Canon Satera LBP9500C User manual

Laser Beam Printer
User's Guide
User's Guide

1
Contents
Tu r ning the Printer On/Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Tu r ning On the Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Tu r ning Off the Printer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Online and Offline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Placing the Printer Online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Placing the Printer Offline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Paper Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Paper Size. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Printable Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Plain Paper, Heavy Paper, Transparencies, Labels, and Coated Paper . . . . . . . . . . . .16
Postcard/Reply Postcard/4 on 1 Postcard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Envelope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Paper Which Requires Attention Before Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Paper Capacity of Paper Source. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Paper Capacity of the Output Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Loading Standard Size Paper (Other Than Postcards and Envelopes) . . . . . . . 21
Loading Standard Size Paper in Cassette 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Loading Paper in the Paper Cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Specifying the Settings for the Paper Cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Registering the Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Loading Standard Size Paper in Cassette 2, 3, or 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Loading Paper in the Paper Cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Specifying the Settings for the Paper Cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Registering the Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Loading Standard Size Paper (Other Than Postcards and Envelopes) in the Multi-purpose Tray
. . . 36
Loading Paper in the Multi-purpose Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Registering the Paper Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Registering the Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Loading Postcards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Loading Postcards in the Multi-purpose Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Registering the Paper Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Registering the Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Loading Envelopes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Loading Envelopes in the Multi-purpose Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Registering the Paper Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Registering the Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60

2
Loading Custom Size Paper (Non-Standard Size Paper) or Long-size Paper . . 63
Loading Custom Size Paper in Cassette 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Loading Custom Size Paper in the Paper Cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Registering the Loading Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Registering the Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Registering a Custom Paper Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Loading Custom Size Paper in Cassette 2, 3, or 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Loading Custom Size Paper in the Paper Cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Registering the Loading Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Registering the Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Registering a Custom Paper Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Loading Custom Size Paper or Long-size Paper in the Multi-purpose Tray . . . . . . . . . 78
Loading Custom Size Paper or Long-size Paper in the Multi-purpose Tray . . . . . . . . . 79
Registering the Loading Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Registering the Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Registering a Custom Paper Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Paper Loading Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Paper Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Precautions When Removing Jammed Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Clearing Paper Jams (MP Tray Area). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Clearing Paper Jams (Output Area, Right Cover Area, Duplex Unit Area, or Cassette 1/2/3/4 Area) . . . . 95
Clearing Paper Jams (Cassette 2/3 Cover Area) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Checking Paper Jams in the Paper Cassette. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Replacing the Toner Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
When a Message Appears. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Precautions when Replacing Toner Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Replacing Toner Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Canceling a Job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Confirming the Printer Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Service Call Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
If a Fixing Unit Error Is Displayed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
If a Service Error or the Message "Power OFF and ON" Is Displayed. . . . . . . . . . . . 125
Message List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

3
Turning the Printer On/Off
Turning On the Printer
1
Turn the printer on.
(1) Open the power switch cover.
(2) Press "I" of the power switch.
 The printer initiates a self-diagnostic test on the printer unit and optional
accessories.
 If the self-diagnostic test result is normal
 The 印刷可
indicator (green), オンライン indicator (green), and 給紙元表示
indicator (green) are turned on, and then the printer is ready to print.
(1) (2)

4
IMPORTANT
Do not turn the printer on immediately after turning it off.
If you want to cycle the power of the printer, wait at least 10 seconds before turning
it on again.
If an error message appears in the display on the control panel
See "Message List," on p. 127.
When turning on the printer for the first time after installing the printer and
paper feeder
Read the following instructions.

Do not load paper in the paper cassette.

Make sure that the packing materials of the paper cassette are removed.
Turning Off the Printer
1
Check that the printer is not performing the following
operations.

Printing

While the printer is running a self-diagnostic test immediately after turning the
power on

While the ジョブ
indicator is on

When any of the following messages appears
- <起動中です。
>
- <キャリブレーション中です。
>
- <Initializing NVRAM...>
2
Press [ ] ( リリ
リリセセ セセッッ ッットト トト ).
3
Select [ シシ
シシャャ ャャッッ ッットト トトダダ ダダウウ ウウンン ンン ] using [ ], and then press [OK].

