Canon N2000 Installation and maintenance instructions

00_J80xNG_Eng.book Page I Thursday, April 11, 2002 7:20 PM

Copyright ©2002 Canon Inc. all rights reserved.
• Unauthorized transfer or duplication of all or any part of this document is prohibited.
• The content of this document is subject to change without notice.
• Every effort has been made to ensure that the information contained in this guide is
correct. If any error or omission is found, contact us directly or an authorized Canon
representative.
• Canon is not responsible for any damages, direct or indirect, arising from or related to
the use of this printer.
Trademarks
• Canon, the Canon logo, BJ, and NetSpot are registered trademarks of Canon Inc.
•Microsoft
®, Windows®, Windows NT®and MS-DOS®are registered trademarks of
Microsoft Corporation in the United States and/or other countries.
• IBM is a trademak of the IBM Corporation in the United States.
• HP is a trademark of Hewlett-Packard, Inc.
• NetWare and Novell are registered trademarks of Novell, Inc. in the United States and
other countries. NDS, NDPS, NLM, and Novell Client is a trademark of Novell, Inc. in
the United States.
• Ethernet is a trademark of the Xerox Corporation in the United States.
• Sun, Sun Microsystems, and SunOS are trademarks of Sun Microsystems, Inc. in the
United States and other countries.
• Adobe and Acrobat are trademarks of Adobe Systems, Inc.
• UNIX is a registered trademark, licensed independently by X/Open Company, Ltd. in
the United States and in other countries.
• Linux is a trademark of Linus Torvalds.
• TurboLinux is a trademark of TurboLinux, Inc.
• Netscape, Netscape Communicator, and Netscape Navigator are trademarks of
Netscape Communications Corporation.
• Red Hat is a trademark of Red Hat Software of the United States.
• Other brand and product names may be trademarks or registered trademarks of their
respective companies.
00_J80xNG_Eng.book Page II Thursday, April 11, 2002 7:20 PM

Notations About Text
i
i
Warning
Caution
Important
Note
Notations About Text
Conventions
To ensure the safe and most efficient use of this printer, important
information is provided under the headings listed below. Before you use this
guide, make sure that you understand what these headings mean and
remember the important information described under these headings.
zFailure to follow these instructions could result in fatal or serious injury.
Always remember and follow the guidelines and advice described under
this heading to ensure your own safety and the safety of other people
working around the printer.
zFailure to follow these instructions could lead to mistakes in the use of
printer and result in minor injury or serious damage to the printer. Always
remember and follow the guidelines and advice described under this
heading to ensure safe use of the printer.
zInstructions and guidelines for operation of the printer provided under this heading
describe restrictions and other important information which if ignored could cause
minor damage to the printer or other equipment or result in the loss of valuable
data. Always remember and follow the guidelines and advice under this heading to
avoid mistakes in procedure.
zInformation under this heading includes tips and hints that will help you avoid
minor problems and use the printer more efficiently.
00_J80xNG_Eng.book Page i Thursday, April 11, 2002 7:20 PM

ii
ii
Screen Examples
The screenshots provided as examples in operational procedures may be
slightly different, depending on the operating system in use.
A button or item to press or select in a procedure appears enclosed with a
circular mark in the screen sample. If a procedure requires more
than one button press or selection, all the items are marked, so be sure to
select them as described in the procedure.
3 Under “Network Configuration Information”, click TCP/IP, then click the Edit
button.
00_J80xNG_Eng.book Page ii Thursday, April 11, 2002 7:20 PM

Notations About Text
iii
iii
Abbreviations
Throughout this document the following abbreviations are used in text.
• Microsoft®Windows®Millennium Edition is abbreviated as “Windows
Me”
• Microsoft®Windows®98 is abbreviated as “Windows 98”
• Microsoft®Windows®95 is abbreviated as “Windows 95”
• Microsoft®Windows®XP is abbreviated as “Windows XP”
• Microsoft®Windows®2000 is abbreviated as “Windows 2000”
• Microsoft®Windows NT®is abbreviated as “Windows NT”
• Microsoft®Windows®is abbreviated as “Windows”
• The term “GARO”, used in the name of this printer driver, is an acronym
for “Graphic Arts Language with Raster Operations”, a printer language
of creating raster images.
Legal Notice
• It is illegal to reproduce currency, bills, negotiable securities and other
documents prohibited by law. Reproduction of such items may be subject
to criminal prosecution.
• It is illegal to reproduce legal certificates, licenses, travel tickets, and
certain public and private documents prohibited from reproduction by
law. Reproduction of such items may be subject to criminal prosecution.
• Please note that intellectual property protected by copyright may not be
reproduced without the express permission of the copyright holder
except for personal or household use under limited circumstances.
00_J80xNG_Eng.book Page iii Thursday, April 11, 2002 7:20 PM

