Canon Color imageclass mf8580cdw User manual

87654321

MF8500Series/MF8200Series

Service Manual Rev.0

Product Overview

Technical Overview

Periodical Services

Disassembly/Assembly

Adjustment

Trouble Shooting

Error codes

Service Mode

Appendex

Application

This manual has been issued by Canon Inc. for qualied persons to learn technical theory,

installation, maintenance, and repair of products. This manual covers all localities where the

products are sold. For this reason, there may be information in this manual that does not

apply to your locality.

Corrections

This manual may contain technical inaccuracies or typographical errors due to improvements

or changes in products. When changes occur in applicable products or in the contents of this

manual, Canon will release technical information as the need arises. In the event of major

changes in the contents of this manual over a long or short period, Canon will issue a new

edition of this manual.

The following paragraph does not apply to any countries where such provisions are

inconsistent with local law.

Trademarks

The product names and company names used in this manual are the registered trademarks

of the individual companies.

not be copied, reproduced or translated into another language, in whole or in part, without the

consent of Canon Inc.

Caution

Use of this manual should be strictly supervised to avoid disclosure of condential

information.

Explanation of Symbols

The following symbols are used throughout this Service Manual.

Symbols Explanation Symbols Explanation

Used to show permission. Remove the screw.

Used to show prohibition. Tighten the screw.

Check. Remove the claw.

Check visually. Insert the claw.

Check the noise. Use the bundled part.

Disconnect the connector. Push the part.

Connect the connector. Plug the power cable.

Remove the cable/wire

from the cable guide or wire

saddle.

Turn on the power.

Set the cable/wire to the

cable guide or wire saddle.

T-0-1

The following rules apply throughout this Service Manual:

1. Each chapter contains sections explaining the purpose of specic functions and the

relationship between electrical and mechanical systems with reference to the timing of

operation.

In the diagrams, represents the path of mechanical drive; where a signal name

accompanies the symbol, the arrow indicates the direction of the electric

signal.

The expression "turn on the power" means ipping on the power switch, closing the

front door, and closing the delivery unit door, which results in supplying the machine with

power.

2. In the digital circuits, '1' is used to indicate that the voltage level of a given signal is

"High", while '0' is used to indicate "Low". (The voltage value, however, differs from

circuit to circuit.) In addition, the asterisk (*) as in "DRMD*" indicates that the DRMD

signal goes on when '0'.

In practically all cases, the internal mechanisms of a microprocessor cannot be checked

in the eld. Therefore, the operations of the microprocessors used in the machines

are not discussed: they are explained in terms of from sensors to the input of the DC

controller PCB and from the output of the DC controller PCB to the loads.

The descriptions in this Service Manual are subject to change without notice for product

improvement or other purposes, and major changes will be communicated in the form of

Service Information bulletins.

All service persons are expected to have a good understanding of the contents of this Service

Manual and all relevant Service Information bulletins and be able to identify and isolate faults

in the machine.

0 Safety Precautions

CDRH Provisions -------------------------------------------------------------0-2

Notes When Handling a Lithium Battery --------------------------------0-2

Laser Safety --------------------------------------------------------------------0-2

About Laser Beams --------------------------------------------------------------- 0-2

Handling Laser Scanner Unit --------------------------------------------------- 0-2

Toner Safety --------------------------------------------------------------------0-3

About Toner ------------------------------------------------------------------------- 0-3

Handling Adhered Toner --------------------------------------------------------- 0-3

Notes on Assembly/Disassembly -----------------------------------------0-3

1 Product Overview

Product Lineups ---------------------------------------------------------------1-2

Main Unit ----------------------------------------------------------------------------- 1-2

Options ------------------------------------------------------------------------------- 1-3

Product Features --------------------------------------------------------------1-4

Features ------------------------------------------------------------------------------ 1-4

Specications ------------------------------------------------------------------1-5

Main Unit Specications ---------------------------------------------------------- 1-5

ADF Specications ---------------------------------------------------------------- 1-7

Wireless LAN Specications ---------------------------------------------------- 1-7

SEND Specications -------------------------------------------------------------- 1-8

FAX Specications ----------------------------------------------------------------- 1-8

Print Speed -------------------------------------------------------------------------- 1-9

Paper types / Paper size --------------------------------------------------------1-10

Name of Parts ---------------------------------------------------------------- 1-12

External View ----------------------------------------------------------------------1-12

Cross Section View ---------------------------------------------------------------1-15

