Camozzi PRE Series Instruction Manual

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
1
Operation and maintenance instructions for Series PRE Electronic proportional
regulator
The products are designed and manufactured in conformity with the following directives:
-2014/30/UE “Electromagnetic compatibility”
They also comply partially or totally with regard to the applicable parts of the following standards:
-EN 61000-6-2:2005 Electromagnetic compatibility (EMC) —Part 6-2:
Generic standards - Immunity for industrial environments
-EN 61000-6-4:2007 Electromagnetic compatibility (EMC) —Part 6-4: Generic standards -
Emissions for industrial environments
-UL 61010-1: Safety requirements for electrical equipment for measurement, control and
laboratory use Part 1: General requirements and the following technical standards
and to the following technical standards:
-EN ISO 4414:2010 Pneumatics - General rules and safety requirements for systems and their
components.
For more information regarding the declarations of conformity, see the Certifications section
on the website http://catalogue.camozzi.com.
Made in Italy

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
2
Sommario
1. Product identification ..................................................................................................................3
2. Introduction .................................................................................................................................4
3. General recommendations ..........................................................................................................4
4. Product description:.....................................................................................................................5
5. General characteristics and conditions of use.............................................................................7
6. Electrical/Pneumatic circuit.......................................................................................................11
7. Product storage and transport...................................................................................................11
8. Installation and start-up.............................................................................................................11
9. CoilVision....................................................................................................................................16
10. Digital output ..........................................................................................................................16
11. NFCanApp................................................................................................................................17
11.1. Monitoring...........................................................................................................................18
12. Universal visual interface X (UVIX)..........................................................................................19
12.1. Monitoring...........................................................................................................................19
12.1.1. Status information...........................................................................................................20
12.1.2. Details ..............................................................................................................................20
12.2. Configurator ........................................................................................................................23
12.2.1. User setup........................................................................................................................23
12.2.1.1. Custom PID parameters...................................................................................................25
12.2.2. Range setup .....................................................................................................................26
12.2.3. Digital output setup.........................................................................................................27
12.2.4. Pressure sensor setup......................................................................................................27
12.3. External sensor configuration - examples ...................................................................28
13. Use...........................................................................................................................................28
14. Troubleshooting and/or exceptional circumstances ..............................................................33
15. Limitations on use...................................................................................................................34
16. Maintenance ...........................................................................................................................34
17. Environmental notes...............................................................................................................34
18. Contacts ..................................................................................................................................36

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
3
1. Product identification

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
4
2. Introduction
This manual illustrates how to properly use the Series PRE electronic pressure regulator in its
version with analog inputs and with digital inputs (preset).
This version of the Controller is identified with code 0234 xx xx xxx x xxxxx, where 0234 indicates
the analog version with external sensor and is followed by year, week, machine, station and
serial number.
For more information, refer to the manual dedicated to the Camozzi UVIX supervision software
(Universal Visual Interface X).
3. General recommendations
The recommendations regarding safe use in this document should be observed at all times.
•Some hazards can only be associated with the product after it has been installed on the
machine/equipment. It is the task of the final user to identify these hazards and reduced the
associated risks accordingly.
•The products dealt with in this manual may be used in circuits that must comply with the
standard EN ISO 13849-1.
•For information regarding component reliability, contact Camozzi.
•Before proceeding with use of the product, carefully read all information in this document.
•The instructions in this manual must be observed together with the instructions and
additional information regarding the product in this manual, available from the following
reference links:
oweb site http://www.camozzi.com
oCamozzi general catalogue
oTechnical assistance service
•Assembly and start-up operations must be performed exclusively by qualified and authorized
personnel on the basis of these instructions.
•It is the responsibility of the system/machine designer to ensure the correct selection of the
most suitable pneumatic component according to the intended application.
•For all situations not contemplated in this manual and in situations in which there is the risk
of potential damage to objects, or injury to persons or animals, contact Camozzi for advice.
•Never make unauthorized modifications to the product. In this case, any damage or injury
to objects, persons or animals will be the responsibility of the user.
•All relevant product safety standards must be observed at all times.
•Never intervene on the machine/system before verifying that all working conditions are safe.
•Before installation and maintenance, ensure that the specific envisaged safety locks are
active, and then disconnect the electrical mains (if necessary) and system pressure supply,
discharging all residual compressed air from the circuit and deactivating residual energy
stored in springs, condensers, recipients and gravity.

