SIMPLIFIED SERVICE MANUAL
1. LIST OF ERROR DISPLAY
2. ADJUSTMENT / SETTINGS
QY8-13CM-000
Rev.00
July 22, 2009
Canon Inc.

(2/24)
1. LIST OF ERROR DISPLAY
1-1. Operator Call Errors (Alarm LED Lit In Orange)
Errors and warnings are displayed by the following ways:
- Operator call errors are indicated by the Alarm LED lit in orange, and messages are displayed
on the printer driver Status Monitor.
- Error codes (the latest 10 error codes at the maximum) are printed in the "operator call/service
call error record" area in EEPROM information print.
Buttons valid when an operator call error occurs:
- Power button: To turn the printer off and on again.
- Resume/Cancel button: To cancel the job at error occurrence, and to clear the error.
LED
(Blinking in
orange) Error Error
code Solution Remarks
No paper in the rear tray. [1000] Confirm that the rear tray is
selected as the paper source. Set
the paper in the rear tray, and
press the Resume/Cancel button.
No CD / DVD tray [1001] Set the CD / DVD tray, and press
the Resume/Cancel button.
No CD or DVD [1002] Set a CD or DVD in the CD / DVD
tray, and inset the CD / DVD tray
in the proper position. Then, press
the Resume/Cancel.
2 times
No paper in the cassette. [1003] Confirm that the cassette is
selected as the paper source. Set
the paper in the cassette, and
press the Resume/Cancel button.
Paper jam. [1300]
Paper jam in the rear
guide. [1303]
Paper jam in the under
guide. [1304]
Remove the jammed paper, and
press the Resume/Cancel button.
3 times
The front door is closed. [1250] Open the front door. The error is detected
at the start of printing
or during printing.
Ink may have run out. [1600] Replace the applicable ink tank
and close the cover. When the error is cleared by pressing
the Resume/Cancel
button, ink may run out
during printing.
4 times
Ink tank not installed. [1660] Install the applicable ink tank(s)
properly, and confirm that the
LED's of all the ink tanks light in
red.

(3/24)
LED
(Blinking in
orange) Error Error
code Solution Remarks
Print head not installed,
or not properly installed. Install the print head properly.
Faulty print head ID.
[1401]
Print head temperature
sensor error. [1403]
5 times
Faulty EEPROM data of
the print head. [1405]
Re-set the print head. If the error
is not cleared, the print head may
be defective. Replace the print
head.
[1841*2,
1846*2,
1851*1,
1856*1]
Close the inner cover, and press
the Resume/Cancel button.
Inner cover error.
[1850*1,
1855*1] Open the inner cover, place the
CD-R tray and press
Resume/Cancel.
6 times
Time-out in CD / DVD
print operation. [1830*1] A prescribed period of time (12
minutes) has elapsed without any
printing since printing was
attempted. Press the
Resume/Cancel button to clear
the error.
Multiple ink tanks of the
same color installed. [1487] Replace the wrong ink tank(s) with the correct one(s).7 times
Ink tank in a wrong
position. [1680] Install the ink tank(s) in the correct position.
8 times Warning: The ink
absorber becomes
almost full.
[1700/
1701] Replace the ink absorber, and reset its counter. [See 2-2.
Adjustment / Settings, (4) Service
mode]
Pressing the Resume/Cancel
button will exit the error, and
enable printing without replacing
the ink absorber. However, when
the ink absorber becomes full, no
further printing can be performed
unless the applicable ink absorber
is replaced.
The error “The ink
absorber becomes
almost full (service
call)” may occur soon.
9 times The connected digital
camera or digital video
camera does not support
Camera Direct Printing.
[2001] Remove the cable between the
camera and the printer.