Control Panel ----------------------------------------------------------------------1-17

Contents

2 Technical Overview

Basic Conguration -----------------------------------------------------------2-2

Conguration function ------------------------------------------------------------ 2-2

Basic Sequence -------------------------------------------------------------------- 2-2

Print Mode --------------------------------------------------------------------------- 2-5

Document Exposure/Feeder System ------------------------------------2-6

Document Exposure System ---------------------------------------------------- 2-6

Document Feeder System ------------------------------------------------------- 2-8

Service Tasks ----------------------------------------------------------------------- 2-9

Controller System ----------------------------------------------------------- 2-10

Overview ----------------------------------------------------------------------------2-10

Controls ----------------------------------------------------------------------------- 2-11

Service Tasks ----------------------------------------------------------------------2-14

Laser Control System ------------------------------------------------------ 2-15

Overview ----------------------------------------------------------------------------2-15

Controls -----------------------------------------------------------------------------2-15

Service Tasks ----------------------------------------------------------------------2-16

Image Formation System ------------------------------------------------- 2-17

Overview ----------------------------------------------------------------------------2-17

Parts ----------------------------------------------------------------------------------2-17

Image Forming Process ---------------------------------------------------------2-18

Controls -----------------------------------------------------------------------------2-23

Service Tasks ----------------------------------------------------------------------2-28

Fixing System ---------------------------------------------------------------- 2-29

Overview ----------------------------------------------------------------------------2-29

Controls -----------------------------------------------------------------------------2-29

Service Works ---------------------------------------------------------------------2-32

Pickup / Feed System ------------------------------------------------------ 2-33

Overview ----------------------------------------------------------------------------2-33

Parts Conguration ---------------------------------------------------------------2-34

Drive Conguration ---------------------------------------------------------------2-35

Controls -----------------------------------------------------------------------------2-36

Service Works ---------------------------------------------------------------------2-38

3 Periodical Services

Periodically Replaced Parts ------------------------------------------------3-2

Durable Parts ------------------------------------------------------------------3-2

Periodical Services -----------------------------------------------------------3-2

Cleaning -------------------------------------------------------------------------3-2

4 Disassembly/Assembly

List of Parts ---------------------------------------------------------------------4-2

List of External/ Internal Cover (MF8500 series)--------------------------- 4-2

List of Main Unit (MF8500 series) --------------------------------------------- 4-4

List of Motor/Fan (MF8500 series) -------------------------------------------- 4-6

List of Clutch / Solenoid/Heater/Thermistor/Switch/speaker

(MF8500 series) -------------------------------------------------------------------- 4-7

List of Sensor (MF8500 series) ------------------------------------------------- 4-8

PCB (MF8500 series) ------------------------------------------------------------- 4-9

Llist of Connector (MF8500 Series) ------------------------------------------4-10

External Cover, Internal Cover ------------------------------------------- 4-15

Location -----------------------------------------------------------------------------4-15

Removing the Left Cover -------------------------------------------------------4-17

Removing the Right Cover -----------------------------------------------------4-20

Removing the Right Front Cover ----------------------------------------------4-22

Removing the Front Cover -----------------------------------------------------4-23

Removing the Rear Upper Cover ---------------------------------------------4-24

Removing the Rear Cover ------------------------------------------------------4-24

Removing the Rear Lower Cover ---------------------------------------------4-25

Removing the Rear Cover Rib Unit ------------------------------------------4-27

Removing the Upper Cover ----------------------------------------------------4-28

Removing the Cartridge Tray --------------------------------------------------4-30

Document Exposure, Feed System ------------------------------------ 4-31

Location -----------------------------------------------------------------------------4-31

Removing the ADF Unit + Reader Unit --------------------------------------4-32

Separating the ADF Unit + Reader Unit -------------------------------------4-35

Removing the ADF Roller Unit -------------------------------------------------4-38

Removing the ADF Pickup Roller ---------------------------------------------4-40

Removing the ADF Separation Roller ---------------------------------------4-41

Removing the ADF Separation Pad ------------------------------------------4-42

Removing the ADF Pickup Feed Unit ----------------------------------------4-43

Removing the ADF Pickup Motor ---------------------------------------------4-46

Removing the Reader Unit Upper Cover -----------------------------------4-47

Removing the CIS Unit ----------------------------------------------------------4-49

Removing the Reader Scanner Motor ---------------------------------------4-52

Controller System ----------------------------------------------------------- 4-55

Location -----------------------------------------------------------------------------4-55

