l T a b l e a n d e l e c t r i  c a t i o n
No Table
1x
1x
1x
1x
1x
M10 x 20 mm
4x
M10 x 40 mm
Green
4x
Green
1x
1x
1x
4x Pink
4,8 x 19 mm

18
2
1

19
3
4
Min. 1m
6 mm
M10 x 40 mm Turquoise
8x

20
5

8 mm
OK NOK
