Chapter 1
Instructions for safe use

Instructions for safe use
Introduction
All products have been tested in accordance with the strictest international safety standards.
Please read the following sections before you connect the machine to the power supply.
These sections contain important information with regard to the user safety and the
prevention of equipment problems. Make sure that you observe the safety rules hereinafter.
This helps to assure safe operation of the product. Make sure that you observe all the
precautions mentioned below.
Note:
Depending on the context, the terms: system, machine, and equipment all will be used
to designate the product for which user documentation is applicable.
Note:
Some parts of the contents of this section may not be applicable to your product.
Note:
Please refer to the corresponding Material Safety Data Sheets for specific safety
information. You can download the Material Safety Data Sheets from the support site
of your product.
Warning and Caution Symbols
Warning:
Ignoring this warning could cause serious injury or even death.
Caution:
Ignoring this warning could cause injury or damage to property.
Note:
Indicates additional important information.
The indicators above are used on the warning labels or in the manuals to categorize the
level of safety warnings.
Chapter 1 - Instructions for safe use6
Instructions for safe use

Disassemble and modification
Warning
•Do not remove covers and panels which are fixed to the machine. Some machines
have a high-voltage component or a laser beam source inside that could cause electrical
shock or blindness
•Do not modify this machine, because this could cause a fire, electrical shock or
breakdown. If the machine contains a laser, the laser beam source could cause blindness.
Caution
•Do not place any liquids on the machine.
•To avoid any risk, only properly qualified and authorized service technicians are allowed
to modify the machine.
•Do not bridge any mechanical or electrical circuit breakers.
Power cord
Warning
•Do not scratch, wrap, heat, twist, bend, place a heavy object on or cause any other
damage to the power cord. The use of a damaged power cord (exposed core wire,
broken wire, for example) could result in a fire or breakdown. If you find any of these
conditions, immediately turn OFF the power switch and unplug the power cord from
the power outlet. Then call your authorized service representative.
•Only use the mains connector cable that was supplied with the machine.
Power source
Warning
•Put the power plug directly into a wall socket that has the same configuration as the
plug. The use of an adapter leads can result in an inadequate power supply. If a proper
wall outlet is not available, ask a qualified electrician to carry out the installation.
•Do not connect the machine to a mains voltage that differs from the value as stated
on the power marking label.
•Do not use a multiple outlet adapter or an extension lead. Contact your authorized
service representative if an extension lead is required.
Note
•If connection to a different mains voltage is required, contact your authorized service
representative.
Power plug
Warning
•For machines that are connected via a wall socket: Place the machine close to a wall
socket that is easily accessible. The power plug is intended to serve as a disconnect
device.
Chapter 1 - Instructions for safe use 7
Instructions for safe use

Grounding
Warning
•Connect the power cord to an electrical outlet (wall socket) that is equipped with a
grounding terminal.
•This equipment was not designed for connection to an IT power system. An IT power
system is a voltage network in which the neutral wire is not grounded.
Installation
Warning
•Make sure that the machine is placed on a level, horizontal surface of sufficient strength.
•Do not place this machine on an unstable or tilted bench.
•Do not place this machine in a location that is subject to lots of vibrations and shocks.
•Do not use flammable sprays, liquids or gases near this product, because this could
cause a fire.
Note
•It is recommended that you connect only copy-control products (or other products)
which meet the (inter)national product safety and radio frequency interference
standards. Only use an attachment cable as specified by the manufacturer.
Ventilation
Caution
•Do not block the machine's ventilation openings.
•Do not place the machine in rooms which are too small and insufficiently ventilated.
•Be sure to allow a clearance of 60 mm or more at the back of this machine for the
ventilation duct.
Actions in response to troubles
Warning
•When a piece of metal, water or any other similar foreign matter gets inside the
machine, immediately turn OFF the power switch and unplug the power cord from
the power outlet. Then call your authorized service representative.
•Immediately stop using the machine if the machine becomes excessively hot, emits
smoke, or produces unusual odors or noises. Immediately turn OFF the power switch
and unplug the power cord from the power outlet. Then call your authorized service
representative.
Caution
•Stop using the machine if the machine was dropped or a cover was damaged.
Immediately turn OFF the power switch and unplug the power cord from the power
outlet. Then call your authorized service representative.
Chapter 1 - Instructions for safe use8
Instructions for safe use

