Campbell 05103 User manual

USER MANUAL
Issued: 31.7.18
Copyright

1984-2018 Campbell Scientific Inc.
Printed under licence by Campbell Scientific Ltd
CSL 256
05103, 05103-45, 05106, 05108,
05108-45 and 05305 R.M.
Young Wind Monitors
(including optional Wind Tracker)

Guarantee
This equipment is guaranteed against defects in materials and workmanship.
We will repair or replace products which prove to be defective during the
guarantee period as detailed on your invoice, provided they are returned to us
prepaid. The guarantee will not apply to:

Equipment which has been modified or altered in any way without the
written permission of Campbell Scientific

Batteries

Any product which has been subjected to misuse, neglect, acts of God or
damage in transit.
Campbell Scientific will return guaranteed equipment by surface carrier
prepaid. Campbell Scientific will not reimburse the claimant for costs incurred
in removing and/or reinstalling equipment. This guarantee and the Company’s
obligation thereunder is in lieu of all other guarantees, expressed or implied,
including those of suitability and fitness for a particular purpose. Campbell
Scientific is not liable for consequential damage.
Please inform us before returning equipment and obtain a Repair Reference
Number whether the repair is under guarantee or not. Please state the faults as
clearly as possible, and if the product is out of the guarantee period it should
be accompanied by a purchase order. Quotations for repairs can be given on
request. It is the policy of Campbell Scientific to protect the health of its
employees and provide a safe working environment, in support of this policy a
“Declaration of Hazardous Material and Decontamination” form will be
issued for completion.
When returning equipment, the Repair Reference Number must be clearly
marked on the outside of the package. Complete the “Declaration of
Hazardous Material and Decontamination” form and ensure a completed copy
is returned with your goods. Please note your Repair may not be processed if
you do not include a copy of this form and Campbell Scientific Ltd reserves
the right to return goods at the customers’ expense.
Note that goods sent air freight are subject to Customs clearance fees which
Campbell Scientific will charge to customers. In many cases, these charges are
greater than the cost of the repair.
Campbell Scientific Ltd,
80 Hathern Road,
Shepshed, Loughborough, LE12 9GX, UK
Tel: [phone]
Fax: [phone]
Email: [email protected]
www.campbellsci.co.uk

PLEASE READ FIRST
About this manual
Please note that this manual was originally produced by Campbell Scientific Inc. primarily for the
North American market. Some spellings, weights and measures may reflect this origin.
Some useful conversion factors:
Area: 1 in2(square inch) = 645 mm2
Length: 1 in. (inch) = 25.4 mm
1 ft (foot) = 304.8 mm
1 yard = 0.914 m
1 mile = 1.609 km
Mass: 1 oz. (ounce) = 28.35 g
1 lb (pound weight) = 0.454 kg
Pressure: 1 psi (lb/in2) = 68.95 mb
Volume: 1 UK pint = 568.3 ml
1 UK gallon = 4.546 litres
1 US gallon = 3.785 litres
In addition, while most of the information in the manual is correct for all countries, certain information
is specific to the North American market and so may not be applicable to European users.
Differences include the U.S standard external power supply details where some information (for
example the AC transformer input voltage) will not be applicable for British/European use. Please note,
however, that when a power supply adapter is ordered it will be suitable for use in your country.
Reference to some radio transmitters, digital cell phones and aerials may also not be applicable
according to your locality.
Some brackets, shields and enclosure options, including wiring, are not sold as standard items in the
European market; in some cases alternatives are offered. Details of the alternatives will be covered in
separate manuals.
Part numbers prefixed with a “#” symbol are special order parts for use with non-EU variants or for
special installations. Please quote the full part number with the # when ordering.
Recycling information
At the end of this product’s life it should not be put in commercial or domestic refuse
but sent for recycling. Any batteries contained within the product or used during the
products life should be removed from the product and also be sent to an appropriate
recycling facility.
Campbell Scientific Ltd can advise on the recycling of the equipment and in some cases
arrange collection and the correct disposal of it, although charges may apply for some
items or territories.
For further advice or support, please contact Campbell Scientific Ltd, or your local agent.
CampbellScientificLtd,CampbellPark,80HathernRoad,Shepshed,Loughborough,LE129GX,UK
Tel:[phone] Fax:[phone]
Email:[e-mail]
www.campbellsci.co.uk

