AIR
-
EAGLE
®
SR
2.4 GHz RF Transmitter
MODEL 38-1500
DESCRIPTION
The AIR-EAGLE SR PLUS TXIs a handheld R.F. transmitter capable of
sending up to sixteen unique digital commands to an Air-Eagle SR
Receiver located up to 300 feet away. Any number of transmitters and
receivers can be combined to create a short range radio frequency
system that operates hazardous or hard-to-reach equipment from safe,
convenient locations. Eight user-programmable frequencies allow
multiple systems to operate simultaneously in the same area without
interference. This transmitter will automatically go into “sleep” mode
when no buttons are being depressed on the unit to dramatically
extend battery life.
APPROVALS
United States (FCC) OUR-XBEEPRO
Canada (IC) 4214A-XBEEPRO
Europe (CE) ETSI
INITIAL OPERATION SET-UP
This transmitter comes readyto operate, withbatteries installed, and
factory programmed to Frequency #1. Nosetup is necessary unless you
wish tochange frequencies.
For example, if you are setting up this transmitter to use with an
existing system that is operating on Frequency #1, no change in this
setting is necessary. However, if you wish to operate this unit with a
receiver on another network, follow the programming procedure on the
next page to change the frequency setting appropriately
Dimensions: 4.72” L x 2.56”W x .88” D
(Note – belt clip adds .48” to depth)
CONTROLS & INDICATORS
TX LED
LED illuminates “RED” continuously while
button is depressed and unit is transmitting.
When this LED blinks brieflyfollowing a
transmission, the battery needs to be
replaced. See note*
Pushbuttons 1 thru 8 Transmit individual button RFcodes to the
receiver
Pushbutton P/Shift
The P/Shift button performs two functions:
1. If button is depressed momentarily and
anotherbuttonis then pressed within 3
seconds, the higher code forthat button is
transmitted. This allows for transmission of
pushbutton codes 9 thru 16.
2. If button is depressed for longer than 3
seconds, the transmitter will enter
“programming” mode. See PROGRAMMING
section.
Pushbuttons 9 thru 16
Used to communicate with a second receiver
– will activate Relays 1 thru 8
INDIVIDUALLY in the second receiver (no
dual relay activation capability)

AIR
-
EAGLE
®
SR
2.4 GHz RF Transmitter
MODEL 38-1500
PROGRAMMING
Please read through these instructions completely before beginning
programming procedure!
At any time, you can check the current frequency setting by depressing
Button 9,for approximately 4 seconds, until the TX LED is illuminated
“RED”. Then release all buttons and watch until the TX LED begins to
blink. The TX LED will blink “RED” one, two, three or four times for
Frequencies 1 thru 4, or will blink “GREEN” one, two, three or four times
for Frequencies 5 thru 8 accordingly. See table below forclarification.
LED Flashes:
Indicates Unit is Operating On:
RED
–
one time
Frequency 1
RED
–
two times
Frequency 2
RED
–
three times
Frequency 3
RED
–
four times
Frequency 4
GREEN
–
one time
Frequency 5
GREEN
–
two times
Frequency 6
GREEN
–
three times
Frequency 7
GREEN
–
four times
Frequency 8
To change the setting, follow these steps:
To select from Frequencies 1 thru 8:
1. DepressButton 9 until the TX LED is illuminated “RED”.
(Approximately 4 seconds)
2. Release Button 9, then while the TX LED is still illuminated
“RED”, depress button #1 to select “Frequency 1” or button #2
toselect “Frequency 2” etc. Ifthe transmit LED goes out before
you have selected a network, no settings will have changed,
and the LED will blink corresponding to the frequency thatthe
TX is currently set to. Youmust then begin again atstep 1 if
you wish to change the current setting.
3. The TX LED will blink to confirm that your frequency selection
has been accepted, and then will go out. For instance, if you
have selected Frequency #1, the TX LED will blink “RED”once
to confirm. If you have selected Frequency #6, the TX LED
blinks “GREEN” two times to confirm.
Programming is now complete andthe transmitter is active for normal
operation.
You may repeat the above procedure if you wish to change the frequency
at any time. See note*in SPECIFICATIONS.
SPECIFICATIONS
Keypad
Durable Sealed Membrane Keypad –
Eliminates Dust, Dirt and Moisture
Failures
Enclosure ABS Plastic – withIP66 Rating
Power Requirements 3.0 VDC
Battery Type (2) 1.5V lithium each, size AAA , to
equal 3.0VDC nominal.
*Note: Current frequencysettings are maintained in flash
memory during batteryreplacement. No reprogramming of
frequency settings is necessary!
Battery Life(Active Usage) Up to 6months
Battery Life(Sleep Mode) Up to 1 Year
Transmit Frequency 2.4GHz Spread Spectrum
RF Output Power 1 mW
Transmit Channels Eight Independent Network
Frequencies
Transmit Range Approximately 300 Feet
Operating Temperature -40oF to +185oF
LIMITED WARRANTY STATEMENT
BWI Eagle Inc. warrants the Air-Eagle Remote Control System, if properly
used and installed, will be free from defects in material and workmanship
for a period of 1 year after date of purchase. Said warranty to include the
repair or replacement of defective equipment. This warranty does not
cover damage due to external causes, including accident, problems with
electrical power, usage not in accordance with product instructions,
misuse, neglect, alteration, repair, improperinstallation, or improper
testing. This limited warranty, and any implied warranties that may exist
understate law, apply onlyto the original purchaser of the equipment, and
last only for as long as such purchaser continues to own the equipment.
This warrantyreplaces all other warranties, express orimplied including,
but not limited to, the implied warranties or merchantability and fitness for
a particular purpose. BWI Eagle makes no express warranties beyond
those stated here. BWI disclaims without limitation, implied warranties of
merchantability and fitness for a particular purpose. Some jurisdictions do
not allowthe exclusion of implied warranties so this limitation may not
apply to you. To obtain warrantyservice,contact BWI Eagle for a return
material authorization. When returning equipment to BWI Eagle, the
customer assumes the risk of damage or loss duringshipping and is
responsible for the shipping costs incurred.
DOCUMENT DATE: 21-Feb-12 / REV. 3