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
5
•To reduce the noise levels caused by the discharge of air from the component, envisage the
use of silencers or convey the fluid to a zone where no personnel are envisaged during
normal operation.
•Avoid covering the equipment with paint or other substances that may reduce heat
dissipation.
•Avoid cleaning with aggressive agents such as to dull the plastics and make it difficult to read
the screen
•In the event of an electrical power failure and pneumatic supply at the port connection 1,
the regulated pressure on port connection 2 will not be maintained and can be discharged.
4. Product description:
The Series PRE electronic pressure regulator is composed of:
•M12 12 pin connector (6): provides connection to power supply, command signal, read the
signal from external sensor, feedback signals and to the output signal (for more details refer
to the paragraph “Installation and Commissioning").
•LCD display (1): if present (depends on the code), it shows the measurement of the regulated
pressure and allows to configure some parameters.
•General diagnostic LED bar (3): provides a quick indication of the general status of the device
(for more details, refer to the "Use" paragraph).
•Function keys (2): if the LCD display is present (depends on the code), these keys allow to
access and navigate the Regulator menu (for more details, refer to the "Use" paragraph).
•Micro USB connector (5) and wireless communication LED (4) to connect to the UVIX: the
device can be connected to the UVIX supervision software via wireless (if present) or USB
that allows to configure and monitor the device.

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
6
The analog version with external sensor of the Series PRE electronic pressure regulator is
available with two different command signal types:
•Analog Voltage: voltage command signal 0 - 10 V.
•Analog Current: current signal 4 - 20 mA.
The choice between the two models must be made when ordering the regulator.
The configuration of some features of the Series PRE electronic pressure regulator is done
through the UVIX supervision software.
Two operating modes have been implemented:
•Automatic: the pressure target is set via the analog input. At startup the Regulator is in this
mode.
•Manual: the pressure target is set using the function keys or through a special command of
the UVIX supervision software. The regulator must be set in this mode during the
configuration phase in order to avoid unwanted pressure adjustments.
•In addition, using the NFCamApp app it is possible to configure the parameters of WiFi
communication (only for models that provide for WiFi communication) and view some
features of the PRE series electronic pressure regulator.

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
7
5. General characteristics and conditions of use
General characteristics and conditions of use
PRE1
PRE2
Reference standards
CE; RoHs
Materials
Body: Aluminum Cover: Technopolymer Seal:NBR and FKM
Assembly position
Any
Overall dimensions
L = 50 mm; W = 50 mm; H = 140
mm
L = 50 mm; W = 50 mm; H = 185
mm
Weight
350gr circa
630gr circa
Medium and its quality
Filtered and non-lubricated compressed air of class 7.4.4
according to ISO 8573.1. Inert gases and oxygen only for OX1
versions.
Maximum free flow rate (Pin 10 bar)
Measured at ±5% of Preg
Pout 6 bar: 1.100 l/min ANR
(PRE104)
Pout 4 bar: 1.200 l/min ANR
(PRE104)
Pout 6 bar: 4.500 l/min ANR
(PRE238)
Pout 4 bar: 5.200 l/min ANR
(PRE238)
Maximum leakage rate
20 cc/min
10 cc/min
Maximun inlet pressure
11 bar
Regulated pressure range
0,05 - 10,3 bar (0,72-150 PSI)
Number of ways
3
Ambient temperature
0 ÷ 50 °C
Protection class
IP65 (according to EN 60529)
Open-type (according to UL 61010)
Pneumatic ports
Standard version: G1/4; G1/8; 1/4
NPTF
Manifold version: G1/4; 1/4 NPTF
Standard version: G1/4, G3/8
Manifold version: G1/4
Vibrations sine
According to EN 60068 part 2-
6:2009-11 (table B.1)
Frequency range: 10-500Hz
Displacement 0-peak: 0,75mm or 100 m/s2
Number of cycle: 10
Continuous shock
According to DIN EN 60068-2-
27:2010-02 (table A.1)
Peak acceleration: 150 m/s2
Duration: 11ms
Pulse shape: half sine
Electric port
M12 12 Pin Male A-key
Input signal setpoint
Analog version: 0÷10V (2), 4÷20 mA (4)
Analog Output signal (feedback)
0÷5 V DC and 4÷20 mA (both present in the analog version (2)
and (4))

