This Parts Catalog contains listings of parts used in the LBP-3260 and hard
disk HD-72. Diagrams are provided with the listings to aid the service
technician in clearly identifying the item to be orderd.
Whenever ordering parts, consult this Parts Catalog for all of the
information pertaining to each item. Be sure to include in the Parts Request
the full item description, the item part number, and the quantity. The parts
catalog may be revised if there is significant product modification. For
minor product modifications, a Service Information Bulletin will be issued.
Canon Inc.
Peripheral Products Quality Planning Div.
Peripheral Products Technical Documentation Dept
5-1, Hakusan 7-chome, Toride-shi, Ibaraki 302-8501, Japan
COPYRIGHT C 1999 CANON INC.
Printed in Japan
Imprime´ au Japon
Use of this manual should be
strictly supervised to avoid dis-
closure of confidential infor-
mation.
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
ii

NAME REMARKS ORDER No. SERIAL No.
LIST OF ORDER AND SERIAL NUMBERS
LBP-3260 220-240V 50/60Hz 600DPI R76-1028 KLL00001-
HARD DISK HD-72 R03-0190
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
iii

A.
100.
101.
102.
103.
104.
141.
151.
152.
250.
300.
301.
310.
320.
330.
340.
341.
350.
351.
810.
900.
W10.
B.
ASSEMBLY LOCATION DIAGRAM
EXTERNAL COVERS, PANELS, ETC.
INTERNAL COMPONENTS 1
INTERNAL COMPONENTS 2
INTERNAL COMPONENTS 3
INTERNAL COMPONENTS 4
FACE-UP SOLENOID
HIGH VOLTAGE POWER SUPPLY ASS'Y
VIDEO CONTROLLER ASS'Y
PRINTER DRIVE ASS'Y
CASSETTE (LOWER)
CASSETTE (UPPER)
PAPER PICK-UP ASS'Y
REGISTRATION ROLLER ASS'Y
FEEDER ASS'Y
MULTI-PURPOSE TRAY PICK-UP ASS'Y
MULTI-PURPOSE TRAY ASS'Y
DELIVERY ASS'Y
DELIVERY FRAME ASS'Y
FIXING ASS'Y
PCB ASS'Y LOCATION DIAGRAM
- HARD DISK -
HARD DISK ASS'Y
NUMERICAL INDEX
CONTENTS
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
iv

Assembly Location Diagrams. These diagrams show
the locations of major assemblies of the machine. Their
names are identified in rectangular boxes. Below each box
is the number of the Figure which shows an exploded view
of the assembly.
Finding a Parts Number. Refer to the Assembly
Location Diagrams and find the Figure Number of the
assembly of interest. Turn to the page(s), locate the part on
the exploded view, and find its Key Number. Refer to the
Parts List on the page facing the exploded view and find
the Key Number, Part Number and quantity required for
your type of machine.
Note : While looking for a Part Number, pay particular
attention to the voltage listed in the SERIAL
NUMBER/REMARKS columm to ensure that the
Part Number selected is for your type of machine.
Immediate shipping or action regarding the part
depends on using its correct Part Number.
Parts List pages. The Parts List pages contain the
following columns and information.
(1) Figure and Key Number column. The first column
shows the Figure Number of the illustration corresponding
to the Parts List, and the Key Number that identifies the part
on the illustration.
(2) Part Number. The second column shows the Part
Number for the part. This Number must be used when
ordering replacement parts or assemblies described in the
description column do not have a Part Number and are not
stocked.
(3) Rank N. Parts marked"N"are service parts, but are
not stock items. They are produced on a special-order basis.
(4) Quantity column. The quantity shown in this
column is the number of parts used in the Figure. However,
the quantity listed for an assembly indicates the number of
that assembly per machine. The letters in this column
indicate that the quantity of a parts is not specified, allowing
the use of the number of parts needed for assembly and that
the quantity cannot be mentioned clearly.
(5) Description column. The Description column lists
the description that should be used when ordering the part.
(6) Serial Number/Remarks. When there are differ-
ences in the specifications of power suppply voltage,
frequency, etc., the differences are described in words or
indicated by one two or three letters in front of the serial
number.
(Example)
Serial number ABC00001
This is the descriptive
indicator.
If a model modified and a part is no longer interchangeable,
the serial number of machines for which the part can be
used is shown in this column. If there is no indication the
part can be used with all models.
Numerical Index. There is a Numerical Index at the
end of this catalog; it lists in numerical order every Part
Number contained in the Parts Lists. The Numerical Index
contains the following columns and information.
(1) Part Number. The first column shows the Part
Number.
(2) Figure and Key Number column. The second
column lists the Figure and Key Number for each
occurrence of the part in the illustrations.
Note : The last three digits (suffix) of the Parts Number
are called the Revision Number. The Revision
Number is changed if the part is modified.
Information regarding such changes will be pro-
vided by Service Information Bulletins. These
Bulletins should be read carefully.
HOW TO USE PARTS LISTS
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
v

