Canon LASER SHOT LBP-1210 User manual

Laser Beam Printer
User's Guide

LBP-1210 Laser Printer
User’s Guide
IMPORTANT:
Read this manual carefully.
Use this manual when you need quick reference help.

ii
Copyright
Copyright ©2002 Canon Inc.
All information in this manual is copyrighted. No part of this publication
may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language or computer language, in any form or by
any means, electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise, without prior written consent from Canon.
Notice
Canon makes no guarantees of any kind with regard to this manual.
Canon is not liable for errors contained herein or for consequential or
incidental damages incurred as a result of acting on information
contained in the manual. The information contained herein shall not be
reproduced in whole or in part without prior written consent from Canon.
Trademarks
LBP, Canon, LASER SHOT, and the Canon Logo are trademarks of
Canon Inc.
Microsoft
®
, Windows
®
, and Windows NT
®
are either registered
trademarks or trademarks of Microsoft Corporation in the United States
and/or in other countries.
Other brand and product names are trademarks or registered trademarks
of their respective companies.
In this manual, Microsoft
®
, Microsoft
®
Windows
®
, and Microsoft
®
Windows NT
®
are referred to as Microsoft, Windows, and Windows NT
respectively.

iii
About this Guide
The following lists the information included in this guide:
❏ Chapter 1
:
Introduction. Introduces you to the printer features and
describes the parts.
❏ Chapter 2: Paper Handling. Explains the types of paper and sizes
you can use, how to load paper, and describes how paper moves
through the printer.
❏ Chapter 3: Using the Canon Advanced Printing Technology.
Describes the Canon Advanced Printing Technology and how to install
and use the software, as well as how to check on the status of a print
job.
❏ Chapter 4: Troubleshooting. Contains helpful information on how to
solve printing problems.
❏ Chapter 5: Maintenance. Explains how to clean and handle the
printer, and how to replace the EP-25 cartridge.
❏ Appendix A. Lists the specifications for the printer.
❏ Appendix B. Describes how to connect the printer using the optional
network adapter.
❏ Glossary. Includes definitions for terminology used in this guide.
Conventions
This guide uses the following conventions:
CAUTION:
Indicates precautions that must be observed to prevent possible injury.
Indicates that neglecting the suggested procedure or practice could result
in damage to the printer.
Indicates notes and memos containing useful tips or detailed information.

iv
Safety Information
FCC Notice (110–127 V model)
Laser Beam Printer, Model L10721A
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
❏ Reorient or relocate the receiving antenna.
❏ Increase the separation between the equipment and receiver.
❏ Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
❏ Consult the dealer or an experienced radio/TV technician for help.
Use of shielded cable is required to comply with class B limits in Subpart
B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless
otherwise specified in the manual. If such changes or modifications
should be made, you could be required to stop operation of the
equipment.

v
FCC Notice (220–240 V model)
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference, in which case the user will be
required to correct the interference at his own expense.
•Use of shielded cable is required to comply with Class A limits in
Subpart B of Part 15 of FCC Rules.
Do not make any changes or modifications to the equipment unless
otherwise specified in this guide. If such changes or modifications should
be made, you could be required to stop operation of the equipment.
Notice for EMC Directive (220–240 V model)
“This equipment has been tested in a typical system to comply with the
technical requirements of EMC Directive.”
•Use of shielded cable is necessary to comply with the technical
requirements of EMC Directive.
International E
NERGY
S
TAR
Office Equipment Program
As an E
NERGY
S
TAR
partner, Canon Inc. has determined that this product
meets the E NERGY S TAR guidelines for energy efficiency.
The International E
NERGY
S
TAR
Office Equipment Program is an
international program that promotes energy saving through the use of
computers and other office equipment. The program backs the
development and dissemination of products with functions that
effectively reduce energy consumption. It is an open system in which
business proprietors can participate voluntarily. The targeted products are
office equipment such as computers, monitors, printers, fax machines,
and copiers. Their standards and logos are uniform among the
participating nations.

vi
Laser Safety (110–127 V / 220–240 V models)
Laser radiation could be hazardous to the human body. For this reason,
laser radiation emitted inside this printer is hermetically sealed within the
protective housing and external cover. In the normal operation of the
product by the user, no radiation can leak from the machine.
This printer is classified as a Class 1 laser product under EN60825-
1:1994, and in the USA, it is classified as Class 1 under the code of
Federal Regulations, §1040.10 of Title 21.
The label shown below is attached to this printer. This label is attached to
the laser scanner unit inside the printer. (110–127 V / 220–240 V models)
This printer has been classified under EN60825-1:1994 and conforms to
the following classes:
CLASS 1 LASER PRODUCT
LASER KLASSE 1
APPAREIL A RAYONNEMENT LASER DE CLASSE 1
APPARECCHIO LASER DI CLASSE 1
PRODUCTO LASER DE CLASE 1
APARELHO A LASER DE CLASSE 1
(220-240 V model only)
CAUTION:
Performance of procedures other than those specified in this manual may
result in hazardous radiation exposure.

