Carrier 42NL series Manual

1
INSTALLATION, OPERATION AND
MAINTENANCE INSTRUCTIONS
Hydronic Ducted Fan Coil Units
42NL & 42NH
Original instructions
DUCTED FAN COIL UNITS
Installation instructions EN
VENTILO-CONVECTEURS GAINABLES
Manuel d’installation FR
VENTILATOR-KONVEKTOREN MIT KANALANSCHLUSS
Installationsanweisungen DE
UNITÀ BATTERIA VENTILATORE CANALIZZATE
Manuale d’installazione IT
UNIDAD DE FANCOIL CON CONDUCTOS
Manual de instalación ES
VENTILATORCONVECTOR VOOR KANAALAANSLUITING
Montagehandleiding NL
UNIDADES DA SERPENTINA DE VENTILADOR COM
CONDUTAS
Instruções de instalação
PT
КАНАЛЬНЫЕ ВЕНТИЛЯТОРНЫЕ ДОВОДЧИКИ
Инструкция по монтажу RU
KLIMAKONWEKTORY WENTYLATOROWE KANAŁOWE
Instrukcja instalacji PL

2
CONTENTS
1 - PRECAUTIONS .......................................................... 17
1.1 - Operating limits ...........................................................17
1.2 - Clearances required.....................................................17
1.3 - Receiving a shipment - installation methods............17
1.4 - Supply voltage..............................................................18
2 - SAFETY CONSIDERATIONS ................................. 18
2.1 - General 18
2.2 - Protection against electrocution................................18
2.3 - General installation conditions..................................18
2.4 - Caution for the control of the unit............................19
2.5 - Conformity...................................................................19
3 - INSTALLATION OF THE UNIT ............................. 19
3.1 - Installing the unit in the false ceiling ........................19
3.2 - Installation procedure.................................................19
3.3 - Removal procedure.....................................................20
4 - COMPONENTS AND MAINTENANCE............... 20
4.1 - Fan motor assembly ....................................................20
4.2 - Drain pan removal ......................................................21
4.3 - Water coil......................................................................21
4.4 - Duct connection spigots .............................................22
4.5 - Duct connection rectangular anges.........................22
4.6 - Optional lter and lter access..................................22
4.7 - Fresh air controller......................................................22
4.8 - Optional water ow control valves............................22
4.9 - Flexible pipe option ....................................................24
4.10 - Optional electric heater............................................24
4.11 - Optional water sensor...............................................24
4.12 - Optional condensate pump......................................24
ENGLISH
INHALT
1 - BESTIMMUNGEN...................................................... 33
1.1 - Betriebs-Grenzwerte...................................................33
1.2 - Erforderliche Abstände ..............................................33
1.3 - Annahme der Sendung - Installationsmethoden .....33
1.4 - Versorgungsspannung .................................................34
2 - SICHERHEITSMASSNAHMEN.............................. 34
2.1 - Allgemeines..................................................................34
2.2 - Schutz gegen elektrische Schläge ..............................34
2.3 - Allgemeine Installationsbedingungen ......................34
2.4 - Warnung für die Regelung der Geräte......................35
2.5 - Konformität..................................................................35
3 - INSTALLATION DES GERÄTS.............................. 35
3.1 - Installation des Geräts in der Zwischendecke.........35
3.2 - Installationsvorgang....................................................35
3.3 - Ausbau 36
4 - BAUTEILE UND WARTUNG ................................. 36
4.1 - Ventilator-Baugruppe .................................................36
4.2 - Ausbau der Kondensatwanne ...................................37
4.3 - Wasserregister .............................................................37
4.4 - Kanalanschlussstutzen................................................38
4.5 - Rechteck-Kanalanschlussansche.............................38
4.6 - Optionaler Filter und Zugang zum Filter.................38
4.7 - Frischluftregler.............................................................38
4.8 - Optionale Wasserregelventile....................................39
4.9 - Optionale Anschlussschläuche ..................................40
4.10 - Optionale Elektroheizung........................................40
4.11 - Optionaler Wassertemperatursensor ......................41
4.12 - Optionale Kondensatpumpe....................................41
DEUTSCH
TABLE DES MATIÈRES
1 - CONSIGNES................................................................. 25
1.1 - Limites de fonctionnement.........................................25
1.2 - Espaces libres nécessaires...........................................25
1.3 - Réception et consignes d’installation........................25
1.4 - Tension d’alimentation................................................26
2 - CONSIGNES DE SÉCURITÉ................................... 26
2.1 - Généralités...................................................................26
2.2 - Protection contre les électrocutions..........................26
2.3 - Conditions générales d’installation...........................26
2.4 - Avertissement relatif à la régulation de l’unité........27
2.5 - Conformité...................................................................27
3 - INSTALLATION DE L’UNITÉ ................................ 27
3.1 - Installation de l’unité dans un faux plafond.............27
3.2 - Procédure d’installation..............................................27
3.3 - Procédure de démontage............................................28
4 - COMPOSANTS ET MAINTENANCE.................... 28
4.1 - Motoventilateurs .........................................................28
4.2 - Retrait du bac d’évacuation ......................................29
4.3 - Batterie à eau...............................................................29
4.4 - Viroles de raccordement aux gaines..........................30
4.5 - Brides rectangulaires de raccordement aux gaines .30
4.6 - Option ltre et accès...................................................30
4.7 - Régulateur d’air neuf..................................................30
4.8 - Option vannes de régulation du débit d’eau............30
4.9 - Option tuyau exible ..................................................32
4.10 - Option batterie électrique........................................32
4.11 - Option sonde d’eau...................................................32
4.12 - Option pompe à condensat ......................................32
FRANCAIS
CONTENUTO
1 - PRECAUZIONI........................................................... 42
1.1 - Limiti di funzionamento .............................................42
1.2 - Spazi necessari .............................................................42
1.3 - Ricevimento delle unità e modalità d’installazione 43
1.4 - Tensione di alimentazione ..........................................43
2 - CONSIDERAZIONI SULLA SICUREZZA.......... 43
2.1 - Generalità.....................................................................43
2.2 - Precauzioni contro le folgorazioni.............................43
2.3 - Raccomandazioni generali per l’installazione .........43
2.4 - Precauzione per il controllo delle unità....................44
2.5 - Conformità...................................................................44
3 - INSTALLAZIONE DELLA UNITÀ........................ 44
3.1 - Installazione dell’unità in un contro-softto............44
3.2 - Procedura di installazione ..........................................44
3.3 - Procedura di smontaggio............................................45
4 - COMPONENTI E MANUTENZIONE................... 45
4.1 - Assieme motoventilante.............................................45
4.2 - Rimozione vasca di drenaggio ...................................46
4.3 - Batteria ad acqua ........................................................47
4.4 - Rubinetti connessioni condotti..................................47
4.5 - Flange rettangolari connessione condotto ...............47
4.6 - Filtro opzionale e accesso al ltro .............................47
4.7 - Controllore dell’aria di rinnovo.................................48
4.8 - Valvole di controllo di portata dell’acqua opzionali48
4.9 - Opzione tubo essibile ...............................................49
4.10 -Riscaldatore elettrico opzionale...............................49
4.11 - Sensore acqua opzionale ..........................................50
4.12 - Pompa del condensato opzionale ............................50
ITALIANO

