Carrier 38QUS014DS2-2 User manual

SUPER INVERTER SERIES
MULTI TYPE
Service Manual 2018

CONTENTS
1. General information of Indoor Units..........................1
2. Features .......................................................................2
3. Dimensions................................................................12
4. Service Space (unit: mm)..........................................20
5. Wiring diagram ..........................................................23
6. Static Pressure (Duct)...............................................30
7. Operation temperature range...................................31
8. Electronic function......................................................32
9. General information of Outdoor Units.......................42
10. Features........................................................................43
11. Dimensions...................................................................44
12. Refrigeration Cycle Diagram.......................................45
13. Wiring diagram.............................................................47
14. Indoor units combination............................................51
15 Sound Levels.............................................................53
16 Installation Details.....................................................54
17 Electronic control function.......................................62
18 Troubleshooting........................................................67

※The specifications, designs, and information in this book are subject to change without notice for
product improvement.

1
1. General information of Indoor Units
Four-way cassette (compact)
Silm cassette
Console
15C
A5 Ducted
A6 Ducted
ODU
38QUS014DS2*
38QUS014DS2-2
38QUS018DS2*
38QUS018DS2-2 38QUS036DS4*
38QUS027DS3* 38QUS042DS5*
Four-way
cassette
(compact)
Super slim cassette Console 15C A5 Duct A6 Duct ODU
38QUS014DS2*
38QUS014DS2-2
38QUS018DS2*
38QUS018DS2-2
42QTD012D8S 42QZA018DS* 42QHC012D8S 42QSS012D8S 38QUS021DS3*
42QTD018D8S 42QHC018D8S 42QSS018DS* 38QUS027DS3*
42QHC024D8S 42QSS024DS* 38QUS028DS4*
38QUS036DS4*
38QUS042DS5*
*Model with gray Mark was phased.
Model
42QSS007D8S
42QSS009D8S
42QSS012DS*
42QHC007D8S
42QZA009DS*
42QZA012DS*
42QTD024DS*
42QTD007D8S
42QTD009D8S
42QHC009D8S

2
2. Features
2.1 Four-way cassette type(compact)
⑴New panel
360°surrounding air outlet design, affords comfortable feeling
⑵Compact design
The body size is 570×260×570mm, it’s just smaller than the ceiling board, so it’s very easy for
installation and will not damage the decoration. The panel size is 647×50×647mm.
The hooks are designed in the four corners of the body, which can save installation space.
⑶Electric control box built-in design
The E-box is simply and safely built inside the indoor unit. It’s convenient for installation and
maintenance. Can check the control part easily, you only need to open the air return grille.
⑷Fresh air intake function:
Fresh air fulfills air quality more healthy and comfortable.

3
⑸Air passage function
Reserves the space for air outlet from the side of indoor unit; It’s availed to connect air duct
from the two sides to the nearby small rooms.
Dimension:Φ75mm
Fresh
Air

4
2.2 A5 Duct
⑴Installation accessories: (Optional)
Front Board, Canvas Air Passage, Filter, Panel, for easy installation
⑵Easy Installation: Two air inlet styles (Bottom side or Rear side)
Air inlet from rear is standard for all capacity; air inlet from bottom is optional.
The size of air inlet frame from rear and bottom is same, it’s very easy to move the cover from bottom to
rear side, or from rear to the bottom, in order to matching the installation condition.
⑶Fresh air intake function
Install one duct from the reserved fresh-air intake to outdoor.
Continually inhale the fresh air to improve the quality of the indoor air, fulfills air quality more healthy and
comfortable.
⑷Easy maintenance
Clean the filter (Optional, standard product without filter)
It is easy to draw out the filter from the indoor unit for cleaning, even the filter is installed in rear side or
bottom side.
Front Board
Filter
Panel
Air intake from rear (Standard)
Air intake from bottom (Optional)

5
Replace the motor or centrifugal fan
Remove the ventilated panel firstly. Remove a half of blower housing and take out the motor with
centrifugal fan. Directly remove two bolts, and then replace the motor or centrifugal fan easily.
⑸Reserved remote on-off and central control ports
Reserved remote on-off ports and central control ports, can connect the cable of an on-off controller or a
central controller to realize remote on-off control function or group control function.
Motor
Blower Housing
Ventilated Panel

6
⑹Built-in drain pump (Optional):
Built-in drain pump can lift the water to 750mm upmost. It’s convenient to install drainage piping under
most space condition.
⑺Built-in display board
The standard indoor unit can be controlled by wired controller.
There is a display board with a receiver in the E-box. Move out the display, and fix it in other place, even
in the distance of 10m. The unit will realized remoter control.
The wired controller and the display board can display the error code or production code when the chips
detect some failure.
Remote on-off ports
Central control ports
750mm upmost