Removing the Controller Cover -----------------------------------------------4-57

Removing the Wireless LAN PCB (MF8580Cdw) ------------------------4-57

Removing the Main Controller PCB ------------------------------------------4-58

Removing the Main Controller Support Plate ------------------------------4-61

Removing the DC Controller PCB --------------------------------------------4-61

Removing the High Voltage Power Supply PCB --------------------------4-63

Removing the Low Voltage Unit -----------------------------------------------4-65

Removing the Fixing Sub PCB ------------------------------------------------4-67

Removing the Driver PCB ------------------------------------------------------4-68

Removing the Relay PCB -------------------------------------------------------4-69

Removing the Control Panel Unit ---------------------------------------------4-70

Removing the Control Panel LCD PCB

and Control Panel Key PCB ----------------------------------------------------4-73

Removing the FAX PCB (MF8580Cdw/8550Cdn) ------------------------4-75

Removing the Off Hook PCB (MF8580Cdw/8550Cdn) ------------------4-75

Removing the Main Drive Unit -------------------------------------------------4-76

Removing the Duplex Reverse Drive Unit ----------------------------------4-85

Removing the Fixing/Fixing Power Supply Cooling Fan Unit ----------4-86

Removing the Duplex Feeding Fan ------------------------------------------4-88

Removing the Speaker (MF8580Cdw/8550Cdn) -------------------------4-89

Laser Exposure System --------------------------------------------------- 4-90

Location -----------------------------------------------------------------------------4-90

Removing the Laser Scanner Unit --------------------------------------------4-90

Image Formation System ------------------------------------------------- 4-95

Location -----------------------------------------------------------------------------4-95

Removing the ITB Unit ----------------------------------------------------------4-95

Removing the Patch Density and Registration Sensor unit ------------4-98

Removing the Developing Motor -------------------------------------------- 4-100

Removing the Drum Motor --------------------------------------------------- 4-102

Fixing System -------------------------------------------------------------- 4-104

Location --------------------------------------------------------------------------- 4-104

Removing the Fixing Assembly ---------------------------------------------- 4-104

Removing the Fixing Film Unit ---------------------------------------------- 4-106

Removing the Fixing Pressure Roller -------------------------------------- 4-110

Removing the Fixing Motor Unit ----------------------------------------------4-111

Pickup Feeder System ----------------------------------------------------4-113

Removing the Cassette Pickup Roller ------------------------------------- 4-114

Removing the Cassette Separation Roller ------------------------------- 4-115

Removing the MP Tray Pickup Roller -------------------------------------- 4-117

Removing the MP Tray Separation Pad ----------------------------------- 4-117

Removing the Pickup Motor -------------------------------------------------- 4-118

Removing the Pickup Unit ---------------------------------------------------- 4-120

Removing the MP Tray Pickup Unit ---------------------------------------- 4-125

Removing the Secondary Transfer Feed Unit --------------------------- 4-127

Removing the Delivery Unit -------------------------------------------------- 4-128

Removing the Duplex Feed Unit -------------------------------------------- 4-130

Removing the Re-pickup Guide Unit --------------------------------------- 4-131

List of Parts ----------------------------------------------------------------- 4-132

List of External / Internal Cover(MF8200 series)------------------------ 4-132

List of Main Unit (MF8200 series) ------------------------------------------ 4-134

List of Motor/Fan (MF8200 series) ----------------------------------------- 4-135

List of Clutch / Solenoid/Heater/Thermistor/Switch/speaker

(MF8200 series) ----------------------------------------------------------------- 4-135

List of Sensor (MF8200 series) ---------------------------------------------- 4-136

PCB (MF8200 series) ---------------------------------------------------------- 4-137

List of connector (MF8200 Series) ----------------------------------------- 4-138

External Cover, Internal Cover ----------------------------------------- 4-142

Location --------------------------------------------------------------------------- 4-142

Removing the Left Cover ----------------------------------------------------- 4-144

Removing the Right Cover --------------------------------------------------- 4-147

Removing the Front Covent Cover ----------------------------------------- 4-150

Removing the Rear Upper Cover ------------------------------------------- 4-153

Removing the Rear Lower Cover ------------------------------------------- 4-154

Removing the Rear Cover ---------------------------------------------------- 4-155

Removing the Upper Cover -------------------------------------------------- 4-156

Document exposure/feeder system ---------------------------------- 4-157

Location --------------------------------------------------------------------------- 4-157