i
Contents
PDF viewers: These page numbers refer to the printed version of this document. Use the
PDF reader bookmarks tab for links to specific sections.
1. Introduction.......................................................1
2. Cautionary Statements .....................................1
3. Initial Inspection................................................2
3.1 Ships With ..............................................................................................2
4. Quickstart ..........................................................2
4.1 Step 1 —Mount the Sensor....................................................................2
4.2 Step 2 —Use SCWin Short Cut to Program Datalogger and Generate
Wiring Diagram......................................................................................3
5. Overview............................................................6
6. Specifications....................................................6
7. Installation.........................................................9
7.1 Siting ......................................................................................................9
7.2 Assembly and Mounting.........................................................................9
7.3 Wiring...................................................................................................10
7.4 Programming ........................................................................................11
7.4.1 Wind Speed.................................................................................11
7.4.2 Wind Direction ...........................................................................12
7.4.3 Wind Vector Processing Instruction ...........................................12
7.4.4 Example Programs......................................................................13
7.4.4.1 CR1000 Example Program............................................13
7.4.4.2 CR6 Example Program .................................................14
7.4.4.3 CR200(X) Example Program ………………………….14
7.4.5 Long Lead Lengths .....................................................................15
8. Sensor Maintenance .......................................15
9. Troubleshooting..............................................16
9.1 Wind Direction .....................................................................................16
9.2 Wind Speed ..........................................................................................16
10. References.......................................................17

ii
Appendices
A. Diagrams provided by R M Young........................ A-1
B. Using the Wind Tracker Display Unit.................... B-1
C. Wind Direction Sensor Orientation....................... C-1
D. Wind Direction Measurement Theory................... D-1
E. Importing Short Cut Code into CRBasic Editor ... E-1
Figures
4-1. Wind monitor mounted to a CM200 Series Crossarm with
pn 008285 Nurail®...........................................................................3
7-1. CM220 Right Angle Mounting Kit mounted to a crossarm ...............10
7-2. The CM216 allows the wind monitor to mount atop a tripod ............10
B-1. Location of 1 mΩ Resistor on Circuit Board ...................................B-2
B-2. Disconnecting the Resistor from the Circuit ....................................B-2
B-3. Wind Monitor to Wind Tracker Cable Connections ........................B-3
B-4. Connecting the Wind Tracker to a Datalogger using Single-ended
Inputs............................................................................................B-4
B-5. Connecting the Wind Tracker to a Datalogger using Differential
Inputs.............................................................................................B-4
C-1. Magnetic declination at 2012.5 (degrees relative to true north,
positive is east) ..........................................................................C-2
C-2. Declination angles east of True North are subtracted from 0 to
get True North ..............................................................................C-2
C-3. Declination angles west of True North are added to 0 to get
True North ....................................................................................C-3
D-1. 05103 potentiometer in a half bridge circuit ....................................D-1
Tables
6-1. Wind Speed Specifications ..................................................................6
6-2. Wind Direction Specifications .............................................................7
6-3. Physical Specifications.........................................................................7
7-1. Wire Colour, Wire Function, and Datalogger Connection.................11
7-2. Wind Speed Multiplier.......................................................................12
7-3. Parameters for Wind Direction ..........................................................11
7-4. Wiring for Example Programs ...........................................................13

