Carrier WF-60A1 Operating instructions

INSTALLATION&
OWNER’ S MANUAL
SMART PORT OF AIR CONDITIONER
MODEL: WF-60A1
Thank you very much for purchasing our product. Before
using your unit, please read this manual carefully and keep it
for future reference.

GB- 1
1. SAFETY PRECAUTION
Smart Phone camera needs to be 5 million pixels
or above to make sure scan QR code well.
Due to different network situation, sometimes,
request time-out could be happened, thus, it is
necessary to do network conguration again.
Due to different network situation, sometimes,
control process may return time out. If this
situation occurs, do not feel confused, the display
on board and App may not be the same.
1. SAFETY PRECAUTION
Read the safety precautions carefully before
installing the unit.
Stated below are important safety issues that
must be obeyed.
Applicable system: iOS, Android.
(Suggest: iOS 8.0 or later , Android 4.0 or later)
Please check the service website for more
applicable devices.
Disclaimer: Due to the special situation existed
during App use, we explicitly claim as below:
Not all of the Andriod and iOS systems are
compatible with APP. We will not be responsible
for any issues as a result of the incompatibility.
Smart Kit wireless safety strategy
Smart Kit only support WPA-PSK/WPA2-PSK
encryption and none encryption .
WPA-PSK/WPA2-PSK encryption is
recommended.
CONTENTS
1. SAFETY PRECAUTION ...................................... 1
2. DOWNLOAD AND INSTALL APP........................ 2
3. INSTALLATION ACCESSORY ............................ 2
4. INSTALLATION METHOD................................... 2
5. SPECIFICATION ................................................. 4
6. USER REGISTRATION....................................... 4
7. NETWORK CONFIGURATION ........................... 4
8. HOW TO USE APP.............................................. 7
9. SPECIAL FUNCTIONS ....................................... 8
10. CHANGE THE INFORMATION OF DEVICE... 10
• This manual gives detailed description of the
precautions that should be brought to your
attention during operation.
• In order to ensure correct service of the smart
port, please read this manual carefully before
using the unit.
• For convenience of future reference, keep this
manual after reading it.

GB- 2
4. INSTALLATION METHOD
3. Wiring gure
4-core shielding wire
Extension cord
(purchased separately) Mainboard
The connective wires group-1
CN40
Fig 4-3
• Connect the male joint of the connective wires
group-1 to the mainboard, then connect the other
side of the connective wires group-1 to the 4-core
shielding wire of the smart port.(See Fig.4-3)
• If want to extent the wire, please use extension
cord (purchased separately). (See Fig.4-3)
4.Remove the upper part of the smart port
• Insert a slot screwdriver into
the slots in the lower part of the
smart port (2 places), and remove
the upper part of the smart port.
(Fig.4-4) Slots
Fig 4-4
4. INSTALLATION METHOD
1. WLAN controller structure size gure
Fig 4-1
2. Wiring Principle Sketch:
-----------------------------------
-----------------------------------
-----------------------------------
-----------------------------------
red red
black black
yellow yellow
brown brown
Fig 4-2
WLAN control box Indoor unit mainboard
Applicable to WF-60A1 only
4-Core Shield Cable, the length is
decided by installation
Insert of the mainboard CN40
3. INSTALLATION ACCESSORY
Select the installation location
Don't install at the place which is covered with heavy
oil, vapor or sulfureted gas, otherwise, this product
would be deformed that would lead to system
malfunction.
Preparation before installation
1. Please conrm that all the following parts have
been supplied.
No. Name Qty. Remarks
1Smart port 1 ————
2Installation and
owner’s manual 1 ————
3Screws 3
M4X20 (For
Mounting on the
Wall)
4Wall plugs 3 For Mounting on the
Wall
5Smart kit 1 ————
6The connective wires
group-1 1 See Fig.4-3
74-core shielding wire 1 See Fig.4-3
8Remote controller* 1 ————
9Battery* 2 ————
10 Remote controller
Manual* 1 ————
* These parts can be removed, which have been
included AC unit.
2. DOWNLOAD AND INSTALL APP
• Android System:
Scan QR Code or go to Google play, search for
'Carrier air conditioner' app and download it.
• iOS System:
Scan QR Code or go to App Store and search for
'Carrier air conditioner' app and download it.
Android iOS

