PRESENTING EXCELLENCE.
Rich Color. Deep Contrast. Sharp Resolution.
W U X 1 0
SX7
S X 6
SX80
SX60
SX800
X 7 0 0

World’s rst WUXGA LCOS projector
Canon:
Focused on
Leadership
LOOKING FOR EXCELLENCE IN
PRESENTATION TECHNOLOGY? YOU’VE
COME TO THE RIGHT SOURCE. FOR OVER
70 YEARS, CANON’S
HERITAGE IN OPTICS AND
COLOR MANAGEMENT
REMAINS UNRIVALLED.
UNLIKE OTHER
MANUFACTURERS,
CANON’S MAIN
FOCUS IS THE OPTICAL SCIENCES. WE
SPEND SIGNIFICANT R&D RESOURCES
IN CULTIVATING GROWTH IN THE
FIVE “IMAGING ENGINES”
— IMAGE
CAPTURING, ELECTROPHOTOGRAPHY,
INKJET PRINTING, PHOTOLITHOGRAPHY
AND DISPLAYS
— AND THESE EXCITING
BREAKTHROUGHS BENEFIT EVERY CANON
PRODUCT, INCLUDING, OF COURSE, CANON
REALiS PROJECTORS WITH LCOS (LIQUID
CRYSTAL ON SILICON) TECHNOLOGY. FROM
THE CREATION OF THE INCOMPARABLE
CANON LENS TO CANON’S HIGH-ACCURACY
COLOR MANAGEMENT SYSTEM,
CANON OPTICS ARE BEST-OF-BREED.
THE IMAGE OF PERFECTION.
2
FPO

OUR PIXELS ARE REALLY CLOSE
What’s the LCOS technology
advantage? Lattice-free, seamless
images. Say goodbye to annoying
visual distractions common with LCD
projectors, such as the grid-like pixel
patterns known as “screen door effect.”
Say goodbye to muted color and detail.
LCOS produces exceptional color,
intricate detail, easy-to-read type
(even at 7pt.) and HD images that leap
off the screen in breathtaking quality
and integrity. The difference is in the
details. In transmissive LCD projectors,
colors become easily muted and text
appears faint and uneven because the
gaps between pixels are huge. REALiS
LCOS projectors minimize those gaps,
creating detailed, color-rich images
with text that is crisp and dark.
Single-chip DLP projectors produce
troublesome red-green-blue spots
when viewers shift their gaze. LCOS
solves this “rainbow effect” by
achieving subtle color gradations. Even
tones of black and gray look better with
LCOS than they do with DLP.
There’s no comparison. The advantages
of LCOS are easy to see for both
presenter and audience alike: rich color,
deep contrast, ne grain and sharp
resolution.
There’s no clearer choice than REALiS.
LCOS vs. LCD or DLP:
What can REALiS
do for you?
3-panel LCOS 3-panel LCD 1-chip DLP
3-panel LCOS 3-panel LCD 1-chip DLP
3-panel LCOS 3-panel LCD 1-chip DLP
3-panel LCOS 3-panel LCD 1-chip DLP
Display of ne lines
CAD images, blueprints
and ne lines are reproduced
smoothly and accurately
with REALiS high-resolution
projectors.
Display of color
and detail
REALiS SXGA+ models
present exceptional color
and intricate detail.
Display of small text
By using more pixels for each
letter, REALiS projectors
can display easy-to-read type,
as small as 7pt., often illegible
on LCD-based XGA projectors.
3
Display of ne
grained objects
REALiS lattice-free images
ensure smooth, crisp
displays of ne grained
objects, including metallic
surfaces, typically dulled by
LCD projectors.
All images are simulated close-ups.

Taking LCOS to the Next Level
The AISYS
Advantage
Canon’s proprietary AISYS optical system
makes it possible to incorporate LCOS
reective LCD panels in a compact
projector, previously considered an
impossible goal in projector design.
4OUR PIXELS ARE REALLY CLOSE
Rarely satised and never complacent,
count on Canon — and only Canon —
to develop a method for making
LCOS technology even better. Our
proprietary AISYS optical system
efciently utilizes and equalizes light
from the projector lamp, thereby
boosting the performance of both key
functions: brightness and contrast.