FIGURE A
ASSEMBLY LOCATION DIAGRAM (1/2)
350
DELIVERY ASS'Y
810
FIXING ASS'Y
330
PAPER FEED ASS'Y
320
REGISTRATION ROLLER ASS'Y
340
MULTI-PURPOSE PICK-UP ASS'Y
310
PAPER PICK-UP ASS'Y
341
MULTI-PURPOSE TRAY ASS'Y
A-1
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]

A-2
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
FIGURE A
ASSEMBLY LOCATION DIAGRAM (2/2)
351
DELIVERY FRAME ASS'Y
141
FACE-UP SOLENOID ASS'Y
301
CASSETTE (UPPER)
300
CASSETTE (LOWER)
250
PRINTER DRIVE ASS'Y
151
HIGH VOLTAGE POWER SUPPLY ASS'Y
152
VIDEO CONTROLLER ASS'Y

FIGURE 100
EXTERNAL COVERS, PANELS, ETC.
SEE FIGURE 351
5
5K 5G
5H 5J 5K
5E
5B
5D
5A
5C
5F
18
8
7
11
19
4E
4A
4C
10
16
16
6B 6
6A
15
15A
19
16
14
3
1
17
4
4B
9
13
16
2
2
12
4H
4D
4G
4F
100-1
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]

100-2
SERIAL NUMBER / REMARKSDESCRIPTION
T
Y
Q'
R
A
N
K
PART NUMBER
FIGURE
&
KEY NO.
100 - NPN RF EXTERNAL COVERS, PANELS, ETC.
1 RB2-4211-000 1 COVER, DELIVERY
2 RF5-2701-000 2 HINGE, STOPPER
3 XA9-0605-000 4 SCREW, M4X8
4 RG5-4776-000 1 UPPER COVER ASS'Y
4A RB1-7080-000 1 PLATE, HINGE
4B RB1-6936-000 1 PLATE, GROUNDING
4C RB1-6938-000 1 COVER, CARTRIDGE
4D RB2-3643-000 1 PLATE, DUCT
4E XA9-0870-000 1 SCREW, M4X10
4F RB1-6983-000 1 STOPPER, DELIVERY
4G RB2-4208-000 1 TRAY, DELIVERY
4H RB2-4209-000 1 TRAY, DELIVERY, SUB
5 RG5-2413-000 1 RIGHT COVER ASS'Y
5A RB1-6973-000 1 COVER, RIGHT, LOWER
5B RB1-6974-000 1 COVER, OPEN/CLOSE, RIGHT
5C RB1-6975-000 1 GUIDE, COVER
5D RB1-6484-000 1 STOPPER, OPEN/CLOSE
5E RB1-6976-000 1 LEVER, COVER
5F RB1-6486-000 1 SPRING, COMPRESSION
5G RB1-6487-000 1 PLATE, GUIDE
5H RB1-6488-000 2 ROLLER, PAPER
5J RS5-2494-000 1 SPRING, TENSION
5K XA9-0605-000 4 SCREW, M4X8
6 RG5-4322-000 1 FRONT COVER ASS'Y
6A RB2-4207-000 1 COVER, FRONT, SUB
6B XZ9-0379-000 1 LATCH
7 RB1-6972-000 1 COVER, LEFT
8 RB1-6977-000 1 COVER, ELECTRICAL
9 RB1-6978-000 1 TRAY, FACE-DOWN
10 XA9-0686-000 6 SCREW, M3X6
11 RB1-6491-000 1 TRAY, FACE-UP
12 RB1-6980-000 1 COVER, SWITCH
13 RB1-6493-000 1 SPRING, COMPRESSION
14 RB2-3642-000 1 COVER, REAR, RIGHT
15 RF5-1749-000 1 COVER, REAR
15A RB1-6520-000 1 SHEET
16 XA9-0947-000 12 SCREW, TP, M3X6
17 RG5-4389-000 1 DISPLAY PANEL ASS'Y
18 RB2-3636-000 1 LOCK, FACE-DOWN TRAY
19 XA9-0962-000 2 SCREW, RS, M3X10
COPYRIGHT

