A7030-AG7030 3kV/ 1mA (1.5W) HV Boards
Rev. 7 - 03 September 2019

Purpose of this Manual
This document is the A7030-AG7030 3kV/ 1mA (1.5W) HV Boards user manual; it contains information about the
installation, the configuration and the use of the board.
Change Document Record
Date
Revision
Changes
30 March 2015
0
PRELIMINARY Release
9 April 2015
1
Updated Overview and Channel status
5 June 2015
2
Updated Technical Specifications
1 July 2015
3
Update to new range 3kV/1mA
30 July 2015
4
Updated Channel specs p.5, set/mon parameters p.10
10 November 2015
5
Updated with 12, 24, 36 channel versions
13 April 2016
6
Updated pictures and table 2
03 September 2019
7
Updated Table1
Symbols, abbreviated terms and notation
T.B.D.
Reference Documents
Disclaimer
No part of this manual may be reproduced in any form or by any means, electronic, mechanical, recording, or otherwise,
without the prior written permission of CAEN SpA.
CAEN will repair or replace any product within the guarantee period if the Guarantor declares that the product is
defective due to workmanship or materials and has not been caused by mishandling, negligence on behalf of the User,
accident or any abnormal conditions or operations.
CAEN declines all responsibility for damages or injuries caused by an improper use of the Modules due to negligence on
behalf of the User. It is strongly recommended to read thoroughly the CAEN User's Manual before any kind of operation.
CAEN reserves the right to change partially or entirely the contents of this Manual at any time and without giving any
notice.
Disposal of the Product The product must never be dumped in the Municipal Waste. Please check your local regulations
for disposal of electronics products.
Made In Italy : We stress the fact that all the boards are made in Italy because in this globalized world, where getting
the lowest possible price for products sometimes translates into poor pay and working conditions for the people who
make them, at least you know that who made your board was reasonably paid and worked in a safe environment. (this
obviously applies only to the boards marked "Made in Italy", we cannot attest to the manufacturing process of "third
party" boards).

CAEN
Electronic Instrumentation
A7030-AG7030 3kV/ 1mA (1.5W) HV Boards
3
Index
1. Overview............................................................................................................................4
Functional description .............................................................................................................................................. 4
Channel Characteristic Table .................................................................................................................................... 5
Front Panel................................................................................................................................................................ 6
Component Specifications ........................................................................................................................................7
Packaging ...............................................................................................................................................................................7
Displays ..................................................................................................................................................................................7
Trimmers................................................................................................................................................................................7
External connections..............................................................................................................................................................7
Multipin connector pin assignment ................................................................................................................................8
2. Safety and installation requirements ..................................................................................9
General safety information.......................................................................................................................................9
Injury Precautions ..................................................................................................................................................................9
Safety Terms and Symbols on the Product...............................................................................................................9
Installation ................................................................................................................................................................9
3. Operating modes..............................................................................................................10
Output control and monitoring ..............................................................................................................................10
Channel STATUS Flag............................................................................................................................................................10
Interlock protection................................................................................................................................................ 11
Grounding specifications ........................................................................................................................................ 11
Safety Earth connection.......................................................................................................................................................12
List of Figures
Fig. 1 –A7030 family front panel (48/36/24 Multipin, 24 SHV and 12 SHV channel version) .................................................................6
Fig. 2 –INTERLOCK electrical scheme....................................................................................................................................................11
Fig. 3 –J1 jumper location.....................................................................................................................................................................11
Fig. 4 –Earth configuration connection examples.................................................................................................................................12
List of Tables
Table 1 –Channel characteristics of the Mod. A7030 / AG7030 HV Board.............................................................................................5
Table 2 –52 pin connector assignment...................................................................................................................................................8

CAEN
Electronic Instrumentation
A7030-AG7030 3kV/ 1mA (1.5W) HV Boards
4
1. Overview
Functional description
The Mod. A7030 –AG7030 is a family of multi channel HV boards, available with either positive or negative polarity,
compatible with the CAEN Universal Multichannel Power Supply System
1
(SY1527, SY2527, SY4527, SY5527).
The A7030 channels share a common floating return, which allows on-detector grounding reducing the noise level;
the floating return is insulated from the crate earth up to ±50 V; the return of the AG7030 channels is wired to the
crate Earth reference.
The output voltage range is 0 ÷ 3 kV, with 1 mA maximum output current and 50mV set and 10mV monitor resolution.
Maximum delivered output power is 1.5W per channel.
The boards are provided with both current and voltage protections.
Two output current limits are foreseen:
•ISet; software limit, individually set for each channel; if exceeded, the relevant channel is signalled in
Overcurrent
•IMax; hardware limit, common to all channels, set via front panel trimmer and monitored via software; if
exceeded the relevant channel can be programmed either to turn off after a programmable trip time or to
keep on providing the maximum allowed current: this particular feature allows the module to work as
current generator.
The maximum output voltage can be fixed, through a trimmer located on the front panel, at the same common value
for all the board channels and this value can be read out via software. The boards have also the safety board interlock
(see p. 11).
The HV RAMP-UP and RAMP-DOWN rates may be selected independently for each channel in the 1 ÷ 500 V/s range
(1 V/s step).
The boards are available with 12, 24, 36 and 48 channels; see also table below:
Model
No. of channels
HV connector
Width
Return
A7030D
12
SHV
Single (5TE)
Common Floating
A7030S
24
SHV
Double (10TE)
Common Floating
A7030L
24
Radiall 52pin
Single (5TE)
Common Floating
A7030T
36
Radiall 52pin
Single (5TE)
Common Floating
A7030
48
Radiall 52pin
Single (5TE)
Common Floating
AG7030D
12
SHV
Single (5TE)
Earth
AG7030S
24
SHV
Double (10TE)
Earth
AG7030L
24
Radiall 52pin
Single (5TE)
Earth
AG7030T
36
Radiall 52pin
Single (5TE)
Earth
AG7030
48
Radiall 52pin
Single (5TE)
Earth
1
Please verify that the Syx527 system is running the latest firmware release

