Product Data

24APA7

Performancet17 2---Stage Air Conditioner

with PuronrRefrigerant

2to5Tons

the environmentally sound refrigerant

Carrier’s Air Conditioners with Puronrrefrigerant provide a

collection of features unmatched by any other family of

equipment. The 24APA7 has been designed utilizing Carrier’s

Puron refrigerant. The environmentally sound refrigerant allows

you to make a responsible decision in the protection of the earth’s

ozone layer.

This product has been designed and manufactured to meet

Energy Starrcriteria for energy efficiency when matched with

appropriate coil components. Refer to the combination ratings in

the Product Data for system combinations that meet Energy Starr

guidelines.

NOTE:Ratings contained in this document are subject to

change at any time. Always refer to the AHRI directory

(www.ahridirectory.org) for the most up--to--date ratings

information.

INDUSTRY LEADING

FEATURES / BENEFITS

Efficiency

S14 -- 18 SEER / 11.6 -- 13.9 EER

SMicrotube Technologytrefrigeration system

SIndoor air quality accessories available

Sound

SSound level as low as 71 dBA

Comfort

SSystem supports InfinitytControl or standard 2--stage

thermostat controls

Reliability

SPuronrrefrigerant -- environmentally sound, won’t

deplete the ozone layer and low lifetime service cost.

SFront--seating service valves

S2--stage scroll compressor

SInternal pressure relief valve

SInternal thermal overload

SLow pressure switch

SHigh pressure switch

SFilter drier

SCrankcase Heater standard

SBalanced refrigeration system for maximum reliability

Durability

WeatherArmortprotection package:

SSolid, Durable sheet metal construction

SSteel louver coil guard

SBaked--on, complete outer coverage, powder paint

Applications

SLong--line -- up to 250 feet (76.2 m) total equivalent

length, up to 200 feet (60.96 m) condenser above

evaporator, or up to 80 ft. (24.38 m) evaporator above

condenser (See Longline Guide for more information.)

MODEL NUMBER NOMENCLATURE

12 3 4567

91011 12 13

NN A AA/N N N A/N A/N A/N N N

24 A P A 7 36A00 3 0

Product

Series

Product

Family

Tier Major

Series

SEER Cooling

Capacity

Variations Open Open Voltage Minor

Series

0, 1, 2...

24=AC A=RES AC P =

Performance

A=Puron 7=17

SEER

Nominal

A=Standard 0=Not

Defined

0=Not

Defined

3=208/230---1

the environmentally sound refrigerant

This product has been designed and manufactured to

meet Energy Star®criteria for energy efficiency when

matched with appropriate coil components. However,

proper refrigerant charge and proper air flow are critical

to achieve rated capacity and efficiency. Installation of

this product should follow all manufacturing refrigerant

charging and air flow instructions. Failure to confirm

proper charge and air flow may reduce energy

efficiency and shorten equipment life.

Use of the AHRI Certified

TM Mark indicates a

manufacturer’s

participation in the

program For verification

of certification for individual

products, go to

www.ahridirectory.org.

STANDARD FEATURES

FEATURES

Unit Size --- Voltage, Series

24---30 36 ---30 48---31 60 ---31

Puron Refrigerant XXXX

Maximum SEER Rating* 17.0 18.0 17.5 17.0

2--- Stage Scroll Compressor XXXX

Crankcase Heater w/Temperature Switch XXXX

Long line Capability XXXX

Low Ambient Capability to 0_F (---17.8_C) w/Infinity Control XXXX

Enhanced Diagnostics w/Infinity Control XXXX

Utility Interface Connection XXXX

Louvered Coil Guard XXXX

FieldInstalledFilterDrier XXXX

Front Seating Service Valves XXXX

Internal Pressure Relief Valve XXXX

Internal Thermal Overload XXXX

Long Line capability XXXX

Low Pressure Switch XXXX

High Pressure Switch XXXX

Sound Blanket XXXX

X=Standard

* With approved combinations

24APA7

REFRIGERANT PIPING LENGTH LIMITATIONS

Liquid Line Sizing and Maximum Total Equivalent Lengths{for Cooling Only Systems with PuronrRefrigerant:

The maximum allowable length of a residential split system depends on the liquid line diameter and vertical separation between indoor and

outdoor units.

See Table below for liquid line sizing and maximum lengths :

Maximum Total Equivalent Length

Outdoor Unit BELOW Indoor Unit

Size Liquid Line

Connection

Liquid

Line

Diam.

w/TXV

AC with Puron Refrigerant Maximum Total Equivalent Length{: Outdoor unit BELOW Indoor

Vertical Separation ft (m)

0 --- 5

(0---1.5)

6 --- 1 0

(1.8---3.0)

11---20

(3.4---6.1)

21---30

(6.4---9.1)

31---40

(9.4---12.2)

41---50

(12.5---15.2)

51---60

(15.5---18.3)

61---70

(18.6---21.3)

71---80

(21.6---24.4)

024

AC with

Puron

3/8

1/4 75 75 75 50 50 --- --- --- --- --- --- --- ---

5/16 250* 250* 250* 250* 250* 225* 175 125 100

3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*

036

AC with

Puron

3/8 5/16 175 150 150 100 100 100 75 --- --- --- ---

3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*

048

AC with

Puron

3/8 3/8 250* 250* 250* 250* 250* 250* 230 160 --- ---

060

AC with

Puron

3/8 3/8 250* 250* 250* 225* 190 150 110 --- --- --- ---

* Maximum actual length not to exceed 200 ft (61 m)

{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.

--- --- = o u t s i d e a c c e p t a b l e r a n g e

Maximum Total Equivalent Length

Outdoor Unit ABOVE Indoor Unit

Size Liquid Line

Connection

Liquid

Line

Diam.

w/TXV

AC with Puron Refrigerant Maximum Total Equivalent Length{: Outdoor unit ABOVE Indoor

Vertical Separation ft (m)

(7.6)

26---50

(7.9---15.2)

51---75

(15.5---22.9)

76---100

(23.2---30.5)

101---125

(30.8---38.1)

126---150

(38.4---45.7)

151---175

(46.0---53.3)

176---200

(53.6---61.0)

024

AC with

Puron

3/8

1/4 100 125 175 200 225* 250* 250* 250*

5/16 250* 250* 250* 250* 250* 250* 250* 250*

3/8 250* 250* 250* 250* 250* 250* 250* 250*

036

AC with

Puron

3/8 5/16 225* 250* 250* 250* 250* 250* 250* 250*

3/8 250* 250* 250* 250* 250* 250* 250* 250*

048

AC with

Puron

3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*

060

AC with

Puron

3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*

* Maximum actual length not to exceed 200 ft (61 m)

{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.

REFRIGERANT CHARGE ADJUSTMENTS

Liquid Line Size Puron Charge oz/ft (g/m)

3/8 0.60 (17.74)

(Factory charge for lineset = 9 oz / 266.16 g)

5/16 0.40 (11.83)

1/4 0.27 (7.98)

Units are factory charged for 15 ft (4.6 m) of 3/8” liquid line. The factory charge for 3/8” lineset 9 oz.(266.16 g). When using other length

or diameter liquid lines, charge adjustments are required per the chart above.

Charging Formula:

[(Lineset oz/ft x total length) – (factory charge for lineset)] = charge adjustment

Example 1: System has 15 ft of line set using existing 1/4“ liquid line. What charge adjustment is required?

Formula: (.27 oz/ft x 15ft) – (9 oz) = (-4.95) oz.

Net result is to remove 4.95 oz of refrigerant from the system

Example 2: System has 45 ft of existing 5/16” liquid line. What is the charge adjustment?

Formula: (.40 oz/ft. x 45ft) – (9 oz.) = 9 oz.

Net result is to add 9 oz of refrigerant to the system

24APA7

LONG LINE APPLICATIONS

An application is considered Long Line, when the refrigerant level in the system requires the use of accessories to maintain acceptable

refrigerant management for systems reliability. See Accessory Usage Guideline table for required accessories. Defining a system as long line

depends on the liquid line diameter, actual length of the tubing, and vertical separation between the indoor and outdoor units.

For Air Conditioner systems, the chart below shows when an application is considered Long Line.

AC WITH PURONrREFRIGERANT LONG LINE DESCRIPTION ft (m)

Beyond these lengths, long line accessories are required

Liquid Line Size Units On Same Level Outdoor Below Indoor Outdoor Above Indoor

1/4 No accessories needed within allowed

lengths

No accessories needed within allowed

lengths 175 (53.3)

5/16 120 (36.6) 50 (15.2) vertical or 120 (36.6) total 120 (36.6)

3/8 80 (24.4) 35 (10.7) vertical or 80 24.4) total 80 (24.4)

Note: SeeLongLineGuidelinefordetails

VAPOR LINE SIZING AND COOLING CAPACITY LOSS

Acceptable vapor line diameters provide adequate oil return to the compressor while avoiding excessive capacity loss. The suction line

diameters shown in the chart below are acceptable for AC systems with Puron refrigerant:

Vapor Line Sizing and Cooling Capacity Losses — PuronrRefrigerant 2--Stage Air Conditioner Applications

Unit

Nominal

Size (Btuh)

Maximum

Liquid

Line

Diameters

(In. OD)

Vapor Line

Diameters

(In.) OD

Cooling Capacity Loss (%)

Total Equivalent Line Length ft. (m)

26 --- 50

(7.9---15.2)

51 --- 80

(15.5---24.4)

81 --- 100

(24.7---30.5)

101 --- 125

(30.8---38.1)

126 --- 150

(38.4---45.7)

151 --- 175

(46.0---50.3)

176 --- 200

(53.6---60.0)

201 --- 225

(61.3---68.6)

226 --- 250

(68.9---76.2)

024

2 --- S t a g e

Puron

3/8

5/8 011233445

3/4 000011111

036

2 --- S t a g e

Puron

3/8

5/8 124567910 11

3/4 001122334

7/8 000011112

048

2 --- S t a g e

Puron

3/8

3/4 122345677

7/8 011222333

1 --- 1 / 8 0 0 — — — — — — —

060

2 --- S t a g e

Puron

3/8

3/4 124567910 11

7/8 012234455

1 --- 1 / 8 000111111

Applications in this area may be long line and may have height restrictions. See the Residential Piping and Long Line Guideline.

— Applications in this area are not recommended due to insufficient oil return

PHYSICAL DATA

UNIT SIZE --- VOLTAGE, SERIES 24 --- 30 36 --- 30 48 --- 31 60 --- 31

Operating Weight lb (kg) 204 (93) 204 (93) 306 (139) 316 (143)

Shipping Weight lb (kg) 243 (110) 243 (110) 363 (165) 373 (169)

Compressor Type 2 --- S t a g e S c r o l l

REFRIGERANT Puron (R ---410A)

Control TXV (Puron Hard Shutoff)

Charge lb (kg) 6.63 (3.01) 6.88 (3.12) 11.63 (5.27) 15.13 (6.86)

COND FAN Propeller Type, Direct Drive

Air Discharge Vertical

Air Qty (CFM) 3100 3400 4300 4450

Motor HP 1/10 1/5 1/4 1/4

Motor RPM 800 800 800 800

COND COIL

Face Area (Sq ft) 21.56 21.56 25.15 30.18

Fins per In. 25 25 20 20

Rows 1 1 2 2

Circuits 4 4 7 8

VALVECONNECT.(In.ID)

Vapor 3/4 7/8 7/8 7/8

Liquid 3/8

REFRIGERANT TUBES (In. OD)

Rated Vapor* 3/4 7/8 1 --- 1 / 8 1 --- 1 / 8

Liquid 3/8

*Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling Capacity Loss table when using other sizes and lengths of lineset.

24APA7

ELECTRICAL DATA

U n i t S i z e ---

Voltage,

Series

V/PH OPER VOLTS* COMPR FAN MCA

MIN

WIRE

SIZE{

MIN

WIRE

SIZE{

MAX

LENGTH

ft. (m)}

MAX

LENGTH

ft. (m)}

MAX

FUSE** or

CKT BRK

AMPS

MIN MAX RLA LRA FLA 60°C75°C60°C75°C

24 --- 30 208/230

187 253

10.30 52.0 0.7 13.58 14.00 14.00 60 (18.3) 57 (17.4) 20

36 --- 30 208/230 16.70 82.0 1.2 22.08 12.00 12.00 57 (17.4) 54 (16.5) 35

48 --- 31 208/230 21.20 96.0 1.3 27.80 10.00 10.00 72 (21.9) 68 (20.7) 40

60 --- 31 208/230 23.00 118.0 1.3 30.06 8.00 10.00 93 (28.3) 57 (17.4) 50

* Permissible limits of the voltage range at which the unit will operate satisfactorily

{If wire is applied at ambient greater than 30_C, consult table 310---16 of the NEC (NFPA 70). The ampacity of non ---metallic---sheathed cable (NM), trade

name ROMEX, shall be that of 60_C conditions, per the NEC (NFPA 70) Article 336 ---26. If other than uncoated (no---plated), 60 or 75_C insulation, copper

wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of the NEC (NFPA 70).

}Length shown is as measured one way along wire path between unit and service panel for voltage drop not to exceed 2%.

* * T i m e --- D e l a y f u s e .

FLA --- F u l l L o a d A m p s

LRA --- L o c k e d R o t o r A m p s

MCA --- Minimum Circuit Amps

RLA ---RatedLoadAmps

NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.

All motors/compressors contain internal overload protection.

Complies with 2007 requirements of ASHRAE Standards 90.1

A--WEIGHTED SOUND POWER (dBA)

U n i t S i z e ---

Voltage, Series

Standard Rating

(dBA)

TYPICAL OCTAVE BAND SPECTRUM (dBA, without tone adjustment)

125 250 500 1000 4000 8000

24 --- 30 7 1 --- l o w s t a g e 49.4 61.4 60.8 61.5 55.5 46.9

7 2 --- h i g h s t a g e 49.9 58.4 61.8 60.0 56.0 50.4

36 --- 30 7 2 --- l o w s t a g e 48.9 57.9 64.3 62.0 55.5 50.9

7 4 --- h i g h s t a g e 49.4 59.4 62.3 64.0 56.5 52.4

48 --- 31 7 4 --- l o w s t a g e 53.9 63.9 61.8 64.0 56.0 47.9

7 4 --- h i g h s t a g e 52.9 60.9 61.8 64.0 60.0 48.9

60 --- 31 7 3 --- l o w s t a g e 51.9 58.9 65.3 61.5 55.0 48.4

7 3 --- h i g h s t a g e 52.4 61.4 62.3 64.0 56.0 49.9

NOTE: Tested in accordance with AHRI Standard 270---08. (Not listed with AHRI).

CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)

UNIT SIZE --- VOLTAGE, SERIES REQUIRED SUBCOOLING _F(_C)

24 --- 30 10 (5.6)

36 --- 30 10 (5.6)

48 --- 31 10 (5.6)

60 --- 31 10 (5.6)

CONTROLS / THERMOSTATS

Infinity Controls DESCRIPTION

SYSTXCCUIZ01 ---B Infinity System Zone Control User Interface

SYSTXCCUID01 ---B Infinity System Non--- Zone Control User Interface

THERMOSTAT / SUBBASE

PKG. DESCRIPTION

T P --- P R H 0 1 --- A Programmable Thermidistat

T P --- N R H 0 1 --- A Non---programmable Thermidistat

T P --- P H P 0 1 * Performance Series Programmable HP Stat

T P --- N H P 0 1 * Performance Series Non --- programmable HP Stat

T C --- P H P 0 1 * Comfort Series Programmable HP Stat

T C --- N H P 0 1 * Comfort Series Non --- programmable HP Stat

*Serial numbers beginning with 2909 and thereafter.