3
ÍNDICE
1 - PRECAUCIONES ....................................................... 51
1.1 - Límites de funcionamiento.........................................51
1.2 - Espacio necesario para el mantenimiento................51
1.3 - Recepción de un envío; métodos de instalación ......51
1.4 - Tensión de alimentación..............................................52
2 - CONSIDERACIONES DE SEGURIDAD ............. 52
2.1 - Generalidades..............................................................52
2.2 - Precauciones contra la electrocución........................52
2.3 - Recomendaciones generales para la instalación......52
2.4 - Precaución con el control de la unidad.....................53
2.5 - Conformidad................................................................53
3 - INSTALACIÓN DE LA UNIDAD........................... 53
3.1 - Instalación de la unidad en falso techo.....................53
3.2 - Procédure d’installation..............................................53
3.3 -Procedimiento de desmontaje ....................................54
4 - COMPONENTES Y MANTENIMIENTO.............. 54
4.1 - Conjunto motor/ventilador ........................................54
4.2 - Extracción de la bandeja de drenaje ........................55
4.3 - Batería de agua............................................................55
4.4 - Espitas de conexión de los conductos.......................56
4.5 - Bridas rectangulares de conexión de los conductos56
4.6 - Filtro (opción) y acceso al ltro.................................56
4.7 - Controlador de aire fresco..........................................56
4.8 - Válvulas de control del caudal de agua (opción).....56
4.9 - Tubo exible (opción).................................................58
4.10 - Calentador eléctrico (opción)..................................58
4.11 - Sensor de agua (opción)...........................................58
4.12 - Bomba de condensado (opción)..............................58
ESPAÑOL
CONTEÚDO
1 - PRECAUÇÕES............................................................ 67
1.1 - Limites de funcionamento..........................................67
1.2 - Distâncias necessárias .................................................67
1.3 - Recepção de uma remessa - métodos de instalação67
1.4 - Tensão de alimentação ................................................68
2 - CONSIDERAÇÕES RELATIVAS À SEGURANÇA .. 68
2.1 - Geral ..... .......................................................................68
2.2 - Proteção contra electrocussão ...................................68
2.3 - Condições gerais da instalação ..................................68
2.4 - Cuidado a ter para o controlo da unidade................69
2.5 - Conformidade..............................................................69
3 - INSTALAÇÃO DA UNIDADE................................. 69
3.1 - Instalação da unidade no teto falso...........................69
3.2 - Procedimento de instalação .......................................69
3.3 - Procedimento de remoção..........................................70
4 - COMPONENTES E MANUTENÇÃO.................... 70
4.1 - Módulo do motor do ventilador................................70
4.2 - Remoção do tabuleiro de drenagem ........................71
4.3 - Serpentina de água .....................................................71
4.4 - Torneiras de conexão à conduta ................................72
4.5 - Flanges retangulares de conexão à conduta.............72
4.6 - Filtro opcional e acesso ao ltro................................72
4.7 - Controlador de ar puro...............................................72
4.8 - Válvulas de controlo do uxo de água opcionais.....72
4.9 - Opção tubo exível .....................................................74
4.10 - Aquecedor elétrico opcional....................................74
4.11 - Sensor de água opcional...........................................74
4.12 - Bomba de condensado opcional..............................74
PORTUGUÊS
INHOUD
1 - VOORZORGSMAATREGELEN ............................ 59
1.1 - Bedrijfslimieten ...........................................................59
1.2 - Benodigde vrije ruimte ...............................................59
1.3 - Ontvangen van een zending - montagemethoden ...59
1.4 - Voedingsspanning ........................................................60
2 - VEILIGHEID ............................................................... 60
2.1 - Algemeen .....................................................................60
2.2 - Voorkomen van elektrische schokken ......................60
2.3 - Algemene aanbevelingen voor de montage.............60
2.4 - Waarschuwing voor de regeling van de unit.............61
2.5 - Conformiteit.................................................................61
3 - MONTAGE VAN DE UNIT ...................................... 61
3.1 - Montage van de unit boven het verlaagd plafond...61
3.2 - Montageprocedure......................................................61
3.3 - Demontage...................................................................62
4 - COMPONENTEN EN ONDERHOUD .................. 62
4.1 - Ventilatormotor ...........................................................62
4.2 - Opvangbak verwijderen ............................................63
4.3 - Waterbatterij ...............................................................63
4.4 - Kanaalaansluiting openingen.....................................64
4.5 - Kanaalaansluiting rechthoekige enzen...................64
4.6 - Optioneel lter en toegang tot het lter...................64
4.7 - Verse lucht regelaar.....................................................64
4.8 - Waterregelkleppen (optie) .........................................64
4.9 - Flexibele leiding (optie) .............................................66
4.10 - Elektrisch verwarmingselement (optie) .................66
4.11 - Water sensor (optie)..................................................66
4.12 - Condensaatpomp (optie)..........................................66
NEDERLANDS
СОДЕРЖАНИЕ
1 - ПРЕДУПРЕЖДЕНИЯ.............................................. 75
1.1 - Условия эксплуатации..............................................75
1.2 - Пространство для технического обслуживания.75
1.3 - Приемка и хранение..................................................76
1.4 - Электропитание.........................................................76
2 - ПРАВИЛА БЕЗОПАСНОСТИ .............................. 76
2.1 - Общие положения.....................................................76
2.2 - Защита от поражения электрическим током .....76
2.3 - Общие условия монтажа .........................................76
2.4 - Подключение контроллера ....................................77
2.5 - Соответствие нормативным документам ............77
3 - МОНТАЖ БЛОКА .................................................... 77
3.1 - Монтаж блока в подвесном потолке.....................77
3.2 - Порядок монтажа......................................................77
3.3 - Порядок демонтажа..................................................78
4 - КОМПОНЕНТЫ БЛОКА И ТЕХНИЧЕСКОЕ ОБСЛУЖИВАНИЕ . 78
4.1 - Узел вентилятора с двигателем..............................78
4.2 - Снятие поддона для сбора конденсата .....................79
4.3 - Водяной теплообменник .........................................80
4.4 - Патрубки соединения с воздуховодом..................80
4.5 - Прямоугольное фланцевое соединение с воздуховодом ..80
4.6 - Дополнительный фильтр и доступ к фильтру....80
4.7 - Регулятор расхода наружного воздуха .................80
4.8 - Дополнительные клапаны регулирования расхода воды ..81
4.9 - Дополнительные шланги.........................................82
4.10 - Дополнительный электрический нагреватель .82
4.11 - Дополнительный датчик температуры воды....83
4.12 - Дополнительный насос отвода конденсата .......83
РУССКИЙ

4
SPIS TREŚCI
1 - ŚRODKI OSTROŻNOŚCI........................................... 84
1.1 - Robocze wartości graniczne ..........................................84
1.2 - Wymagane prześwity.....................................................84
1.3 - Odbiór przesyłki - metody montażu ..............................84
1.4 - Napięcie zasilania ..........................................................85
2 - UWAGI DOTYCZĄCE BEZPIECZEŃSTWA........... 85
2.1 - Informacje ogólne..........................................................85
2.2 - Zabezpieczenie przed porażeniem prądem....................85
2.3 - Ogólne warunki instalacji..............................................85
2.4 - Ostrzeżenie dotyczące systemu sterującego jednostki ..86
2.5 - Zgodność .......................................................................86
3 - INSTALACJA JEDNOSTKI........................................ 86
3.1 - Instalacja jednostki w podwieszanym sucie...........................86
3.2 - Procedura instalacji........................................................86
3.3 - Procedura demontażu ....................................................87
4 - PODZESPOŁY I KONSERWACJA............................ 87
4.1 - Zespół wentylatora z silnikiem......................................87
4.2. - Demontaż tacki na skropliny ......................................88
4.3 - Wężownica wodna.........................................................88
4.4 - Króćce przyłączne do podłączenia kanałów..................89
4.5 - Kołnierze prostokątne do podłączenia kanałów ............89
4.6 - Filtr opcjonalny i dostęp do ltra ..................................89
4.7 - Sterownik świeżego powietrza ......................................89
4.8 - Opcjonalne zawory sterujące natężeniem przepływu wody.. 89
4.9 - Opcja przewodu giętkiego.............................................91
4.10 - Opcjonalna nagrzewnica elektryczna ..........................91
4.11 - Opcjonalny czujnik wody ............................................91
4.12 - Opcjonalna pompa skroplin.........................................91
POLSKA

