Canon imagePROGRAF W7200 Installation and maintenance instructions

Copyright ©2002 Canon Inc. all rights reserved.
• Unauthorized transfer or duplication of all or any part of this document is prohibited.
• The content of this document is subject to change without notice.
• Every effort has been made to ensure that the information contained in this guide is
correct. If any error or omission is found, contact us directly or an authorized Canon
representative.
• Canon is not responsible for any damages, direct or indirect, arising from or related to
the use of this printer.
Trademarks
• Canon, the Canon logo and Page Composer are registered trademarks or trademarks
of Canon Inc.
•Microsoft
®, Windows®, Windows NT®, and MS-DOS®are registered trademarks of
Microsoft Corporation in the United States and/or other countries.
• Apple, AppleTalk, EtherTalk, LocalTalk, and Macintosh are trademarks of Apple
Computer, Inc. in the United States.
• IBM is a trademark of the IBM Corporation in the United States.
•NetWare
®and Novell are registered trademarks of Novell, Inc., in the United States
and/or other countries. NDS, NDPS, NLM, and Novell Client are trademarks of Novell,
Inc. in the United States.
• Ethernet is a trademark of the Xerox Corporation in the United States.
• Netscape, Netscape Communicator, and Netscape Navigator are trademarks of
Netscape Communications Corporation.
• Other brand and product names in this document may be trademarks or registered
trademarks of their respective companies.

i
i
Warning
Caution
Important
Note
Notations About Text
Conventions
To ensure the safe and most efficient use of this printer, important
information is provided under the headings listed below. Before you use this
guide, make sure that you understand what these headings mean and
remember the important information described under these headings.
zFailure to follow these instructions could result in fatal or serious injury.
Always remember and follow the guidelines and advice described under
this heading to ensure your own safety and the safety of other people
working around the printer.
zFailure to follow these instructions could lead to mistakes in the use of
printer and result in minor injury or serious damage to the printer. Always
remember and follow the guidelines and advice described under this
heading to ensure safe use of the printer.
zInstructions and guidelines for operation of the printer provided under this heading
describe restrictions and other important information which if ignored could cause
minor damage to the printer or other equipment or result in the loss of valuable
data. Always remember and follow the guidelines and advice under this heading to
avoid mistakes in procedure.
zInformation under this heading includes tips and hints that will help you avoid
minor problems and use the printer more efficiently.

ii
ii
Screen Examples
The screenshots provided as examples in operational procedures may be
slightly different, depending on the operating system in use.
A button or item to press or select in a procedure appears enclosed with a
circular mark in the screen sample. If a procedure requires more
than one button press or selection, all the items are marked, so be sure to
select them as described in the procedure.
3 Enter the MAC address into the MAC Address box then click the Next button.

iii
iii
Abbreviations
Throughout this document the following abbreviations are used in text.
•Microsoft
®Windows®Millennium Edition is abbreviated as “Windows
Me”
•Microsoft
®Windows®98 is abbreviated as “Windows 98”
•Microsoft
®Windows®95 is abbreviated as “Windows 95”
•Microsoft
®Windows®XP is abbreviated as “Windows XP”
•Microsoft
®Windows®2000 is abbreviated as “Windows 2000”
•Microsoft
®Windows NT®is abbreviated as “Windows NT”
•Microsoft
®Windows®is abbreviated as “Windows”
• The term “GARO”, used in the name of this printer driver, is an acronym
for “Graphic Arts Language with Raster Operations”, a printer language
of creating raster images.
Legal Notice
• It is illegal to reproduce currency, bills, negotiable securities and other
documents prohibited by law. Reproduction of such items may be subject
to criminal prosecution.
• It is illegal to reproduce legal certificates, licenses, travel tickets, and
certain public and private documents prohibited from reproduction by
law. Reproduction of such items may be subject to criminal prosecution.
• Please note that intellectual property protected by copyright may not be
reproduced without the express permission of the copyright holder
except for personal or household use under limited circumstances.

iv
iv
Contents
Notations About Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Screen Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Legal Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Chapter 1 Before You Begin
Required System Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
System Environment Required for Printing . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Using a TCP/IP Network for Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Using an AppleTalk Network for Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Using a NetWare®Network for Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
The Network Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Windows Network Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Macintosh Network Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
NetWare®Network Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Chapter 2 TCP/IP Network Settings (Windows)
Procedures Required for a TCP/IP Network . . . . . . . . . . . . . . . . . 2-2
Setting the Printer IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Setting the IP Address with GARO Device Setup Utility . . . . . . . . . . . . . 2-4
Setting the IP Address with the ARP/PING Command . . . . . . . . . . . . . . . 2-6
Setting TCP/IP Protocol for the Printer . . . . . . . . . . . . . . . . . . . . . 2-8
Setting TCP/IP Protocol with a Web Browser (Remote UI) . . . . . . . . . . . 2-8
Setting the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Windows Me, Windows 98, and Windows 95 Settings . . . . . . . . . . . . . . . . . 2-13
Windows XP and Windows 2000 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Windows NT 4.0 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Setting the Printer for Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Managing the Printer from a Computer . . . . . . . . . . . . . . . . . . . . 2-17
Chapter 3 AppleTalk Network Settings (Macintosh)
Procedures Required for an AppleTalk Network . . . . . . . . . . . . . . 3-2
Setting a Macintosh . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Setting the Network Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Mac OS 8.6/9.x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Mac OS X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-4
Setting the Printer Protocols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-5
Setting up with a Web Browser (Remote UI) . . . . . . . . . . . . . . . . . . . . . . 3-5
Installing the Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9

