PIXMA iP5200 and iP5200R Bubble Jet Printers
Outstanding photos and documents at blistering speeds –
you can even print wirelessly with the iP5200R.
PIXMA – HOME PHOTOS HAVE NEVER BEEN THIS REAL
PIXMA is the direct result of Canon’s expertise in print-head technology, photography and copying. Canon’s new PIXMA range
features FINE print-head technology which places microscopic ink droplets on the page with unparalleled accuracy and
consistency. PIXMA delivers superior quality to your photographic and document printing with unsurpassed speed and reliability.
PRINTING
CD / DVD
6
iP5200R only

SUPERIOR QUALITY PHOTO PRINTS AT BLISTERING SPEEDS
 Ultra-sharp 1 picolitre FINE technology results
in enhanced shading and precise detail for
superb images.
 Produce high-definition photos and documents
at up to 9600 x 2400 dpi.
1
 The ContrastPlus 5 individual ink system gives
your photos greater contrast with a dynamic
three-dimensional feel.
 Enjoy borderless photo printing at home
– up to A4 size.
 Print a true-to-life, borderless 6" x 4" photo in
approximately 36 seconds.
2
 The USB 2.0 Hi-Speed interface ensures fast data transfer, so you won’t waste time waiting.
3
BE CREATIVE WITH EASY-TO-USE SOFTWARE
 Easy-PhotoPrint is a user-friendly application for printing out digital photos, retouching portraits
and lab quality trimming.
 Easy-WebPrint* eliminates waste and frustration by automatically adjusting the size of a web page
to ensure it fits on the sheet perfectly when you print.
5
 PhotoRecord* lets you create beautiful photo albums
with imaginative layouts and captions.
 CD-LabelPrint allows you to layout label designs and
print them directly onto printable CD and DVD media.
*Windows only
CONVENIENCE, VERSATILITY AND VALUE
 Reduce paper wastage with the convenient automatic duplex unit that allows
quick and easy double-sided printing. You can also use automatic duplex and
Canon’s PAK-101 (optional Photo Album Kit) to create your own double-sided
photo albums at home.
 The dual paper-path allows paper to be loaded from both the auto sheet-feeder
(ASF) and front cassette, perfect for switching between plain and photo paper
without having to re-load each time.
 Create your own label designs and print them directly onto printable CDs and DVDs.
 Prints directly from compatible digital
cameras using Bubble Jet Direct or PictBridge
technology, the industry standard for direct
printing – no computer required.
4
 Individual ink tanks save you money as each
colour is stored in a separate tank so you only
need to replace the one that runs out.
Automatic Duplex Printing
1 picolitre FINE technology eliminates graininess to produce razor-sharp images
Image simulation
4-colour model PIXMA iP5200 with photo black
for heightened contrast
Easy-PhotoPrint – Simple 3 step process
Image simulation
Prints directly on CD
and DVD media
Create your own CD
or DVD labels
5 Individual Ink Tanks

Want to know more? Visit canon.com.au
PRINT WIRELESSLY WITH THE iP5200R*
The iP5200R uses the latest in wireless technology to give you the freedom to print from virtually
anywhere around your home.
*Wireless Router is required for wireless network to operate.
TRUE-TO-LIFE PHOTOS THAT LAST A LIFETIME
A beautiful photograph is something worth keeping forever. Now with
ChromaLife 100, the photos you print at home will maintain all their vibrancy and
colour for 100 years.
6 The combination of genuine Canon ChromaLife 100 ink
and selected Canon photo papers lets you print long-lasting photos of unrivalled
quality. Thanks to ChromaLife 100, the precious memories in your albums will
still be bright and fresh a century from now.
Canon has a range of specialty photo papers
that’s suitable for virtually every photo size and
use. To ensure you gain all the long-lasting
benefits of ChromaLife 100, make sure you
choose Canon’s Photo Paper Pro, Photo Paper
Plus Glossy, Photo Paper Plus Semi-gloss or
Glossy Photo Paper.
PRINT FROM THE GARDEN
Supports the latest Wi-Fi
Protected Access (WPA2)
security technology for
secure wireless printing.
PRINT FROM ACROSS
THE HALLWAY
Simple USB connection
set-up takes as few as
3 steps to set up.