vii
Important Safety Instructions
CAUTION:
This printer is a high-precision electronic device. Before operation, be
sure to read the following instructions to handle the printer properly.
❏ Read the manual carefully before operation.
❏ Do not dispose of these instructions. Save them for future reference.
❏ Follow all warnings and instructions on the printer and consumables.
❏ Do not place the printer on an unstable cart, stand, or table.
❏ When installing the printer, carefully observe the location
requirements described in this guide.
❏ The shaded part of the face-up delivery area may be hot. Be careful
not to touch it.
❏ Do not expose the printer to a wet environment.
❏ Do not expose the printer directly to a chemical environment
(experimental laboratories, etc.). The exterior of the printer is made of
plastic, and the outside covering might fade, become deformed, or
melt.
❏ Do not install the printer where it will be exposed to smoke or steam.
❏ Be sure to connect the printer to a grounded outlet.
❏ Do not operate the printer until all packing materials (packing tape,
spacers, and styrofoam molds) have been removed.

viii
❏ 110–127 V model only:
This product is equipped with a 3-wire grounding type plug, a plug
that has a third (grounding) pin. As a safety feature, this plug fits only
into a grounding-type power outlet. If you are unable to insert the plug
into the outlet, contact an electrician to replace your obsolete outlet.
Do not defeat the purpose of the grounding-type plug.
❏ 220–240 V model only:
A certified power supply cord is to be used with this equipment. For a
rated current up to 6 A, a type not lighter than H05VV-F 3G 0.75 mm
2
or H05VVH2-F 3G 0.75 mm
2
shall be used.
❏ Be sure to turn off the power before unplugging or plugging in the
printer power cord or interface cable.
❏ When moving the printer, be sure to turn off the power before
unplugging the power cord.
❏ Be sure to unravel the power cord prior to plugging it in; otherwise it
may lead to damage, overheating, short-circuit, or result in fire.
❏ Be sure to plug the power cord firmly into the power outlet, as any
flammable material caught between an opening might result in fire.
❏ Avoid using an extension cord. If you must use an extension cord, be
sure to take the following precautions. Failure to do this might lead to
overheating, result in fire, or cause flickering due to a drop in voltage.
•Be sure not to exceed the allowed rating current of the extension
cord.
•Use a short extension cord. Do not connect several extension cords
together.
•Make sure that the total ampere rating of the products plugged into
the extension cord does not exceed the extension cord ampere
rating.
❏ Slots and openings in the cabinet are provided for ventilation. To
ensure reliable operation of the printer and to protect it from
overheating, these openings must not be blocked or covered. The
openings should never be blocked by placing the printer on a bed,
sofa, shag rug, or other similar surface.

ix
❏ The printer should never be placed near or over a radiator, heat
register, or flame. It should not be placed in a built-in installation
unless proper ventilation is provided.
❏ Before connecting the printer to a power source, check the voltage
rating label at the back of the printer to ensure that the printer voltage
matches that of the power source. The voltage rating label is located
on the rear side of the printer. If the voltage label is missing, contact
your nearest authorized dealer or the place of purchase.
❏ The power cord should be routed so that it is not likely to be walked
on or pinched by items placed on or against it. Pay particular attention
to the plug, the power socket, and the point where the cord exits the
unit.
❏ Keep the power cord and cables away from children.
❏ Do not handle plugs with wet hands.
❏ When the printer will not be used for a long period, turn the power off
and unplug the power cord for safety.
❏ Unplug the printer from the wall outlet before cleaning. Do not spray
liquid cleaners or aerosol cleaners directly on the cabinet or the
openings, as the spray could penetrate inside the printer and
contaminate internal parts. Use a damp cloth for cleaning.
❏ Never push objects of any kind into the printer through openings in the
enclosure, as the objects might touch dangerous voltage points or
short out parts. This could result in a fire or electrical shock. Never
spill liquid of any kind into the printer.
❏ Unplug the printer and request servicing from qualified service
personnel in the following situations:
•When the power cord or plug is damaged or becomes frayed.
• If liquid is spilled into the printer.
• If the printer is exposed to water.
Ventilation slots