5
1
AB C
42NH/L - size 2 744 300 50
42NH/L - size 3 914 300 50
42NH/L - size 4 1114 300 50
42NH/L - size 5 1314 300 50
42NH/L - size 6 1314 345 50
42NH/L - size 7 1614 345 50
2
AB
42NH/L - size 2744 300
42NH/L - size 3914 300
42NH/L - size 41114 300
42NH/L - size 51314 300
42NH/L - size 61314 345
42NH/L - size 71614 345

6
3
AB
42NH/L - size 2744 300
42NH/L - size 3914 300
42NH/L - size 41114 300
42NH/L - size 51314 300
42NH/L - size 61314 345
42NH/L - size 71614 345
8
0.5 %
7
4
5
6

7
9a
10
10b
10a
13
13a 13a
9b
11
11a
11a
12
12b
12a

8
5
1
2
1
21
2
3
4
2w-v
9
2
6
5
7
8
6
4w-v
5
2w-v + B
5
10
2
6
14

9
16a
16b
16d
16e
16c
15a
15b
15c
15d
15e
15
17a
17b
17c
17
16
16a16b16c16 d

10
1
3
5
2
4
5a
5b
18
4a
4b

11
19
19a

12
Figure titles and legends:
1 Clearance in mm without rectangular ange inlet
2 Clearance in mm with rectangular ange inlet
3 Clearance in mm with small or large plenum
4 Electrical danger pictogram
5 Caution hand hazard pictogram
6 General danger pictogram
7 Lifting unit for installation in a false ceiling
8/9 Levelling the unit
10 Condensate drain pipe
10a 20 mm/m fall in horizontal pipe
run
10b 50 mm siphon
11 Several units connected to one condensate collector
11a 20 mm/m fall
12 Fan assembly removal
12a Removing fan access panel
12b Position of torx screws
13 Electric heater removal
13a Location of screw
14 Coil inlet/outlet positions, all sizes
1 Cooling water outlet (4 and 2-pipe coil)
2 Cooling water inlet (4 and 2-pipe coil)
3 Heating water outlet (4-pipe coil)
4 Heating water inlet (4-pipe coil)
5 Air vent
6 Water drain
7 Water outlet of 4w-v
8 Water inlet of 4w-v
9 Water outlet of 2w-v
10 Water outlet of 2w-v + B
2w-v Two-way valve
2w-v+B Two-way valve and balancing function
4w-v Four-way valve (= Three-way valve with
integral by-pass)
Connections for two-way valve with balancing function :
- size 2 and 3 : 3/4’’ diameter
- size 4 and 5 : 1’’ diameter
Connections for other valves and coils:
- size 2, 3, 4 and 5 : 1/2’’ diameter
- size 6 and 7 : 3/4’’ diameter
15 Meaning of wires - Proportional valve actuator (not applicable for
valves with balancing functions)
15a Black wire (230 V valve
actuator), actuator rod rising
15b Green wire (24 V valve
actuator), actuator rod rising
15c Brown wire, Actuator rod
lowering
15d Actuator rod in high position
15e Actuator rod in low position
16 Waterow adjustment of optional 2-way valve with balancing
function
16a Control knob removal
16b Knurled nut untightening
16c Waterow adjustment (white
knob)
16d Knurled nut tightening in initial
position
17 Optional airow controller
17a Air Damper
17b Fresh airow setting (in m3/h)
17c Airow adjustment screw
18 Condensate pump assembly
1 Fit the pump support on the edges of the
drain pan
2 Connect the rubber pipe on both sides
3 Check the sealing
4 (Recommended) Lower the position of the
pump
4a Highest position
4b Lowest position
5 Plug
5a the electrical wire
5b the outlet pipe (6mm inner diameter)
19 Coil protective caps removal
19a Protective caps (factory tted)
ENGLISH

1 Espace libre en mm sans bride rectangulaire de reprise
2 Espace libre en mm avec bride rectangulaire de reprise
3 Espace libre en mm avec petit ou grand plénum
4 Pictogramme : risque d’électrocution
5 Pictogramme : risque pour les mains
6 Pictogramme : danger
7 Appareil de levage pour installation dans un faux plafond
8/9 Mise à niveau de l’unité
10 Tuyau exible d’évacuation des condensats
10a Inclinaison de 20 mm/m pour le tuyau
horizontal
10b Siphon de 50 mm
11 Raccordement de plusieurs unités à un collecteur de condensats
11a Inclinaison de 20 mm/m
12 Démontage du motoventilateur
12a Retrait du panneau d’accès au ventilateur
12b Emplacement des vis Torx
13 Retrait de la batterie électrique
13a Emplacement de la vis
14 Emplacement de l’entrée et de la sortie de la batterie (toutes dimensions)
1 Sortie d’eau froide (batterie à 4 et 2 tubes)
2 Sortie d’eau froide (batterie à 4 et 2 tubes)
3 Sortie d’eau chaude (batterie à 4 tubes)
4 Entrée d’eau chaude (batterie à 4 tubes)
5 Purgeur d’air
6 Point de vidange
7 Sortie d’eau de 4w-v
8 Entrée d’eau de 4w-v
9 Sortie d’eau de 2w-v
10 Sortie d’eau de 2w-v + B
2w-v Vanne deux voies
2w-v + B Vanne 2 voies et équilibrage
4w-v Vanne 4 voies (= vanne 3 voies avec by-pass intégré)
Raccordements pour vanne 2 voies avec équilibrage :
- Tailles 2 et 3 : diamètre de 3/4»
- Tailles 4 et 5 : diamètre de 1»
Raccordements pour les autres vannes et les batteries :
- Tailles 2, 3, 4 et 5 : diamètre de 1/2»
- Tailles 6 et 7 : diamètre de 3/4»
15 Signication des câbles : servomoteur proportionnel (sauf pour les
vannes équipées d’une fonction d’équilibrage)
15a Câble noir (servomoteur de 230 V),
élévation de la tige du servomoteur
15b Câble vert (servomoteur de 24 V),
élévation de la tige du servomoteur
15c Câble marron, abaissement de la tige du
servomoteur
15d Tige du servomoteur en position haute
15e Tige du servomoteur en position haute
16 Régulation du débit d’eau de la vanne 2 voies en option avec
fonction d’équilibrage
16a Retrait de la molette de régulation
16b Desserrage de l’écrou moleté
16c Régulation du débit d’eau (molette
blanche)
16d Serrage de l’écrou moleté en position de
départ
17 Régulateur du débit d’air en option
17a Registre d’air
17b Réglage du débit d’air neuf (en m3/h)
17c Vis de régulation du débit d’air
18 Ensemble pompe de relevage de condensat
1 Installer le support de la pompe sur les bords du bac
d’évacuation
2 Brancher le tuyau de caoutchouc des deux côtés
3 Vérier l’étanchéité
4 (Recommandé) Abaisser la position de la pompe
4a Position la plus haute
4b Position la plus basse
5 Brancher
5a le l électrique
5b le tuyau de sortie (diamètre interne 6 mm)
19 Retrait des bouchons protecteurs de la batterie
19a Bouchons protecteurs (installés en usine)
FRANCAIS