1
05103, 05103-45, 05106, 05108, 05108-45
and 05305 R.M. Young Wind Monitors
1. Introduction
The 05103, 05103-45, 05106, 05108, 05108-45 and 05305 Wind Monitor sensors
are used to measure horizontal wind speed and direction. The 05305 is a high
performance version of the 05103 designed to meet PSD specifications for air
quality applications. The 05103-45 is an alpine version that discourages ice
buildup. The 05106 is recommended for marine applications. The 05108 is a
heavy duty wind monitor that greatly extends service life and the 05108-45 is a
heavy duty wind monitor suitable for alpine applications.
Wind Monitors purchased directly from R.M. Young will be wired
differently and may not have the 1 MΩ resistor used to short the
readings in the dead band to ground.
Before installing the Wind Monitor, please study
Section 2, Cautionary Statements
Section 3, Initial Inspection
Section 4, Quickstart
2. Cautionary Statements
The Wind Monitor is a precision instrument. Please handle it with care
Do not use cable lengths greater than 30 m (9ft) in electrically noisy
environments.
If the Wind Monitor is to be installed at heights over 6 feet, be familiar with
tower safety and follow safe tower climbing procedures.
Danger —Use extreme care when working near overhead electrical wires.
Check for overhead wires before mounting the Wind Monitor or before
raising a tower.
The black outer jacket of the cable is Santoprene® rubber. This compound
was chosen for its resistance to temperature extremes, moisture, and UV
degradation. However, this jacket will support combustion in air. It is rated
as slow burning when tested according to U.L. 94 H.B. and will pass
FMVSS302. Local fire codes may preclude its use inside buildings.
Wire colour and functions of sensors purchased through Campbell Scientific
may not correspond with the wire colours and functions given in the
manuacturer’s manual. to ensure proper function, follow the wiring provided
in Short Cut or in the Campbell Scientific manual.
Wind monitors purchased directly from R.M. Young may not have the 1 MΩ
resistor used to short the readings in the dead band to ground.
NOTE

05103, 05103-45, 05106, 015108, 05108-45 and 05305 R.M. Young Wind Monitors
2
3. Initial Inspection
Upon receipt of the Wind Monitor, inspect the packaging and contents for
damage. File damage claims with the shipping company. Immediately check
package contents against the shipping documentation (see Section 3.1, Ships
With).
Contact Campbell Scientific about any discrepancies.
The model number and cable length are printed on a label at the connection
end of the cable. Check this information against the shipping documents to
ensure the expected product and cable length are received.
3.1 Ships With
The Wind Monitors ship with:
(1) Allen wrench from manufacturer
(1) Bearing spacer from manufacturer
(1) Calibration sheet
(1) Instruction manual
(1) 006766 mounting pipe
4. Quickstart
4.1 Step 1 —Mount the Sensor
Figure 4-1 shows a 05103 installed with a 008285 Nurail®
*
. Please review
Section 7, Installation, for siting and other guidelines.
Install the 05103 using:
006766 300 mm (12 inch) aluminium pipe
CM220 Right-Angle Mounting Kit, or
008285 1 x 1 inch Nurail® Crossover Fitting
1. Secure the propeller to its shaft using the nut provided with the sensor.
2. Mount a CM202, CM204, or CM206 crossarm to a tripod or tower.
3. Orient the crossarm North-South, with the 008285 Nurail® on the north end.
Appendix C contains detailed information on determining true north using a
compass and the magnetic declination for the site.
4. Secure the 006766 300 mm (12 inch) aluminium pipe to the 008285 Nurail®.
The 006766 aluminium pipe is shipped with the Wind Monitor.
5. Place the orientation ring, followed by the Wind Monitor on the aluminium
pipe.
6. Orient the junction box to the south, and tighten the band clamps on the
orientation ring and aluminium pipe. Final sensor orientation is done after the
datalogger has been programmed to measure wind direction as described in
Appendix C.
*
Nurail®is a registered trademark of the Hollaender Manufacturing Company.

User Manual
3
7. Use the torpedo level to ensure that the Wind Monitor is level.
8. Route the sensor cable along the underside of the crossarm to the tripod or
tower, and to the instrument enclosure.
9. Secure the cable to the crossarm and tripod or tower using cable ties.
Figure 4-1. Wind monitor mounted to a CM200 Series Crossarm
with pn 008285 Nurail®
4.2 Step 2 —Use SCWin Short Cut to Program Datalogger and
Generate Wiring Diagram
The simplest method for programming the datalogger to measure the Wind
Monitor is to use Campbell Scientific’s SCWin Short Cut Program Generator.
Wind Monitor
pn 008285 Nurail®
Mounting Pipe
(supplied with sensor)
CM200 Series Crossarm

05103, 05103-45, 05106, 015108, 05108-45 and 05305 R.M. Young Wind Monitors
4
1. Open Short Cut and click on New Program.
2. Select the Datalogger Model and enter the Scan Interval.