(4/24)
LED
(Blinking in
orange) Error Error
code Solution Remarks
10 times Automatic duplex
printing cannot be
performed.
[1310] The paper length is not supported
for duplex printing.
Press the Resume/Cancel button
to eject the paper being used at
error occurrence.
Data which was to be printed on
the back side of paper at error
occurrence is skipped (not
printed).
Data which was to be
printed on the back
side of paper at error
occurrence is not
printed.
11 times Failed in automatic print
head alignment. [2500] Press the Resume/Cancel button to clear the error, then perform the
automatic print head again.
(In the iP4700 / iP4760, use Matte
Photo Paper MP-101.)
13 times The remaining ink
amount unknown. [1683] Replace the applicable ink tank with a new one. Printing with a
once-empty ink tank can damage
the printer.
To continue printing without
replacing the ink tank(s), press
the Resume/Cancel button for 5
sec. or longer to disable the
function to detect the remaining
ink amount. After the operation, it
is recorded in the printer
EEPROM that the function to
detect the remaining ink amount
was disabled.
The ink tank installed
is judged to have once
been empty.
14 times Ink tank not recognized. [1684] A non-supported ink tank (an ink
tank that is sold in a different
region from where the printer was
purchased) is installed (the ink
tank LED is turned off). Install the
supported ink tanks.
15 times Ink tank not recognized. [1682] A hardware error occurred in an
ink tank (the ink tank LED is
turned off). Replace the ink
tank(s).

(5/24)
LED
(Blinking in
orange) Error Error
code Solution Remarks
16 times No ink (no raw ink). [1688] Replace the empty ink tank(s),
and close the scanning unit
(cover).
Printing with an empty ink tank
can damage the printer.
To continue printing without
replacing the ink tank(s), press
the Resume/Cancel button for 5
sec. or longer to disable the
function to detect the remaining
ink amount. After the operation, it
is recorded in the printer that the
function to detect the remaining
ink amount was disabled.
19 times Non-supported hub [2002] Remove the applicable USB hub
from the PictBridge (USB)
connector.
*1: Only for models supporting CD / DVD printing
*2: Only for models not supporting CD / DVD printing

(6/24)
1-2. Service Call Errors (by Cyclic Blinking of Alarm and Power LEDs)
Cycles of
blinking of
Alarm and
Power LEDs
Error Error
code Conditions Solution (Check points and replacement items)
2 times Carriage error [5100] An error occurred in the
carriage encoder signal. 1) Smearing or scratches on the carriage slit film;
clean the timing slit film.
2) Foreign material or paper debris that
obstructs the carriage movement;
remove foreign material.
3) Ink tank conditions;
re-set the ink tanks.
4) Cable connection
5) Part replacement:
- Timing slit disk film
- Carriage unit
- Logic board
- Carriage motor
3 times Line feed error [6000] An error occurred in the LF
encoder signal. 1) Smearing or scratches on the LF / EJ slit film;
clean the LF / EJ slit film.
2) Foreign material or paper debris in the
LF drive;
remove foreign material.
3) Cable connection
4) Part replacement:
- LF / EJ slit film
- LF / EJ timing sensor unit
- Paper feed roller unit
- Logic board
- Paper feed motor
4 times Purge cam
sensor error [5C00] An error occurred in the purge unit. 1) Foreign material or paper debris around the purge drive system unit;
remove foreign material.
2) Cable connection
3) Part replacement:
- Purge drive system unit
- Logic board
5 times ASF (cam)
sensor error [5700] An error occurred in the ASF cam sensor. 1) Cable connection 2) Part replacement:
- ASF unit
- PE sensor board unit
- Logic board
6 times Internal
temperature
error
[5400] The internal temperature is
not normal. 1) Cable connection 2) Part replacement:
- Carriage unit
- Logic board
- Print head