13
Abbildungstitel und Legenden:
1 Freiraum in mm, ohne rechteckigen Einlassansch
2 Freiraum in mm, mit rechteckigem Einlassansch
3 Abstand in mm, mit kleinem oder großem Plenum
4 Piktogramm für elektrische Gefahren
5 Piktogramm „Gefahr für die Hände“
6 Piktogramm für allgemeine Gefahren
7 Hebegerät für die Montage in einer Zwischendecke
8/9 Horizontale Ausrichtung des Gerätes
10 Kondensatablaueitung
10a 20 mm/m Gefälle in horizontalen
Leitungssträngen
10b Siphon 50 mm
11 Mehrere Geräte an eine Kondensatwanne angeschlossen
11a 20 mm/m Gefälle
12 Ausbau der Ventilatorbaugruppe
12a Ausbau des Zugangspaneels
12b Position der Torx-Schrauben
13 Ausbau der Elektroheizung
13a Position der Schraube
14 Position der Ein- und Austritte am Register, alle Baugrößen
1 Kühlwasseraustritt (4- und 2-Leiterregister)
2 Kühlwassereintritt (4- und 2-Leiterregister)
3 Heizwasseraustritt (4-Leiterregister)
4 Heizwassereintritt (4-Leiterregister)
5 Entlüftung
6 Wasserablauf
7 Wasseraustritt des 4w-v
8 Wassereintritt des 4w-v
9 Wasseraustritt des 2w-v
10 Wasseraustritt des 2w-v + B
2w-v Zwei-Wege-Ventil
2w-v + B Zwei-Wege-Ventil mit Ausgleichsfunktion
4w-v Vier-Wege-Ventil (= Dreiwegeventil mit integriertem
Bypass)
Anschlüsse für Zwei-Wege-Ventile mit Ausgleichsfunktion:
- Baugröße 2 und 3: Durchmesser 3/4’’
- Baugröße 4 und 5: Durchmesser 1’’
Anschlüsse für andere Ventile und Register:
- Baugröße 2, 3, 4 und 5: Durchmesser 1/2’’
- Baugröße 6 und 7: Durchmesser 3/4’’
15 Bedeutung der Drahtfarbe - Stellantrieb des stufenlosen Ventils
(nicht bei Ventilen mit Ausgleichsfunktion)
15a Schwarzer Draht (230 V Ventilstellantrieb),
Antriebsstange fährt aus
15b Grüner Draht (24 V Ventilstellantrieb),
Antriebsstange fährt aus
15c Braunes Kabel, Antriebsstange fährt ein
15d Antriebsstange in ausgefahrener Stellung,
15e Antriebsstange in eingefahrener Stellung
16 Optionales 2-Wege-Ventil zur Einstellung der
Wasserdurchussmenge mit Ausgleichsfunktion
16a Drehknopf abnehmen
16b Rändelmutter lösen
16c Durchuss einstellen (weißer Knopf)
16d Rändelmutter in der ursprünglichen
Stellung festziehen
17 Optionaler Regler für den Luftvolumenstrom
17a Luftklappe
17b Einstellung der Frischluftmenge (in m3/h)
17c Einstellschraube für den Luftvolumenstrom
18 Kondensatpumpen-Baugruppe
1 Montieren Sie die Pumpenhalterung am Rand der
Kondensatwanne.
2 Schließen Sie den Gummischlauch an beiden Enden an.
3 Überprüfen Sie die Abdichtung.
4 (Empfehlung) Senken Sie die Pumpenstellung etwas ab.
4a Höchste Position
4b Niedrigste Position
5 Anschluss
5a des Stromkabels
5b der Austrittsleitung (6 mm
Innendurchmesser)
19 Entfernung der Schutzkappen des Registers
19a Schutzkappen (werkseitig angebracht)
DEUTSCH

1 Spazio libero in mm senza ingresso angia rettangolare
2 Spazio libero in mm con ingresso angia rettangolare
3 Spazio libero in mm con plenum piccolo o grande
4 Pittogramma di pericolo elettrico
5 Pittogramma di avvertenza di pericolo per le mani
6 Pittogramma di pericolo generale
7 Unità di sollevamento per installazione in un controsotto
8/9 Livellamento dell’unità
10 Tubo di scarico del condensato
10a Pendenza 20 mm/m in esecuzione tubo
orizzontale
10b Sifone 50 mm
11 Varie unità collegate a un collettore del condensato
11a Pendenza 20 mm/m
12 Rimozione ventilatore e boccaglio
12a Rimozione del pannello di accesso ventilatore
12b Posizione delle viti Torx
13 Rimozione riscaldatore elettrico
13a Posizione della vite
14 Posizioni ingresso/uscita batteria, tutte le dimensioni
1 Uscita dell’acqua di rareddamento (batteria a 2 e 4 tubi)
2 Ingresso dell’acqua di rareddamento (batteria a 2 e 4 tubi)
3 Uscita acqua calda (batteria a 4 tubi)
4 Ingresso acqua calda (batteria a 4 tubi)
5 Sato dell’aria
6 Scarico acqua
7 Uscita acqua de 4w-v
8 Ingresso acqua de 4w-v
9 Uscita acqua de 2w-v
10 Uscita acqua de 2w-v + B
2w-v Valvola bidirezionale
2w-v + B Valvola bidirezionale e funzione di bilanciamento
4w-v Valvola quadridirezionale (= Valvola tridirezionale con
bypass integrale)
Connessioni per valvola bidirezionale con funzione di bilanciamento:
- dimensione 2 e 3: diametro 3/4’’
- dimensione 4 e 5: diametro 1’’
Connessioni per altre valvole e batterie:
- dimensione 2, 3, 4 e 5: diametro 1/2’’
- dimensione 6 e 7: diametro 3/4’’
15 Signicato dei cavi - Attuatore valvola proporzionale (non
applicabile per valvole con funzioni di bilanciamento)
15a Cavo nero (attuatore valvola 230 V),
sollevamento asta attuatore
15b Cavo verde (attuatore valvola 24 V),
sollevamento asta attuatore
15c Cavo marrone, abbassamento asta
attuatore
15d Asta attuatore in posizione alta
15e Asta attuatore in posizione bassa
16 Regolazione portata acqua della valvola bidirezionale opzionale
con funzione di bilanciamento
16a Rimozione manopola di controllo
16b Allentamento dado zigrinato
16c Regolazione portata acqua (manopola
bianca)
16d Serraggio dado zigrinato in posizione
iniziale
17 Controllore portata aria opzionale
17a Ammortizzatore ad aria
17b Impostazione portata aria di rinnovo (in m
3
/h)
17c Vite di regolazione portata aria
18 Montaggio pompa del condensato
1 Inserire il supporto pompa sui bordi della vasca di
drenaggio
2 Collegare il tubo di gomma su entrambi i lati
3 Controllare la tenuta
4 (Consigliato) Abbassare la posizione della pompa
4a Posizione più alta
4b Posizione più bassa
5 Inserire
5a il cavo elettrico
5b il tubo di uscita (diametro interno di 6mm)
19 Rimozione cappucci protettivi batteria
19a Cappucci protettivi (montati in fabbrica)
ITALIANO

