C-Aire Companion 5 User manual

PROVIDER TECHNICAL MANUAL
Companion 5
Oxygen Concentrator

General Information ............................................................ 3
Warning and Caution Statements ..................................... 3
Introduction to the Companion 5 Oxygen Concentrator.. 4
Companion 5 Oxygen Concentrator Specifications........... 5
Provider Support Policy ....................................................... 6
Electromagnetic Compatibility............................................ 7
Guidance and Manufacturer’s Declaration - electromagnetic
emissions .................................................................... 7
Guidance and manufacturer’s declaration–electromagnetic
immunity .................................................................... 8
Guidance and manufacturer’s declaration–electromagnetic
immunity .................................................................... 9
Recommended separation distances
between portable and mobile RF communications equip-
ment and the Companion 5...................................... 10
Theory of Operation .......................................................... 11
Introduction.................................................................... 11
Pressure Swing Adsorption ............................................. 11
Flow Delivery .................................................................. 12
Electrical Operation ........................................................ 12
Microprocessor ............................................................... 13
4-Way Solenoid Valve ..................................................... 13
LCD Display .................................................................... 13
Audible Alarm ................................................................ 13
LED Lights....................................................................... 13
OCSI Sensor – (OCSI units only) ..................................... 14
Serial Number Identification............................................ 14
End of Life...................................................................... 14
User Controls And System Status Indicators .................... 15
Indications for Use ............................................................. 16
Contraindications ............................................................... 16
Introduction ....................................................................... 16
Pre-Delivery Check List.................................................... 16
Using Around the House................................................. 17
Locating the Companion 5 for Proper Use and Ventilation17
Power On and Warm Up................................................. 17
Adjust Flow Control Rate................................................ 18
Maintenance–Patient ......................................................... 19
Clean and Care for Tubing and
Cannula.................................................................... 19
Clean the Cabinet........................................................... 19
Patient Training Checklist................................................ 19
Table of Contents
Preventive Maintenance—Provider .................................. 20
Introduction.................................................................... 20
Maintenance Check List.................................................. 20
Maintenance Schedule....................................................... 20
Preventive Maintenance Check list .................................. 20
Oxygen Concentration Check ......................................... 20
Maintenance Procedures ................................................... 21
Oxygen Concentration Test ............................................. 22
Record Hours of Operation ............................................. 23
Hour Meter..................................................................... 23
Cleaning the Companion 5 ............................................ 23
Shipping and Transporting the
Companion 5............................................................ 23
Storing the Companion 5 ............................................... 23
Discarding ...................................................................... 23
Provider Service and Maintenance Record ....................... 24
Troubleshooting, Service, and Repair Procedures............ 25
Troubleshooting Table ..................................................... 26
Alarm Conditions and Alarm Codes.................................. 28
Warning Alarms.............................................................. 28
Outer Case ..................................................................... 30
Outlet Pressure Test ........................................................ 31
Flow Rate Test................................................................. 32
Start-up Verification Test................................................. 33
Power Failure Alarm Test................................................. 33
Product Regulator Check and Setting.............................. 33
Adjusting the Product
Regulator for Normal Operation................................ 33
Pressure Regulator Replacement ..................................... 33
Flapper (Check) Valve...................................................... 34
Compressor ................................................................... 34
Printed Circuit Board (PCB) ............................................. 35
4-Way Solenoid Valve ..................................................... 35
Sieve Bed Assembly ........................................................ 36
Cooling Fan.................................................................... 36
Power Switch ................................................................. 37
Flow Meter .................................................................... 37
Power Cord .................................................................... 37
Leak Testing.................................................................... 37
Parts Price List..................................................................... 38
Optional Accessories....................................................... 39
CAIRE Inc. Customer Service Contact Information........... 40

Oxygen Concentrator
PN 14940837 B — 3
General Information
This technical manual will familiarize you with Provider-specific
information regarding the Companion 5 oxygen concentrator.
Instructions in this manual are intended to help ensure that:
• Providers are familiar with Companion 5 system components
and system principles of operation
• Providers are given proper guidance in the use of the Com-
panion 5 and its accessories that can be conveyed to patients
• Providers are made aware of the care, diagnostics, mainte-
nance, and repair of the Companion 5
Warning and Caution Statements
Safety instructions are defined as follows:
WARNING: Important safety information for hazards that
might cause serious injury.
CAUTION Important information for preventing damage to
the Companion 5.
Note: Places emphasis on an operating characteristic or
important consideration.

