CAME AMICO Series User manual

AMICO SERIES
AUTOMATION FOR SWING GATES
INSTALLATION MANUAL
A1824

The data and information shown in this manual may be changed by CAME cancelli automatici s.p.a. at any time without prior warning.
2
ENGLISH
4.1 Gate Operator
4 Description
2.1 Intended use
1 Legend of symbols
This symbol tells you to read the section with particular care.
This symbol tells you that the sections concern safety issues.
This symbol tells you what to say to the end-users.
2 Intended use and application
The A1824 operator is designed to automate swing gates used in residential or condominium settings..
The use of this product for purposes other than those described above and installation executed in a manner other
than as instructed in this technical manual are prohibited.
3 Reference Standards
“IMPORTANT INSTALLATION, SAFETY INSTRUCTIONS”
“CAUTION: IMPROPER INSTALLATION MAY CAUSE SERIOUS DAMAGE, FOLLOW ALL INSTALLATION INSTRUCTIONS CAREFULLY”
“THIS MANUAL IS ONLY FOR PROFESSIONAL OR QUALIFIED INSTALLERS”
2.2 Application
This product is engineered and manufactured by CAME cancelli automatici s.p.a. and complies with current safety regulations.
Guaranteed 24 months if not tampered with.
The gearmotor is made up of two aluminium alloy half shells housing the Encoder gearmotor – which features an electric blocking
mechanism – and an epicyclical reduction system with endless screw.
4.2 Technical features
Control board power supply: 230V A.C. 50/60Hz
Motor power supply: 24V D.C.
Max draw: 4A
Power: 100W
Adjustable thrust:400÷2000N
Opening time (90°): Adjustable
Gear ratio: 1/36
Duty Cycle: Intensive use
Protection Rating: IP44
Weight: 7,5 kg
#
#
The company CAME cancelli automatici s.p.a. is ISO 9001:2000 quality certified; it has also obtained the ISO 14001 environ-
mental safeguarding certification. Came engineers and manufactures all of its products in Italy.
This product complies with the following standards: EN 12978, UNI EN 954-1, CEI EN 60335-1, UNI EN 12453.
Length of gate leaf 1 m 1,5 m 1,8 m
Weight of gate leaf 250 kg 215 kg 200 kg

3
The data and information shown in this manual may be changed by CAME cancelli automatici s.p.a. at any time without prior warning.
ENGLISH
4.4 Dimensions
4.3 Description of parts
A1824
1) Operator
2) Pilaster bracket
3) Gate bracket
4) Screw, bushing and nut for the pilaster
bracket
5) Bolt and nut for the gate bracket
6) Distanziale per perno attacco
(mm)
1
3
5





5 Installation
Before installing, do the following:
• Make sure you have suitable tubing and conduits for the electrical cables to pass through and be protected against mechanical
damage;
• Fit tubing to drain away any water leaks which may cause oxidation;
• Make sure that any connections inside the case (that provide continuance to the protective circuit) be fitted with extra
insulation as compared to the other conductive parts inside;
• Make sure the structure of the gate is sturdy, the hinges work and that the is no friction between moving and non-moving
parts;
• Make sure there is a mechanical stop for opening and closing.
Installation must be carried out by expert qualified personnel and in full compliance with current regulations.
5.1 Preliminary checks
4
2
6

The data and information shown in this manual may be changed by CAME cancelli automatici s.p.a. at any time without prior warning.
4
ENGLISH
Make sure you have all the tools and materials you will need for the installation at hand to work in total safety and
compliance with the current standards and regulations. The following figure illustrates the minimum equipment needed by
the installer.
N.B.: If the cable length differs from that specified in the table, then you must determine the proper cable diameter in the
basis of the actual power draw by the connected devices and depending on the standards specified in CEI EN 60204-1.
For connections that require several, sequential loads, the sizes given on the table must be re-evaluated based on actual
power draw and distances.
When connecting products that are not specified in this manual, please follow the documentation provided with said
products.
5.3 Cable list and minimum thickness
Connections Type of
cable
Length of cable
1 < 10 m
Length of cable
10 < 20 m
Length of cable
20 < 30 m
Control panel power supply 230V
FROR CEI
20-22
CEI EN
50267-2-1
3G x 1,5 mm23G x 2,5 mm23G x 4 mm2
Motor power supply 24V 3 x 1 mm23 x 1,5 mm23 x 2,5 mm2
Flashing light 2 x 0,5 mm22 x 1 mm22 x 1,5 mm2
Photocell transmitters 2 x 0,5 mm22 x 0.5 mm22 x 0,5 mm2
Photocell receivers 4 x 0,5 mm24 x 0,5 mm24 x 0,5 mm2
Accessories power supply 2 x 0,5 mm22 x 0,5 mm22 x 1 mm2
Control and safety devices 2 x 0,5 mm22 x 0,5 mm22 x 0,5 mm2
Antenna RG58 max. 10 m
5.2 Tools and materials
1) A1824 operator
2) Control panel
3) Reception antenna
4) Flashing light
5) Selector switch
6) Photocells
7) Electric cable junction box
8) Mechanical gate stops
5.4 Standard installation
3
2
8
1
1
4
5
6
6
7
8

