Cannondale SuperSix EVO Configuration guide

READ THIS SUPPLEMENT AND YOUR
CANNONDALE BICYCLE OWNER’S MANUAL.
Both contain important safety information.
Keep both for future reference.
Owner’s Manual Supplement
SuperSix EVO
English

Safety Messages
In this supplement, particularly important information
is presented in the following ways:
Indicates a hazardous situation which, if
not avoided, may result in death or serious
injury.
NOTICE
Indicates special precautions that must
be taken to avoid damage.
Cannondale Help Center
Our online Help Center contains helpful
resources to consult about our bikes.
https://cannondale.zendesk.com/hc/en-us
Symbols:
Symbol Name Description
CRB-GEL
Carbon gel/friction paste Apply carbon gel (friction paste) KF115/
GREASE
NGLI2 synthetic grease Apply NGLI2 synthetic grease.
Loc 242
Medium-strength removable thread
lock Apply Loctite® 242 (blue) or equivalent.

3
CONTENTS
Safety Information.......................... 47
Technical Information................... 823
Replacement Parts......................2425
Notes ..................................................26
Cannondale Supplements
This manual is a “supplement” to your
Cannondale Bicycle Owner’s Manual.
This supplement provides additional and
important model specific safety, maintenance,
and technical information. It may be one of
several important manuals/supplements for
your bike; obtain and read all of them.
Please contact your Authorized Cannondale
Dealer immediately if you need a manual or
supplement or have a question about your
bike. You may also contact us using the
appropriate country/region/location
information.
You can download Adobe Acrobat PDF
versions of any manual/supplement from our
website: http://www.cannondale.com.
Contacting Cannondale
Cannondale USA
Cycling Sports Group, Inc.
1 Cannondale Way
Wilton, CT 06897 USA
1800726-BIKE (2453)
CSG Europe (Woudenberg)
Cycling Sports Group Europe B.V.
Geeresteinselaan 57
3931JB Woudenberg
The Netherlands
PH: 00.31.541.200374
International Distributors
Consult our website to identify the appropriate
Cannondale Dealer for your region.
Your Cannondale Dealer
To make sure your bike is serviced and
maintained correctly, and that you protect
applicable warranties, please coordinate all
service and maintenance through your
Authorized Cannondale Dealer.
NOTICE
Unauthorized service, maintenance, or
repair parts can result in serious damage
and void your warranty.

4
SuperSix EVO OMS
Safety Information
Important Composites Message
151901 Rev. 0 (09/22)
SAFETY INFORMATION
Important Composites
Message
Your bike (frame and components) is
made from composite materials also
known as “carbon fiber.”
All riders must understand a fundamental
reality of composites. Composite
materials constructed of carbon fibers are
strong and light, but when crashed or
overloaded, carbon fibers do not bend,
they break.
For your safety, as you own and use the
bike, you must follow proper service,
maintenance, and inspection of all the
composites (frame, stem, fork, handlebar,
seat post, etc.) Ask your Cannondale
Dealer for help.
We urge you to read PART II, Section D.
“Inspect For Safety” in your Cannondale
Bicycle Owner’s Manual BEFORE you
ride.
You can be severely injured, paralyzed
or killed in an accident if you ignore this
warning.
Inspection & Crash Damage
Of Carbon Frames/Forks
After A Crash Or Impact:
Inspect frame carefully for damage. See
PART II, Section D. Inspect For Safety in
your Cannondale Bicycle Owner’s Manual.
Do not ride your bike if you see any sign of
damage, such as broken, splintered, or
delaminated carbon fiber.
Any of the following may indicate a
delamination or damage:
• An unusual or strange feel to the
frame
• Carbon which has a soft feel or
altered shape
• Creaking or other unexplained
noises,
• Visible cracks, a white or milky color
present in carbon fiber section
Continuing to ride a damaged frame
increases the chances of frame failure,
with the possibility of injury or death of
the rider.