AISYS, which stands for Aspectual
Illumination System, increases brightness
and contrast together; one function
never sacrices the other, and that’s a
capability only Canon can deliver.
Image quality is optimized thanks
to new optical elements that were
incorporated into the illumination optical
system, enhancing the uniformity
of light. Technically speaking, the
Polarizing Beam Splitters (PBS) in the
color separation and recombination
system are now designed for more
precise light control. AISYS even allows
us to produce a more compact unit,
reducing unit weight and cost.
What does all this science mean to you?
It means no one does LCOS like
Canon. REALiS brings you a whole
new standard in bright, beautiful,
high-denition, high-contrast images.
REALiS assures a captivated audience.
REALiS assures condent presenters.
REALiS brings you the next level in
LCOS performance.
AISYS OPTICAL SYSTEM

REALiS Multimedia Projectors come in a variety of models and feature sets
to match your discerning needs. Select the solution that’s right for you.
3200 Lumens
4000 Lumens
3500 Lumens
2500 Lumens
4000 Lumens
3000 Lumens
3000 Lumens
Whether you’re in the engineering,
architecture or business eld...in
healthcare, higher education or
government...in ne arts, fashion
or graphic design...if you’re in the
business of making impressions,
impress your audience with REALiS.
Engineering, Architecture & Business
• The ne lines of blueprints and
renderings are visible in clear detail.
• Contrast and accurate shadowing
maximize form and texture.
• Tiny type is clearly readable and
complex charts spring to life.
Healthcare, Higher Education
& Government
• Anatomical imagery and
microscopic photography are
recreated true-to-life.
• Historical documents and photos
display stunning resolution.
• Intricate charts, maps and grids
are easily viewed from a distance.
Fine Arts, Fashion & Graphic Design
• Even the subtlest hues and color
gradations are reproduced with
amazing clarity.
• Crisp contrast and accurate grayscale
help produce a true picture.
• Fine detail and razor resolution add
depth, dimension and drama.
Project an
Enhanced Image
OUR PIXELS ARE REALLY CLOSE
WUX10 Cutting-Edge Hi Definition
•1.5x optical powered zoom lens
•Full 10-bit image processing
•HDMI™ (V.1.3 with Deep Color)
•Supports HD 1080p signals
SX7 Astounding Color Reproduction
•1.7x optical powered zoom lens
•Adobe RGB color-match system
•1000:1 contrast ratio
SX6 Exceptional Image Quality
•1.7x optical powered zoom lens
•Adobe RGB color-match system
•1000:1 contrast ratio
SX60 Whisper-Quiet Operation
•1.7x optical powered zoom lens
•1000:1 contrast ratio
•2000:1 contrast ratio in Home Cinema mode
X700 High Quality – Fast, Easy and Quiet
•1.7x optical powered zoom lens
•1000:1 contrast ratio
SX800 Affordable and Reliable
•1.5x optical powered zoom lens
•900:1 contrast ratio
SX80 Versatile High Performance
•1.5x optical powered zoom lens
•HDMI™ (V.1.3 with Deep Color)
•Supports HD 1080p signals
•PC-free presentation, PictBridge
•900:1 contrast ratio
LCOS
LCOS
LCOS
LCOS
LCOS
LCOS
LCOS
WUXGA 1920 x 1200
SXGA+ 1400 x 1050
SXGA+ 1400 x 1050
SXGA+ 1400 x 1050
XGA 1024 x 768
SXGA+ 1400 x 1050
SXGA+ 1400 x 1050
NEW!
NEW!
5
NEW!

REALiS Simple.
REALiS
Spectacular.
SIMPLY PUT, OUR CANON REALiS
MULTIMEDIA PROJECTOR LINEUP
PROVIDES POWERFUL FEATURES AND
LEADING PERFORMANCE THAT
EXCEED THE MOST DEMANDING
QUALITY EXPECTATIONS
— AND WE DO
SO ON AN ORDER OF MAGNITUDE FAR
BEYOND OTHER SYSTEMS. YES, THERE
ARE OTHER PROJECTORS AVAILABLE,
BUT CANON SIMPLY DOES IT BEST.
Genuine Canon Optics
In Canon’s REALiS Series, the lens
conguration is a six-group assembly
with 12 elements and four moving
groups, featuring one UD lens and two
high-precision double-sided aspherical
lenses. The result: amazing clarity.