Oxygen Concentrator
PN 14940837 B — 4
Introduction to the Companion 5 Oxygen Concentrator
FRONT
Companion 5
LED Display
Power Switch
Flow Meter
Oxygen
Outlet Barb
Humidifier
Bottle Support
Stand (Bottle
optional)
LCD Display
Outer Case
BACK
Exhaust Vent
Air Inlet
Air Inlet

Oxygen Concentrator
PN 14940837 B — 5
Companion 5 Oxygen Concentrator Specifications
Dimensions (H x W X D) 21.5 x 12.5 x 13.5 inches
(54.6cm x 31.8cm x 34.3cm)
Weight
Companion 5 36.0 lb (16.3 kg)
Flow Settings
Continuous Flow (measured in Liters Per Minute
LPM) 0.5 to 5.0 LPM
Continuous Flow Accuracy +/- 10% or 200ml/min, whichever is greater
Oxygen Concentration 90% (+5.5/-3%) for all flow settings
Oxygen Output Pressure 4.6 psig (31.7 kPa) nominal
LED Status Indicators
Green Light = Normal Operation
Red = Indicates ow rate error, loss of power, ambient pressure
reading out of range, or general system malfunction.
Yellow Light = Poor Oxygen Concentration below 85% (OCSI
models only)
Nominal Sound Level
2.0 LPM Continuous Flow 40 dB(A)
Operating Environment
Temperature
Humidity
41º F to 104º F (5° to 40°C)
10% to 95%, Non-condensing, 82.4°F (28°C) Maximum Dew
point
Storage Environment
Temperature
Humidity
-40º F to 158º F (-40° to 70°C)
Up to 95% Non-condensing
Altitude Operating Range -1253 to 9878 ft (-382 to 3010 m)
Nominal Power 250 watts at 2.0 LPM, 350 Watts Maximum
Fuse Rating 230VAC unit: T4AL, 250V
120VAC unit: T8AL, 250V
Continuous Flow Indication Expressed in liters per minute (LPM)
Audible Alarm Indicators See ALARM CONDITION AND ALARM CODES
Back-Up Alarm Power Capacitor
Filters HEPA, Compressor Intake Filter
Device Classification IEC Class II, Type BF Applied Part, IPX1
Note: To ensure there is no power to the Companion 5
oxygen concentrator, please unplug cord.

Oxygen Concentrator
PN 14940837 B — 6
Independent Safety Testing
Safety IEC 60601-1 :1988 + A1 :1991 + A2 :1995 + Corrigendum (6/95)
EN 60601-1(1990) + A1(1993) + A2(1995) + A12(1993) + A13(1996) + Corrigenda (7/94)
Electromagnetic
Compatibility
FCC 15B (Sec. 107 & 109), EN55011, EN60601-1-2 :2001, EN61000-3-2, EN61000-3-3,
IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-8,
IEC61000-4-11, IEC 60601-1-2 :2001
The CAIRE Companion 5 is designed to comply with the following standards:
• EN 60601-1-2—Electromagnetic Compatibility
• IEC 60601-1—General Requirement for Basic Safety of Electrical Medical Equipment
• ISO 8359—Oxygen Concentrators For Medical Use
• ISO 13485—Medical Device Quality System
• UL 60601-1 – General Requirement for Basic Safety of Electrical Medical Equipment
It is classified as Class 2 Medical Device by the United States Food and Drug Administration (FDA) and as a Class IIA device by
the European Medical Device Directive (MDD).
Provider Support Policy
Objective: As a manufacturer our organizational goal is to provide customer support and assistance to the highest level of excellence.
Customers are Providers (which include Dealers, Distributors and Agents).
Support includes, but is not limited to, troubleshooting and Return Material Authorizations (RMA).
Business Hours are Monday – Friday, 8:30am – 5:00pm EST.
CAIRE Inc. can only support customers who are recognized as Providers, Dealers, Distributors and/or Agents.
These partnerships are qualified as having an existing account or are in the process of credit application completion. All patient or end-
user inquiries including but not limited to RMA, warranty or serial number questions must be handled by their Provider.
Provider Support Policy: CAIRE Inc. is unable to provide direct assistance, clinical advice or recommendations to a patient or end-
user. Providers have sole responsibility in assisting their patients.

