Carbatec BS-B200H User manual

CARBATEC.COM.AU
BSB200H MANUAL
8" (205 mm)
Benchtop Bandsaw
1

FOR TECHNICAL SUPPORT CALL 1800 658 111
2
BS-B200H
V1
Carbatec has been a trusted brand for woodworking enthusiasts
and professionals across Australia and New Zealand, since 1987.
Our quality woodworking products are designed and built to oer
value and performance, making the latest features and technological
advancements more accessible to Aussie woodworkers.
Backed by our no-fuss after-sales care and warranty support,
you can trust Carbatec to keep you woodworking, as promised.
We look forward to sharing in your woodworking journey!
If you have any questions about our products or service,
please call us on 1800 658 111 or email us at [e-mail]
Find us on social media
facebook.com/Carbatec
instagram.com/Carbatec
youtube.com/CarbaTecToolsForWood
THANK YOU
FOR CHOOSING

CARBATEC.COM.AU
3
BS-B200H
WHAT’S IN THE BOX
WELCOME
A. Fence
B. Front fence rail
C. Table mounting bolts
D. Alloy table
E. Fence mounting knobs
F. Tools
G. Push stick
H. Bench brackets and bolts
I. Mitre gauge
BSB200H 8" BANDSAW
1. Remove parts from all of the cartons
and lay them on a clean work surface.
2. Remove any protective materials and
coatings from all of the parts and the
bandsaw. The protective coatings can
be removed by spraying WD-40 on
them and wiping it o with a soft cloth.
3. Compare the items to verify that all are
accounted for before discarding the
shipping box.
DO NOT USE ACETONE, gasoline or lacquer
thinner to remove any protective coatings.
!
If any parts are missing, do not attempt to plug in
the power cord and turn “ON” the bandsaw. The
bandsaw can only be turned “ON” after all the
parts have been obtained and installed correctly.
!
This bandsaw will require a minimal amount of assembly.
A
B
C
D
E
H
F
G
The following items are provided in the shipping box:
F
I

FOR TECHNICAL SUPPORT CALL 1800 658 111
4
BS-B200H
DATE OF PURCHASE:
SERIAL NUMBER:
Record the serial number and date of purchase
in your manual for future reference.
1
Made for:
CARBATEC PTY LTD
Brisbane - Australia
Model:
Voltage
Freq:
Phase:
Amp:
kW:
Speed:
Lot No.:
Serial No.:
Date:
QUALITY INSPECTED
Key information can be found on the inspection
panel, found on the rear of the machine.
IMPORTANT
DUST COLLECTION: All woodworking machines require effective dust extraction to ensure
quality work and longevity of the machine itself. Failure to connect your machine to a
suitable dust collector may affect your warranty. The collector required for your machine
will depend on several factors including the type of machine and its dust port connection,
distance between collector and machine, type & frequency of use and the material being
worked. We recommend a dust collector that will provide you a minimum airflow of 500-CFM
when measured at the machine connection.

CARBATEC.COM.AU
5
BS-B200H
NOTE: The specifications, photographs, drawings and information in this manual represent
the current machine model when the manual was prepared. Changes and improvements
may be made at any time, with no obligation on the part of Carbatec to modify previously
delivered units. Reasonable care has been taken to ensure that the information in this
manual is correct, to provide you with the guidelines for the proper safety, assembly and
operation of this machine.
Introduction 2
What’s in the box 3
Key information 4
Safety instructions - General 6-9
Safety instructions - Bandsaw 9-10
Safety instructions - Electrical 11
Overview 12
Specications 13
Assembly 14-17
Setup 18–21
Operation 22-23
Maintenance 24-25
Troubleshooting 26
Wiring diagram 27
Parts diagram/Parts list 28-29
Warranty 30
Notes 31
CONTENTS
CONTENTS