5
Safety Information
Intended Use
Intended Use
The intended use of all
models is
ASTM CONDITION 1,
High-Performance
Road.
Please read your Cannondale Bicycle
Owner’s Manual for more information
about Intended Use and Conditions 15.
Servicing
This supplement may include procedures
beyond the scope of general mechanical
aptitude.
Special tools, skills, and knowledge may
be required. Improper mechanical work
increases the risk of an accident. Any
bicycle accident has risk of serious injury,
paralysis, or death.
To minimize risk we strongly recommend
that owners always have mechanical
work done by an Authorized Cannondale
Dealer.
Disc Brakes on Road Bikes
Relative to conventional rim brakes, disc
brakes are less aected by water, do not
wear or heat the rims and therefore are
more consistent. Disc brakes also may be
more powerful.
To minimize risk of injury or accidents:
• Understand that road bikes have a
relatively small tire contact patch
(part of the tire that touches the
road). In order to apply the brakes
safely and eectively, you may need
more or less braking force in
dierent situations. You need to take
into account various road and
weather conditions that can aect
traction.
• Disc brakes are excellent, but not
some kind of magic. Take some time
riding your new disc brake road bike
in lower risk circumstances to get
used to the feel and performance of
the disc brakes and tires.
You can be severely injured, paralyzed
or killed in an accident if you ignore this
message.

6
SuperSix EVO OMS
Safety Information
Using a Trainer
151901 Rev. 0 (09/22)
Using a Trainer
Follow the trainer manufacturer instructions for the
use of any required adapters.
Be particularly cautious with a carbon frame or fork.
Carbon is relatively soft, not abrasion resistant. If
there is any relative movement, carbon will wear
quickly.
If you ride a trainer a lot, consider using an old bike:
Corrosion from sweat will take its toll. Weight is
irrelevant. Save wear on your expensive
components.
Ask you dealer for help with trainers, the right one
and the correct way to use it.
NOTICE
TRAINERS - Improperly mounting a bike in a
trainer, or using one that is not compatible with
your particular bike frame can cause serious
damage.
This kind of damage is not covered by the
Cannondale Limited Warranty.
See “2-in-1 Trainer Thru Axle Installation
Instructions 138252.pdf”
at www.cannondale.com
Water Bottles
Side impacts to a water bottle or cage can
result in damage to threaded inserts due to
the leverage on a very small area. In a crash,
certainly the last thing you should be worried
about is saving the threaded inserts in your
frame. However, when you are storing or
transporting your bike, take steps to prevent
situations where a water bottle may be hit or
bumped by a strong force that would cause
damage. Remove the bottle and cage when
you are packing your bike for travel.
Periodically check the attachment of the
bottle cage; tighten the cage bolts if
necessary. Don’t ride with a loose bottle
cage.
A loose cage will damage the insert and
possibly lead to the inserts pulling out.
It may be possible to repair a loose insert or
to install another insert only if the frame is
undamaged. Replacement requires the use
of a special tool. If you notice damage to the
threaded insert, please ask your Cannondale
Dealer for help.
NOTICE
An impact, crash, or loose bottle cage can result
in damage to your frame. This kind of damage
is not covered by the Cannondale Limited
Warranty.

7
Safety Information
Building Up A Frameset
Building Up A Frameset
Before building up a frameset, consult with
your Cannondale Dealer and the component
manufacturers and discuss your riding style,
ability, weight, and interest in and patience
for maintenance.
Make sure the components chosen are
compatible with your bike and intended for
your weight and riding style.
Generally speaking, lighter weight
components have shorter lives. In selecting
lightweight components, you are making a
trade-o, favoring the higher performance
that comes with less weight over longevity. If
you choose more lightweight components,
you must inspect them more frequently. If
you are a heavier rider or have a rough,
abusive, or “go for it” riding style, buy
heavy-duty components.
Read and follow the component
manufacturers warnings and instructions.
Tightening Torques
Correct tightening torques for the fasteners
on your bicycle (e.g., bolts, screws, and
nuts) are important for your safety and to
maintain the durability and performance of
your bicycle.
We urge you to have your dealer correctly
torque all fasteners using a torque wrench.
If you decide to torque fasteners yourself,
always use a torque wrench.
Find Tightening Torque Information :
The wide range of bicycle models and
components used means that a listing of
tightening torques would be out-of-date
by the time it was published. Many
fasteners should be installed with a thread
locking adhesive such as Loctite®.
To determine the correct tightening
torque and any adhesive application
for a fastener we ask you to check the
following:
• On-product torque markings.
• Torque specs in the component
manufacturer’s instructions shipped
with your bicycle.
• Torque specs listed on the websites
of component manufacturers.
• With your dealer. Dealers have
access to current data and have
experience with correct torques for
most fasteners.