Oxygen Concentrator
PN 14940837 B — 7
Electromagnetic Compatibility
Medical Electrical Equipment needs special precautions regarding EMC and needs to be installed and put into service according to the
EMC information provided in this manual.
Portable and mobile RF communications equipment can affect Medical Electrical Equipment.
The use of Accessories, transducers, and cables other than those specied, with the exception of transducers and cables sold by the
Manufacturer of this device as replacement parts for internal components, may result in increased Emissions or decreased Immunity of
the Companion 5.
The Companion 5 should not be used adjacent to or stacked with other equipment and that if adjacent or stacked use is necessary, the
Companion 5 should be observed to verify normal operation in the configuration in which it will be used.
Guidance and Manufacturer’s Declaration - electromagnetic emissions
The Companion 5 is intended for use in the electromagnetic environment specified below. The customer or the user of the
Companion 5 should assure that it is used in such an environment.
Emissions Test Compliance Electromagnetic environment - guidance
RF emissions
EN 55011 Group 1
The Companion 5 uses RF energy only for its internal function. Therefore,
its RF emissions are very low and are not likely to cause any interference in
nearby electronic equipment.
RF emissions
EN 55011 Class B
The Companion 5 is suitable for use in all establishments, including domestic
establishments and those directly connected to the public low - voltage
power supply network that supplies buildings used for domestic purposes.
Harmonic emissions IEC
61000-3-2 Class A
Voltage fluctuations/
flicker emissions IEC
61000-3-3
Complies

Oxygen Concentrator
PN 14940837 B — 8
Guidance and manufacturer’s declaration–electromagnetic immunity
The Companion 5 is intended for use in the electromagnetic environment specified below. The customer or the user of the
Companion 5 should assure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment – guid-
ance
Electromagnetic
environment –
guidance
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be wood, concrete or ceramic
tile. If floors are covered with synthetic
material, the relative humidity should be at
least 30 %.
Electrical fast tran-
sient/burst
IEC 61000-4-4
±2 kV for power supply
lines
±1 kV for input/output
lines
±2 kV for power supply
lines
N/A
Mains power quality should be that of a
typical commercial or hospital environment.
Surge
IEC 61000-4-5
±1 kV line(s) to line(s)
±2 kV line(s) to earth
±1 kV line(s) to line(s)
±2 kV line(s) to earth
Mains power quality should be that of a
typical commercial or hospital environment.
Voltage dips, short
interruptions and
voltage variations
on power supply
input lines IEC
61000-4-11
<5 % UT
(>95 % dip in UT)
for 0,5 cycle
40 % UT
(60 % dip in UT)
for 5 cycles
70 % UT
(30 % dip in UT)
for 25 cycles
<5 % UT
(>95 % dip in UT)
for 5 sec
<5 % UT
(>95 % dip in UT)
for 0,5 cycle
40 % UT
(60 % dip in UT)
for 5 cycles
70 % UT
(30 % dip in UT)
for 25 cycles
<5 % UT
(>95 % dip in UT)
for 5 sec
Mains power quality should be that of a
typical commercial or hospital environment.
If the user of the Companion 5 requires
continued operation during power mains
interruptions, it is recommended that the
Companion 5 be powered from an uninter-
ruptible power supply or a battery.
Power frequency
(50/60 Hz) mag-
netic field IEC
61000-4-8
3 A / m 3 A / m Power frequency magnetic fields should be
at levels characteristic of a typical location
in a typical commercial or hospital environ-
ment.
NOTE UTis the a.c. mains voltage prior to application of the test level.