iv
iv
Contents
Notations About Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Screen Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Legal Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iii
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Chapter 1 Before You Begin
Required System Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
System Environment Required for Printing . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Using a TCP/IP Network for Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Using a NetWare®Network for Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Using a NetBIOS Network for Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
The Network Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Windows Network Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Windows Me, Windows 98, or Windows 95 Computers Only . . . . . . . . . . . . . 1-4
Windows XP, Windows 2000, Windows NT Computers . . . . . . . . . . . . . . . . . 1-5
UNIX Server or Linux Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
NetWare®server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Chapter 2 TCP/IP Network Settings (Windows)
Procedures Required for a TCP/IP Network . . . . . . . . . . . . . . . . . 2-2
Setting the Printer IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Setting the IP Address with NetSpot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Setting the IP Address with the ARP/PING Command . . . . . . . . . . . . . . . 2-6
Setting the IP Address with the Printer Operation Panel . . . . . . . . . . . . . . 2-7
Setting TCP/IP Protocol for the Printer . . . . . . . . . . . . . . . . . . . . . 2-9
Setting TCP/IP Protocol with NetSpot . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-9
Setting TCP/IP Protocol with a Web Browser (Remote UI) . . . . . . . . . . 2-14
Setting TCP/IP Protocol with FTP Client . . . . . . . . . . . . . . . . . . . . . . . . 2-20
Setting the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
Settings for LPD/RAW Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-23
Windows Me, Windows 98, Windows 95 LPD Connection . . . . . . . . . . . . . . 2-23
Windows XP, Windows 2000 RAW Connection . . . . . . . . . . . . . . . . . . . . . . 2-26
Windows NT 4.0 LPD Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-28
UNIX LPD Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30
IPP Connection Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-32
Windows Me, Windows 98, Windows 95 IPP Connection . . . . . . . . . . . . . . . 2-32
Windows XP, Windows 2000 IPP Connection . . . . . . . . . . . . . . . . . . . . . . . . 2-33
Setting the Printer for Sharing . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-36
Managing the Printer from a Computer . . . . . . . . . . . . . . . . . . . . 2-38
Managing the Printer with NetSpot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-38
Managing the Printer with a Web Browser (Remote UI) . . . . . . . . . . . . 2-38
Managing the Printer with an FTP Client . . . . . . . . . . . . . . . . . . . . . . . . 2-38
Managing the Printer with E-mail Notification . . . . . . . . . . . . . . . . . . . . 2-40
00_J80xNG_Eng.book Page iv Thursday, April 11, 2002 7:20 PM

v
v
Setting Up the E-mail Notification Function . . . . . . . . . . . . . . . . . . . . . . 2-41
Chapter 3 NetWare®Settings (Windows)
Procedures Required for a NetWare®Network . . . . . . . . . . . . . . . 3-2
Setting NetWare®Frame Type . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Setting Up a NetWare®Print Service . . . . . . . . . . . . . . . . . . . . . . 3-6
Types of Print Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Setting Up a NetWare®Print Server with NetSpot . . . . . . . . . . . . . . . . . . 3-7
Using NDS Queue Server Mode/Remote Printer Mode . . . . . . . . . . . . . . . . . . 3-7
Using Bindery Mode Queue Server/Remote Mode . . . . . . . . . . . . . . . . . . . . . 3-12
Setting NetWare®Printer Protocol . . . . . . . . . . . . . . . . . . . . . . . 3-17
Setting the Computer for NetWare® . . . . . . . . . . . . . . . . . . . . . . 3-21
Connecting to a NetWare®Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
Installing the Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
Setting the Printer Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-21
Chapter 4 NetBIOS Network Settings (Windows Me/Windows 98/
Windows 95)
Procedures Required for a NetBIOS Network . . . . . . . . . . . . . . . . 4-2
Windows Settings for a NetBIOS Network . . . . . . . . . . . . . . . . . . 4-3
NetBIOS Network Connection Methods . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
Installing the Printer Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Setting the Printer Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Chapter 5 Troubleshooting
When You Cannot Use NetSpot . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
When You Cannot Print . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Chapter 6 Other Important Information
Initializing Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
List of Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
General Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
TCP/IP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
NetWare Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
NetBIOS Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
Software Applications that Use Network Settings . . . . . . . . . . . . . 6-8
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
00_J80xNG_Eng.book Page v Thursday, April 11, 2002 7:20 PM

vi
vi
00_J80xNG_Eng.book Page vi Thursday, April 11, 2002 7:20 PM

1
1
Before You Begin
This chapter describes the network, network environment, and
other important information that you should confirm before
you begin.
00_J80xNG_Eng.book Page 1 Thursday, April 11, 2002 7:20 PM