WUXGA Super-High Resolution
This exciting new technology means
Canon now offers the world’s rst
WUXGA LCOS projector, featuring
superior brightness, spectacular
image quality and exible operational
functions — all in a conveniently
compact and cost-effective package.
In fact, the latest notebook PCs
already support native WUXGA, an
ideal solution for today’s HD and
Blu-Ray content. (See chart A)
1.5x Power Zoom Lens
The new 1.5x Powered Zoom Lens has
been engineered to accommodate
LCOS reective LCD panels. And,
with our new 10:0 lens offset, REALiS
projectors can now be pulled back
even further without the image hitting
the table or the ceiling. This minimizes
the need for keystone correction.
(See chart on opposite page.)
1.7x Power Zoom Lens
The 1.7x Powered Zoom Lens gives
you a diagonal screen size range of
40” when placed 3.9’ away and 100”
at 9.8’ away. With a maximum screen
size of 300”, REALiS adapts to virtu-
ally any room. The incorporation of
a dual-sided aspherical lens in the
optical array suppresses distortion
and keeps peripheral image distortion
to an absolute minimum. The result is
enhanced resolution for accurate re-
production of highly detailed images.
UD lens
Two high-precision double-sided aspherical lenses
6
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
Chart A
Genuine Canon Optics

C
SX7/SX6 Color Space
Adobe RGB support
Adobe RGB
sRGB
Amazing Color Quality and Control
Canon’s high-accuracy Color
Management System (CMS) ensures
accurate color reproduction for
an extended color space and
compensates for color variances
due to lighting differences. The
advantage: true HD-quality color
even in the toughest conditions.
Crisp Blacks Enhance Shadow Detail
Precise control prevents the excess
leakage of light, producing rich,
detailed gradations even in the
shadowed portions of images —
recreating depth and dimension
with stunning drama and realism.
Adobe RGB Color Match System
Proprietary color lters incorporated
into the AISYS optical system deliver
exceptional accuracy and detail in both
Adobe RGB and sRGB modes. This is
ideal for professional photography,
design, publishing, printing and ne
art, where color integrity is crucial.
6-Axis Color Adjustments
A 6-Axis Color Adjustment function
meets and exceeds the demands of
professionals with demanding color
requirements. Both hue and saturation
can be adjusted independent of RGB
and CMYK color axes.
Canon Throw Distance WUX10 SX7 SX6 SX80 SX6O SX80O X700
4:3 ASPECT RATIO
Projector screen size 40” 80” 100” 150” 200” 300”
Screen width 2’8” 5’4” 6’8” 10’0” 13’4” 20’O”
Projection distance (Wide -Tele) 3’11”- 5’10” 7’11” - 11’8” 9’10” - 14’6” 14’10” - 21’10” 19’9” - 29’1” 29’7” - 29’10”
SX7, SX6, SX80, SX60, SX800, X700 3’11”- 6’6” 7’9” - 13’0” 9’9” - 16’2” 14’7” - 24’4” 19’6” - 29’6” 29’2” - 29’6”
16:9 ASPECT RATIO
Projector screen size 40” 80” 100” 150” 200” 300”
Screen width 2’ll” 5’lO” 7’3” 10’11” 14’6” N/A
Projection distance (Wide -Tele) 4’4” - 6’4” 8’7” - 12’8” 10’9” - 15’10” 16’1” - 23’9” 21’6” - 29’10” N/A
SX7, SX6, SX80, SX60, SX800, X700 4’3” - 7’1” 8’6” - 14’1” 10’7” - 17’8” 15’11” - 26’6” 21’3” - 29’6” N/A
16:10 ASPECT RATIO
Projector screen size 40” 80” 100” 150” 200” 300”
Screen width 2’10” 5’8” 7’1” 10’7” 14’2” 21’2”
Projection distance (Wide -Tele)
WUX10 4’2” - 6’2” 8’4” - 12’4” 10’6” - 15’5” 15’8” - 23’1” 20’11” - 29’10” N/A
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
Proprietary Color Management
Original Color Adjusted
A bluer sky
Original Color Adjusted
More orange in the sunset
7

Screen Aspect Modes
Canon REALiS projectors operate
brilliantly in both 4:3 aspect ratio and
16:9 aspect ratio. So, no matter which
screen you own, you won’t need to
purchase another.
