Canon 1318C002 User manual

ENGLISHENGLISH
MULTIMEDIA PROJECTOR
User’s Manual
/

i
Trademark Recognition
Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued
registrations and pending applications in other countries throughout the world.
HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks
or registered trademarks of HDMI Licensing LLC in the United States and other
countries.
HDBaseT is a trademark of HDBaseT Alliance.
Crestron Connected and the Crestron logo are trademarks or registered
trademarks of Crestron Electronics, Inc. in the United States and other countries or
both.
All other product names used in this manual are the properties of their respective owners and are
acknowledged.
Copyright Notice
Please note that enlarging or reducing the size of an image for commercial purposes or public
presentation may infringe on the legally protected copyright or the copyright holder of the original
material.
About Trademarks
■Ethernet is a registered trademark of Xerox Corporation.
■Microsoft, Windows, Windows Vista, Windows 7, Windows 8 and Aero are registered trademarks or
trademarks of Microsoft Corporation in the United States and / or other countries.
■Mac, Mac OS and Macintosh are trademarks of Apple Inc., registered in the United States and / or
other countries.
■ HDMI, the HDMI logo and High-Denition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing, LLC.
■PJLink is a registered trademark, or an application has been submitted for trademark, in Japan, the
United States and / or other countries or regions.
■AMX is a trademark of AMX Corporation.
■Crestron®, Crestron RoomView®, and Crestron Connected™ are registered trademarks of Crestron
Electronics, Inc.
Ensure Network Security
Take measures to ensure network security. Note that Canon is not liable in any way for direct or indirect
loss from network security incidents, such as unauthorized access.
Examples of Security Measures
■Use in an intranet environment.
■Assign a private IP address.
■ Use behind a rewall.
■Change passwords regularly.

ii
♦Projector Installation Notice
■Allow at least 50 cm clearance around the exhaust vent.
■Ensure that the intake vents do not recycle hot air from the exhaust vent.
■When operating the projector in an enclosed space, ensure that the surrounding air temperature
within the enclosure does not exceed operation temperature while the projector is running, and the
air intake and exhaust vents are unobstructed.
■Do not block the air intake or air outlet of the cooling fan. If the air intake or air outlet is blocked,
heat cannot be released from inside the projector, which may cause malfunction.
♦Verify Installation Location
■Turn on Altitude Mode when located in high altitude areas.
■ When installation the bracket, make sure the weight limit is not exceed and rmly secured.
■ Avoid installing at high temperature, insufcient cooling and heavy dust locations.
■ Keep your product away from uorescent lamps to avoid malfunction caused by IR interference.
■The power cord and signal cable should be connected before power on the projector. During the
projector starting and operating process, DO NOT insert or remove the signal cable or the power
cord to avoid damaging the projector.
♦Cooling notes
Exhaust vent
■Exhaust vent location should not be in front of the lens of other projector to avoid causing illusions.
■Keep the exhaust vent at least 50 cm away from the inlets of other projectors.
Air intake vent
■Make sure there is no object blocking air intake vent within 30 cm.
■Keep the air intake vent away from other heat sources.
■Do not install the projector in a location that is damp, or where there is a lot of dust, oily smoke or
tobacco smoke.
♦Power Safety
■Only use the supplied power cord.
■Do not place anything on the power cord. Place the power cord where it will not be in the way of
foot trafc.
■The wall outlet must be able to meet the power demands of the device.
About this manual
This manual is intended for qualied technicians / end users and describes how to install and operate
the DLP projector. Wherever possible, relevant information such as an illustration and its description has
been kept on one page. It is suggested that you only print sections that are relevant to your needs.

iii
