Cardiac Science Burdick 8300 Manual

Burdick® 8300 and 8500 Electrocardiograph
Network Setup Guide
70-00900-02 C

BURDICK 8300 AND BURDICK 8500
NETWORK SETUP GUIDE
70-00900-02 C
Use this document to setup the network and troubleshoot network setup issues for the
Burdick 8300 and Burdick 8500 electrocardiograph.

Information in this document is subject to change without notice. Names and data used in
the examples are fictitious unless otherwise noted.
CE Mark Declaration
The CE marking of conformity indicates that the device having this symbol on its
immediate label meets the applicable requirements of the European Medical Device
Directive.
Trademark Information
Cardiac Science, the Shielded Heart logo, Quinton, Burdick, and HeartCentrix are
trademarks or registered trademarks of Cardiac Science Corporation. All other product
and company names are trademarks or registered trademarks of their respective companies.
Copyright © 2011 Cardiac Science Corporation. All Rights Reserved.
TO RESPONSIBLE SERVICE PERSONNEL:
The contents of this document are not binding. If any significant differences between the
product and this document are encountered regarding service work, contact Cardiac
Science Corporation for more information.
Cardiac Science Corporation recommends the use of authorized Cardiac Science
Corporation personnel for the maintenance and repair of all Burdick equipment. Cardiac
Science cannot warrant the operation of the equipment if other than Burdick genuine
replacement or exchange parts are used in the service or repair of this equipment, and if
such service or repair is performed by non-authorized personnel.
This product has been carefully designed to provide a high degree of safety and
dependability. However, we can not guarantee against the deterioration of components
due to aging and normal wear.
70-00900-02 C Burdick 8300/8500
ii
Cardiac Science Corporation
3303 Monte Villa Parkway
Bothell, WA 98021, USA
800.426.0337 (USA)
425.402.2000
[email protected]
www.cardiacscience.com
MDSS GmbH
Schiffgraben 41
D-30175 Hannover
Germany
EC REP

70-00900-02 C Contents iii
Contents
Contents
Chapter 1: Network Connection Set-up
Network connection worksheet.............................................................. 1-2
Wired Ethernet network setup ............................................................... 1-6
Wireless 802.11 network setup .............................................................. 1-7
Chapter 2: Exporting to Network Share
Network share worksheet ....................................................................... 2-2
Configuration ........................................................................................ 2-3
Chapter 3: Web Services Communications
Web services worksheet.......................................................................... 3-2
Configure web services communication ................................................. 3-3
Configure the ECG device .............................................................. 3-3
Register the ECG device.................................................................. 3-4
Download the custom header .......................................................... 3-5
Web services options ....................................................................... 3-6
Chapter 4: Network Printing
Plain paper printing worksheet............................................................... 4-2
Configuration ........................................................................................ 4-3
Automate plain paper printing ........................................................ 4-3
Chapter 5: Network Troubleshooting
General troubleshooting......................................................................... 5-2
Explanation of messages on the display .................................................. 5-3
Communication log messages ................................................................ 5-5
Appendix A: Supplicant Configuration Details
Configure and install the supplicant configuration file ...........................A-2
Custom configuration examples.............................................................A-3

Contents 70-00900-02 C
iv
Contents

Burdick 8300/8500 70-00900-02 C 1-1
1Network Connection Set-up
Contents
◆Network connection worksheet 1-2
◆Wired Ethernet network setup 1-6
◆Wireless 802.11 network setup 1-7
This section describes how to configure the ECG device for your network. Choose the
appropriate network setup (Wired Ethernet Network or Wireless 802.11 Network) and
configure the network before setting up any network functions. Use the network
connection worksheet to record settings specific to your network.
Note: You may need help from your network administrator to complete this section.
Cardiac Science recommends having your network administrator with you when completing
the configuration in this section.