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
8
External sensor signal
0÷10 V DC or 4÷20 mA (selectable)
Electrical power supply
24Vdc ±10%
Current consumption
Max 0,250A (refer to the table below for more details,
external sensor consumption is not included)
Hysteresis (*)
0,5% FS
0,7% FS
Repeatability (*)
0,4% FS
0,4% FS
Linearity (*)
0,4% FS
0,4% FS
Resolution (*)
0,3% FS
0,6% FS
Overpressure discharge
With relieving
Modularity
With Series MD
Display
WIFI module
Integrated
exaust valve
Code
Maximum current
consumption
NO
NO
NO
PRExxx-Ex5xxx-xx
PRExxx-Ex7xxx-xx
0,105 A
YES
NO
NO
PRExxx-Dx5xxx-xx
PRExxx-Dx7xxx-xx
0,135 A
NO
YES
NO
PRExxx-Ex5xxx-xxxW
PRExxx-Ex7xxx-xxxW
0,145 A
YES
YES
NO
PRExxx-Dx5xxx-xxxW
PRExxx-Dx7xxx-xxxW
0,165 A
NO
NO
YES
PRExxx-Ex6xxx-xx
PRExxx-Ex8xxx-xx
0,190 A
YES
NO
YES
PRExxx-Dx6xxx-xx
PRExxx-Dx8xxx-xx
0,215 A
NO
YES
YES
PRExxx-Ex6xxx-xxxW
PRExxx-Ex8xxx-xxxW
0,230 A
YES
YES
YES
PRExxx-Dx6xxx-xxxW
PRExxx-Dx8xxx-xxxW
0,250 A

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
9
•FLOW CHARTS SIZE 1 - Standard version (1/4G)
Typical curve for version PRE104-x2…
P = Regulated outlet pressure and exhaust pressure
Q = Flow
% = Percentage of the command signal
•FLOW CHARTS SIZE 1 –Manifold version (1/4G)
Typical curve for version PRE1M4-x2…
P = Regulated outlet pressure and exhaust pressure
Q = Flow
% = Percentage of the command signal
DECAY FACTOR FOR MANIFOLD REGULATOR SIZE 1
N° = number of regulators in manifold configuration
% = relative percentage decay of the maximum flow rate
Note: the air inlet is only from one side, in case it should be on the
right and on the left, only consider the positions as from 1 ÷ 3..
•FLOW CHARTS SIZE 2 - Standard version (1/4G)
Typical curve for version PRE204-x2…
P = Regulated outlet pressure and exhaust pressure
Q = Flow
% = Percentage of the command signal

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
10
•FLOW CHARTS SIZE 2 - Standard version (3/8G)
Typical curve for version PRE238-x2…
P = Regulated outlet pressure and exhaust pressure
Q = Flow
% = Percentage of the command signal
•FLOW CHARTS SIZE 2 –Manifold version (1/4G)
Typical curve for version PRE2M4-x2…
P = Regulated outlet pressure and exhaust pressure
Q = Flow
% = Percentage of the command signal
DECAY FACTOR FOR MANIFOLD REGULATOR SIZE 2
N° = number of regulators in manifold configuration
% = relative percentage decay of the maximum flow rate
Note: the air inlet is only from one side, in case it should be on the right and
on the left, only consider the positions as from 1 ÷ 3..