•LCD display. Do not rub, press or touch the display surface with hard material, because
the polarizer at the surface can be easily scratched. The LCD module consists of glass.
Therefore, the LCD module can damage when you drop, pinch strongly or punch
the module. If glass breaks, be careful that you do not get injured by the glass fragments.
Contact your authorized service representative.
Moving the machine
Caution
•Make sure that you disconnect the power cord and other cables before you move the
machine.
•Make sure that you check the documentation for the space requirements before you
move the machine.
Vacation
Caution
•Unplug the machine when you will not use the machine for a long period of time.
Chapter 1 - Instructions for safe use 9
Instructions for safe use

Chapter 1 - Instructions for safe use10
Instructions for safe use

Chapter 2
Regulation notices

Regulation notices
Introduction
This section describes the regulation notices.
Radio Interference suppression (all countries except USA)
Warning: This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate measures.
FCC approval (USA-only)
This system has been tested and found to comply with the limits for a class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the system is operated in a
commercial environment. This system generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required
to correct the interference at his own expense.
ICES-003 Interference-causing equipment (Canada- only)
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
Laser Safety (All Countries)
Laser safety
This is a digital machine which operates using a laser. There is no possibility of danger
from the laser provided the machine is operated according to the instructions in this
manual. Since the radiation emitted by the laser is completely confined within a protective
housing, the laser beam cannot escape from the machine during any phase of user
operation. This machine is certified as a Class 1 laser product: This means the machine
does not produce hazardous laser radiation.
CDRH regulations
This machine is certified as a Class 1 Laser product under Radiation Performance Standard
according to the Food, Drug and Cosmetic Act of 1990. Compliance is mandatory for
laser products marketed in the United States and is reported to the Centre for Devices
and Radiological Health (CDRH) of the U.S. Food and Drug Administration of the U.S.
Department of Health and Human Services (DHHS). This means that the device does
not produce hazardous laser radiation. The label shown on page xx indicates compliance
Chapter 2 - Regulation notices12
Regulation notices

with the CDRH regulations and must be attached to laser products marketed in the
United States.
Caution
Use of controls, adjustments, or performance of procedures other than those specified in
this manual may result in hazardous radiation exposure. This is a semiconductor laser.
The maximum power of the laser diode is 21 mW and the wavelength is 658 nm.
Mercury (All Countries)
At the end of the equipment's service life the mercury-containing fluorescent lamp must
be removed from the equipment and treated separately according Directive 2002/96/EC
(Waste Electrical and Electronic Equipment). Dispose of in accordance with all federal,
state, and local regulations. The European Waste Catalogue (EWC) number of the
mercury-containing fluorescent lamp is: 20 01 12.
Battery Labeling (EU Only)
This product contains a battery. Please do not remove the battery. If the battery needs
replacement, this should be done only by authorized service technicians who are aware
of the removal instructions.
This product contains (a) button cell(s). It (They) is (are) located in (a) printed circuit
board(s) that is (are) essential for the continuous error-free functioning of the product.
The button cell(s) should be removed only by authorized service technicians who are
aware of the removal instructions.
Button cell specification#
Contains the following
substances (if applicable)
Button cell
capacity
Button cell location
Lithium220 mAhMotherboard
Caution: Canon / Océ does not accept any liability for any damage or consequences, if
the batteries are removed by persons other than Canon / Océ authorized service
technicians.
Chapter 2 - Regulation notices 13
Regulation notices