Dynamic Gamma
When dynamic gamma is “on,”
gamma is automatically adjusted to
optimum values. This feature is vital
for projecting rapidly moving images.
Each frame is displayed with optimum
contrast balance to prevent washed-
out whites and blocked-up blacks.
AC Projector Lamp
A newly engineered AC lamp boosts
the purity of projected reds and
greens. Built for extended life as well,
it not only ensures more vivid images,
it also means a better value.
Image Modes
REALiS projectors allow you to select
the image mode that best suits the
characteristics of your content. For
example, select “Presentation” mode
for briengs and conferences or
“Adobe RGB” or “sRGB” when color
delity is essential. The model SX60
even comes equipped with a home
cinema lter, making it ideal for this
entertainment application. (see below)
B
Presenter-Friendly Use
Quiet Operation
Why do most projectors make so
much noise? It’s the cooling system
needed to dissipate the considerable
heat generated by the unit. On all
REALiS models, however, ventilation
vents, the cooling fan and the layout
of the optical array have all been
engineered with noise prevention in
mind, resulting in exceptionally quiet
operation.
LED Illumination
LEDs on most REALiS models
indicate the projector’s connection
and operation status at a glance.
When several image input devices
are connected, an LED indicates
which image signal is selected as
the input. The LED illumination
on the operation panel ashes to
indicate start-up, end of presentation
and other commands.
16:9 Screen Aspect Mode
Watch 4:3 content
on a 16:9 screen
Watch 16:9 content
on a 16:9 screen
Digital Image Shift DOWN
Digital Image Shift UP
16:9 Digital Image Shift
Before Shift
Versatile
Performance
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
8
WUX10 SX7 SX6 SX80 SX6O SX800 X700
• Luminous spectrum of DC & AC lamps
= Standard Prioritizes reproduction
of white, closely matching the image
characteristics of the original
= Presentation Produces a bright,
high-contrast display for ease of viewing
text and numerical data
= Movie Suitable for displaying
theatrical content; image quality
emphasizes gradation in dark areas
= Movie & Photo For display of video
and digital camera images; clearly defines
gradations and improves color reproduction
= Adobe RGB = sRGB Reproduces
colors in the appropriate color space for
accurate projection of content produced
in specific standardized formats
= Home Cinema Controls brightness
while enhancing contrast to a ratio of
2000:1; for display of theatrical content
in pitch-dark rooms
Brightness > > > >
WUX10 SX80 SX7 SX6 SX6O SX800 X700

Remote Control Convenience
These exible remote control features
enable presenters to drive home a
point without ever breaking stride.
Digital Zoom – enlarges a selected
single area of the screen, like specic
data in a graph; images can be
enlarged up to 12x*.
Freeze – lets you freeze the on-screen
display for pauses in the presentation,
such as changing PC connections or
checking the subsequent image le.
Spot – highlights a portion of the
image on the screen; the spotlight can
be made larger or smaller, or it can
be moved anywhere on the screen.
Auto Setup
These smart features make preparing
for a presentation quick and easy.
Just press the Auto Setup button,
and within seconds your input source
is connected, distortion is corrected,
focus is sharpened and color is
balanced.
*The SX800 Auto-Set-up feature does not include
Auto Focus and Auto Screen Color
Auto Keystone – automatically
calculates the angle of the projector
and corrects for image distortion.
Vertical (+/- 20°).
Auto Screen Color – automatically
adjusts the color balance according to
the projection surface’s color, such as
a green chalkboard.
Auto Input – automatically detects
and identies the image signal from
the input terminal and selects it
for display.
Auto Focus – automatically measures
the distance to the screen using an
infrared sensor, and adjusts the focus
in as little as one second.
Direct Power On
All models can be
switched on and off
from a central control
terminal without having
to press the buttons on
the unit. This permits remote operation
when the unit is mounted overhead.
When the Direct Power setting is “on,”
and power is introduced, the projector
starts up automatically and is ready to
display in about 20 seconds.
Guide Functions
All REALiS models display guide
messages in an on-screen window,
providing feedback on invalid
operations and setup tips.
Off and Go
All REALiS models are equipped with
an internal charging system to run the
fan. This makes it possible to unplug
the projector and pack up and go
immediately after using it, while the
unit continues to cool down.