FOR TECHNICAL SUPPORT CALL 1800 658 111
6
BS-B200H
A safety alert symbol Indicates DANGER, WARNING, or CAUTION.
May be used in conjunction with other symbols or pictographs.
Indicates an imminently hazardous situation, which, if not avoided,
will result in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided,
could result in minor or moderate injury.
(Without Safety Alert Symbol) Indicates a situation that may result
in property damage.
Carbatec products bearing the Regulatory Compliance Mark (RCM) have been
tested in accordance with applicable Australian/New Zealand Standards
to ensure their compliance with all mandatory standards and regulations
(applicable at time of original sale). Carbatec Pty Ltd are registered as a
responsible supplier with relevant Australian government departments and
our products are registered on the EESS & ACMA database.
!
!
!
!
SYMBOL MEANING
IMPORTANT! Safety is the single most important consideration in the operation of this
equipment. The following instructions must be followed at all times. Failure to follow all
instructions listed below may result in electric shock, re, and/or serious personal injury.
There are certain applications for which this tool was designed. We strongly recommend
that this tool not be modied and/or used for any other application other than that for
which it was designed. If you have any questions about its application, do not use the tool
until you have contacted us and we have advised you.
The purpose of safety symbols is to attract your attention to possible dangers. The safety
symbols and the explanations with them deserve your careful attention and understanding.
The symbol warnings do not, by themselves, eliminate any danger. The instructions and
warnings they give are no substitutes for proper accident prevention measures.
!
Be sure to read and understand all safety instructions in this manual, including all safety
alert symbols such as “DANGER,” “WARNING,” and “CAUTION” before using this tool.
Failure to following all instructions listed below may result in electric shock, re, and/or
serious personal injury.
SAFETY INSTRUCTIONS

CARBATEC.COM.AU
7
BS-B200H
Operating a power tool can be dangerous if
safety and common sense are ignored. The
operator must be familiar with the operation of
this machine. Read this manual to understand this
machine. DO NOT OPERATE this machine IF YOU
DO NOT FULLY UNDERSTAND the limitations of
this tool. DO NOT MODIFY this machine in any way.
BEFORE USING
THIS MACHINE
!
To avoid serious injury and damage to the tool,
read and follow all of the Safety and Operating
Instructions before operating the machine.
!
1. SOME DUST CREATED BY USING
POWER TOOLS CONTAINS CHEMICALS
known to cause cancer, birth defects, or
other reproductive harm. Some examples of
these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement, and
other masonry products.
• Arsenic and chromium from chemically
treated lumber
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to these
chemicals: work in a well ventilated area
and work with approved safety equipment,
such as those dust masks that are specially
designed to lter out microscopic particles.
2. READ this entire manual. LEARN how to use
the tool for its intended applications.
3. GROUND ALL TOOLS. If the tool is supplied
with a 3-prong plug, it must be plugged into
a 3-contact electrical receptacle. The third
prong is used to ground the tool and provide
protection against accidental electric shock.
4. AVOID A DANGEROUS WORKING
ENVIRONMENT. Do not use electrical tools in
a damp environment or expose them to rain.
5. DO NOT USE electrical tools in the presence
of FLAMMABLE liquids or gases.
6. ALWAYS KEEP THE AREA CLEAN, well lit,
and organized. Do not work in an environment
with oor surfaces that are slippery from
debris, grease, and wax.
7. KEEP VISITORS AND CHILDREN AWAY. Do
not permit people to be in the immediate
work area, especially when the electrical tool
is operating.
8. DO NOT FORCE THE TOOL to perform an
operation for which it was not designed. It
will do a safer and higher quality job by only
performing operations for which the tool was
intended.
9. WEAR PROPER CLOTHING.
Do not wear loose clothing, gloves, neckties,
or jewellery. These items can get caught in
the machine during operations and pull the
operator into the moving parts. The user
must wear a protective cover on their hair, if
hair is long, to prevent it from contacting any
moving parts.
10. CHILDPROOF THE WORKSHOP AREA by
removing switch keys, unplugging tools from
the electrical receptacles, and using padlocks.
GENERAL SAFETY
SAFETY INSTRUCTIONS