Removing the ADF Unit/Copyboard + Reader Unit -------------------- 4-158

Separating the ADF Unit/Copyboard + Reader Unit ------------------- 4-160

Removing the ADF Roller Unit

(MF8280Cw/8250Cn/8240Cw/8230Cn) ----------------------------------- 4-164

Removing the ADF Pickup Roller

(MF8280Cw/8250Cn/8240Cw/8230Cn) ----------------------------------- 4-166

Removing the ADF separation roller

(MF8280Cw/8250Cn/8240Cw/8230Cn) ----------------------------------- 4-166

Removing the ADF Separation Pad

(MF8280Cw/8250Cn/8240Cw/8230Cn) ----------------------------------- 4-167

Removing the ADF Pickup Feed Unit

(MF8280Cw/8250Cn/8240Cw/8230Cn) ----------------------------------- 4-169

Removing the ADF Pickup Motor

(MF8280Cw/8250Cn/8240Cw/8230Cn) ----------------------------------- 4-172

Removing the Reader Unit Upper Cover --------------------------------- 4-173

Removing the CIS Unit -------------------------------------------------------- 4-175

Removing the Reader Scanner Motor ------------------------------------- 4-178

Controller System --------------------------------------------------------- 4-180

Location --------------------------------------------------------------------------- 4-180

Removing the Controller Cover --------------------------------------------- 4-182

Removing the Wireless LAN PCB (MF8280Cw/8240Cw) ------------ 4-182

Removing the Main Controller PCB ---------------------------------------- 4-183

Removing the DC Controller PCB ------------------------------------------ 4-186

Removing the Driver PCB ---------------------------------------------------- 4-187

Removing the Low Voltage Power Supply Unit ------------------------- 4-190

Removing the High Voltage Power Supply PCB ------------------------ 4-193

Removing the Fixing Power Supply Unit ---------------------------------- 4-195

Removing the Control Panel Unit ------------------------------------------- 4-196

Removing the Control Panel LCD PCB

and Control Panel Key PCB -------------------------------------------------- 4-199

Removing the FAX PCB (MF8280Cw/8250Cn) ------------------------- 4-201

Removing the Off Hook PCB (MF8280Cw/8250Cn) ------------------- 4-201

Removing the Main Drive Unit ----------------------------------------------- 4-202

Removing the Sub Drive Unit ------------------------------------------------ 4-209

Removing the Main Motor ---------------------------------------------------- 4-210

Removing the Fan -------------------------------------------------------------- 4-211

Removing the Speaker (MF8280Cw/8250Cn)--------------------------- 4-212

Laser Exposure System ------------------------------------------------- 4-213

Location --------------------------------------------------------------------------- 4-213

Removing the Laser Scanner Unit ------------------------------------------ 4-213

Image Formation System ----------------------------------------------- 4-218

Location --------------------------------------------------------------------------- 4-218

Removing the ITB Unit -------------------------------------------------------- 4-218

Removing the Secondary Transfer Outer Roller ------------------------ 4-223

Fixing System -------------------------------------------------------------- 4-225

Location --------------------------------------------------------------------------- 4-225

Removing the Fixing Assembly ---------------------------------------------- 4-225

Replacing the Fixing Film Unit ----------------------------------------------- 4-228

Removing the Fixing Pressure Roller -------------------------------------- 4-231

Removing the Fixing Motor --------------------------------------------------- 4-232

Pickup Feeder System --------------------------------------------------- 4-233

Location --------------------------------------------------------------------------- 4-233

Removing the Cassette Pickup Roller ------------------------------------- 4-233

Removing the Cassette Separation Roller ------------------------------- 4-235

Removing the Multi-purpose Tray Unit ------------------------------------ 4-237

Removing the Pickup Unit ---------------------------------------------------- 4-242

5 Adjustment

Overview ------------------------------------------------------------------------5-2

Adjustment at Parts Replacement ----------------------------------------5-3

Document Exposure / Feed System ------------------------------------------ 5-3

Controller System ------------------------------------------------------------------ 5-6

Laser Exposure System ---------------------------------------------------------- 5-9

6 Trouble Shooting

Test Print ------------------------------------------------------------------------6-2

Engine test print -------------------------------------------------------------------- 6-2

Controller test print ---------------------------------------------------------------- 6-3

Trouble shooting items-------------------------------------------------------6-5

Recurring faulty image ------------------------------------------------------------ 6-5

Conrming nip width -------------------------------------------------------------- 6-5

