User’s Guide
Cardiac Science Powerheart®
Automated External Debrillator
70-01704-01 B

USER’S GUIDE
POWERHEART® G5
AUTOMATED EXTERNAL
DEFIBRILLATOR
70-01704-01 B

Information in this document is subject to
change without notice. Names and data
used in the examples are ctitious unless
otherwise noted.
Trademark Information
Cardiac Science, the Shielded Heart logo,
Powerheart, STAR‚ Intellisense‚ Rescue Ready‚
RescueCoach‚ and RHYTHMx are trademarks
or registered trademarks of Cardiac Science
Corporation. All other product and company
names are trademarks or registered
trademarks of their respective companies.
Copyright © 2015 Cardiac Science
Corporation. All Rights Reserved.
Patents
U.S. and foreign patents pending. See
www.cardiacscience.com/patents for a
complete list.
Cardiac Science Corporation
N7 W22025 Johnson Drive
Waukesha, WI 53186 USA
[e-mail]
www.cardiacscience.com
MDSS GmbH
Schigraben 41
D-30175 Hannover
Germany
Powerheart® G5 Automated External Debrillator70-01704-01 Bii

Chapter 1: About the AED
AED overview ..........................................................................................................1-1
AED parts...................................................................................................................1-2
The display panel ...................................................................................................1-2
Debrillation pads .................................................................................................1-3
CPR feedback device.............................................................................................1-3
Intellisense® battery..............................................................................................1-3
Chapter 2: Steps to a Rescue
1: Assess the patient..............................................................................................2-2
2: Prepare the patient...........................................................................................2-2
3: Place pads.............................................................................................................2-2
4: Analyze the ECG................................................................................................ 2-3
5: Deliver a shock................................................................................................... 2-3
6: Give CPR............................................................................................................... 2-4
7: Prepare the AED for the next rescue .........................................................2-4
Chapter 3: Safety
Indications for use ................................................................................................ 3-1
Safety alert descriptions..................................................................................... 3-1
Warnings and cautions ....................................................................................... 3-1
Symbols and labels............................................................................................... 3-3
Chapter 4: AED Features
Dual languages...................................................................................................... 4-1
Prompting levels ................................................................................................... 4-1
CPR behavior types .............................................................................................. 4-2
AED device history and rescue data recording.......................................... 4-2
AED Manager software....................................................................................... 4-2
Chapter 5: Troubleshooting
Self-tests................................................................................................................... 5-1
Troubleshooting of indicators.......................................................................... 5-2
Maintenance and service messages .............................................................. 5-3
Diagnostic mode messages..............................................................................5-4
Chapter 6: Product Care
Periodic maintenance.......................................................................................... 6-1
Cleaning and care ................................................................................................. 6-2
Authorized service................................................................................................ 6-2
Contents
Appendix A: RescueCoach™Voice and Text Prompts
Start up ....................................................................................................................A-1
Pads placement ....................................................................................................A-2
Pads prompts .........................................................................................................A-3
Analysis ....................................................................................................................A-3
Delivering therapy - G5 semi-automatic .....................................................A-3
Delivering therapy - G5 automatic ................................................................A-4
CPR .............................................................................................................................A-5
CPR feedback device (optional) ......................................................................A-6
Data transfer ..........................................................................................................A-7
Language selection .............................................................................................A-8
Appendix B: Technical Data
Powerheart G5 parameters ............................................................................... B-1
Debrillation pads ................................................................................................B-3
Intellisense® battery (model XBTAED001).................................................... B-3
Appendix C: ECG Analysis Algorithm and Rescue Waveform
RHYTHMx® AED ECG analysis algorithm ...................................................... C-1
Rescue protocol..................................................................................................... C-1
STAR® biphasic waveform.................................................................................. C-1
Appendix D: Electromagnetic Emissions Standards Compliance
Guidance and manufacturer’s declaration—
electromagnetic emissions...............................................................................D-1
Guidance and manufacturer’s declaration—
electromagnetic immunity ...............................................................................D-1
Recommended separation distances between portable
and mobile RF communications equipment and the AED................... D-3
Appendix E: Waste Electrical and Electronic
Equipment (WEEE) Directive Compliance
Manufacturer’s WEEE compliance instructions..........................................E-1
Appendix F: Limited Warranty
For how long?..........................................................................................................F-1
What you must do: ................................................................................................F-1
What we will do: .....................................................................................................F-1
Obligations and warranty limits:......................................................................F-1
What this warranty does not cover: ................................................................F-2
This limited warranty is void if: .........................................................................F-2
If the warranty period has expired:.................................................................F-2
1Powerheart® G5 Automated External Debrillator 70-01704-01 B