24APA7

ACCESSORIES

ORDER NUMBER DESCRIPTION 24 --- 30 36 --- 30 48--- 31 60 --- 31

KSAHS2301AAA HARD START KIT X

KSAHS2401AAA HARD START KIT X

KSAHS2501AAA HARD START KIT X

KSAHS2601AAA HARD START KIT X

KSASF0101AAA SUPPORT FEET X X X X

KSATX0201PUR TXV PURON HSO X

KSATX0301PUR TXV PURON HSO X

KSATX0401PUR TXV PURON HSO X

KSATX0501PUR TXV PURON HSO X

x = Accessory

ACCESSORY USAGE GUIDELINE

ACCESSORY

REQUIRED FOR

L O W --- A M B I E N T C O O L I N G

APPLICATIONS

(Below 55°F/12.8_C)

REQUIRED FOR LONG LINE AP-

PLICATIONS*

(Over 80 ft/24.38 m)

REQUIRED FOR SEA COAST

APPLICATIONS (Within 2

miles/3.22 km)

Crankcase Heater Standard Standard Standard

Evaporator Freeze Protection

Standard with InfinitytControl

(Low Ambient not allowed with

non---communicating thermostat)

No No

Liquid---Line Solenoid Valve No No No

Low--- Ambient Control

Standard with Infinity Control

(Low ambient not allowed with

non---communicating thermostat)

No No

Puron Refrigerant Balance Port Hard ---

ShutOff TXV Ye s {Ye s{Ye s {

Support Feet Recommended No Recommended

Winter Start Control

Standard with Infinity Control

(Low Ambient not allowed with

non---communicating thermostat)

No No

* For tubing set lengths between 80 and 200 ft. (24.38 and 60.96 m) horizontal or 35 ft. (10.7 m) vertical differential (total equivalent length), refer to the Long

Line Guideline—Air Conditioners and Heat Pumps using Puron®Refrigerant.

{Required on all indoor units. Standard on all new Puron refrigerant fan coils and furnace coils.

Accessory Description and Usage (Listed Alphabetically)

1. Compressor Start Assist -- Capacitor and Relay

Start capacitor and relay gives a ”hard” boost to compressor

motor at each start up.

Usage Guideline:

Not required on this unit since compressor always starts

unloaded.

Available if required by local codes.

2. Crankcase Heater

An electric resistance heater which mounts to the base of the

compressor to keep the lubricant warm during off cycles.

Improves compressor lubrication on restart and minimizes the

chance of liquid slugging.

Usage Guideline:

Required in low ambient cooling applications.

Required in long line applications.

Suggested in all commercial applications.

3. Support Feet

Four stick--on plastic feet that raise the unit 4 in. (101.6 mm)

above the mounting pad. This allows sand, dirt, and other debris

to be flushed from the unit base, minimizing corrosion.

Usage Guideline:

Suggested in the following applications:

Coastal installations.

Windy areas or where debris is normally circulating.

Rooftop installations.

For improved sound ratings.

4. Thermostatic Expansion Valve (TXV)

A modulating flow--control valve which meters refrigerant liquid

flow rate into the evaporator in response to the superheat of the

refrigerant gas leaving the evaporator.

Kit includes valve, adapter tubes, and external equalizer tube.

Hard shut off types are available.

NOTE: When using a hard shut off TXV with single phase

reciprocating compressors, a Compressor Start Assist Capacitor

and Relay is required.

Usage Guideline:

Required to achieve AHRI ratings in certain equipment

combinations. Refer to combination ratings.

Hard shut off TXV or LLS required in air conditioner

long line applications.

24APA7

DIMENSIONS -- ENGLISH

5/16"

3 1/2"

1 7/8"

UNIT SERIES ELECTRICAL

CHARACTERISTICS ABCDEFGKLMNP

OPERATING

WEIGHT (lbs)

SHIPPING

WEIGHT (lbs)

SHIPPING

DIMENSIONS (L x W x H)

24APA724 0 X O O O 31 3/16" 39 1/8" 3 7/8" 3/4" 6 9/16" 24 11/16" 9 1/8" 2 15/16" 5/8" 14 1/4" 17 1/4" 19 1/4" 204 243 32 3/8" X 35 1/2" X 42 3/4"

24APA736 0 X O O O 31 3/16" 39 1/8" 3 7/8" 7/8" 6 9/16" 24 11/16" 9 1/8" 2 15/16" 5/8" 14 1/4" 17 1/4" 19 1/4" 206 243 32 3/8" X 35 1/2" X 42 3/4"

24APA748 0, 1 X O O O 35" 39 1/8" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 18" 17 1/2" 19 1/2" 306 263 36 1/8" X 39 5/16" X 42 3/4"

24APA760 0, 1 X O O O 35" 45 7/8" 3 7/8" 7/8" 6 9/16" 28 7/16" 9 1/8" 2 15/16" 5/8" 17 7/8" 18 5/8" 20 1/4" 316 373 36 1/8" X 39 5/16" X 46 3/16"

208-230-1-60

230-1-60

208/230-3-60

460-3-60

UNIT SIZE

MINIMUM

MOUNTING PAD

DIMENSIONS

24, 36 31 1/2" X 31 1/2"

48, 60 35" X 35"

AIR

DISCHARGE

AIR DISCHARGE

SQ.

AIR IN

VAPOR LINE CONN.

3/8"

LIQUID LINE CONN.

AIR IN

3/8" TIEDOWN KNOCKOUTS

(2) PLACES

FIELD CONTROL

SUPPLY CONN.

7/8" HOLE

FIELD POWER SUPPLY CONN.

7/8" HOLE WITH

1 1/8" KNOCKOUT

X = YES

O = NO

24APA7

DIMENSIONS -- SI

76.2

8.0

88.9

47.6

UNIT SERIES ELECTRICAL

CHARACTERISTICS ABCDEFGKLMNP

OPERATING

WEIGHT (Kgs)

SHIPPING

WEIGHT (Kgs)

SHIPPING

DIMENSIONS (L x W x H)

24APA724 0 X O O O 792.2 993.8 98.4 19.1 166.7 627.1 231.8 74.6 15.9 362.0 438.2 489.0 93 110 822.3 X 901.7 X 1085.9

24APA736 0 X O O O 792.2 993.8 98.4 22.2 166.7 627.1 231.8 74.6 15.9 362.0 438.2 489.0 93 110 822.3 X 901.7 X 1085.9

24APA748 0, 1 X O O O 889.0 993.8 98.4 22.2 166.7 722.3 231.8 74.6 15.9 457.2 444.5 495.3 139 119 917.6 X 998.5 X 1085.9

24APA760 0, 1 X O O O 889.0 1165.2 98.4 22.2 166.7 722.3 231.8 74.6 15.9 454.0 473.1 514.4 143 169 917.6 X 998.5 X 1173.2

208-230-1-60

230-1-60

208/230-3-60

460-3-60

UNIT SIZE

MINIMUM

MOUNTING PAD

DIMENSIONS

24,36 800.1 X 800.1

48,60 889.0 X 889.0

AIR DISCHARGE

SQ.

AIR

DISCHARGE

AIR IN

VAPOR LINE CONN.

9.53

LIQUID LINE CONN.

AIR IN

9.53 TIEDOWN KNOCKOUTS

(2) PLACES

FIELD CONTROL

SUPPLY CONN.

22.23 HOLE

FIELD POWER SUPPLY CONN.

22.23 HOLE WITH

28.58 KNOCKOUT

X = YES

O = NO

24APA7

CLEARANCES

Clearances (various examples)

Wall

24”

Service

6”

(152.4 mm)

24”

(609.6)

Service

24”

(609.6)

Service

24”

(609.6)

Service

24”

(609.6)

Service

24”

(609.6)

24”

(609.6)

24”

(609.6)

12”

(304.8)

12”

(304.8)

12”

(304.8)

12”

(304.8)

6”

(152.4)

Note: Numbers in ( ) = mm

IMPORTANT: When installing multiple units in an alcove, roof well, or partially enclosed area, ensure there is adequate ventilation to prevent re--circulation of discharge air.