14

1 Distancia en mm sin admisión con brida rectangular
2 Distancia en mm con admisión con brida rectangular
3 Distancia en mm con plénum pequeño o grande
4 Pictograma de peligro de descarga eléctrica
5 Pictograma de atención por peligro para las manos
6 Pictograma de peligro general
7 Unidad de elevación para instalación en falso techo
8/9 Nivelación de la unidad
10 Tubo de drenaje de condensado
10a 20 mm/m de pendiente en el tendido de
tubo horizontal
10b Sifón de 50 mm
11 Varias unidades conectadas a un colector de condensado
11a Pendiente de 20 mm/m
12 Desmontaje del conjunto de ventilador
12a Desmontaje del panel de acceso al ventilador
12b Posición de los tornillos torx
13 Desmontaje del calentador eléctrico
13a Ubicación del tornillo
14 Posiciones de entrada/salida de batería, todos los tamaños
1 Salida de agua de refrigeración (batería de 4 y 2 tubos)
2 Entrada de agua de refrigeración (batería de 4 y 2 tubos)
3 Salida de agua de calefacción (batería de 4 tubos)
4 Entrada del agua de calefacción (batería de 4 tubos)
5 Purga de aire
6 Drenaje de agua
7 Salida de agua de 4w-v
8 Entrada de agua de 4w-v
9 Salida de agua de 2w-v
10 Salida de agua de 2w-v + B
2w-v Válvula de dos vías
2w-v + B Válvula de dos vías y función de equilibrado
4w-v Válvula de cuatro vías (= válvula de tres vías con
derivación integrada)
Conexiones para válvula de dos vías con función de equilibrado:
- tamaños 2 y 3: 3/4’’ de diámetro
- tamaños 4 y 5: 1’’ de diámetro
Conexiones para otras válvulas y baterías:
- tamaños 2, 3, 4 y 5: 1/2’’ de diámetro
- tamaños 6 y 7: 3/4’’ de diámetro
15 Signicado de los cables. Actuador de la válvula proporcional (no
aplicable para válvulas con funciones de equilibrado)
15a Cablenegro(actuadorde válvulade230V),
elevación de la varilla del actuador
15b Cableverde(actuador deválvulade 24V),
elevación de la varilla del actuador
15c Cable marrón, descenso de la varilla del
actuador
15d Varilla del actuador en posición alta
15e Varilla del actuador en posición baja
16 Ajuste del caudal de agua en la válvula opcional de 2 vías con
función de equilibrado
16a Desmontaje del botón de control
16b Aojamiento de la tuerca moleteada
16c Ajuste del caudal de agua (botón blanco)
16d Aprietedelatuercamoleteada enposición
inicial
17 Controlador opcional de caudal de aire
17a Compuerta de aire
17b Ajuste de caudal de aire fresco (en m3/h)
17c T ornillo de ajuste del caudal de aire
18 Conjunto de bomba de condensado
1 Encaje el soporte de la bomba en los bordes de la
bandeja de drenaje
2 Conecte el tubo de goma por los dos lados
3 Compruebe la estanqueidad
4 (Recomendado) Baje la posición de la bomba
4a Posición más alta
4b Posición más baja
5 Enchufe
5a el cable eléctrico
5b el tubo de salida (diámetro interior 6 mm)
19 Extracción de los tapones de protección de la batería de aire
19a Tapones de protección (instalados de
fábrica)
ESPAÑOL
Titels en verklaringen van afbeeldingen:
1 Vrije ruimte in mm zonder rechthoekige intrede aansluitens
2 Vrije ruimte in mm met rechthoekige intrede aansluitens
3 Vrije ruimte in mm met klein of groot plenum
4 Elektrisch gevaar pictogram
5 Let op handgevaar pictogram
6 Algemeen gevaar pictogram
7 De unit optillen voor montage in een verlaagd plafond
8/9 De unit op afschot plaatsen
10 Condensaatafvoerleiding
10a 20 mm/m afschot in horizontale leiding
10b 50 mm sifon
11 Meerdere units aangesloten op condensaatverzamelleiding
11a 20 mm/m afschot
12 Uitbouwen van de ventilator
12a Verwijderen van het ventilatortoegangspaneel
12b Plaats van torx-schroeven
13 Uitbouwen van het elektrische verwarmingselement
13a Plaats van schroef
14 Plaatsen van intrede/uittrede van de batterij, alle types
1 Koud water uittrede (4- en 2-pijps batterij)
2 Koud water intrede (4- en 2-pijps batterij)
3 Warm water uittrede (4-pijps batterij)
4 Warm water intrede (4-pijps batterij)
5 Ontluchter
6 Water aftapkraan
7 Water uittrede van 4w-v
8 Water intrede van 4w-v
9 Water uittrede van 2w-v
10 Water uittrede van 2w-v + B
2w-v Tweewegklep
2w-v + B Tweewegklep en balansfunctie
4w-v Vierwegklep (= driewegklep met integrale bypass)
Aansluitingen voor tweewegklep met balansfunctie:
- type 2 en 3: 3/4’’ diameter
- type 4 en 5: 1’’ diameter
Aansluitingen voor andere kleppen en batterijen:
- type 2, 3, 4 en 5: 1/2’’ diameter
- type 6 en 7: 3/4’’ diameter
15 Betekenis van de draden - Proportionele klepaandrijving (niet van
toepassing voor kleppen met balansfuncties)
15a Zwarte draad (230 V klepaandrijving),
actuatorstang gaat omhoog
15b Groene draad (24 V klepaandrijving),
actuatorstang gaat omhoog
15c Bruine draad, actuatorstang gaat omlaag
15d Actuatorstang in bovenste stand
15e Actuatorstang in onderste stand
16 Waterdebietaanpassing van optionele 2-wegklep met balansfunctie
16a Verwijderen van de regelknop
16b Losdraaien van de kartelmoer
16c Waterdebietaanpassing (witte knop)
16d Losdraaien van de kartelmoer in
oorspronkelijke stand
17 Optionele luchtdebietregelaar
17a Luchtdemper
17b Verse lucht instelling (in m3/u)
17c Luchtdebietinstelschroef
18 Condensaatpomp monteren
1 Monteer de pompsteun op de randen van de opvangbak
2 Sluit de rubberen slang aan beide kanten aan
3 Controleer de afdichting
4 (Aanbevolen) Duw de pomp omlaag
4a Hoogste positie
4b Onderste positie
5 Sluit aan:
5a de elektrische draad
5b de afvoerpijp (binnendiameter 6 mm)
19 Beschermdoppen van de batterij verwijderen
19a Beschermdoppen (in de fabriek
gemonteerd)
NEDERLANDS

15

1 Distância em mm sem entrada do ange retangular
2 Distância em mm com entrada do ange retangular
3 Distância em mm com plenum pequeno ou grande
4 Pictograma de perigo elétrico
5 Pictograma cuidado perigo para as mãos
6 Pictograma de perigo geral
7 Unidade de elevação para instalação num tecto falso
8/9 Nivelar a unidade
10 Tubo de drenagem de condensado
10a Queda de 20 mm/m na tubagem horizontal
10b Sifão de 50 mm
11 Várias unidades ligadas a um coletor de condensado
11a Queda de 20 mm/m
12 Remoção da montagem de ventilador
12a Remover o painel de acesso do ventilador
12b Posição dos parafusos torx
13 Remoção do aquecedor elétrico
13a Localização dos parafusos
14 Posições de entrada/saída da serpentina, todos os tamanhos
1 Saída da água de refrigeração (serpentina de 4 e 2 tubos)
2 Entrada da água de refrigeração (serpentina de 4 e 2 tubos)
3 Saída de água de aquecimento (serpentina de 4 tubos)
4 Entrada de água de aquecimento (serpentina de 4 tubos)
5 Ar de ventilação
6 Drenagem de água
7 Saída de água de v-4v
8 Entrada de água de v-4v
9 Saída de água de v-2v
10 Saída de água v-2v + E
v-2v Válvula de duas vias
v-2v + E Válvula de duas vias e função de equilíbrio
v-4v Válvula de quatro vias (= Válvula de três vias com
derivação integral)
Conexões para válvula de duas vias com função de equilíbrio:
- tamanho 2 e 3: diâmetro de 3/4”
- tamanho 4 e 5: diâmetro de 1”
Conexões para outras válvulas e serpentinas:
- tamanho 2, 3, 4 e 5: diâmetro de 1/2”
- tamanho 6 e 7: diâmetro de 3/4”
15 Signicado dos os - Atuador de válvulas proporcional (não
aplicável a válvulas com funções de equilíbrio)
15a Fio preto (atuador de válvula de 230 V),
elevação da haste do atuador
15b Fio verde (atuador da válvula de 24 V),
elevação da haste do atuador
15c Fio castanho, descida da haste do atuador
15d Haste do atuador na posição elevada
15e Haste do atuador na posição baixa
16 Ajuste do uxo de água da válvula de 2 vias opcional com função
de equilíbrio
16a Remoção do botão de controlo
16b Desaperto da porca serrilhada
16c Ajuste do uxo de água (botão branco)
16d Aperto da porca serrilhada na posição
inicial
17 Controlador do uxo de ar opcional
17a Registo do Ar
17b Denição do uxo de ar puro (em m3/h)
17c Parafuso de ajuste do uxo de ar
18 Módulo da bomba de condensado
1 Coloque o suporte da bomba nas extremidades do
tabuleiro de drenagem
2 Ligue o tubo de borracha em ambos os lados
3 Verique a vedação
4 (Recomendado) Baixe a posição da bomba
4a A posição maior
4b A posição menor
5 Encaixe
5a o o elétrico
5b no tubo de saída (6mm de diâmetro
interno)
19 Remoção das tampas de proteção da serpentina de ar
19a Tampas de proteção (instaladas de
fábrica)
PORTUGUÊS