5
The data and information shown in this manual may be changed by CAME cancelli automatici s.p.a. at any time without prior warning.
ENGLISH
Warning: after establishing the best point to which you will secure the gate bracket, secure the bracket to the pillar and make sure
the quotas shown in the table below are met.
Note: by increasing measure B, the opening angle and gate speed are reduced, while the gearmotor thrust is increased. By
increasing the measure A, the opening angle and gate speed are increases, while the gearmotor thrust is decreased.
Opening A
(mm)
B
(mm)
C
(mm)
90° 130 130 60
120° 130 110 50
Ideal securing
point
Gate bracketPillar bracket
Lay the corrugated tubing needed for the connections deriving from the junction box.
N.B. the number of tubes depends on the type of system and accessories employed.
The following illustrations are only examples, given that the space available for anchoring the operator and accessories
may vary from gate to gate. It is up to the installer, thus, to choose the most suitable solution.
5.5 Installing the operator
Electric cable junction box

The data and information shown in this manual may be changed by CAME cancelli automatici s.p.a. at any time without prior warning.
6
ENGLISH


Assemble and weld the two parts of the pillar bracket. Secure the bracket to the point you have chosen with proper plugs and
screws or – if the pillar is made of metal – weld it on.
Weld the gate bracket to the gate leaf making sure the quotas shown in the table are met.
Note: on non-metal gate leaves assemble and weld the two parts of the bracket and secure them with proper screws. Secure the
Tail joint
Screw M8 x 35
Insert the bushing (lubricated) into the pillar bracket’s hole. The bracket has holes that allow the opening angle to be changed.
Secure the tail joint to the bracket.
Bushing
Nut UNI 7474 M8

7
The data and information shown in this manual may be changed by CAME cancelli automatici s.p.a. at any time without prior warning.
ENGLISH
Attachment pin
Washer
Release the gearmotor (see paragraph on manual release), completely open the gate leaf, loosen the nuts of the opening
mechanical stop and position it up against the attachment pin, then secure it.
Open the gate leaf and insert the pin into the gate bracket.
Close the gate leaf, loosen the nuts on the closing mechanical stop, place it up against the attachment pin, then secure it.
Nut M12
Bushing
Insert the bushing into the head attachment pin.

The data and information shown in this manual may be changed by CAME cancelli automatici s.p.a. at any time without prior warning.
8
ENGLISH
,.-.
%.#
-. %.#
Slide open the small door that protects the release, insert the tri-lobed key and turn it.
5.6 Manual release of the gearmotor
For the electrical connection procedures, use the junction box and branching boxes.
5.7 Connecting to the control panel
Power
230V a.c. - 50/60 Hz
Connecting the 24V d.c. delayed closing
gearmotor
Connecting the 24V d.c. delayed opening
gearmotor
-.
%.#
ZL90 Control panel
-.
%.#

9
The data and information shown in this manual may be changed by CAME cancelli automatici s.p.a. at any time without prior warning.
ENGLISH
5.8 Outward opening installation
%
!
"
Opening A
(mm)
B
(mm)
E
(mm)
90° 130 130 720
Weld the extra bracket to that of the pillar, secure the extra
bracket to the pillar making sure the A and B quotas are
met as shown in the table.
Open the gate to a 90° arc, weld or secure using proper
screws the gate bracket making sure the E quota is met.
Secure the gearmotor to the brackets.
Connect the gearmotors to the panel as shown in the diagram.
Pillar bracket
Extra bracket
Gate bracket
,.-.
%.#
-. %.#
Power
230V a.c.
50/60 Hz
-.
%.#
-.
%.#
Extra bracket
Delayed
closing
action
Delayed
opening
action

The data and information shown in this manual may be changed by CAME cancelli automatici s.p.a. at any time without prior warning.
10
ENGLISH
7 Safety instructions
This product must only be employed for its originally intended use. Any other use is wrong and potentially dangerous. The
manufacturer cannot be held liable for any damages resulting from wrongful, erroneous or negligent uses.
Avoid working close to the hinges or other moving mechanical parts. Stay out of the opening/closing arc when operator is in
motion.
Do not exercise force against the motion of the operator as this could result in potentially dangerous situations.
Important safety instructions
Do not allow children to play or loiter within the opening/closing arc of the operator.
Keep remote controls and any other command device out the reach of children, to prevent operator from being activated by
accident.
In the event of anomalous behaviour, stop using the operator immediately.
Danger of crushing hands
Danger of crushing feet
Danger! High voltage
No transit during operation