5
IMPORTANT
If you perform a shutdown when a secured print job is in the hard disk
The message <
実行できませんでした。
> appears.
If you want to execute a shutdown, perform a soft reset to delete the job, and then
perform a shutdown again.
If you do not want to execute a shutdown, press [ ] (
オンライン
).
NOTE
When you are using WSD printing
The shutdown notifies the computer that the printer is turned off.
4
Select [ はは
ははいい いい ] using [ ], and then press [OK].
 The process to turn the printer off is performed, and the messages < 実行中で
す。
> and < シャットダウン実行中です。通知があるまで主電源を切らないでください >
appear.
5
Confirm the message.
 When the printer is ready to be turned off, the message appears.
LBP9600C

6
6
Turn the printer off.
(1) Open the power switch cover.
(2) Press " " of the power switch.
IMPORTANT
Precautions when turning off the printer
If you turn the printer off, all print data remaining in the printer memory will be
erased.
Power consumption when the power is off (when " " is pressed)
Even if the power of the printer is turned off, power is consumed only slightly while
the power plug is inserted into the AC power outlet.
To cut the power consumption completely, unplug the power plug from the AC
power outlet.
If the printer is not turned off immediately even after " " of the power
switch is pressed
The printer is cooling down the inside and stopping the printer processes.
Please wait a moment.
(1) (2)

7
Online and Offline
When the printer can receive data from the computer and print the data, the printer
is in the state of "Online", and when the printer is disconnected with the computer
and cannot receive data, the printer is in the state of "Offline".
To perform the settings for each menu using the control panel, switch the printer
status as follows.
: The status that you can enter the menu
: The status that you cannot enter the menu
* The ユーザメンテナンス
options cannot be specified when the printer is online.
Placing the Printer Online
When printing from the computer, the printer has to be online.
If not, place the printer online using the following procedure.
1
Press [ ] ( オオ
オオンン ンンララ ラライイ イインン ンン ).
The オンライン
indicator turns on, and the printer is online.
IMPORTANT
If you cannot place the printer online
If an error is occurring in the printer, the printer does not come online.
Eliminate the cause of the error before you place the printer online.
NOTE
About the
オオ
オオンン ンンララ ラライイ イインン ンン
indicator during Power Save Mode
During Power Save Mode, the
オンライン
indicator is off even when the printer is
online.
When the printer is online When the printer is offline
セットアップ
Menu *
給紙選択
Menu
リセット
Menu
ジョブ
Menu
ユーティリティ
Menu

8
Placing the Printer Offline
To configure the printer so that it does not receive data from the computer or
specify the settings for all the items in the セットアップ
menu, place the printer offline
using the following procedure.
1
Press [ ] ( オオ
オオンン ンンララ ラライイ イインン ンン ).
The オンライン
indicator goes off, and the printer is offline.
IMPORTANT
About the automatic online function
The printer comes online automatically if left in the offline state for five minutes or
longer.
If an error is occurring in the printer, however, the printer does not come online
automatically.

9
Paper Requirements
Paper Size
The following shows the paper sizes that can be used with this printer.
: The paper is available for 1-sided printing and automatic 2-sided printing.
: The paper is available for only 1-sided printing.
: The paper cannot be used for printing.
Paper Size
(short edge x long edge)
Paper Source
Multi-purpose
Tray Cassette 1
Cassette 2,
Cassette 3*
1
,
Cassette 4*
1
(Optional)
A3 (297.0 mm x 420.0 mm)
B4 (257.0 mm x 364.0 mm)
A4 Portrait*
2
(210.0 mm x 297.0 mm)
A4 Landscape*
3
(210.0 mm x 297.0
mm)
B5 Portrait*
2
(182.0 mm x 257.0 mm)
A5 Portrait*
2
(148.0 mm x 210.0 mm)
A5 Landscape*
3
(148.0 mm x 210.0
mm)
12 x 18 (12.00 in. x 18.00 in.)
Ledger (11.00 in. x 17.00 in.)
Legal (8.50 in. x 14.00 in.)
Letter Portrait*
2
(8.50 in. x 11.00 in.)
Letter Landscape*
3
(8.50 in. x 11.00 in.)
Executive Portrait*
2
(7.25 in. x 10.50 in.)
Custom paper size Portrait*
2
*
4
*
5
*
7
*
8
*
9

