Caple WCi46B User manual

WCI46B
Ca
p
le Wine Cellar
Caple Wine Cellar
Instruction Manual

Item Part Code Description Qty
1DG2-3 Power cord 1
2DG13-1 Water tank 1
3DG7-1.1 Condenser fan 1
4DG19-1 Fan cover 2
5DG1-11 Compressor 1
6DG13-2 Electrical box cover 1
7DG11-2 Junction block 1
8DG22-25 Cabinet 1
9DG8-5 Senser 2
10 DG13-11 Cover of sensor 2
11 DG14-1 Top hinge module (pair) 1
12 DG8-4 Senser 1
13 DG12-1 Eva
p
orato
r
1
WCI46B - Caple Wine Cellar
p
14 DG13-10 Water box 1
15 DG11-1 PTC heater 1
16 DG7-3 Evaporator fan 2
17 DG7-4 PTC heater fan 1
18 JG44A.01-01 Air duct board 1
19 DG13-5 Lamp cover 2
20 JG44A.01-02 Upper panel for middle airway-board 1
21 DG5-2 Bulb 1
22 DG4-2 Lamp-holder 1
23 JG44A.09-01 Foam 1
24 DG3-1.2 PCB board 1
25 DG6-1 Transforme
r
1
26 JG44A.01-03 Lower panel for middle airway-board 1
27 Display panel 1
28 DG13-1.2 Humid box 2
29 DG15-20.1 Wooden shelves A7A 2
30 DG15-23 Stainkess Steel edge,wooden shelves 5
31 DG23-3 Cabinet door(Alloy handle) 1
32 DG14-2.6 Lower hinge 1
33 DG15-33 Wooden shelves G2 1
34 DG13-7 Shelf support 10
35 DG15-20 Wooden shelves A7 3
36 DG14-2 Lower hinge module (pair) 1
37 JG44A.01-05 Support bracket of front legs 1
38 DG12-17 Condense
r
1
39
DG13
-
6.11
Cabinet leg, type BC50N
4
39
DG13 6.11
Cabinet
leg,
type
BC50N
4
40 DG12-6
A
ir-circulating pipe 1
41 Compressor bracket 1
42 DG14-33 Bracket of fan (pair) 1