A07833

24APA7

COMBINATION RATINGS

AHRI

Ref. No. Model Number Coil

Model Number

Furnace

Model Number

Cooling

Capacity EER SEER ID CFM

High Low High Low

3483687 24APA724A30 †CNPV*4217A** 58PH*045 ---08 25,200 21,000 13.2 16.0 715 585

3483688 24APA724A30 CAP**2414A**+TDR 24,200 20,000 11.8 14.0 700 560

3613515 24APA724A30 CAP**2417A** 58ME(B,C)040---12 25,200 21,200 13.3 16.5 765 655

3483781 24APA724A30 CAP**2417A** 58ME(B,C)060---12 25,200 21,000 13.3 16.5 780 625

3483780 24APA724A30 CAP**2417A** 58MEB040---12 25,200 21,200 13.3 16.5 765 655

3877989 24APA724A30 CAP**2417A** 58UVB060---14 24,800 20,600 13.2 16.0 725 580

3563730 24APA724A30 CAP**2417A** 58VLR105---12 24,800 20,600 13.2 16.5 715 585

3563729 24APA724A30 CAP**2417A** 58VMR105 ---12 24,600 20,200 13.0 16.0 660 520

4213144 24APA724A30 CAP**2417A** OVLAAB036098 24,800 19,800 12.5 16.0 865 530

4213143 24APA724A30 CAP**2417A** OVMAAB036098 24,400 20,000 12.7 16.2 725 550

4213145 24APA724A30 CAP**2417A** OVMAAB042112 24,400 20,200 13.0 16.2 690 580

3483689 24APA724A30 CAP**2417A**+TDR 24,200 20,000 11.8 14.0 700 560

3483691 24APA724A30 CAP**2417A**+UI 58CV(A,X)090---16 24,600 20,400 13.2 16.0 670 535

3483690 24APA724A30 CAP**2417A**+UI 58MV(B,C)060---14 24,800 20,600 13.2 16.0 725 580

3483694 24APA724A30 CAP**3014A** 58PH*045---08 25,000 20,600 13.0 16.0 720 585

3483692 24APA724A30 CAP**3014A**+TDR 24,400 20,000 11.9 14.0 700 560

3483693 24APA724A30 CAP**3014A**+UI 58CV(A,X)070---12 24,600 20,200 13.1 16.0 660 530

3613512 24APA724A30 CAP**3017A** 58ME(B,C)040---12 25,400 21,200 13.5 16.5 785 680

3483785 24APA724A30 CAP**3017A** 58ME(B,C)060---12 25,400 21,200 13.4 16.5 795 650

3483784 24APA724A30 CAP**3017A** 58MEB040---12 25,400 21,200 13.5 16.5 785 680

3877990 24APA724A30 CAP**3017A** 58UVB060---14 25,000 20,600 13.3 16.5 725 580

3563732 24APA724A30 CAP**3017A** 58VLR105---12 25,000 20,600 13.0 16.5 715 585

3563731 24APA724A30 CAP**3017A** 58VMR105 ---12 24,600 20,200 13.0 16.0 660 520

4213147 24APA724A30 CAP**3017A** OVLAAB036098 25,000 19,800 12.7 16.2 865 530

4213146 24APA724A30 CAP**3017A** OVMAAB036098 24,600 20,000 12.7 16.2 725 550

4213148 24APA724A30 CAP**3017A** OVMAAB042112 24,400 20,200 13.0 16.5 690 580

3483695 24APA724A30 CAP**3017A**+TDR 24,400 20,000 11.9 14.0 700 560

3483697 24APA724A30 CAP**3017A**+UI 58CV(A,X)090---16 24,800 20,400 13.3 16.0 670 535

3483696 24APA724A30 CAP**3017A**+UI 58MV(B,C)060---14 25,000 20,600 13.3 16.5 725 580

3483700 24APA724A30 CAP**3614A** 58PH*045---08 25,000 20,800 13.1 16.0 725 590

3483698 24APA724A30 CAP**3614A**+TDR 24,400 20,200 11.9 14.0 700 560

3483699 24APA724A30 CAP**3614A**+UI 58CV(A,X)070---12 24,800 20,400 13.1 16.0 660 530

3613513 24APA724A30 CAP**3617A** 58ME(B,C)040---12 25,400 21,400 13.5 17.0 790 695

3483789 24APA724A30 CAP**3617A** 58ME(B,C)060---12 25,600 21,200 13.5 16.5 805 660

3483788 24APA724A30 CAP**3617A** 58MEB040---12 25,400 21,400 13.5 17.0 790 695

3877991 24APA724A30 CAP**3617A** 58UVB060---14 25,200 20,800 13.4 16.5 725 580

4213150 24APA724A30 CAP**3617A** OVLAAB036098 25,200 20,000 12.7 16.2 865 530

4213149 24APA724A30 CAP**3617A** OVMAAB036098 24,600 20,200 12.7 16.2 725 550

4213151 24APA724A30 CAP**3617A** OVMAAB042112 24,600 20,400 13.2 16.5 690 580

3483701 24APA724A30 CAP**3617A**+TDR 24,400 20,200 11.9 14.0 700 560

3483703 24APA724A30 CAP**3617A**+UI 58CV(A,X)090---16 24,800 20,400 13.3 16.5 670 535

3483702 24APA724A30 CAP**3617A**+UI 58MV(B,C)060---14 25,200 20,800 13.4 16.5 725 580

3563746 24APA724A30 CAP**3619A** 58HDV040 --- ---12 25,000 20,600 13.0 16.0 765 595

3563747 24APA724A30 CAP**3619A** 58HDV060 --- ---12 25,000 21,000 13.0 16.0 820 640

4213156 24APA724A30 CAP**3619A** OVLAAB036098 25,200 20,000 12.7 16.2 865 530

4213155 24APA724A30 CAP**3619A** OVMAAB036098 24,600 20,200 12.7 16.2 725 550

4213157 24APA724A30 CAP**3619A** OVMAAB042112 24,600 20,400 13.2 16.5 690 580

3594971 24APA724A30 CAP**3619A**+TDR 24,000 20,000 11.8 14.0 700 560

3483790 24APA724A30 CAP**3621A** 58ME(B,C)060---12 25,600 21,400 13.6 17.0 820 695

3877992 24APA724A30 CAP**3621A** 58UVB080---14 24,800 20,400 13.3 16.5 660 530

3877993 24APA724A30 CAP**3621A** 58UVB080---20 24,600 20,200 13.2 16.0 630 505

3877994 24APA724A30 CAP**3621A** 58UVB100---20 24,800 20,400 13.3 16.5 665 530

4213153 24APA724A30 CAP**3621A** OVLAAB036098 25,200 20,000 12.7 16.2 865 530

4213152 24APA724A30 CAP**3621A** OVMAAB036098 24,600 20,200 13.0 16.2 725 550

4213154 24APA724A30 CAP**3621A** OVMAAB042112 24,600 20,400 13.2 16.5 690 580

3483704 24APA724A30 CAP**3621A**+TDR 24,400 20,200 11.9 14.0 700 560

3483708 24APA724A30 CAP**3621A**+UI 58CV(A,X)110---20 24,800 20,400 13.3 16.5 675 540

3483705 24APA724A30 CAP**3621A**+UI 58MV(B,C)080---14 24,800 20,400 13.3 16.5 660 530

3483706 24APA724A30 CAP**3621A**+UI 58MV(B,C)080---20 24,600 20,200 13.2 16.0 630 505

3483707 24APA724A30 CAP**3621A**+UI 58MV(B,C)100---20 24,800 20,400 13.3 16.5 665 530

3613517 24APA724A30 CNPH*2417A** 58ME(B,C)040---12 25,000 21,000 13.2 16.5 725 610

3483803 24APA724A30 CNPH*2417A** 58ME(B,C)060---12 25,000 20,800 13.2 16.5 735 575

3483802 24APA724A30 CNPH*2417A** 58MEB040---12 25,000 21,000 13.2 16.5 725 610

3483732 24APA724A30 CNPH*2417A** 58PH*045---08 24,600 20,600 12.9 16.0 695 565

4213178 24APA724A30 CNPH*2417A** OVLAAB036098 24,800 20,000 12.2 16.0 865 530

4213177 24APA724A30 CNPH*2417A** OVMAAB036098 24,400 20,000 12.5 16.0 725 550

4213179 24APA724A30 CNPH*2417A** OVMAAB042112 24,200 20,400 12.7 16.2 690 580

3483726 24APA724A30 CNPH*2417A**+TDR 24,200 20,200 11.8 14.0 700 560

3483730 24APA724A30 CNPH*2417A**+UI 58CV(A,X)070 ---12 24,400 20,200 13.0 16.0 660 530

3483731 24APA724A30 CNPH*2417A**+UI 58CV(A,X)090 ---16 24,600 20,400 13.1 16.0 670 535

3483728 24APA724A30 CNPH*2417A**+UI 58MV(B,C)060---14 24,800 20,600 13.1 16.0 725 580

See notes on page 21

24APA7

COMBINATION RATINGS CONTINUED

AHRI

Ref. No. Model Number Coil

Model Number

Furnace

Model Number

Cooling

Capacity EER SEER ID CFM

High Low High Low

3483729 24APA724A30 CNPH*2417A**+UI 58MV(B,C)080---14 24,600 20,400 13.0 16.0 660 530

3483727 24APA724A30 CNPH*2417A**+UI 58MVB040---14 24,600 20,400 12.9 16.0 675 540

3613518 24APA724A30 CNPH*3017A** 58ME(B,C)040---12 25,400 21,200 13.4 16.5 775 675

3483805 24APA724A30 CNPH*3017A** 58ME(B,C)060---12 25,400 21,200 13.4 16.5 790 645

3483804 24APA724A30 CNPH*3017A** 58MEB040---12 25,400 21,200 13.4 16.5 775 675

3483739 24APA724A30 CNPH*3017A** 58PH*045---08 25,000 20,800 13.1 16.0 730 595

4213181 24APA724A30 CNPH*3017A** OVLAAB036098 25,200 20,000 12.7 16.2 865 530

4213180 24APA724A30 CNPH*3017A** OVMAAB036098 24,600 20,000 12.7 16.2 725 550

4213182 24APA724A30 CNPH*3017A** OVMAAB042112 24,400 20,400 13.0 16.5 690 580

3483733 24APA724A30 CNPH*3017A**+TDR 24,400 20,000 11.9 14.0 700 560

3483737 24APA724A30 CNPH*3017A**+UI 58CV(A,X)070 ---12 24,600 20,200 13.1 16.0 660 530

3483738 24APA724A30 CNPH*3017A**+UI 58CV(A,X)090 ---16 24,800 20,400 13.3 16.5 670 535

3483735 24APA724A30 CNPH*3017A**+UI 58MV(B,C)060---14 25,000 20,600 13.3 16.5 725 580

3483736 24APA724A30 CNPH*3017A**+UI 58MV(B,C)080---14 24,600 20,200 13.2 16.0 660 530

3483734 24APA724A30 CNPH*3017A**+UI 58MVB040---14 24,800 20,400 13.1 16.0 675 540

4213184 24APA724A30 CNPH*3117A** OVLAAB036098 25,600 20,400 13.0 16.5 865 530

4213183 24APA724A30 CNPH*3117A** OVMAAB036098 25,000 20,400 13.0 16.5 725 550

4213185 24APA724A30 CNPH*3117A** OVMAAB042112 25,000 20,800 13.2 16.7 690 580

3483806 24APA724A30 CNPH*3617A** 58ME(B,C)060---12 25,200 21,200 13.4 16.5 790 645

3483748 24APA724A30 CNPH*3617A** 58PH*045---08 25,000 20,800 13.1 16.0 730 595

4213187 24APA724A30 CNPH*3617A** OVLAAB036098 25,200 20,000 12.7 16.2 865 530

4213186 24APA724A30 CNPH*3617A** OVMAAB036098 24,600 20,000 12.7 16.2 725 550

4213188 24APA724A30 CNPH*3617A** OVMAAB042112 24,400 20,400 13.0 16.5 690 580

3483742 24APA724A30 CNPH*3617A**+TDR 24,400 20,000 11.9 14.0 700 560

3483746 24APA724A30 CNPH*3617A**+UI 58CV(A,X)070 ---12 24,600 20,200 13.1 16.0 660 530

3483747 24APA724A30 CNPH*3617A**+UI 58CV(A,X)090 ---16 24,800 20,400 13.3 16.5 670 535

3483744 24APA724A30 CNPH*3617A**+UI 58MV(B,C)060---14 25,000 20,600 13.3 16.5 725 580

3483745 24APA724A30 CNPH*3617A**+UI 58MV(B,C)080---14 24,600 20,200 13.2 16.0 660 530

3483743 24APA724A30 CNPH*3617A**+UI 58MVB040---14 24,800 20,400 13.1 16.0 675 540

3483711 24APA724A30 CNPV*2414A** 58PH*045---08 24,600 20,600 12.9 16.0 695 565

3483709 24APA724A30 CNPV*2414A**+TDR 24,200 20,200 11.8 14.0 700 560

3483710 24APA724A30 CNPV*2414A**+UI 58CV(A,X)070---12 24,400 20,200 13.0 16.0 660 530

3613514 24APA724A30 CNPV*2417A** 58ME(B,C)040---12 25,000 21,000 13.2 16.5 725 610

3483794 24APA724A30 CNPV*2417A** 58ME(B,C)060---12 25,000 20,800 13.1 16.5 735 575

3483793 24APA724A30 CNPV*2417A** 58MEB040---12 25,000 21,000 13.2 16.5 725 610

3877995 24APA724A30 CNPV*2417A** 58UVB060---14 24,800 20,600 13.0 16.0 725 580

3563734 24APA724A30 CNPV*2417A** 58VLR105---12 24,800 20,800 13.0 16.5 715 585

3563733 24APA724A30 CNPV*2417A** 58VMR105---12 24,400 20,200 12.8 16.0 660 520

4213160 24APA724A30 CNPV*2417A** OVLAAB036098 24,800 20,000 12.2 16.0 865 530

4213158 24APA724A30 CNPV*2417A** OVMAAB036098 24,400 20,000 12.5 16.0 725 550

4213161 24APA724A30 CNPV*2417A** OVMAAB042112 24,200 20,400 12.7 16.2 690 580

3483712 24APA724A30 CNPV*2417A**+TDR 24,200 20,200 11.8 14.0 700 560

3483714 24APA724A30 CNPV*2417A**+UI 58CV(A,X)090---16 24,600 20,400 13.1 16.0 670 535

3483713 24APA724A30 CNPV*2417A**+UI 58MV(B,C)060---14 24,800 20,600 13.0 16.0 725 580

3483717 24APA724A30 CNPV*3014A** 58PH*045---08 24,800 20,600 13.0 16.0 705 580

3483715 24APA724A30 CNPV*3014A**+TDR 24,400 20,000 11.9 14.0 700 560

3483716 24APA724A30 CNPV*3014A**+UI 58CV(A,X)070---12 24,600 20,200 13.1 16.0 660 530

3483797 24APA724A30 CNPV*3017A** 58ME(B,C)060---12 25,400 21,200 13.4 16.5 790 645

3877987 24APA724A30 CNPV*3017A** 58UVB060---14 25,000 20,600 13.3 16.5 725 580

3563736 24APA724A30 CNPV*3017A** 58VLR105---12 25,000 20,800 13.0 16.5 715 585

3563735 24APA724A30 CNPV*3017A** 58VMR105---12 24,600 20,200 13.0 16.0 660 520

4213163 24APA724A30 CNPV*3017A** OVLAAB036098 25,200 20,000 12.7 16.2 865 530

4213162 24APA724A30 CNPV*3017A** OVMAAB036098 24,600 20,000 12.7 16.2 725 550

4213164 24APA724A30 CNPV*3017A** OVMAAB042112 24,400 20,400 13.0 16.5 690 580

3483718 24APA724A30 CNPV*3017A**+TDR 24,400 20,000 11.9 14.0 700 560

3483720 24APA724A30 CNPV*3017A**+UI 58CV(A,X)090---16 24,800 20,400 13.3 16.5 670 535

3483719 24APA724A30 CNPV*3017A**+UI 58MV(B,C)060---14 25,000 20,600 13.3 16.5 725 580

3483798 24APA724A30 CNPV*3117A** 58ME(B,C)060---12 25,600 21,600 13.7 17.0 800 655

3878044 24APA724A30 CNPV*3117A** 58UVB060---14 25,600 21,200 13.6 16.5 725 580

3563738 24APA724A30 CNPV*3117A** 58VLR105---12 25,600 21,200 13.5 16.5 715 585

3563737 24APA724A30 CNPV*3117A** 58VMR105---12 25,200 20,600 13.0 16.5 660 520

4213166 24APA724A30 CNPV*3117A** OVLAAB036098 25,600 20,400 13.0 16.5 865 530

4213165 24APA724A30 CNPV*3117A** OVMAAB036098 25,000 20,400 13.0 16.5 725 550

4213167 24APA724A30 CNPV*3117A** OVMAAB042112 25,000 20,800 13.2 16.7 690 580

3747702 24APA724A30 CNPV*3117A** 24,800 20,600 12.1 14.5 700 560

3483721 24APA724A30 CNPV*3117A**+TDR 24,800 20,600 12.1 14.5 700 560

3484271 24APA724A30 CNPV*3117A**+UI 58CV(A,X)090---16 25,200 20,800 13.5 16.5 670 535

3484270 24APA724A30 CNPV*3117A**+UI 58MV(B,C)060---14 25,600 21,200 13.6 16.5 725 580

3877988 24APA724A30 CNPV*3617A** 58UVB060---14 25,000 20,600 13.3 16.5 725 580