Network connection worksheet Burdick 8300/8500
1-2
Network connection worksheet
Network connection worksheet Table 1-1: Network connection worksheet Burdick 8300/8500Software Ref# 20071019 or later
General Network Information:
Network Type: Ethernet (Wired Networks)
Network Type: 802.11 or Ethernet/802.11 (Wireless Networks) Explanation
DHCP (On/ Off) (Required) The method of obtaining a network address as defined by
the network administrator.
UTC/GMT time zone offset
This is the offset in hours (and optional minutes) the device applies to correct for your timezone. Note: You may need to subtract an hour from your offset during
Daylight Savings Time (or your local equivalent) if your region requires it.
Example: For Central Time zone (USA) enter "6" (winter) or "5" (summer), for Pacific Timezone (USA) enter "8" (winter) or "7" (summer), for Amsterdam enter "-1", and for Newfoundland enter "3:30".
If DHCP Off: Fixed IP Address (Required if DHCP is Off) The IP address assigned by the network
administrator for the ECG device. Enter: xxx.xxx.xxx.xxx Where each xxx is a number between 0 and 255.
Subnet Mask (Required if DHCP is Off) The Subnet mask assigned by the network
administrator for the facility's network. Enter: xxx.xxx.xxx.xxx Where each xxx is a number between 0 and 255.
Gateway IP Address (Required if DHCP is Off) The Gateway IP Address assigned by the
network administrator for the ECG device. Enter: xxx.xxx.xxx.xxx Where each xxx is a number between 0 and 255.

Burdick 8300/8500 Network Connection Set-up 1-3 Network Connection Set-up
Wireless 802.11 Information: Wireless Security Method: Choose:
•None—Security is disabled. •WEP— 64 or 128 bit WEP •WPA/WPA2 Personal—TKIP or AES, uses a shared key entered on
the access point and does not use a RADIUS server.
•WPA/WPA2 Enterprise—TKIP or AES with RADIUS Server. Use this
option for wpa-eap (including AES) enterprise mode. Select this option for PEAP/MSCHAPv2, EAP-TLS, LEAP, and EAP- FAST used with a RADIUS server (including Microsoft IAS, Cisco ACS, and Cisco Aironet 1200). Your ECG device automatically detects the EAP method that is configured on your wireless network. If, the automatic detection method is not compatible with your wireless network, refer to the “Supplicant Config” option.
•Supplicant Config—Sets a custom configuration when the
standard settings are not compatible with the wireless network. Refer to the section in this guide for more detailed information.
If None:
Wireless SSID (Required) The value configured on your wireless access point labeled
as “SSID”. Enter the value exactly; the field is case sensitive.
Wireless Channel (Required) The channel of the wireless network, which is programmed
into the wireless access point. A one or two digit number between 1 and 14.
If WEP:
Wireless Authentication (Required) The authentication method programmed into the wireless
access point. Choose open or shared. If you do not know, select open.
Wireless SSID (Required) The value configured on your wireless access point labeled
as “SSID”. Enter the value exactly; the field is case sensitive.
Table 1-1: Network connection worksheet Burdick 8300/8500Software Ref# 20071019 or later (continued)
General Network Information:
Network Type: Ethernet (Wired Networks)
Network Type: 802.11 or Ethernet/802.11 (Wireless Networks) Explanation

Network connection worksheet Burdick 8300/8500
1-4
Network connection worksheet
Wireless Channel (Required) The channel of the wireless network, which is programmed
into the wireless access point. A one or two digit number between 1 and 14.
Encryption Key 1 (Required if the wireless access point has an entry for Key 1.) WEP Key
1. This entry must match the wireless access point Key 1 exactly. A 13 hexadecimal digits for 64 bit WEP, or 26 hexadecimal digits for 128 bit WEP. Example of a 64 bit WEP key: 123A97B2345F6
Encryption Key 2 (Required if the wireless access point has an entry for Key 2.) WEP Key
2. This entry must match the wireless access point Key 2 exactly. 13 hexadecimal digits for 64 bit WEP, or 26 hexadecimal digits for 128 bit WEP. Example of a 64 bit WEP key: 123A97B2345F6
Encryption Key 3 (Required if the wireless access point has an entry for Key 3.) WEP Key
3. This entry must match the wireless access point Key 3 exactly. 10 hexadecimal digits for 64 bit WEP, or 26 hexadecimal digits for 128 bit WEP. Example of a 64 bit WEP key: 123A97B2345F6
Encryption Key 4 (Required if the wireless access point has an entry for Key 4.) WEP Key
4. This entry must match the wireless access point Key 4 exactly. 13 hexadecimal digits for 64 bit WEP, or 26 hexadecimal digits for 128 bit WEP. Example of a 64 bit WEP key 123A97B2345F6
If WPA or WPA2 Personal:
WPA Supplicant Timeout (Required) The default is 120 seconds. Adjust if the connection time to
your wireless network takes longer.
Table 1-1: Network connection worksheet Burdick 8300/8500Software Ref# 20071019 or later (continued)
General Network Information:
Network Type: Ethernet (Wired Networks)
Network Type: 802.11 or Ethernet/802.11 (Wireless Networks) Explanation