PRINT FROM UPSTAIRS
Enables wireless printing
within a 50 metre* radius,
even through walls.
* The actual communication range will vary,
depending on specific circumstances
PRINT FROM ANYWHERE
IN THE HOME
Print on demand automatically
queues print jobs, and you can
view print status from multiple
computers in the home.
Canon Photo Papers ChromaLife 100 Ink

Specifications in blue apply to iP5200R only
PRINTER FUNCTIONS
Paper Feeding Automatic feed
Printing Method Bubble Jet ink-on-demand with FINE
(Full-photolithography Inkjet Nozzle Engineering)
technology
Printing Speed2 Monochrome: approx. 30 ppm†
,
Colour graphics: approx. 24 ppm††
Photo Paper Plus Glossy (6" x 4" image on PP-101
in standard mode): approx. 36 secs††† borderless
Photo Paper Plus Glossy (6" x 4" image on PP-101
in standard mode): Wireless approx. 58 secs†††
borderless
Maximum Printing Resolution1 9600 x 2400 dpi
Borderless Printing A4, 5" x 7", 6" x 4", Credit Card size (54mm x 86mm)
Ink Tank PGI-5Bk – black ink tank,
CLI-8C/M/Y/Bk – individual colour ink tanks
Ink Yield* Borderless 6" x 4" photo:
CLI-8C – approx. 390, CLI-8M – approx. 250,
CLI-8Y – approx. 280, CLI-8Bk – approx. 1100
Paper Handling and Capacity 300 sheets (ASF + Paper cassette)
Approx. Paper Handling (ASF / Paper Cassette)
Plain Paper (13mm): 150 / 150
Super White Paper (SW-201): 100 / 100
High Resolution Paper (HR-101N): 80 / 80
Photo Paper Pro (PR-101): A4: 10, 6" x 4": 20 / A4: 10, 6" x 4": 20
Photo Paper Plus Glossy (PP-101): A4 / 5" x 7": 10, 6" x 4": 20 / A4 / 5" x 7": 10, 6" x 4": 20
Photo Paper Plus Semi-gloss (SG-101): A4: 10, 6" x 4": 20 / A4: 10, 6" x 4": 20
Glossy Photo Paper (GP-401): A4: 10, 6" x 4" / Credit card: 20 / A4: 10, 6" x 4": 20
Glossy Photo Paper-everyday use (GP-501): A4: 10, 6" x 4": 20 / A4: 10, 6" x 4": 20
Matte Photo Paper (MP-101): A4: 10, 6" x 4": 20 / A4: 10, 6" x 4": 20
Photo Paper Plus Double Sided (PP-101D): A4 / 5" x 7": 10 / A4 / 5" x 7": 10
Photo Stickers (PS-101): 1 / N/A
Envelopes (DL, Com#10): 10 / 5
Transparencies (CF-102): 30 / 30
T-Shirt Transfers (TR-301): 1 / 1
Supported Paper Sizes A4, A5, B5, Letter, Legal, Envelopes (DL, Com#10),
5" x 7", 6" x 4", Credit card (2.1" x 3.4")
Supported Paper Weights Plain Paper: 64-105g/m2, Canon specialty paper
(max paper weight): approx 273g/m2 (Photo Paper
Plus Double Sided)
Printable Area Bordered printing – Top Margin: 3mm,
Bottom Margin: 5mm, Left/Right margin: 3.4mm
Borderless photo printing – Top/Bottom/Right/Left
margin: 0mm
Bundled Software Windows: Easy-PhotoPrint, Easy-WebPrint5
,
PhotoRecord, CD-LabelPrint.