8
SuperSix EVO OMS
Technical Information
Specifications
151901 Rev. 0 (09/22)
TECHNICAL INFORMATION
Specifications
Item Specification
Head Tube UPR: 11/8in, LWR: 11/4in
Headset Integrated 11/8in-11/4in,
IS42 Top IS47 Bottom
Bottom Bracket: Type/Width BSA/68mm - Sleeve required
Front Derailleur Braze-on
Seat Post: 0mm Oset: K26062
20mm Oset: K26072
Seatbinder: K26002
Min. Seat Post Insert 65mm
Max. Seat Post Insert 44cm: 100mm 48cm: 140mm 51cm: 166mm
54cm: 190mm 56cm: 193mm 58cm: 205mm
61cm: 215mm
Tire Size x Max. Tire Width 700c x 30mm (measured)
Brakes: Mount Type / Min./Max. Rotor Dia. FT: Flat Mount/140mm/160mm
RR: Flat Mount/140mm/160mm
Axles: Type/Length FT: Syntace 100mmxM121.0P,
122mm Overall Length
RR: Syntace 142mmxM121.0P,
160mm Overall Length
Fork Oset Size 44cm-54cm: 55mm
Size 56cm-61cm: 45mm
Intended Use ASTM Condition 1: High-Performance Road
Max. Weight Limit: Total
(Rider+All Equipment)
285lbs/129kg
1
Serial Number
Use the 7-digit serial number label (1) located
on the bottom bracket to register your bike.
Product Registration
www.cannondale.com

9
Technical Information
Geometry
75mm
A
M
O
B
P
L
JI
H
N
K
F
G
E
D
Geometry
Dimensions = centimeter
* = same spec.
Size 44 48 51 54 56 58 61
Wheel Size 700c 700c 700c 700c 700c 700c 700c
ASeat Tube Length 40.0 43.8 47.7 51.5 53.4 56.7 60.0
BTop Tube Horizontal 51.2 52.0 52.8 54.6 56.2 57.8 60.3
CTop Tube Actual 46.9 47.9 48.9 50.9 52.3 54.1 56.4
DHead Tube Angle 70.9° 71.2° 71.2° 71.2° 73.0° 73.0° 73.0°
ESeat Tube Angle Eective 74.3° 74.3° 74.3° 73.7° 73.3° 72.9° 72.3°
E’ Seat Tube Angle Actual 74.3° 74.3° 74.3° 73.7° 73.3° 72.9° 72.3°
F Standover 69.8 72.7 75.6 78.8 80.7 83.6 86.6
GHead Tube Length 10.0 11.4 13.0 15.4 16.5 18.8 22.0
H Wheelbase 98.1 98.7 99.6 101.0 99.4 100.7 102.4
I Front Center 58.2 58.9 59.8 61.1 59.4 60.7 62.4
J Chain Stay Length 41.0 41.0 41.0 41.0 41.0 41.0 41.0
K Bottom Bracket Drop 7.4 7.4 7.4 7.2 7.2 6.9 6.9
L Bottom Bracket Height 26.8 26.8 26.8 27.1 27.1 27.3 27.3
M Fork Rake 5.5 5.5 5.5 5.5 4.5 4.5 4.5
N Trail 6.0 5.8 5.8 5.8 5.8 5.8 5.8
O Stack 50.5 52.0 53.5 55.5 57.5 59.5 62.5
P Reach 37.0 37.4 37.8 38.4 38.9 39.5 40.3

10
SuperSix EVO OMS
Technical Information
Shimano Di2 Battery
151901 Rev. 0 (09/22)
Shimano Di2 Battery
3
1
2
4
5
a
a
1. BB plug
2. Tether
3. Di2 battery
4. O-ring, larger
5. O-ring, smaller
a. groove
Identification
• The tethering assembly is compatible with
Shimano BT_DN110 Di2 battery.
• The tether is fitted to the battery and secured
onto it by the O-rings. Be sure that the O-rings
are seated in the grooves.
• After the battery is inserted into the frame,
fold up the tether end loop and tuck it into the
opening. Insert the BB plug; make sure it is
inserted completely. The hole in the BB plug
is simply a drain to allow collected moisture to
exit.
NOTICE
Do not allow the tether to dangle outside
the frame opening.
Do not insert other objects into the frame
battery pocket.