User Manual
5
3. Under Available Sensors and Devices, select your sensor, and select the
right arrow to add it to the list of sensors to be measured then select next.
4. Select WindVector for the output and then select Finish.

05103, 05103-45, 05106, 015108, 05108-45 and 05305 R.M. Young Wind Monitors
6
5. Wire according to the wiring diagram generated by SCWin Short Cut.
5. Overview
Wind speed is measured with a helicoid-shaped, four-blade propeller. Rotation of
the propeller produces an AC sine wave signal with frequency proportional to
wind speed.
Vane position is transmitted by a 10 kpotentiometer. With a precision
excitation voltage applied, the output voltage is proportional to wind direction.
The R.M. Young Instruction Manual includes additional information on the
operating principles, installation, and maintenance of the sensor.
6. Specifications
Table 6-1, Table 6-2 and Table 6-3 provide the wind speed, wind direction and
physical specifications, respectively.
Features:
Rugged enough for harsh environments
Constructed with thermoplastic material that resists corrosion from sea-
air environments and atmospheric pollutant
Ideal for wind profile studies
Compatible with the LLAC4 4-channel Low Level AC Conversion
Module, which increases the number of anemometers one datalogger can
measure
Compatible with Campbell Scientific CRBasic dataloggers: CR200(X)
series, CR300 series, CR6 series, CR800 series, CR1000, CR3000,
CR5000 and CR9000(X).
Maximum cable length is 300 m.
NOTE

User Manual
7
Table 6-1. Wind Speed Specifications
05103
Wind
Monitor
05103-45
Wind
Monitor-
Alpine
05106
Wind
Monitor-
MA
05108 Heavy
Duty Wind
Monitor
05108-45
Heavy duty
Wind
Monitor -
Alpine
05305
Wind Monitor-AQ
Range
0 to 100 m s–1(0 to 224 mph)
0 to 50 m s–1
(0 to 112 mph)
Accuracy
±0.3 m s–1(±0.6 mph) or 1% of reading
±0.2 m s–1( ±0.4 mph)
or
1% of reading
Starting
Threshold
1.0 m s–1(2.2 mph)
2.4 mph
(1.1 m s–1)
1.0 m s-1 (2.2 mph)
0.4 m s–1(0.9 mph)
Distance
Constant
(63%
recovery)
2.7 m (8.9 ft)
2.1 m (6.9 ft)
Output
ac voltage (3 pulses per revolution);
1800 rpm (90 hz) = 8.8 m s–1(19.7 mph)
ac voltage (3 pulses per
revolution);
1800 rpm (90 hz) =
9.2 m s–1
(20.6 mph)
Resolution
(0.0980 m s–1)/(scan rate in seconds) or
(0.2192 mph)/(scan rate in (seconds)
(0.1024 m s–1)/(scan rate
in sec.) or (0.2290
mph)/(scan rate in sec.)