Macintosh: Easy-PhotoPrint, CD-LabelPrint
Interface PC: USB 2.0 Hi-Speed3
Camera Direct: Direct Print Port
(PictBridge / Bubble Jet Direct)4
Wireless LAN, Wired LAN (RJ-45)
Operating System USB: Windows XP/2000/Me/98,
Mac OS X v 10.2.1 or later
NETWORK SPECIFICATIONS
Protocol TCP/IP
Wired LAN Network Type: IEEE802.3u (100BASE-TX) /
IEEE802.3 (10BASE-T)
Transmission System: 10M/100Mbps
(auto switchable)
Wireless LAN Network Type: IEEE802.11g/IEEE802.11b
Frequency Band: 2.412GHz-2.462GHz
Channel: 1–11
Transmission System: OFDM/DS-SS system
Data Rate: 54/48/36/24/18/12/9/6 Mbps
(IEEE802.11g, auto switchable), 11/5.5/2/1Mbps
(IEEE802.11b, auto switchable)
Range: indoor 50m (depending on the transmission
speed and conditions)
Security: Encryption {WPA-PSK (TKIP/AES),
WPA2-PSK (TKIP/AES), WEP64/128bit},
IP address filtering, blocking by MAC address
registration, password
Standard: Wi-Fi, TELEC, FCC, IC, ETSI, iDA
GENERAL FEATURES
Weight Approx. 7.3kg, 7.5kg
Power Source AC 220-240V, 50/60Hz
Power Consumption Max (printing): 17W, 19W;
Standby: 0.8W, 3W
Acoustic Noise Level 34.7dB(A) in best quality mode
Operating Environment Temperature: 5–35ºC,
Humidity: 10–90% RH (no condensation)
Storage Environment Temperature: 0–40ºC,
Humidity: 5–95% RH (no condensation)
Dimensions (W x D x H) 444 x 309 x 160mm (minimum dimensions with paper
trays and other extensions closed)
Included in the Box
PIXMA iP5200 or iP5200R Bubble Jet printer, CD Tray, Setup Software & User’s Guide
CD-ROM, Printed Manual, 5 individual ink tanks (PGI-5Bk, CLI-8C, CLI-8M, CLI-8Y, CLI-8Bk),
Print-head, 12 months warranty card, Power cord, Sample Photo Paper
PIXMA iP5200 AND iP5200R SPECIFICATIONS
The 1 year warranty can be upgraded to 3 years for a minimal cost and
is backed by Canon’s Customer Care Info-Line support. Driver updates
and Technical Support are also available from our websites
– canon.com.au or canon.co.nz
canon.com.au
canon.co.nz
canon.com.au/digitalimage
Canon is a registered trademark of Canon Inc. and ‘advanced simplicity’ is a registered trademark of
Canon Australia Pty Limited. PIXMA and the PIXMA logo are trademarks of Canon Inc. Microsoft,
Windows and the Windows logo are registered trademarks of Microsoft Corporation in the United
States and in other countries. All other trademarks are the property of their respective owners.
Canon Australia Pty. Ltd.
Freecall: 1800 021 167
Facsimile No: + 61 2 9805 2632
Canon New Zealand Limited
Freecall: 0800 222 666
Facsimile No: + 64 9 489 0380
CAN0718
* Ink yield calculation is based on printing Canon 24 standard digital images on Photo Paper Plus
Glossy (6" x 4" borderless print) with default settings in Windows XP driver. The figure in the table
is an average value, measured when printing continuously using the ink immediately after it is
unsealed, until the ink is out. Ink yield may vary depending on photos printed, applications
software used, print mode and type of paper used. This should be used as a guide only and does
not take into account ink that might be used for head cleaning or head refreshing to maintain
printer performance. Please visit our website for further details.
1. Ink droplets can be placed with a pitch of 1/9600 inch at minimum.
2. Print speed dependent on system configuration, image/document complexity, type of paper used,
software, print mode and does not take into account data processing time on host computer.
3. USB 2.0 Hi-Speed performance requires Windows XP with Service Pack 1 or Windows 2000 with
Service Pack 4 with pre-installed USB 2.0 Hi-Speed port.
4. PictBridge camera direct and Bubble Jet Direct printing requires PictBridge or Bubble Jet Direct
compatible digital cameras in order to function. Check with your digital camera manufacturer
or users guide to determine PictBridge or Bubble Jet Direct compatibility.
5. Easy-WebPrint requires Microsoft® Internet Explorer version 5.5, version 6.0 recommended.
6. Up to 100 Years’ Life in a Photo Album when printed with ChromaLife 100 ink on selected Canon
photo papers. Kept in a photo album, shut out light and air (gas), temperature 23 degrees and 50%
humidity. Predicted value from the accelerated test. Result may vary based on individual environmental
factors. For more information, please visit canon.com.au/ChromaLife100
All specifications may change without notice.