*Resolution of enlarged section is reduced. Original Adjusted
Without Color Correction With Color Correction
Before Auto Focus
Guide functions display
A f t e r A u t o F o c u s
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
9

Flexible Compatibility
REALiS Multimedia Projectors
are compatible with a variety of
image signals, including HDTV.
Convenient.
Connectable.
Compatible.
Digital RGB Input/
Analog RGB Output (DVI-I)
HDMI In
Analog RGB Input
Component Input
Monitor Output
USB Port
S-Video Terminal
Video Input
Stereo Audio Input
Stereo Audio Output
RS-232C/Controller
Network
1
2
3
4
5
6
7
8
9
10
11
12
REALiS MULTIMEDIA PROJECTORS
ARE NOT ONLY EASY FOR
PRESENTERS TO USE, BUT ALSO
FOR ORGANIZATIONS TO INSTALL,
NETWORK AND MAINTAIN. OUR
TECHNOLOGY IS ENGINEERED
FOR SEAMLESS INTEGRATION
WITH A VARIETY OF INFORMATION
TECHNOLOGY, NETWORK
MANAGEMENT AND AUDIO/VISUAL
ENVIRONMENTS. IN A PHRASE,
IT’S BUILT TO FIT IN.
SX80
SX800
WUX10 SX7 / X700
SX6 / SX60
1 2 3 4 5 6
2 1 3 4
8 9
9 9 10 11 12987
9 9 10
113 3 4
1 3 4 5 1 3 4 5
6
Network Management
With the optional network adapter,
you can operate the projector from a
networked PC. Multiple projectors can
also be managed remotely this way. This
feature makes it possible to operate
ceiling-mounted units or other remote
installations from a single PC screen.
The WUX10 and the SX80 come with a
network port built in.
Audio Input & Output
Audio input source will switch auto-
matically to match the image signal
source. Audio output terminals permit
connection to external audio devices,
making it easy to control sound levels
from the projector’s remote control unit.
PC-Free Presentations
Need to share media not resident on a
PC? No problem with our convenient
built-in interfaces. Connect a USB
memory stick directly into the projector,
connect a PictBridge-compatible digital
camera via USB cable or use the HDMI
terminal for instant display of HD video.
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
WUX10 SX7 SX6 SX80 SX6O SX800 X700
10
99 99 10 10 99
11
11
11
128
8
8 6
9 7
7

*Only included with the SX800. **Not included with the SX800. ***Not included with the WUX10, SX80, and SX800.
REALiS projectors come with everything you need to begin presenting right out of the box.
To increase the performance value of your REALiS projector, add these smart accessories.
Make it real.
Make it REALiS.
Remote Control
Replacement Lamp
RS-LP02
(SX6)
RS-LP03
(SX60)
RS-LP04
(WUX10, SX7, X700)
RS-LP05
(SX80, SX800)
Ceiling Mount
RS-CL07
(WUX10, SX7,
SX6, SX60, X700)
RS-CL10
(SX80, SX800)
Ceiling Extension
RS-CL08†
(15.75”-23.60)
RS-CL09†
(23.60”-39.37”)
(WUX10, SX7,
SX6, SX80,
SX60, SX800, X700)
Network Adapter
RS-NA01
(SX7, SX6,
SX60, X700)
DVI-D Cable
LV-CA29
(WUX10, SX7,
SX6, SX80,
SX60, X700)
RS-232C Cable
RS-CA01 9.8’
1025V632 18”
(SX7, SX6,
SX60, X700)
Wide Angle
Converter Lens
T-WC070
(SX7, SX6,
SX60, X700)
REALiS Projector Case
(WUX10, SX7,
SX6, SX80, SX60,
SX800, X700)
Soft Case Computer Cable**
(DVI-VGA)
Computer Cable*
(VGA-VGA)
Component Video
Adapter Cable
USB Cable*** Power Cord
Kit Contents
Optional Accessories
FROM ANY DIRECTION AND
FROM ALL ANGLES, CANON HAS
PROJECTION EXCELLENCE COVERED.
