Cadet C052 Guide

The Com-Pak Plus Element
Replacement Instructions
http://cadetelectricheat.com/replacement-parts/com-pak-parts
IMPORTANT INSTRUCTIONS
MODELS
The Com-Pak Plus
C051, C052, C072,C101,
C102, C122, C151, C152,
C202, C208
C052T, C072T, C101T,
C102T, C122T, C151T,
C152T, C202T, C208T
The Com-Pak Twin Plus
CT402, CT302, CT408,
CT402T, CT302T, CT408T
Note:
Now is the perfect opportunity to clean your
heater. See original product Owner’s Guide or go
to cadetheat.com/support/install-help#install
and nd our detailed cleaning instruction video.
TOOLS REQUIRED:
WARNING
Turn the electrical power off at the electrical panel board (circuit breaker or fuse box) and lock or tag
the panel board door to prevent someone from turning on power while you are working on the heater.
Failure to do so could result in serious electrical shock, burns, or possible death.
IF YOU ARE UNCOMFORTABLE WORKING WITH ELECTRICAL APPLIANCES, UNABLE TO FOLLOW
THESE GUIDELINES, OR DO NOT HAVE THE NECESSARY EQUIPMENT, CONSULT A LICENSED ELECTRICIAN
1. It is important that you verify power has been turned off and
no power is going to the heater before proceeding. Circuit
breakers are often not marked correctly and turning the
wrong breaker off could mean electricity is owing to the
heater, even if the heater does not appear to be working.
2. Once you verify the power has been turned off correctly,
proceed to the next step.
3. Please see your product Owner’s Guide for additional
installation, operation and maintenance instructions for both
element and heater. Owner’s Guides may be downloaded at
cadetheat.com.
SAVE THESE INSTRUCTIONS
cadetheat.com Tel: 855.CADET.US P.O. Box 1675 Vancouver, WA 98668-1675
©2016 Cadet Printed in U.S.A. 11/16 #720201
• Phillips Screwdriver
• Crimping Tool • Wire Cutter • Needle Nose Pliers • Wire Stripper • Crimp Connectors

To Thermostat or Wall
Upper 5/16”
Pass through
Hole
Lower 5/16”
Pass through
Hole
INSTALLATION INSTRUCTIONS
WARRANTY
©2016 Cadet Printed in U.S.A. 11/16 #720201
LIMITED 90-DAY WARRANTY: Cadet will repair or replace any part found to
be defective within 90 days after the date of purchase.
These warranties do not apply:
1. Damage occurs to the product through improper installation or incorrect
supply voltage;
2. Damage occurs to the product through improper maintenance, misuse,
abuse, accident, or alteration;
3. The use of unauthorized accessories or unauthorized components constitutes
an alteration and voids all warranties. Refer to Cadet website or call customer
service at 855.CADET.US for list of authorized accessories and components.
4. CADET’S WARRANTY IS LIMITED TO REPAIR OR REPLACEMENT.
5. IN THE EVENT CADET ELECTS TO REPLACE ANY PART OF YOUR
CADET PRODUCT, THE REPLACEMENT PARTS ARE SUBJECT TO
THE SAME WARRANTIES AS THE PRODUCT. THE INSTALLATION OF
REPLACEMENT PARTS DOES NOT MODIFY OR EXTEND THE UN-
DERLYING WARRANTIES. REPLACEMENT OR REPAIR OF ANY CADET
PRODUCT OR PART DOES NOT CREATEANY NEW WARRANTIES.
If you believe your Cadet product is defective, please contact Cadet
during the warranty period, for instructions on how to have the repair or
replacement processed.
Parts and Service
Visit cadetheat.com/parts-service for information on where to obtain parts
and service.
Reduce-Reuse-Recycle
This product is made primarily of recyclable materials. You can
reduce your carbon footprint by recycling this product at the end
of its useful life. Contact your local recycling support center for
further recycling instructions.
For more effective and safer operation and to prolong the life of the heater, read the Owner’s Guide and follow the instructions. Failure to properly maintain
the heater will void any warranty and may cause the heater to function improperly.
1. Remove knob (if applicable) and screws that hold grill in place.
2. Remove grill.
3. Remove securing screw at the top of heater and remove
heatbox from wall can.
4. Unwiring
A. Remove insulated wire connectors that connect heatbox to wall can.
B. Cut as many wire-ties on back of heatbox as necessary
for easier accessibility.
C. Cut both wires one inch above upper pass through. (See Figure 1)
5. With heater facing upward, remove the screw at the bottom
of face cover. (See Figure 2)
6. Lift face from bottom and slide over tab on top of box and set aside.
7. Bend a single tab at top of shell ange (right or left side) with pliers to
allow shell ange to move outward. (See Figure 4)
8. Pull old element from slots and set aside.
9. Feed new element wires through upper 5/16” hole. Make sure
element end with wires is closest to pass through hole and DO NOT
leave any slack in lines.
10. Carefully place new element in element slots. (See Figure 4)
11. Align side tab and slot on heater shell. Bend side tab 45 degrees
to secure shell. (See Figure 4)
12. Take face cover previously set aside and place over tab on top.
Be sure the face covers shell ange completely and snugly. All
pieces of ange must be within edges of face to secure it properly.
13. Tighten securing screw on bottom of face. (See Figure 2)
14. Wiring
A. Attach new element wires to lead wires using wire connectors.
(See Figure 1)
B. Fasten wiring with wire ties so all wires t neatly to the side of the
motor and are out of the way. Cut off wire tie ends.
C. Re-connect supply lead wires to heater securely, using wire
connectors. Double check connections for tightness.
15. Reinstall heater into wall can, tabs rst, then attach screw.
16. Attach grill and knob (if applicable).
17. Turn power on and test heater’s operation.
Figure 1
Face Cover
Shell Flange
Shell
Flange
Screw (remove
to seperate)
Figure 2
Shell
Flange
Loosened
Figure 3
Element
Slots
Side Tab
Figure 4