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
11
6. Electrical/Pneumatic circuit
7. Product storage and transport
•Adopt all measures possible to avoid accidental damage to the product during transport, and
when available use the original packaging.
•Observe the specified storage temperature range of -20 ÷ 70 °C.
8. Installation and start-up
•During unpacking, take great care not to damage the product.
•Check whether there are any faults caused by product transport or storage.
•Separate all packaging material to enable the recovery or disposal in accordance with current
standards in the country of use.
•Where possible avoid the risk of repeated pressure surges on the circuit where the component
is installed.
•The components must be fixed correctly using, where possible, the specific anchors and
ensuring that the fixture remains efficient even when the actuator is repeatedly used at a high
frequency and in the presence of strong vibrations.
•Once the component is installed, ensure that all air ways are securely connected to the
respective couplings.
•If the power supply is turned off, residual pressure may remain on the secondary side of the
regulators. The manufacturer must provide for additional exhaust components.
Recommended pneumatic circuit
•Keep the protective cap of the M12 connector until the regulator is completely installed

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
12
•PRE series electronic regulator can be connected to DIN rails using the relative elements PCF-
E520 fitted on the rear of the body using two M4 threaded holes.
•The Series PRE electronic regulator can be directly fixed to a support using the 2 through holes
with diameter 4mm present on the body (not available in the PRE1 manifold version).
•The PRE1 electronic regulator can be fixed to the wall with the optional bracket code MD1-
ST/1 (if the two through holes in the body have a 34 mm center distance) or with the optional
bracket code PRE-ST (if the two through holes in the body have a 42 mm center distance); the
PRE2 electronic regulator can be fixed to the wall with the optional bracket code PRE-ST:
1. Fix the bracket to the wall with suitable screws
2. Connect the fittings G1/4; G3/8 or NPTF according to the PRE regulator size
3. Connect the regulator to the bracket with the two M4 x 55 screws supplied
•Make sure that the bracket is completely resting on the wall
•Connection of Manifold regulators with related Kit PRE-M-Pin-1-2
1. Insert the pins (1) in the seats on the regulator body
2. Insert the O-ring seal (3) into the special seat on the side face of the body
3. Bring the two modules sideways up until contact
4. Tighten the four grub screws (2) until they are locked (Tightening torque: 2,5 ± 0,5 Nm)

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
13
•There are 2 additional pneumatic ports on the PRE series electronic regulator:
oM5 to discharge the exhaust valve to the outside. It is important to keep this port free
and clean to ensure that air is discharged without obstructions that could limit the
flow. If necessary, only for version with conveyable port, remove the pre-assembled
filter, connect a suitable coupling and use a hose to convey discharged air to a suitable
area.
oM5 for external servo-pilot supply. The regulator is supplied with a preassembled cap
for the versions with internal servo-pilot supply and with the fitting 6625 3-M5 for the
versions with external servo-pilot supply.
•In order to connect the regulator with MD series, use the PRE-1/4-C kit for regulator with
G1/4 pneumatic port or use the PRE-3/8-C kit for regulator with G3/8 pneumatic port.
•The board implements a protection against inversion of polarity on the power supply voltage.
•The board is also fitted with a resettable 1A fuse to limit the maximum current absorption of
the servovalve. Use a power supply unit able to deliver a current of at least 0,5A
(recommended 1.0A).
•If UL/CSA standard compliance is required, the unit shall be supplied by an isolated power
source which fulfils at least one of the following the requirements of:
- Limited-Energy Circuit in accordance with UL/CSA 61010-1/ UL/CSA 61010-2-201
- Limited Power Source (LPS) in accordance with UL/CSA 60950-1
- a Class 2 supply source which complies with the National Electrical Code (NEC), NFPA 70,
Clause 725.121 and Canadian Electrical Code (CEC), Part I, C22.1. (typical examples are a Class
2 transformer or a Class 2 power sources in compliance with, UL 5085-3/ CSA-C22.2 No. 66.3
or UL 1310/CSA-C22.2 No. 223). In order to respect the UL/CSA 61010 requirements, install
the regulator inside a box, not in external environment.
If the equipment is used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
•The power supply voltage must be within the range of 24V±10%.
•The board implements a protection against overload of the reference signal.
•The M12 12 pin male connector has the following pinout