1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]

FIGURE 101
INTERNAL COMPONENTS 1
1A 1B
1
2
4
4
5
17
17
6
7
7
8
9
10 501
17 18
17
11
13
14
15
11
16
11
18
17
12
1A
22
12
SEE FIGURE 330
SEE FIGURE 320
SEE FIGURE 340
SEE FIGURE 250
SEE FIGURE 141
SEE FIGURE 810
SEE FIGURE 350
SEE FIGURE 310
3
(MT1)
(J12)
(J218)
19
20
21
SEE FIGURE 341
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
101-1

COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
SERIAL NUMBER / REMARKSDESCRIPTION
T
Y
Q'
R
A
N
K
PART NUMBER
FIGURE
&
KEY NO.
101 - NPN RF INTERNAL COMPONENTS 1
1 RG9-4304-000 1 TRANSFER ROLLER GUIDE ASS'Y
1A RB1-6441-000 2 BUSHING
1B RF5-2676-000 1 HOLDER, TRANSFER
2 RS5-8597-000 1 LABEL, JAM REMOVAL
3 RB1-6749-000 1 COVER, MP TRAY PICK-UP
4 RB1-6456-000 2 RAIL, FIXING
5 RB1-6461-000 1 HOLDER, DAMPER, FRONT
6 RB1-6462-000 1 HOLDER, DAMPER, REAR
7 RB1-6466-000 2 GUIDE, OPTION
8 RB2-3631-000 1 COVER, CLUTCH
9 RB1-6982-000 1 COVER, FRONT
10 RH7-5219-000 1 MOTOR, MAIN MT1, J12
11 XA9-0947-000 9 SCREW, TP, M3X6
12 XA9-0872-000 7 SCREW, W/WASHER, M3X8
13 RB1-6403-000 1 STOPPER, PAWL
14 RS5-0708-000 1 GEAR, 21T
15 RG5-4386-000 1 MOTOR CABLE J12, J218
16 XA9-0962-000 1 SCREW, RS, M3X10
17 XA9-0605-000 5 SCREW, M4X8
18 XA9-0686-000 5 SCREW, M3X6
19 WT2-0408-000 1 CLAMP
20 RB1-6708-000 1 PLATE, STOPPER, LEFT
21 RB1-6709-000 1 PLATE, STOPPER, RIGHT
22 RF9-1394-000 1 ROLLER, TRANSFER
501 XB6-7400-807 4 SCREW, TP, M4X8
101-2

COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
102-1
FIGURE 102
INTERNAL COMPONENTS 2
13
28
16
14
24
12
11
29
18
2
38
35B
36B
35A
36A
35
36
4
17
4
326 23 20
39
38
4
4
5
38
32
39
31
30
133
33
37
SEE FIGURE 900
SEE
FIGURE
900
(J1601B)
(J1601A)
(J215)
5
27
25 22 34
6
7
9
10
821A
21
15
19
A
A

COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
102-2
SERIAL NUMBER / REMARKSDESCRIPTION
T
Y
Q'
R
A
N
K
PART NUMBER
FIGURE
&
KEY NO.
102 - NPN RF INTERNAL COMPONENTS 2
1 RB1-6419-000 2 BLOCK, RETAINER
2 RB1-6430-000 2 CLIP, SLIDE
3 RB1-6421-000 4 FOOT
4 XA9-0686-000 10 SCREW, M3X6
5 WT2-0482-000 2 CLIP, WIRE
6 RB1-6432-000 1 COVER, EDGE, UPPER
7 RB1-6433-000 1 COVER, EDGE, LOWER
8 RB2-3622-000 1 GUIDE, FRONT
9 RB1-6444-000 1 ARM, PRESSURE, FRONT
10 RS5-2468-000 1 SPRING, TENSION
11 RB1-6434-000 1 SPRING, LEAF
12 RB1-6446-000 1 ARM, PRESSURE, REAR
13 RB1-6447-000 1 ARM, RELEASE, UPPER
14 RB1-6448-000 1 ARM, RELEASE, LOWER
15 RB1-6449-000 1 PLATE, DRUM
16 RB1-6523-020 1 SPRING, LEAF
17 XA9-0642-000 1 SCREW, RS, M3X6
18 RS6-8124-000 1 LABEL
19 RB1-6971-030 1 COVER, RIGHT, UPPER
20 RB2-3510-000 2 STOPPER, RAIL
21 RF5-2726-000 1 GUIDE, REAR
21A RS6-8125-000 1 LABEL, "CAUTION"
22 XA9-0686-000 4 SCREW, M3X6
23 RS5-2500-000 2 SPRING, TENSION
24 RS5-2468-000 1 SPRING, TENSION
25 RS5-2499-000 2 SPRING, TENSION
26 RB2-3615-000 2 ROD, RAIL
27 RB2-3614-000 2 RAIL, TRAY
28 RB1-9617-000 1 BRUSH, CLEANING
29 RB1-6455-000 1 COVER, FIXING, LOWER
30 RB2-3567-000 1 COVER, CABLE, LVT
31 RB1-6474-000 1 COVER, SIZE
32 RB1-6512-000 1 SPRING, LEAF
33 RB1-6909-000 2 SPRING, LEAF
34 RB2-3613-000 2 GUIDE, RAIL
35 RF5-1395-000 1 RAIL, CASSETTE, UPPER
35A RB1-6429-000 1 GUARD, EDGE
35B RS5-8593-000 1 LABEL, CASSETTE
36 RF5-1396-000 1 RAIL, CASSETTE, LOWER
36A RB1-6429-000 1 GUARD, EDGE
36B RS5-8593-000 1 LABEL, CASSETTE
37 RG5-1920-000 1 CASSETTE SIZE CABLE J215, J1601A, J1601B
38 XA9-0605-000 6 SCREW, M4X8
39 XA9-0947-000 2 SCREW, TP, M3X6