Burdick 8300/8500 Network Connection Set-up 1-5 Network Connection Set-up
Wireless SSID (Required) This value is configured on your wireless access point. It
may be labeled as “SSID” or as “DSSID”. Enter the value exactly; the field is case sensitive.
WPA/WPA2 Passphrase (Required) The shared passphrase that must match the passphrase
configured on your wireless access point.
If Supplicant Config:
WPA Supplicant Timeout (Required) The default is 120 seconds. Adjust if the connection time to
your wireless network takes longer.
If WPA or WPA2 Enterprise:
WPA Supplicant Timeout (Required) The default is 120 seconds. Adjust if the connection time to
your wireless network takes longer.
Wireless SSID (Required) This value is configured on your wireless access point. It
may be labeled as “SSID” or as “DSSID”. Enter the value exactly; the field is case sensitive.
WPA/WPA2 Enterprise ID (Required) Enter the ID (user name) that is set on the RADIUS Server on
the enterprise network that is used for this connection.
WPA/WPA2 Password (Required) Enter the password for the Enterprise ID (user name) that is
set on the RADIUS Server on the enterprise network that is used for this connection.
Table 1-1: Network connection worksheet Burdick 8300/8500Software Ref# 20071019 or later (continued)
General Network Information:
Network Type: Ethernet (Wired Networks)
Network Type: 802.11 or Ethernet/802.11 (Wireless Networks) Explanation

70-00900-02 C Burdick 8300/8500
1-6
Network Connection Set-up
Wired Ethernet network setup
Note: This procedure assumes you have a functional Ethernet network. If not, setup and test
your network before attempting to connect your 8300/8500. It is easier to test out Ethernet
network configurations using a PC or laptop first, and then attempt to add your 8300/8500
to the network. The 8300/8500 needs almost the same configuration information as a PC.
To configure the ECG device for use with a wired Ethernet network:
1. Press Setup,
2. Use the arrow keys (Next and Previous) to scroll to Network connection and press
Select.
Refer to the Network connection worksheet on page 1-2 to configure the network
connection fields. The fields that appear depend upon the network type that was
selected.
3. Enter your UTC/GMT time zone offset.
This is the offset in hours (and optional minutes) the device applies to correct for your
timezone.
Note: You may need to subtract an hour from your offset during Daylight Savings Time
(or your local equivalent) if your region requires it.
Example: For Central Time zone (USA) enter "6" (winter) or "5" (summer), for Pacific
Timezone (USA) enter "8" (winter) or "7" (summer), for Amsterdam enter "-1", and for
Newfoundland enter "3:30".
4. Connect the ECG device to your network.
Attach an RJ-45 cable to the RJ-45 port on the back of the ECG device and attach the
other end to an available RJ-45 Ethernet network port.
5. To complete the configuration see one of these sections:
•Chapter 2, Exporting to Network Share
•Chapter 3, Web Services Communications
•Chapter 4, Network Printing