10
*
1
Cassette 3 and Cassette 4 can be used only for LBP9600C.
*
2
Portrait: The short edges of the paper are parallel to the front side of the printer.
*
3
Landscape: The long edges of the paper are parallel to the front side of the printer.
*
4
Can be loaded only when the LIPS LX printer driver is used.
*
5
Automatic 2-sided printing can be performed on the custom size paper whose short edges are 148.0 to 297.0 mm
and long edges are 182.0 to 297.0 mm.
*
6
Automatic 2-sided printing can be performed on the custom size paper whose short edges are 148.0 to 297.0 mm
and long edges are 182.0 to 450.0 mm.
*
7
The custom size paper whose short edges are 127.0 to 297.0 mm and long edges are 127.0 to 297.0 mm can be
loaded.
*
8
The custom size paper whose short edges are 182.0 to 297.0 mm and long edges are 182.0 to 297.0 mm can be
loaded.
*
9
The custom size paper whose short edges are 148.0 to 297.0 mm and long edges are 210.0 to 297.0 mm can be
loaded.
*
10
The custom size paper whose short edges are 76.2 to 320.0 mm and long edges are 127.0 to 457.2 mm can be
loaded.
When the paper whose short edges are more than 312 mm is used, however, streaks may appear on both sides of
the paper.
*
11
The custom size paper whose short edges are 148.0 to 297.0 mm and long edges are 182.0 to 431.8 mm can be
loaded.
† The paper whose short edges are 100.0 to 147.9 mm can be loaded by using the optional small size paper
adjuster.
*
12
The custom size paper whose short edges are 210.0 to 297.0 mm and long edges are 210.0 to 431.8 mm can be
loaded.
*
13
The long-size paper whose short edges are 210.0 to 297.0 mm and long edges are 457.3 to 1,200.0 mm can be
loaded.
Custom paper size Landscape*
3
*
6
*
10
*
11
*
12
Long size *
13
Postcard Landscape*
3
(100.0 mm x
148.0 mm)
Reply postcard Landscape*
3
(148.0 mm
x 200.0 mm)
4 on 1 postcard Portrait*
2
(200.0 mm x
296.0 mm)
Envelope
YOUNAGA No. 3 Landscape*
3
(120.0
mm x 235.0 mm)
NAGAGATA No. 3 Landscape*
3
(120.0 mm x 235.0 mm)
KAKUGATA No. 2 Landscape*
3
(240.0 mm x 332.0 mm)
Paper Size
(short edge x long edge)
Paper Source
Multi-purpose
Tray Cassette 1
Cassette 2,
Cassette 3*
1
,
Cassette 4*
1
(Optional)