3563740 24APA724A30 CNPV*3617A** 58VLR105---12 25,000 20,800 13.0 16.5 715 585

3563739 24APA724A30 CNPV*3617A** 58VMR105---12 24,600 20,200 13.0 16.0 660 520

See notes on page 21

24APA7

COMBINATION RATINGS CONTINUED

AHRI

Ref. No. Model Number Coil

Model Number

Furnace

Model Number

Cooling

Capacity EER SEER ID CFM

High Low High Low

4213169 24APA724A30 CNPV*3617A** OVLAAB036098 25,200 20,000 12.7 16.2 865 530

4213168 24APA724A30 CNPV*3617A** OVMAAB036098 24,600 20,000 12.7 16.2 725 550

4213170 24APA724A30 CNPV*3617A** OVMAAB042112 24,400 20,400 13.0 16.5 690 580

3483722 24APA724A30 CNPV*3617A**+TDR 24,400 20,000 11.9 14.0 700 560

3483724 24APA724A30 CNPV*3617A**+UI 58CV(A,X)090---16 24,800 20,400 13.3 16.5 670 535

3483723 24APA724A30 CNPV*3617A**+UI 58MV(B,C)060---14 25,000 20,600 13.3 16.5 725 580

3613516 24APA724A30 CNPV*3621A** 58ME(B,C)040---12 25,400 21,400 13.5 16.5 780 680

3483800 24APA724A30 CNPV*3621A** 58ME(B,C)060---12 25,400 21,200 13.4 16.5 790 650

3483799 24APA724A30 CNPV*3621A** 58MEB040---12 25,400 21,400 13.5 16.5 780 680

3895971 24APA724A30 CNPV*3621A** 58MV(B,C)080---14 24,000 19,200 13.0 16.0 660 490

3895970 24APA724A30 CNPV*3621A** 58UVB080---14 24,000 19,200 13.0 16.0 660 490

4213172 24APA724A30 CNPV*3621A** OVLAAB036098 25,200 20,000 12.7 16.2 865 530

4213171 24APA724A30 CNPV*3621A** OVMAAB036098 24,600 20,000 12.7 16.2 725 550

4213173 24APA724A30 CNPV*3621A** OVMAAB042112 24,400 20,400 13.0 16.5 690 580

4213198 24APA724A30 CNPV*3621A**+UI 58MV(B,C)100---20 24,600 20,800 13.0 16.5 700 680

3483801 24APA724A30 CNPV*3717A** 58ME(B,C)060---12 26,200 22,000 13.9 17.0 810 680

3878038 24APA724A30 CNPV*3717A** 58UVB060---14 25,800 21,400 13.7 17.0 725 580

3563742 24APA724A30 CNPV*3717A** 58VLR105---12 25,800 21,400 13.5 16.5 715 585

3563741 24APA724A30 CNPV*3717A** 58VMR105---12 25,400 20,800 13.5 16.5 660 520

4213175 24APA724A30 CNPV*3717A** OVLAAB036098 26,000 20,600 13.2 16.7 865 530

4213174 24APA724A30 CNPV*3717A** OVMAAB036098 25,400 20,600 13.2 16.7 725 550

4213176 24APA724A30 CNPV*3717A** OVMAAB042112 25,200 21,000 13.5 17.0 690 580

3483725 24APA724A30 CNPV*3717A**+TDR 25,200 20,800 12.2 14.5 700 560

3484273 24APA724A30 CNPV*3717A**+UI 58CV(A,X)090---16 25,400 21,000 13.6 16.5 670 535

3484272 24APA724A30 CNPV*3717A**+UI 58MV(B,C)060---14 25,800 21,400 13.7 17.0 725 580

3483757 24APA724A30 CSPH*2412A** 58HDV040--- ---12 24,800 20,600 12.7 16.0 705 540

3483758 24APA724A30 CSPH*2412A** 58HDV060--- ---12 25,000 20,800 12.8 16.0 735 565

3613519 24APA724A30 CSPH*2412A** 58ME(B,C)040 ---12 25,200 21,000 13.3 16.5 710 585

3483808 24APA724A30 CSPH*2412A** 58ME(B,C)060 ---12 25,200 20,600 13.2 16.5 725 545

3483807 24APA724A30 CSPH*2412A** 58MEB040 ---12 25,200 21,000 13.3 16.5 710 585

3483756 24APA724A30 CSPH*2412A** 58PH*045---08 24,800 20,600 13.0 16.0 685 555

3563743 24APA724A30 CSPH*2412A** 58VMR105 ---12 24,800 20,400 13.0 16.0 660 520

4213190 24APA724A30 CSPH*2412A** OVLAAB036098 25,000 20,200 12.2 16.0 865 530

4213189 24APA724A30 CSPH*2412A** OVMAAB036098 24,600 20,200 12.7 16.2 725 550

4213191 24APA724A30 CSPH*2412A** OVMAAB042112 24,600 20,600 12.7 16.2 690 580

3483751 24APA724A30 CSPH*2412A**+TDR 24,600 20,400 12.0 14.5 700 560

3483754 24APA724A30 CSPH*2412A**+UI 58CV(A,X)070---12 24,800 20,400 13.0 16.0 660 530

3483755 24APA724A30 CSPH*2412A**+UI 58CV(A,X)090---16 24,800 20,600 13.2 16.0 670 535

3483753 24APA724A30 CSPH*2412A**+UI 58MV(B,C)060---14 25,200 20,800 13.1 16.0 725 580

3483752 24APA724A30 CSPH*2412A**+UI 58MVB040---14 24,800 20,600 13.0 16.0 675 540

3483765 24APA724A30 CSPH*3012A** 58HDV040--- ---12 25,000 20,600 12.8 16.0 735 570

3483766 24APA724A30 CSPH*3012A** 58HDV060--- ---12 25,200 20,800 12.9 16.0 780 605

3613520 24APA724A30 CSPH*3012A** 58ME(B,C)040 ---12 25,400 21,200 13.4 16.5 750 640

3483810 24APA724A30 CSPH*3012A** 58ME(B,C)060 ---12 25,400 21,000 13.4 16.5 765 605

3483809 24APA724A30 CSPH*3012A** 58MEB040 ---12 25,400 21,200 13.4 16.5 750 640

3483764 24APA724A30 CSPH*3012A** 58PH*045---08 25,000 20,800 13.1 16.0 715 580

3563744 24APA724A30 CSPH*3012A** 58VMR105 ---12 24,800 20,200 13.0 16.0 660 520

4213193 24APA724A30 CSPH*3012A** OVLAAB036098 25,200 20,200 12.7 16.2 865 530

4213192 24APA724A30 CSPH*3012A** OVMAAB036098 24,800 20,400 12.7 16.5 725 550

4213194 24APA724A30 CSPH*3012A** OVMAAB042112 24,600 20,600 13.0 16.5 690 580

3483759 24APA724A30 CSPH*3012A**+TDR 24,600 20,200 11.9 14.0 700 560

3483762 24APA724A30 CSPH*3012A**+UI 58CV(A,X)070---12 24,800 20,400 13.1 16.0 660 530

3483763 24APA724A30 CSPH*3012A**+UI 58CV(A,X)090---16 24,800 20,400 13.3 16.0 670 535

3483761 24APA724A30 CSPH*3012A**+UI 58MV(B,C)060---14 25,200 20,800 13.3 16.5 725 580

3483760 24APA724A30 CSPH*3012A**+UI 58MVB040---14 24,800 20,400 13.1 16.0 675 540

3483774 24APA724A30 CSPH*3612A** 58HDV040--- ---12 25,600 21,000 13.1 16.5 755 585

3483775 24APA724A30 CSPH*3612A** 58HDV060--- ---12 25,800 21,400 13.2 16.5 815 630

3613521 24APA724A30 CSPH*3612A** 58ME(B,C)040 ---12 25,800 21,800 13.7 17.0 780 675

3483812 24APA724A30 CSPH*3612A** 58ME(B,C)060 ---12 26,000 21,600 13.7 17.0 795 640

3483811 24APA724A30 CSPH*3612A** 58MEB040 ---12 25,800 21,800 13.7 17.0 780 675

3483773 24APA724A30 CSPH*3612A** 58PH*045---08 25,400 21,200 13.3 16.5 735 590

3563745 24APA724A30 CSPH*3612A** 58VMR105 ---12 25,200 20,600 13.0 16.5 660 520

4213196 24APA724A30 CSPH*3612A** OVLAAB036098 25,600 20,200 13.0 16.2 865 530

4213195 24APA724A30 CSPH*3612A** OVMAAB036098 25,000 20,400 13.0 16.5 725 550

4213197 24APA724A30 CSPH*3612A** OVMAAB042112 25,000 20,600 13.2 16.7 690 580

3483767 24APA724A30 CSPH*3612A**+TDR 24,800 20,400 12.1 14.5 700 560

3483771 24APA724A30 CSPH*3612A**+UI 58CV(A,X)070---12 25,000 20,600 13.3 16.5 660 530

3483772 24APA724A30 CSPH*3612A**+UI 58CV(A,X)090---16 25,200 20,800 13.5 16.5 670 535

3483769 24APA724A30 CSPH*3612A**+UI 58MV(B,C)060---14 25,600 21,000 13.5 16.5 725 580

3483770 24APA724A30 CSPH*3612A**+UI 58MV(B,C)080---14 25,200 20,600 13.4 16.5 660 530

3483768 24APA724A30 CSPH*3612A**+UI 58MVB040---14 25,200 20,800 13.3 16.5 675 540

See notes on page 21

24APA7

COMBINATION RATINGS CONTINUED

AHRI

Ref. No. Model Number Coil

Model Number

Furnace

Model Number

Cooling

Capacity EER SEER ID CFM

High Low High Low

3483777 24APA724A30 FE4AN(B,F)003+UI 25,000 20,800 13.5 17.0 700 560

3483776 24APA724A30 FE4ANF002+UI 25,000 20,800 13.3 16.5 700 560

3483779 24APA724A30 FV4CN(B,F)003 25,000 20,800 13.5 16.5 700 560

3483778 24APA724A30 FV4CNF002 25,000 20,800 13.3 16.5 700 560

3483813 24APA736A30 †CNPV*4821A** 58PH*090 ---16 36,600 30,400 13.2 16.5 1,090 960

3483814 24APA736A30 CAP**3614A**+TDR 34,800 28,600 11.8 14.5 1,050 840

3483815 24APA736A30 CAP**3614A**+UI 58CV(A,X)070---12 35,600 28,800 12.4 16.0 1,005 805

3483951 24APA736A30 CAP**3617A** 58ME(B,C)060---12 36,000 29,600 12.7 16.5 1,080 955

3483952 24APA736A30 CAP**3617A** 58ME(B,C)080---12 36,000 29,600 12.7 16.5 1,055 925

3483953 24APA736A30 CAP**3617A** 58ME(B,C)080---16 36,000 29,800 12.7 16.0 1,080 985

3877996 24APA736A30 CAP**3617A** 58UVB060---14 36,000 29,200 12.7 16.5 1,055 845

3563751 24APA736A30 CAP**3617A** 58VLR105---12 36,000 29,400 12.5 16.0 1,065 880

3563750 24APA736A30 CAP**3617A** 58VMR105 ---12 35,600 28,800 12.6 16.0 975 800

4213199 24APA736A30 CAP**3617A** OVMAAB042112 35,400 28,600 12.2 16.2 1,035 825

3483816 24APA736A30 CAP**3617A**+TDR 35,400 28,600 11.8 14.5 1,050 840

4230276 24APA736A30 CAP**3617A**+UI 58CV(A,X)070---12 35,400 28,800 12.2 16.2 1,050 840

3483818 24APA736A30 CAP**3617A**+UI 58CV(A,X)090---16 35,800 29,000 12.8 16.5 1,005 805

3483817 24APA736A30 CAP**3617A**+UI 58MV(B,C)060---14 36,000 29,200 12.7 16.5 1,055 845

3563786 24APA736A30 CAP**3619A** 58HDV040 --- ---12 35,000 28,000 12.0 16.0 1,055 815

3563787 24APA736A30 CAP**3619A** 58HDV060 --- ---12 35,000 28,000 12.5 16.5 1,100 780

4213212 24APA736A30 CAP**3619A** OVLAAB048112 35,600 29,000 12.2 16.0 1,085 880

4213211 24APA736A30 CAP**3619A** OVMAAB042112 35,400 28,600 12.2 16.2 1,035 825

3594966 24APA736A30 CAP**3619A**+TDR 35,400 28,600 11.8 14.0 1,050 840

3483823 24APA736A30 CAP**3621A** 58PH*090---16 36,200 29,600 12.9 16.5 1,085 955

3877997 24APA736A30 CAP**3621A** 58UVB080---20 35,800 29,000 12.5 16.5 1,010 810

3877998 24APA736A30 CAP**3621A** 58UVB100---20 36,000 29,000 12.8 16.5 1,040 830

3563753 24APA736A30 CAP**3621A** 58VLR105---12 36,000 29,400 12.5 16.0 1,065 880

3563755 24APA736A30 CAP**3621A** 58VLR120---20 36,400 30,000 12.5 16.5 1,170 1,005

3563752 24APA736A30 CAP**3621A** 58VMR105 ---12 35,600 29,000 12.5 16.5 975 800

3563754 24APA736A30 CAP**3621A** 58VMR120 ---20 36,400 29,800 12.5 16.0 1,155 1,000

4213201 24APA736A30 CAP**3621A** OVLAAB048112 35,600 29,000 12.2 16.2 1,085 880

4213200 24APA736A30 CAP**3621A** OVMAAB042112 35,400 28,600 12.2 16.2 1,035 825

3483819 24APA736A30 CAP**3621A**+TDR 35,400 28,600 11.8 14.5 1,050 840

3483822 24APA736A30 CAP**3621A**+UI 58CV(A,X)110---20 35,800 29,000 12.8 16.5 1,020 815

3483820 24APA736A30 CAP**3621A**+UI 58MV(B,C)080---20 35,800 29,000 12.5 16.5 1,010 810

3483821 24APA736A30 CAP**3621A**+UI 58MV(B,C)100---20 36,000 29,000 12.8 16.5 1,040 830

3483828 24APA736A30 CAP**4221A** 58PH*090---16 36,400 29,800 13.0 16.5 1,085 950

3877999 24APA736A30 CAP**4221A** 58UVB080---20 36,000 29,200 12.8 16.5 1,010 810

3878000 24APA736A30 CAP**4221A** 58UVB100---20 36,200 29,200 12.8 16.5 1,040 830

3563757 24APA736A30 CAP**4221A** 58VLR105---12 36,200 29,600 12.5 16.5 1,065 880

3563759 24APA736A30 CAP**4221A** 58VLR120---20 36,800 30,200 12.8 16.5 1,170 1,005

3563756 24APA736A30 CAP**4221A** 58VMR105 ---12 35,800 29,200 12.6 16.5 975 800

3563758 24APA736A30 CAP**4221A** 58VMR120 ---20 36,600 30,000 12.7 16.5 1,155 1,000

4213203 24APA736A30 CAP**4221A** OVLAAB048112 35,800 29,200 12.2 16.2 1,085 880

4213202 24APA736A30 CAP**4221A** OVMAAB042112 35,800 28,800 12.5 16.5 1,035 825

3483824 24APA736A30 CAP**4221A**+TDR 35,600 28,800 11.9 14.5 1,050 840

3483827 24APA736A30 CAP**4221A**+UI 58CV(A,X)110---20 36,200 29,200 12.9 16.5 1,020 815

3483825 24APA736A30 CAP**4221A**+UI 58MV(B,C)080---20 36,000 29,200 12.8 16.5 1,010 810

3483826 24APA736A30 CAP**4221A**+UI 58MV(B,C)100---20 36,200 29,200 12.8 16.5 1,040 830

3483833 24APA736A30 CAP**4224A** 58HDV100 --- ---20 36,600 29,800 12.8 16.5 1,140 900

3878001 24APA736A30 CAP**4224A** 58UVB120---20 36,200 29,200 13.0 16.5 1,010 810

4213204 24APA736A30 CAP**4224A** OVLAAB048112 36,000 29,200 12.5 16.2 1,085 880

4213205 24APA736A30 CAP**4224A** OVLAAB060154 36,600 29,800 12.7 16.7 1,250 1,020

3483829 24APA736A30 CAP**4224A**+TDR 35,600 28,800 11.9 14.5 1,050 840

3483831 24APA736A30 CAP**4224A**+UI 58CV(A,X)135---22 36,200 29,200 13.0 16.5 1,010 810

3483832 24APA736A30 CAP**4224A**+UI 58CV(A,X)155---22 36,200 29,200 13.2 17.0 1,015 810

3483830 24APA736A30 CAP**4224A**+UI 58MV(B,C)120---20 36,200 29,200 13.0 16.5 1,010 810

3483954 24APA736A30 CAP**4817A** 58ME(B,C)060---12 37,400 30,600 13.0 17.0 1,085 960

3483955 24APA736A30 CAP**4817A** 58ME(B,C)080---12 37,200 30,400 13.1 17.0 1,060 925

3483956 24APA736A30 CAP**4817A** 58ME(B,C)080---16 37,400 30,600 13.0 16.5 1,085 990

3878002 24APA736A30 CAP**4817A** 58UVB060---14 37,200 30,000 13.0 17.0 1,055 845

3563761 24APA736A30 CAP**4817A** 58VLR105---12 37,200 30,000 12.9 16.5 1,065 880

3563760 24APA736A30 CAP**4817A** 58VMR105 ---12 36,600 29,600 12.9 16.5 975 800

4213206 24APA736A30 CAP**4817A** OVMAAB042112 36,600 29,400 12.7 16.7 1,035 825