7
2.3 Console
(1) Consumes up to 30% less energy than non-inverter units
——DC inverter compressor
——indoor fan motor adopts DC motor
(2) Achieves set temperature more quickly
——air supplying from top and bottom or from top only
——air inlet from four directions
(3) Compact unit body, space saving
——this unit body is very thin and harmonious with room. It is beautiful, elegant and space saving.
——light weight and compact.
(4) Flexible installation.
——can be used for floor standing or lower wall applications
——as a floor standing floor model, it can be semi or fully recessed without loss of capacity.
(5) High efficiency filter
——built in Formaldehyde nemesis filter
——active-carbon and biological anti-virus filter is optional.
(6) Comfort
——flexible air blow: vertical auto swing and wide angle louvers ensure that warm air reaches the furthest
corners of the room and increase the air flow coverage
——Low noise operation, lowest to 23Db
——Low starting power and precise room temperature adjustment
(7) Powerful mode can be selected for rapid cooling or heating.
Display
Wired Controller (Standard)
Remote Controller (Optional)

8
(8) Easy cleaning grille and maintenance
(9) Indoor unit adopts DC motor, it has five level fan speed meet different requirements.
7.4 Super slim cassette
(1) Overview
Compact design, super slim body size, less space requiring in installation
Each louver can be separately controlled, more comfort air blowing is possible.
Auto-lifting panel design, more convenient to clean and maintain the filter. (optional)
(2) Fresh air intake function
Fresh air fulfills air quality more healthy and comfortable.
Ventilation motor is optional to increase the effect of fresh air.
(3) Optional ionizer generator
Ionizer generator is optional to get refreshing air to your room.
Ionizer can be switched on or off by remote controller.
When pressing the Clean Air button on the remote controller, Ionizer will work and the indicator light on
display board will shine.
I
Io on ni iz ze er r g ge en ne er ra at to or r
c
co on nn ne ec ct to or r
V
Ve en nt ti il la at ti io on n m mo ot to or r
c
co on nn ne ec ct to or r

9
(4) External air duct design
Reserve external air duct, more flexible for the air supply.
(5) Built-in draining pump
Due to the improvement of structure, more convenient to repair or replace the draining pump.
Built-in draining pump to make sure condensed water drain out reliably.
(6) Terminals for alarm lamp and long-distance on-off controller connection are standard
Reserve terminals for the connection of alarm lamp and long-distance on-off controller, more human
control.
Draining Pump

10
7.5 Ceiling-Floor
(1) New design, more modern and elegant appearance.
(2) Convenient installation
--The ceiling type can be easily installed into a corner of the ceiling even if the ceiling is very narrow
--It is especially useful when installation of an air conditioner in the center of the ceiling is impossible
due to a structure such as one lighting.
(3) Two direction auto swing (vertical & horizontal) and wide angle air flow,
--Air flow directional control minimizes the air resistance and produces wilder air flow to vertical
direction.
--The range of horizontal air discharge is widened which secures wider air flow distribution to provide
more comfortable air circulation no matter where the unit is set up
(4) New foam drain pan with plastic-spraying inner surface
Alarm lamp
Long-distance on-off controller

11
(5) Easy operation.
(6) Remote control and optional wired control method.

12
3. Dimensions
3.1 Four-way cassette type (compact):
P a ne l
E -pa rts b ox
G as side
Liq uid side
4-install h a ng e r
B o dy
W iring connection port
D rain pip e
32
Fresh air intake
65
570
545
570 523
260
647
647
50
150 D is trib ution duct
170
2-
2-
4 -S c re w h ole
(for install panel)
D rain hole
( for S e rvic e )
75
156
125
68
40
44

13
3.2 A5 Duct
A
C
B
D
J
I
K
A ir filter ( o p tional )
air in let from rear side
air inlet fro m bo tto m sid e
FE
G
H
E le ctric co ntro l b ox
A ir filter ( o p tional )
L
4-install han g e r
G as side
Liq u id side
M
W1
W2
H1
H2
25 D rain connectin g pip e
( fo r pum p )
Test m o u th & T est co ver
Fresh a ir in ta ke
25 D rain pip e
25 D rain pip e
Note: standard product without filter Unit: mm
Model
Outline dimension(mm)
Air outlet opening size
Air return opening size
Size of install
hanger
Size of refrigerant pipe
A
B
C
D
E
F
G
H
I
J
K
L
M
H1
H2
W1
W2
42QSS012DS*
700
210
635
570
65
493
35
119
595
200
80
740
350
120
143
95
150

14
3.3 Console
16 D rain pipe
195
H ang ing arm
700
600
210

15
3.4 Super-Slim Cassette Type
840
840
950
950
C
Te st m outh & Te st cover
D rain h ole
32
W iring co nne ctio n port
680
780
780
680
136
126
91
196
132
A
A
B
AA
B
A
A
B
A
B
S e rv ic e h ole fo r
drainin g pu m p
Fresh a ir intake
75
55
80
80
4-in stall hang er
G as side
Liquid side
E -pa rts b ox
135
90
Panel
B o dy
92929292
DD
92 92
D
D
DD
92
9292
92
92 92 92 92
D
D
Unit: mm
Model
A
B
C
D
42QTD024DS*
160
95
245
60

16
3.5 Ceiling &Floor Type
A
B
220
222
C
120
2- 40
120
140
2- 33
W irin g c o n n e ctio n p o rt
204
94
F re sh a ir in ta k e
D r ain d is ch a rg e p o rt
R e frig e r an t p ip e h o le
H a n g in g a rm
D
Capacity (KBtu/h)
A
B
C
D
18/24
1068
675
235
983

17
3.6 Ducted
A5