THERE’S NO MORE COMPELLING
EXAMPLE OF THIS THAN OUR
TOP-TIER LINEUP OF REALiS LCOS
MULTIMEDIA PROJECTORS. IF
YOU’RE LOOKING FOR THE BEST IN
PRESENTATION TECHNOLOGY, TURN
YOUR ATTENTION TO THE LEADER
IN THE FIELD. MAKE IT REALiS.
MAKE IT CANON.
Customer Service
How do you make what’s already
better best in its class? You provide
unprecedented customer support.
Like our “Triple P” Program.
“Triple P” Program
Canon’s Projector
Protection Program, also
known as “Triple P,” is
a service program that provides a
loaner projector of equal or greater
quality in the event that your
projector needs to be repaired.
• Free to any buyer within their rst
year of new product warranty
• Canon Customer Support Center
toll-free hotline: [phone]
• Customer Service Hours: 8 a.m. to
midnight EST, Monday to Friday; 10
a.m. to 8 p.m. EST, Saturday
• For next business day delivery of
loaner, a Customer Activation Form
must be received by Canon Customer
Support Center by 3 p.m. EST
(Monday to Friday)
• Customer must provide a valid credit
card as security for the loaner unit
• Delivery not available on Saturday
and Sunday
• Program available for products
purchased and utilized in the
U.S.A. only
• Applies to Canon WUXGA, SXGA+
and XGA resolution products only
• Loaner unit based on availability
• Program subject to change at any
time without any given notice
Specications are subject to change without notice. Weight and dimensions are approximate. Images are simulated. Canon and
imageANYWARE are registered trademarks of Canon Inc. In the United States and may also be registered trademarks in other countries.
Microsoft and Windows are either registered trademarks or trademarks of the Microsoft Corporation in the United States and/or other
countries. Other names and products not mentioned above may be registered trademarks or trademarks of their respective companies.
Warning: Unauthorized recording of copyrighted materials may infringe on the rights of copyright owners and be contrary to copyright laws.
TRIPLE P
11
†
Compatible with the RS-CL07 and RS-CL10.

FEATURES
WUX10 •SX7 •SX6 •SX80 •SX6O •SX800 • X700
3200 Lumens 4000 Lumens 3500 Lumens 3000 Lumens 2500 Lumens 3000 Lumens 4000 Lumens
1000:1 900:1 900:1 1000:1
0.7” LCOS x 3 0.55” LCOS x 3 0.7” LCOS x 3 0.55” LCOS x 3 0.7” LCOS x 3
1920 x 1200 Pixels 1400 x 1050 Pixels 1024 x 768 Pixels
1920 x 1200 1600 x 1200 Max
10.9 lbs. 10.6 lbs. 10.4 lbs. 11.5 lbs. 10.1 lbs. 11.0 lbs. 10.6 lbs.
11.2” x 13.2” x 4.5” 10.5” x 13.2” x 4.5” 13.0” x 13.4” x 4.8” 10.5” x 13.2” x 4.5” 13.0” x 13.4” x 4.8” 10.5” x 13.2” x 4.5”
10:0, Fixed 9:1, Fixed 10:0, Fixed 9:1, Fixed 10:0, Fixed 9:1, Fixed
1.5x Powered 1.7x Powered 1.5x Powered 1.7x Powered 1.5x Powered 1.7x Powered
12x Digital 12x Digital 12x Digital 12x Digital 12x Digital 12x Digital
Powered (Auto/Manual) Powered Powered (Auto/Manual)
40” - 300”
3.9 - 29.9 ft (1.2 - 9.1 m) 3.9 - 29.5 ft (1.2 – 9.0 m) 3.9 - 29.9 ft (1.2 - 9.1 m) 3.9 - 29.5 ft (1.2 – 9.0 m) 3.9 - 29.9 ft (1.2 - 9.1 m) 3.9 - 29.5 ft (1.2 – 9.0 m)
1.48 - 2.18:1 1.46 - 2.43:1 1.48 - 2.18:1 1.46 - 2.43:1 1.48 - 2.18:1 1.46 - 2.43:1
88%
Digital PC Input (DVI-I)†, Analog PC Input (D-sub 15pin and/or DVI-I)††, Analog PC Output (D-sub 15pin)†††
N/A Mouse (USB) PictBridge (USB) Mouse (USB) N/A Mouse (USB)
D-Sub 9 Mini DIN D-Sub 9 Mini DIN 8 pin D-Sub 9 Mini DIN 8 pin
Yes, RJ-45 Optional Adapter Yes, RJ-45 Optional Adapter N/A Optional Adapter
275W NSH (AC) 270W NSH (DC) 230W NSH (AC) 180W NSH (DC) 230W NSH (AC) 275W NSH (AC)
2000/3000 Hours 1500/2000 Hours 2000/2500 Hours 2500/4000 Hours 2000/2500 Hours 2000/3000 Hours
36/32dB 35/31dB 30/27dB 35/31dB
AC 100 - 240V, 50/60Hz
3 years parts and labor, 120-day lamp 0130W063 1/09
©2009 CANON U.S.A., INC.