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
14
PIN
NAME
DESCRIPTION
1
24 VDC
Power supply
Connect to the positive pole (24VDC) and to the negative pole (GND) of the power supply.
2
GND
3
IN+
Input of voltage (0-10V) or current (4-20mA) reference signal
Connect to the positive pole (IN+) and to the negative pole (IN-) of the reference signal
generator.
Internal resistance with voltage input: >10kΩ. Use reference signal generator with low
impedance and with output current >1mA@10V.
Internal resistance with current input: 100Ω.
It is mandatory to connect all negative poles of the power supply and the reference signal
generator together (pin 2 and pin 4).
4
IN-
5
Vout+
Voltage analog feedback signal (0-5V)
Connect the positive pole (Vout+) and the negative pole (Vout-) to the voltage input.
Output resistance: <10MΩ.
Do not connect the negative pole (Vout-) with other negative poles (pin 2 and pin 4): as noise,
input signal errors or feedback signal errors might occur.
6
Vout-
7
Iout+
Current analog feedback signal (4-20mA)
Connect to the positive pole of the current input.
Connect the negative pole of the current input to GND (pin 2).
8
OUT
Digital output signal (0-24V)
Connect to a digital input. If the input is of the NPN type, use pin 1 (24VDC) as reference of
digital input; otherwise if the input is of the PNP type, use pin 2 (GND) as reference of digital
input. Output resistance: >15MΩ. Max current: 50mA.
9
EXT+
Voltage (0-10V) or current (4-20mA) analog external sensor signal
Connect the output (EXT+) and the reference (EXT-) of the external sensor.
Internal resistance with voltage input: >10kΩ. Use reference signal generator with low
impedance and with output current >1mA@10V.
Internal resistance with current input: 100Ω.
It is mandatory to connect all negative poles of the power supply and the external sensor
together (pin 2 and pin 10).
10
EXT-
11
NC
Not connected
12
NC
Not connected

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
15
•For the electrical connection the following cable types are available:
CODE
DESCRIPTION
CS-LF12HC-C200
co-moulded connector M12 12 pole, female, straight with 2-metre cable unshielded
CS-LF12HC-C500
co-moulded connector M12 12 pole, female, straight with 5-metre cable unshielded
CS-LR12HC-C200
co-moulded connector M12 12 pole, female, bend with 2-metre cable unshielded
CS-LR12HC-C500
co-moulded connector M12 12 pole, female, bend with 5-metre cable unshielded
CS-LF12HC-D200
co-moulded connector M12 12 pole, female, straight with 2-metre cable shielded
CS-LF12HC-D500
co-moulded connector M12 12 pole, female, straight with 5-metre cable shielded
CS-LR12HC-D200
co-moulded connector M12 12 pole, female, bend with 2-metre cable shielded
CS-LR12HC-D500
co-moulded connector M12 12 pole, female, bend with 5-metre cable shielded
CS-AA08EC
4-ways T connector for external transducer, power supply and command signal
G11W-G12W-2
Micro USB cable (it may be used during the configuration phase)

