Cardiac Science AED TRAINING SIMULATOR User manual

Battery Saver Feature 3
The Training Simulator powers off automatically about 30 minutes after a key
was last pressed, or after a defib discharge was last detected. This is normal
operation.
If you want to disable the battery saver feature, follow these instructions:
1. Power off the simulator.
2. Press and hold down the convert key, the press and release the
ON-OFF key. The simulator will power on.
3. Observe NSR indicator. When it blinks on and off, release the convert
key. (NSR indicator will continue to blink for approximately one second.)
The battery saver feature is now disabled.
When you power off the simulator, it will return to normal battery saver operation.
Cleaning and Sterilization
The Training Simulator may be cleaned using a sponge or cloth moistened with
water or rubbing alcohol. Do not use abrasives or solvents.
Do not steam, autoclave, or gas sterilize.
Service
The Training Simulator is warranted to be free of defects in material or
workmanship for three years from date of purchase.
If your simulator needs service, or if you have questions about its operation,
please contact your authorized Cardiac Science dealer, or Cardiac Science
Technical Support.
Cardiac Science Corporation
Waukesha, WI 53186 USA
800.426.0337 (USA)
262.953.3499
[e-mail]
www.cardiacscience.com
The Training Simulator is intended for training and sales demo purposes only. Not for
equipment testing or verification.
TRAINING SIMULATOR
OPERATING INSTRUCTIONS
Product Description......................................................................... 1
Controls and Indicators................................................................... 1
Waveforms........................................................................................ 2
Exercises .......................................................................................... 2
Battery Saver Feature...................................................................... 3
Cleaning and Sterilization............................................................... 3
Service .............................................................................................. 3

DEFIB DSCHG
Green indicator illuminates
for two seconds when
discharge is delivered from
the AED.
Product Description 1
The Training Simulator is an easy to use training tool that allows practice in
working with an AED and defibrillation procedures.
NOTE: The Training Simulator is intending for training and sales demo purposes
only. Not for equipment testing or verification. Not for human use.
Controls and Indicators
The Training Simulator has eight waveform keys. LED indicators in each key
show you which waveform is running.
Convert
The convert feature allows the simulator to convert automatically from one
shockable rhythm (the running rhythm) to another rhythm (the waiting rhythm)
when a discharge is delivered from the AED. To perform convert operation:
1. Press the key of a shockable rhythm.
2. Press the convert key. Indicator of running rhythm pulses brighter.
3. Press key of the rhythm you want simulated immediately after defib
discharge.
4. Deliver discharge from the AED.
To cancel a convert operations before it’s completed, either press the convert
key again or press the key of the running rhythm. If a convert operation is started
but not completed within two minutes, it will cancel automatically.
Waveforms 2
VF Ventricular Fibrillation, over 200 bpm.
VT fast Ventricular Tachycardia (wide QRS). Rate is approximately 185.
VT slow Ventricular Tachycardia (wide QRS). Rate is approximately 140.
NSR Normal Sinus Rhythm. Rate is approximately 72. Non-shockable.
ASYS Asystole. Non-shockable.
SVT slow Supra Ventricular Tachycardia. Rate is approximately 170.
artifact Unusable signal. Rate is not applicable; frequency and/or amplitude
exceed ECG parameters.
SVT fast Supra Ventricular Tachycardia. Rate is approximately 210.
Exercises
The following examples demonstrate how the Training Simulator can be used for
training.
A. At Simulator:
1. Press VF key. VF indicator glows steadily. (VF is displayed on monitor.)
2. Press convert key. VF indicator pulses brighter.
3. Press NSR key. NSR indicator blinks on and off. VF indicator glows
steadily again.
B. At AED in semi-automatic/AED mode:
1. Open lid of AED. If packaged electrodes are under the lid, disconnect
and remove them.
2. Connect simulator cable to the AED electrodes socket.
The AED will give the following voice prompts:
“Push flashing button to erase date and perform rescue.”
“Do not touch patient. Analyzing rhythm.”
“Shock advised. Charging.”
“Stand clear. Push flashing button to deliver shock.”
C. With ECG monitoring cable (for Pro models only):
1. Open lid of AED. If packaged electrodes are under the lid, disconnect
and remove them.
2. Connect ECG cable to the AED electrodes socket.
3. Connect each of the 3 leads on the ECG cable to the appropriate
terminal labeled RA, LA, LL.
The AED will give the following voice prompts:
“ECG Monitoring Mode.”
4. Press the NSR key. NSR is now being simulated. View the ECG in the
screen of the Pro AED.
112-0050-002 Rev B
ON-OFF
Press to power on and to power off
NSR is selected automatically when powered on.
LOW BATT
Red indicator illuminates when
battery voltage is low.
convert
Press before defib discharge
to activate another rhythm
immediately after defib
discharge.
3-LEAD TERMINALS:
LL, LA, RA