v
v
Chapter 4 NetWare®Settings (Windows)
Procedures Required for a NetWare®Network . . . . . . . . . . . . . . . 4-2
Setting the Printer Frame Type . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Setting the frame type with GARO Device Setup Utility . . . . . . . . . . . . . 4-4
Setting Up a NetWare®Print Service . . . . . . . . . . . . . . . . . . . . . . 4-6
Types of Print Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-6
Setting Up a NetWare®Server with NWADMIN and PCONSOLE . . . . . 4-8
Using NDS Queue Server Mode/Remote Printer Mode . . . . . . . . . . . . . . . . . . 4-8
Using Bindery Queue Server/Remote Printer Mode . . . . . . . . . . . . . . . . . . . . . 4-9
Setting NetWare®Printer Protocol . . . . . . . . . . . . . . . . . . . . . . . 4-11
Setting up with a Web Browser (Remote UI) . . . . . . . . . . . . . . . . . . . . . 4-11
Setting the Computer for NetWare® . . . . . . . . . . . . . . . . . . . . . . 4-18
Connecting to a NetWare®Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
Installing the Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
Setting the Printer Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-18
Chapter 5 Troubleshooting
When You Cannot Use GARO Device Setup Utility . . . . . . . . . . . 5-2
When You Cannot Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Chapter 6 Other Important Information
Initializing Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
List of Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
General Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
TCP/IP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
AppleTalk Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
NetWare®Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Software Applications that Use Network Settings . . . . . . . . . . . . . 6-6
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7

vi
vi

1
1
Before You Begin
This chapter describes the network, network environment, and
other important information that you should confirm before
you begin.

Before You Begin
2
1-2
Important
Note
Required System Environment
This section describes the system environments that are supported by the
network interface of the printer.
System Environment Required for Printing
The lists below describe the system environments required to support the
network in use.
Using a TCP/IP Network for Printing
zCompatible Operating Systems:
• Windows Me/Windows 98/Windows 95
• Windows NT 4.0
• Windows 2000
• Windows XP
zCompatible Computers:
• IBM PC or IBM compatible PC
zIf you are using Windows NT 4.0, install Service Pack 6 or later.
Using an AppleTalk Network for Printing
zCompatible Computer
• A Macintosh Series computer equipped with a Power PC processor.
zCompatible Operating Systems
• Mac OS 8.6 or later
• Mac OS x 10.1 or later
zCompatible AppleTalk
• EtherTalk Phase 2
zRequired Memory
• 24 MB or more for Mac OS 8.6, 32 MB or more for Mac OS 9
zThis printer is not compatible with a Macintosh Local Network.

Required System Environment
3
1-3
Using a NetWare®Network for Printing
zCompatible Servers
• Novell NetWare®Version 4.2/5.1
zCompatible Clients
• Windows Me/Windows 98/Windows 95
• Windows XP Professional
• Windows 2000 Server
• Windows 2000 Professional
• Windows NT Server 4.0
• Windows NT Workstation 4.0
zCompatible Computers
• IBM PC or IBM compatible PC

Before You Begin
4
1-4
Note
The Network Environment
Use the diagrams below as reference to determine the type of network where
the printer is connected, and then follow the required procedure.
Windows Network Examples
If you are using Windows network, you can use TCP/IP as the protocol.
(ÆChapter 2 “TCP/IP Network Settings (Windows)”)
zAfter performing the settings for a TCP/IP network with a Windows computer,
every computer on the network can print with every printer connected directly to
the network. Also, setting up a Windows XP, Windows 2000, or Windows NT
computer as a server greatly improves the efficiency of managing network printers.
For more details about how to set up a server, see “Setting the Printer for Sharing”.
(ÆP. 2 - 1 5 )
zThe NetBIOS protocol cannot be used with this printer.
 
  
   



The Network Environment
5
1-5
Note
Macintosh Network Examples
For a Macintosh computer, the AppleTalk (EtherTalk) protocol is used.
(ÆChapter 3 “AppleTalk Network Settings (Macintosh)”).
NetWare®Network Examples
If the network is like the network environment shown in the illustration
below, you can print using NetWare®protocol. NetWare®client software
must be installed on every server computer and client computer.
(ÆChapter 4 “NetWare®Settings (Windows)”)
zYou can use TCP/IP or AppleTalk in common even in a network environment
where there is a NetWare®server. In such a case, perform the settings for the
protocol to use.
Macintosh
AppleTalk
W7200/W7250
Macintosh
 

   




Before You Begin
6
1-6

1
2
TCP/IP Network Settings
(Windows)
This chapter describes the setting methods and procedures for
connecting the printer to a TCP/IP network.