GB- 3
4. INSTALLATION METHOD
9. Connect the smart port to the wire controller (if
needed)
①Remove the top cover from the gap between the
top cover and bottom by a tool with at head. (See
Fig.4-11)
②Use the connective cable to connect the wire
controller and CN3 of the smart port. (See Fig.4-12)
(refer to the Wire controller manual for details)
CN3
Fig 4-11 Fig 4-12
NOTE:
• Connection for R485 Communication wired
controller.
4. INSTALLATION METHOD
Putty Trap Putty
Fig 4-9
CAUTION
Trap
Avoid the water enter into the smart port, use trap
and putty to seal the connectors of wires during
wiring installation. (Fig. 4-9) When under installation,
reserve certain length of the connecting wire for
convenient to take down the smart port while during
maintenance.
8.Reattach the upper part of the smart port
• After adjusting the upper case and then buckle
the upper case; avoid clamping the wiring during
installation. (Fig 4-10)
Fig 4-10
4. INSTALLATION METHOD
7.Wiring
A. For exposed mounting, two outletting positions.
Top side wire outlet
Bottom side wire outlet Fig 4-7
B. Shielded wiring
Wiring through the wall
Wiring hole and wall hole
Diameter of wall hole:Φ20mm Fig 4-8
4. INSTALLATION METHOD
5. Fasten the back plate of the smart port
• For exposed mounting, fasten the back plate on
the wall with the 3 screws (M4×20) and plugs.
(Fig.4-5)
Back plate
Screws (M4×20)
Fig 4-5
6. Insert the smart kit with slightly strength into the
main PCB of the smart port .(Fig.4-6)
Fig 4-6

GB- 4
7. NETWORK CONFIGURATION
Kindly reminder:
• When the air conditioner entered into WLAN
network setting mode, the remote controller can
not control the AC before the WLAN network
setting nished.
• If there is no setting operation under WLAN
network setting mode, the air conditioner will quit
this mode automatically 8 minutes later, then the
user can control the AC with remote controller
normally.
Add device to the account
Note: The conguration process is different for
Android system and iOS system mobile.
First, open the APP, sign in with the registered
account and password.
If the mobile is Android system, please follow the
process as below, if the mobile is iOS system,
please go to page 10 and follow the process.
7. NETWORK CONFIGURATION
CAUTION
• It is better to log in email box and active
registration account by clicking link in case forget
the password.
• Make sure the mobile connect to the WLAN
network.
• Make sure the mobile WLAN function works
well and can be connected to WLAN network
automatically.
• If the Smart Kit failed to connect to the router,
please conrm the encryption setting of router
should be WPA.
Set Air conditioner into AP mode
①Disconnect the power supply of Air conditioner.
②Connect the power supply of Air conditioner, press
the ‘LED’ button on the remote controller for 7
times continuously.
③ When the display show ‘AP’ and ash, it means
that the Smart Kit has already entered the WLAN
network setting mode.
• Some type of AC do not need the step to be in AP
mode.
6. USER REGISTRATION
• Please ensure the mobile device has connected
to WLAN router. And the router has already
connected to Internet before registration and
network conguration.
[email protected]
Create Account
①Click ‘Create Account’. ②Enter your email
address and
password, and then
click ‘Registration’.
5. SPECIFICATION
Smart Kit Model OSK102/EU-OSK103/
US-OSK103
Standard IEEE802.11b/g/n
Antenna Type Printed PCB Antenna
Frequency WLAN: EU--
2412~2472MHz; US--
2412~2462MHz
Maximum Transmitted
Power
19.8 dBm Max
Operation Temperature 0°C~45°C/32°F~113°F
Operation Humidity 10%~85%
Power Input DC 5V/300mA

GB- 5
7. NETWORK CONFIGURATION
WLAN
WLAN
family WLAN
⑥Please enter
password.
⑦ Network conguration
is successful.
7. NETWORK CONFIGURATION
④Choose the network
conguration method.
* Note: No need to scan
QR code to complete
conguration.
⑤Choose the “Manual
Setup” method.
7. NETWORK CONFIGURATION
③Follow the above steps to enter “AP” mode.
7. NETWORK CONFIGURATION
Network conguration for Android system mobile
Select Appliance Type
①Press ‘+ Add Device’ ②Select the appliance
you are setting up.