FOR TECHNICAL SUPPORT CALL 1800 658 111
8
BS-B200H
11. ALWAYS UNPLUG THE TOOL FROM THE
ELECTRICAL RECEPTACLE
when making adjustments, changing parts or
performing any maintenance.
12. KEEP PROTECTIVE GUARDS IN PLACE AND
IN WORKING ORDER.
13. AVOID ACCIDENTAL STARTING. Make sure
that the power switch is in the “OFF” position
before plugging in the power cord to the
electrical receptacle.
14. REMOVE ALL MAINTENANCE TOOLS from
the immediate area prior to turning “ON”
the machine.
15. USE ONLY RECOMMENDED ACCESSORIES.
Use of incorrect or improper accessories
could cause serious injury to the operator
and cause damage to the tool. If in doubt,
check the instruction manual that comes with
that particular accessory.
16. NEVER LEAVE A RUNNING TOOL
UNATTENDED. Turn the power switch to the
“OFF” position. Do not leave the tool until it
has come to a complete stop.
17. DO NOT STAND ON A TOOL. Serious injury
could result if the tool tips over, or you
accidentally contact the tool.
18. DO NOT STORE ANYTHING ABOVE OR
NEAR the tool where anyone might try to
stand on the tool to reach it.
19. MAINTAIN YOUR BALANCE. Do not extend
yourself over the tool. Wear oil resistant
rubber soled shoes. Keep oor clear of
debris, grease, and wax.
20. MAINTAIN TOOLS WITH CARE. Always
keep tools clean and in good working order.
Keep all blades and tool bits sharp, dress
grinding wheels and change other abrasive
accessories when worn.
21. EACH AND EVERY TIME, CHECK FOR
DAMAGED PARTS PRIOR TO USING THE
TOOL. Carefully check all guards to see that
they operate properly, are not damaged, and
perform their intended functions. Check for
alignment, binding or breaking of moving
parts. A guard or other part that is damaged
should be immediately repaired or replaced.
22. DO NOT OPERATE TOOL WHILE TIRED,
OR UNDER THE INFLUENCE OF DRUGS,
MEDICATION OR ALCOHOL.
23. SECURE ALL WORK. Use clamps or jigs to
secure the work piece. This is safer than
attempting to hold the work piece with
your hands.
24. STAY ALERT, WATCH WHAT YOU ARE
DOING, AND USE COMMON SENSE WHEN
OPERATING A POWER TOOL. A moment of
inattention while operating power tools may
result in serious personal injury.
25. ALWAYS WEAR A DUST MASK TO PREVENT
INHALING DANGEROUS DUST OR
AIRBORNE PARTICLES, including wood dust,
crystalline silica dust and asbestos dust.
Direct particles away from face and body.
Always operate tool in well ventilated area
and provide for proper dust removal. Use
dust extraction system wherever possible.
Exposure to dust may cause serious and
permanent respiratory or other injury,
including silicosis (a serious lung disease),
cancer, and death. Avoid breathing dust, and
GENERAL SAFETY

CARBATEC.COM.AU
9
BS-B200H
avoid prolonged contact with dust. Allowing
dust to get into your mouth or eyes, or lay on
your skin may promote absorption of harmful
material. Always use properly tting AS/NZS
approved respiratory protection appropriate
for the dust exposure, and wash exposed
areas with soap and water.
26. USE A PROPER EXTENSION CORD IN GOOD
CONDITION. Use of extension cords should
be avoided where possible. When using an
extension cord, be sure to have a cord heavy
SAFETY INSTRUCTIONS
enough to carry the current your product will
draw, and with compatible pin conguration
and connections. NEVER use an extension
cord rated at less than your machine.
Longer run extensions will need heavier
duty extension cords. Only connect your
extension cord or machine to a receptacle
that accepts your plug and never modify your
plug to suit a receptacle.
BANDSAW SAFETY
The device and packaging materials are
not toys! Children must not be allowed
to play with plastic bags, lm and small
parts! There is a risk of swallowing and
suocation!
NOTE: According to the applicable product
liability law the manufacturer of this device is not
liable for damages which arise on or in connection
with this device in case of:
• Improper handling
• Non-compliance with the instructions
for use
• Repairs by third party, non authorised skilled
workers
• Installation and replacement of non-genuine
spare parts
• Improper use
!RECOMMENDATIONS:
• Read the entire text of the operating
instructions prior to the assembly and
operation of the device. These operating
instructions are intended to make it easier
for you to get familiar with your device and
utilise its intended possibilities of use.
• The operating instructions contain
important notes on how to work safely with
your machine and how to avoid dangers, and
increase the reliability and working life of the
machine.
• Retain and store these instructions near the
machine. The instructions must be read and
carefully observed by each operator prior to
starting the work.
• In addition to the safety notes contained
in the present operating instructions and
the special regulations of your country, the
generally recognised technical rules for the
operation of wood working machines must
be observed.

