C-Dax C-DIT300 User manual

OWNER’S MANUAL
FOR THE
GROUND DRIVEN SPREADER
C-DIT300
C-Dax Ltd
PO Box 1010, 145 Harts Road
Tiritea, Palmerston North
Ph:06 354 6060
Fax:[phone]
E-Mail: [e-mail]
www.c-dax.co.nz

2
SAFETY PRECAUTIONS
CDIT300
AN IMPORTANT MESSAGE FOR OWNERS & OPERATORS OF C-Dax
ATTACHMENTS/ACCESSORIES
Be warned of the dangers of loading your ATV or other vehicle in excess of its carrying capacity.
It is important to understand that any loads or attachments whether fastened to or placed on a vehicle or ATV
will alter the stability or handling characteristics of that vehicle or ATV.
Spray tanks or other equipment must be filled only to a level where the gross weight is within the load limit of
the ATV or other vehicle.
Safety is a primary concern in the design, manufacture, sale, and use of spray tanks and other equipment. As
manufacturers of spray tanks and other equipment we want to confirm to you, our customers, our concern for
safety. We take this opportunity to remind you about the simple, basic and common sense rules of safety
when using spray tanks and other equipment. Failure to follow these rules can result in severe injury or death
to operators and bystanders.
It is essential that everyone involved in the assembly, operation, transport, maintenance and storage of this
equipment be aware, concerned, prudent and properly trained in safety.
This also applies to equipment that is loaned or rented to someone who has not read the owner’s manual and
is not familiar with the operation of application equipment.
•NEVER EXCEED THE LOAD LIMIT CAPACITY OF THE ATV OR OTHER VEHICLE.
•ALL ATV AND TRAILED EQUIPMENT TYRES SHOULD BE INFLATED TO MANUFACTURERS
RECOMMENDED OPERATING PRESSURES.
•PLEASE NOTE THAT FILLING THE SPRAY TANK OR OTHER EQUIPMENT COMPLETELY AND OR
THE ATTACHMENT OF ADDITIONAL EQUIPMENT TO THE ATV MAY EXCEED THE ATV’S
MAXIMUM LOAD CAPACITY, AND ADVERSELY AFFECT THE STABILITY OF THE ATV OR OTHER
VEHICLE.
•CARGO SHOULD BE PROPERLY DISTRIBUTED AND SECURELY ATTACHED.
•REDUCE SPEED WHEN CARRYING CARGO OR PULLING A TRAILER OR TRAILED APPLICATION
EQUIPMENT AND ALLOW GREATER DISTANCE FOR BRAKING.
•NEVER ALLOW ANYONE TO RIDE ON YOUR SPRAYER OR OTHER EQUIPMENT.
•ALWAYS FOLLOW THE INSTRUCTIONS IN THE OWNER’S VEHICLE MANUAL FOR CARRYING
CARGO OR PULLING A TRAILER.
•PROPER MAINTENANCE IN LINE WITH MANUFACTURER’S RECOMMENDED MAINTENANCE
PROCEDURES IS ESSENTIAL.
•BEFORE APPLYING CHEMICALS, READ THE LABEL OF THE CHEMICAL MANUFACTURER OR
SUPPLIER FOR PERSONAL PROTECTIVE EQUIPMENT AND OPERATE AS RECOMMENDED.
•THE SAFETY OF ALL CHEMICALS USED IN AGRICULTURE IS UNDER THE JURISDICTION OF A
GOVERNMENT AGENCY, IE N.Z. MINISTRY FOR THE ENVIRONMENT; USA ENVIRONMENTAL
PROTECTION AGENCY. FURTHER LOCAL GOVERNMENT OR STATE LAWS MAY APPLY.

