CM 324 Series
Active Infrared “Hands-Free” Switch
INSTALLATION INSTRUCTIONS
Door Activation Devices
1. GENERAL DESCRIPTION
Sure-Wave™ hands-free” switch is an active infrared device
designed for use with an automatic door operator or other
access control products. Applications include low-energy doors,
drive-up windows, health-care facilities, manufacturing, etc.
The assembly ts in a variety of locations from a 1-3/4” door
frame to a 1-gang or 2-gang electrical box. Various size surface
mounting boxes are also available from Camden.
Three standard face plate widths are available:
CM-324: 2-3/4” x 4-1/2” polycarbonate or stainless steel,
ts on single gang electrical boxes.
CM-324/ N: 1-3/4” x 4-1/2” polycarbonate or stainless steel,
ts 1-3/4” door frames or our CM-23D Jamb box.
CM-324/ W: 4-1/2” x 4-1/2” polycarbonate or stainless steel, ts
on single gang, double gang or 4 x 4 electrical boxes.
All faceplates may be ordered up with a plain face (/1), with the
waving hand symbol (/2), or with the waving hand symbol and
words: WAVE TO OPEN (/3).
2. SPECIFICATIONS
Input Voltage 12-24V AC/DC ± 12%
Operating Modes Pulse (sense) / Toggle
Operating Temp -4 to +153 ºF (-20 to +85 ºC)
Electrical Life
100,000 Operations @ Rated Capacity
500,000 Operations @ 1/2 Rated Capacity
Current Draw 50 - 60 mA
Response Time 100 ms
Relay Output Form 'C' (SPDT)
Output Type Normal or Fail-Safe
Relay Contact Rating 5 amps @ 30 VDC
Time Delay 1 to 5 seconds
Connections 11" 22 AWG Leads
Security Automatic Self-charging ID
Technology Infra-Red with Coded Modulated Carrier
Mounting 2 x #6-32 MS
Faceplates Jamb, 1-gang and 2-gang
Activation Range
(See Page 4)
Factory Set to 12” (304mm)
Range: 1” – 30” (25.4mm – 762mm)
Dimension 1” W x 4” L x 1-1/2” D
(25.4mm x 101.6mm x 38.1mm)
3. INSTALLATION
MOUNTING
Sure-Wave™ may be mounted in door jambs, single or double
gang electrical boxes, and 4 x 4 boxes.
NOTE: The sealing gasket (included) is recommended for
outdoor or wet locations. If using with Automatic doors
install in accordance with ANSI A156.10 / A156.19.
Select from one of the following three mounting subsections:
SINGLE GANG ELECTRICAL BOX: CM-324
1a. If using an in-wall box, ensure the box is plumb and square,
and ush with the wall surface (See Diagram 1).
1b. If using a surface box, ensure it is secure and plumb.
2. Bring your 4-conductor wire through the back or side of the
enclosure and leave approximately 6” tail for wiring connection.
3. Make the electrical connections to the device according to
the wiring section (following).
4. Using the dip switch located on the end of the unit, set the
operating mode (See Section 4) .
5. Attach the unit to the enclosure using the two #6-32
screws provided.
6. Apply power and adjust range and time delay via the
potentiometers on the front of the unit
(See Section 4 for adjustments).
7. Attach the faceplate to the unit using the two black
#6-32 x 3/8 machine screws or tamper-proof screws.
NOTE: Do not overtighten

Page 2 of 4
CM-324 ACTIVE INFRARED “HANDS-FREE” SWITCH
INSTALLATION INSTRUCTIONS
2-GANG (or 4x4) ELECTRICAL BOX: CM-324W
1a. If using an in-wall box ensure the box is plumb and square,
and ush with the wall surface (See Diagram 1).
1b. If using a surface box, ensure it is secure & plumb.
1c. If using a 4 x 4 box, ensure the box is plumb and square, and
ush with the wall surface, then attach the metal adaptor
plate (included in the CM-324W package) to the box using
appropriate fasteners.
2. Bring your 4-conductor wire through the back or side of
the enclosure, leaving approximately a 6” tail for
wiring connection.
3. Make the electrical connections to the device according to
the wiring section (following).
4. Using the dip switch located on the end of the unit, set the
operating mode (See Section 4).
5. Attach unit to enclosure using the two #6-32 screws provided.
6. Apply power and adjust range and time delay via
potentiometers on the front of the unit (See Section 4).
7. Attach the faceplate to the unit using the two black
#6-32 x 3/8 machine screws or tamperproof screws.
NOTE: Do not overtighten
DOOR FRAME: CM-324N
1a. If mounting directly in a 1” wide aluminum jamb, make a
cutout in the door frame at the intended location as per
Diagram 2.
Drill and tap two mounting holes as shown.
1b. If mounting the unit in CM-23d deep jamb box, rst mount
the jamb box according to the instructions packaged with the
enclosure. Using the CM-23D as a guide, drill a wire access
hole through the jamb to sh the wiring through.
2. Bring your 4-conductor wire through the back or side of
the enclosure (or jamb) and leave approximately 6” tail
for wiring connection.
3. Make the electrical connections to the device according
to the wiring section (following).
4. Using the dip switch located on the end of the unit, set the
operating mode. (See Section 4)
5. Attach the unit to the enclosure or jamb using the two
#6-32 screws provided.
6. Apply power and adjust range and time delay via
potentiometers on the front of the unit (See Section 4).
7. Attach the faceplate to the unit using the two black
#6-32 x 3/8 machine screws or tamperproof screws.
NOTE: Do not overtighten
WIRING
CAUTION: Do not apply power to the unit until all secondary
wiring is complete, and dip-switches have been set.
The CM-324 can be powered from 12 or 24 volts, AC or DC.
Connect the two Red wires, (non-polarity sensitive) to the
power source.
The output is a form C relay. N.O is Blue, N.C. is Violet, and
Common is Green. Selecting the correct output is also
dependant on the operating mode chosen (See Section 4).
Most applications will utilize the N.O. and Common terminals.
Rough Wall Finish
Recessed Box
Wall
Wall Box
Flush
Unaligned Box
Smooth Wall Finish
Correct
Installation
Diagram 1 - Proper Box Installation
Incorrect Installation