PRINTED IN U.S.A.
Product Specifications
1000:1/2000:1 in
Home Cinema mode
Stereo audio input x 3,
Stereo audio output x 1
Stereo audio input x 3,
Stereo audio output x 1
Stereo audio input x 3,
Stereo audio output x 1
Stereo audio
input x 1
Stereo audio
input x 1
†Not available on the SX800 †† DVI-I replaced by the D-sub 15pin on the SX800
††† Not available on the WUX10 and the SX800 * Component (5BNC) using analog PC input 2.
Errors and omissions excepted. Weight and dimensions are approximate. Specifications subject to change without notice.
Brightness
Contrast Ratio
Imaging Technology
Native Resolution
Max. Resolution Supported
Weight
Dimensions (WxDxH)
Lens Offset
Zoom Lens
Focus
Screen Size
Projection Distance
Throw Ratio (D:W)
Uniformity
Digital Keystone Correction
Computer Inputs/Outputs
Scanning Frequency
Video Inputs
Video Support
Audio Input/Output
Mouse Control/PictBridge
Serial Control
Network
Lamp Type
Lamp Life (Normal/Quiet)
Noise Level (Normal/Quiet)
Power Voltage
Warranty
H:15 ~ 75kHz,
V:50 ~ 85Hz,
Dot clock: 170MHz
1080p / 1080i / 1035i /
720p / 576p / 480p /
576i / 480i
1080p / 1080i / 1035i /
720p / 576p / 480p /
576i / 480i
1080i / 1035i / 720p / 575p / 480p / 575i / 480i
1080i / 1035i / 720p /
575p / 575i /
480p / 480i
1080i / 1035i / 720p /
575p / 575i /
480p / 480i
1080p / 1080i / 1035i /
720p / 576p / 576i
480p / 480i
1-800-OK-CANON
www.usa.canon.com/projectors
Canon U.S.A., Inc.
One Canon Plaza
Lake Success, NY 11042 U.S.A.
Canon Canada Inc.
6390 Dixie Road
Mississauga, Ontario L5T 1P7 Canada
Canon Latin America
703 Waterford Way, Suite 400
Miami, FL 33126 U.S.A.
Canon Mexicana, S. de R.L. de C.V.
Blvd. Manuel Ávila Camacho
No. 138, Piso 17
Col. Lomas de Chapultepec
C.P. 11000 México, D.F. México
NEW!NEW!NEW!
+ 20˚ vertical
(Auto/Manual)
+20˚ vertical (Auto/Manual),
+/-20˚ horizontal (Manual)
+20˚ vertical
(Auto/Manual)
+20˚ vertical
(Auto/Manual)
+20˚ vertical (Auto/Manual),
+/-20˚ horizontal (Manual)
+20˚ vertical (Auto/Manual),
+/-20˚ horizontal (Manual)
H:15 ~ 100kHz,
V:50 ~ 100Hz,
Dot clock: 170MHz
H:15 ~ 75kHz,
V:50 ~ 85Hz,
Dot clock: 170MHz
H:15 ~ 75kHz,
V:50 ~ 85Hz,
Dot clock: 170MHz
H:15 ~ 100kHz,
V:50 ~ 100Hz,
Dot clock: 170MHz
H:15 ~ 100kHz,
V:50 ~ 100Hz,
Dot clock: 170MHz
HDMI, Component*,
Composite
HDMI , Component*,
Composite
Component*,
Composite
DVI-I, Component*,
S-Video, Composite
DVI-I, Component*,
S-Video, Composite
DVI-I, Component*,
S-Video, Composite