3
SAFETY PRECAUTIONS
Before attempting to install or operate the equipment, read and understand the manual thoroughly. Failure to
comply with this instruction constitutes improper use and will invalidate the warranty.
Throughout this manual there are highlighted text boxes containing warnings, cautions and notes.
Warnings are mandatory instructions to prevent serious injury or permanent damage.
Cautions are advisory instructions to ensure reliable operation of the equipment.
Notes are for convenient operation
•Do not overload your spreader. The maximumpermissible payload is 250 Kg.
•Never use dirty product or product with stones or lumps.
•Ensure that your towing vehicle is adequate for the task. The maximum tare weight is 350 Kg.
•If using the spreader over hilly terrain the payload should be reduced to ensure that the spreader
stability is not compromised.
•Never allow anyone to ride on the spreader.
•Keep the spreader in good condition. Cleanliness and maintenance are essential for safe and trouble
free operation.
•Never leave product in the hopper or store the spreader without cleaning it.
•Always make sure that all moving parts are clear of debris or excess product before putting the unit
away, failure to do so may cause problems with clutch mechanism

4
C-Dax CDIT300
OWNER’S MANUAL
(Pt.No.2400-5600 Issue 18, October 2015)
TABLE OF CONTENTS
2 Safety Precautions
4 Table of Contents
5 Introduction
Description
Specifications
Order Information
6Warranty
Liability
7Operation
8 Calibration
Magnesium Oxide
9 Operating the Spreader
Adjusting the Spread Pattern
Fitting the Rain Cover
10 Maintenance
Before Use
After Each Use or Daily when in Use
10 Hints
11 Parts Diagram
12 Parts List

5
INTRODUCTION
C-Dax thanks you for your purchase of an advanced spreader from C-Dax Ltd. C-Dax Ltd is committed to
providing you, the farmer, with quality applicating systems.
DESCRIPTION
The C-Dax C-DIT300 is a ground-driven spreader designed for application of pelleted fertilisers. It can also be
used for application of other products such as grass seed and magnesium oxide. The uniquely designed 300-
litre translucent non-corrosive polyethylene hopper is specially profiled for good product flow and ease of
filling. The convenient flexible polypropylene cover is easy to remove, install and store if not required. A high-
quality stainless steel agitator and shutter ensures even flow of product to the spinner. A unique spinner
design ensures wide, even spread of product over 180 degrees (Urea). The drive train uses high quality steel
and a double sealed self-aligning bearing and heavy-duty gearbox for maximum durability. While seated, the
operator has access to the control handle. This handle allows disengagement and engagement of the clutch
and setting of product feed rate all in one motion. Also standard are mudguards, swivel tow-hitch and a fully
shrouded polyethylene front deflector to further protect the operator from product being thrown off the spinner.
Specifications: All Models Unless Stated
(Specifications subject to change without notice)
Dry Weight 75 Kg
Dimensions W1430mm, H1200mm, L1700mm
W1450mm (Wide wheel models)
Capacity 300 litre (250Kg Urea)
Drive Ground driven (single wheel)
Wheels 18x950x8 Chunky turf tyres
Tyre Pressure 12 PSI
Clutch Lever operated mechanical clutch
Control Adjustable stainless steel slide with index handle
Agitator Mechanical arm, stainless steel
Spinner Galvanised steel with three-position adjustable vanes
Hopper Non-corrosive polyethylene, ergonomically designed for ease of filling and inspection
Hopper Cover Lightweight polypropylene fabric
Frame Galvanised steel
Gearbox Heavy duty with double sealed bearings
Gearbox oil 400ml SAE30
Axle Bearings Sealed ball races
Clutch bearing Self-lubricating Vesconite bearing
Axle grease General Purpose
Application Rate 140Kg per hectare @ 10 kph (nominal, Urea)
Spread width 18M (nominal, Urea @ 15 Kph)
Towing speed 15 Kph (Maximum recommended)
NZ UK EXPORT
Order Information
Standard C-DIT300 model P/N 3003 3010