Special Management Mode ------------------------------------------------6-6

Overview ----------------------------------------------------------------------------- 6-6

Supported models ----------------------------------------------------------------- 6-6

Operational Description ---------------------------------------------------------- 6-6

Menu List ----------------------------------------------------------------------------- 6-7

Version Upgrade ------------------------------------------------------------ 6-11

Overview ---------------------------------------------------------------------------- 6-11

UST ----------------------------------------------------------------------------------- 6-11

Preparation ------------------------------------------------------------------------- 6-11

Downloading System Software ------------------------------------------------6-12

Upgrading via Internet -----------------------------------------------------------6-13

7 Error codes

Overview ------------------------------------------------------------------------7-2

Outline -------------------------------------------------------------------------------- 7-2

Jam code ----------------------------------------------------------------------------- 7-2

Error Codes ---------------------------------------------------------------------7-3

Jam Code -----------------------------------------------------------------------7-8

MF8500 Series --------------------------------------------------------------------- 7-8

MF8200 Series --------------------------------------------------------------------- 7-9

8 Service Mode

Overview ------------------------------------------------------------------------8-2

Service Mode Menu --------------------------------------------------------------- 8-2

Backing up Service Mode -------------------------------------------------------- 8-2

Screen ow of Service Mode --------------------------------------------------- 8-3

Remote UI service mode --------------------------------------------------------- 8-4

Supported models ----------------------------------------------------------------- 8-4

COPIER -------------------------------------------------------------------------8-5

DISPLAY ----------------------------------------------------------------------------- 8-5

I/O -------------------------------------------------------------------------------------- 8-7

ADJUST ------------------------------------------------------------------------------ 8-7

FUNCTION -------------------------------------------------------------------------8-19

OPTION -----------------------------------------------------------------------------8-27

COUTER ----------------------------------------------------------------------------8-30

FEEDER ----------------------------------------------------------------------- 8-34

ADJUST -----------------------------------------------------------------------------8-34

FUNCTION -------------------------------------------------------------------------8-35

FAX ----------------------------------------------------------------------------- 8-36

List of SSSW -----------------------------------------------------------------------8-36

List of MENU -----------------------------------------------------------------------8-38

List of NUM -------------------------------------------------------------------------8-38

Setting of NCU Parameters ----------------------------------------------------8-39

TESTMODE ------------------------------------------------------------------ 8-43

PRINT --------------------------------------------------------------------------------8-43

FAX -----------------------------------------------------------------------------------8-44

Appendex

Service Tools --------------------------------------------------------------------- II

Special Tools --------------------------------------------------------------------------- II

Solvents and Oils --------------------------------------------------------------------- II

General Circuit Diagram -------------------------------------------------------III

General Circuit Diagram (MF8500) ---------------------------------------------- III

General Circuit Diagram (MF8200) ---------------------------------------------- VI

Backup Data --------------------------------------------------------------------VIII

■CDRH Provisions

■Notes When Handling

a Lithium Battery

■Laser Safety

■Toner Safety

■Notes on Assembly/

Disassembly

Safety Precautions

F-0-1

0-2

CDRH Provisions

Food and Drug CDRH (Center for Devices and Radiological Health) under FDA (Food and

Drug Administration) enforced provisions of the section for laser and laser products on August

2, 1976. These provisions are applicable to all laser products manufactured or assembled

after August 1, 1976 and allow only products certied their compliance with the provisions

to market in the US. Each product shall have afxed the applicable label as shown below to

follow the labeling requirements prescribed in CDRH provisions.

Note that the wording included in labels is different depending on laser product

classications.

Notes When Handling a Lithium Battery

CAUTION:

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

The following warnings are given to comply with Safety Principles (EN60950).

CAUTION:

Wenn mit dem falschen Typ ausgewechselt, besteht Explosionsgefahr.

Gebrauchte Batterien gemäß der Anleitung beseitigen.

Laser Safety

About Laser Beams

Laser radiation may be hazardous to human. The laser scanner unit mounted in this device is

sealed in the protective housing and the external cover to prevent laser beams from leaking

to the environment. As long as the device is operated under normal conditions, users are

safely arded from laser leaks.

Handling Laser Scanner Unit

Before providing service works for the laser scanner unit and its peripherals, ensure to turn

off the power of the device.

Any cover with potential dangers of laser beam reection has afxed the caution label at the

position shown in the gure below.

F-0-2

0-3

Toner Safety

About Toner

Toner is a nontoxic matter composed of plastic, iron and a trace of pigments.