(7/24)
Cycles of
blinking of
Alarm and
Power LEDs
Error Error
code Conditions Solution (Check points and replacement items)
7 times Ink absorber full [5B00,
5B01] The ink absorber is supposed to be full.
Error codes:
5B00:Main ink absorber is
full (overseas).
5B01:Main ink absorber is
full (Japan).
1) Ink absorber condition
2) Part replacement:
- Ink absorber kit
3) Ink absorber counter value in the
EEPROM;
reset the ink absorber counter.
8 times Print head
temperature rise
error
[5200] The print head temperature
exceeded the specified
value.
1) Print head condition
2) Head contact pin condition of the
carriage unit
3) Cable connection
4) Part replacement:
- Print head
- Logic board
- Carriage unit
9 times EEPROM error [6800,
[6801] A problem occurred in reading from or writing to
the EEPROM.
1) Part replacement:
- Logic board
10 times VH monitor error [B200] The print head voltage is
abnormal. 1) Head contact pin condition of the carriage unit
2) Cable connection (especially the
carriage FFC)
3) Part replacement:
- Print head and logic board
(Replace them at the same time.)
- Power supply unit
- Carriage unit
11 times Carriage lift
mechanism
error
[5110] The carriage did not move
up or down properly. 1) Foreign material or paper debris that obstructs the carriage movement;
remove foreign material.
2) Part replacement:
- Switch system unit
- Carriage unit
12 times APP position
error [6A80] An error occurred in the APP motor.
14 times APP sensor
error [6A90] An error occurred during paper feeding or paper
ejection.
1) Foreign material or paper debris
around the purge drive system unit;
remove foreign material, and
confirm that the ink absorber right
beneath the purge drive system unit
stays in place and does not contact
the unit.
2) Foreign material or paper debris
around the ASF unit;
remove foreign material.
3) Cable connection
4) Part replacement:
- Purge drive system unit
- Logic board

(8/24)
Cycles of
blinking of
Alarm and
Power LEDs
Error Error
code Conditions Solution (Check points and replacement items)
Paper feed cam
sensor error [6B10] An error occurred in the paper feed cam sensor
during paper feeding from
the cassette, or the paper
absorbing a large amount
of ink jammed in the PF
rear guide.
1) Jammed paper in the PF rear guide
(when a large amount of ink was
absorbed in the paper);
remove the jammed paper and
foreign material.
2) Foreign material or paper debris in the
cassette or in the PF rear guide;
remove foreign material.
3) Part replacement:
- PF pick-up unit
- Logic board
15 times USB Host VBUS
overcurrent [9000] The USB Host VBUS is overloaded. 1) Part replacement: - Logic board
16 times Pump roller
sensor error [5C20] The pump roller position cannot be detected. 1) Cable connection 2) Part replacement:
- Purge drive system unit
17 times Paper eject
encoder error [6010] Paper eject encoder error 1) Smearing or scratches on the LF / EJ slit film;
clean the LF / EJ slit film.
2) Foreign material or paper debris in the
paper path;
remove foreign material.
3) Cable connection
4) Part replacement:
- LF / EJ slit film
- LF / EJ timing sensor unit
- Platen unit
- Logic board
- Paper feed motor
19 times Ink tank position
sensor error [6502] None of the ink tank position is detected. 1) Ink tank position; confirm the ink tank position.
2) Re-set or replacement of ink tanks
3) Cable connection
4) Part replacement:
- Spur unit
- Logic board
20 times Other errors [6500] An unidentified error
occurred. 1) Part replacement: - Logic board
21 times Drive switch
error [C000] Drive was not switched properly. 1) Foreign material or paper debris in the drive switch area;
remove foreign material,
confirm the ink tank conditions, or
re-set the ink tanks properly.
2) Part replacement:
- Purge drive system unit
- ASF unit
- Carriage unit

(9/24)
Cycles of
blinking of
Alarm and
Power LEDs
Error Error
code Conditions Solution (Check points and replacement items)
23 times Valve cam
sensor error [6C10] The valve cam sensor was faulty at power-on or when
purging was attempted.
1) Foreign material or paper debris
around the purge drive system unit;
remove foreign material.
2) Cable connection
3) Part replacement:
- Purge drive system unit
- Logic board
Note: Before replacement of the logic board ass'y, check the ink absorber counter value (by service
test print or EEPROM information print). If the counter value is 7% or more, also replace the ink
absorber kit when replacing the logic board ass'y. If the counter value is less than 7%, register
the current ink absorber counter value to the replaced new logic board instead.