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
16
9. CoilVision
With the integrated CoilVision technology the proportional regulator is able to
constantly monitor the operation of the coils inside it and prevent any malfunctions.
Depending on the model chosen, the proportional regulator can have three different levels of
diagnostics:
•Without diagnosticc: the CoilVision technology isn’t implemented.
•Basic diagnostics: CoilVision technology is active and will advice the user when the coils are
nearing the end of their life cycle
•CoilVision diagnostics: CoilVision technology is active and, in addition to advice the user
when the coils are nearing the end of their life cycle, constantly sends information about
their current health status to the UVIX environment.
10.Digital output
The digital output (OUT signal, pin 8) is a 0-24V digital signal. Through the UVIX configuration
software it is possible to set the logic of this output:
•Active –high level: if the output is activated, its value is brought to a high logic level.
•Active –low level: if the output is activated, its value is brought to a low logic level.
Furthermore, based on the electrical connection made by the user, the following configurations
can be obtained:
•PNP: in this configuration the output signal refers to GND (pin 2), therefore the PNP digital
input of the control system must be connected between pin 8 (OUT) and pin 2 (GND).
•NPN: in this configuration the output signal refers to + 24V (pin 1), therefore the NPN digital
input of the control system must be connected between pin 8 (OUT) and pin 1 (+ 24V)
The operating mode of the digital output depends on what code is ordered. There are three
different operating modes:
•Error: the digital output changes state if the Regulator detects an error.
•Switch pressure: with this operating mode it is possible to set two fixed pressure thresholds,
a lower one and a higher one. The digital output changes state if the regulated pressure is
outside the range delimited by the two thresholds set. This is a useful way to check whether
the regulated pressure lies within the preset pressure range.

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
17
•Window pressure: with this operating mode it is possible to set two thresholds, a lower one
and a higher one, which determine a pressure range with respect to the target pressure value.
The digital output changes state if the regulated pressure is outside the instantaneous range
(depending on the value of the target pressure at that moment) delimited by the two
thresholds set.
This is a useful way to check whether the regulated pressure lies within the pre-established
precision range.
11.NFCanApp
NFCamApp is a configuration application that can be installed on android mobile device and
available on Play Store.
NFCamApp communicates with the Series PRE electronic pressure regulator via NFC connection
and is able view some device parameters and modify, if present, the parameters of the wi-fi card.
The NFC antenna is located under the front label in the lower left corner.
For installation and use of the NFCamApp, please refer to the dedicated manual.

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
18
11.1. Monitoring
This section ( ) displays the information about selected device.

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
19
•Type: description of device type.
•Subtype: description of device sub-type.
•Firmware: firmware version.
•WiFi connection: indicates if the WiFi connection is present
•Fieldbus connection: indicates the fieldbus connection available
•Serial number: univocal serial number device assigned by producer.
•Setup version: internal memory mapping version.
12. Universal visual interface X (UVIX)
UVIX is a supervisor software that can be installed on PC or on server that is part of the
company network and accessible from other PCs.
UVIX communicates with the Series PRE electronic pressure regulator via wireless connection (if
present) or via USB cable and is able to monitor and configure the device.
Following the monitoring and configurator of the Series PRE electronic pressure regulator is
described in detail. For installation and use of the UVIX, please refer to the dedicated manual.
12.1. Monitoring
Once the device is selected, the work page will be displayed. This page is divided into two parts;
•Status information
•Details

Operation and maintenance instructions
Series PRE proportional pressure regulator
External sensor version
5000056022
Ver. 00
20
12.1.1. Status information
This section displays the following fields related to the selected device. These information
are the same for all devices manageable by UVIX.
oA picture of the device with a coloured frame based on its global state (green is status
is ok, yellow/orange if a warning occurs, red if an error occurs)
oName: name given by the user
oDevice number: univocal serial number device assigned by producer.
oFamily name: description of device type
oFirmware: firmware version
oLast transmission: date and time of last data received
oDevice status: global state of device
oOperational status: operational status of device that can either be “work” if the target
pressure is received by the command signal (analog input or digital inputs) or
“manual” if the target pressure is received by UVIX.
oConnection: indicates if the device is transmitting or, more precisely, if the UVIX is
receiving data from it. The indication is given by the color of the dot that turns green
if the device is connected or red if it is not connected.
oUnder the device picture the “Configuration” command is located. Via this command
it is possible to open the configuration window of the selected device
12.1.2.Details
This section is divided into 3 sub-sections and lists specific information about selected device.