Before You Begin
2
1-2
Required System Environment
This section describes the system environments that are supported by the
network interface board of the printer.
System Environment Required for Printing
The lists below describe the system environments required to support the
network in use.
Using a TCP/IP Network for Printing
zCompatible Server Operating Systems:
• Windows XP Professional
• Windows 2000 Server
• Windows 2000 Professional
• Windows NT Server 4.0
• Windows NT Workstation 4.0
• Solaris Version 1.1.x (SunOS Version 4.1.x) or later
• Solaris Version 2.5.x (SunOS Version 5.5.x) or later
• HP-UX Version 10.x or later
• IBM-AIX Version 4.x or later
• Redhat Linux 5.2 or later
• Turbo Linux 3.0 or later
zCompatible Client Computers:
• An IBM PC or IBM compatible PC is required for Windows Me,
Windows 98, Windows 95, Windows XP, Windows 2000, or Windows
NT.
Using a NetWare®Network for Printing
zCompatible Servers:
• Novell NetWare®Version 3.20/4.1/4.11/4.20/5.0/5.1
zCompatible Clients:
• Windows Me/Windows 98/Windows 95
• Windows XP Professional
• Windows 2000 Server
• Windows 2000 Professional
• Windows NT Server 4.0
• Windows NT Workstation 4.0
zCompatible Computers:
00_J80xNG_Eng.book Page 2 Thursday, April 11, 2002 7:20 PM

Required System Environment
3
1-3
Important
• IBM PC or IBM PC compatible PC.
Using a NetBIOS Network for Printing
zCompatible Operating Systems:
• Windows Me, Windows 98, Windows 95
zCompatible Computers:
• IBM PC or IBM PC compatible PC.
zRequired Memory:
• 16MB or more
zIf you are using Windows NT 4.0, install Service Pack 5 or later.
00_J80xNG_Eng.book Page 3 Thursday, April 11, 2002 7:20 PM

Before You Begin
4
1-4
The Network Environment
Use the diagrams below as reference to determine the type of network where
the printer is connected, and then follow the required procedure.
Windows Network Examples
Windows Me, Windows 98, or Windows 95 Computers Only
If the network is like the network environment shown in the illustration
below, you can print with a few simple settings if you use NetBIOS protocol.
By installing the software utility Canon LPR Port on each computer, you can
also use TCP/IP protocol.
Refer to the following pages for details about the protocols to use.
• Chapter 2 TCP/IP Network Settings (Windows)
• Chapter 4 NetBIOS Network Settings (Windows Me/Windows 98/
Windows 95)
Windows 98 Windows 95 Windows Me
NetBIOS, TCP/IP
N1000
00_J80xNG_Eng.book Page 4 Thursday, April 11, 2002 7:20 PM

The Network Environment
5
1-5
Windows XP, Windows 2000, Windows NT Computers
If the network is like the network environment shown in the illustration
below, you can print using the TCP/IP protocol. Computers with Windows
XP, Windows 2000, or Windows NT can use the TCP/IP functions of the
operating system to print. By installing the software utility Canon LPR Port
on each computer using Windows Me, Windows 98, or Windows 95, you
can also use Canon LPR port to print.
Refer to the following pages for details about setting procedures.
• Chapter 2 TCP/IP Network Settings (Windows)
If Windows XP or Windows 2000, Windows NT are used on the network,
you can manage the network printer efficiently by setting up a print server.
For more details about how to set up a print server, see the following section.
• Chapter 2 Setting the Printer for Sharing (ÆP.2-36)
Windows 98 Windows 95 Windows NT
TCP/IP
N1000
Windows 2000
00_J80xNG_Eng.book Page 5 Thursday, April 11, 2002 7:20 PM

Before You Begin
6
1-6
Note
UNIX Server or Linux Server
If the network is like the network environment shown in the illustration
below, you can print using TCP/IP protocol. If you print through a UNIX or
Linux server set up as a print server, then the Windows computer can be
released from print job processing much earlier, thus increasing the
efficiency of your system.
Refer to the following pages for details about setting procedures.
• Chapter 2 TCP/IP Network Settings (Windows)
zYou cannot print directly from a computer running UNIX or Linux.
zYou can use NetBIOS in common even in a network environment where there is a
UNIX or Linux computer. In such a case, perform the settings for the protocol to
use.
Windows 98
UNIX Server
Windows 95 Windows 2000
TCP/IP
N1000
00_J80xNG_Eng.book Page 6 Thursday, April 11, 2002 7:20 PM