FOR TECHNICAL SUPPORT CALL 1800 658 111
10
BS-B200H
BANDSAW SAFETY
INTENDED USE
• The machine must only be used in
technically perfect condition in accordance
with its designated use and the instructions
set out in the operating manual, and
only by safety-conscious persons who
are fully aware of the risks involved in
operating the machine. Any functional
disorders, especially those aecting the
safety of the machine, should therefore
be rectied immediately. The safety, work
and maintenance instructions of the
manufacturer as well as the technical data
given in the calibrations and dimensions
must be adhered to.
• Relevant accident prevention regulations
and other, generally recognised safety-
technical rules must also be adhered to.
• The machine may only be used, maintained,
and operated by persons familiar with it and
instructed in its operation and procedures.
Arbitrary alterations to the machine release
the manufacturer from all responsibility for
any resulting damages.
• The machine may only be used with original
accessories and tools made
by or recommended by the manufacturer
• Any other use exceeds authorisation.
The manufacturer is not responsible
for any damages resulting from unauthorized
use; risk is the sole responsibility of the
operator.
SAFETY FOR BANDSAWS
• This bandsaw is intended for use in dry
conditions, and for indoor use only.
• Do not cut pieces of material too small
to hold by hand outside the blade guard.
• Avoid awkward hand positions where
a sudden slip could cause a hand to move
into the blade.
• Always use the blade guard to avoid
possible injury due to blade breakage.
• Never leave the work area with the power
connected, or before the machine has come
to a complete stop.
• Do not perform layout, assembly or set
up work on the table while the cutting tool is
in operation.
• Never turn your bandsaw on before clearing
the table of all objects: (tools, scraps of
wood, etc) except for the workpiece and
related feed or support devices for the
operation planned.
REMAINING HAZARDS
The machine has been built using modern
technology in accordance with recognised safety
rules. Some remaining hazards, however, may
still exist.
• Long hair and loose clothing can be
hazardous. Wear personal protective gear
such as a hair net and tight tting
work clothes.
• Saw dust and wood chips can be hazardous.
Always wear AS/NZS approved personal
protective gear such as safety goggles, dust
mask and hearing protection.
• The use of incorrect or damaged mains
cables can lead to injuries caused
by electricity.
• Even when all safety measures are taken,
some remaining hazards which are not yet
evident may still be present.
• Remaining hazards can be minimised
by following the instructions in Safety
Precautions, Proper Use and
in the entire operating manual.
• Do not force the machine unnecessarily:
excessive cutting pressure may lead to rapid
deterioration of the blade and a decrease in
performance in terms of nish and
cutting precision.

CARBATEC.COM.AU
11
BS-B200H SAFETY INSTRUCTIONS
!
This tool must be grounded while in use to
protect the operator from electric shock. IN THE
EVENT OF A MALFUNCTION OR BREAKDOWN,
grounding provides the path of least resistance
for electric current and reduces the risk of electric
shock. This tool may be equipped with an electric
cord that has an equipment grounding conductor
and a grounding plug. The plug MUST Be plugged
into a matching electrical receptacle that is
properly installed and grounded in accordance
with ALL local codes and ordinances.
DO NOT MODIFY THE PLUG PROVIDED.
If it will not t the electrical receptacle, have the
proper electrical receptacle installed by a
qualied electrician.
IMPROPER ELECTRICAL CONNECTION of the
equipment grounding conductor can result in
risk of electric shock. The conductor with the
green insulation (with or without yellow stripes)
is the equipment grounding conductor. DO NOT
connect the equipment grounding conductor to a
live terminal if repair or replacement of the electric
cord or plug is necessary.
CHECK WITH A QUALIFIED ELECTRICIAN
or service personnel if you do not completely
understand the grounding instructions, or if you
are not sure the tool is properly grounded.
Use only a 3-wire extension cord that has a
3-prong grounding plug and a 3-pole receptacle
that accepts the tool’s plug. Replace a damaged
or worn cord immediately.
Power tools and machinery are intended for use
on a circuit that has an electrical receptacle as
shown in FIGURE A that shows a 10 Amp 3-wire
electrical plug and corresponding electrical
receptacle that has a grounding conductor.
If this particular tool has been designed and tted
with a two prong electrical plug, ensure it displays
the ‘Double Insulated’ logo shown in FIGURE B,
before connecting to a 3- wire receptacle.
!
Never modify the standard tted electrical
plugs to t your receptacle.
ELECTRICAL SAFETY
Fig. A Fig. B

FOR TECHNICAL SUPPORT CALL 1800 658 111
12
BS-B200H
BSB200H 8” 200MM BENCHTOP BANDSAW
OVERVIEW
A. Blade tension knob
B. Blade tracking and locking knobs
C. Table tilt trunnion
D. Top door lock
E. Blade guard lock and adjustment knobs
F. Top blade guide
G. Fence
H. Alloy table
I. Bottom blade guide
J. Bottom door lock
K. 4” Dust port
L. Top & bottom door access
M. Fence rail
N. On/o switch
A
C
D
E
F
G
H
I
J
K
L
M
N
B
485 mm485 mm
490 mm490 mm
725 mm725 mm