11
IMPORTANT
About print speed
 The print speed may drop depending on the settings for the paper size, paper type,
orientation, and number of copies.
 When continuously printing paper whose width is 279.4 mm (Letter size) or less, the
print speed may drop gradually.
 Printing speed drops in the following cases.
- When printing is performed with [
スーパーファイン（1200 dpi）
] in [
解像度
] selected
- When printing is performed on paper whose width is more than 300 mm
Paper Type
The following shows the paper types that can be used with this printer.
: The paper is available for 1-sided printing and automatic 2-sided printing.
: The paper is available for only 1-sided printing.
: The paper cannot be used for printing.
Paper Type
[カカ
カカセセ セセッッ ッットト トト NN NN
（（
（（NN NN== ==11 11、、 、、22 22、、 、、33 33、、 、、
44
44）） ））
用用
用用紙紙 紙紙種種 種種類類 類類 ]*
1 in
the セセ
セセッッ ッットト トトアア アアッッ ッッププ ププ
Menu
Paper Source
Multi-purpose
Tray Cassette 1
Cassette 2,
Cassette 3*
1
,
Cassette 4*
1
(Optional)
Plain
paper
*2
75 to 90 g/m
2
[普通紙 ]
[ラフ紙 ]*
3
60 to 74 g/m
2
[普通紙 L ]
91 to 105 g/m
2
[普通紙 H ]
[ラフ紙 ]*
3
Heavy
paper
106 to 128 g/m
2
[厚紙 1 ]
129 to 163 g/m
2
[厚紙 2 ]
164 to 216 g/m
2
[厚紙 3 ]
Transparency
(black-and-white printing
only)
[OHP フィルム ]
Label [ ラベル用紙 ]
Coated paper
100 to 129 g/m
2
[コート紙 1 ]
130 to 160 g/m
2
[コート紙 2 ]
161 to 220 g/m
2
[コート紙 3 ]

12
*
1
Cassette 3 and Cassette 4 can be used only for LBP9600C.
*
2
Recycled paper can be used as plain paper.
*
3
Specify [ ラフ紙 ] for this item when a paper jam occurs or when you want to improve the fixation on printing coarse
paper (75 to 105 g/m
2
) with [ 普通紙 ] or [ 普通紙 H
] selected.


Plain paper
This printer can print plain paper (60 to 105 g/m
2
) of the following sizes.

Standard paper size: A3, B4, A4, B5, A5, 12 x 18, Ledger (11 x 17), Legal, Letter,
Executive

Custom paper size: Short edges 76.2 to 320.0 mm; Long edges 127.0 to 457.2 mm

Long size: Short edges 210.0 to 297.0 mm; Long edges 457.3 to 1,200.0 mm
† The following plain paper is available for automatic 2-sided printing.
- A3, B4, A4, B5, A5, Ledger (11 x 17), Legal, Letter, or Executive size paper
- Custom size paper whose short edges are 148.0 to 297.0 mm and long edges are
182.0 to 450.0 mm
† Recycled paper can be used as plain paper.


Heavy paper
This printer can print heavy paper (106 to 216 g/m
2
) of the following sizes.

Standard paper size: A3, B4, A4, B5, A5, 12 x 18, Ledger (11 x 17), Legal, Letter,
Executive

Custom paper size: Short edges 76.2 to 320.0 mm; Long edges 127.0 to 457.2 mm

Long size: Short edges 210.0 to 297.0 mm; Long edges 457.3 to 1,200.0 mm
† The following heavy paper (106 to 163 g/m
2
) is available for automatic 2-sided printing.
- A3, B4, A4, B5, A5, Ledger (11 x 17), Legal, Letter, or Executive size paper
- Custom size paper whose short edges are 148.0 to 297.0 mm and long edges are
182.0 to 450.0 mm
IMPORTANT
About print speed
The print speed drops when printing on heavy paper.
Postcard/Reply postcard/
4 on 1 postcard [はがき ]
Envelope [ 封筒 ]
Paper Type
[カカ
カカセセ セセッッ ッットト トト NN NN
（（
（（NN NN== ==11 11、、 、、22 22、、 、、33 33、、 、、
44
44）） ））
用用
用用紙紙 紙紙種種 種種類類 類類 ]*1
in
the セセ
セセッッ ッットト トトアア アアッッ ッッププ ププ
Menu
Paper Source
Multi-purpose
Tray Cassette 1
Cassette 2,
Cassette 3*
1
,
Cassette 4*
1
(Optional)

13


Transparency
This printer can print A4 and Letter size transparencies.
IMPORTANT
Precautions when using transparencies

Transparencies can only be printed in black and white.