The Network Environment
7
1-7
Note
NetWare®server
If the network is like the network environment shown in the illustration
below, you can print using NetWare®protocol. NetWare®client software
must be installed on every server computer and client computer.
For details about settings, refer to the pages below.
• Chapter 3 NetWare®Settings (Windows)
zYou can use TCP/IP or NetBIOS in common even in a network environment where
there is a NetWare®server. In such a case, perform the settings for the protocol to
use.
Windows 98
NetWare®Server
Windows 95 Windows 2000
NetWare®
N1000
00_J80xNG_Eng.book Page 7 Thursday, April 11, 2002 7:20 PM

Before You Begin
8
1-8
00_J80xNG_Eng.book Page 8 Thursday, April 11, 2002 7:20 PM

1
2
TCP/IP Network Settings
(Windows)
This chapter describes how to set the printer for a TCP/IP
network.
00_J80xNG_Eng.book Page 1 Thursday, April 11, 2002 7:20 PM

TCP/IP Network Settings (Windows)
2
2-2
Important
Procedures Required for a TCP/IP Network
Here is a summary of the procedures required to set the printer for use on a
TCP/IP network.
zSteps 1, 2, and 3 should be performed by the network system administrator.
zThe following print applications can be used to print on a TCP/IP network: LPD,
FTP, RAW (Windows XP, Windows 2000), and IPP (Windows Me, Windows 98,
Windows 95, Windows XP, Windows 2000)
1
Install the network interface board and connect the
network cable. ÆSetup Guide
Follow the instructions in the Setup Guide to install the network interface board and connect the
network cable. The standard network compatible printer does not require installation of the
network interface board (only the network interface cable must be connected).
2
Setting the Printer IP Address ÆP. 2 - 3
Setting the IP address allows setting the printer protocol to enable communication between the
printer and the computer . You can use one of the methods below to set the protocol:
• NetSpot (Canon software application provided with the printer)
• ARP/PING command
• Printer operation panel
3
Setting TCP/IP Protocol for the Printer ÆP. 2 - 9
This procedure selects TCP/IP for the printer protocol. You can use one of the methods below to
set the protocol from the computer:
• NetSpot
• Web Browser (Remote UI)
• FTP Client
4
Setting the Computer ÆP.2-22
This procedure is performed for each computer to be used for printing.
00_J80xNG_Eng.book Page 2 Thursday, April 11, 2002 7:20 PM

Setting the Printer IP Address
3
2-3
Important
Setting the Printer IP Address
Before setting the printer protocol, you must set the IP address to enable
communication between the printer and the computer. You can use one of the
methods below to set the IP address. Use whichever method is easiest:
• NetSpot (Canon software application provided with the printer)
• ARP/PING command
• Printer operation panel
zNetSpot must be installed on the computer before you can use NetSpot to set the IP
address. The system administrator should install NetSpot on the computer. (Æ
Setup Guide)
zIf you are using an operating system that is not compatible with NetSpot, you can
use another computer on the network, the ARP/PING command, or the printer
operation panel to perform the IP address setting.
zThe following procedure is required for the MAC address. To confirm the MAC
address, execute “Ext. I/F Print” with the printer operation panel:
1. Press the Online button. The Online lamp switches off.
2. Press the Cancel Job/Utility button.
3. Press or to select Ext. I/F Print then press .
zBefore setting the IP address, confirm that the printer is switched on and connected
to the network.
zIf you are using a DHCP, BOOTP, or RARP server where the IP address is
acquired automatically, use the printer operation panel to select “Automatic” for
the “IP Mode” setting, then select ON for the server in use.
zIf you are using a DHCP, BOOTP, or RARP server, selecting the IP address for the
printer is not required. However, the IP address changes every time the printer is
powered on, so in order to access the printer every time the printer is switched on,
the IP address must be checked.
00_J80xNG_Eng.book Page 3 Thursday, April 11, 2002 7:20 PM

TCP/IP Network Settings (Windows)
4
2-4
Note
Setting the IP Address with NetSpot
1
Start NetSpot as the system administrator.
zWhen the icon for the printer that you want to set is displayed in NetSpot, the
printer and computer are communicating normally, so the following procedure is
not required. Set the printer protocol directly. (Æ“Setting TCP/IP Protocol for the
Printer”, P.2-9)
2
If the Device window does not open, from the Window menu select
New Window, then select IP Devices.
3
If the icon for the printer is not displayed, confirm that the printer is
switched on and connected to the network, then from the Device
menu select New.
4
In the MAC Address box, enter the MAC address, in the IP Address
box enter 192.168.0.215, then click the Continue button.
00_J80xNG_Eng.book Page 4 Thursday, April 11, 2002 7:20 PM