1 Зазор в мм без прямоугольного входного фланца
2 Зазор в мм с прямоугольным входным фланцем
3 Зазор в мм с малым или большим пленумом
4 Знак опасности поражения электрическим током
5 Знак опасности травмирования рук
6 Знак прочих опасностей
7 Подъем блока к месту установки в подвесном потолке
8/9 Выравнивание блока
10 Труба для слива конденсата
10a Уклон горизонтальных участков 20 мм/м
10b Сифон 50 мм
11 Присоединение нескольких блоков к коллектору конденсата
11a Уклон 20 мм/м
12 Демонтаж узла вентилятора
12a Удаление панели, закрывающей
вентилятор
12b Положение винтов с шестигранным
углублением
13 Демонтаж электрического нагревателя
13a Положение винта
14 Положение входов/выходов теплообменника, все
типоразмеры
1 Выход охлаждающей воды (4- и 2-трубные системы)
2 Вход охлаждающей воды (4- и 2-трубные системы)
3 Выход нагревающей воды (4-трубные системы)
4 Вход нагревающей воды (4-трубные системы)
5 Выпуск воздуха
6 Слив воды
7 Выход 4w-v
8 Вход 4w-v
9 Выход 2w-v
10 Выход 2w-v + B
2w-v Двухходовой клапан
2w-v + B Двухходовой клапан с функцией балансировки
4w-v Четырехходовой клапан (= трехходовой со встроенным
байпасом)
Соединения двухходового клапана с функцией балансировки:
- типоразмеры 2 и 3: диаметр 3/4’’
- типоразмеры 4 и 5: диаметр 1’’
Соединения других клапанов и теплообменников:
- типоразмеры 2, 3, 4 и 5: диаметр 1/2’’
- типоразмеры 6 и 7: диаметр 3/4’’
15 Назначение проводов – привод пропорционального клапана
(не устанавливается на клапанах с функцией балансировки)
15a Черный провод (привод 230 В), подъем
штока
15b Зеленый провод (привод 24 В), подъем
штока
15c Коричневый провод, спуск штока
15d Шток в верхнем положении
15e Шток в нижнем положении
16 Регулирование расхода через дополнительный 2-ходовой
клапан с функцией балансировки
16a Снятие ручки регулировки
16b Ослабление гайки с накаткой
16c Регулировка расхода воды (белая ручка)
16d Затяжка гайки с накаткой
17 Дополнительный регулятор расхода воздуха
17a Воздушная заслонка
17b Разметка расхода наружного воздуха (м
3
/ч)
17c Винт регулировки расхода воздуха
18 Монтаж насоса отвода конденсата
1 Прикрепите монтажный кронштейн насоса к краям
поддона для сбора конденсата
2 Подсоедините резиновый патрубок с обеих сторон
3 Проверьте состояние уплотнений
4 Рекомендуется установить насос как можно ниже (в
допустимых пределах)
4a Верхнее предельное положение
4b Нижнее предельное положение
5 Заглушка
5a Кабель электропитания
5b Патрубок отвода воды (внутренний
диаметр 6 мм)
19 Удаление защитных заглушек теплообменника
19a Защитные заглушки (установлены на
заводе-изготовителе)
РУССКИЙ

16
Tytuły rysunków i legenda:
1 Prześwit w mm bez wlotu z kołnierzem prostokątnym
2 Prześwit w mm z wlotem z kołnierzem prostokątnym
3 Prześwit w mm z małą lub dużą komorą rozprężną
4 Piktogram sygnalizujący niebezpieczeństwo porażenia prądem
5 Piktogram sygnalizujący niebezpieczeństwo obrażeń rąk
6 Piktogram sygnalizujący ogólne niebezpieczeństwo
7 Urządzenie podnośnikowe do instalacji w podwieszanym sucie
8/9 Poziomowanie jednostki
10 Przewód odprowadzający skropliny
10a spadek 20 mm/m w poziomym przebiegu
przewodu
10b syfon 50 mm
11 Wiele jednostek podłączonych do jednego kolektora skroplin
11a spadek 20 mm/m
12 Demontaż zespołu wentylatora
12a Demontaż panelu dostępu do wentylatora
12b Pozycja śrub torx
13 Demontaż nagrzewnicy elektrycznej
13a Lokalizacja śruby
14 Pozycja wlotu/wylotu wężownicy, wszystkie rozmiary
1 Wylot wody chłodzącej (wężownica 4 i 2-rurowa)
2 Wlot wody chłodzącej (wężownica 4 i 2-rurowa)
3 Wylot wody ogrzewającej (wężownica 4-rurowa)
4 Wlot wody ogrzewającej (wężownica 4-rurowa)
5 Odpowietrznik
6 Zawór upustowy wody
7 Wylot wody z 4w-v
8 Wylot wody z 4w-v
9 Wylot wody z 2w-v
10 Wylot wody z 2w-v + B
2w-v Zawór dwudrogowy
2w-v+B Zawór dwudrogowy z funkcją równoważenia
4w-v Zawór czterodrogowy (= Zawór trójdrogowy z
wbudowanym obejściem)
Podłączenia zaworu dwudrogowego z funkcją równoważenia:
- rozmiar 2 i 3: średnica 3/4’’
- rozmiar 4 i 5: średnica 1’’
Podłączenia innych zaworów i wężownic:
- rozmiar 2, 3, 4 i 5: średnica 1/2’’
- rozmiar 6 i 7: średnica 3/4’’
15 Rodzaje przewodów - Siłownik zaworu proporcjonalnego (nie ma
zastosowania do zaworów z funkcją równoważenia)
15a Czarny przewód (siłownik zaworu 230 V),
podnoszenie trzpienia siłownika
15b Zielony przewód (siłownik zaworu 24 V),
podnoszenie trzpienia siłownika
15c Brązowy przewód, opuszczanie trzpienia
siłownika
15d Trzpień siłownika w położeniu wysokim
15e Trzpień siłownika w położeniu niskim
16 Regulacja natężenia przepływu wody przez opcjonalny zawór
2-drogowy z funkcją równoważenia
16a Demontaż pokrętła sterującego
16b Odkręcanie nakrętki radełkowanej
16c Regulacja natężenia przepływu wody
(białe pokrętło)
16d Dokręcanie nakrętki radełkowanej w
pozycji początkowej
17 Opcjonalny sterownik strumienia powietrza
17a Przepustnica powietrza
17b Ustawienie strumienia świeżego powietrza
(w m3/h)
17c Śruba regulacji strumienia powietrza
18 Zespół pompy skroplin
1 Zamontować wspornik pompy na brzegach tacki na
skropliny
2 Podłączyć przewód gumowy z obu stron
3 Sprawdzić uszczelnienie
4 (Zalecane) Obniżyć położenie pompy
4a Najwyższe położenie
4b Najniższe położenie
5 Wtyczka
5a przewód elektryczny
5b przewód rurowy wylotowy (średnica
wewnętrzna 6mm)
19 Demontaż zatyczek ochronnych wężownicy
19a Zatyczki ochronne (montowane
fabrycznie)
POLSKA

17
ENGLISH

Only specially trained and
qualified technicians and
installers who have been fully
trained on the product
concerned are authorized to
install, to commission and
service this equipment.
In particular it is obligatory to
disconnect all power supplies
to the unit and its accessories
before carrying out any work.