Oxygen Concentrator
PN 14940837 B — 9
Guidance and manufacturer’s declaration–electromagnetic immunity
The Companion 5 is intended for use in the electromagnetic environment specified below. The customer or the user of the
Companion 5 should assure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment –
guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
3 Vrms
150 kHz to 80 MHz
3 V/m
80 MHz to 2,5 GHz
3 Vrms
3 V/m
Portable and mobile RF communications
equipment should be used no closer to any
part of the Companion 5, including cables,
than the recommended separation distance
calculated from the equation applicable to
the frequency of the transmitter.
Recommended separation distance
80 MHz to 800 MHz
800 MHz to 2,5 GHz
where Pis the maximum output power rat-
ing of the transmitter in watts (W) according
to the transmitter manufacturer and dis the
recommended separation distance in metres
(m).
Field strengths from xed RF transmitters,
as determined by an electromagnetic site
survey, ashould be less than the compliance
level in each frequency range. b
Interference may occur in the vicinity of
equipment marked with the following
symbol:
NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflec-
tion from structures, objects and people.
a Field strengths from xed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile
radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
To assess the electromagnetic environment due to xed RF transmitters, an electromagnetic site survey should be
considered. If the measured field strength in the location in which the Companion 5 is used exceeds the applicable RF
compliance level above, the Companion 5 should be observed to verify normal operation. If abnormal performance is
observed, additional measures may be necessary, such as re-orienting or relocating the Companion 5.
b Over the frequency range 150 kHz to 80 MHz, eld strengths should be less than 3 V/m.
d= 1.2 P
d= 1.2 P
d= 2.3 P

Oxygen Concentrator
PN 14940837 B — 10
Recommended separation distances
between portable and mobile RF communications equipment and the Companion 5
The Companion 5 is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled.
The customer or the user of the Companion 5 can help prevent electromagnetic interference by maintaining a minimum
distance between portable and mobile RF communications equipment (transmitters) and the Companion 5 as recommended
below, according to the maximum output power of the communications equipment.
Rated maximum
output power of
transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2,5 GHz
0,01 0.12 0.12 0.23
0,1 0.38 0.38 0.73
1 1.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended separation distance d in metres (m)
can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power
rating of the transmitter in watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection
from structures, objects and people.
d= 1.2 P d= 1.2 P d= 2.3 P

Oxygen Concentrator
PN 14940837 B — 11
Theory of Operation
Introduction
The Companion 5 is a stationary medical device used to extract
oxygen from the atmosphere, concentrate it, and present the
oxygen to the patient. The device will operate in Continuous Flow
Mode. In Continuous Flow Mode the oxygen is provided at a con-
stant flow rate between 0.5 and 5.0 LPM (Continuously Variable).
Table 2 below lists the major internal components of the con-
centrator and their functions. Reference Table 2 and Figure 3 (on
the following page) for clarification while reading the Theory of
Operation Section of the manual.
Item Function
Intake Filter Provides HEPA level filtration for intake to compres-
sor.
Compressor Pump that routes air into and through the concen-
trator.
Cooling Fan Cools the compressor area.
4-Way
Solenoid
Valve
Routes air flow through one sieve bed and vents
the purged air to the atmosphere from the other
bed. Responsible for alternating flow between the
beds.
Sieve Beds
(2)
Chemically adsorbs nitrogen molecules from the
air.
Orifice Routes a larger portion of air exiting one sieve bed
back through the other bed for purging.
Flapper Valve
Routes a smaller portion of air exiting one sieve
bed into the product holding tank. Prevents back
flow from product tank to sieve bed
Product
Holding Tank
Holds concentrated oxygen prior to its regulation
and delivery to the patient.
Pressure
Regulator
Reduces the outlet pressure to be compatible with
the flow meter and accessories.
OCSI Sensor
Detects oxygen concentration of flow exiting the
concentrator (OCSI models only). Sends a signal to
activate alarm if concentration is too low.
Flow Control
Valve
Integral needle valve that controls volumetric flow
(LPM) to the patient. Is read against the printed
scale.
HEPA Filter HEPA level filtration of outlet flow.
Printed
Circuit Board
(PCB)
Responsible for all of the electrical operation of the
concentrator. Contains a programmable micropro-
cessor that controls valve timing, alarm indications,
and OCSI functions (if applicable).
Table 2: Internal Components of Concentrator
Pressure Swing Adsorption
The CAIRE Companion 5 utilizes the Pressure Swing Adsorption
(PSA) Process to concentrate oxygen gas from ambient air. In the
PSA process, a compressor draws ambient air into the machine
through an intake filter. The compressor then forces the filtered air
into a solenoid valve which directs the air into one of two tanks
that are full of a molecular sieve material, referred to as sieve
beds. As the pressure in sieve bed 1 increases, nitrogen molecules
are removed from the ambient air and are stored in the sieve
material. The gas that exits sieve bed 1 is highly-concentrated
oxygen. The majority of this gas flows through an orifice to sieve
bed 2 and is used to purge the stored nitrogen gas from its sieve
material. The remainder of the oxygen gas is directed through a
apper valve to the product holding tank. Here, it is stored for
delivery to the patient.
Sieve bed 1 continues to pressurize until the sieve material is
completely saturated with nitrogen. At this time the printed circuit
board (PCB) switches the state of the solenoid valve, dumping
pressurized air in sieve bed 1 back into the atmosphere via the
purge mufer. Simultaneously, the valve now directs the com-
pressed air into sieve bed 2, which has been completely purged of
nitrogen gas and is ready for nitrogen adsorption/oxygen concen-
tration. This cycle continuously repeats pressurizing and depressur-
izing the sieve beds, feeding concentrated oxygen to the product
holding tank.