6
WARRANTY
1WARRANTY AND LIABILITY
Use of the equipment
1.1 You must satisfy yourself as to the suitability of the equipment for your intended use(s) of the
equipment.
Your relationship with the retailer
1.2 Where you consider you have a warranty claim (or any other claim) in relation to the
equipment, you must contact the retailer who sold you the equipment, not C Dax directly. The
retailer is responsible for liaising with C Dax in respect of your claim.
Warranty
1.3 C Dax warrants to the original purchaser that the equipment is sold free from defects in
materials and workmanship for a period of 12 months from date of first retail sale (6 months
from date of first retail sale if the equipment is sold in the U.K.) subject to the terms set out
below.
1.4 C Dax will at its option repair or replace the defective equipment (or part of the equipment) or
notify the retailer of the equipment to refund the purchase price for such defective equipment
to you in the event of a breach of this warranty, subject to the terms set out below.
Liability
1.5 Except for the warranty set out in clause 1.2 above, all warranties and representations
(including those expressed or implied by law) in respect of the equipment or advice relating to
the equipment provided to you by C Dax are excluded to the extent permitted by law.
1.6 Notwithstanding anything else in this manual, C Dax’s maximum liability to you (in the event
that such liability exists) in respect of any breach of warranty, any matter set out in this
manual, or for defective equipment or advice relating to the equipment provided is limited at
C Dax’s option to:
(a) repairing or replacing the equipment (or part of the equipment); or
(b) notifying the retailer of the equipment to refund the price for the equipment paid by
you.
1.7 Notwithstanding anything else in this manual, in no event will C Dax be liable, whether in
contract, tort (including negligence) or otherwise:
(a) where you have altered or modified the equipment, misused or misapplied the
equipment, or the equipment has been subjected to any unusual, excessive or non
recommended use, service or handling (including as set out in this manual);
(b) where the equipment is not transported, stored, handled or used in accordance with any
directions given by C Dax (or the retailer) to you (including as set out in this manual);
(c) where the equipment:
(i) has been subject to neglect, accident or hireage, or the damage arises from fair
wear and tear, battery damage or chemical attack;
(ii) has been built to a customer’s specifications; or
(iii) has been dismantled, repaired or serviced other than by an authorised service
agent of C Dax;
(d) for loss or damage caused by any factors beyond C Dax’s control; or

7
(e) for any loss of profit or revenue, or for any special, indirect, incidental or consequential
damage, loss or injury of any kind suffered by you.
1.8 Where C Dax elects to repair or replace the equipment it will use reasonable endeavours to do
so as soon as practicable but will not be liable for any delay in doing so.
1.9 You agree that the transactions entered into between you and the retailer (and C Dax) are for
the purposes of trade and that, having regard to all relevant circumstances of the transactions,
it is fair and reasonable that the provisions of the Consumer Guarantees Act 1993 (NZ) do not
apply to those transactions to the fullest extent permitted by law.
OPERATION
The product to be spread is placed in the hopper. When the spreader is towed forward, the right hand wheel
drives through the lever operated mechanical clutch and gearbox to turn the spinner in a clockwise direction.
When the control handle is in the disengage position (fully back) the clutch is disengaged and the shutter is
closed. Pulling the handle forward (towards the operator) engages the clutch and rotates the shutter located at
the bottom of the hopper to an open position. The size of the opening is set by a shutter stop lever, which
locates into one of nine pre-set positions.
An extension of the spinner boss is connected to a stainless steel agitator arm inside the bottom of the hopper.
The agitator ensures that product flows continuously out of the hopper to the spinning disk.
A delivery chute on the bottom of the hopper ensures that product is delivered to the correct spot of the disk so
that the deflectors distribute the product over a wide angle behind and to each side of the spreader.
The clutch systemcan be engaged or disengaged at up to 5KPH while the spreader is in motion.
A fabric hopper cover with an elastic band sewn into the outer edge to grip the lip of the hopper can be fitted to
prevent rain and debris from entering the hopper.
WARNING
To prevent premature failure or damage to the CDIT300 clutch system, do not engage or disengage the clutch
at speeds in excess of 5 KPH.