Water circuit Min. inlet Temperature >5°C
ethylene / propylene glycol rate < 40%
Water side pressure < 15,5 bar (1550 kPa)



T < 27°C / 65% relative humidity or humidity
weight < 14,7 g/kg dry air

 T > 12°C with maximum ambient humidity
conditions (14,7 g/kg dry air)


Water circuit Max. inlet Temperature < 80°C
ethylene / propylene glycol rate < 40%
Water side pressure < 15,5 bar (1550 kPa)



T < 40°C

 T < 60°C with supply plenum and spigots
application

The 42NH / 42NL has been designed for indoor application
in ‘urban’ conditions having a non-corrosive, dust-free and
non-marine environment.
The concentrations of the following chemicals must not be
exceeded in any event:
• SO2< 0.02 ppm
• H2S < 0.02 ppm
• NO, NO2< 1 ppm
• NH3< 6 ppm
• N2O < 0.25 ppm
Do not install a unit where ammable gases or products of
an acidic or alkaline character may be present.The copper/
aluminium coil or components inside the unit could suffer
irreparable corrosion damage in their presence.

At installation handover, and then periodically every year,
it is advised to analyse the water for bacteria (detection of
ferro-bacteria, H2S-producing and sulphate-reducing
bacteria) and chemicals (in order to avoid problems due to
corrosion and scaling).
The water circuit must include all the necessary elements
for the treatment of the water:lters,additives, intermediate
exchangers, purges, drains, isolating valves, etc., according
to the analysis results.
The results must be in accordance with the values shown
below:
• Total hardness in mmol/l: 1 < mmol/l < 1.5
• Chloride [CL-] < 10 mg/litre
• Sulphate [SO42-] < 30 mg/litre
• Nitrate [NO3-] = 0 mg/litre
• Dissolved iron: < 0.5 mg/litre
• Dissolved oxygen: 4 < [O2] < 9 mg/litre
• Carbon dioxide [CO2] < 30 mg/litre
• Resistivity: 20 Ohm·m < Resistivity< 50 Ohm·m
• pH: 6.9 < pH < 8

Without rectangular ange inlet : Fig.1
With rectangular ange inlet : Fig.2
With plenum : Fig.2 and Fig. 3
NOTE : All informations about dimensions and weights
are available in the PSD documentation on Carrier
Webportal


When receiving a shipment,check the condition of the goods
and report any damage in transit to the shipping company.
Do not unpack the units until just before they are due to be
installed, and make sure they are as close as possible to the
installation site when unpacking them. Do not place heavy
articles of any sort on them.

18
ENGLISH

Check that the supply voltage and frequency correspond to
the values of the unit to be installed.



Min : 207V
Max : 253 V
60 or 50 Hz -1ph


Min : 207V
Max : 253 V
60 or 50 Hz -1ph
(60Hz not available for 42NH3_5)
NOTE: All performances data certied by Eurovent are
based on 50Hz application. Carrier doesn’t ensure the same
performances when the unit operates at 60Hz; the RPM
and power input of the fan-motor are usually higher.
WARNING: Failure to take proper account of the above
advice and unauthorised modication of the electrical
connections will render the Carrier warranty on the product
null and void.

WARNING: Switch off the main electrical power supply
to the unit and accessories (if installed) before doing any
work on the unit.
2.1 - General
Installing, commissioning and servicing of the various
component (unit,control system,hot and cold water system,
air distribution system) can be dangerous unless certain
aspects of the installation, such as the presence of mains
electricity and hot or cold water in the air conditioning
equipment, are taken into account. Only specially trained
and qualied technicians and installers who have been fully
trained on the product concerned are authorised to install,
commission and service this equipment.
During servicing work, it is essential to apply all
recommendations and instructions given in service leaets,
on labels or in the instructions delivered with the equipment,
and to comply with any other relevant instructions.
Denition of the pictograms used:
• Electrical danger - Fig.4
• Caution hand hazard - Fig.5
• General danger - Fig.6
Comply with all safety rules and regulations currently in
force. Wear eye protectors and work with hand gloves and
any individual protection equipment following local
legislation. Take care when moving or positioning of the
equipment.
2.2 - Protection against electrocution
Only electricians qualied to the level recommended by the
IEC (International Electrotechnical Commission) in its
standard IEC 364,corresponding to Europe HD 384,France
NFC 15 100 and UK IEE Wiring Regulations, may have
access to electrical components.In particular it is obligatory
to disconnect all power supplies to the unit and its accessories
before carrying out any work. Disconnect the main power
supply with an isolating device (not supplied by Carrier).
IMPORTANT:The components,which make up the different
control loops described in this manual include electronic
items. As such, they may generate or be harmed by
electromagnetic interference unless they are installed and
used in accordance with these instructions. The components
making up these control systems conform to the requirements
of electromagnetic compatibility in residential, commercial
and light industrial areas. They also comply with the
low-voltage directive.
If the product is supplied without a Carrier control device,
vericationof EMCconformity is theresponsibilityof theinstaller.
2.3 - General installation conditions
IMPORTANT: The Carrier numeric controller, power
module, or in general units tted with controls loops must
have an isolating device upstream (for example a
double-pole circuit breaker). If necessary, an easily
operated emergency stop device (such as a punch-button
switch) must cut off the power to all equipment. These
safety devices shall be sized and installed in accordance
with IEC Recommendation 364, corresponding to Europe
HD 384, France NFC 15 100 and UK IEE Wiring
Regulations. These devices are not supplied by Carrier.
In general terms the following rules must be applied:

Size (42NL &
42NH) Without Elec. Heater
2_5; 2_9 T2A
3_5; 3_9 T2A
4_5; 4_9 T2A
5_5; 5_9 T3A
6_5; 6_9 T3A
7_9; 7_9 T3A
Size (42NL &
42NH)
With Elec.
Heater
[0-1400W] [1500-2400W] [3000-3200W]
2_5; 2_9 T10A NA NA
3_5; 3_9 T10A NA NA
4_9 T10A NA NA
4_5 T10A T16A NA
5_5; 5_9 T10A T16A NA
6_5; 6_9 T10A T16A T20A
7_5; 7_9 T10A T16A T20A
• Electrical connections must be made according to the
wiring diagram provided with the unit and the
installation and operation manual of the controller.

