Car Solutions QVI-LVTX-1CH-V7 User manual

Update Date 2014.04.25
Model QVI-LVTX-1CH-V7.1
Firmware Date
Car-Solutions.com
www.car-solutions.com
[email protected]

Warning
When installing the main unit, do not remove or alter existing
vehicle fasteners, including nuts, bolts, screw, clips, and fittings.
Never detach, move or alter existing vehicle wiring, including
electrical grounds and straps. Alteration of existing vehicle
components may make vehicle unsafe to operate. Should be
no any electronic devices or magnetic pole around installation
place.
Air bags are vital part of a safety system. Never install main unit
in a way which will alter air bag wiring or interfere with air bag
deployment. Air bags must function properly in the event of an
accident.
Before installing, check the location of pipe, tank, electrical
cables and others.
Read and follow the instruction manual.
Wiring location must not interfere driving, get in or out from car.
Use electrical tape to insulate the ends of all wires, even if they
are not used. Proper insulation prevents arcs, shocks and fires.
When installation is complete, test all vehicle electrical systems
to ensure they operate correctly, including lights, horn, brake
lights, and emergency flashers.
According to our sales policy, any problems caused by user’s
mistake, careless can not be guaranteed.
Caution
All steps of installation should be done by well-trained specialist.
During installation ignition key should be taken off and after all
installation finish connect power cable with interface for the last
step.
Do not install the main unit in places where it ma be exposed to
dew condensation (around the air conditioning hose, etc), or in
locations where it may come in contact with water, high levels of
moisture, dust or oily smoke
Install wiring in a manner in which cables will not come in contact
with metal parts. The wiring may be damaged by contact with
metal parts, resulting in fire and shocks. Avoid all contact with hot
surfaces when wiring the main unit. High temperatures may
damage wiring, causing shorts, arcing and fires.
Kindly check all parts are in the box, when receiving the product, if
anything missing, inform to the supplier or manufacturer.
Warning / Caution
Car-Solutions.com
www.car-solutions.com
[email protected]

Table of Contents
1. Specifications
1.1 Main Specifications
1.2 Features
1.3 System Diagram
1.4 Components
1.5 Exterior
2. Installation
2.1 Installation Diagram
2.2 Cautions on Installation
2.3 Installation
3. Setting
3.1 DIP Switch
3.2 Remote Control
3.3 FACTORY MODE
3.3.1 IMAGE, PARK
3.3.2 UTIL
3.4 OSD(ON SCREEN DISPLAY)
3.4.1 ANALOG RGB MODE
3.4.2. VIDEO MODE
4. Trouble Shooting
1
2
3
4
5
6
7
8
13
14
15
17
19
20
21
Car-Solutions.com
www.car-solutions.com
[email protected]

1. Specification
-1-
1. Car Compatibility
-Renault Model
: Master, Trafic, Scenic, Laguna, Megane, Clio
- Opel Model
: Movano, Vivaro
2. Components
Multimedia Interface * 1
Sub-board * 1
3. MULTIMEDIA INTERFACE input specification
3 * A/V (NTST&PAL) Input
1 * CVBS(Rear Camera) Input
2 * Analog RGB
1 * LCD input (Car system input)
4. MULTIMEDIA INTERFACE output specification
1 * LCD output
1 * Audio output
2 * CVBS output
5. Power specification
Input power : 9VDC ~ 16VDC
Consumed power : 4WATT (Max)
6. Switch modes
- Input video skip function : able to select whether to use the
respective input video sources or not via DIP switch.
- Able to change input modes via the remote control.
- Able to switch modes via the Toggle switch.
1.1 Main Specification
Car-Solutions.com
www.car-solutions.com
[email protected]

1. Specification
-2-
Possible to move the displayed position of DVD and Navigation.
Improved Display Screen (convenience-oriented Interfaces for users)
Add a safe function (show the main screen while driving)
1.2 Features
Car-Solutions.com
www.car-solutions.com
[email protected]

1. Specification
-3-
1.3 System diagram
DISPLAY
A/V 1
NAVIGATION Input
(Analog RGB)
CVBS
(Rear camera)
Car Screen Input
(CAR MAIN BOARD)
A/V 2
A/V 3
VIDEO
CIRCUIT
VIDEO MUX
MCU
Power Input
(+9VDC ~ +16VDC)
POWER
CIRCUIT
Dip S/W
A/V OUT HEADREST
MONITOR
Remote control Switch for source toggle
OEM Navi Button (Can Signal)
Car Installation
OEM LCD
RGB 2 Input
Car-Solutions.com
www.car-solutions.com
[email protected]