GB- 6
7. NETWORK CONFIGURATION
④Connect to the
Wireless network.
⑤Please enter
password.
7. NETWORK CONFIGURATION
③Follow the above steps to enter “AP” mode.
7. NETWORK CONFIGURATION
Network conguration for iOS system mobile
Select Appliance Type
①Press ‘+ Add Device’ ②Select the appliance
you are setting up.
7. NETWORK CONFIGURATION
Recommend Name (Support by ECHO):
Self-defining Name (Cannot support by ECHO):
Living Room
Dining Room
Kitchen
Master bedroom
Children bedroom
Study
Guest bedroom
Storage room
Air Condtioner40C8
Device name Save
Air Condtioner40C8
⑧ Conguration
Success, you can
choose the name as
you like.
⑨Finally, you can see
the device on the list.

GB- 7
8. HOW TO USE APP
③Touch the logo in the
center to turn on the
air conditioner.
④Now, the air
conditioner is available
to be controlled by
APP.
NOTE:
• Not all the functions of the APP are available for
every air conditioner. For example: ECO is only
available for inverter model, vertical louver swing
is only available for the models with vertical
swing motor.
8. HOW TO USE APP
Please ensure both mobile device and air conditioner
are connected to the Internet before using app to
control the air conditioner via internet, please follow
the next steps:
[email protected]
Air Condtioner40C8
①Enter user account
and password, Click
"Sign in ".
②Select the target air
conditioner to enter
the main control
interface.
7. NETWORK CONFIGURATION
Air Condtioner40C8
⑧Finally, you can
see the device
on the list.
NOTE:
• When nishing network
conguration, APP will
display success cue words
on the screen.
• Due to different internet
environment, it is possible
that the device status still
display “ofine” and can
not access to the operation
interface.
If this situation occurs, user
should pull the device list
down and refresh the status
become “online”.
If it does not work, turn off
the AC power and turn on it
again.
7. NETWORK CONFIGURATION
Recommend Name:
Custom Name:
Living Room
Dining Room
Kitchen
Master bedroom
Children bedroom
Study
Guest bedroom
Storage room
Air Condtioner40C8
Device name Save
WLAN
WLAN
⑥ Network conguration
is successful.
⑦ Conguration
Success, you can
choose the name as
you like.

GB- 8
9. SPECIAL FUNCTIONS
9. SPECIAL FUNCTIONS
Including: Timer on, Timer off, 8°C Heat, Sleep,
Check.
NOTE:
●The Smart Kit will check the software program in
the air conditioner control parts, only show the
available functions on the APP.
Timer on/ Timer off
Weekly, user can make an appointment to turn on
or turn off the AC on specic time. User can choose
circulation to keep the AC under schedule control
every week.
8. HOW TO USE APP
ON/OFF:
Press this button to turn on or turn off the unit.
Mode selection:
Press this button to change the running mode (COOL, HEAT,
DRY, FAN, AUTO)
Fan speed selection:
Press this button to change the fan speed High fan 3 layer
Med fan 2 layer Low fan 1 layer
Turbo: *
Press this button to active turbo mode. (Only available for
cool running)
IntelligentEye *
Press these button to select wind ow follow people or wind
ow away from
people.
ECO : *
Press this button to active ECO mode.
Comfort Humidity : *
Press this button to detect humidity level of the room.
Vertical louvers swing: *
Press this button to active the vertical louvers swing.
Horizontal louvers swing:
Press this button to active the horizontal louvers swing.
Celsius / Fahrenheit:
Press this button to change the temperature unit showing on
the AC display.
Setting temperature:
Touch the screen near the temperature, slip up & down to
change the
temperature, do not loosen nger until the number reach to
target.
28
* Model dependent
8. HOW TO USE APP
Main interface and functions
Device Name
Running mode
Setting
temperature
Fan speed
ON/OFF
Intelligent Eye
Horizontal
louvers swing
Vertical
louvers swing
Celsius /
Fahrenheit
ECO
mode
Special
functions
Mode
selection
Fan speed
selection
Turbo
Dehumidity
Page selection

GB- 9
9. SPECIAL FUNCTIONS
Share Device
The air conditioner can be controlled by multi-
users at the same time by Share Device function.
① ②
Now please ask your family to use APP
on their own mobile phones to scan
this QR code and share this device to
them.
①Click “Share device” ②Let the others to scan
the displayed QR
code.
9. SPECIAL FUNCTIONS
Check
This function can simply check the AC running
status.
When nishing this procedure, it can show
the normal items, abnormal items, and detail
information.
9. SPECIAL FUNCTIONS
Sleep
This funciton can customize comfortable sleep by
setting target temperature.
Edit
Young
Older
Children
9. SPECIAL FUNCTIONS
8°C Heat
In this mode, the air conditioner will run under 8°C
Heat. When people go outisde, this function can
protect the furniture from frost damage.