(10/24)
2. ADJUSTMENT / SETTINGS
2-1. Service Mode
< Service mode operation procedures >
Use the Service Tool on the connected computer.
1) Start the printer in the service mode.
i. With the printer power turned off, while pressing the Resume/Cancel button, press and hold
the Power button. (DO NOT release the buttons).
ii. When the Power LED lights in green, while holding the Power button, release the
Resume/Cancel button. (DO NOT release the Power button.)
iii. While holding the Power button, press the Resume/Cancel button 2 times, and then release
both the Power and Resume/Cancel buttons. (Each time the Resume/Cancel button is
pressed, the Alarm and Power LEDs light alternately, Alarm in orange and Power in green,
starting with Alarm LED.)
iv. When the Power LED lights in green, the printer is ready for the service mode operation.
2) Start the Service Tool on the connected computer.
i. When a button is clicked in the Service Tool dialog box, that function is performed. During
operation of the selected function, all the Service Tool buttons are dimmed and inactive.
ii When the operation is completed, "A function was finished." is displayed, and another
function can be selected.
iii If a non-supported function is selected, "Error!" is displayed. Click OK in the error message
dialog box to exit the error.
< Service Tool Functions >
V.1.05

(11/24)
No. Name Function Remarks
(1) Test Print Service test print Paper (2 sheets) will feed from the rear tray.
Service test print items:
- Model name
- ROM version
- USB serial number
- EEPROM information
- Process inspection information
- Barcode (model name + destination + printer
serial number)
- Ink system function check result
- CD / DVD sensor check result (printed on the
second sheet)
(2) EEPROM EEPROM information print The dialog box opens to select the paper source.
Select Rear tray or Cassette, and click OK.
EEPROM information print items:
- Model name
- ROM version
- Ink absorber counter value (ink amount in the ink
absorber)
- Print information
- Error information, etc.
(3) CD-R CD-R check pattern print For refurbishment use. Not used in servicing.
(4) LF / EJECT LF / Eject correction
pattern print
Perform LF / Eject correction only when streaks or
uneven printing occurs after the repair.
See “LF / Eject correction” below for details.
(5) Nozzle Check Nozzle check pattern print The dialog box opens to select the paper source.
Select Rear tray or Cassette, and click OK.
(6) Integration Successive print of (1)
service test pattern, (2)
EEPROM information, and
(5) nozzle check pattern
Paper will feed from the rear tray.
(7) Left Margin Left margin pattern print Not used.
(8) Deep Cleaning Print head deep cleaning Cleaning of both Black and Color at the same
time.
Main Main ink absorber counter
resetting
Set a sheet of A4 or Letter sized plain paper. After
the ink absorber counter is reset, the counter value
is printed automatically.
(9)
Platen Platen ink absorber
counter resetting
Not used.

(12/24)
No. Name Function Remarks
(10) EEPROM Clear EEPROM initialization The following items are NOT initialized, and the
shipment arrival flag is not on:
- USB serial number
- Destination settings
- Record of ink absorber counter resetting and
setting
- Record of repair at the production site
- CD / DVD print position correction value
- LF / Eject correction values
- Left margin correction value
- Production site E-MIP correction value and
enabling of it
- Endurance correction value and enabling of it
- Record of disabling the function to detect the
remaining ink amount
- Ink absorber counter value (ink amount in the ink
absorber)
(11) Panel Check Button and LCD test Not used.
(12) Set Destination Destination settings Select the destination, and click Set.
ASA, AUS, BRA, CHN, CND, EUR, JPN, KOR,
LTN, TWN, USA
(13) CD-R Correction CD / DVD print position
correction (X and Y
direction)
Also for printing of the CD / DVD check pattern in
refurbishment operation.
The reference center in the X direction and in the
Y direction can be adjusted respectively.
(Adjustable range between -1.0 mm to +1.0 mm, in
0.1 mm increment)
(14) LF / EJECT
Correction
LF / Eject correction value
setting
Set the correction value according to the result of
(4) LF / Eject correction pattern print.
See " LF / Eject correction " below for details.
(15) Left Margin Correction Left margin correction
value setting
Not used.
(16) Ink Absorber Counter Ink absorber counter
setting
See " Ink absorber counter setting " below.
(17) Wetting Liquid
Counter Wetting liquid counter setting Not used.
< LF / Eject correction >
After replacement of the feed roller, platen unit, LF / Eject encoder, encoder film, or logic board in
repair servicing or in refurbishment operation, perform the adjustment to maintain the optimal print
image quality.
1) Print the LF / Eject correction pattern.
Click LF/EJECT of the Service Tool on the connected computer, select the paper source and the
paper type, and print the pattern. 5 sheets of paper will be used for the pattern printing.
- Paper source: Select either Rear tray or Cassette.
- Media type: Select one from HR-101, GF-500/Office Planner, HP Bright White, and
Canon Extra/STEINBEIS.