1. Specification
-4-
1.4 Components
POWER cable (24P) * 1ea
(HPOWER0011)
LVDS cable * 1ea
REMOTE CONTROL * 1ea
(REMOTE0001)
(HLVDSC0018)
A/V cable * 1ea
(HAVCAB0002)
REAR CAMERA POWER cable * 1ea
(HARETC0002)
IR cable * 1ea MODE cable * 1ea
(HARETC0001)
(HIRCAB0002) RGB cable * 1ea
(HNAVIC0004)
Sub-bard * 1ea
(QCPASS0510)
FFC cable*1ea
(FFCBAL0044) FFC cable* 1ea
(FFCBAL0045) FFC cable* 1ea
(SCREWS0068)
Car-Solutions.com
www.car-solutions.com
[email protected]

1. Specification
-5-
1.5 Exterior
①LED
②POWER
③RGB IN-2
④R-CAM
⑤AV(IN/OUT)
⑥DIP SWITCH
⑦TOUCH OUT TO NAVI
⑧LVDS OUT
Dimension
Horizontal Length 125mm
Vertical Length 105mm
Height 21mm
⑥⑦⑧
- SUB BOARD -
⑧
⑩
⑨
⑨LVDS-IN
⑩LCD OUT
⑪COMMAND IN
①②③④⑤
⑪
Car-Solutions.com
www.car-solutions.com
[email protected]

2. Installation
-6-
2.1 Installation Diagram
IR-AV2 (DVD)
AUX-ON (N.C)
CAN-L
CAN-H
IR-AV3 (DTV)
IR-AV1 (NAVI)
PARKING (SAFE)
REAR
OPT2 (N.C)
MODE : Toggle S/W
IR
PB12 (N.C)
GPIO-ZO : MMI
GND
ACC
RGB
REAR (12V OUT)
GND
AV1 AV2 AV3
REAR C
Audio L
Audio R
AV/OUT Video
LVDS cable
<COMMAND>
Same side FFC cable
Opposite side FFC cable
<LCD>
※Please make sure that
the installation should be
carefully conducted to
avoid from the damage of
a monitor by
ESD(Electrostatic discharge)
and misalignment
while connecting the
module of a monitor with
cables.
Car-Solutions.com
www.car-solutions.com
[email protected]

2. Installation
-7-
2.2 Cautions on installation
Ignition key should be taken off before starting installation, interface
power connection must be the last step in installation.
Power cable should be separated when connecting interface.
Should be no any electronic devices or magnetic pole around installation
place.
All steps of installation should be done by well-trained specialist.
Dismantling without manufacturer’s permission can not be guaranteed,
(No permission to break attached label on the board.)
Kindly check all parts are in the box, when receiving the product, if
anything missing, inform to the supplier or manufacturer.
According to our sales policy, any problems caused by user’s mistake,
careless can not be guaranteed.
Car-Solutions.com
www.car-solutions.com
[email protected]

2. Installation
-8-
2.3 Installation
①Please dismantle the monitor and LCD as above.
Car-Solutions.com
www.car-solutions.com
[email protected]

2. Installation
-9-
1. Disconnect a FPC cable connected
between a command and a monitor.
2. Connect same sides FFC cable to the
command.
3. Please connect opposite sides FFC
cable to the LCD.
2.3 Installation
Car-Solutions.com
www.car-solutions.com
[email protected]

-10-
①Tape up the FFC cable connected to the command and turn over the
FFC cable as above..
②Tape up the FFC cable connected to the LCD and turn over the FFC
cable as above.
2.3 Installation
2. Installation
Car-Solutions.com
www.car-solutions.com
[email protected]

-11-
- Connect FFC cable connected with the Command to Command In of
Sub-board.
- Connect FFC cable connected with the LCD to LCD out
2.3 Installation
2. Installation
Car-Solutions.com
www.car-solutions.com
[email protected]

2. Installation
-12-
2.3 Installation
①Please screw up a provided sub-board as above.
Car-Solutions.com
www.car-solutions.com
[email protected]