Powerheart® G5 Automated External Debrillator70-01704-01 B2

1About the AED
Contents
◆AED overview ......................................................................................1-1
◆AED parts ..............................................................................................1-2
◆The display panel ...............................................................................1-2
◆Debrillation pads ............................................................................ 1-3
◆CPR feedback device ....................................................................... 1-3
◆Intellisense® battery ........................................................................ 1-3
This section describes parts of the AED and the optional features for use in rescues.
AED overview
The Powerheart G5 automated external debrillator (AED) is
designed for treating life-threatening heart beat irregularities, such
as ventricular brillation, that cause Sudden Cardiac Arrest (SCA).
There are two models available—fully automatic and semi-automatic.
After the debrillations pads are applied to the patient, the fully
automatic model evaluates the heart rhythm and, if a shockable
rhythm is detected, delivers a shock without any rescuer assistance.
The semi-automatic model evaluates the heart rhythm and requires
the rescuer to press the shock button if a shockable rhythm is
detected. Both models have voice and text instructions that guide
the rescuer through the entire debrillation process.
Note: Not all congurations described in this document are available
in all areas.
1-1Powerheart® G5 Automated External Debrillator 70-01704-01 B

About the AED
AED parts
The display panel
R
E
A
D
Y
R
E
S
C
U
E
R
E
A
D
Y
R
E
S
C
U
E
AED is Rescue Ready. Rescue Ready technology
assesses the AED, battery, and pads to ensure
they are ready to perform a rescue.
AED is not Rescue Ready.
Pad package holders
Speaker
Pad socket/USB port
Display (details below)
SHOCKS 1
NOW SAFE
00:00
TO TOUCH PATIENT
Information display
◆ Number of shocks delivered
◆ Rescue timer
◆ Rescue prompts and CPR
countdown timer
Function buttons
Press to enter diagnostic mode or to
change the prompt language.
Smartgauge™ battery status indicator
The green LEDs display the capacity of
the battery. With use, the LEDs turn o
as battery capacity decreases. When
the green LEDs turn o and the red LED
lights, replace the battery.
Shock button (semi-automatic model
only)
◆ Lights red when the AED is ready to
deliver a debrillation shock.
◆ Press to deliver therapy to the patient.
Service indicator
Lights when the AED detects a need for
maintenance or service.
Debrillation pads indicator
Lights when the pads are:
◆ improperly connected to the AED
◆ cold, dried, or damaged
◆ detached from the patient during a rescue
Latch (press to open)
Pad expiration window
Lid
Battery compartment (on bottom)
Rescue Ready® status indicator
1-2 Powerheart® G5 Automated External Debrillator70-01704-01 B

See Warnings and cautions on page 3-1
for important safety
information.
CPR feedback device
The CPR feedback device is about the size
of the palm of a hand. Its non-slip surface
and shape transfers the rescuer’s com-
pressions to the patient’s chest. The CPR
feedback device (included with optional
preinstalled pads with CPR feedback de-
vice) measures the depth and rate of chest
compressions. The AED uses this information to help guide proper
compression rate and compression depth during CPR.
Note: Use of the CPR feedback device is optional.
If the CPR Feedback Device slips during CPR performance, continue
chest compressions as trained, without interruption.
If you do not use the CPR feedback device, place it on a surface next
to the patient. DO NOT attempt to detach the device from its cable.
Contact Cardiac Science Customer Care to order the preinstalled pads
with CPR feedback device.
*DO NOT use the CPR feedback device on children under 8 years old
or under 55 lbs.
Debrillation pads
The AED comes with debrillation pads installed. Pads are stored
in a ready-to-use, sealed package. The preinstalled pads are for use
with adults and children 8 years and older or over 55lbs. If the child
appears younger or lighter do not delay treatment to determine the
child’s exact age or weight, use the preinstalled pads. Pads are self-ad-
hesive with an attached cable and connector for power and ECG
transmission. Pads are disposable; discard after use in a rescue.
The pads have a limited shelf life and should not be used beyond the
expiration date. Always keep a fresh, unopened pair of pads plugged
into the AED.
The AED can identify the pad type and expiration date. The AED is
compatible with these types of pads:
◆XELAED001 debrillation pads
◆XELAED002 debrillation pads with CPR feedback device*
◆XELAED003 pediatric debrillation pads
When the patient is 8 years of age or younger or weighs 25 kg
(55 lbs) or less, use the AED with pediatric debrillation pads,
if available. See the instructions for use accompanying pediatric
pads to replace preinstalled pads with pediatric pads. DO NOT
delay therapy to determine the patient’s exact age or weight.
Contact Cardiac Science Customer Care to order replacement pads.
Important: Pediatric pads are not to be pre-connected to the AED.
Follow the instructions for use provided with pediatric pads.
About the AED
Intellisense®battery
The Intellisense battery (model XBTAED001) automatically stores history of its operating life.
The battery history can be reviewed with AED Manager software.
Important: See Warnings and cautions on page 3-1 for important safety information.
Note: Ensure that the battery is at room
temperature before inserting it into the AED.
How to replace the battery:
Press tab
1 2
Lift out
3
Insert new
5
Ensure Rescue Ready
is green
4
Press down to hear click
www.cardiacscience.com/batteryrecycle
1-3Powerheart® G5 Automated External Debrillator 70-01704-01 B