(13/24)
2) When printing is finished, the printer returns to be ready for selection of another function.
3) In the printout, determine the Pattern No. in which streaks or lines are the least noticeable for the
LF check pattern and the Eject check pattern respectively. (LF Pattern No. 0 to 4, Eject Pattern
No. 0 to 4)
4) In the LF/EJECT Correction section of the Service Tool, select the Pattern No. (from 0 to 4)
determined in step 3) for LF and EJECT respectively, and click Set.
5) The selected LF and Eject correction values are written to the EEPROM, making the E-MIP
correction value (which was set at shipment from the production site) invalid.
Note: At the production site, the E-MIP correction, which is equivalent to the LF / Eject correction,
is performed using the special tool, and the E-MIP correction value is written to the EEPROM
as the valid data.
When LF / Eject correction is performed, the LF / Eject correction values become valid
instead of the E-MIP correction value (thus, in the initial EEPROM information print, "LF = *"
and "EJ = *" are printed, but the selected values are printed after the LF / Eject correction).
<Ink absorber counter setting>
Set the ink absorber counter value to a new EEPROM after the logic board is replaced in servicing.
1) Before replacement of the logic board, check the ink absorber counter value in EEPROM
information print.
2) After replacement of the logic board, the ink absorber counter value should be set in the service
mode using the Service Tool.
In the Ink Absorber Counter section of the Service Tool, select Main from the Absorber
pull-down menu.
From the Counter Value(%) pull-down menu, select the value (in 10% increments) which is the
closest to the actual counter value confirmed before replacement of the logic board, and click
Set.
3) Print EEPROM information to confirm that the value is properly set to the EEPROM.
<CD / DVD print position correction>
Set the CD / DVD print position value to a new EEPROM after the logic board is replaced in
servicing.
Note: For solution of user complaints, this function can be used, however, use of the application
software is recommended to adjust the CD / DVD print position.

(14/24)
1) Before replacement of the logic board, check the CD / DVD print position value in EEPROM
information print.
2) After replacement of the logic board, set the print position value in CD-R Correction of the
Service Tool.
3) If EEPROM information is not available before replacement of the logic board due to logic board
failure, etc., click CD-R in the Service Tool to print the CD-R check pattern, and confirm that the
intersection of the axes Y and X is at the center of the CD / DVD.