11
Technical Information
Routing 1
Routing 1
1
2
3
4
5
2
6
7
8
9
10
1. Front brake hose
2. Rear brake hose
3. DT cable guide
4. DT cover
5. Rear derailleur wire
6. Front derailleur wire
7. SmartSense port cover
8. SmartSense cable
9. SmartSense seatpost
grommets
10. SmartSense cable
Identification

12
SuperSix EVO OMS
Technical Information
Routing 2
151901 Rev. 0 (09/22)
Routing 2
2
1
2
a
a
1
2
1. Headset bearing dust
cover
2. 2-piece spacers
a. Clearance area for brake
hose and electric wire
Identification

13
Technical Information
Downtube (DT) Port Guides / Routing
0.5 N·m
M3
5
1
2
3
4
6
7
NGLI-2
NGLI-2
Downtube (DT) Port Guides / Routing
Identification
1. 4-cable port cover
2. Mechanical shift housing
stop (DO NOT USE)
3. Shimano Di2 port cover
4. Wireless shifting cover
5. Internal brake hose guide
6. Guide screws, M3  8
7. Cover screws, M3  12

14
SuperSix EVO OMS
Technical Information
Rear Derailleur Mount (RD)
151901 Rev. 0 (09/22)
2 N·m
3
1
2
M3 X 14mm
GREASE
Loc 242
To replace:
1. Remove the rear axle.
2. Remove the screws (2).
3. Remove the hanger (1) and
thru axle nut (3).
4. Clean the area around the dropout and
inspect the frame carefully for any cracks
or damage. If you find damage, have the
frame inspected by your Cannondale
Dealer .
If the frame is not damaged, apply a light
film of grease between the frame and
hanger. This will help minimize any noise
or “creaking” that might result from
slight movement between the frame and
hanger.
5. Slide the new hanger and thru axle nut
onto the frame.
6. Apply Loctite® 242 (or medium strength
thread lock) to the screw threads and
tighten to the specified torque. Do not
over-tighten.
Rear Derailleur Mount (RD)
1. RD Hanger
2. Screws
3. Thru axle nut
As an option, this frame supports installation
of a Cannondale SmartSense.
What is SmartSense?
SmartSense is a system of powered
accessories. Each accessory shares the same
data communication and same rechargeable
battery. The behavior of each accessory can
be programmed and controlled independently
or coordinated with any other component via
the Cannondale App.
SmartSense Owner’s Manual
https://www.cannondale.com/-/media/
files/manual-uploads/cy22/138691-rev1-
cd-cy22-smartsense-owners-
manual-020922.ashx
The SmartSense Owner’s Manual contains
important safety information and information
regarding how to identify, to set up, and to
operate any installed/attached SmartSense-
compatible components.
SmartSense

15
Technical Information
Bottom Bracket
Bottom Bracket
1
2
3
4
Identification
1. Bottom bracket
2. Left bearing cup
3. Sleeve
4. Right bearing cup
This frame requires a bottom bracket
with integrated sleeve to prevent
spindle contact with internal wiring or
hoses! Do not remove or omit the
sleeve during assembly or service.