Never throw toner in ames to avoid explosion.

Handling Adhered Toner

• Use dry tissue paper to wipe off toner adhered to skin or clothes and wash in water.

• Never use warm water for cleaning up toner to prevent toner particles from being gelated to

soak into bers permanently.

• Toner particles are reactive with vinyl polymers. Avoid contacting these materials.

Notes on Assembly/Disassembly

Follow the items below to assemble/disassemble the device.

1. Disconnect the power plug to avoid any potential dangers during assembling/disassembling

works.

2. If not specially instructed, reverse the order of disassembly to reinstall.

3. Ensure to use the right screw type (length, diameter, etc.) at the right position when

assembling.

4. To keep electric conduction, binding screws with washers are used to attach the grounding

wire and the varistor. Ensure to use the right screw type when assembling.

5. Unless it is specially needed, do not operate the device with some parts removed.

6. Never remove the paint-locked screws when disassembling.

CAUTION

DOUBLE POLE/NEUTRAL FUSING

F-0-3

1Product Overview

Product Overview

■Product Lineups

■Product Features

■Specications

■Name of Parts

1-2

Product Overview > Product Lineups > Main Unit

Product Lineups

Main Unit

Function MF8500 Series

MF8580Cdw MF8570Cdw MF8550Cdn MF8540Cdn MF8530Cdn

Appearance

Copy Yes Yes Yes Yes Yes

Print Yes Yes Yes Yes Yes

Fax Yes Yes Yes - -

USB Scan Yes Yes Yes Yes Yes

Network Scan Yes Yes Yes Yes Yes

Wireless LAN Yes Yes - - -

SEND Yes Yes Yes Yes Yes

Sequre Print Yes Yes Yes Yes Yes

Remote UI Yes Yes Yes Yes Yes

ADF (1-side) Yes Yes Yes Yes Yes

ADF (2-side) Yes Yes Yes Yes Yes

Automatic 2-sided Print Yes Yes Yes Yes Yes

F-1-1

T-1-1

Function MF8200 Series

MF8280Cw MF8250Cn MF8240Cw MF8230Cn MF8210Cn

Appearance

Copy Yes Yes Yes Yes Yes

Print Yes Yes Yes Yes Yes

Fax Yes Yes - - -

USB Scan Yes Yes Yes Yes Yes

Network Scan Yes Yes Yes Yes Yes

Wireless LAN Yes - Yes - -

SEND - - - - -

Sequre Print - - - - -

Remote UI Yes Yes Yes Yes Yes

ADF (1-side) Yes Yes Yes Yes -

ADF (2-side) - - - - -

Automatic 2-sided Print - - - - -

F-1-2

T-1-2

1-3

Product Overview > Product Lineups > Options > MF8200 Series

Options

■MF8500 Series

[1]

[2]

No. Name Description Remarks

1 Cassette Feeding Module-V1 A cassette unit with 250 sheet capacity

(for paper of 60-90g/m2)

2 TELEPHONE 6 KIT Long cord

Cool White

Telephone call is enabled by using the

handset.

AUS, EUR

HANDSET KIT 3 Long cord Cool

White

CLA, CSPL, CIPL,

CHK, TWN

F-1-3

T-1-3

■MF8200 Series

[1]

No. Name Description Remarks

1 TELEPHONE 6 KIT Long cord

Cool White

Telephone call is enabled by using the

handset.

AUS, EUR

HANDSET KIT 3 Long cord Cool

White

CLA, CSPL, CIPL,

CHK, TWN

F-1-4

T-1-4

1-4

Product Overview > Product Features > Features > MF8500Series / MF8200Series

Product Features

Features

■MF8500Series / MF8200Series

●Compact MFP

430 mm

428.5 mm

430 mm

375 mm

434 mm

478.5 mm

●Improved operability by new color UI

F-1-5

F-1-6

●Mobile print supported (Apple Air Print, Google Cloud Print)

●Addition of Scan to PC, Paper Save Copy by supporting Smart

Shortcut Key

●Wireless LAN supported (MF8570Cdw, MF8580Cdw, MF8240Cw,

MF8280Cw)

●Increased engine speed from 8/12 ppm (CL/BW) to 14/14 ppm (CL/

BW) (MF8200 series only)

1-5

Product Overview > Specications > Main Unit Specications

Specications

Main Unit Specications

Item Specication / function

MF8500 Series MF8200 Series

Copyboard Fixed

Device Installation Desktop

Light source LED (RGB)

