Carbatec BAS-250C User manual

10″BANDSAW
OWNER’S MANUAL
zAssembly
zOperating
zRepair parts
FOR YOUR SAFETY:READALL INSTRUCTIONS CAREFULLY

1
Contents
1.0 General 2.5 Safety Information
1.1 Specifications 2.6 Electrical Installation
1.2 User Responsibility/Warranty 3.0 Accessories
1.3 Final Assembly and Installation 3.1 Mitre Fence
2.0 Settings 4.0 Electrical Wiring Diagrams
2.1 Changing and Setting the Sawblade 5.0 Spare Parts List/Exploded View Drawing
2.2 Blade Guiding
2.3 Setting the Cutting Height
2.4 Saw Table Tilt
1.0General
1.1 Specifications
Dimensions (lxwxh) 800x330x420 mm
Weight with motor 33 kg
Table height from floor 368 mm
Throat width 245 mm
Max. cutting height 120 mm
Sawblade width 6-13 mm
Sawblade length 1790 mm
Sawtable size 290x290 mm
Sawtable tilt 0° - 45°
Sawblade speeds 700 m/min
Motor capacity 350 W
1.2 User Responsibility/Warranty
This appliance will perform in conformity with the description contained in the instructions provided.
This machine must be checked periodically. Defective equipment (including power cables) should not
be used. Parts that are broken, missing, obviously worn, distorted or contaminated, should be
replaced immediately. Should such repair or replacement become necessary, it is recommended that
only genuine replacement parts ate used and that such repairs ate carried out by qualified persons.
This appliance or any of its parts should not be altered or changed from standard specifications. The
user of this machine shall have the sole responsibility for any malfunction which results from improper
use or unauthorized modification from standard specifications, faulty maintenance, damage or
improper repair by anyone other than qualified person.

- 2 -
1.3 Final Assembly and Installation
Unpack machine and check forany visible damage which may have occurred during transport. If a damage is detected
notify your dealer immediately.
This machine is shipped partly disassembled saw table, Mitre Fenceand star knob have to be installed prior to use.
zRemove the wing nut and Hex. socket head cap screw the table.
zPlace the table onto the uppertable trunnion.
zInstall to trunnion with 4 each serrated lock washer and hexagon
head screw M6x12.
zAttach the wing nut and Hex. socket head cap screw to table
with the wrench Hex.
zPlace table insert into the table center hole (table insert with
wide slot for bevel cuts only).
zPlace the star knob into the hole on the frame
After installation adjust the table so that thesawblade runs through the center of the table insert’s slot.
Centering the table
zLoosen the screws holding the lower table trunnion.
zMove table sideways as required, until sawblade runs through the
center of table insert.

- 3 -
Setting the Table Square with the Sawblade
The saw table can be tilted up to 45°. To tilt ,
loosen the wing nut of the table trunnion.
Loosen the wing nut on the turnnion and adjust the
table at 90°. with the blade.
Check the table with a square to make sure the table
is 90°. with the blade. If an adjustment is necessary,
loosen the screw and adjust the pointer to 0°.
To ensure sufficient upright stability of the machine it
should be bolted to floor, bench or table, or mounted
on the Workstand BAS, available as optional
accessory. For this purpose 4 - Φ6.5 mm holes are
provided in the machine’s base plate.
Dust Collection
The machine is fitted with a dust extracton port of 60mm diameter.
2.0 Band Saw Settings
2.1 Changing and Setting the Saw Blade
This band saw is factory-equipped with a general
purpose wood cutting blade, the blade set. To change
the blade, remove the wing nut and screw from the table.
Then slacken the blade tension by turning the hand
wheel on top of the upper wheel housing.
Fit new blade and tension lightly. The blade
should run in the center of the rubber lined band
saw wheels or else it may jump of. To check
tracking, turn upper wheel by hand. If required,
adjust tracking with the knurled handle at the rear
of the upper wheel housing.
It is recommended that when in use, the machine is connected to a suitable dust extractor.

- 4 -
2.2 Blade Guiding
The saw blades guide
of this band saw ensure
an exact guiding of the
blade for clean cuts.
When using narrow
blades ensure that the
lower blade guide
positively supports the
blade from both sides
and the rear. Set the
bearings of the upper blade guide to within approx. 0.5 mm of the blade, and the large thrust bearing against the back of the
blade, just clear of it. Do not set the bearing too close, as the friction generates heat, which may have an adverse effect on the
bearings and the saw blade as well.
2.3 Setting the Cutting Height
The upper blade guide should always be set as
close as practical against the work. To adjust,
loosen the wing nut at the side of the upper
wheel housing, and set the blade guide to the
required height. Tighten wing nut after setting.
2.4 Saw Table Tilt
For bevel cuts the saw table tilts steplessly through
45°。To tilt, loosen the wing nut on the table
trunnions, set table to the required angle and tighten
the wing nut again.
It is recommended to verify the correct angle setting
by making trial cuts in scrap wood.

