Car Solutions HDMI interface User manual

Installation Manual
HDMI Interface for New SKODA
car-solutions.com
[email protected]
car-solutions.com

Compatibility: VW, Skoda, Polo 2017~
Components: Interface*1
Sub Board*1
Ex Board*1
Interface Input / Output specification:
Input: HDMI*2
Analog RGB*1
A/V*2
CVBS(Rear camera)*1
CVBS(Front camera)*1
Output: To LCD*1
Power Spec:
Input Power: 8VDC ~ 18VDC
Consumption: 5WATT
Switch input mode:
1. External video sources skip function: Able to control input videos on and off
via Dip switches
2. Able to switch videos via the remote and button switch
3. Able to detect the rear view camera by CAN
2
1. High-resolution display through HDMI input
2. Control EXT devices(DVD/DTV) via Multi Media Touch GUI
3. Adjustable screen position of external device
4. Mode switching with OEM button
5. Power output for rear camera drive
6. Dynamic PAS(parking assistance system)
7. Able to use OEM Touch and support multi touch with our QROI2-RGB Android
Navigation Box
car-solutions.com
[email protected]
car-solutions.com

3
MAIN BOARD
QCPASS1239
POWER CABLE
HPOWER0209
CAN CABLE
HARETC0128
ADC CABLE
HARETC0267
AV CABLE
HAVCAB0056
MULTI CABLE
HARETC0240
REMOTE CONTROL
REMOTE0001
REAR CABLE
HARETC0002
IR CABLE 4P
HIRCAB0002
RGB CABLE
HRGBCA0013
EX CABLE
HARETC0249
S/W CABLE
HARETC0001
VW-MIB2GP-5CH-SUB
QCPASS1305
SUBARU-5CH-EX
QCPASS1283
LVDS CABLE
HLVDSC0066
TOUCH CABLE
HTOUCH0047
FFC CABLE
FFCABL0093
HDMI Cable
HARETC0067
car-solutions.com
[email protected]
car-solutions.com

4
Key Function
POWER & PIP No use
MENU Activate FACTORY mode
OK Select, Changing image display
▲Move up
▼Move down
◀Move left(Access to the factory mode if you press
this button more than 2 seconds)
▶Move right (Activate the data reset if you press this
button more than 2 seconds)
※ON : DOWN / OFF : UP
PIN FUNCTION DIP S/W SELECT
1 RGB OFF : RGB MODE
ON : RGB MODE SKIP
2 HDMI1 OFF : HDMI1 MODE
ON : HDMI1 MODE SKIP
3 AV1 OFF : AV1 MODE
ON : AV1 MODE SKIP
4 AV2 OFF : AV2 MODE
ON : AV2 MODE SKIP
5 No use
6 No use
7 REAR CAMERA OFF : OEM REAR CAMERA MODE
ON : EXT REAR CAMERA MODE
8 N/C
car-solutions.com
[email protected]
car-solutions.com

5
To Sub board
A
U
D
I
O
(R)
O
U
T
A
U
D
I
O
(L)
O
U
T
F
C
A
M
A
U
D
I
O
(R)
IN
1
A
U
D
I
O
(L)
IN
1
R
C
A
M
V
I
D
E
O
IN
1
V
I
D
E
O
O
U
T
1
V
I
D
E
O
O
U
T
2
A
U
D
I
O
(R)
IN
2
A
U
D
I
O
(L)
IN
2
V
I
D
E
O
IN
2
A/V CABLE
RGB NAVI BOX
R
C
A
M
S
A
F
E
R
E
A
R
V
1
I
R
V
2
I
R
R
E
M
O
T
E
T
O
G
G
L
E
12
V
S
E
L
F
C
A
M
12
V
ADC No Use
car-solutions.com
[email protected]
car-solutions.com

6
Please disassemble the
monitor as above picture.
Please put the supplied sub
board like above.
Please connect OEM FPC
cable to supplied sub board.
Please connect supplied FFC cable
to sub board.
Please remove OEM resistances and
do soldering some points with
supplied cable on OEM PCB. Please
refer to next page for the details.
Please connect supplied LVDS
Cable to Sub board like above
picture.
Please connect the cable to sub
board in red circle and assemble
soldered OEM PCB.
Please connect OEM FPC cable to OEM
PCB and supplied FFC to OEM PCB
①②
③ ④
⑤⑥
⑦⑧
Please be careful the connector on
sub B/D doesn’t touch to OEM
bracket in Red circle.
car-solutions.com
[email protected]
car-solutions.com