Thoroughly fan the transparencies before loading them as they may stick to each other.
 Ta ke care not to mark or stain the printing surface of the transparencies with
fingerprints, dust, or oil.

The print speed drops when printing on transparencies.


Label
This printer can print labels of the following sizes.
However, it is recommended to use A4 or Letter size labels for the optimum print quality.
 Standard paper size: A3, B4, A4, B5, A5, 12 x 18, Ledger (11 x 17), Legal, Letter,
Executive

Custom paper size: Short edges 76.2 to 320.0 mm; Long edges 127.0 to 457.2 mm

Long size: Short edges 210.0 to 297.0 mm; Long edges 457.3 to 1,200.0 mm
IMPORTANT
Precautions when using labels

Using the following types of labels may result in paper jams that are difficult to clear or
may result in damage to the printer.
-Peeled labels or partly used labels
- Coated labels that are easily peeled off from the backing sheet
- Labels with uneven adhesive
 The print speed drops when printing labels.
NOTE
When printing labels
Depending on the label type, the output paper may curl excessively. In this case, perform
printing using either of the following methods.

Taking out one sheet at a time each time it is output

Changing the loading orientation of the labels before printing
- If the labels curl when they are loaded in portrait orientation, load them in landscape
orientation.
- If the labels curl when they are loaded in landscape orientation, load them in portrait
orientation.


Coated paper
This printer can print coated paper (100 to 220 g/m
2
) of the following sizes.
However, it is recommended to use A3, A4, or Letter size coated paper for the optimum
print quality.
 Standard paper size: A3, B4, A4, B5, A5, 12 x 18, Ledger (11 x 17), Legal, Letter,
Executive

Custom paper size: Short edges 76.2 to 320.0 mm; Long edges 127.0 to 457.2 mm

Long size: Short edges 210.0 to 297.0 mm; Long edges 457.3 to 1,200.0 mm

14
† The following coated paper (100 to 160 g/m
2
) is available for automatic 2-sided printing.

A3, B4, A4, B5, A5, Ledger (11 x 17), Legal, Letter, or Executive size paper

Custom size paper whose short edges are 148.0 to 297.0 mm and long edges are 182.0
to 450.0 mm
IMPORTANT
Precautions when using coated paper
The print speed drops when printing on coated paper.


Postcard
This printer can print postcards, reply postcards, and 4 on 1 postcards.
IMPORTANT
Precautions when using postcards

Using the following types of postcard may deteriorate print quality or result in paper
jams.
- Inappropriate size postcards other than Postcard, Reply postcard, and 4 on 1
postcard
- Creased reply postcard
-Postcards and reply postcards for ink jet printers
 If the postcards are curled, flatten the curls by warping them in the opposite direction
before loading them.
 The print speed drops when printing on postcards.

15
 Envelope
This printer can print the following envelopes.
IMPORTANT
Precautions when using envelopes

Using the following types of envelopes may result in paper jams that are difficult to clear
or may result in damage to the printer.
-Envelopes with fasteners or snaps
-Envelopes with address windows
-Envelopes with adhesive on the surface
-Wrinkled or creased envelopes
-Poorly manufactured envelopes in which the glued parts are uneven
- Irregularly-shaped envelopes

Before loading envelopes, flatten the stack of envelopes to release any remaining air,
and press the fold lines along the edges tight.

Do not print on the reverse side (glued side) of envelopes.