Photoreceptor OPC drum (φ24)

Image scanning CIS (color)

Light exposure method Laser beam exposure

Charging method Roller charging

Developing method Contact development

Transfer method Primary transfer:

Sequential 4 colors transfer to Intermediate Transfer Belt

Secondary transfer:

4-color batch transfer onto the transfer material by the Transfer Roller

Separation method Curvature separation

Cassette paper feed Simple separation retard

Multi-purpose tray paper

feed

Pad separation method Separation roller method

Drum cleaning method Cleaning blade

Transfer cleaning method Cleaning brush and roller

Fixing method On-demand xing

Paper delivery method Face-down

Toner level sensor Mounted

Toner type Non-magnetic one-component toner

Toner supply method All-in-one cartridge (drum + toner)

Toner save mode N/A

Document types Sheet / book

Maximum document size Copyboard Glass: 216 mm x 297 mm

Feeder: 216 x 356 mm

Document size sensor N/A

Image size magnication AB series :25.0%, 50.0%, 70.7%, 81.6%, 86.5%, 100.0%, 115.4%,

122.4%, 141.4%, 200.0%, 400.0%

Inch series :25.0%, 50.0%, 64.7%, 78.5%, 100.0%, 129.4%, 200.0%,

400.0%

A series :25.0%, 50.0%, 70.7%, 100.0%, 141.4%, 200.0%, 400.0%

AB series / Inch series :25.0%, 50.0%, 70.7%, 81.6%, 86.5%, 100.0%,

115.4%, 122.4%, 141.4%, 200.0%, 400.0%

Zoom :25 to 400% (1% increment)

Warm-up Time *1 About 23 seconds or less About 23 seconds or less

Item Specication / function

MF8500 Series MF8200 Series

Print area Cassette For print jobs (Non-envelope)

• Leading edge: 5.0 ± 2.0 mm

• Left Side: 5.0 ± 1.5 mm

For print jobs (envelope)

• Leading edge: 10.0 ± 2.0 mm

• Left Side: 10.0 ± 1.5 mm

For copy jobs:

• Leading edge: 5.0 ± 2.0 mm

• Left Side: 5.0 ± 1.5 mm

FAX / Report

• Leading edge: 5.0 ± 2.0 mm

• Left Side: 5.0 ± 1.5 mm

For print jobs (Non-envelope)

• Leading edge: 5.0 ± 1.5 mm

• Left Side: 5.0+1.8 mm / -1.2 mm

For print jobs (envelope)

• Leading edge: 10.0 ± 1.5 mm

• Left Side: 10.0+1.8 mm / -1.2 mm

For copy jobs:

• Leading edge: 5.0 ± 1.5 mm

• Left Side: 5.0+1.8 mm / -1.2 mm

FAX / Report

• Leading edge: 5.0 ± 1.5 mm

• Left Side: 5.0+1.8 mm / -1.2 mm

Multi-

purpose

Tray

(Non-envelope)

For print jobs

• Leading edge: 5.0 ± 2.0 mm

• Left Side: 5.0 ± 1.5 mm

For copy jobs:

• Leading edge: 5.0 ± 2.0 mm

• Left Side: 5.0 ± 1.5 mm

FAX / Report

• Leading edge: 5.0 ± 2.0 mm

• Left Side: 5.0 ± 1.5 mm

(envelope)

For print jobs / For copy jobs:

• Leading edge: 10.0 ± 2.5 mm

• Left Side: 10.0 ± 2.5 mm

(Non-envelope)

For print jobs

• Leading edge: 5.0 ± 2.0 mm

• Left Side: 5.0 ± 1.5 mm

For copy jobs:

• Leading edge: 5.0 ± 2.0 mm

• Left Side: 5.0 ± 1.5 mm

FAX / Report

• Leading edge: 5.0 ± 2.0 mm

• Left Side: 5.0 ± 1.5 mm

(envelope)

For print jobs / For copy jobs:

• Leading edge: 10.0 ± 3.0 mm

• Left Side: 10.0 ± 2.5 mm

Reading resolution Color: 600 x 600 dpi, 300 x 600 dpi, 300 x 300 dpi

B&W: 600 x 600 dpi, 300 x 600 dpi

Reading Speed Fixed (A4/LTR):

N/A

Continuous reading, SEND:

Color: 10 images / minute (A4/LTR)

B&W: 20 images / minute (A4)