FIGURE 103
INTERNAL COMPONENTS 3
11 26 25 14
5
5
15
31
21
24
29
4
1
5
9
23 23
28
12
18
27
19
16
501
13
30
10
20
22
6
23
87
17
23
A
B
B
C
C
E
E
D
F
A
(J18)
(J16)
(J25)
(J205)
(J1401)
(J206)
(J207)
(J225)
(J221)
(J208)
(FAM1)
(J202)
(J3)
(J203)
(J1001)
(PS1401)
(PS1402)
(PS1403)
(J1402) (SW2)
(J1401)
SEE FIGURE 151
SEE FIGURE 900
SEE FIGURE 900
D
31
F
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
103-1

COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
103-2
SERIAL NUMBER / REMARKSDESCRIPTION
T
Y
Q'
R
A
N
K
PART NUMBER
FIGURE
&
KEY NO.
103 - NPN RF INTERNAL COMPONENTS 3
1 RB1-6425-000 2 SPRING, LEAF
2 RB1-6426-000 1 PLATE, FIXING
3 RB1-6427-000 2 STOPPER, CARTRIDGE
4 RB2-3646-000 1 SHEET, INSULATION
5 XA9-0605-000 6 SCREW, M4X8
6 RG5-4344-000 1 LASER/SCANNER ASS'Y
7 RB2-3645-000 1 DUCT, SCANNER
8 RB1-6457-000 1 COVER, COUPLER
9 RB1-6458-000 1 SHUTTER
10 RB1-6459-000 1 SPRING, LEAF
11 RB1-6460-000 1 PLATE, HOLDER
12 RB1-6465-000 1 PLATE, DUCT, FRONT
13 RB1-6467-000 1 MOUNT, FAN
14 RB1-6472-000 1 ARM, LOCK, INTER
15 RB1-6473-000 1 SHUTTER
16 RH7-1396-000 1 FAN FAM1, J208
17 RS5-2467-000 1 SPRING, TENSION
18 RG5-4775-000 1 LASER CABLE J3, J202, J203, J1001
19 RG5-4378-000 1 SCANNER MOTOR CABLE J16, J18, J25, J205, J207
J221, J225, J1401
20 RB2-3508-000 1 PLATE, SHIELD
21 RB1-6471-020 1 MOUNT, CONTROL
22 RB2-3637-000 1 COVER, CABLE
23 XA9-0686-000 6 SCREW, M3X6
24 RB1-6503-000 1 SUPPORT, PCB
25 RS5-2469-000 1 SPRING, TENSION
26 RS5-2470-000 1 SPRING, COMPRESSION
27 XA9-0817-000 4 SCREW,W/WASHER,M3X20
28 WT2-0369-000 3 CLAMP, CABLE
29 RB1-6469-020 1 COVER, CABLE, DC
30 RB2-3644-000 1 GUIDE, CABLE
31 XA9-0947-000 5 SCREW, TP, M3X6
501 XB6-7300-007 2 SCREW, TP, M3X30