Oxygen Concentrator
PN 14940837 B — 12
Flow Delivery
Oxygen exiting the product holding tank flows through a pressure
regulator that reduces the high pressure oxygen to a lower, more
manageable pressure before it is delivered to the patient. This
ensures that the oxygen flowing from the device will work ap-
propriately with accessories and provide a safe pressure for patient
delivery.
The Companion 5 oxygen concentrator may be equipped with
an Oxygen Concentration Status Indicator (OCSI). In that case,
oxygen gas exiting the pressure regulator flows through a check
valve and then through the OCSI sensor. This is the same area of
the concentrator where the flow is measured. The PCB monitors
the concentration and the ow measured by these sensors, and
it will activate a warning light and audible alarm if the concentra-
tion drops below predetermined levels described in the Warning
Alarms section of the manual.
After exiting the concentration and ow rate sensors, oxygen
flows through the flow control valve (FCV) at the LPM flow rate
selected by the patient and indicated on the flow meter. The
oxygen gas then flows through the HEPA filter where unwanted
contaminants are removed. The oxygen is then delivered to the
patient through the outlet barb.
Figure 3: Schematic Diagram of Pneumatic Operation
Electrical Operation
All electrical components of the CAIRE Companion 5 are all
controlled by a PCB. The electrical cord supplies mains AC power
(120 VAC @ 60 Hz or 230 VAC @ 50 Hz) to the main circuit board
when the power switch is in the “ON” (|)position. The PCB dis-
tributes the mains power to all of the electrical components. The
AC mains power is distributed and routed directly to the compres-
sor and the cooling fan. The compressor and cooling fan both
operate at 120 VAC @ 60 Hz or 230 VAC @ 50 Hz. The remaining
power travels to a DC power convertor/regulator. Figure 4 is a
block diagram showing the flow and distribution of mains power
into the concentrator.
or
or or
Figure 4: Diagram of Mains Electrical Distribution