The print speed drops when printing on envelopes.
NOTE
When printing on envelopes
They may become creased.
YOUNAGA No. 3
(120 mm x 235 mm )
NAGAGATA No. 3
(120 mm x 235 mm)
KAKUGATA No. 2
(240 mm x 332 mm)

16
Printable Area
NOTE
If you want to extend the printable area
Specify the following settings in the printer driver.
1. Click [Finishing Details] in the [Finishing] sheet.
2. Select the [Print with Upper Left of Sheet as Starting Point] check box.
† The edges of the printout may be partly missing depending on the property of the
document to be printed.
If the paper width exceeds 315 mm
The right and left margins increase respectively as follows.
† The right and left margins may not be even.
Plain Paper, Heavy Paper, Transparencies, Labels, and Coated Paper
You can print in the area up to 5 mm of the edges of the paper.
Paper width Margin
315 mm 5 mm
316 mm 5.5 mm
317 mm 6 mm
318 mm 6.5 mm
319 mm 7 mm
320 mm 7.5 mm
5 mm
5 mm
5 mm5 mm

17
Postcard/Reply Postcard/4 on 1 Postcard
You can print in the area up to 5 mm of the edges of the postcards.
IMPORTANT
When printing on postcards
It is recommended that you configure the document to print the data smaller than the
printable area.
When printing data in the entire printable area, you may not be able to obtain the
optimum print quality.
Envelope
This printer can print on the following area.
You may have to change the printable area before printing, depending on the
application you use.
(Sample: YOUNAGA No. 3/NAGAGATA No. 3)
IMPORTANT
When a part of the printed zip code is missing
Specify the following settings in the printer driver.
1. Click [Finishing Details] in the [Finishing] sheet.
2. Select the [Print with Upper Left of Sheet as Starting Point] check box.
5 mm
5 mm
5 mm5 mm
123-4567
200 mm
148 mm
5 mm
5 mm
5 mm5 mm
123-4567
100 mm
148 mm
10 mm
10 mm10 mm
10 mm
120 mm
235 mm

18
Paper Which Requires Attention Before Use
Using the following types of paper may cause influence to the printout results or
printer in some cases.
Paper That Was Stored Poorly
Creased or folded paper
Torn or damaged paper
Wrinkled paper
Curled paper
Wet or moist paper
Paper with rough edges
Irregularly-shaped paper
Paper with Holes or Perforations
Paper with binding holes
Paper with perforations
Paper with Adhesive or a Special Coating
Heat-sensitive paper
Paper with adhesive
Carbon paper
Treated color paper
Specially coated paper (coated paper for ink jet printers, etc.)
Previously Printed Paper
Paper that has already been printed by a copy machine or another printer (The reverse
side of the paper is also not usable. Using the multi-purpose tray, however, you can
perform 2-sided printing manually on the other side of paper previously printed by this
printer. You cannot print on the printed side again.)
Paper That Is Difficult for Toner to Adhere to
Paper with rough surfaces
Paper containing thick fibers
Paper with an extremely rough or smooth surface
Paper that is thicker or thinner than the specified usable paper
See "Paper Type," on p. 11.
IMPORTANT
About paper with staples, clips, ribbons or tape
This kind of paper may result in the printer malfunction or damage to the printer.
About paper that contains ink that melts, burns, evaporates or emits harmful
gases at or lower than the heating temperature of the fixing unit
This kind of paper may result in the printer malfunction or damage to the printer.

19
Paper Capacity of Paper Source
: The paper source cannot be used.
* Cassette 3 and Cassette 4 can be used only for LBP9600C.
Paper Type
Paper Source
Multi-purpose
Tray Cassette 1
Cassette 2,
Cassette 3*,
Cassette 4*
(Optional)
Plain paper (Ex. 64 g/m2)Approx. 100
sheets
Approx. 250
sheets
Approx. 550
sheets
Heavy paper (Ex. 128 g/m2)Approx. 80
sheets
Approx. 200
sheets
Approx. 400
sheets
Heavy paper (Ex. 163 g/m2)Approx. 50
sheets
Transparency (black-and-white
printing only)
Approx. 50
sheets
Label Approx. 40
sheets
Coated paper Approx. 50
sheets
Postcard Approx. 50
sheets
Reply postcard Approx. 50
sheets
4 on 1 postcard Approx. 50
sheets
Envelope Approx. 10
sheets