CARBATEC.COM.AU
13
BS-B200H SPECIFICATIONS
CODE BS-B200H
MOTOR 370 W (½ HP) induction - regular 10 A plug
SWITCH TYPE Magnetic NVR
BLADE GUIDES Euro style with rack and pinion rise and fall
BLADE LENGTH 1490 mm
BLADE RELEASE Standard tension release knob
BLADE SPEED 880 m/min
DEPTH OF CUT 100 mm
DUST PORT 1 × 100 mm (4")
MINIMUM BLADE WIDTH 3.2 mm (")
MAXIMUM BLADE WIDTH 12 mm (½")
MAXIMUM RIP CAPACITY 195 mm
POSITIVE STOPS 0° (adjustable)
TABLE HEIGHT 315 mm
TABLE SIZE 300 × 310 mm
TABLE TILT + 45°
WORKSHOP FOOTPRINT (W×D×H) 485 × 490 × 725 mm
WHEEL DIAMETER 204 mm
WHEEL TYPE Cast alloy
WARRANTY PERIOD 1 year
SHIPPING WEIGHT 20.5 kg
NETT WEIGHT 18.5 kg
SPECIFICATIONS

FOR TECHNICAL SUPPORT CALL 1800 658 111
14
BS-B200H
ASSEMBLY
A. TABLE ASSEMBLY
1. With the machine safely placed on a at,
stable surface such as a workbench, tilt
the trunnion to 30˚ and lock it in place.
Fig. A1
2. Slide the table into approximate position
ensuring the blade passes through the
slot, with the table opening facing to the
front of the machine.
Fig. A2
3. Insert the table mounting bolts and
washers into the matching threaded
holes in the table, from underneath. The
table is tilted to provide easier access
to all bolt holes. Finger tighten all bolts,
leaving them just loose enough to adjust
the table.
Fig. A3
4. Using a ruler or straight edge, align the
table slot to be parallel with the blade by
slightly rotating the loose table.
Fig. A4
Fig. A1Fig. A1
Fig. A2Fig. A2
Fig. A3
Fig. A4

CARBATEC.COM.AU
15
BS-B200H ASSEMBLY
5. Once you are happy with the alignment,
go ahead and tighten all the table bolts
with the spanner provided. You can then
adjust the tilt of the table back to 0˚.
Fig. A5
6. The blade needs to run through the
middle of the table insert. If required,
you can adjust this by loosening the
three trunnion mounting bolts on the
back of the machine two turns each,
sliding the assembly into position and
re-tightening.
Fig. A6
7. The next step is to assemble the fence.
Screw the fence rail wing nuts (x4) into
the threaded holes at the front edge of
the table. Leave approximately 5 mm
unthreaded on each bolt.
Fig. A7
8. Slide the fence rail into position, in the
gap you left on the wing nuts and nger
tighten, ensuring the rail is pressed
against the front of the table.
Fig. A8
Fig. A4
Fig. A5
Fig. A6
Fig. A7
Fig. A8

FOR TECHNICAL SUPPORT CALL 1800 658 111
16
BS-B200H
9. Place the fence onto the rail to the left of
the blade. The fence needs to be parallel
to the table slot/mitre track. If necessary,
this can be adjusted via two Allen bolts,
one through the hole in the top face of
the fence; the other under the black
plastic end cap which can be popped
o for access. Simply loosen, adjust the
fence angle slightly as required and
re-lock.
Fig. A9
10. Move the fence and set the hairline
magnier to “0” on the left of the blade,
locking the fence in this position.
Fig.10
11. Loosen and slide the rail slightly as
required, so the face of the fence is ush
with the set of the teeth on the blade,
without pushing on the blade itself.
Fig. A11
12. If you have moved the fence rail as far
as its adjustment will go, but the fence
does not reach the blade on the “0”
setting, you can adjust the position of
the rail scale with a Philips screwdriver.
Undo the small bolt on the right side of
the fence rail scale a few turns, slide the
scale until you are able to zero the fence
to the blade and re-tighten.
Fig. A12
ASSEMBLY
Fig. A9
Fig. A10
Fig. A12
Fig. A11

