Canon LBP3310 User manual

ENG
IMPORTANT:
Read this manual carefully before using your printer.
Save this manual for future reference.
User's Guide
User's Guide

LBP3310
Laser Printer
User's Guide

Manuals for the Printer
The manuals for this printer are arranged as follows. Please use them as a reference as needed.
CD-ROM
Guides with this symbol are PDF manuals included in the accompanying CD-ROM.
•
Installation
•
Basic Operations
•
Troubleshooting
User's Guide
(This Manual)
CD-ROM
•
Setting Up the Network Environment for
Printing
•
Managing the Printer in the Network
Environment
Only if the optional network board is installed
Network Guide
CD-ROM
• Operating/Setting the Printer from the Web
Browser
Only if the optional network board is installed
Remote UI Guide
CD-ROM
To view the manual in PDF format, Adobe Reader/Adobe Acrobat Reader is required. If Adobe Reader/Adobe Acrobat Reader is not installed on your
system, please download it from the Adobe Systems Incorporated website.

How This Manual Is Organized
Before You Start
Installing the Printer
Paper Loading and Output Tray
Setting Up the Printing Environment
Basic Usage of the Printer
Using the Various Printing Functions
Routine Maintenance
Troubleshooting
Installing the Optional Accessories
Appendix
Chapter 1
Chapter 2
Chapter 3
Chapter 4
Chapter 5
Chapter 6
Chapter 7
Chapter 8
Chapter 9
Chapter 10
Considerable effort has been made to ensure that this manual is free of inaccuracies and omissions. However, as we are constantly improving our
products, if you need an exact specification, please contact Canon.