8
CALIBRATION
1. Ensure the control handle is fully back (clutch disengaged, shutter closed).
2. To calibrate your spreader, place a measured amount of product (10 Kg) in the hopper.
3. Set the Shutter Stop Lever to the position (1-9) indicated in the Calibration Guides below. Hole position 9
(shutter fully open) is denoted by two holes vertically one above the other.
4. Tow the spreader at the desired speed and pull the control handle forward to engage the clutch and open
the shutter.
5. When the product has been exhausted, measure the distance covered and band width in metres. It is
recommended that this be done over an area where the product can be seen on the ground so that the
spread width can be measured.
6. Check the application rate using the following formula:
Rate (Kg/ha) = product applied (Kg) x 10,000
distance travelled (metres) x spread width (metres).
7. Adjust either the Shutter Stop Lever or the speed of travel until the desired application rate is achieved.
NOTE
Because of variations in product characteristics, speedometer calibration and driving speed, the information in
the calibration guide should be regarded as a starting point only. It is recommended that the spreader be
calibrated before use.
Calibration Guide
(Average Speed 10 Kph)
Product
Rate
(Kg/ha)
Shutter Setting
(Lever Position)
Nominal Spread
(Metres)
Urea or DAP
50
4
15
Urea or DAP
75
5
15
Urea or DAP
100
6
15
Super phosphate
100
7
12
30% Potassic Super
100
8
10
Rye Grass
30
3
4
Magnesium Oxide
Magnesium Oxide powder is applied at a rate determined by the number of cows to be treated. When
spreading this product, calculate the weight of powder to be applied and apply this amount using shutter
setting 4 or 5. Because this product may set hard if left exposed to air, it must not be stored in the machine
even for a short time. Load the spreader only with the amount required to be spread and clean all traces of
product from the machine after use.

9
OPERATING THE SPREADER
When the spreader has been correctly calibrated, the hopper may be filled to the required level and spreading
commenced.
To reduce agitator damage to product and to ensure that product is not forced past the agitator shaft when
towing the spreader to the area to be treated, the drive to the gearbox should be disconnected by ensuring the
control lever is in the disengage position (fully back).
WARNING
To prevent damage to the spreader do not tow the spreader at speeds in excess of 15 Kph.
To prevent damage to the mechanical clutch do not engage or disengage the clutch on the CDIT300 at
speeds in excess of 5 KPH.
CAUTION
The double roll pins present in the clutch assembly are designed to shear if subject to excessive use
(preventing greater damage to the rest of the unit). If you find these pins to continually break, engage the
clutch at a slower speed.
To prevent inadvertent operation of the shutter while the spreader is in transit it is recommended that the
Shutter Stop Lever be moved to Position 1 to lock the shutter closed.
To prevent the shutter from vibrating closed when the spreader is operated over rough ground, the Shutter
Control Handle friction may be increased by tightening the adjustment nut at the bottomof the Handle.
Adjusting the Spread Pattern
The spreader has been set up for spreading pelletised fertiliser. When spreading lighter products or products
with a high powder content it may be necessary to adjust the deflectors on the spinner to centralise the spread
pattern. To shift the pattern to the left (facing forward) the inside end of the vanes should be moved anti-
clockwise. To shift the pattern to the right (facing forward) the inside end of the vanes should be adjusted
clockwise. These positions are highlighted in the diagram on the following page.
Shift to the left setup
Default setup
Shift to the right setup
WARNING
To prevent damage to the spinner and shrouds, do not operate the spreader unless the screws are tight.
Fitting the Rain Cover
To fit the rain cover to the hopper, loop one corner of the cover over a corner of the hopper then stretch the
cover over the opposite corner of the hopper so that the elastic edge holds it in place. Then stretch the third
corner over the hopper rim followed by the last corner. Ensure that the cover is properly stretched over the
hopper rim before moving off.