Burdick 8300/8500 70-00900-02 C 1-7
Wireless 802.11 network setup
Wireless 802.11 network setup
!
Caution: Possible data corruption
This procedure requires you to access the Service Functions menu. The Service Functions
menu is intended for qualified Service personnel. If you have any question, please contact
Technical Support.
Note: This procedure assumes you have a functional wireless Ethernet (802.11) network. If
not, setup and test your network before attempting to connect your 8300/8500. It is easier to
test out wireless network configurations using a PC or laptop first, and then attempt to add
your ECG device to the network. The ECG device needs almost the same configuration as a
PC.
Note: Wireless 802.11 adapters are also compatible with 802.11g (54 MB/sec) wireless
802.11 networks.
Note: Before attempting to configure your unit for wireless communications, be sure you
have purchased the wireless 802.11 option from Cardiac Science.
To configure your ECG device for use with a wireless 802.11 network:
1. Press Setup,
2. Use the arrow keys (Next and Previous) to scroll to Network connection and press
Select.
Refer to the Network connection worksheet on page 1-2 to configure the 802.11 setup
fields. The fields that appear depend upon the wireless security method that was
selected.
Note: If you selected the wireless security option Supplicant config, refer to
Appendix A for detailed instructions.
3. Connect the 802.11 wireless adapter to the USB port on the back of the ECG device.
Note: Do not plug your USB adapter into your RJ-45 Ethernet connector, as it will not
work if plugged into the wrong receptacle.
4. Verify the configuration works with your wireless network:
a. Press Setup.
b. Use the arrow keys (Next and Previous) to scroll to Service functions and press
Select.
The system displays a warning message. Press Select to proceed.

70-00900-02 C Burdick 8300/8500
1-8
Network Connection Set-up
c. Select Te s t w p a s u pp l i ca n t c o n f ig .
Watch until the display indicates the results.
–If the results indicate success, then your configuration is correct for your wireless
network.
–If the results indicate a failure, then review your configuration to ensure that the
settings are correct for your wireless network.Repeat the test until the results
indicate success.
For troubleshooting tips see Chapter 5, Network Troubleshooting.
5. To complete the configuration see one of these sections:
•Chapter 2, Exporting to Network Share
•Chapter 3, Web Services Communications
•Chapter 4, Network Printing

Burdick 8300/8500 70-00900-02 C 2-1
2Exporting to Network Share
Contents
◆Network share worksheet 2-2
◆Configuration 2-3
Chapter 1, Network Connection Set-up is a prerequisite to this section. Ensure that the
network connection type is configured before completing this section. This section
explains how to configure the ECG device unit for communication to a computer that has
a network share. Additional configuration is required on the network share computer in
order to complete this setup.
Note: This section may require assistance from a network administrator.

70-00900-02 C Burdick 8300/8500
2-2
Exporting to Network Share
Network share worksheet
For a complete example of the entire setup, see Appendix A.
Table 2-1: Network share worksheet
Share Computer Information:
URL/IP
Share Name
Share Workgroup
Share Path
Share User
Share Password
Table 2-2: Field details
URL/IP (Required) The URL or the IP address of the device
assigned by the network administrator for the computer
with the network share. Enter:
xxx.xxx.xxx.xxx
Where each xxx is a number between 0 and 255.
Share Name (Required) The share name assigned by the network
administrator on the network share computer.
Share Workgroup (Optional) Workgroup or domain name assigned by the
network administrator on the network share computer.
Share Path (Optional) The path to the folder within the share on the
network share computer.
Share Username (Required) The Username of the user who has sufficient
rights to send a test to the share on the network share
computer.
Share Password (Required) The password for the Share Username.