TCP/IP Network Settings (Windows)
2
2-2
Important
Procedures Required for a TCP/IP Network
Here is a summary of the procedures required to set the printer for use on a
TCP/IP network.
zSteps 1, 2, and 3 should be performed by the network system administrator.
zAn LPD connected print application can be used to print on the TCP/IP network.
zThis printer is not compatible with RAW protocol. If you are using Windows XP or
Windows 2000, you must set and use LPR protocol.
1 Connect the network cable. ÆSetup Guide
Follow the instructions in the Setup Guide to connect the network cable.
2 Setting the Printer IP Address ÆP. 2 - 3
Setting the IP address allows setting the printer protocol to enable communication between the
printer and the computer . You can use one of the methods below to set the protocol:
• GARO Device Setup Utility (Canon software application provided with the printer)
• ARP/PING command
• Printer operation panel
3 Setting TCP/IP Protocol for the Printer ÆP. 2 - 8
This procedure sets the printer protocol settings using a Web browser on a computer connected
to the network.
• Web browser (Remote UI)
4 Setting the Computer ÆP. 2 - 1 3
This procedure is performed for each computer to be used for printing.

Setting the Printer IP Address
3
2-3
Important
Setting the Printer IP Address
Before setting the printer protocol, you must set the IP address to enable
communication between the printer and the computer. You can use one of the
methods below to set the IP address. Use whichever method is easiest:
• GARO Device Setup Utility (ÆP. 2 - 4 )
• ARP/PING command (ÆP. 2 - 6 )
• Printer operation panel (ÆSetup Guide, Chapter 2, “Doing the settings
on the Printer Operation Panel”)
zWhen you use the GARO Device Setup Utility to perform the settings, you must
make the settings from a computer in the same subnet as the printer.
zWhen you use the GARO Device Setup Utility to perform the printer network
settings, the subnet mask and gateway address settings are set to 0.0.0.0, so use the
Remote UI or printer operation panel to make the settings for your network.
zIf you are using an operating system that is not compatible with the GARO Device
Setup Utility, use another computer on the network, use the ARP/PING command,
or use the printer operation panel to perform the settings.
zThe GARO Device Setup Utility must be installed on your computer in order to
use this utility to make the settings. Ask your system administrator to install the
GARO Device Setup Utility on your computer. (ÆSetup Guide)
zBefore setting the IP address, confirm that the printer is switched on and connected
to the network.
zThe MAC address is required to perform the setting with the GARO Device Setup
Utility or the ARP/PING command. If you need to confirm the MAC address, use
the printer operation panel to print a Status Print.
1. Press ONLINE to display MAIN MENU.
2. Press or to select Test Print then press .
3. Press or to select Status Print then press ENTER.

TCP/IP Network Settings (Windows)
4
2-4
Note
Setting the IP Address with GARO Device Setup Utility
If you are using Windows, use the GARO Device Setup Utility, the software
utility provided with the printer, to perform the printer network settings.
zIf you are using a Macintosh computer, use the printer operation panel to perform
the settings. (ÆSetup Guide, Chapter 2, “Doing the settings on the Printer
Operation Panel”)
1 On the desktop, click the Start button, point to Programs, then click
GARO Device Setup Utility.
2 Click the Settings button.

Setting the Printer IP Address
5
2-5
Important
3 Enter the MAC address into the MAC Address box then click the Next
button.
The utility searches for the printer on the network and when the printer is
found, the protocol settings dialog box opens.
zIf the printer cannot be found, make sure that the computer and the printer are in
the same subnet. If you use the GARO Device Setup Utility to perform the settings,
you must make the settings from a computer in the same subnet as the printer.
4 For the TCP/IP Frame Type, select ETHERNET II from the list, enter
the IP address allocated for the printer into the IP Address box, then
click the Next button.
When printing via AppleTalk, select Phase2 for AppleTalk Phase. When
printing with NetWare®, select the frame type in use for Frame Type.

TCP/IP Network Settings (Windows)
6
2-6
Note
5 Confirm the settings then click the Finish button.
The network interface settings are changed.
zThe subnet mask and gateway address settings have been set to 0.0.0.0. After
completing the above settings, use the Remote UI or the printer operation panel to
perform the subnet mask and gateway address settings for your network. (ÆP.2- 8)
This completes preparation for selecting the printer protocol. Now you are
ready to select the printer protocol. (ÆP. 2 - 8 )
Setting the IP Address with the ARP/PING Command
The examples of entries and settings below are for the English operating
system.
1 Start at the MS-DOS prompt or command line.
2 Execute the following commands, and add the static entry to the arp
table.
arp -s <IP address> <MAC address>
where:
IP address:
Set the IP address assigned to the printer. The IP address consists of four
decimal numbers (within the range 0 to 255) separated by dots.
MAC address:
Set the MAC address of the printer. In the MAC address every two numbers
is separated by a hyphen (-).
arp -s 172.20.88.196 00-00-85-05-70-31
3 Execute the following commands to set the IP address for the printer.
ping <IP address> -l 479
Set the same address entered at Step 2.
Sample:
ping 172.20.88.196 -l 479