10
MAINTENANCE
The following maintenance actions are mandatory for reliable use of the spreader.
Before Use
Check the tyre pressures and charge with air as required. The correct pressure is 12 psi. (80 Kpa)
Disengage the clutch by ensuring the control lever is fully back then turn the spinner by hand to ensure that it
is free to turn without interference.
Check the hopper to ensure that no debris is inside.
If the spreader has not been used for some time, grease the wheel bearing located in the pillow block mount
near the drive wheel.
Check the gearbox for leaks. If leaks are detected it will be necessary to drain and replenish the gearbox with
400ml of SAE 30 oil.
CAUTION
To replenish the gearbox the spreader may be inverted to place the filler plug uppermost. However in doing so
extreme care must be taken to prevent damage to the spinner and deflectors.
After Each Use or Daily when in Use
Remove all traces of product from the spreader by brushing or washing. Pay particular attention to areas
where product has accumulated and built up. Remove by scraping if necessary taking care not to damage the
surface finish of the spreader or its components.
If washing do not direct high-pressure water onto the gearbox, axle or wheel bearing seals.
After washing, apply grease to the grease nipple on the wheel bearing and apply water displacing fluid such as
WD 40 or LPS3 to all metal parts.
Check for damaged or worn components and replace as required.
NOTE
To ensure trouble free operation of the mechanical clutch, pay particular attention to
cleaning and removal of any product build-up on the unit.
HINTS
The clutch mechanism in the axle assembly utilises a stainless steel shaft and with self-lubricating plastic
bushes on the moving part of the clutch. This arrangement does not require greasing and doing so may attract
unwanted particulate into the mechanism.
If the drive axle is removed from the axle housing for any reason care must be taken to ensure that both the
axle scroll and bush are clean and free of debris before reassembly.
To remove the agitator from the hopper, remove the bolt, which attaches the agitator shaft to the spinner
flange assembly then withdraw the agitator from inside the hopper.
When ordering replacement parts always quote the Part Number of the required part.
The mechanical clutch engage/disengage bolt, which operates the clutch head is intended as a replacement
item. If excessive wear is noticed, remove the bolt and replace with part number # 2890-0816.

11
PARTS DIAGRAM

12
PARTS LIST
I
tem
No. QTY Part NO Description
1 1 1036-8240 Agitator- preader-CDIT300/400-In-Ex300/400-
2 1 1110-2310 Ball-End-Internal Thread-M10-Zinc Plated
3 1 1140-1200 Bearing-Ball-Pillow Block-Drive Axle- preaders
4 1 1140-4000 Bearing-Housing-Pillow Block-Drive Axle- preaders
5 1 1280-1600 Boot-Clutch-Convoluted-CDIT300/400-Rubber
6 1 1300-3010 Bracket-Clutch Engager-CDIT300/400GT-ZP
7 1 1300-6800 Bracket-Mudguard-CDIT300/400/MM165-LH-GL
8 1 1300-6801 Bracket-Mudguard-CDIT300/400/MM165-RH-GL
9 1 2100-2300 Clutch-Engager-CDIT400-ZP
10 1 2100-6000 Clutch-Pin Engager-CDIT300/400-ZP
11 1 2150-0025 Collar- haft-ID25-ZP
12 1 2250-1600 Cover-Clutch-CDIT300/400-OD 90x92 Long-Grey-PVC
13 1 2250-4100 Cover-Hopper- ilver Fabric- preader CDIT300
14 1 2250-7920 Cover- haft-Drive Axle-90mm Long-CDIT300GT-PVC
15 4 2810-0860 Fastener-Bolt&Nut-Hex-304 Grade-M8x60- tainless
16 1 2840-1065 Fastener-Bolt&Nut-Hex-8.8 Grade-M10x65-ZP
17 5 2840-1120 Fastener-Bolt&Nut-Hex-8.8 Grade-M10x120-ZP
18 2 2890-0812 Fastener-Cap Head-Allen- crew-12.9 Grade-M8x12-Black
19 2 2890-0816 Fastener-Cap Head-Allen- crew-12.9 Grade-M8x16-Black
20 2 3010-0810 Fastener-Grub crew- ocket Head-M8x10- tainless
21 2 3070-0512 Fastener-Machine- crew-C K-M5x12-Phillips- tainless
22 4 3075-0820 Fastener- et- crew-Hex-304 Grade-M8x20- tainless
23 4 3130-0108 Fastener-Nut-Nyloc-M8- tainless teel
24 11 3170-0008 Fastener-Nut-Nyloc-M8-ZP
25 8 3170-0010 Fastener-Nut-Nyloc-M10-ZP
26 4 3170-0012 Fastener-Nut-Nyloc-M12-ZP
27 1 3180-0010 Fastener-Nut-Plain-M10-ZP
28 1 3210-0540 Fastener-Pin-Roll-M5x40-Black
29 1 3210-0840 Fastener-Pin-Roll-M8x40-BK
30 3 3220-0320 Fastener-Pin- plit-M3.2x20-ZP
31 11 3240-0018 Fastener-Rivet-Blind-Truss Head-3/16x18mm-Aluminium
32 6 3270-8012 Fastener- elf Tap- crew-C K-8Gx1/2"-Pozi- tainless
33 4 3290-0840 Fastener- et crew-Hex-8.8 Grade-M8x40-ZP
34 1 3290-0850 Fastener- et crew-Hex-8.8 Grade-M8x50-ZP
35 1 3290-1025 Fastener- et crew-Hex-8.8 Grade-M10x25-ZP
36 1 3290-1225 Fastener- et crew-Hex-8.8 Grade-M12x25-ZP
37 2 3290-1240 Fastener- et crew-Hex-8.8 Grade-M12x40-ZP
38 2 3290-1275 Fastener- et crew-Hex-8.8 Grade-M12x75-ZP
39 4 3310-2809 Fastener-Washer-Flat-M8x22x1.5-Grade 316- tainless
40 1 3310-5012 Fastener-Washer-Flat-Heavy-M12x32x3-Galv
41 2 3310-6008 Fastener-Washer-Flat-M8-ZP
42 6 3310-6008 Fastener-Washer-Flat-M8-ZP
43 10 3310-6010 Fastener-Washer-Flat-M10-ZP
44 2 3310-6012 Fastener-Washer-Flat-M12-ZP