(15/24)
2-2. User Mode
Function Procedures Remarks
Nozzle check pattern
printing Perform from the printer driver Maintenance tab, or see
"Standalone printer operation"
below.
Set a sheet of plain paper (A4 or Letter) in
the cassette, or the rear tray if selected.
Print head manual
cleaning Perform from the printer driver Maintenance tab.
- Cleaning of both Black and Color
- Cleaning Black or Color separately
Unclogging of the print head nozzles, and
maintenance to keep the print head
conditions good.
If there is a missing portion or white streaks
in the nozzle check pattern printout,
perform this cleaning.
Print head deep
cleaning Perform from the printer driver Maintenance tab. If print head cleaning is not effective, perform this cleaning. Since the deep
cleaning consumes more ink than regular
cleaning, it is recommended to perform
deep cleaning only when necessary.
Automatic print head
alignment Perform from the printer driver Maintenance tab. Set 1 sheet of A4 Matte Photo Paper (MP-101) in the rear tray.
If automatic alignment is not effective,
perform manual print head alignment.
Manual print head
alignment Perform from the printer driver Maintenance tab. Set 3 sheets of plain paper (A4 or Letter) in the cassette, or the rear tray if selected.
Print head alignment
value printing Perform from the printer driver Maintenance tab. Confirmation of the current print head alignment values.
Paper feed roller
cleaning Perform from the printer driver Maintenance tab. The paper feed rollers of the selected paper source (the rear tray or the cassette)
rotate while being pushed to the paper
lifting plate. Since the rollers will wear out in
this cleaning, it is recommended that you
perform this only when necessary.
Bottom plate cleaning Perform from the printer driver
Maintenance tab, or see
"Standalone printer operation"
below.
Cleaning of the platen ribs when the back
side of paper gets smeared.
Fold a sheet of plain paper (A4 or Letter) in
half crosswise, then unfold and set it in the
rear tray with the folded ridge facing down.
(No paper feeding from the cassette)
< Standalone printer operation >
1) Turn on the printer in the user mode.
2) Press and hold the Resume/Cancel button until the Power LED blinks in green the specified
number of times listed in the table below, and release it. The operation starts.
Power
LED
(blinking in
green)
Operation Remarks
1 time Manual print head cleaning
2 times Nozzle check pattern printing Set a sheet of plain paper (A4 or Letter) in the cassette.

(16/24)
Power
LED
(blinking in
green)
Operation Remarks
5 times Bottom plate cleaning
2-3. Special Notes on Assembling
(1) External housing removal
1) Remove the cassette.
2) Remove the paper support unit and the access cover.
<While pushing the both sides of the paper support so that the center will warp slightly, release the
left and right bosses. >
3) Remove the main case covers L and R.
< While inserting a flat-blade screwdriver, etc. through into a space under the main case cover; and
pressing the claw downward, slide the main case cover toward the front side of the printer. >


(17/24)
4) Remove the side cover L.
 


5) Remove the side cover R.
 



(18/24)
6) Remove the front door unit.
< While slightly warping the center of the paper output tray downward, release the left and right
bosses. >
7) Remove the panel cover unit (1 screw).
 



(19/24)
8) Remove the main case unit.
 

 

 



(20/24)
(2) Notes on Service Part Replacement (and Disassembling / Reassembling)
Service part Notes on replacement*1 Adjustment / settings Operation check
Logic board ass'y - Before removal of the
logic board ass'y,
remove the power cord,
and allow for approx. 1
minute (for discharge of
capacitor's accumulated
charges), to prevent
damages to the logic
board ass'y.
- Before replacement,
check the ink absorber
counter value (by service
test print or EEPROM
information print).
After replacement:
1) Initialize the EEPROM.
2) Set the ink absorber counter
value.
3) Set the destination in the
EEPROM.
4) Correct the CD / DVD and
automatic print head
alignment sensors.
5) Check the ink system
function.
6) Perform LF / Eject
correction (only when
streaks or uneven printing
occurs).
Perform 1 to 6 in the service
mode.
7) Perform print head
alignment in the user mode.
- EEPROM information print
- Service test print
- Printing via USB connection
- Direct printing from a digital
camera (PictBridge)
Absorber kit After replacement:
1) Reset the ink absorber
counter.
- Ink absorber counter
volume print (After the ink
absorber counter is reset,
the counter value is printed
automatically.)
Carriage unit At replacement:
1) Before removal of the
carriage rail, mark the
carriage rail position.
2) Apply grease to the sliding
portions of the carriage rail.
[See 2-2. Adjustment /
Settings, (2) Grease
application]
3) Check the ink system
function.
4) Perform print head
alignment in the user mode.
- Service test print (Confirm
CD / DVD and automatic
print head alignment sensor
correction, and ink system
function.)
Switch system unit
Paper feed motor
- The red screws securing
the paper feed motor are
allowed to be loosened
only for paper feed motor
replacement. (DO NOT
loosen them in any other
cases.)
At replacement:
1) Adjust the paper feed motor.
- EEPROM information print
- Service test print
Platen unit After replacement:
1) Perform LF / Eject
correction in the service
mode (only when streaks or
uneven printing occurs).
- EEPROM information print
- Service test print