End of Life; WEEE (EU-only)
The symbol "the crossed-out wheeled bin" indicates that at end-of-life of the equipment
separate collection is required in the EU Member States. The black bar specifies that the
appliance is put on the market after August 13, 2005. Reference: Directive 2002/96/EC.
Contact your local organization for further information.
RoHS (China- only)
The Environmental Protection Use Period (EPUP) applicable for the printing system
designated for deliveries to the Peoples Republic of China is 20 years. This EPUP, which
does not include consumables or expendables, does not affect any warranty that is provided
for the system and may not be construed or interpreted as a separate guarantee for the
printing system.
Energy consumption (All countries)
In order to limit energy consumption during times of non-use the PRISMAsync has a
Sleep mode during which the power level is reduced.
Power Modes and Delay Times
Energy consumption and efficiency are influenced both by the product technology and
by the settings chosen by the user, especially the delay times that are selected to enter
reduced power states. The following delay times have been pre-set.
Power Modes and Delay Times#
Default delay time (minutes)Operational mode
20 minutesLow power
40 minutesSleep
The modes above are automatically entered after the Default Delay Time has elapsed;
counting from the moment the last print has been produced. These settings are
recommended and for most users ensure both ease of use and low energy consumption.
The minimum and maximum values are between the brackets. The Delay Times can be
changed. Shorter delay times will lower the energy consumption even further, but may
cause longer recovery times. In some cases longer delay times may prove to be more
convenient, but it should be noted that this may cause an increase in energy consumption.
Therefore, from an energy preservation point-of-view, longer delay times are not
recommended.
Chapter 2 - Regulation notices14
Regulation notices

Automatic duplex
Using both sides of paper reduces paper costs, national energy consumption and the
amount of paper in the waste disposal process. Therefore, thePRISMAsync is default set
for automatic duplex copying and printing.
Chapter 2 - Regulation notices 15
Regulation notices

Chapter 2 - Regulation notices16
Regulation notices

Chapter 3
General information

Caution labels and notations
Introduction
You can find the power-marking label at the bottom side of the controller. If connection
to a different mains voltage is required, contact your authorized service representative.
Do not remove caution labels or caution notations. If a label or notation is soiled, please
clean the label or notation. If you cannot make label or notation legible, or if the label
or notation is damaged, please contact your service representative.
Operating environment
The environmental requirements for correct operation of the machine are as follows:
•Operating temperature (T): 10 °C (50 °F) to 40 °C (104 °F)
•Relative Humidity (RH): 20 % to 90 %
Chapter 3 - General information18
Caution labels and notations

+1

-
Beyond the Ordinary
o
Printing for
Professionals
Creating global leadership in printing
Canon and Océ have joined forces to create the global
leader in the printing industry. For our customers, this
combines Canon and Océ technology with the support
of the Océ direct sales and service organizations. Look
to the new Canon-Océ combination for:
•Enterprise printing in the office and corporate
printroom
•Large format printing of technical documentation,
signage, and display graphics
•Production printing for marketing service bureaus and
graphic arts
•Business Services for document process outsourcing
©2011 Océ. Illustrations and specifications do
not necessarily apply to products and services offered in each local
market. Technical specifications are subject to change without prior
notice. Trademarks mentioned in this document are the property of
their respective owners.
2011-07
CANON SINGAPORE PTE. LTD.
1 HarbourFront Avenue #04-01 Keppel Bay Tower, Singapore 098632
CANON HONGKONG CO., LTD
19/F., The Metropolis Tower, 10 Metropolis Drive, Hunghom, Kowloon, Hong Kong
CANON INC.
30-2, Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan
CANON U.S.A., INC.
One Canon Plaza, Lake Success, NY 11042, U.S.A.
CANON CANADA INC.
6390 Dixie Road Mississauga, Ontario L5T 1P7, Canada
CANON EUROPA N.V.
Bovenkerkerweg 59-61 1185 XB Amstelveen, The Netherlands
(See http://www.canon-europe.com/ for details on your regional dealer)
CANON LATIN AMERICA, INC.
703 Waterford Way Suite 400 Miami, Florida 33126 U.S.A.
CANON AUSTRALIA PTY. LTD
1 Thomas Holt Drive, North Ryde, Sydney, N.S.W. 2113, Australia
CANON CHINA CO., LTD
15F Jinbao Building No.89 Jinbao Street, Dongcheng District, Beijing 100005, China