05103, 05103-45, 05106, 015108, 05108-45 and 05305 R.M. Young Wind Monitors
8
Table 6-2. Wind Direction Specifications
05103
Wind
Monitor
05103-45
Wind
Monitor-
Alpine
05106
Wind
Monitor-
MA
05108 Heavy
Duty Wind
Monitor
05108-45
Heavy duty
Wind
Monitor -
Alpine
05305
Wind Monitor-AQ
Range
0° to 360° mechanical, 355° electrical (5° open)
Accuracy
±3°
±5°
±3°
Starting
Threshold
1.1 m s–1(2.4 mph)
1.0 m s–1(2.0 mph)
0.5 m s–1(1.0 mph)
Distance
Constant (50%
recovery)
1.3 m (4.3 ft)
1.2 m (3.9 ft)
Damping Ratio
0.3
0.25
0.45
Damped
Natural
Wavelength
7.4 m (24.3 ft)
4.9 m (16.1 ft)
Undamped
Natural
Wavelength
7.2 m (23.6 ft)
4.4 m (14.4 ft)
Output
analogue dc voltage from potentiometer—resistance 10 kΩ; linearity 0.25%;
life expectancy 50 million revolutions
Power
switched excitation voltage supplied by datalogger
Table 6-3. Physical Specifications
05103
Wind
Monitor
05103-45
Wind
Monitor-
Alpine
05106
Wind
Monitor-
MA
05108 Heavy
Duty Wind
Monitor
05108-45 Heavy
duty Wind
Monitor - Alpine
05305
Wind Monitor-AQ
Operating
Temperature
Range
–50° to +50°C, assuming non-
riming conditions
–50° to +60°C, assuming non-riming
conditions
–50° to +50°C,
assuming non-riming
conditions
Overall
Height
37 cm (14.6 in)
40 cm (15.7 in)
38 cm (15 in)
Overall
Length
55 cm (21.7 in)
57 cm (22.4 in)
65 cm (25.6 in)
Main
Housing
Diameter
5 cm (2 in)
Propeller
Diameter
18 cm
(7.1 in)
14 cm
(5.5 in)
18 cm
(7.1 in)
20 cm (7.9 in)
Mounting
Pipe
Description
34 mm (1.34 in) outer diameter; standard 1.0 in IPS schedule 40
Weight
1.5 kg
(3.2 lb)
1 kg
(2.2 lb)
1.5 kg
(3.2 lb)
1 kg (2.2 lb)
1.1 kg (2.5 lb)

User Manual
9
The black outer jacket of the cable is Santoprene® rubber. This
compound was chosen for its resistance to temperature extremes,
moisture, and UV degradation. However, this jacket will support
combustion in air. It is rated as slow burning when tested according
to U.L. 94 H.B. and will pass FMVSS302. Local fire codes may
preclude its use inside buildings.
7. Installation
7.1 Siting
Locate wind sensors away from obstructions (for example, trees and building).
Generally, there should be a horizontal distance of at least ten times the height of
the obstruction between the windset and the obstruction. If the sensors need to be
mounted on a roof, the height of the sensors above the roof, should be at least 1.5
times the height of the building. See Section 10, References, for a list of
references that discuss siting wind speed and direction sensors.
7.2 Assembly and Mounting
Tools Required:
5/64 inch Allen wrench
1/2 inch open end wrench
compass and declination angle for the site (see Appendix C)
small screw driver provided with datalogger
UV resistant cable ties
small pair of diagonal-cutting pliers
6 –10 inch torpedo level
Install the propeller to its shaft using the nut provided with the sensor.
The Wind Monitor mounts to a standard 1 inch IPS schedule 40 pipe (1.31 inch
O.D.). A 12 inch long mounting pipe ships with the Wind Monitor for attaching
the sensor to a CM200-series crossarm with the CM220 (Figure 7-1) or 008285
Nurail® fitting (Figure 4-1 in Quickstart section). The 05103 can also be mounted
to a CM110 series tripod mast with the CM216 Mast Mounting Kit (see Figure
7-2).
Mount the CM200-series crossarm to the tripod or tower. Orient the crossarm
North-South, with the 1 inch Nurail® or CM220 on the North end. Appendix C
contains detailed information on determining true north using a compass and the
magnetic declination for the site.
Secure the mounting pipe to the Nurail® or CM220. Place the orientation ring,
followed by the Wind Monitor on the mounting pipe. Orient the junction box to
the south, and tighten the band clamps on the orientation ring and mounting post.
Final sensor orientation is done after the datalogger has been programmed to
measure wind direction as described in Appendix C.
Route the sensor cable along the underside of the crossarm to the tower/tripod
mast, and to the instrument enclosure. Secure the sensor cable to the crossarm and
mast using cable ties.
CAUTION

05103, 05103-45, 05106, 015108, 05108-45 and 05305 R.M. Young Wind Monitors
10
Figure 7-1. CM220 Right Angle Mounting Kit mounted to a crossarm
Figure 7-2. The CM216 allows the wind monitor to mount atop a tripod
7.3 Wiring
Connections to Campbell Scientific dataloggers are given in Table 7-1. When
Short Cut for Windows software is used to create the datalogger program, the
sensor should be wired to the channels shown in the wiring diagram created by
Short Cut.
CM220
CM200-Series Crossarm