CARBATEC.COM.AU
17
BS-B200H
Fig. A13
ASSEMBLY
13. Check the table is set at 90˚ (square)
to the blade, using a quality square. If
necessary adjust the tilt on the trunnion
and lock in place.
Fig. A13
14. Ensure your “pointer” on the trunnion
scale is accurately pointing to “0” in
this position. Adjust with a Philips head
screwdriver if required.
Fig. A14
15. The bandsaw is tted with an adjustable
stop, allowing you to easily return the
table to 90˚ when required. With the
table currently locked at exactly 90˚,
loosen the nuts on the bolt below the
table and turn the screw until the head
is resting against the underside of the
table. Now lock this into position with
the nut.
Fig. A15
*NB: this “zero stop” setting will prevent
you from tilting the table in the opposite
direction (-), unless you wind it out of
the way.
16. Finally, the bandsaw includes some
bench mounting brackets and bolts.
If desired, you can now attach the
brackets to the machine with the bolts
provided, in the holes at the base of
the machine. You can then screw these
brackets down to your bench. This
provides the ultimate in stability for your
machine, at the expense of being able to
move it out of the way easily.
Fig. A16
Fig. A14
Fig. A15
Fig. A16

FOR TECHNICAL SUPPORT CALL 1800 658 111
18
BS-B200H
B. SETTING UP THE BANDSAW
1. Using the Allen key provided, unlock
the top door by rotating a quarter turn
anti-clockwise. This machine requires
a “tool” (Allen key) to open the door to
meet CE and school/business safety
specication requirements.
Fig. B1
2. Turn the knob on the bottom door in an
anti-clockwise direction to unthread
the retaining bolt. Note that this bolt is
long! This long thread holds the door
assembly closed and engages the
micro-switch on the door.
Fig. B2
3. Open the door and place a block in front
of it to hold it open. This will allow you to
readily access the adjustments required
to properly setup your bandsaw.
4. Tension and track the blade on the upper
wheel. To do so without impediment,
loosen the blade guides so they are well
clear of the blade for now. Using the
Allen key provided, go ahead and loosen
all guide and thrust bearings, moving
them away from the blade.
Fig. B3 and B4
SETUP
Fig. B1
Fig. B2Fig. B2
Fig. B3Fig. B3
Fig. B4
Ensure power is disconnected from your
machine before undertaking any adjustments
or alignment.

CARBATEC.COM.AU
19
BS-B200H SETUP
5. Adjust the blade tension by turning the
knob located on the top of the bandsaw.
Clockwise rotation will increase tension,
anti-clockwise will reduce tension.
Fig. B5
6. Correct tension is applied when a
deection of approximately 5 mm is
achieved with moderate nger pressure,
in the centre of the blade (hence the
guides being out of the way). Note that
this is an approximate setting only.
Correct tension will vary by blade size
and type, spring tension wear and other
factors.
Fig. B6
7. Once you have the tension set, the
tracking will need adjustment. Loosen
the tracking lock knob on the back of
the machine.
Fig. B7
8. Hand-rotate the upper wheel very slowly.
The blade will either move towards the
back of the wheel or the front. Care is
required here as the blade can run right
o the wheel if considerable adjustment
in the blade tension was required. If
this occurs, you will need to loosen
the upper wheel, place the blade back
on the upper and lower wheels and
go through the blade tension process
again.
Fig. B8
Fig. B5Fig. B5
Fig. B6
Fig. B7
Fig. B8

FOR TECHNICAL SUPPORT CALL 1800 658 111
20
BS-B200H
SETUP
9. To adjust the blade tracking, turn
the tracking knob on the rear of the
machine. Clockwise will move the blade
towards the front of the tyre, anti-
clockwise towards the back.
Fig. B9
10. The aim is to have the blade tracking on
the crown of the tyre, that is the middle
of the wheel. Once achieved, tighten the
blade tracking lock knob again.
Fig. B10
11. The European style blade guides can
now be set. Below the table, adjust
the side guides so they are behind the
set of the teeth, where they will guide
the at of the blade. Bring them in to
the blade until they just barely miss. A
rule-of-thumb here is a “piece of paper”
thickness away from the blade. Once in
position, lock these in place.
Fig. B11
12. The thrust guide is the one which sits
behind the blade to assist in pushing the
blade backward during cutting. Again,
this needs to be positioned a fraction
behind the blade, eectively so it is not
touching when the machine is turned on
alone, but is engaged when in use.
Fig. B12
Fig. B9
Fig. B10
Fig. B11
Fig. B12Fig. B12