FIGURE 104
INTERNAL COMPONENTS 4
SEE FIGURE 152
SEE FIGURE 900 68
18
18 7
17
12
12A
11
10
19
1
3
5
14
13B
13
16
4
18 15 501
13A
4A
2
19
9
(J210)
(J12)
(J13)
(J50)
(J222)
(J213)
(J10)
(J19)
(J15)
(J17) (J16)
(J209)
(J204)
(J217)
(J102)
(J216)
(FAM2)
(J10)
(SW1)
(J14)
(FAM3)
20
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
104-1

COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
SERIAL NUMBER / REMARKSDESCRIPTION
T
Y
Q'
R
A
N
K
PART NUMBER
FIGURE
&
KEY NO.
104 - NPN RF INTERNAL COMPONENTS 4
1 RB2-3499-000 1 COVER, CABLE
2 RG5-4381-000 1 CABLE, FIXING, 1 J10, J50, J222
3 RG5-1850-000 1 FIXING CABLE 2 J19, J213
4 RG5-4301-000 1 POWER SUPPLY ASS'Y SW1, J10, J102, J204, J217
4A VD7-0643-151 1 FUSE, AC250V, 3.15A
5 RS5-2465-000 1 SPRING, TENSION
6 RB1-6930-000 1 GUIDE, TRAY
7 RB1-6775-000 1 GUIDE, SLIDE
8 RF5-2678-000 1 COVER, SHIELD
9 RB1-6760-000 1 DUCT A
10 RB1-6761-000 1 DUCT B
11 RH7-1271-000 1 FAN FAM3, J13
12 RG5-1921-000 1 CABLE, FAN J12, J210
12A VS1-0842-003 1 CONNECTOR, 3P J13
13 RG5-1928-000 1 REGISTRATION CABLE J14, J16, J209
13A VS1-5057-002 1 CONNECTOR, 2P J16, J17
13B VS1-5057-003 1 CONNECTOR, 3P J14, J15
14 RB1-6970-000 1 ROD, SWITCH
15 RH7-1266-000 1 FAN FAM2, J216
16 RB1-6772-000 1 PLATE, SHIELD
17 RF5-1464-020 1 PLATE, SHIELD
18 XA9-0686-000 19 SCREW, M3X6
19 XA9-0947-000 3 SCREW, TP, M3X6
20 FH2-5761-000 1 CORD, POWER
501 XB6-7300-007 2 SCREW, TP, M3X30
104-2

FIGURE 141
FACE-UP SOLENOID ASS'Y
SERIAL NUMBER / REMARKSDESCRIPTION
T
Y
Q'
R
A
N
K
PART NUMBER
FIGURE
&
KEY NO. RG5-1875-000 1 FACE-UP SOLENOID ASS'Y
1 RB1-6698-000 1 HOLDER, SOLENOID
2 RB1-6699-000 1 LEVER, SOLENOID
3 RB1-6700-000 1 ARM, LOCK, INTER
4 RB1-6702-000 1 CUSHION, LEVER, 9.5X11
5 RH7-5123-000 1 SOLENOID SL3, J1402
6 RS5-2492-000 1 SPRING, TENSION
7 RS5-2493-000 2 SPRING, TENSION
501 XB6-7300-409 2 SCREW, TP, M3X4
502 XD3-1300-082 1 PIN, SPRING
141 -
5
502
1
2
4
6
501
7
7
3
(J1402)
(SL3)
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
141-1

FIGURE 151
HIGH VOLTAGE POWER SUPPLY ASS'Y
SERIAL NUMBER / REMARKSDESCRIPTION
T
Y
Q'
R
A
N
K
PART NUMBER
FIGURE
&
KEY NO. RG5-4306-000 1 HIGH VOLTAGE POWER SUPPLY ASS'Y
1 RB1-6753-000 1 SPRING, COMPRESSION
2 RB1-6756-020 1 COVER, HVT
3 RB1-6757-000 3 PIN, CONTACT
4 RB1-6758-000 1 CASE, HIGH VOLTAGE
5 RB1-6759-000 5 SPRING, COMPRESSION
6 RG5-4376-000 1 HIGH VOLTAGE PCB ASS'Y
7 XA9-0605-000 1 SCREW, M4X8
151 -
2
53
35
1
6
7
4
151-1
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]

FIGURE 152
VIDEO CONTROLLER ASS'Y
10
13
12
10
501
14
7
11
3
3
8
1
6
9
4
5
2
2A
SEE FIGURE 900
COPYRIGHT  1999 CANON INC. CANON LBP-3260 REV.0 JAN. 1999 PRINTED IN JAPAN [IMPRIME AU JAPON]
152-1