Burdick 8300/8500 70-00900-02 C 2-3
Configuration
Configuration
To configure communication to a network share:
1. Press Setup,
2. Use the arrow keys (Next and Previous) to scroll to Printer and ECG destinations and
press Select.
3. Select Add new destination.
4. Set Destination type to Network share.
5. Enter the Destination name.
This is a text description of the share computer. Enter any text; Cardiac Science
suggests entering the name of the system.
6. Enter the URL/IP for the computer you wish to send the ECG to.
Your local system administrator can provide this information.
7. Enter the Workgroup.
This is the Microsoft Windows workgroup / domain. This is the same domain used
when you log onto Windows. See your system administrator for assistance.
8. Enter the Share name.
This is the location where the ECG data will be stored. To store the ECG data to the
root of the share, then leave this field blank. Use / (slash) to separate the sections of the
path. A leading / is optional.
Note: Some characters may be converted to underscores ( _ ) in network file share
names.
9. Enter the Path.
This is the full network path to the location of the share. If you wish to store the ECG
data to the root of the share, then leave this field blank. Use / (slash) to separate the
sections of the path. A leading / is optional.
10. Enter the User.
This is the Microsoft Windows user name. This is the same user name used when you
log onto Windows.
11. Enter the Password.
This is the Microsoft Windows user password. This is the same password used when
you log onto Windows.
12. Select the Ty p e :
•To store all the ECGs to a single folder, select Flat.
•To store ECGs in a separate folder for each patient, select Tr e e .

70-00900-02 C Burdick 8300/8500
2-4
Exporting to Network Share
13. Select the type of files to send, for each option select Enabled or Disabled:
•SCP
•PDF
•XML
14. Press Home.
15. Press ECG to take a test ECG.
16. Select the option to Quick send ECG.
Wait for the display to indicate that the record was sent successfully. If the send was
not completed successfully, refer to Chapter 5, Network Troubleshooting, for possible
resolutions.

Burdick 8300/8500 70-00900-02 C 3-1
3Web Services Communications
Contents
◆Web services worksheet 3-2
◆Configure web services communication 3-3
Chapter 1, Network Connection Set-up is a prerequisite to this section. Ensure that the
network connection type is configured before completing this section.

70-00900-02 C Burdick 8300/8500
3-2
Web Services Communications
Web services worksheet
Table 3-1: Web services worksheet
EMR System Information:
URL/IP
Web Services Provider ID
Registration Information:
Provider ID
Web User ID
Web Password
Table 3-2: Field details
URL/IP (Required) The URL/IP address of the EMR System.
If the system is a secure server, the line begins with “https://”,
otherwise start with “http://”. Add the IP address of the server
followed by a slash (/). Add the path name followed by a slash (/).
Add the server application name.
For example:
https://198.24.137.22/HeartCentrixAPI/USERWEBAPI.asmx
Web Services Provider ID (Required) The Provider ID of the EMR system.
Enter the name of the device (in lower case).
Registration Information:
Web Provider ID (Required if the field is defined on the EMR system) Web Provider ID
of the EMR system. May not be the same as the Web Services
Provider ID.
Enter: ecgmgmt
Web User ID (Required) Web User ID as defined on the EMR system.
Enter: cardiac
Web Password (Required) Password for the Web User ID.
Enter: science

Burdick 8300/8500 70-00900-02 C 3-3
Configure web services communication
Configure web services communication
To configure web services, configure and register the ECG device. You can also download a
custom header and setup orders.
Configure the ECG device
To configure the ECG device:
1. Press Setup.
2. Use the arrow keys (Next and Previous) to scroll to Printer and ECG destinations and
press Select.
3. Select Add new destination.
4. Set Destination type to Pyramis/HeartCentrix.
5. Enter an Destination name.
This is a text description of the EMR your system is configured to connect to. Enter
any text; Cardiac Science suggests entering the name of the system.
6. Enter the Web Services URL/IP.
a. If the server is a secure server, begin the line with: https://, otherwise start with
http://.
b. Add the IP address of the server followed by a slash (/).
c. Add the path name followed by a slash (/).
d. Add the server application name.
For example: https://198.24.137.22/HeartcentrixAPI/
USERWEBAPI.asmx
7. For the Web Services Provider ID, enter the name of the device in lower case.
See your EMR administrator for help with this.
8. For Institution number, enter 1.
This number is transmitted to the EMR system with your ECG record. The
Institution number is usually 1, unless your server services multiple institutions.
9. For Device Id enter 0000.
This is a unique, user definable number identifying this specific ECG device. The
Device Id is transmitted to the EMR system with your ECG record.
10. Continue the web services configuration with Register the ECG device on page 3-4.