B&W: 21 images / minute (LTR)

Copy resolution 600 x 600 dpi

Print resolution 600 x 600 dpi

First copy time Fixed (A4/LTR):

Color: 16 seconds or less

B&W: 15.3 seconds or less

Fixed (A4/LTR):

Color / B&W: 19 seconds or less

Continuous reading: (A4/LTR)

Color: 16.5 seconds or less

B&W: 16.2 seconds or less

Continuous reading (A4/LTR)

Color / B&W: 19 seconds or less

First print time Color / B&W:

14.3 seconds or less (A4/LTR)

Color / B&W:

18.0 seconds or less (A4/LTR)

1-6

Product Overview > Specications > Main Unit Specications

Item Specication / function

MF8500 Series MF8200 Series

Print Speed 1-sided print (A4/LTR):

Color / B&W: 21 ppm (A4/LTR)

2-sided print (A4/LTR):

Color / B&W: 10 ppm (A4/LTR)

(For details, see “Print Speed”.)

Color / B&W:

14 ppm (A4/LTR)

(For details, see “Print Speed”.)

Available paper type for

cassette

Plain paper, Recycled paper, Color paper, Thick paper, Coated paper,

Transparency, Label, Postcard, Envelope

(For details, see “Paper types / Paper size”.)

Available paper type for

multi-purpose tray

Plain paper, Recycled paper, Color paper, Thick paper, Coated paper,

Transparency, Label, Postcard, Envelope

(For details, see “Paper types / Paper size”.)

Available paper size in

cassette

A4, B5, A5, LGL, LTR, STMT, EXEC, OFFICIO, B-OFFICIO, M-OFFICIO,

GLTR, GLGL, FLS, K16, Index card, Postcard, Reply Postcard,

Envelopes (COM10, Monarch, Nagagata 3, Yougatanaga 3, C5, DL),

Custom Paper Size

(For details, see “Paper types / Paper size”.)

Multi-purpose Tray / Multi-

purpose Tray Pickup Slot

paper size

A4, B5, A5, LGL, LTR, STMT, EXEC, OFFICIO, B-OFFICIO, M-OFFICIO,

GLTR, GLGL, FLS, K16, Index card, Postcard, Reply Postcard,

Envelopes (COM10, Monarch, Nagagata 3, Yougatanaga 3, C5, DL),

Custom Paper Size

(For details, see “Paper types / Paper size”.)

Cassette capacity Cassette:

250 sheets (60 to 90 g/m2)

Option:

250 sheets (60 to 90 g/m2)

Cassette:

150 sheets (60 to 90 g/m2)

Multi-purpose tray

capacity

50 sheets (60 to 90 g/m2) 1 sheet

Delivery tray stacking

capacity *2

125 sheets (60 to 90 g/m2)

Continuous copying 1 - 99 sheets

Automatic 2-sided Available (A4, B5, LGL, LTR,

EXEC)

N/A

Memory capacity 256MB 128MB

Sleep mode Available

Allowable environmental

temperature

10 - 30 deg C

Allowable humidity 20 - 80% in relative humidity (no condensation)

Operational noise At stand-by:

• 43 dB or lower (acoustic power

level)

During copy jobs:

• Color: 67 dB or lower

• B&W: 66 dB or lower

At stand-by:

• 43 dB or lower (acoustic power

level)

During copy jobs:

• Color: 65.2 dB or lower

• B&W: 63.9 dB or lower

Power rating Rated input voltage : 100-127 V (100V system) / 220-240 V (200V

system)

Rated input frequency: 50/60 Hz

Item Specication / function

MF8500 Series MF8200 Series

Maximum power

consumption

100 V: 1200 W or lower / 9.5 A

120 V: 1200 W or lower / 9.0 A

230 V: 1200 W or lower / 6.0 A

100 V: 1200 W or lower / 9.5 A

120 V: 1200 W or lower / 9.0 A

230 V: 1200 W or lower / 6.0 A

Average power at

operation

100 V: 550 W or lower / 7.0 A

120 V: 550 W or lower / 6.0 A

230 V: 550 W or lower / 3.0 A

100 V: 400 W or lower / 4.5 A

120 V: 400 W or lower / 4.5 A

230 V: 400 W or lower / 2.5 A

Average power at standby 100 V: 23 Wh

120 V: 23 Wh

230 V: 25 Wh

100 V: 23 Wh

120 V: 23 Wh

230 V: 23 Wh

Average power at sleep

mode

100 V:
