Canon imageCLASS MF756Cx User manual

En
Vi
Th
Ms
Setup Guide
• After you finish reading this guide, store it in a safe
place for future reference.
• The information in this guide is subject to change
without notice.
https://oip.manual.canon/
1Important Safety Instructions
Be sure to read these instructions before using
the machine.
3User's Guide
This section explains all the ways this machine
can be used.
FAQ
This section describes problems that may arise
and how to resolve these problems.
2Setup Guide (this document)
See p. 8“Accessing the Online Manual”for details.
for Asia for Oceania

2
En
Vi
Th
Ms
Unless otherwise stated, illustrations used in this
document are for the MF756Cx
Checking the Items
Included
x 4
* May not be included with some models.
*
*
Removing the Packing
Material
1. Install the machine in the location where it
will be used.
The machine should be carried by at least two
people.
2. Remove all packing material.
Remove all of the tape.
Do not remove the sticker that covers the USB port
until you actually use the USB port.
Rear
1
2
1234567 12

En
Vi
Th
Ms
3
Loading Paper
1.
2.
A4/LGL
A4
3.
Ensure that the
amount of paper
loaded is not above
this line
4.
3Installing the Optional
Part
If you are not using optional part, proceed to
step .
Before Installing the Optional Part
After the machine has been installed, perform the
following before installing the optional part:
1. Turn OFF the machine and your computer.
2. Unplug the machine from the mains power outlet.
3. Disconnect all cords and cables from the machine.
Paper Feeder
1. Remove all packing material.
2. Install the paper feeder in the location
where it will be used.
4
1 2 3 4 5 6 7 12

En
Vi
Th
Ms
4
3.
4.
Handset
* The handset cannot be used with some models.
1.
Rear
2.
Insert the attached
pin halfway (Do not
insert it all the way in
here).
3.
Insert the pin all
the way in.
4.
5.
Connecting the Power Cord
2
1
Rear
5
45678 121

En
Vi
Th
Ms
5
Specifying the Basic
Settings
When you turn on the machine for the first time, the Setup
Guide appears on the operation panel. Perform the initial
machine setup by following the on-screen instructions.
Operation panel
1. Select the language, the country or region,
and then the time zone.
2. Set the current date/time.
Specifying the Security
Settings
To prevent unauthorized access to the machine, set access
restrictions for Remote UI.
What is Remote UI?
Remote UI allows you to use your computer’s Web
browser to check the machine’s operating status,
change settings, and save items to the Address
Book.
1. To use the Remote UI, select <Yes>.
• To continue without using the Remote UI, select
<No> and proceed to step 8.
• When <A Remote UI Access PIN must be
configured...> appears, proceed to step 5.
2. To use System Manager mode, select <Yes>.
• Set the System Manager ID and PIN so that you
can configure the settings for extended functions
and the management of access privileges, etc.
• To continue without using System Manager
mode, select <No> and proceed to step 5.
6
7
3. Set the System Manager ID.
Enter any number and then select <Apply>.
4. Set the System Manager PIN.
• Enter any number and then select <Apply>.
• Re-enter the same PIN on the next screen as
confirmation and select <Apply>.
5. To use General User mode, select <Yes>.
• Set the PIN to be used by general users to access
the Remote UI.
• To continue without using General User mode,
select <No> and proceed to step 8.
6. Set the Remote UI Access PIN.
• Enter any number and then select <Apply>.
• Re-enter the same PIN on the next screen as
confirmation and select <Apply>.
Using Color Correction
For better print results, the use of color correction is
recommended.
1. Choose whether to use color correction.
2. Check that the paper displayed on screen is
actually loaded and then select <OK>.
3. Select <Start> and correct the colors by
following the on-screen instructions.
Specifying the Network
Settings
Specify the settings for connecting the machine to a
network. Before proceeding, check that the computer and
router are correctly connected to the network.
• You cannot use a wired LAN and a wireless LAN at the
same time.
8
9
6 7 8 9 1110 121

En
Vi
Th
Ms
6
Wireless LAN
1. Check the router's "SSID" and "Network
key."
SSID : XXXXXXXXXXXX
Network key : XXXXXXXXXXXX
2. To configure the settings, select <Yes> on
the operation panel.
3. Select the network with a matching SSID.
4. Enter the password (network key) and select
<Apply>.
Wired LAN
Connect the router to the machine with a LAN cable and
then select <No> in the screen for choosing how to
connect to the network.
Rear
Ending the Setup Guide
Check the description in the Application Library and then
select <End>.
Installing the Software/
Drivers
To use the print, fax, and scan functions of the machine,
you must install the respective drivers.
10
11
On models with a fax function,
configure the fax settings next.
Downloading from the Canon website
1. Search for“(model name) download.”
Example: MF756Cx download
XXXXXXX download
If you cannot find the download site, go to
https://global.canon/en/support/
2. Download the software and drivers, and
install them on your computer.
To use the scan function, install the “MF Scan Utility”
scanning application and the scan driver.
Installing from the Bundled CD/DVD-
ROM
1. Load the CD/DVD-ROM into your computer,
and install the software and drivers.
For normal installation, select “Easy Installation.”
Selecting “Easy Installation” installs the drivers along
with the standard software and manuals.
If a problem arises during the installation, see “See
Troubleshooting (FAQ) for drivers” in “FAQ.”
Accessing the FAQ
p. 8 “Accessing the Online Manual”
6789 1110 121

En
Vi
Th
Ms
7
Fax Setup
The first time you select <Fax> in the Home screen, the Fax Setup Guide starts.
Setup Procedure
12 * These settings do not appear on models without a fax function.
1. Select <Fax> on the Home screen.
2. Select <Set Up Now>.
3. Select <Next>.
4. Enter the Unit Telephone Number and
select <Apply>.
5. Select <Next>.
6. Enter the Unit Name (name and company
name, etc.) and select <Apply>.
7. Select the receive mode that best suits your
telephone connection and the way you
receive calls.
Refer to the illustration below and select <Yes> or
<No>. Finally, select <Apply> to set the receive
mode.
8. Connect the machine to a telephone line.
LINE
HAND
SET
EXT.
Handset (optional part)
Telephone line jack
Telephone
Rear
9. When you have completed the connection,
select <End>.
10. Select <Yes>.
Selecting the Receive Mode
Do you want to
connect a telephone?
Do you want to use
an answering machine?
For fax use only. Receives faxes automatically.
Can be used for both fax and phone. Uses an
answering machine function to record phone
messages while you are away. Receives faxes
automatically.
Can be used for both fax and phone. Receives faxes
automatically.
Can be used for both fax and phone. Allows you to
check for incoming faxes and receive them manually.
Auto
Answering Machine
Fax/Tel (Auto Switch)
Manual
Do you want to receive
faxes automatically?
Yes
No
Start
6 7 8 9 1110 121

En
Vi
Th
Ms
8
Useful Functions and Helpful Information
Accessing the Online Manual
1. Scan the QR code to open the website to the
Canon online manual.
for Asia for Oceania
If the site does not open, go to
https://oip.manual.canon/
2. Select the manual.
User’s Guide
This section lists the functions of the machine,
including machine operations, settings, and
operating procedures.
FAQ
This section lists frequently asked questions and
their answers.
If a problem arises during driver installation,
see“See Troubleshooting (FAQ) for drivers.”
See Troubleshooting (FAQ) for
drivers
Using this Machine from a
Mobile Device (Linking with
Mobile Devices)
This machine can be used from mobile devices such as
smartphones. This makes it easy to print documents or
photos from a mobile device and to save data scanned
on this machine on a mobile device.
User’s Guide
See “Linking with Mobile Devices.”
Managing the Machine from
a Computer (Remote UI)
Remote UI allows this machine to be managed using the
Web browser on a computer. You can use it to check the
machine’s operating status, change settings, and save
items to the Address Book.
User’s Guide
See “Managing the Machine from a
Computer (Remote UI).”