3. Setting
-13-
3.1 DIP Switch
※ ON : DOWN / OFF : UP
※DIP S/W usage example
- Input Mode : A/V3, Navigation (RGB)
- Select 5.8inch monitor
- When original Navigation is not installed
- Rear camera : When to be installed on CVBS 4
▷DIP S/W : 1 OFF
▷DIP S/W : 2,3 ON (INPUT MODE SKIP)
▷DIP S/W : 4 OFF (displaying A/V3)
▷DIP S/W : 5 ON
▷DIP S/W : 6 ON
▷DIP S/W : 7 ON (displaying CVBS4)
▷DIP S/W : 8 OFF
PIN Function Dip S/W Selection
1 RGB INPUT MUTE ON : Skipping RGB Mode
OFF : RGB Display
2 A/V 1 MUTE ON : Skipping A/V 1
OFF : A/V1 Display
3 A/V 2 MUTE ON : Skipping A/V 2
OFF : A/V2 Display
4 A/V 3 MUTE ON : Skipping A/V 3
OFF : A/V3 Display
5 N.C
6 N.C
7 Rear Mode ON : External Rear Camera
OFF : OEM Rear Camera
8 N.C
※Please make sure to disconnect the power cable of the interface and reconnect
the power cable again to apply the dip switch setting whenever changing DIP switch.
Otherwise, DIP switch setting will not be applied.
Car-Solutions.com
www.car-solutions.com
[email protected]

3. Setting
-14-
3.2 Remote Control
Key Function
POWER & PIP Unavailable
MENU Activating OSD menu
OK Making a selection, changing image display
▲Moving upward
▼Moving downward
◀Moving leftward (If you press this button 5 seconds long, you can get access to the
factory mode.)
▶Moving rightward (If you press this button 2 seconds long, you can reset all the data
about user environment.)
*FACTORY MODE (Interface setting for installer)
: Operated by pressing ▲→ ▼→ ▲→MENU button or
press ◀more than 5seconds long on the remote control.
Car-Solutions.com
www.car-solutions.com
[email protected]

3. Setting
-15-
3.3.1 FACTORY MODE-IMAGE, PARK
IMAGE
Adjusting the position of navigation
* H-POSITION
: moving in horizontal direction
* V-POSITION
: moving in vertical direction
PARK
PARK ENABLE : Selecting Type of parking
guide line(Default- ON)
PARK SETUP : Adjusting the position of the
parking guide line
REAR SELECT : Choose rear camera recognition
* LAMP - Detecting the rear view camera via
rear lamp (Installer must connect
“Rear-C” cable of the power cable
to the rear lamp of the car.)
*CAN - Detecting the rear view camera by
CAN signal (Installer must connect
“CAN” cable of the power cable to
the “CAN” cable of the car.)
SAFE ENABLE : If your car is connected with
CAN cable and it is in ”ON”
state, you can NOT watch DVD
or A/V except original image or
navigation while driving. At that
time the screen get back to the
main (default : OFF)
PARK
UTIL
INFO
H-POSITION
V-POSITION
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL
INFO
PARK ENABLE
PARK SETUP
REAR SELECT
SAFE ENABLE
Menu of FACTORY
MENU to Return SEL to Select/Save
Car-Solutions.com
www.car-solutions.com
[email protected]

3. Setting
-16-
3.3.1 FACTORY MODE-IMAGE, PARK
“H_POS’’ will be shown on the right and
control moving in horizontal direction
In Factory Menu, Adjusting the position of the parking guide line (available in PARK
SETUP -> V-POSITION, H-POSITION)
‘’V_POS’’ will be shown on the right and
control moving in vertical direction
H-POS
V-POS
FACTORY mode – Press ◀button 2 seconds long on the remote control.
Car-Solutions.com
www.car-solutions.com
[email protected]

3. Setting
-17-
3.3.2 FACTORY MODE-UTIL
UTIL – NAVI MODEL
Select the model of NAVIGATION
UTIL – IR MEMORY
No use
UTIL – DVD TYPE / DTV TYPE
No use
UTIL – AVOUT SELECT
Selecting background sound After
returning navigation or original
mode
DEFAULT : Selecting AV sound just
before changing navigation or
original mode from the AV mode
AV 1~3 : Sound of the selected AV
source 1~3
PARK
UTIL
UTIL2
NAVI MODEL
AVOUT SELECT
IR MEMORY
DVD TYPE
DTV TYPE
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL
UTIL2
NAVI MODEL
AVOUT SELECT
IR MEMORY
DVD TYPE
DTV TYPE
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL
UTIL2
NAVI MODEL
AVOUT SELECT
IR MEMORY
DVD TYPE
DTV TYPE
Menu of FACTORY
MENU to Return SEL to Select/Save
PARK
UTIL
UTIL2
NAVI MODEL
AVOUT SELECT
IR MEMORY
DVD TYPE
DTV TYPE
Menu of FACTORY
MENU to Return SEL to Select/Save
FACTORY mode – Press ◀button 2 seconds long on the remote control.
Car-Solutions.com
www.car-solutions.com
[email protected]