Oxygen Concentrator
PN 14940837 B — 13
Microprocessor
The microprocessor is the only processing element of the CAIRE
Companion 5. It contains embedded software which is pro-
grammed with all of the parameters for alarm conditions and
settings of the concentrator. The microprocessor is directly respon-
sible for the following functions of the concentrator:
• Cycling (timing) of the 4-way solenoid valve
• Driving the LCD display
• Controlling the audible alarm
• Controlling the operational and warning LED lights
• Reading input from the OCSI sensor (OCSI models only)
The microprocessor is programmed with the alarm thresholds and
trigger points, as well as the timing of the 4-way solenoid valve
to cycle between sieve beds. A diagram of the input and output
of the microprocessor is shown below in Figure 5. Each input and
output is described further in the following sections.
Figure 5: Microprocessor Operation Block Diagram
4-Way Solenoid Valve
The solenoid valve is connected to the circuit board’s microproces-
sor by a 4-pin connector. The microprocessor is responsible for
sending the signal to open and close the valves. This cycles the air
through alternating sieve beds for the PSA process. The timing for
alternating the sieve beds is programmed into the microprocessor.
LCD Display
The 6-digit digital LCD display is mounted on the PCB and is vis-
ible on the front of the concentrator. Its purpose is to continually
count and display the hours that the concentrator has been in
operation and to display alarm conditions. The LCD display cannot
be re-set and displays time to the nearest tenth of an hour.
Audible Alarm
The CAIRE Companion 5 contains an audible buzzer that is sur-
face mounted on the PCB. Its purpose is to alert users of alarm
conditions. The microprocessor detects alarms by reading the
input from the OCSI sensor and the mains power switch. When
there is an alarm condition, the microprocessor sends a signal to
activate the audible alarm.
LED Lights
There are two (2) or three (3) (OCSI) LED lights that are surface
mounted on the PCB. They are visible from the front of the
concentrator and their purpose is to alert the user of operating
conditions or alarms.
The top LED indicator is green. It remains on at all times when the
power switch is in the “ON” (|) position and the electrical cord is
plugged in. A continuous green light indicates normal operation.
The next LED indicator will be red. This light will indicate mal-
functions with the device. When the microprocessor detects an
alarm condition from the power switch or the ow rate sensor, it
will send a signal for the red LED to illuminate. The red LED will
indicate a system malfunction, loss of power, or ow rate is out of
specifications.
The bottom LED indicator will be yellow (OCSI Models only). This
light will only indicate low oxygen concentration. This LED will
illuminate when the microprocessor detects an alarm condition
from the OCSI sensor. The LED will be solid if the oxygen concen-
tration is 70%-85%, and it will ash if the concentration is less
than 70%. The warning alarms section will describe these alarm
conditions in detail, and provide basic troubleshooting steps.

Oxygen Concentrator
PN 14940837 B — 14
OCSI Sensor – (OCSI units only)
The OCSI sensor detects the oxygen concentration of the air
being delivered to the patient. The sensor consists of an intake
and outlet port on each end of a flow path that is encased in an
air-tight cover. The microprocessor determines concentration from
the OCSI sensor output, and activates alarms when appropriate.
The limits for alarm conditions are programmed into the software
of the microprocessor and are described in the Warning Alarms
section of this manual. The concentrator takes several minutes to
build internal pressure and concentration. This is known as the
warm-up period, and the signal from the sensor is ignored by the
PCB for ten (10) minutes. This means that the alarms associated
with the OCSI will not activate until this predetermined amount of
time has passed.
Serial Number Identification
The serial number of the CAIRE Companion 5 is located on the
back label of the outer case. The serial number is in the middle of
the label, just below the bar code. A sample label is shown below.
Figure 7: Serial Number Label
End of Life
At the end of the service life of the CAIRE Companion 5, it should
be disposed of in accordance with local regulations.

Oxygen Concentrator
PN 14940837 B — 15
User Controls And System Status Indicators
Symbol Definition Symbol Definition
Read user manual before operation. See user manual
for instructions. I/O On/Off Switch
No Smoking Icon: Do not smoke near unit. Use no oil or grease.
Warnings / ALERT (Yellow) Indicator No open or naked ames.
Class II equipment No serviceable parts inside. Do not open cover.
02Oxygen Output Certied for both the U.S. and Canadian markets, to
the applicable U.S. and Canadian standards.
Type BF Applied Part (degree of protection against
electric shock)
This device complies with the requirements of
Directive 93/42/EEC concerning medical devices. It
therefore bears the CE marking as shown.
This symbol is to remind the equipment owners
to return it to a recycling facility at the end of its
life, per Waste Electrical and Electronic Equipment
(WEEE) Directive.
IPX1
Drip Proof Equipment-IPX1: The Companion 5
provides protection against the harmful effects of the
ingress of liquids. (IPX1, per IEC 60529)
Authorized representative in the European
Community Name and address of manufacturer
Buzzer: An audible alarm (or buzzer) is used to alert you to the operating condition of the device, either a warning or failure.