- 5 -
2.5 Safety Information
1.Check that all guards are in place and securely locked
before switching the machine on.
2.Always disconnect from power when servicing this
machine.
3.Do not use bent or cracked band saw blades.
4.Replace table insert if slot has enlarged.
5.When cutting round stock use a suitable jig of fixture to
keep the work from turning.
6.When cutting boards in an upright position use a
suitable push block to prevent kickback.
7.Exchange the standard table insert against the one with
the wide slot before tilting the table.
8.To keep health risk to a minimum it is recommended to
always connect this band saw to a dust collector having
an air flow rate of at least 20m/s.
The most common hazards associated with the operation ofband saws ate the following:
-a hazard by the running saw blade, e.g. contact with the teeth of the blade.
-Flinging of cutoffs or knots.
-Work-piece kickback
The principal hazard areas of a band saw are:
-the work area
-the area around a running machine
-the kickback area
despite the use of the specific safety devices and compliance with all relevant regulations for the prevention of
accidents, when operating a band saw the followingresidual risks remain:
-hearing damage by excessivenoise
-danger of accidents in the unprotected cuttingarea of the running saw blade
-danger of injury when changing blades (dangerof cuts by the sharp teeth)
-endangering by flung about workpieces or parts
-squashing of fingers
-danger of injury by kickback of workpieces
-health risk caused by the dustemission, especially from oak and beechsaw dust.
2.6 Electrical Installation
This band saw is equipped with a 0.35 Kw 230V single-phase motor. Connect to a proper grounding type
receptacle.
Have damaged power cables replaced at once by a qualified electrician. Risk of electric shock if operated with a
damaged power cable.
Children should not operate this band saw.

- 6 -
3.0Accessories
3.1 Mitre Fence
Provides a Mitre Fence for angle cutting.
4.0 Wiring Diagrams
MOTOR
MOTOR CORD
POWERCORD
GREEN
YELLOW
GREEN
YELLOW
BROWN
BLUE
POWER
SWITCH
BLUE
BROWN

7
5.0 Spare parts list
Key No. Description Key No. Description
1 Band saw frame 47 Carriage bolt
2 Door upper 48 Hexagon screw
3 Door lower 49 Bearing ball
4 Upper wheel 50 Washer
5 Bearing ball 51 Bolt guide
6 Wing nut 52 Mount shaft
7 Pan head tapping screw 53 Tension angle
8 Star lock cap 54 Bolt guide
9 Bearing bolt upper 55 Lower guide shaft
10 Wheel carrier bracket 56 Lockwasher extend
11 Spring washer 57 Hex. nut with flange
12 Hex. nut 58 Carriage bolt
13 U-mount 59 Hex. nut with flange
14 Pan head screw 60 Washer
15 Shaft mount 61 Hex. socket head cap screw
16 Carriage bolt 62 J-belt
17 Blade tensioner 63 Bearing bolt lower
18 Blind rivel nut 64 Motor
19 Preruling torque type hex nut 65 Motor pulley
20 Slotted insert 66 Table trunnion lower
21 Spring washer 67 Wheel pulley
22 Housing 68 Lower guide mount
23 Washer 69 Pin guide seat
24 Hex. nut 70 Lower guide body
25 Tongue 71 Table
26 Lockwasher extend 72 Table insert
27 Hex. screw 73 Hex. socker head cap screw
28 Leaf spring 74 Carriage bolt
29 Lamello plug black 75 Glide piece
30 Star knob 76 Table trunnion upper
31 Hex. screw 77 Scale
32 Washer 78 Pan head tapping screw
33 Hex. screw 79 Lower wheel
34 Wing nut 80 Pan head cross screw
35 Hex. nut 81 Ring-retaining
36 Knurled thamb screw 82 Spacer bushing
37 Blade guard 83 Brush strip
38 Roller guide carrier extrusion 84 Carriage bolt
39 Guide angle 85 Hex. nut
40 Carriage bolt 86 Blade
41 Adjusting shaft 87 Pan head cross screw
42 Upper guide mount 88 Lock switch
43 Washer 89 Cover-switch plate
44 Preruling torque type hex nut 90 Washer
45 3-roller guide ass’y 91 Hex. nut
46 Screw socket set