7
Please assemble OEM cover
like above.
Please do supplied LVDS cable as
same as above picture.
Please do supplied LVDS cable as same
as above picture.
⑨⑩
⑪
Please assemble HU and
Monitor
⑫
car-solutions.com
[email protected]
car-solutions.com

8
Please solder provided wires as same as above picture. (Follow the wires’ colors)
1. Please remove the
registers in red
circle.
2. Solder provided
wires as same as
beside picture.
(Follow the wires’
colors)
car-solutions.com
[email protected]
car-solutions.com

PAS TYPE: Select parking line type.
- NOT USED: Do not use parking line
- PAS ON: Use Flexible Parking Lines
- PAS OFF: Use fixed parking line
PAS SETUP: You can move the position of parking line.
REAR TYPE : Choose rear camera recognition.
-CAN : By connecting to “CAN” cable of the car gear, changing to rear camera
mode when shifting into reverse. (Connect “CAN” cable of the power cable to the
“CAN” cable of the car gear)
- LAMP : By connecting to the rear lamp of the car, switch to rear camera mode
when shifting into rear. (Connect “Rear-C” cable of the power cable to the rear
lamp of the car)
SAFE ENABLE : If it is enable, HDMI, RGB, and A/V mode doesn’t show up while
driving. (YES/NO)
RADAR ENABLE: Set the parking distance alarm sensor to ON/OFF.
PARK SETTING
IMAGE SETTING
H-POSITION: Move the screen left and right.
V-POSITION: Move the screen up and down.
H-SIZE (NAVI): Adjust the left and right size of navigation.
PARK
UTIL
INFO
H-POSITION
V-POSITION
H-SIZE(NAVI)
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
PAS TYPE
PAS SETUP
REAR TYPE
SAFE ENABLE
RADAR ENABLE
Menu of FACTORY
MENU to Return SEL to Select/Save
9
car-solutions.com
[email protected]
car-solutions.com

UITL1
NAVI MODEL: RGB navigation setting
CAR MODEL: Car model setting
AVOUT SELECT: Select audio channel
transmitted through AUX (HDMI1, HDMI2, AV)
HDMI SKIP: HDMI2 skip setting
OEM SKIP: OEM skip setting
FACTORY RESET: Factory mode reset
PARK
UTIL1
UTIL2
INFO
NAVI MODEL
CAR MODEL
AVOUT SELECT
HDMI SKIP
OEM SKIP
FACTORY RESET
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL1
UTIL2
INFO
I-DRV REMOTE
TOUCH ENABLE
IR MEMORY
OEM KEY
CALIBRATE
FCAM TIME
Menu of FACTORY
MENU to Return SEL to Select/Save
10
PARK
UTIL1
UTIL2
INFO
SYSTEM VERSION
MAIN -181010
MCU: S1.8.10.10
Menu of FACTORY
MENU to Return SEL to Select/Save
INFO
SYSTEM VERSION INFORMATION
UTIL2
IDRV REMOTE : Able to use remote control on DVD,
DTV by selecting “User” after IR memory registered
TOUCH ENABLE: (No/Use OEM Touch)
IR MEMORY : Register IR memory of DTV and DVD
※Refer to “IR MANUAL” for more details
OEM KEY: Select handle DISP KEY ON/OFF
CALIBRATE: Not support, Use OEM Touch
F-CAM TIME: Front camera operation time setting
(OFF, 3s, 5s, 10s, 15s)
car-solutions.com
[email protected]
car-solutions.com

Q. I cannot change mode
A. Check connection of Ground cable and IR Cable. Check LED lamp is on, if not
check connection of POWER cable.
Q. All I got on the screen is black.
A. Check second LED lamp of the interface is on, if not, check A/V sources
connected are working well.
(Second lamp indicates AV sources connected works well)
Check interface connection has been done well.
Q. Displayed image color is not proper (too dark or unsuitable color)
A. Press ▶button on the remote control for 2 seconds and check how it goes, if it
does not work, inform to manufacturer.
Q. I cannot watch the rear camera on the screen
A. Set the DIP switch #7 as state “ON”.
Q. Set mode not appear
A. Check DIP Switch.
Q. OEM image is not displayed.
A. Check interface’s LCD In/Out cable connection. If the status keeps on, inform to
manufacturer.
Q. Screen only displays white color.
A. Check LCD out cable is connected well, if this status keeps, inform to manufacturer.
Q. If no image is shown on screen after connecting CAN wire with Park gear.
A. Go on the “FACTORY MODE”, check “UTIL-Rear Select”. If “LAMP”, change the
setting as “CAN” with the remote control. (※when connecting Rear-C wire of
LAMP power cable to Backup lights, Setting should be like this / CAN : if controlling
rear camera with CAN wire)
