BXC910
Ca
p
le
90cm
chimne
y
Caple 90cm chimney
Technical information
Item Part Code Description Qty
1B23-2501-029-P Upper chimney bracket 1
2B20-2102-036-P Upper chimney 500mm 1
3B20-2102-008-P Lower chimney 500mm 1
4B23-2501-031-P Lower chimney bracket 1
5B64-2301-024-0 Capacitor 6µF 1
6B30-2501-025-0 PCB Box bottom 1
7B62-2602-043-0 UK BS plug cable 1
8B30-2501-034-0 PCB Box cover 1
9B30-2501-035-0 PCB Box wiring holder 1
10 B30-2501-068-0 motor housing wiring holder 1
11 B36-2201-040-0 Plastic pipe f153 (2M) 1
12 B64-2301-087-0 Transformer 1
13 B23-2201-012-P Hanger 1
14 B20-2102-019-P 900mm Lamp board 1
15 B62 2602 036 0 LED L ( l ) 2
BXC910
- Caple 90cm chimney s.steel
15 B62-2602-036-0 LED Lamp (warm color) 2
16 B62-2802-008-0 Front calble of LED 1
17 B35-2501-131-0 Aluminum filter 3
18 D10-3000-002-X Push button set 1
19 XXXX Casing assembly 1
20 B76-4102-001-B 750m3h Motor assembly 1
-- For motor accessory(B76-4102-001-B) 1
2.1 B30-2301-012-0 Motor housing(left) 1
2.2 B30-2301-014-0 Blower 1
2.3 B61-2301-039-0 Motor(750-2) 1
2.4 B30-2301-013-0 Motor housing(right) 1
2.5 B30-2201-068-0 Motor housing holder 1
2.6 B30-2201-022-0 One-way Valve Flap(Air Outlet) 2
-- -- For Mechanical switch(D10-3000-002-X) 1
3.1 B30-2201-090-0 Switch box cover lid 1
3.2 B60-2501-089-0 Push button 1
3.3 B30-2201-089-0 Push button bottom 1
3.4 B62-2301-048-0 Switch Cable 1
--- --- For Chassis assembly() 1
4.1 B11-0501-002-B Round Casing Lid 1
4.2 B20-2102-024-P 900mm casing cover board 1
4.3 B23-2102-022-P Frame Support 1
4.4 B11-2102-094-Q Frame panel 1
4.5 B20-2102-020-P Back cover 1
4.6 B23-2102-021-P Back support 1
4.7 B23-2102-042-P Frame support Rib(small) 2
4.8 B23-2102-041-P Frame support Rib(big) 2
