Usage and Maintenance Instructions
Lavenham & Weymouth Tables - RR07135/RR07136
www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Thank you for choosing an overbed table by CareCo, our design and quality are a guaranteed for comfort, safety and reliability.
Our tables are designed and built to meet all your demands for a practical, correct use. This user manual provides some
suggestions to correctly use the table you have chosen and offers a lot of valuable advice for your safety. Please read carefully
through the manual before using the overbed table. Should you have any queries, please contact your retailer for advice and
assistance.
The bed trays are primarily intended for people who have mobility problems, mainly bedridden where it is expected the
consumption of meals in bed or chair. However they are adaptable for both hospitals and home.
Always pay close attention to the presence of moving parts that could cause limb entrapment and injury.
• For proper use of the device refer to this manual.
• For proper use of the device consult your doctor or therapist.
• Keep the packaged product away from any source of heat because the packaging is made of cardboard.
• The shelf-life of the accessory is determined by the wear of parts that cannot be repaired and / or replaced.
• Be careful when children are nearby.
• Do not exceed the maximum payload.
A. Big screw – 2pc
B. Small screw – 2pc
C. Perforated plate – 1pc
D. Tools – 2pc
E. Base – 1pc
F. Castors – 4pc
G. Column - 1pc
H. Big table – 1pc
*Small table and big table pre-setup
Check that the product has not been damaged during shipment. In case of damage do not use it and contact your dealer for
further instructions.
RR07136 - Lavenham Tilt-Top Overbed Table
Introduction
Intended Use
General Warnings
Note:
C
A B
D
• Do not use the product for a purpose not indicated in this manual.
• CareCo declines all responsibilities for any consequences resulting from an incorrect use of this product and from
unauthorized alteration to the frame of the product.
• The manufacturer reserves the right to change the information contained in this document without previous notice.

1. Unpack the product and check the content matches with the description of the
parts in the manual.
2. Assemble the four castors by inserting them into the holes on the base.
3. Once this is done assemble the column onto the base using the tools provided.
4. Assemble the column onto the table by undoing the Knob on the column and the
2 screws underneath the table. Once this is done position the column into place
and slot each screw in and tighten with tools provided.
5. Now the overbed table is ready for use.
www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Lavenham & Weymouth Tables - RR07135/RR07136
A. Big screw – 2pc
B. Small screw – 1pc
C. Perforated plate – 1pc
D. Tools – 1pc
E. Base – 1pc
F. Castors – 4pc
G. Column - 1pc
RR07135 - Weymouth Tilt-Top Overbed Table
Assembly - Lavenham Tilt-Top Overbed Table - RR07136
A B C
Note: Do not remove the safety band before point 3.
Assembly - Weymouth Tilt-Top Overbed Table - RR07135
1. Unpack the product and check that the content matches with the description.
2. Assemble the four castors by inserting them into holes on the base.
3. Assemble column using the perforated plate, big screws and cylinder tube and lock them with the 17mm Spanner.
4. Unscrew the black screw on the column and replace with the smaller screw (B) provided.
5. Now the overbed table is ready for use.
Note: Do not remove the safety band before point 3.
fig. 1

www.careco.co.ukCareCo, Hubert Road, Brentwood, Essex, CM14 4JE
Lavenham & Weymouth Tables - RR07135/RR07136
RR07135 - Weymouth Tilt-Top Overbed Table
A
B
To disassemble do the exact opposite of the assembly instructions.
• Always check the status of the mechanical parts to guarantee they are used in total safety.
• Check the device is properly assembled. Pay particular attention to the locking of the knobs.
• Do not exceed the maximum load capacity.
• Make sure that the floor surface supporting the overbed table is level.
• Make the adjustment operations without load.
• Check all components are well fixed.
• Always assist the patient during the elevation operation
The assistant must place and adjust the overbed table with the maximum care to avoid sudden movements or dangerous
oscillations. An assistant has to check any movement of the patient.
Check the structure periodically: the correct positioning of the tubes, the connections, the hooks, and the complete
tightening of screws and / or terminals.
Use a damp cloth or a solution of lukewarm water and neutral soap. Do not use abrasive substances, acids,alkali, alcohol,
chlorine-based cleaners, disinfectants and acetone when cleaning,because these substances cause the abrasion of the plastic
surfaces and rusting of the metal surfaces.
The manufacture company is not responsible for any damage caused by using materials that can damage the product surface
or corrosive chemicals during cleaning.
If you need to disinfect the product, use a common delicate disinfectant neutral detergent.
Tighten the handle to lock at the required height. By turning
the handle (fig. 2) the big tray can rotate. Tighten the handle
again to lock it at the required inclination.
By pulling the handle (A) the tray will lift up automatically. Pushing
on the tray, it will come down. Tighten the lever to lock at the
required height. By turning the handle (B), the tray can rotate.
Tighten the handle again to lock it at the required inclination.
Disassembly
Before Use
Precautions For Use
How To Use
Maintenance
Cleaning and Disinfection
RR07136 - Lavenham Tilt-Top Overbed Table
fig. 2

www.careco.co.uk CareCo, Hubert Road, Brentwood, Essex, CM14 4JE
When disposing of the device, never use the normal return systems of municipal solid waste. It is recommended instead the
disposal through the joint municipal ecological islands for the expected operations of recycling the materials used.
Height 80-120cm
Small table Width 20cm
Big table Width 60.5cm
Depth 39cm
Weight about 12kg
Pay load 20Kg
Height 78-110cm
Width 77cm
Depth 39cm
Weight about 12 kg
Pay load 20Kg
For spare parts and accessories, please contact CareCo. CareCo shall not be liable for any incident caused by improper use.
Your CareCo branded product is under warranty to be free from defects in material and workmanship for one year from date of
receipt. This warranty expresses our confidence in the workmanship and materials used for our products.
In the event of a defect covered by this warranty, CareCo will, at our discretion, replace the product or supply parts to remedy.
This warranty does not cover device failure due to owner misuse or negligence, or due to normal wear and tear. The warranty
does not extend to non-durable parts. If you have any queries please contact CareCo.
The manufacturer reserves the right to alter without notice any weights, measurements or other technical data shown in this
manual. All figures, measurements and capacities shown in this manual are approximate and do not constitute specifications.
Conditions of Disposal
Spare Parts
Warranty
Technical Specification
RR07135 - Weymouth Tilt-Top Overbed TableRR07136 - Lavenham Tilt-Top Overbed Table
• Painted and chromed steel frame
• Manual adjustable height (only for RR07036)
• Automatic adjustable height with lever (only for RR07035)
• Laminate table scratch resistant
• Containment edge made in polypropylene
• Anti-shock and cut resistant edge made in polyethylene
• Reclining table in more positions
• Small table(*only for RR07036)