3483834 24APA736A30 CAP**4817A**+TDR 36,600 29,400 12.1 15.0 1,050 840

4230277 24APA736A30 CAP**4817A**+UI 58CV(A,X)070---12 36,600 29,600 12.7 16.7 1,050 840

3483836 24APA736A30 CAP**4817A**+UI 58CV(A,X)090---16 37,000 29,800 13.1 17.0 1,005 805

3483835 24APA736A30 CAP**4817A**+UI 58MV(B,C)060---14 37,200 30,000 13.0 17.0 1,055 845

3878003 24APA736A30 CAP**4821A** 58UVB080---14 36,600 29,600 12.8 16.5 1,030 825

3878004 24APA736A30 CAP**4821A** 58UVB080---20 36,600 29,400 12.9 16.5 1,010 810

See notes on page 21

24APA7

COMBINATION RATINGS CONTINUED

AHRI

Ref. No. Model Number Coil

Model Number

Furnace

Model Number

Cooling

Capacity EER SEER ID CFM

High Low High Low

3878005 24APA736A30 CAP**4821A** 58UVB100---20 36,800 29,600 13.0 16.5 1,040 830

3563763 24APA736A30 CAP**4821A** 58VLR105---12 36,800 29,800 12.8 16.5 1,065 880

3563762 24APA736A30 CAP**4821A** 58VMR105 ---12 36,400 29,400 12.8 16.5 975 800

4213208 24APA736A30 CAP**4821A** OVLAAB048112 36,400 29,600 12.5 16.5 1,085 880

4213207 24APA736A30 CAP**4821A** OVMAAB042112 36,200 29,200 12.5 16.7 1,035 825

3483837 24APA736A30 CAP**4821A**+TDR 36,200 29,200 12.0 14.5 1,050 840

3483841 24APA736A30 CAP**4821A**+UI 58CV(A,X)110---20 36,800 29,600 13.0 16.5 1,020 815

3483838 24APA736A30 CAP**4821A**+UI 58MV(B,C)080---14 36,600 29,600 12.8 16.5 1,030 825

3483839 24APA736A30 CAP**4821A**+UI 58MV(B,C)080---20 36,600 29,400 12.9 16.5 1,010 810

3483840 24APA736A30 CAP**4821A**+UI 58MV(B,C)100---20 36,800 29,600 13.0 16.5 1,040 830

3563789 24APA736A30 CAP**4823A** 58HDV040 --- ---12 36,000 29,000 12.5 16.5 1,070 825

3563790 24APA736A30 CAP**4823A** 58HDV060 --- ---12 36,000 29,000 12.8 16.5 1,115 795

3563791 24APA736A30 CAP**4823A** 58HDV080 --- ---20 37,000 30,000 13.0 16.5 1,200 935

4213213 24APA736A30 CAP**4823A** OVLAAB048112 36,400 29,600 12.5 16.5 1,085 880

3594967 24APA736A30 CAP**4823A**+TDR 36,200 29,200 12.0 14.5 1,050 840

3878006 24APA736A30 CAP**4824A** 58UVB120---20 36,800 29,600 13.1 17.0 1,010 810

4213209 24APA736A30 CAP**4824A** OVLAAB048112 36,600 29,600 12.5 16.5 1,085 880

4213210 24APA736A30 CAP**4824A** OVLAAB060154 37,400 30,200 12.7 17.0 1,250 1,020

3483842 24APA736A30 CAP**4824A**+TDR 36,200 29,200 12.0 14.5 1,050 840

3483844 24APA736A30 CAP**4824A**+UI 58CV(A,X)135---22 36,800 29,600 13.2 17.0 1,010 810

3483845 24APA736A30 CAP**4824A**+UI 58CV(A,X)155---22 36,800 29,600 13.3 17.0 1,015 810

3483843 24APA736A30 CAP**4824A**+UI 58MV(B,C)120---20 36,800 29,600 13.1 17.0 1,010 810

3594396 24APA736A30 CAP**6025A** 58HDV080 --- ---20 38,000 30,400 13.0 17.0 1,220 950

3594397 24APA736A30 CAP**6025A** 58HDV100 --- ---20 37,000 30,200 13.0 17.0 1,140 900

3483966 24APA736A30 CNPH*3617A** 58ME(B,C)060---12 35,800 29,600 12.6 16.0 1,055 935

3483967 24APA736A30 CNPH*3617A** 58ME(B,C)080---12 35,800 29,400 12.7 16.0 1,035 905

3483968 24APA736A30 CNPH*3617A** 58ME(B,C)080---16 35,800 29,600 12.6 16.0 1,055 965

3483880 24APA736A30 CNPH*3617A** 58PH*090---16 35,800 29,400 12.7 16.0 1,035 905

4213228 24APA736A30 CNPH*3617A** OVLAAB048112 35,400 28,800 12.0 15.7 1,085 880

4213229 24APA736A30 CNPH*3617A** OVLAAB060154 36,200 29,600 12.2 16.2 1,250 1,020

4213227 24APA736A30 CNPH*3617A** OVMAAB042112 35,200 28,600 12.2 16.2 1,035 825

3483872 24APA736A30 CNPH*3617A**+TDR 35,400 28,600 11.8 14.5 1,050 840

4230281 24APA736A30 CNPH*3617A**+UI 58CV(A,X)070 ---12 35,400 28,600 12.2 16.2 1,050 840

3483878 24APA736A30 CNPH*3617A**+UI 58CV(A,X)090 ---16 35,600 28,800 12.7 16.5 1,005 805

3483879 24APA736A30 CNPH*3617A**+UI 58CV(A,X)155 ---22 35,800 29,000 12.8 16.5 1,015 810

3483873 24APA736A30 CNPH*3617A**+UI 58MV(B,C)060---14 35,800 29,000 12.5 16.0 1,055 845

3483874 24APA736A30 CNPH*3617A**+UI 58MV(B,C)080---14 35,600 29,000 12.4 16.0 1,030 825

3483875 24APA736A30 CNPH*3617A**+UI 58MV(B,C)080---20 35,600 28,800 12.5 16.0 1,010 810

3483876 24APA736A30 CNPH*3617A**+UI 58MV(B,C)100---20 35,800 29,000 12.6 16.0 1,040 830

3483877 24APA736A30 CNPH*3617A**+UI 58MV(B,C)120---20 35,800 29,000 12.7 16.5 1,010 810

3483969 24APA736A30 CNPH*4221A** 58ME(B,C)060---12 36,400 30,000 12.8 16.5 1,080 950

3483970 24APA736A30 CNPH*4221A** 58ME(B,C)080---12 36,400 29,800 12.8 16.5 1,055 920

3483971 24APA736A30 CNPH*4221A** 58ME(B,C)080---16 36,400 30,000 12.8 16.5 1,075 980

3483891 24APA736A30 CNPH*4221A** 58PH*090---16 36,400 29,800 12.9 16.5 1,055 925

4213231 24APA736A30 CNPH*4221A** OVLAAB048112 35,800 29,200 12.2 16.2 1,085 880

4213232 24APA736A30 CNPH*4221A** OVLAAB060154 36,800 29,800 12.5 16.5 1,250 1,020

4213230 24APA736A30 CNPH*4221A** OVMAAB042112 35,800 29,000 12.2 16.2 1,035 825

3483883 24APA736A30 CNPH*4221A**+TDR 35,800 28,800 11.9 14.5 1,050 840

3483888 24APA736A30 CNPH*4221A**+UI 58CV(A,X)070 ---12 36,000 29,200 12.6 16.0 1,005 805

3483889 24APA736A30 CNPH*4221A**+UI 58CV(A,X)090 ---16 36,200 29,200 12.9 16.5 1,005 805

3483890 24APA736A30 CNPH*4221A**+UI 58CV(A,X)110 ---20 36,200 29,200 12.9 16.5 1,020 815

3483884 24APA736A30 CNPH*4221A**+UI 58MV(B,C)060---14 36,400 29,400 12.8 16.5 1,055 845

3483885 24APA736A30 CNPH*4221A**+UI 58MV(B,C)080---14 36,200 29,200 12.6 16.5 1,030 825

3483886 24APA736A30 CNPH*4221A**+UI 58MV(B,C)080---20 36,000 29,200 12.7 16.5 1,010 810

3483887 24APA736A30 CNPH*4221A**+UI 58MV(B,C)100---20 36,200 29,200 12.8 16.0 1,040 830

4213234 24APA736A30 CNPH*4321A** OVLAAB048112 37,000 30,000 12.7 16.7 1,085 880

4213235 24APA736A30 CNPH*4321A** OVLAAB060154 38,000 30,800 13.0 17.2 1,250 1,020

4213233 24APA736A30 CNPH*4321A** OVMAAB042112 36,800 29,600 12.7 17.0 1,035 825

4230282 24APA736A30 CNPH*4321A**+UI 58CV(A,X)070 ---12 37,000 29,800 13.0 17.0 1,050 840

3483972 24APA736A30 CNPH*4821A** 58ME(B,C)060---12 37,200 30,600 13.1 17.0 1,115 985

3483973 24APA736A30 CNPH*4821A** 58ME(B,C)080---12 37,200 30,400 13.1 17.0 1,085 945

3483974 24APA736A30 CNPH*4821A** 58ME(B,C)080---16 37,200 30,600 13.1 16.5 1,110 1,010

4213237 24APA736A30 CNPH*4821A** OVLAAB048112 36,600 29,600 12.5 16.5 1,085 880

4213238 24APA736A30 CNPH*4821A** OVLAAB060154 37,400 30,400 12.7 17.0 1,250 1,020

4213236 24APA736A30 CNPH*4821A** OVMAAB042112 36,400 29,400 12.7 16.7 1,035 825

3483893 24APA736A30 CNPH*4821A**+TDR 36,400 29,200 12.1 14.5 1,050 840

4230283 24APA736A30 CNPH*4821A**+UI 58CV(A,X)070 ---12 36,400 29,400 12.7 16.7 1,050 840

3483898 24APA736A30 CNPH*4821A**+UI 58CV(A,X)090 ---16 36,800 29,600 13.1 17.0 1,005 805

3483899 24APA736A30 CNPH*4821A**+UI 58CV(A,X)110 ---20 36,800 29,600 13.1 17.0 1,020 815

3483900 24APA736A30 CNPH*4821A**+UI 58CV(A,X)135 ---22 36,800 29,600 13.2 17.0 1,010 810

3483901 24APA736A30 CNPH*4821A**+UI 58CV(A,X)155 ---22 37,000 29,800 13.4 17.0 1,015 810

See notes on page 21

24APA7

COMBINATION RATINGS CONTINUED

AHRI

Ref. No. Model Number Coil

Model Number

Furnace

Model Number

Cooling

Capacity EER SEER ID CFM

High Low High Low

3483894 24APA736A30 CNPH*4821A**+UI 58MV(B,C)080---14 36,800 29,800 12.9 16.5 1,030 825

3483895 24APA736A30 CNPH*4821A**+UI 58MV(B,C)080---20 36,800 29,600 13.0 16.5 1,010 810

3483896 24APA736A30 CNPH*4821A**+UI 58MV(B,C)100---20 36,800 29,800 13.0 16.5 1,040 830

3483897 24APA736A30 CNPH*4821A**+UI 58MV(B,C)120---20 36,800 29,600 13.2 17.0 1,010 810

3483957 24APA736A30 CNPV*3617A** 58ME(B,C)060---12 35,800 29,600 12.6 16.0 1,055 935

3483958 24APA736A30 CNPV*3617A** 58ME(B,C)080---12 35,800 29,400 12.7 16.0 1,035 905

3483959 24APA736A30 CNPV*3617A** 58ME(B,C)080---16 35,800 29,600 12.6 16.0 1,055 965

3878007 24APA736A30 CNPV*3617A** 58UVB060---14 35,800 29,000 12.5 16.0 1,055 845

3563765 24APA736A30 CNPV*3617A** 58VLR105---12 35,800 29,200 12.4 16.0 1,065 880

3563764 24APA736A30 CNPV*3617A** 58VMR105---12 35,400 28,800 12.4 16.0 975 800

4213214 24APA736A30 CNPV*3617A** OVMAAB042112 35,200 28,600 12.2 16.2 1,035 825

3483846 24APA736A30 CNPV*3617A**+TDR 35,400 28,600 11.8 14.5 1,050 840

4230278 24APA736A30 CNPV*3617A**+UI 58CV(A,X)070---12 35,400 28,600 12.2 16.2 1,050 840

3483848 24APA736A30 CNPV*3617A**+UI 58CV(A,X)090---16 35,600 28,800 12.7 16.5 1,005 805

3483847 24APA736A30 CNPV*3617A**+UI 58MV(B,C)060---14 35,800 29,000 12.5 16.0 1,055 845

3483854 24APA736A30 CNPV*3621A** 58PH*090---16 36,000 29,400 12.8 16.0 1,045 910

3878008 24APA736A30 CNPV*3621A** 58UVB080---14 35,600 29,000 12.4 16.0 1,030 825

3878009 24APA736A30 CNPV*3621A** 58UVB080---20 35,600 28,800 12.5 16.0 1,010 810

3878010 24APA736A30 CNPV*3621A** 58UVB100---20 35,800 29,000 12.6 16.0 1,040 830

3563767 24APA736A30 CNPV*3621A** 58VLR105---12 35,800 29,200 12.4 16.0 1,065 880

3563766 24APA736A30 CNPV*3621A** 58VMR105---12 35,400 28,800 12.5 16.0 975 800

4213216 24APA736A30 CNPV*3621A** OVLAAB048112 35,400 28,800 12.0 15.7 1,085 880

4213215 24APA736A30 CNPV*3621A** OVMAAB042112 35,400 28,600 12.2 16.2 1,035 825

3483849 24APA736A30 CNPV*3621A**+TDR 35,400 28,600 11.8 14.5 1,050 840

3483853 24APA736A30 CNPV*3621A**+UI 58CV(A,X)110---20 35,800 29,000 12.7 16.5 1,020 815

3483850 24APA736A30 CNPV*3621A**+UI 58MV(B,C)080---14 35,600 29,000 12.4 16.0 1,030 825

3483851 24APA736A30 CNPV*3621A**+UI 58MV(B,C)080---20 35,600 28,800 12.5 16.0 1,010 810

3483852 24APA736A30 CNPV*3621A**+UI 58MV(B,C)100---20 35,800 29,000 12.6 16.0 1,040 830

3483960 24APA736A30 CNPV*3717A** 58ME(B,C)060---12 37,600 30,800 13.1 17.0 1,090 965

3483961 24APA736A30 CNPV*3717A** 58ME(B,C)080---12 37,400 30,600 13.2 17.0 1,060 930

3483962 24APA736A30 CNPV*3717A** 58ME(B,C)080---16 37,600 30,800 13.1 17.0 1,085 990

3878039 24APA736A30 CNPV*3717A** 58UVB060---14 37,400 30,200 13.1 17.0 1,055 845

3563769 24APA736A30 CNPV*3717A** 58VLR105---12 37,400 30,400 13.0 16.5 1,065 880

3563768 24APA736A30 CNPV*3717A** 58VMR105---12 36,800 29,800 13.0 16.5 975 800

4213217 24APA736A30 CNPV*3717A** OVMAAB042112 36,800 29,600 12.7 16.7 1,035 825

3483855 24APA736A30 CNPV*3717A**+TDR 36,800 29,600 12.0 15.0 1,050 840

4230279 24APA736A30 CNPV*3717A**+UI 58CV(A,X)070---12 37,000 29,800 13.0 16.7 1,050 840

3484275 24APA736A30 CNPV*3717A**+UI 58CV(A,X)090---16 37,200 30,000 13.2 17.0 1,005 805

3484274 24APA736A30 CNPV*3717A**+UI 58MV(B,C)060---14 37,400 30,200 13.1 17.0 1,055 845

3483963 24APA736A30 CNPV*4217A** 58ME(B,C)060---12 36,800 30,200 12.9 16.5 1,075 950

3483964 24APA736A30 CNPV*4217A** 58ME(B,C)080---12 36,600 30,000 12.9 16.5 1,050 920

3483965 24APA736A30 CNPV*4217A** 58ME(B,C)080---16 36,800 30,200 12.9 16.5 1,075 980

3878011 24APA736A30 CNPV*4217A** 58UVB060---14 36,600 29,600 12.8 16.0 1,055 845

3563771 24APA736A30 CNPV*4217A** 58VLR105---12 36,600 29,800 12.5 16.5 1,065 880

3563770 24APA736A30 CNPV*4217A** 58VMR105---12 36,200 29,400 12.7 16.5 975 800

4213218 24APA736A30 CNPV*4217A** OVMAAB042112 36,000 29,200 12.5 16.5 1,035 825

3483856 24APA736A30 CNPV*4217A**+TDR 36,000 29,000 12.0 14.5 1,050 840

4230280 24APA736A30 CNPV*4217A**+UI 58CV(A,X)070---12 36,200 29,200 12.5 16.5 1,050 840

3483858 24APA736A30 CNPV*4217A**+UI 58CV(A,X)090---16 36,400 29,400 12.9 16.5 1,005 805

3483857 24APA736A30 CNPV*4217A**+UI 58MV(B,C)060---14 36,600 29,600 12.8 16.0 1,055 845

3680497 24APA736A30 CNPV*4221A** 58CV(A,X)090 ---16 36,000 29,000 12.8 16.5 1,005 835

3878012 24APA736A30 CNPV*4221A** 58UVB080---14 36,200 29,400 12.6 16.0 1,030 840

3878013 24APA736A30 CNPV*4221A** 58UVB080---20 36,000 29,200 12.7 16.5 1,010 825

3878014 24APA736A30 CNPV*4221A** 58UVB100---20 36,200 29,200 12.8 16.5 1,040 810

3563775 24APA736A30 CNPV*4221A** 58VLR105---12 36,200 29,600 12.6 16.0 1,065 880

3563777 24APA736A30 CNPV*4221A** 58VLR120---20 36,800 30,200 12.7 16.5 1,170 1,005

