STEP 1.
Insert part 7 into part 5. Feed part 4
through parts 3, 5 and 2. Hold part 1
by hand. Use the hex wrench to lock
part 4. Assemble part 1 and part 6 as
above.
Flexus Adjustable Bed Rail - BD06022
www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Usage and Maintenance Instructions
STEP 2.
Insert part 1 into part 8 and insert part
7 (seat belt) into part 9. Assemble
part 8 according to the method of
STEP 1. Lock all screws tightly.
No.
7
8
9
10
11
12
Part Name
Safety Belt (Short)
Main Frame
Supporting Foot - Right
Telescopic Inner Tube Set
Telescopic Outer Tube Set
Safety Belt (Long)
Quantity
1
1
1
1
1
1
No.
1
2
3
4
5
6
Part Name
Inner Tube
Plastic Curved Gasket
Iron Arc Gasket
Pan Head Hexagonal Screw
Supporting Foot - Left
Cross Tube
Quantity
1
4
4
4
1
1
1 Inner Tube
2 Plastic Curved Gasket
3 Iron Arc Gasket
4 Pan Head Hexagonal Screw
5 Supporting Foot - Left
6 Cross Tube
7 Safety Belt (Short)
8 Main Frame
9 Supporting Foot - Right
10 Telescopic Inner Tube Set
11 Telescopic Outer Tube Set
12 Safety Belt (Long)

SAFETY INSTRUCTIONS
1. When using make sure that the seat belt is tied to the matress and the bed board, and the mattress is
pressed against the support foot.
2. When the bolts on both sides are completely inserted into the hole, the armrest frame is fixed and can
be used.
3. The maximum load must not exceed 180kg.
4. This product needs to be properly installed and used correctly. If it is installed incorrectly or used
improperly it will cause damage to the product and risk personal injury.
STEP 3.
Press part 10 into the marble and insert into part 11. Adjust the marble to the appropriate
hole position. Insert part 12 into part 7. Bind the mattress with part 12 to complete
assembly.
Note:
Apply pressure using your
hand to the area indicated by
the arrow when stretching.
