Canon iPF720 - imagePROGRAF Color Inkjet Printer User manual

iPF720
Print-Head
PF -03
Technology
FINE (Photolithography Inkjet Nozzle Engineering)
Print Resolution (Max.)
2400 x 1200 pi
Line Accuracy*
±0.1% or Less
Minimum Line Weight**
0.02mm
Number o Nozzles
Matte Black: 5,120 Nozzles
Other Colors: 2,560 Nozzles per Color
Droplet Size
4 Picoliter
Nozzle Pitch (Head Resolution)
1200 pi x Two Rows
Print Head Swath
1.07 inch
Ink Type
Dye
Cyan (C), Magenta (M), Yellow (Y), Black (K)
Pigment
Matte Black (MBK) – Two Channels
Ink Tank
PFI-102
Ink Tank Capacity***
130ml per Color
Number o Colors
5
Ink Supply Method
Tubing System
Nozzle Recovery System
Non-firing Nozzle Detection an Compensation
Printer Controller
L-COA Controller
Printer Memory
256MB
Built-in Hard Disk Capacity
80GB
Media Feed
Front-loa ing Manual Fee , Rear-loa ing Roll Fee
Media Width
Roll Feed
10" – 36" (254mm – 914.4mm)
Cut Sheet
8" – 36" (203.2mm – 914.4mm)
Printable Margins
Roll Feed
All Si es: 0.12" (3mm) or 0" for Bor erless
Minimum Printable Media Length
Roll Feed
8.0" (203mm)
Maximum Print Length†
Roll Feed
59' (18m)
Cut Sheet
5.2' (1.6m)
Borderless Printing Widths (Roll Media Only)
10", 14", 16", 24", 36",
B2 (20.28"/515mm), A1 (23.38"/594mm)
B1 (28.66"/728mm, AO (33.11"/841mm)
Media Cutter
Durable Rotary Bla e
Media Thickness
Roll Feed
0.07 – 0.8mm (2.8 – 31.4mil)
Cut Sheet
0.07 – 0.8mm (2.8 – 31.4mil)
Media Core Sizes
2" or 3" Core (2/3" Core A apter Inclu e )
Maximum Roll Outer Diameter
5.9" (150mm)
So tware
Printing So tware
imagePROGRAF Printer Driver, HDI Driver for
AutoCAD®/AutoCAD LT 2000–2008,†† Printer Driver
Extra Kit (Free Layout, imageRUNNER Linking Function)
Utilities
Me ia Configuration Tool
Applications
Digital Photo Front-Access,

imagePROGRAF
Device Setup Utility, PosterArtist Lite

Device Status
imagePROGRAF Status Monitor, Remote UI
Printer Language
GARO (Canon Proprietary), HP-GL/2, HP RTL
Operating Systems
Win ows®2000/XP/Server 2003/Win ows Vista®
(32-/64-bit), Macintosh®OS 10 (PowerPC or Intel®)
Inter ace
Standard (Built-in)
USB 2.0 Hi-Spee , 10/100Base-T/TX
Optional
IEEE1394 (FireWire)
Acoustic Noise
Operation
52 B (A) or Less
Standby
35 B (A) or Less
Acoustic Power
6.6 Bels or Less
Power Supply
AC 100–240V (50-60Hz)
Power Consumption
Maximum
140W or Less
Standby
5W or Less (10W or less
when IEEE1394 is mounte )
Power O
1W or Less (Executive Or er Compliant)
Certifications
Electrical Sa ety
UL®(USA), C-UL (Cana a), CE Mark (EN60950,
EN55022 classB, EN61000-3-2, EN61000-3-3, EN55024)
(Europe), TUV (GS) (Germany), AS (Australia),
PSB (Singapore), CCC (China), EK (Korea), S mark
(Argentina), Gost-R (locally obtaine ) (Russia),
CB Certification (other countries)
Electromagnetic
FCC Class B (USA), IC Class B (Cana a), CE Mark (EU),
VCCI class B, JEITA (Japan), C-tick (Australia), MIC
(Korea)
Environmental
ENERGY STAR®(WW), RoHS, IT ECO Declaration
(Europe), WEEE, Executive Or er (USA), China RoHS
TECHNICAL DOCUMENTS
LARGE-FORMAT PRINTING

Operational Environment
Temperature
59 – 86 F° (15 – 30 C°)
Relative Humidity
10 – 80% (No Con ensation)
Printer Dimensions (W x D x H)
59.3" x 34.3" x 43.1"
(1507mm x 871mm x 1094mm)
Weight (with Stand)
Approx. 141 lb.
(Approx. 64kg)
Package Dimensions (W x D x H) (with Pallet)
66.7" x 29.9" x 35.9"
(1695mm x 760mm x 912mm)
Package Weight (with Pallet)
Approx. 208 lb.
(Approx. 94kg)
Options
IEEE1394 Expansion Boar (EB-05)
Roll Hol er Set (RH4 - 32)
PosterArtist 2007
PhotoPRINT Select (A obe®PostScript®RIP)
User Replaceable Items
Print-Hea (PF-03)
Ink Tanks (PFI -102)
Maintenance Cartri ge (MC -07)
Cutter Bla e (CT-05)
What’s In The Box
Printer, User Software CD (Printer Driver, HDI Driver,
Utilities),PosterArtist Lite CD, User Manual CD,
6 Starter Ink Tanks (MBK x 2, Cyan, Magenta, Yellow,
Black), 2" Core Me ia Spool with 3" A apter, Print-Hea ,
Maintenance Cartri ge, Me ia Cutter, Built-in Ethernet/
USB 2.0 Interface, Quick Setup Gui e (Poster), Printer
Reference Gui e (Booklet), Power Cor , One-Year
Onsite Warranty, Registration Car , Stan , Basket,
Har ware (For Setting Up the Stan )
0308-iPF720-PDF-SP
* After user a justment an un er the same
environmental con itions. Applies to me ia for line
rawing only.
** Theoretical value base on ata resolution
*** The starter ink tanks initially package with the printer
are not the same capacity as the replacement ink
tanks specifie here.
†The maximum printable length varies epen ing on
the application, OS, an RIP use .
†† For AutoCAD or AutoCAD LT 2000/2000i/2002/
2004/2005/2006/2007/2008

Win ows 2000/XP/Win ows Vista 32-bit
 
For imagePROGRAF Printer Driver. For printing from
PostScript applications such as A obe Illustrator®or
QuarkXPress™, please use a PostScript compatible RIP
package. For a list of Canon recommen e RIP
packages, please consult with Canon Alliance an
In ustry Market program list of RIP ven ors.