CAEN
Electronic Instrumentation
A7030-AG7030 3kV/ 1mA (1.5W) HV Boards
5
Channel Characteristic Table
Table 1 –Channel characteristics of the Mod. A7030 / AG7030 HV Board
Polarity
Positive / Negative depending on purchased version
Output Voltage
0 ÷ 3 kV
Max. Output Current
1mA
VSet Resolution
50 mV
VMon Resolution
10 mV
Current Set Resolution
20 nA
Current Monitor Resolution
2 nA
IMAX hardware
0÷1 mA
IMAX hardware resolution
1 µA
IMAX hardware accuracy
<1% of FSR
VMAX hardware
0 ÷ 3 kV common for all the board channels
VMAX hardware resolution
1 V
VMAX hardware accuracy
<1% of FSR
VMAX software
0 ÷ 3 kV settable for each channel
VMAX software resolution
1 V
Ramp Up / Ramp Down
1÷ 500 Volt/sec, 1 Volt/sec step
Voltage Ripple 2
10 ÷ 1000 Hz
<15 mV typical; 20 mV max
➢1000 Hz
<5 mV typical; 10 mV max
VMon vs. VOut Accuracy 3,4
typical: ± 0.3% ± 0.2 V
max: ± 0.3% ± 1 V
VSet vs. VMon Accuracy 2
typical: ± 0.3% ± 0.2 V
max: ± 0.3% ± 1 V
IMon vs. IOut Accuracy 2
typical: ± 1% ± 100 nA
max: ± 1% ± 1 µA
Maximum output power
1.5 W (per channel)
Consumption @ full power
48 channels (A7030): 160 W
36 channels (A7030T): 120 W
24 channels (A7030S, A7030L): 90 W
12 channels (A7030D): 50 W
2
From 10 Hz to 20 MHz at full load; ripple may exceed such limits whenever OVC and UNV occur (see Output control and
monitoring)
3
From 10% to 90% of Full Scale Range
4
During operation in Overcurrent or when VMAX Hardware is reached (and/or exceeded), VMON values have to be assumed as
“indication”; possible monitor drifts are caused by the different regulation mode.

CAEN
Electronic Instrumentation
A7030-AG7030 3kV/ 1mA (1.5W) HV Boards
6
Front Panel
Fig. 1 –A7030 family front panel (48/36/24 Multipin, 24 SHV and 12 SHV channel version)

CAEN
Electronic Instrumentation
A7030-AG7030 3kV/ 1mA (1.5W) HV Boards
7
Component Specifications
Packaging
All models are single width (5 TE), except A/AG-7030S that are double width (10TE). Height is 6U.
Displays
HV ON LED
lights up as at least one channel is on; red: positive polarity; yellow: negative polarity.
POWER GOOD
Board correctly powered
WARNING
Warning status detected (over current, over/under voltage, trip, external disable)
INTERLOCK LED
Function: Red LED. Lights up as the board is in INTERLOCK (channel are disabled)5.
Trimmers
VMAX:
Function: it allows to adjust the hardware maximum voltage VMAX common to all the
channels. Its value can be read out via software.
IMAX:
Function: it allows to adjust the hardware maximum current IMAX common to all the
channels. Its value can be read out via software.
External connections
The specifications of the external connectors are listed in the following subsections.
Series:
A/AG-7030-7030L-7030T
A/AG-7030D-7030S
Output Channels:
Multipin connector Radiall 691803004 type, 52 pin
male (to be mated with Radiall 691802002 [SCEM
09.41.34.700.2]type6); see Table below
HV coaxial connectors Radiall
SHVR317580
INTERLOCK (see p. 11):
AMP 280371-2
AMP 280371-2
5
Not available on A/AG-7030D-7030S
6
Requires 52 pins Radiall 691804300 [SCEM 09.41.33.830.7]type, to be inserted using the insertion/extraction tool
Radiall 282549024 [SCEM 34.95.17.125.3] type.

CAEN
Electronic Instrumentation
A7030-AG7030 3kV/ 1mA (1.5W) HV Boards
8
Multipin connector pin assignment
Table 2 –52 pin connector assignment
A/AG7030 –7030T (CH36..47 N.C. on A7030T & AG7030T)
+
+
43
44
45
46
47
48
49
50
51
52
32
33
34
35
36
37
38
39
40
41
42
22
23
24
25
26
27
28
29
30
31
11
12
13
14
15
16
17
18
19
20
21
1
2
3
4
5
6
7
8
9
10
#
function
#
function
#
function
#
function
#
function
1
CH02
11
RETURN
22
CH01
32
RETURN
43
CH00
2
CH07
12
CH04
23
CH06
33
CH03
44
CH05
3
CH12
13
CH09
24
CH11
34
CH08
45
CH10
4
CH17
14
CH14
25
CH16
35
CH13
46
CH15
5
CH22
15
CH19
26
CH21
36
CH18
47
CH20
6
CH27
16
CH24
27
CH26
37
CH23
48
CH25
7
CH32
17
CH29
28
CH31
38
CH28
49
CH30
8
CH37
18
CH34
29
CH36
39
CH33
50
CH35
9
CH42
19
CH39
30
CH41
40
CH38
51
CH40
10
CH47
20
CH44
31
CH46
41
CH43
52
CH45
21
RETURN
42
SAFETY LOOP
