PRODUCT INFORMATION
BULLETIN
105 Bonnie Drive
Butler, PA 16002
724-283-4681
724-283-5939 (fax)
www.bwieagle.com
AIR-EAGLE®XLT
900 MHz RF Transmitter
MODEL 441-1400-BAT
DESCRIPTION
The AIR-EAGLE XLT TX Is an R.F. transmitter capable of sending four
independent dry-contact input commands to an Air-Eagle XLT
Receiver located up to 2500 feet away (longer ranges can be achieved
with external high gain antennas). Any number of transmitters and
receivers can be combined to create a medium range radio frequency
system that operates hazardous or hard-to-reach electrical apparatus
from safe, convenient locations. Eight user-selectable frequencies
allow multiple systems to operate simultaneously in the same area
without interference.
APPROVALS
United States (FCC)
MCQ-XB900HP
Canada (IC)
1846A-XB900HP
INSTALLATION
1. Mount the AIR-EAGLE XLT TRANSMITTER in a convenient location.
2. Install wiring to contact input terminal strip (Note –the terminal block
header lifts up off the basefor easy wiring)
3. Install the 2 AA Lithium batteries that were provided.
4. Attach supplied antenna to connector on right side of unit.
TERMINAL STRIP WIRING
Wire as shown based on number of contact inputs
1
2
3
4
5
6
7
8
9
10
C Input 1
Input 1
C Input 2
Input 2
C Input 3
Input 3
C Input 4
Input 4
Not Used
Not Used
GENERAL OPERATION
A closure on any input transmits its channelcommand to activate the
corresponding relay in the remote receiver. The transmission continues as
long as the input is closed and ceases when the input opens.
Dimensions (with mounting plate) 6.3” L x 4.8” W x 2.3” H
CONTROLS & INDICATORS
TX LED
Illuminates green when power is applied. Changes to
red while any contact input is closed and unitis
transmitting. When this LED blinks briefly following a
transmission, the battery needs to be replaced.
Dry Contact Inputs
Transmits individual RF codes to the receiver
SEL2
Dip switch bank for digital address selection
SEL1
Dip switch bank for frequency selection

AIR-EAGLE®XLT
900 MHz RF Transmitter
MODEL 441-1400-BAT
DIGITAL ADDRESS & FREQUENCY SET-UP
This transmitter is factory programmed toDigital Address “1”and
Frequency “1”. These settings can be changed by the user in any
combination but must match the receiver that is set up to
communicate with this transmitter. Note –only change digital
address if using with a digitally addressable receiver. Otherwise, the
digital address must be kept at the default of Digital Address “1”.
1) Remove power from unit.
2) Remove top cover.
3) Select desired digital address and/or network frequency using table
below.
4) Reattach cover and apply power.
5) Programming is now complete.
DIGITAL ADDRESS SET-UP
SEL2 (SW1 –4)
SEL2
(SW1-4)
Digital
Address
SW1
SW2
SW3
SW4
1 (default)
OPEN
OPEN
OPEN
OPEN
2
CLOSED
OPEN
OPEN
OPEN
3
OPEN
CLOSED
OPEN
OPEN
4
CLOSED
CLOSED
OPEN
OPEN
5
OPEN
OPEN
CLOSED
OPEN
6
CLOSED
OPEN
CLOSED
OPEN
7
OPEN
CLOSED
CLOSED
OPEN
8
CLOSED
CLOSED
CLOSED
OPEN
9
OPEN
OPEN
OPEN
CLOSED
10
CLOSED
OPEN
OPEN
CLOSED
11
OPEN
CLOSED
OPEN
CLOSED
12
CLOSED
CLOSED
OPEN
CLOSED
13
OPEN
OPEN
CLOSED
CLOSED
14
CLOSED
OPEN
CLOSED
CLOSED
15
OPEN
CLOSED
CLOSED
CLOSED
16
CLOSED
CLOSED
CLOSED
CLOSED
SEL2 (SW5-7) –Leave in OPEN position!!