3563774 24APA736A30 CNPV*4221A** 58VMR105---12 35,800 29,200 12.6 16.5 975 800

3563776 24APA736A30 CNPV*4221A** 58VMR120---20 36,600 30,000 12.5 16.0 1,155 1,000

4213220 24APA736A30 CNPV*4221A** OVLAAB048112 35,800 29,200 12.2 16.2 1,085 880

4213219 24APA736A30 CNPV*4221A** OVMAAB042112 35,800 29,000 12.2 16.2 1,035 825

3483859 24APA736A30 CNPV*4221A**+TDR 35,800 28,800 11.9 14.5 1,050 840

3747877 24APA736A30 CNPV*4221A**+UI 58CV(A,X)090---16 36,000 29,000 12.8 16.5 1,005 835

3483860 24APA736A30 CNPV*4221A**+UI 58MV(B,C)080---14 36,200 29,400 12.6 16.0 1,030 840

3483861 24APA736A30 CNPV*4221A**+UI 58MV(B,C)080---20 36,000 29,200 12.7 16.5 1,010 825

3483862 24APA736A30 CNPV*4221A**+UI 58MV(B,C)100---20 36,200 29,200 12.8 16.5 1,040 810

4213221 24APA736A30 CNPV*4324A** OVLAAB048112 37,200 30,000 12.7 16.7 1,085 880

4213222 24APA736A30 CNPV*4324A** OVLAAB060154 38,000 30,800 13.0 17.2 1,250 1,020

3483978 24APA736A30 CNPV*4821A** 58ME(B,C)060---12 37,200 29,800 13.1 17.0 1,115 835

3483975 24APA736A30 CNPV*4821A** 58ME(B,C)080---16 37,000 30,600 13.0 16.5 1,090 995

3878018 24APA736A30 CNPV*4821A** 58UVB080---14 36,800 29,600 12.9 16.5 1,030 820

3878015 24APA736A30 CNPV*4821A** 58UVB080---20 36,800 29,600 13.0 16.5 1,010 810

See notes on page 21

24APA7

COMBINATION RATINGS CONTINUED

AHRI

Ref. No. Model Number Coil

Model Number

Furnace

Model Number

Cooling

Capacity EER SEER ID CFM

High Low High Low

3878016 24APA736A30 CNPV*4821A** 58UVB100---20 36,800 29,800 13.0 16.5 1,040 830

3563783 24APA736A30 CNPV*4821A** 58VLR105---12 37,000 30,000 12.9 16.5 1,065 880

3563785 24APA736A30 CNPV*4821A** 58VLR120---20 37,600 30,600 13.0 16.5 1,170 1,005

3563782 24APA736A30 CNPV*4821A** 58VMR105---12 36,400 29,600 12.9 16.5 975 800

3563784 24APA736A30 CNPV*4821A** 58VMR120---20 37,400 30,600 13.0 16.5 1,155 1,000

4213224 24APA736A30 CNPV*4821A** OVLAAB048112 36,600 29,600 12.5 16.5 1,085 880

4213223 24APA736A30 CNPV*4821A** OVMAAB042112 36,400 29,400 12.7 16.7 1,035 825

3483864 24APA736A30 CNPV*4821A**+TDR 36,400 29,200 12.1 14.5 1,050 840

3483977 24APA736A30 CNPV*4821A**+UI 58CV(A,X)090---16 36,800 29,800 13.1 17.0 1,005 835

3483867 24APA736A30 CNPV*4821A**+UI 58CV(A,X)110---20 36,800 29,600 13.1 17.0 1,020 815

3483976 24APA736A30 CNPV*4821A**+UI 58MV(B,C)080---14 36,800 29,600 12.9 16.5 1,030 820

3483865 24APA736A30 CNPV*4821A**+UI 58MV(B,C)080---20 36,800 29,600 13.0 16.5 1,010 810

3483866 24APA736A30 CNPV*4821A**+UI 58MV(B,C)100---20 36,800 29,800 13.0 16.5 1,040 830

3878019 24APA736A30 CNPV*4824A** 58UVB080---14 36,800 29,600 12.9 16.5 1,030 820

3878020 24APA736A30 CNPV*4824A** 58UVB080---20 36,600 29,800 13.0 16.5 1,010 840

3878021 24APA736A30 CNPV*4824A** 58UVB100---20 36,800 29,600 13.1 16.5 1,040 800

3878017 24APA736A30 CNPV*4824A** 58UVB120---20 36,800 29,600 13.1 17.0 1,010 810

4213225 24APA736A30 CNPV*4824A** OVLAAB048112 36,600 29,600 12.5 16.5 1,085 880

4213226 24APA736A30 CNPV*4824A** OVLAAB060154 37,400 30,400 12.7 17.0 1,250 1,020

3483868 24APA736A30 CNPV*4824A**+TDR 36,400 29,200 12.1 14.5 1,050 840

3483870 24APA736A30 CNPV*4824A**+UI 58CV(A,X)135---22 36,800 29,600 13.2 17.0 1,010 810

3483871 24APA736A30 CNPV*4824A**+UI 58CV(A,X)155---22 37,000 29,800 13.4 17.0 1,015 810

3483979 24APA736A30 CNPV*4824A**+UI 58MV(B,C)080---14 36,800 29,600 12.9 16.5 1,030 820

3483980 24APA736A30 CNPV*4824A**+UI 58MV(B,C)080---20 36,600 29,800 13.0 16.5 1,010 840

3483981 24APA736A30 CNPV*4824A**+UI 58MV(B,C)100---20 36,800 29,600 13.1 16.5 1,040 800

3483869 24APA736A30 CNPV*4824A**+UI 58MV(B,C)120---20 36,800 29,600 13.1 17.0 1,010 810

3483920 24APA736A30 CSPH*3612A** 58HDV060--- ---12 36,800 29,200 12.5 16.0 1,100 775

3483917 24APA736A30 CSPH*3612A** 58ME(B,C)060 ---12 37,000 29,600 13.0 17.0 1,080 805

3483918 24APA736A30 CSPH*3612A** 58ME(B,C)080 ---12 36,800 30,200 13.0 16.5 1,055 920

3483919 24APA736A30 CSPH*3612A** 58ME(B,C)080 ---16 37,000 30,400 12.9 16.5 1,080 980

3483916 24APA736A30 CSPH*3612A** 58PH*090---16 37,000 30,200 13.1 16.5 1,060 925

4213240 24APA736A30 CSPH*3612A** OVLAAB048112 36,400 29,600 12.5 16.2 1,085 880

4213241 24APA736A30 CSPH*3612A** OVLAAB060154 37,200 30,200 12.7 16.7 1,250 1,020

4213239 24APA736A30 CSPH*3612A** OVMAAB042112 36,200 29,200 12.5 16.5 1,035 825

3483907 24APA736A30 CSPH*3612A**+TDR 36,200 29,200 12.1 14.5 1,050 840

3483911 24APA736A30 CSPH*3612A**+UI 58CV(A,X)070---12 36,400 29,400 12.8 16.5 1,005 805

3483912 24APA736A30 CSPH*3612A**+UI 58CV(A,X)090---16 36,600 29,600 13.0 16.5 1,005 805

3483913 24APA736A30 CSPH*3612A**+UI 58CV(A,X)110---20 36,600 29,600 13.0 16.5 1,020 815

3483914 24APA736A30 CSPH*3612A**+UI 58CV(A,X)135---22 36,600 29,600 13.1 17.0 1,010 810

3483915 24APA736A30 CSPH*3612A**+UI 58CV(A,X)155---22 36,800 29,600 13.2 17.0 1,015 810

3483908 24APA736A30 CSPH*3612A**+UI 58MV(B,C)080---20 36,600 29,600 12.9 16.5 1,010 810

3483909 24APA736A30 CSPH*3612A**+UI 58MV(B,C)100---20 36,800 29,600 12.9 16.5 1,040 830

3483910 24APA736A30 CSPH*3612A**+UI 58MV(B,C)120---20 36,600 29,600 13.0 16.5 1,010 810

3483935 24APA736A30 CSPH*4212A** 58HDV060--- ---12 37,000 29,400 12.5 16.5 1,110 785

3483932 24APA736A30 CSPH*4212A** 58ME(B,C)060 ---12 37,200 29,800 13.1 17.0 1,095 815

3483933 24APA736A30 CSPH*4212A** 58ME(B,C)080 ---12 37,200 29,600 13.1 17.0 1,065 780

3483934 24APA736A30 CSPH*4212A** 58ME(B,C)080 ---16 37,200 30,600 13.0 16.5 1,090 990

3483931 24APA736A30 CSPH*4212A** 58PH*090---16 37,200 30,400 13.2 16.5 1,070 935

4213243 24APA736A30 CSPH*4212A** OVLAAB048112 36,600 29,600 12.5 16.5 1,085 880

4213244 24APA736A30 CSPH*4212A** OVLAAB060154 37,600 30,400 12.7 16.7 1,250 1,020

4213242 24APA736A30 CSPH*4212A** OVMAAB042112 36,400 29,400 12.7 16.7 1,035 825

3483921 24APA736A30 CSPH*4212A**+TDR 36,400 29,400 12.1 15.0 1,050 840

3483926 24APA736A30 CSPH*4212A**+UI 58CV(A,X)070---12 36,800 29,600 12.9 16.5 1,005 805

3483927 24APA736A30 CSPH*4212A**+UI 58CV(A,X)090---16 36,800 29,600 13.1 17.0 1,005 805

3483928 24APA736A30 CSPH*4212A**+UI 58CV(A,X)110---20 37,000 29,800 13.1 17.0 1,020 815

3483929 24APA736A30 CSPH*4212A**+UI 58CV(A,X)135---22 36,800 29,800 13.2 17.0 1,010 810

3483930 24APA736A30 CSPH*4212A**+UI 58CV(A,X)155---22 37,000 29,800 13.3 17.0 1,015 810

3483922 24APA736A30 CSPH*4212A**+UI 58MV(B,C)080---14 36,800 29,800 12.9 16.5 1,030 825

3483923 24APA736A30 CSPH*4212A**+UI 58MV(B,C)080---20 36,800 29,600 13.0 16.5 1,010 810

3483924 24APA736A30 CSPH*4212A**+UI 58MV(B,C)100---20 37,000 29,800 13.0 16.5 1,040 830

3483925 24APA736A30 CSPH*4212A**+UI 58MV(B,C)120---20 36,800 29,800 13.1 17.0 1,010 810

3483950 24APA736A30 CSPH*4812A** 58HDV060--- ---12 37,200 29,600 12.6 16.5 1,110 790

3483947 24APA736A30 CSPH*4812A** 58ME(B,C)060 ---12 37,400 30,000 13.1 17.0 1,095 820

3483948 24APA736A30 CSPH*4812A** 58ME(B,C)080 ---12 37,400 30,600 13.1 17.0 1,065 930

3483949 24APA736A30 CSPH*4812A** 58ME(B,C)080 ---16 37,400 30,800 13.1 16.5 1,090 990

3483946 24APA736A30 CSPH*4812A** 58PH*090---16 37,400 30,600 13.2 16.5 1,070 940

4213246 24APA736A30 CSPH*4812A** OVLAAB048112 36,800 29,800 12.5 16.5 1,085 880

4213247 24APA736A30 CSPH*4812A** OVLAAB060154 37,600 30,600 12.7 17.0 1,250 1,020

4213245 24APA736A30 CSPH*4812A** OVMAAB042112 36,600 29,600 12.7 16.7 1,035 825

3483936 24APA736A30 CSPH*4812A**+TDR 36,600 29,400 12.2 15.0 1,050 840

3483941 24APA736A30 CSPH*4812A**+UI 58CV(A,X)070---12 36,800 29,800 12.9 16.5 1,005 805

See notes on page 21

24APA7

COMBINATION RATINGS CONTINUED

AHRI

Ref. No. Model Number Coil

Model Number

Furnace

Model Number

Cooling

Capacity EER SEER ID CFM

High Low High Low

3483942 24APA736A30 CSPH*4812A**+UI 58CV(A,X)090---16 37,000 29,800 13.1 17.0 1,005 805

3483943 24APA736A30 CSPH*4812A**+UI 58CV(A,X)110---20 37,000 29,800 13.1 17.0 1,020 815

3483944 24APA736A30 CSPH*4812A**+UI 58CV(A,X)135---22 37,000 29,800 13.2 17.0 1,010 810

3483945 24APA736A30 CSPH*4812A**+UI 58CV(A,X)155---22 37,200 30,200 13.3 17.0 1,015 810

3483937 24APA736A30 CSPH*4812A**+UI 58MV(B,C)080---14 37,000 29,800 12.9 16.5 1,030 825

3483938 24APA736A30 CSPH*4812A**+UI 58MV(B,C)080---20 37,000 29,800 13.0 16.5 1,010 810

3483939 24APA736A30 CSPH*4812A**+UI 58MV(B,C)100---20 37,200 30,000 13.1 16.5 1,040 830

3483940 24APA736A30 CSPH*4812A**+UI 58MV(B,C)120---20 37,000 29,800 13.2 17.0 1,010 810

3483982 24APA736A30 FE4AN(B,F)003+UI 36,400 29,400 13.0 17.0 1,100 875

3483983 24APA736A30 FE4AN(B,F)005+UI 37,800 30,200 13.5 17.5 1,100 875

3483984 24APA736A30 FE4ANB006+UI 38,500 30,800 13.8 17.5 1,200 925

3850575 24APA736A30 FE4ANF002+UI 36,400 29,600 12.3 16.0 1,200 925

3483985 24APA736A30 FE5ANB004+UI 38,500 31,000 13.7 18.0 1,200 925

3483904 24APA736A30 FV4CN(B,F)003 36,200 29,200 13.0 17.0 1,050 840

3483905 24APA736A30 FV4CN(B,F)005 37,600 30,000 13.5 17.5 1,050 840

3483906 24APA736A30 FV4CNB006 38,000 30,200 13.7 17.5 1,050 840

3584911 24APA736A30 FV4CNF002 35,800 29,200 12.6 16.0 1,050 840

3638145 24APA748A**31 †CNPH*6124A**+UI 58MV(B,C)100---20 50,000 41,000 13.2 16.5 1,395 1,115

3638020 24APA748A**31 CAP**4817A**+TDR 47,500 39,000 12.0 14.5 1,400 1,120

3638039 24APA748A**31 CAP**4817A**+UI 58CV(A,X)090---16 47,500 39,000 12.5 16.0 1,345 1,075

3638117 24APA748A**31 CAP**4821A** 58ME(B,C)080---16 47,500 39,000 12.3 16.0 1,430 1,105

3638118 24APA748A**31 CAP**4821A** 58ME(B,C)100---20 47,500 39,000 12.6 16.0 1,385 1,050

3638042 24APA748A**31 CAP**4821A** 58PH*110 ---20 47,500 39,000 12.7 16.0 1,350 1,110

3877980 24APA748A**31 CAP**4821A** 58UVB080---20 47,000 38,500 12.3 15.5 1,310 1,050

3877981 24APA748A**31 CAP**4821A** 58UVB100---20 47,000 39,000 12.2 15.5 1,395 1,115

3638155 24APA748A**31 CAP**4821A** 58VLR120---20 47,000 39,000 12.2 15.5 1,350 1,170

3638154 24APA748A**31 CAP**4821A** 58VMR120---20 47,000 39,000 12.1 15.5 1,355 1,155

4213273 24APA748A**31 CAP**4821A** OVLAAB048112 47,500 39,500 12.2 15.7 1,450 1,170

3638021 24APA748A**31 CAP**4821A**+TDR 48,000 38,500 12.0 14.5 1,600 1,120

3638040 24APA748A**31 CAP**4821A**+UI 58MV(B,C)080---20 47,000 38,500 12.3 15.5 1,310 1,050

3638041 24APA748A**31 CAP**4821A**+UI 58MV(B,C)100---20 47,000 39,000 12.2 15.5 1,395 1,115

3638171 24APA748A**31 CAP**4823A** 58HDV080--- ---20 46,000 39,000 11.8 15.0 1,470 1,160

4213253 24APA748A**31 CAP**4823A** OVLAAB048112 47,500 39,500 12.2 15.7 1,450 1,170

3638030 24APA748A**31 CAP**4823A**+TDR 46,000 38,000 11.8 14.5 1,400 1,120

3638119 24APA748A**31 CAP**4824A** 58ME(B,C)100---20 47,500 39,000 12.7 16.0 1,410 1,065

3638120 24APA748A**31 CAP**4824A** 58ME(B,C)120---20 48,000 40,000 12.8 16.0 1,425 1,260

3638046 24APA748A**31 CAP**4824A** 58PH*090 ---16 47,500 39,000 12.5 16.0 1,415 1,100

3638047 24APA748A**31 CAP**4824A** 58PH*110 ---20 47,500 39,500 12.8 16.0 1,375 1,130

3877982 24APA748A**31 CAP**4824A** 58UVB120---20 47,500 39,000 12.5 16.0 1,360 1,090

3638157 24APA748A**31 CAP**4824A** 58VLR120---20 47,000 39,500 12.2 15.5 1,350 1,170

3638156 24APA748A**31 CAP**4824A** 58VMR120---20 47,000 39,000 12.2 15.5 1,355 1,155

4213248 24APA748A**31 CAP**4824A** OVLAAB048112 48,000 39,500 12.2 15.7 1,450 1,170

4213249 24APA748A**31 CAP**4824A** OVLAAB060154 48,500 40,000 13.0 16.7 1,445 1,170

3638022 24APA748A**31 CAP**4824A**+TDR 47,000 38,500 12.0 14.5 1,400 1,120

3638044 24APA748A**31 CAP**4824A**+UI 58CV(A,X)110---20 47,500 39,000 12.6 16.0 1,355 1,085

3638045 24APA748A**31 CAP**4824A**+UI 58CV(A,X)135---22 47,500 39,000 12.8 16.0 1,355 1,085

3638043 24APA748A**31 CAP**4824A**+UI 58MV(B,C)120---20 47,500 39,000 12.5 16.0 1,360 1,090