Page 3 of 4
CM-324 SERIES ACTIVE INFRARED “HANDS-FREE” SWITCH
INSTALLATION INSTRUCTIONS
4. APPLICATIONS & SET-UP APPLICATIONS
Switch 1 – Normal Mode/Fail-Safe Mode
Choose Normal Mode if you wish the N.O. contact to remain
open if the power were to fail. This is the factory setting.
Choose Fail-safe Mode if you wish the contacts to close upon
power fail. Move the Dip switch to OFF position, and wire your
device to the Common and N.C. wires.
Switch 2 – Time Delay Mode/Toggle Mode
Factory setting is Time Delay (Sense) mode, whereby the
contact closure will be adjustable from 1 – 5 seconds using the
Time Delay Potentiometer.
In Toggle (or Switch) mode, when the CM-324 is activated
once, the relay will stay energized until it is activated once
again (adjustable timer is inactive in this mode).
Switch 3 – LED On/LED Off
This switch disables the LED, should this feature be desired.
Factory setting is ON. Once the Dip switches have been set, and
the unit is installed in the frame or enclosure, apply power to
the unit and observe operation.
Set both potentiometers to minimum setting initially
(fully counter-clockwise). See Diagram 3 for location.
Adjust the range potentiometer by turning
the pot in a clockwise manner, and passing your hand in front of
the unit. Rotate the pot until the desired range is obtained.
See Diagram 5 for patterns.
Next, adjust the time delay potentiometer by turning clockwise
until the desired time delay is obtained. It is sometimes
benecial to leave this adjustment set to minimum and utilize
the time delay on the door operator, if present.
Diagram 3 - Location of Dipswitch Adjustments
Photo Eye
Red LED
Time Delay
Adjustment
Dip Switch
Red
Red
Blue
Green
Violet
12-24V
Power
N.O.
COM
N.C.
Range
Adjustment
CM-324
Wiring
Pigtail
NOTE:
Timer is non-functional in
Toggle Mode.
Install the faceplate using
the screws provided.
NOTE: Do not overtighten
OPTIONAL
Apply the included Wheelchair
logo to the frame or wall at
desired location. See Diagram 5.
NOTE: Do not apply directly
to the faceplate
If using this product with an
Automatic Door, proceed to
Section 5 for System
Inspection Instructions.
5. SYSTEM INSPECTION INSTRUCTIONS
After the Installation and operational check of the system:
1. Place warning label on the door (as per ANSI A156.10 or
A156.19 guidelines). This will advise the person entering
the swing side zone that the door will move.
2. Instruct the owner on door system operation and how to
test it. This should be checked on a daily basis.
3. Instruct the owner on what to do if the door or any of its
components become damaged.
4. Strongly recommend to the owner that the complete entry
be inspected twice a year as part of the service agreement.
6. WARRANTY
Camden Door Controls guarantees the Sure-Wave™ to be free
from manufacturing defects for 3 years from date of sale.
If during the rst 3 years the CM-324 fails to perform correctly,
it may be returned to our factory where it will be repaired or
replaced (at our discretion) without charge. Except as stated
herein, Camden extends no warranties expressed or implied
regarding function, performance or service.
Diagram 5 - Wheelchair
Sticker Placement
1”
(25mm)
CM-324/N3
Door Frame

Call: 1.877.226.3369 / 905.366.3377
Visit: www.camdencontrols.com
Opening New Doors to
Innovation, Quality and Support!
Page 4 of 4
CM-120i/CM-120wV2 VER. 3 DIGITAL KEYPADS
INSTALLATION INSTRUCTIONS
File: CM-324 Manual_R4.indd
Revision: 03/05/2020
Part No.: #40-82B100