FREQUENCY SET-UP
SEL1 (SW1-3)
SEL1
(SW1-3)
Network
Frequency
SW1
SW2
SW3
1 (default)
OPEN
OPEN
OPEN
2
CLOSED
OPEN
OPEN
3
OPEN
CLOSED
OPEN
4
CLOSED
CLOSED
OPEN
5
OPEN
OPEN
CLOSED
6
CLOSED
OPEN
CLOSED
7
OPEN
CLOSED
CLOSED
8
CLOSED
CLOSED
CLOSED
SEL1 (SW4) –Not used on this model
SPECIFICATIONS
Power Requirements
3.0 VDC
Battery Type
(2) 1.5V lithium or alkaline each, size AA,
to equal 3.0VDC nominal.
Battery Life
(Active Usage)
Approximately 3 months
Battery Life (Idle)
Up to 1 Year
Transmit Data
Four Dry Contact Inputs
Transmit Frequency
900MHz Spread Spectrum
RF Output Power
250 mW
Transmit Range
Up to 2500 Feet w/standard antenna
Note: Range figures are estimates, based on free-air terrain with limited sources of
interference. Actual range will vary based on transmitting power, orientation of
transmitter and receiver, height of transmitting antenna, height of receiving antenna,
weather conditions, interference sources in the area, and terrain between receiver and
transmitter, including, but not limited to, indoor and outdoor structures such as walls,
metal objects, trees, buildings, hills, and mountains.
RF Networks
Eight Independent Frequencies
Enclosure
Polycarbonate, IP66 (NEMA 4)
Operating
Temperature
-40oF to +185oF
ACCESSORIES
Standard Antenna (Included):
900MHz TNC “Rubber Duck” Antenna
49-1103
Mobile/Base Antennas –
Used to help achieve max range in both nonline of sight andline of
sight applications. - ContactBWI Eagle for recommendations
900MHz Thru-Hole Mount Mobile Antenna
49-2101
900MHz Magnet Mount Mobile Antenna
49-2102
900MHz Omni Directional Base Antenna
49-3101
900MHz Yagi Directional Base Antenna
49-3102
High Quality Coax Cables –
Used to connect external high gain antennas to control unit
Flex Coax Cable w/Connectors –Available in
5’,15’,25’,30’,40’,60’,80’,100’ Lengths
49-4000-XX
(XX = # of Feet)
Bulkhead Extensions –
Used to provide an external antenna connection whenmounting
control unit inside another enclosure
TNC Male to TNCBulkhead Cable Assembly
- Available in 2’, 4’, 7’ Lengths
49-5004-X-ISO
(X = # of Feet)
LIMITED WARRANTY STATEMENT
BWI Eagle Inc. warrants the Air-Eagle Remote Control System, ifproperly used and
installed, will be free from defects in material and workmanship for a period of 1 year
after date of purchase. Said warranty to include the repair or replacement of defective
equipment. This warranty does not cover damage due to external causes, including
accident, problems with electrical power, usage not in accordance with product
instructions, misuse, neglect, alteration, repair, improperinstallation, or improper
testing. This limited warranty, and any implied warranties that may exist under state
law, apply only to the original purchaser of the equipment, and last only for as long as
such purchasercontinues to own the equipment. This warranty replaces all other
warranties, express or implied including, but not limited to, the implied warranties or
merchantability and fitness for a particular purpose. BWI Eagle makes no express
warranties beyond those stated here. BWI disclaims without limitation, implied
warranties of merchantability and fitness for a particular purpose. Some jurisdictions
do not allow the exclusion of implied warranties so this limitation may not apply to
you. To obtain warranty service, contact BWI Eagle for a return material
authorization. When returning equipment to BWI Eagle, the customer assumes the
risk of damage or loss during shipping and is responsible for the shipping costs
incurred.
DOCUMENT DATE: 07/22/2021 / PRODUCT REV. 5