User Manual
11
Table 7-1. Wire Colour, Wire Function, and Datalogger Connection
Wire
Colour
Wire
Function
Datalogger Connection Terminal
Red
WS Signal
U configured for pulse input1, (pulse input),
Or P_LL (pulse, low-level ac)
Black
WS Signal
Reference
Green
WD Signal
U configured for single-ended analogue input1,
SE (single-ended, analogue input)
Blue
WD Voltage
Excitation
U configured for voltage excitation1, EX, or
VX (voltage excitation)
White
WD Signal
Reference
(analogue ground)
Clear
Shield
(analogue ground)
1U channels are automatically configured by the measurement instruction.
7.4 Programming
This section is for users who write their own programs. A datalogger program to
measure this sensor can be created using Campbell Scientific’s SCWin Short Cut
Program Generator software. You do not need to read this section to use Short
Cut.
7.4.1 Wind Speed
For CRBasic dataloggers, wind speed is measured using the PulseCount()
instruction. Syntax of the PulseCount() instruction is:
PulseCount( Dest, Reps, PChan, PConfig, POption, Mult, Offset )
The PConfig parameter should be set to 1 (Low Level AC) and the POption
parameter should be set to 1 (Frequency).
For Edlog dataloggers, wind speed is measured using Edlog instruction Pulse
(P3). The configuration parameter should be set to code 21 (Low Level AC,
Output Hz configuration).
The expression for wind speed (U) is:
U = Mx + B
where
M = multiplier
x = number of pulses per second (Hertz)
B = offset
Table 7-2 lists the multipliers to obtain miles/hour or metres/second when the
measurement instruction is configured to output Hz.
The helicoid propeller has a calibration that passes through zero, so the offset is
zero (Gill, 1973; Baynton, 1976).

05103, 05103-45, 05106, 015108, 05108-45 and 05305 R.M. Young Wind Monitors
12
Table 7-2. Wind Speed Multiplier
Model
Miles/
Hour Output
Metres/
Second Output
05103, 05103-45, or 05106
0.2192
0.0980
05108 or 05108-45
0.3726
0.1666
05305
0.2290
0.1024
7.4.2 Wind Direction
The wind vane is coupled to a 10 kpotentiometer, which has a 5 degree
electrical dead band between 355 and 360 degrees. A 1 Mresistor between the
signal and ground pulls the signal to 0 mV (0 degrees) when wind direction is
between 355 and 360 degrees.
The CR200(X) datalogger uses the ExDelSE() instruction to measure wind
direction. All other CRBasic dataloggers use the BRHalf() instruction. Edlog
dataloggers (CR510, CR10X, CR23X) use Edlog Instruction 4—Excite, Delay
(P4).
Some CRBasic measurement sequences cause the measurement of the wind
direction to return a negative wind direction (–30º) while in the dead band. This
can be overcome by using a delay of 40 ms (40,000µs) or by setting negative wind
direction values to 0.0: If WindDir < 0, then WindDir = 0.0.
The excitation voltage, range codes, and multipliers for the different datalogger
types are listed in Table 7-3. Appendix B has additional information on the P4
and BRHalf() measurement instructions.
Table 7-3. Parameters for Wind Direction
CR200(X)
CR300
Series
CR800,
CR850,
CR1000
CR1000X
CR6
CR5000,
CR3000
Measurement
Range
NA
mV 2500
mV 2500
mV 5000
mV 5000
mV 5000
Excitation
Voltage
2500 mV
2500 mV
2500 mV
2500 mV
2500 mV
5000 mV
Reverse
Excitation
NA
NA
True
True
True
True
Delay or
Settling Time
20000 µs
20000 µs
20000 µs
20000 µs
20000 µs
20000 µs
Multiplier
0.142
355
355
355
355
355
Offset
0
0
0
0
0
0
7.4.3 Wind Vector Processing Instruction
The Wind Vector output instruction is used to process and store mean wind speed,
unit vector mean wind direction, and Standard Deviation of the wind direction
(optional) using the measured wind speed and direction samples.