Oxygen Concentrator
PN 14940837 B — 16
Indications for Use
The Companion 5 is indicated for the administration of supple-
mental oxygen. The device is not intended for life support nor
does it provide any patient monitoring capabilities.
A physician must prescribe a specific oxygen flow rate setting to
meet patients’ individual needs.
Recommended oxygen flow rates should be adjusted only under
the advice of a physician.
WARNING: Federal law restricts this device to sell by or on the
order of a physician.
Contraindications
WARNING: The Companion 5 is not intended for life sup-
porting or life sustaining applications, nor does it
provide any patient monitoring capabilities.
WARNING: In certain circumstances, the use of non-prescribed
oxygen can be hazardous. This device should only
be used when prescribed by a physician.
WARNING: Not for use in the presence of flammable anes-
thetics.
WARNING: As with any electrically powered device, the user
may experience periods of non-operation as a
result of electrical power interruption, or the need
to have the Companion 5 serviced by a qualified
technician.
The Companion 5 is not appropriate for any
patient who would experience adverse health
consequences as a result of such temporary inter-
ruption.
Introduction
Welcome to the CAIRE Companion 5 oxygen concentrator. Setting
up and training your patient to use the Companion 5 has never
been easier! You can expect your patients and care providers to
easily learn how to use the device by following the directions in
this section. While setting up and training a patient, be sure to
point out the advantages of the Companion 5. For example:
• Easy-to-use controls
• Quiet operation
• Self-monitoring alarm system
After completing each training procedure, ask your patient if he or
she has any questions. Proper training of your patients will result
in fewer service calls, improved compliance and increased patient
satisfaction.
Pre-Delivery Check List
Verify that the Companion 5 is provided to the patient with the
following items:
Users’ Manual
Required Oxygen Delivery Accessories (Cannula, Tubing, Hu-
midier, etc.)
Power - Insert the AC power cord into an electrical outlet to
check for proper operation
Before delivering the device, check and log the status of the fol-
lowing using the LCD Display:
Hours on the hour meter
Software Revision (The LCD Display will show this upon
startup)
You may adjust the liter flow settings to your patient’s prescription
when you deliver and set up the device.
Connecting the AC Power
The Companion 5 operates from external power.
1. Plug the power cord into an AC outlet.
2. The Companion 5 is now ready for use.
Note:
If the Companion 5 is not receiving power when it
is turned on, the unit will alarm and display a solid
red light.
WARNING: Ensure adequate clearance around the AC Cord.

Oxygen Concentrator
PN 14940837 B — 17
CAUTION • DO NOT connect the Companion 5 to an
extension cord or electrical outlet controlled
by a switch.
• Always check to see that the Air Inlet and the
Exhaust Vent are not blocked.
Disconnecting the AC Power
To ensure that there is no power to the Companion 5, unplug
from AC power.
Note: Turn the Companion 5 to the “Off” (O) position to avoid alarming before
disconnecting the AC Power cord.
Using Around the House
Your patient may use 50’ tubing when operating the Companion
5 in the house. When a humidier is used, the tubing between it
and the patient must not exceed 7’.
CAUTION When using a humidier adapter of any kind,
the Companion 5 unit must remain stationary,
meaning that the unit must NOT be moved or
transported in any manner to avoid damage to the
Companion 5.
Locating the Companion 5 for Proper
Use and Ventilation
Ask your patient where they would like to set up the device.
Whenever possible, the Companion 5 should be in the same room
as the patient for convenience and assurance that the patient can
adequately hear and respond to Companion 5 alerts and alarms.
While unpacking and setting up the device, tell your patient about
these important cautions and warnings:
WArnIng: LoCAte the ComPAnIon 5 In A WeLL-ventILAted
sPACe thAt ProvIdes AdequAte AIrfLoW.
WArnIng: ensure thAt furnIture, drAPerIes or CLothIng
WILL not ImPede AIr CIrCuLAtIon.
WArnIng: AvoId PLACIng the unIt over A fLoor heAt regIster or
AgAInst A BAseBoArd heAtIng system.
WArnIng: do not use In the PresenCe of fLAmmABLe AnesthetICs,
soLvents, AerosoLs or fLAmmABLe CLeAnIng Agents.
WArnIng: AvoId hIgh PoLLutAnt envIronments.
CAUTION Some patients are highly mobile and may use
the device under varying circumstances. Make
sure your patient or patient caregiver completely
understands the basic precautions to safely locate
the device.
Note: After completing this training procedure, ask your patient if he/she has
any questions.
Power On and Warm Up
Plug the electrical cord of the CAIRE Companion 5 into an AC
outlet.
WArnIng: InsPeCt the eLeCtrICAL Cord for dAmAge Be-
fore use. If the Cord Is dAmAged, do not PLug It Into An
eLeCtrICAL outLet or AttemPt to oPerAte the ConCentrA-
tor.
Press the power switch in the “ON” (I) position.
When the Companion 5 is plugged in properly and turned on,
a green indicator on the LED Display will light up. After initially
powering ON the device, please allow up to ten (10) minutes for
the device to reach its performance specifications.
Note: All LED lights will illuminate upon start-up. After the concentrator com-
pletes the warm-up cycle, only the green light will remain on.
For OCSI Models: The O2 Light will illuminate for four (4) seconds
upon start-up. After this initial start-up, this light is disabled for
approximately ten (10) minutes while the concentration rises to
specifications.
The warm-up period could be up to 10 minutes. After this time,
only the green LED remains lit to indicate normal operation.