3638051 24APA748A**31 CAP**6021A** 58PH*090 ---16 48,500 39,500 12.8 16.0 1,410 1,100

3638052 24APA748A**31 CAP**6021A** 58PH*110 ---20 48,500 39,500 13.0 16.5 1,370 1,125

3877983 24APA748A**31 CAP**6021A** 58UVB080---20 48,000 39,000 12.6 16.0 1,310 1,050

3877984 24APA748A**31 CAP**6021A** 58UVB100---20 48,500 39,500 12.5 16.0 1,395 1,115

3638159 24APA748A**31 CAP**6021A** 58VLR120---20 47,000 39,000 12.7 15.5 1,350 1,170

3638158 24APA748A**31 CAP**6021A** 58VMR120---20 48,000 39,000 12.4 15.5 1,355 1,155

4213250 24APA748A**31 CAP**6021A** OVLAAB048112 49,000 40,000 12.5 16.0 1,450 1,170

3638023 24APA748A**31 CAP**6021A**+TDR 48,000 39,000 12.3 14.5 1,400 1,120

3638050 24APA748A**31 CAP**6021A**+UI 58CV(A,X)110---20 48,500 39,500 12.8 16.0 1,355 1,085

3638048 24APA748A**31 CAP**6021A**+UI 58MV(B,C)080---20 48,000 39,000 12.6 16.0 1,310 1,050

3638049 24APA748A**31 CAP**6021A**+UI 58MV(B,C)100---20 48,500 39,500 12.5 16.0 1,395 1,115

3638121 24APA748A**31 CAP**6024A** 58ME(B,C)100---20 48,500 39,500 12.9 16.5 1,410 1,070

3638122 24APA748A**31 CAP**6024A** 58ME(B,C)120---20 49,000 40,500 13.0 16.5 1,425 1,260

3638057 24APA748A**31 CAP**6024A** 58PH*110 ---20 48,500 40,000 13.1 16.5 1,380 1,130

3638058 24APA748A**31 CAP**6024A** 58PH*135 ---20 48,500 40,000 12.9 16.0 1,400 1,235

3877985 24APA748A**31 CAP**6024A** 58UVB120---20 48,500 39,500 12.8 16.0 1,360 1,090

4213251 24APA748A**31 CAP**6024A** OVLAAB048112 49,000 40,000 12.5 16.0 1,450 1,170

4213252 24APA748A**31 CAP**6024A** OVLAAB060154 49,500 40,500 13.2 16.7 1,445 1,170

3638054 24APA748A**31 CAP**6024A**+UI 58CV(A,X)110---20 48,500 39,500 12.8 16.0 1,355 1,085

3638055 24APA748A**31 CAP**6024A**+UI 58CV(A,X)135---22 48,500 39,500 13.0 16.5 1,355 1,085

3638056 24APA748A**31 CAP**6024A**+UI 58CV(A,X)155---22 48,500 39,500 13.1 16.5 1,365 1,090

3638053 24APA748A**31 CAP**6024A**+UI 58MV(B,C)120---20 48,500 39,500 12.8 16.0 1,360 1,090

3638170 24APA748A**31 CAP**6025A** 58HDV080--- ---20 47,500 40,000 12.2 16.0 1,495 1,185

See notes on page 21

24APA7

COMBINATION RATINGS CONTINUED

AHRI

Ref. No. Model Number Coil

Model Number

Furnace

Model Number

Cooling

Capacity EER SEER ID CFM

High Low High Low

3638172 24APA748A**31 CAP**6025A** 58HDV100--- ---20 47,000 39,000 12.2 15.5 1,430 1,120

4213254 24APA748A**31 CAP**6025A** OVLAAB048112 49,000 40,000 12.5 16.0 1,450 1,170

4213255 24APA748A**31 CAP**6025A** OVLAAB060154 49,500 40,500 13.2 16.7 1,445 1,170

3638031 24APA748A**31 CAP**6025A**+TDR 47,000 38,000 12.0 14.5 1,400 1,120

3638092 24APA748A**31 CNPH*4821A** 58HDV080--- ---20 48,000 39,500 12.3 16.0 1,495 1,185

3638093 24APA748A**31 CNPH*4821A** 58HDV100--- ---20 47,500 39,500 12.4 16.0 1,430 1,125

3638130 24APA748A**31 CNPH*4821A** 58ME(B,C)080---16 47,500 38,500 12.4 16.0 1,450 1,020

3638131 24APA748A**31 CNPH*4821A** 58ME(B,C)100---20 47,500 39,000 12.7 16.5 1,410 1,070

3638132 24APA748A**31 CNPH*4821A** 58ME(B,C)120---20 48,000 40,000 12.8 16.0 1,425 1,260

3638090 24APA748A**31 CNPH*4821A** 58PH*090---16 47,500 39,500 12.6 16.0 1,420 1,105

3638091 24APA748A**31 CNPH*4821A** 58PH*110---20 48,000 39,500 12.8 16.0 1,380 1,130

4213263 24APA748A**31 CNPH*4821A** OVLAAB048112 48,000 40,000 12.2 15.7 1,450 1,170

4213264 24APA748A**31 CNPH*4821A** OVLAAB060154 48,500 40,000 13.0 16.7 1,445 1,170

3638028 24APA748A**31 CNPH*4821A**+TDR 47,000 38,500 12.1 14.5 1,400 1,120

4000159 24APA748A**31 CNPH*4821A**+UI 58CV(A,X)090---16 47,500 39,500 13.0 16.0 1,400 1,120

3638089 24APA748A**31 CNPH*4821A**+UI 58CV(A,X)110---20 47,500 39,000 12.6 16.0 1,355 1,085

3638087 24APA748A**31 CNPH*4821A**+UI 58MV(B,C)080---20 47,000 39,000 12.4 16.0 1,310 1,050

3638088 24APA748A**31 CNPH*4821A**+UI 58MV(B,C)100---20 47,500 39,000 12.3 15.5 1,395 1,115

3638035 24APA748A**31 CNPH*6024A** 58HDV100--- ---20 48,500 40,000 12.6 16.0 1,440 1,135

3638133 24APA748A**31 CNPH*6024A** 58ME(B,C)080---16 48,500 39,500 12.6 16.0 1,455 1,130

3638134 24APA748A**31 CNPH*6024A** 58ME(B,C)100---20 48,500 39,500 12.9 16.5 1,425 1,085

3638135 24APA748A**31 CNPH*6024A** 58ME(B,C)120---20 49,000 40,500 13.0 16.5 1,440 1,275

3638033 24APA748A**31 CNPH*6024A** 58PH*110---20 48,500 40,000 13.1 16.5 1,395 1,145

3638034 24APA748A**31 CNPH*6024A** 58PH*135---20 48,500 40,500 12.9 16.0 1,420 1,255

4213265 24APA748A**31 CNPH*6024A** OVLAAB048112 49,000 40,000 12.5 16.2 1,450 1,170

4213266 24APA748A**31 CNPH*6024A** OVLAAB060154 49,500 40,500 13.2 17.0 1,445 1,170

3638029 24APA748A**31 CNPH*6024A**+TDR 48,000 39,000 12.2 14.5 1,400 1,120

3638095 24APA748A**31 CNPH*6024A**+UI 58CV(A,X)135---22 48,500 39,500 13.0 16.5 1,355 1,085

3638096 24APA748A**31 CNPH*6024A**+UI 58CV(A,X)155---22 48,500 39,500 13.2 16.5 1,365 1,090

3638115 24APA748A**31 CNPH*6024A**+UI 58MV(B,C)080---20 48,000 39,000 12.7 16.0 1,310 1,050

3638116 24APA748A**31 CNPH*6024A**+UI 58MV(B,C)100---20 48,500 39,500 12.6 16.0 1,395 1,115

3638094 24APA748A**31 CNPH*6024A**+UI 58MV(B,C)120---20 48,000 39,500 12.8 16.5 1,360 1,090

3638038 24APA748A**31 CNPH*6124A** 58HDV100--- ---20 50,500 41,500 13.3 17.0 1,420 1,115

3638136 24APA748A**31 CNPH*6124A** 58ME(B,C)080---16 50,500 40,500 13.2 17.0 1,445 1,010

3638137 24APA748A**31 CNPH*6124A** 58ME(B,C)100---20 50,500 41,000 13.6 17.5 1,400 1,060

3638138 24APA748A**31 CNPH*6124A** 58ME(B,C)120---20 50,500 42,000 13.7 17.0 1,420 1,250

3638111 24APA748A**31 CNPH*6124A** 58PH*090---16 50,500 41,000 13.4 17.0 1,410 1,095

3638036 24APA748A**31 CNPH*6124A** 58PH*110---20 50,500 41,500 13.7 17.5 1,370 1,120

3638037 24APA748A**31 CNPH*6124A** 58PH*135---20 50,500 42,000 13.5 17.0 1,390 1,220

4213267 24APA748A**31 CNPH*6124A** OVLAAB048112 49,000 40,500 12.5 16.0 1,450 1,170

4213268 24APA748A**31 CNPH*6124A** OVLAAB060154 49,500 40,500 13.2 17.0 1,445 1,170

3638152 24APA748A**31 CNPH*6124A**+UI 58CV(A,X)110---20 50,000 41,000 13.5 17.0 1,355 1,085

3638153 24APA748A**31 CNPH*6124A**+UI 58CV(A,X)135---22 50,500 41,000 13.6 17.0 1,355 1,085

3638151 24APA748A**31 CNPH*6124A**+UI 58MV(B,C)120---20 50,000 41,000 13.4 17.0 1,360 1,090

3638123 24APA748A**31 CNPV*4821A** 58ME(B,C)080---16 47,500 39,500 12.4 16.0 1,450 1,120

3638124 24APA748A**31 CNPV*4821A** 58ME(B,C)100---20 48,000 39,000 12.7 16.5 1,410 1,070

3638062 24APA748A**31 CNPV*4821A** 58PH*110---20 47,500 39,500 12.8 16.0 1,380 1,130

3877986 24APA748A**31 CNPV*4821A** 58UVB080---20 47,000 39,000 12.4 16.0 1,310 1,050

3877967 24APA748A**31 CNPV*4821A** 58UVB100---20 47,500 39,000 12.3 15.5 1,395 1,115

3638161 24APA748A**31 CNPV*4821A** 58VLR120---20 47,000 39,000 12.3 15.5 1,350 1,170

3638160 24APA748A**31 CNPV*4821A** 58VMR120---20 47,000 39,000 12.2 15.5 1,355 1,155

4213256 24APA748A**31 CNPV*4821A** OVLAAB048112 48,000 40,000 12.2 15.7 1,450 1,170

3638024 24APA748A**31 CNPV*4821A**+TDR 47,000 38,500 12.1 14.5 1,400 1,120

3638061 24APA748A**31 CNPV*4821A**+UI 58CV(A,X)110---20 47,500 39,000 12.6 16.0 1,355 1,085

3638059 24APA748A**31 CNPV*4821A**+UI 58MV(B,C)080 ---20 47,000 39,000 12.4 16.0 1,310 1,050

3638060 24APA748A**31 CNPV*4821A**+UI 58MV(B,C)100 ---20 47,500 39,000 12.3 15.5 1,395 1,115

3638125 24APA748A**31 CNPV*4824A** 58ME(B,C)100---20 48,000 39,000 12.7 16.5 1,410 1,070

3638068 24APA748A**31 CNPV*4824A** 58ME(B,C)120---20 48,000 40,000 12.8 16.0 1,425 1,265

3638066 24APA748A**31 CNPV*4824A** 58PH*110---20 48,000 39,500 12.8 16.0 1,380 1,130

3638067 24APA748A**31 CNPV*4824A** 58PH*135---20 47,500 40,000 12.7 16.0 1,400 1,235

3638163 24APA748A**31 CNPV*4824A** 58VLR120---20 47,000 39,000 12.3 15.5 1,350 1,170

3638162 24APA748A**31 CNPV*4824A** 58VMR120---20 47,000 39,000 12.1 15.5 1,355 1,155

4213257 24APA748A**31 CNPV*4824A** OVLAAB048112 48,000 40,000 12.2 15.7 1,450 1,170

4213258 24APA748A**31 CNPV*4824A** OVLAAB060154 48,500 40,000 13.0 16.7 1,445 1,170

3638025 24APA748A**31 CNPV*4824A**+TDR 47,000 38,500 12.1 14.5 1,400 1,120

3638063 24APA748A**31 CNPV*4824A**+UI 58CV(A,X)110---20 47,500 39,000 12.6 16.0 1,355 1,085

3638064 24APA748A**31 CNPV*4824A**+UI 58CV(A,X)135---22 47,500 39,000 12.8 16.0 1,355 1,085

3638065 24APA748A**31 CNPV*4824A**+UI 58CV(A,X)155---22 47,500 39,500 12.9 16.5 1,365 1,090

4149555 24APA748A**31 CNPV*6024A** 58HDV100--- ---20 48,500 40,000 12.6 16.0 1,440 1,115

3747710 24APA748A**31 CNPV*6024A**

58HDV100--- ---20

(DWNFLWONLY) 48,500 40,000 12.6 16.0 1,440 1,115

See notes on page 21

24APA7

COMBINATION RATINGS CONTINUED

AHRI

Ref. No. Model Number Coil

Model Number

Furnace

Model Number

Cooling

Capacity EER SEER ID CFM

High Low High Low

3638126 24APA748A**31 CNPV*6024A** 58ME(B,C)100---20 48,500 39,500 12.9 16.5 1,425 1,085

3638127 24APA748A**31 CNPV*6024A** 58ME(B,C)120---20 49,000 40,500 13.1 16.5 1,440 1,275

3638072 24APA748A**31 CNPV*6024A** 58PH*110---20 48,500 40,000 13.1 16.5 1,395 1,145

3638073 24APA748A**31 CNPV*6024A** 58PH*135---20 48,500 40,500 12.9 16.0 1,420 1,255

3877968 24APA748A**31 CNPV*6024A** 58UVB080---20 48,000 39,000 12.6 16.0 1,310 1,050

3877969 24APA748A**31 CNPV*6024A** 58UVB100---20 48,500 39,500 12.6 16.0 1,395 1,115

3877970 24APA748A**31 CNPV*6024A** 58UVB120---20 48,500 39,500 12.8 16.0 1,360 1,090

3638165 24APA748A**31 CNPV*6024A** 58VLR120---20 48,000 40,000 12.6 16.0 1,350 1,170

3638164 24APA748A**31 CNPV*6024A** 58VMR120---20 48,000 39,000 12.5 16.0 1,355 1,155

4213259 24APA748A**31 CNPV*6024A** OVLAAB048112 49,000 40,000 12.5 16.2 1,450 1,170

4213260 24APA748A**31 CNPV*6024A** OVLAAB060154 49,500 40,500 13.2 17.0 1,445 1,170

3638026 24APA748A**31 CNPV*6024A**+TDR 48,000 39,000 12.2 14.5 1,400 1,120

3638069 24APA748A**31 CNPV*6024A**+UI 58CV(A,X)110---20 48,500 39,500 12.9 16.5 1,355 1,085

3638070 24APA748A**31 CNPV*6024A**+UI 58CV(A,X)135---22 48,500 39,500 13.0 16.5 1,355 1,085

3638071 24APA748A**31 CNPV*6024A**+UI 58CV(A,X)155---22 48,500 39,500 13.2 16.5 1,365 1,090

3638112 24APA748A**31 CNPV*6024A**+UI 58MV(B,C)080 ---20 48,000 39,000 12.6 16.0 1,310 1,050

3638113 24APA748A**31 CNPV*6024A**+UI 58MV(B,C)100 ---20 48,500 39,500 12.6 16.0 1,395 1,115

3638114 24APA748A**31 CNPV*6024A**+UI 58MV(B,C)120 ---20 48,500 39,500 12.8 16.0 1,360 1,090

3638032 24APA748A**31 CNPV*6124A** 58CV(A,X)155 ---22 51,000 41,500 13.9 18.0 1,365 1,090

3638128 24APA748A**31 CNPV*6124A** 58ME(B,C)100---20 51,000 41,500 13.7 17.5 1,430 1,095

3638129 24APA748A**31 CNPV*6124A** 58ME(B,C)120---20 51,000 42,500 13.8 17.5 1,445 1,285

3638110 24APA748A**31 CNPV*6124A** 58PH*090---16 51,000 42,000 13.6 17.5 1,435 1,125

3638085 24APA748A**31 CNPV*6124A** 58PH*110---20 51,000 42,000 13.8 17.5 1,400 1,160

3638086 24APA748A**31 CNPV*6124A** 58PH*135---20 51,000 41,000 13.7 17.5 1,425 1,265

3877971 24APA748A**31 CNPV*6124A** 58UVB100---20 50,500 41,500 13.4 17.0 1,395 1,115

3877972 24APA748A**31 CNPV*6124A** 58UVB120---20 50,500 41,500 13.6 17.5 1,360 1,090

3638167 24APA748A**31 CNPV*6124A** 58VLR120---20 48,000 42,000 13.5 16.5 1,350 1,170

3638166 24APA748A**31 CNPV*6124A** 58VMR120---20 48,000 42,000 13.2 16.5 1,355 1,155

4213261 24APA748A**31 CNPV*6124A** OVLAAB048112 49,500 41,000 12.7 16.2 1,450 1,170

4213262 24APA748A**31 CNPV*6124A** OVLAAB060154 50,000 41,000 13.5 17.2 1,445 1,170

3638018 24APA748A**31 CNPV*6124A**+TDR 50,500 41,000 13.0 15.5 1,400 1,120

3638148 24APA748A**31 CNPV*6124A**+UI 58CV(A,X)110---20 50,500 41,500 13.7 17.5 1,355 1,085

3638149 24APA748A**31 CNPV*6124A**+UI 58CV(A,X)135---22 50,500 41,500 13.8 17.5 1,355 1,085

3638150 24APA748A**31 CNPV*6124A**+UI 58CV(A,X)155---22 51,000 41,500 13.9 17.0 1,365 1,090

3638146 24APA748A**31 CNPV*6124A**+UI 58MV(B,C)100 ---20 50,500 41,500 13.4 17.0 1,395 1,115