16
SuperSix EVO OMS
Technical Information
Seat Post
151901 Rev. 0 (09/22)
Seat Post
To remove seat post:
1. Turn the binder screw with a 4mm hex key
counter-clockwise to loosen the clamp.
When clamp is loose, simply lift the seat
post up out of the seat tube.
To install the seat post:
1. Remove the binder clamp, clean it and
the frame pocket, then apply fresh
grease to the surface that will fit against
the frame, as shown on the next page.
Reinstall the binder clamp into the frame
pocket.
2. Apply fresh carbon friction paste to the
inserted section of the seat post and
inside the seat tube, including the surface
of the binder clamp which contacts the
seat post.
3. Insert the seat post into the frame.
4. Set the saddle height, observing the
minimum insert and within the limits of
the maximum insert for the frame and
tighten the clamp screw to 8 Nm.
5. Lower the rubber cover to the frame.
To adjust height:
1. Insert a 4mm hex into the clamp screw.
2. Loosen the binder screw suciently to
move the seat post up or down in the seat
tube.
3. Set the seat post position.
4. Tighten the binder clamp screw to 8 Nm.
To remove binder:
1. Remove the seat post.
2. Using a 4mm hex key, turn the screw
clockwise (tightening it) until the binder
clamp disengages from the threaded
base and can be lifted up out of the seat
tube. Take care not to let the binder
clamp fall into the seat tube.
Maintenance
Periodically remove the seat post and the
binder clamp assembly to clean, to inspect
for damage, and to renew the application of
grease and of carbon gel.
NOTICE
Do not exceed the specified torque.
Do not use any spray cleaners or solvents
to clean.
Do not adjust a seat post so it is bottomed
out in the frame.
For more information about carbon fiber
seat posts, see also “Care and
Maintenance of Carbon Fiber Seat Posts”
in your Cannondale Bicycle Owner’s
Manual.

17
Technical Information
Seat Post
5mm
65mm
1
4
2
3
8 N·m
CRB-GEL
CRB-GEL
GREASE
6 N·m
5
Minimum Insert
Maximum Insert
Bike Size
44cm 100mm
48cm 140mm
51cm 166mm
54cm 190mm
56cm 193mm
58cm 205mm
61cm 215mm
Bottomed Out
Have a professional bike mechanic
size the seat post. Incorrectly cutting
the seat post can result in damage
leading to an accident.
1. Seat post
2. Binder clamp
3. Binder screw
4. Cover
5. Clamp bolts
Identification
Don’t grease the surface
that faces the seat post.
Maximum Insert

18
SuperSix EVO OMS
Technical Information
Headset Delta Compression Assembly - K35051
151901 Rev. 0 (09/22)
Headset Delta Compression Assembly - K35051
The Supersix Evo utilizes a fork with a
triangular steerer, also known as a “delta
steerer”
Only headset compression assembly K35051
can be used with the fork.
Important Information For Owners
The headset, stem, handlebar spacers, and
compression assembly are parts of a system
designed to work together. It is important to
your safety that you do not alter, remove or
omit parts, or assemble the system
incorrectly.
This manual does not include instructions for
servicing. This is why you should have work on
the system performed by a professional
bicycle mechanic with the experience, tools,
and information to complete any needed
service.
Have a professional bicycle mechanic service the fork, headset ,and stem of your bicycle.
Headset compression assembly K35051 must be assembled with both filler pieces. Do not
remove them for any reason.
The steerer top must be level (+2/-1mm) with top of the stem.
Key Points
The delta steerer must be sized correctly. A
mechanic must observe guidlines for cutting
and preparing the carbon fork for the frame.
The spacers used for bikes with internal
routing have been designed so that both filler
pieces are correctly positioned with the foot
pointing down.
Internal routing of the cables/housing is
limited to the void between the headset
bearing and the steerer sides.
NOTICE
Hose lengths must be carefully selected.
Avoid both too long and too short, because
incorrect lengths can limit steering angle
and damage hoses.

19
Technical Information
Headset Delta Compression Assembly - K35051
9
4
1
2
4
3
5
a
a
b
b
6
6
8
7
10
1. Stem
2. Fork steerer
3. Expander
4. Filler pieces
5. Spacer 2.5mm
6. Expander bolt
7. Front brake hose
8. Rear brake hose
9. Spacers
10. Headset bearing dust
cover
a. Lip
b. Filler foot
Identification
Item (5) used as the top spacer,
immediately below the stem, to
support the ller feet whenever
spacers are used which don’t have
foot supports (e.g., common round
spacers).

20
SuperSix EVO OMS
Technical Information
SystemBar ROne
151901 Rev. 0 (09/22)
4
5
3
6
1
2
5 N·m
1. Handlebar
2. Handlebar bolts
M5X18
3. Dogbone nut
4. Stem cover mod
5. Top cap for
6. Headset delta
compression
assembly
Identification
SystemBar ROne