19
ENGLISH
• Units must be provided with over-voltage protection
upstream (not supplied by Carrier).
• The power disconnection device must be clearly
labelled to identify which items of equipment are
connected to it.
• The wiring of the components which make up the
different control systems and the communication
buses must be carried out in accordance with the latest
rules and regulations by professional installers.
• The power supply cable must be doubly insulated and
xed using a cable clamp.A hole is provided for this
purpose in the plastic Carrier controller housing.The
cable must be clamped on the outer insulation.
• The control loop components must be installed in an
environment, which conforms to their index of
protection (IP).
• The maximum level of pollution is normally pollutant
(level 2) and installation category II.
• The low-voltage wiring (communication bus) must be
kept physically separate from the power wiring.
• In order to avoid interference with the communication
links:
-Keep low-voltage wiring away from power cables
and avoid using the same cable run (a maximum
of 300 mm in common with the 230 V a.c., 30 A
cable).
-Do not pass low-voltage wires through loops in
the power cables.
-Do not connect heavy inductive loads to the same
electrical supply (circuit breaker) used by the
controllers, power modules or speed controllers.
-Use the screened cable type recommended by
Carrier and make sure all cables are connected to
the controllers and power modules.

IMPORTANT: It is not permitted to connect several units
to the same control device (electronic NTC controller, WTC
controller, or any other third party controller). Carrier
electronic Thermostat type A&B for AC motors require
additional accessory board to allow master/slave function.
Carrier electronic Thermostat type C&D for EC motors
can be connected upto 10 units, refer to thermostat
installation manual instructions.

This equipment is in compliance with the essential
requirements of the following European directives:
• Electromagnetic compatibility: 2004/108/EC,
• Low-voltage directive: 2006/95/EC.
• Restriction of Hazardous substances directive:
2011/65/EC

3.1 - Installing the unit in the false ceiling
The positioning of the unit must not create an obstacle that
may lead to an unequal distribution and/or return ow of
the air.The ceiling must be sufciently even to allow a simple
installation without danger from the unit. The supporting
structure must be able to carry the unit weight and prevent
deformation, breaks or vibrations during operation.
INSTALLATION PRECAUTIONS: During the
installation process, remove all debris and construction
material from the ducts to prevent any damage to the unit.

NOTE:The fan-coil units are delivered upside down when
stacked on a pallet.
• Position the unit close to where it is to be installed in
the ceiling void. For installation in a false ceiling use
a hydraulic lift and a folding ladder to make the task
easier (Fig. 7).
• Check that the clearances around the unit are
sufcient to allow easy maintenance. Please refer to
the diagram that shows the service clearances.
• Mark the position of the threaded hangers on the
ceiling (if several units need to be installed,it may be
advisable to produce a drilling template).The method
of fixing the threaded hangers (not supplied by
Carrier) depends on the ceiling type (maximum
diameter of the threaded hangers is 10 mm).Once the
threaded hangers are xed to the ceiling, tighten the
rst nuts.
WARNING:When moving the units, do not use water pipes,
condensate drain pan, valves or exible pipes to lift them.
‘Without lter’ unit must be connected to an air ductwork.
It is not allowed to operate the unit without any lter and
with a free inlet at the same time.
Lift the unit and align it on the threaded hangers, insert the
second nuts and tighten them slightly.
NOTE: At this point do not tighten the nuts fully and do
not clamp the unit up to the ceiling (leave a space between
the ceiling and the unit). The nuts will be adjusted nally,
when the unit has been connected to the pipework and ducts
and levelled.
Level the unit (Figs. 8 and 9).
Adjust the hanger nuts so that the unit is inclined 0.5%
towards the condensate drain pan. In the other direction
(air ow direction) the unit must be perfectly level (Figs. 8
and 9).
Condensate drain pipe (Fig.10):Use a exible pipe with an inside
diameter of 16 mm and provide a constant fall of 20 mm/m over
the whole horizontal pipe run.Install a 50 mm (minimum) siphon
to prevent gases and odours from owing back into the ceiling
void.
WARNING:After drain pipe connection, control clamping
of the drain pipe and be sure there is no water leakage.

20
ENGLISH
If several units are connected to a common collector, a
device must be installed (Fig.11).Before operating the unit,
ensure that the water ows into the internal condensate
drain pan by pouring some water into it. If problems are
detected, check the drain pipe slope and look for possible
obstructions. In all cases the connection duct(s) at the unit
outlet must be insulated to prevent any condensate
formation on the walls.
NOTE: The pressure losses of these ducts must be
compatible with the unit performance. The duct must be
as smooth as possible.Avoid sharp bends. Check that there
are no leaks or kinks, and that there is no dirt or
installation debris inside the ducts. Debris within the ducts
might damage the fan wheel and the damper in the air
diffusers.
When installation is complete - i.e.when the unit is attached
to the ceiling, air ducts are complete, water mani-folds are
in position with stop valves ready on the connection stubs,
and electrical installation is prepared - then connect the
water pipe (1/2” gas screw connector for size 2 to 5 ; 3/4”
gas screw connector for size 6 and 7).
WARNING: Be sure that the coil protective caps are
removed before connecting the water pipes (see Fig. 19).
NOTE : Each fan-coil units shall be connected with water
flexible pipes in order to avoid any damage due to
vibrations.
Ensure that a gasket (not supplied by Carrier) is installed
between the screw connector and the stop valve.
When all units are installed, open the stop valves on the
manifolds, bleed and then pressurize the circuits. To bleed
the coils, slightly loosen the bleed screws. The installation
can then be started.
NOTE: Do not switch on the power until all connections
are made and earthed.

Switch off the unit power supply at the isolator provided
for the purpose during installation (isolator not supplied
by Carrier).
• Disconnect the power supply and connection cables.
• Close the isolating valves on the manifolds.
• Disconnect the exible water pipes by unscrewing the
gas connectors.
WARNING: Since the exible water pipes do not have
drain valves, a receiver must be provided to allow the
cooling coil to be drained.
• Disconnect the supply air ducts.
• Disconnect the exible condensate drain pipe. Drain
the siphon into a suitable vessel.
• Support the unit lightly and release it by unscrewing
the four nuts on the threaded hangers.Lower the unit
carefully.



WARNING: Disconnect the power supply to the unit before
carrying out any work on the unit.
• Identify and note the wired fan speeds. If the fan
develops a fault the whole assembly must be removed
and replaced (Fig. 12).
• Remove the lter.
• Remove the fan access panel.
• Disconnect the fan assembly power supply cables
(power and control wiring for variable-speed motor).
• If necessary remove the controller (xed with screws)
to gain access to the maintenance screws of the panel
supporting the fan.
• The fan assembly and its panel are held in place by four
screws.Remove these screws and slide the assembly down.
• Remove the fan motor assembly.
NOTE: Be careful not to touch the fan blades during the
removal process to avoid unbalancing the fans.
• For units with the electric heater option, disconnect
the power supply cable to the heater. Withdraw the
cable through the cable gland.
• Unscrew the electric heaters.
• Replacement of the fan motor assembly is by the
reversal of the above procedure.
WARNING: The electrical connections to the fan motor
must be made in accordance with the labels on the
connector block

• Disconnect the power supply to the unit before
carrying any work on the unit.
• Remove the lter.
• Remove the fan motor assembly access panel.
• Remove the capacitor that is attached to the motor
chassis assembly.
• Disconnect the capacitor by withdrawing the at
spade connectors from the back of the capacitor.
• Replacement of the capacitor assembly is by the
reversal of the above procedure.

For any modications of the wiring harness, refer to the fan
wiring diagrams provided with the units.
With the optional electrical box, three of the available ve
or six speeds ofAC motor are connected - (maximum speed
= R1, minimum speed = R5 for 42NH /R6 for 42NL).
When the unit is delivered with anWTC or a NTC controller,
for AC motor, three of the 5 or 6 speeds are connected.
Speeds arrangement can be changed on site according to
the electrical diagram.
WARNING: With the optional electric heater a minimum
air ow must be maintained (see tables below).