Oxygen Concentrator
PN 14940837 B — 18
Adjust Flow Control Rate
Turn the flow control knob to the oxygen flow rate (LPM)
prescribed by your physician.
To adjust flow rate:
Turn counter-clockwise to increase flow.
Turn clockwise to decrease flow.
The middle of the ball indicates flow rate.
There are two sets of lines (front and back). In the example below,
the flow meter would read “4LPM”.
WArnIng: It Is very ImPortAnt to seLeCt onLy the Pre-
sCrIBed LeveL of oXygen. do not ChAnge the fLoW
seLeCtIon unLess you hAve Been dIreCted to do so By A
LICensed CLInICIAn. the oXygen ConCentrAtor mAy Be used dur-
Ing sLeeP under the reCommendAtIon of A quALIfIed CLInICIAn.

Oxygen Concentrator
PN 14940837 B — 19
Maintenance–Patient
Clean and Care for Tubing and
Cannula
Provide your patient instructions on cleaning, disinfection and/or
replacement information for the tubing and cannula.
Clean the Cabinet
To clean the cabinet do the following:
1. Turn OFF the Companion 5 and disconnect from AC power
before any cleaning or disinfection activity.
2. Use mild detergent and water solution.
3. Use a damp (not soaking wet) cloth or sponge.
4. Spray or wet the cloth or sponge with the mild detergent
solution. DO NOT spray the cabinet.
5. Wipe down the cabinet.
6. To disinfect the Companion 5, use Lysol® Brand II disinfec-
tant (or equivalent). Spray or wet a cloth or sponge with
the disinfectant. DO NOT spray the cabinet or the LED/LCD
display. Proceed as directed by the manufacturer.
Patient Training Checklist
Use the following checklist as a guide to assist in setup and training a patient on the use of the Companion 5 and its accessories.
Patient Name:
Companion 5 Serial #:
Training Topic Initials
Pre-Delivery Check List
Indications for Use
Contraindications
Basic Concept Training
Advise to read the Users Manual
Safety Guidelines and Operational Safety Warnings/Cautions
Locating the Companion 5
Indicators
Alerts and Alarms
Companion 5 Maintenance
Clean and Care for the Cannula per manufacturer’s instructions.
Clean the Cabinet as needed.
Schedule PM every 2 years
Trained By: Date:

Oxygen Concentrator
PN 14940837 B — 20
Preventive Maintenance—
Provider
Introduction
Properly maintaining the Companion 5 will ensure longer life and
higher performance. Preventative Maintenance is required every 2
years at a minimum.
CAUTION The Companion 5 contains electrostatic sensitive
components. Do not open or handle except at a
static free workstation. Do not remove cover with-
out electrostatic discharge (ESD) protection.
Maintenance Check List
Perform the following maintenance procedures at least every two
years or more often, as needed. The frequency of the periodic
maintenance should be based on the environment in which the
Companion 5 is used.
• Inspect AC Power cord and plug for damage
• Read and record hour meter
• Check ow rate, concentration, and alarm functions
• Replace air intake lter and HEPA lter
Maintenance Schedule
Preventative Maintenance Check list
Perform the following maintenance procedures at least once
every two years or more often, as needed. The frequency of the
periodic maintenance should be based on the environment in
which the Companion 5 is used. Harsh environments may require
preventative maintenance more frequently than every 2 years.
• Replace air intake lter
• Replace HEPA lter
Oxygen Concentration Check
CAIRE recommends the oxygen concentration be checked peri-
odically as required by the provider. For non-OCSI units, CAIRE
recommends a 6 month interval between concentration checks.
