Car Solutions ML2012-TDC User manual
Contents
1. Main Specifications
2. Block Diagram
3. Dimensions
4. External Appearance
5. Connector Pin Assignment
6. Package Content
7. DIP S/W Setting
8. Mode Change
9. Touch Control
10. OSD (On Screen Display) Control
11. Installation Guide
12. Q & A
car-solutions.com
car-solutions.com
1. Main Specifications
1. Input Spec. (MULTI VIDEO INTERFACE)
- 1 x Digital RGB Input (Navigation System source)
- 1 x Analog RGB Input (Navigation System output)
- 2 x A/V Input (External video source)
- 1 x CVBS (REAR CAMERA) Input. (Rear camera source)
- 1 x CVBS (FRONT CAMERA) Input. (Front camera source)
- 1 x LVDS Input. (Car Command System)
2. Output Spec.
- 2 x CVBS Output (Video out for Installing Headrest Monitor)
- 1 x Audio L/R Output.
- 1 x Virtual Analog Touch (Navigation System source)
- 1 x UART Digital Touch (Navigation System source)
- 1 x LVDS Output (LCD Operation)
3. Power Spec.
- Input Power: 8VDC ~ 24VDC
- Consumption Power: 12Watt, Max
4. Switch Input mode
- Possible to select CAR model while switching mode by DIP S/W
- By button on the Commander in the car via CAN
car-solutions.com
car-solutions.com
3. Dimensions
* This can change under manufacturer’s circumstance
car-solutions.com
car-solutions.com
6. Package Content
* CarPlay Set Sales (optional) –KPLAY
car-solutions.com
car-solutions.com
6. Package Content
* CarPlay Set Sales (NV17) –KPLAY