3638147 24APA748A**31 CNPV*6124A**+UI 58MV(B,C)120 ---20 50,500 41,500 13.6 17.5 1,360 1,090

3638080 24APA748A**31 CSPH*4812A** 58HDV080 --- ---20 48,000 40,000 12.3 16.0 1,465 1,160

3638081 24APA748A**31 CSPH*4812A** 58HDV100 --- ---20 48,000 39,500 12.5 16.0 1,400 1,100

3638139 24APA748A**31 CSPH*4812A** 58ME(B,C)080 ---16 48,000 39,500 12.4 16.0 1,425 1,100

3638140 24APA748A**31 CSPH*4812A** 58ME(B,C)100 ---20 48,000 39,000 12.8 16.5 1,380 1,045

3638141 24APA748A**31 CSPH*4812A** 58ME(B,C)120 ---20 48,000 40,500 12.9 16.0 1,395 1,230

3638077 24APA748A**31 CSPH*4812A** 58PH*090---16 48,000 39,500 12.6 16.0 1,390 1,080

3638078 24APA748A**31 CSPH*4812A** 58PH*110---20 48,000 39,500 12.9 16.5 1,340 1,105

3638079 24APA748A**31 CSPH*4812A** 58PH*135---20 48,000 40,000 12.7 16.0 1,360 1,200

3638168 24APA748A**31 CSPH*4812A** 58VMR120 ---20 47,000 40,000 12.2 15.5 1,355 1,155

4213269 24APA748A**31 CSPH*4812A** OVLAAB048112 48,500 40,000 12.2 15.7 1,450 1,170

4213270 24APA748A**31 CSPH*4812A** OVLAAB060154 49,000 40,500 13.0 16.7 1,445 1,170

3638019 24APA748A**31 CSPH*4812A**+TDR 47,500 39,000 12.2 14.5 1,400 1,120

3638074 24APA748A**31 CSPH*4812A**+UI 58CV(A,X)090---16 47,500 39,000 12.5 15.5 1,345 1,075

3638075 24APA748A**31 CSPH*4812A**+UI 58CV(A,X)110---20 48,000 39,500 12.6 15.5 1,355 1,085

3638076 24APA748A**31 CSPH*4812A**+UI 58CV(A,X)135---22 48,000 39,500 12.8 16.0 1,355 1,085

3638104 24APA748A**31 CSPH*6012A** 58HDV080 --- ---20 49,000 40,500 12.6 16.0 1,510 1,190

3638105 24APA748A**31 CSPH*6012A** 58HDV100 --- ---20 49,000 40,000 12.7 16.5 1,440 1,130

3638142 24APA748A**31 CSPH*6012A** 58ME(B,C)080 ---16 49,000 40,000 12.6 16.0 1,460 1,125

3638143 24APA748A**31 CSPH*6012A** 58ME(B,C)100 ---20 49,000 40,000 13.0 16.5 1,425 1,075

3638144 24APA748A**31 CSPH*6012A** 58ME(B,C)120 ---20 49,000 41,000 13.1 16.5 1,440 1,270

3638101 24APA748A**31 CSPH*6012A** 58PH*090---16 49,000 40,000 12.9 16.5 1,430 1,110

3638102 24APA748A**31 CSPH*6012A** 58PH*110---20 49,000 40,000 13.1 16.5 1,395 1,135

3638103 24APA748A**31 CSPH*6012A** 58PH*135---20 49,000 40,500 13.0 16.5 1,420 1,250

3638169 24APA748A**31 CSPH*6012A** 58VMR120 ---20 48,000 40,000 12.8 16.0 1,355 1,155

4213271 24APA748A**31 CSPH*6012A** OVLAAB048112 49,000 40,500 12.7 16.2 1,450 1,170

4213272 24APA748A**31 CSPH*6012A** OVLAAB060154 49,500 41,000 13.2 17.0 1,445 1,170

3638027 24APA748A**31 CSPH*6012A**+TDR 48,500 39,500 12.3 15.0 1,400 1,120

3638097 24APA748A**31 CSPH*6012A**+UI 58CV(A,X)090---16 48,500 39,500 12.8 16.5 1,345 1,075

3638098 24APA748A**31 CSPH*6012A**+UI 58CV(A,X)110---20 48,500 40,000 12.9 16.5 1,355 1,085

3638099 24APA748A**31 CSPH*6012A**+UI 58CV(A,X)135---22 48,500 40,000 13.1 16.5 1,355 1,085

3638100 24APA748A**31 CSPH*6012A**+UI 58CV(A,X)155---22 49,000 40,000 13.2 16.5 1,365 1,090

3638082 24APA748A**31 CSPH*6012A**+UI 58MV(B,C)080---20 48,000 39,500 12.7 16.0 1,310 1,050

3638083 24APA748A**31 CSPH*6012A**+UI 58MV(B,C)100---20 48,500 40,000 12.6 16.0 1,395 1,115

3638084 24APA748A**31 CSPH*6012A**+UI 58MV(B,C)120---20 48,500 40,000 12.9 16.5 1,360 1,090

3638106 24APA748A**31 FE4AN(B,F)005+UI 48,500 40,000 13.1 16.5 1,400 1,120

See notes on page 21

24APA7

COMBINATION RATINGS CONTINUED

AHRI

Ref. No. Model Number Coil

Model Number

Furnace

Model Number

Cooling

Capacity EER SEER ID CFM

High Low High Low

3638107 24APA748A**31 FE4ANB006+UI 49,500 40,500 13.4 17.0 1,400 1,120

3638108 24APA748A**31 FV4CN(B,F)005 48,500 40,000 13.1 16.5 1,400 1,120

3638109 24APA748A**31 FV4CNB006 49,500 40,500 13.4 17.0 1,400 1,120

3638181 24APA760A**31 †CNPH*6124A** 58PH*110---20 59,000 47,000 13.0 16.5 1,675 1,245

3638211 24APA760A**31 CAP**6021A** 58ME(B,C)100---20 58,000 46,500 12.9 16.0 1,620 1,255

3638185 24APA760A**31 CAP**6021A** 58PH*110 ---20 58,500 46,500 13.0 16.5 1,670 1,250

3877973 24APA760A**31 CAP**6021A** 58UVB080---20 58,000 46,500 12.0 15.5 1,730 1,310

3877974 24APA760A**31 CAP**6021A** 58UVB100---20 58,000 47,000 12.3 15.5 1,660 1,395

3638243 24APA760A**31 CAP**6021A** 58VLR120---20 58,500 47,000 12.5 16.0 1,735 1,350

3638242 24APA760A**31 CAP**6021A** 58VMR120---20 57,500 47,000 12.0 15.5 1,740 1,355

3638173 24APA760A**31 CAP**6021A**+TDR 58,500 46,500 12.6 15.0 1,750 1,400

3638184 24APA760A**31 CAP**6021A**+UI 58CV(A,X)110---20 58,500 47,000 12.7 16.0 1,695 1,355

3638182 24APA760A**31 CAP**6021A**+UI 58MV(B,C)080---20 58,000 46,500 12.0 15.5 1,730 1,310

3638183 24APA760A**31 CAP**6021A**+UI 58MV(B,C)100---20 58,000 47,000 12.3 15.5 1,660 1,395

3638190 24APA760A**31 CAP**6024A** 58HDV100--- ---20 58,500 47,500 12.4 15.5 1,775 1,415

3638212 24APA760A**31 CAP**6024A** 58ME(B,C)100---20 58,500 46,500 12.9 16.0 1,630 1,260

3638213 24APA760A**31 CAP**6024A** 58ME(B,C)120---20 58,500 47,000 13.1 16.5 1,640 1,280

3638189 24APA760A**31 CAP**6024A** 58PH*135 ---20 58,500 46,500 12.9 16.0 1,650 1,260

3877975 24APA760A**31 CAP**6024A** 58UVB120---20 58,000 47,000 12.6 15.5 1,680 1,360

3638245 24APA760A**31 CAP**6024A** 58VLR120---20 58,000 47,000 12.7 16.0 1,735 1,350

3638244 24APA760A**31 CAP**6024A** 58VMR120---20 58,000 47,000 12.2 15.5 1,740 1,355

4213274 24APA760A**31 CAP**6024A** OVLAAB060154 58,000 47,000 11.5 15.2 2,110 1,675

3638174 24APA760A**31 CAP**6024A**+TDR 58,500 46,500 12.6 15.0 1,750 1,400

3638187 24APA760A**31 CAP**6024A**+UI 58CV(A,X)135---22 58,500 47,000 13.0 16.0 1,685 1,355

3638188 24APA760A**31 CAP**6024A**+UI 58CV(A,X)155---22 59,000 47,500 13.1 16.5 1,705 1,365

3638186 24APA760A**31 CAP**6024A**+UI 58MV(B,C)120---20 58,000 47,000 12.6 15.5 1,680 1,360

3638251 24APA760A**31 CAP**6025A** 58HDV080--- ---20 56,500 46,000 11.6 15.5 1,845 1,445

3638252 24APA760A**31 CAP**6025A** 58HDV100--- ---20 56,500 46,500 11.8 15.5 1,775 1,415

4213275 24APA760A**31 CAP**6025A** OVLAAB060154 58,000 47,000 11.5 15.2 2,110 1,675

3638180 24APA760A**31 CAP**6025A**+TDR 57,000 46,000 11.8 14.5 1,750 1,400

3638226 24APA760A**31 CNPH*6024A** 58ME(B,C)100---20 58,500 47,000 13.0 16.5 1,645 1,275

3638227 24APA760A**31 CNPH*6024A** 58ME(B,C)120---20 58,500 47,000 13.0 16.5 1,655 1,290

3638217 24APA760A**31 CNPH*6024A** 58PH*110---20 58,500 47,000 13.0 16.5 1,700 1,275

3638218 24APA760A**31 CNPH*6024A** 58PH*135---20 58,500 47,000 12.9 16.0 1,670 1,280

4213278 24APA760A**31 CNPH*6024A** OVLAAB060154 58,000 47,000 11.5 15.2 2,110 1,675

3638177 24APA760A**31 CNPH*6024A**+TDR 58,500 46,500 12.6 15.0 1,750 1,400

3638198 24APA760A**31 CNPH*6024A**+UI 58CV(A,X)110---20 58,500 47,000 12.8 16.0 1,695 1,355

3638199 24APA760A**31 CNPH*6024A**+UI 58CV(A,X)135---22 58,500 47,000 13.0 16.0 1,685 1,355

3638200 24APA760A**31 CNPH*6024A**+UI 58CV(A,X)155---22 58,500 47,500 13.1 16.5 1,705 1,365

3638196 24APA760A**31 CNPH*6024A**+UI 58MV(B,C)100---20 57,500 47,000 12.3 15.5 1,660 1,395

3638197 24APA760A**31 CNPH*6024A**+UI 58MV(B,C)120---20 58,000 47,000 12.6 16.0 1,680 1,360

3638220 24APA760A**31 CNPH*6124A** 58HDV100--- ---20 58,500 47,500 12.4 15.5 1,765 1,410

3638228 24APA760A**31 CNPH*6124A** 58ME(B,C)100---20 58,500 47,000 13.0 16.5 1,625 1,255

3638229 24APA760A**31 CNPH*6124A** 58ME(B,C)120---20 58,500 47,000 13.1 16.5 1,630 1,270

3638219 24APA760A**31 CNPH*6124A** 58PH*135---20 58,500 47,000 12.9 16.0 1,640 1,245

4213279 24APA760A**31 CNPH*6124A** OVLAAB060154 58,500 47,500 11.5 15.2 2,110 1,675

3638178 24APA760A**31 CNPH*6124A**+TDR 59,000 47,000 12.7 15.0 1,750 1,400

3638235 24APA760A**31 CNPH*6124A**+UI 58CV(A,X)110---20 58,500 47,500 12.8 16.0 1,695 1,355

3638236 24APA760A**31 CNPH*6124A**+UI 58CV(A,X)135---22 59,000 47,500 13.0 16.0 1,685 1,355

3638237 24APA760A**31 CNPH*6124A**+UI 58CV(A,X)155---22 59,000 47,500 13.2 16.5 1,705 1,365

3638233 24APA760A**31 CNPH*6124A**+UI 58MV(B,C)100---20 58,000 47,500 12.3 15.5 1,660 1,395

3638234 24APA760A**31 CNPH*6124A**+UI 58MV(B,C)120---20 58,500 47,500 12.6 15.5 1,680 1,360

3638214 24APA760A**31 CNPV*6024A** 58ME(B,C)100---20 58,500 47,000 13.0 16.5 1,645 1,275

3638215 24APA760A**31 CNPV*6024A** 58ME(B,C)120---20 58,500 47,000 13.1 16.5 1,655 1,290

3638210 24APA760A**31 CNPV*6024A** 58PH*110---20 58,500 47,500 13.0 16.0 1,700 1,425

3638194 24APA760A**31 CNPV*6024A** 58PH*135---20 58,500 47,000 12.9 16.0 1,670 1,280

3877977 24APA760A**31 CNPV*6024A** 58UVB100---20 57,500 47,000 12.3 15.5 1,660 1,395

3877976 24APA760A**31 CNPV*6024A** 58UVB120---20 58,000 47,000 12.6 16.0 1,680 1,360

3638247 24APA760A**31 CNPV*6024A** 58VLR120---20 58,500 47,000 12.7 16.0 1,735 1,350

3638246 24APA760A**31 CNPV*6024A** 58VMR120---20 57,500 47,000 12.2 15.5 1,740 1,355

4213276 24APA760A**31 CNPV*6024A** OVLAAB060154 58,000 47,000 11.5 15.2 2,110 1,675

3638175 24APA760A**31 CNPV*6024A**+TDR 58,500 46,500 12.6 15.0 1,750 1,400

3638209 24APA760A**31 CNPV*6024A**+UI 58CV(A,X)110---20 58,500 47,000 12.8 16.0 1,695 1,355

3638192 24APA760A**31 CNPV*6024A**+UI 58CV(A,X)135---22 58,500 47,000 13.0 16.0 1,685 1,355

3638193 24APA760A**31 CNPV*6024A**+UI 58CV(A,X)155---22 58,500 47,500 13.1 16.5 1,705 1,365

3638208 24APA760A**31 CNPV*6024A**+UI 58MV(B,C)100 ---20 57,500 47,000 12.3 15.5 1,660 1,395

3638191 24APA760A**31 CNPV*6024A**+UI 58MV(B,C)120 ---20 58,000 47,000 12.6 16.0 1,680 1,360

3638216 24APA760A**31 CNPV*6124A** 58ME(B,C)100---20 59,000 47,500 13.1 16.5 1,650 1,285

3638225 24APA760A**31 CNPV*6124A** 58ME(B,C)120---20 58,500 47,000 13.0 16.5 1,660 1,300

3638207 24APA760A**31 CNPV*6124A** 58PH*110---20 59,500 48,500 13.2 16.5 1,710 1,435

See notes on page 21

24APA7

Other manuals for 24APA7 Performance

Table of contents

Other Carrier Air Conditioner manuals

Carrier

Carrier W4A5S User manual

Carrier

Carrier 51QC/QG User manual

Carrier

Carrier 42CSR010 Series User manual

Carrier

Carrier 48ES---A Instruction Manual

Carrier

Carrier FV4C User manual

Carrier

Carrier 42QHM009ES User manual

Carrier

Carrier Infinity 48XL Instruction Manual

Carrier

Carrier 38VT 188CTST Series User manual

Carrier

Carrier 40MBF/38MAQ User manual

Carrier

Carrier PA3Z-B User manual

Carrier

Carrier bryant 315S User manual

Carrier

Carrier 42cvur018-703 User manual

Carrier

Carrier 38AUM Series Instruction manual

Carrier

Carrier 040-420 Manual

Carrier

Carrier AIRSTREAM 42BHE Operation manual

Carrier

Carrier 42TSV0131CP User manual

Carrier

Carrier PY4G B Series User manual

Carrier

Carrier 48PG03---16 User guide

Carrier

Carrier CAPRI-280 Operation manual

Carrier

Carrier 42VMC---N User manual

Carrier

Carrier 50ZP Series User manual

Carrier

Carrier 38VT 188CTST Series User manual

Carrier

Carrier GA5S User manual

Carrier

Carrier Infinity 24VNA6 User manual

Popular Air Conditioner manuals by other brands

LG LW1013ER specification

Honeywell

Honeywell CL30XC owner's manual

Bestron

Bestron AAC6000 instruction manual

Challenge

Challenge MPPHA-05CRN1-QB6 instruction manual

Panasonic

Panasonic CU-2S18NBU-1 Service manual

Haier

Haier 2HUM14HC03-R2 installation manual

Argo

Argo Relax Service manual

Honeywell

Honeywell CL20AE user manual

Technibel

Technibel MTA8FIA0R5I operating instructions

Daewoo

Daewoo DSB-122L owner's manual

Sanyo

Sanyo KS1822 Service manual

Fujitsu

Fujitsu ASY7FSACW Service manual

Fujitsu

Fujitsu AGYG09LVCB Service manual

INVT

INVT VCS Series user manual

Samsung

Samsung AS U Series User & installation manual

Toshiba

Toshiba RAS-M10N3KVP Series owner's manual

Panasonic

Panasonic CS-E15DKEW Service manual

Frigidaire

Frigidaire L0806995 installation instructions

Carrier 24APA7 Performance Operation manual

Popular Air Conditioner manuals by other brands