13
45 1 3500-5600 Frame- preader-CDIT300GT-GL
46 1 3800-1000 Gearbox-Ferroni-RV10-Ratio 1 to 2.78
47 1 3865-3800 Grip-Handle-7/8"-PVC-Black-Plastic
48 1 3990-3900 Guide-Handle-CDIT300/400GT-ZP
49 1 4050-1500 Handle-CDIT300/400GT-ZP
50 1 4050-4250 Handle-Indicator-CDIT400GT-ZP
51 1 5050-1600 Linkage-Clutch-CDIT300/400GT-ZP
52 1 5050-7960 Linkage- hutter-CDIT300GT-ZP
53 1 5200-6300 Machined-Key-8x8-Ground Drive preaders
54 1 5200-6505 Machined- haft-Axle-CDIT300GT- tainless teel
55 1 5245-3900 Mount-Handle-CDIT300/400GT-ZP
56 1 5270-0003 Nipple-Grease- traight- hort-M6-ZP
57 1 6500-7770 Profiled- hutter-CDIT300/400
58 1 6500-9000 Profiled-Washer- pinner haft-34.9x67x2mm- tainless 304
59 1 7500-2140 Rota-Hopper- preader-CDIT300 -Yellow-MDPE
60 2 7500-2590 Rota-Mudguard-Blue-MDPE-1/4 Circle
61 1 7500-2830 Rota- pout- preader-CDIT400GT-Yellow-MDPE
62 1 7970-8200 hroud- preader CDIT300GT-MDPE-Yellow
63 1 8200-1010 pinner Assembly- preader-CDIT300/400- TAINLE
64 1 8200-5200 pinner-Mount-CDIT300/400/INEX300-ZP
65 3 8250-1800 pring-Compression-Crinkle Plate-ZP
66 1 8800-3800 Tow-Coupling-Handle-Double Ended-1 78 x 50mm-ZP
67 1 9200-8700 Wheel-Turf-Bearing-18x950x8-4 Ply
68 1 9200-8900 Wheel-Turf-Keyed-18x950x8-4 Ply
