Carrier Infinity 24ANB7 Operation manual

Product Data
24ANB7**C
Infinityr2---Stage Air Conditioner
with PuronrRefrigerant for Coastal Applications
2to5NominalTons
Carrier’s Air Conditioners with Puronrrefrigerant provide a
collection of features unmatched by any other family of
equipment. The 24ANB7 has been designed utilizing Carrier’s
Puron refrigerant. The environmentally sound refrigerant allows
you to make a responsible decision in the protection of the earth’s
ozone layer.
This product has been designed and manufactured to meet
Energy Starrcriteria for energy efficiency when matched with
appropriate coil components. Refer to the combination ratings in
the Product Data for system combinations that meet Energy Starr
guidelines.
NOTE:Ratings contained in this document are subject to
change at any time. Always refer to the AHRI directory
(www.ahridirectory.org) for the most up--to--date ratings
information.
INDUSTRY LEADING
FEATURES / BENEFITS
Efficiency
S14 -- 17.7 SEER / 11.3 -- 13.7 EER
SMicrotube Technologytrefrigeration system
Sound
SSound level as low as 67 dBA
SQuiet mount split post compressor grommets
SForward--swept condenser fan blade
SCompressor sound hood
SLaminated steel compressor mounting plate
S8 pole PSC ball bearing outdoor condenser fan motor
Comfort
SSystem supports InfinitytControl or standard 2--stage
thermostat controls
Reliability
SPuronrrefrigerant -- environmentally sound, won’t
deplete the ozone layer and low lifetime service cost.
SFront--seating service valves
S2--stage scroll compressor
SInternal pressure relief valve
SInternal thermal overload
SLow pressure switch
SHigh pressure switch
SFilter drier
SBalanced refrigeration system for maximum reliability
Controls and Diagnostics
SInfinitytControl or 2--Stage Thermostat
S2 control wires to outdoor unit with Infinity Control (serial
numbers 0213E and newer)
SUtility Interface Connection
SEnhanced diagnostics capability with InfinitytControl
Durability
WeatherArmor Ultratprotection package:
SSolid, Durable sheet metal construction
SSteel louver coil guard
S2--Sided, baked--on, complete coverage, powder paint
WeatherShield Condenser Coil
SAluminum fin material is pre--coated on both sides with a
corrosion protective epoxy phenolic coating.
ArmorPlatetCondenser Coil
SAluminum fin material is pre--coated on both sides with a
corrosion protective epoxy phenolic thermoset coating.
SIndustry leading standard coastal warranty coverage
Applications
SLong--line -- up to 250 feet (76.2 m) total equivalent
length.

2
MODEL NUMBER NOMENCLATURE
12 3 4567
8
N
91011 12 13
NN A AA/N N N A/N A/N A/N N N
24 A N B 7 36 C 0 0 3 0
Product
Series
Product
Family
Tier Major
Series
SEER Cooling
Capacity
Variations Open Open Voltage Minor
Series
0, 1, 2...
24=AC A=RES AC N = Infinity B=Puron 7=17
SEER
Nominal
C=Coastal 0=Not
Defined
0=Not
Defined
3=208---230 ---1
the environmentally sound refrigerant
This product has been designed and manufactured to
meet Energy Starcriteria for energy efficiency when
matched with appropriate coil components. However,
proper refrigerant charge and proper air flow are critical
to achieve rated capacity and efficiency. Installation of
this product should follow all manufacturing refrigerant
charging and air flow instructions. Failure to confirm
proper charge and air flow may reduce energy
efficiency and shorten equipment life.
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
STANDARD FEATURES
FEATURES Unit Size --- Voltage, Series
24---31 36---31 48 ---31 60 ---31
Puron Refrigerant XXXX
Maximum SEER Rating* 17.0 17.7 17.0 16.5
Inner and Outer Sheet Metal Surfaces
Coated with Baked on Powder Paint XXXX
2 control wires to outdoor unit with Infinity Control
(serial numbers 0213E and newer) XXXX
2---Stage Scroll Compressor XXXX
Crankcase Heater O O X X
Long line Capability XXXX
Low Ambient Capability to 0_F (--- 17.8_C) w/Infinity Control XXXX
Enhanced Diagnostics w/Infinity Control XXXX
Utility Interface Connection XXXX
Louvered Coil Guard XXXX
FieldInstalledFilterDrier XXXX
Front Seating Service Valves XXXX
Internal Pressure Relief Valve XXXX
Internal Thermal Overload XXXX
Long Line capability XXXX
Low Pressure Switch XXXX
High Pressure Switch XXXX
Sound Blanket XXXX
X = Standard O = Accessory
* With approved combinations
24ANB7**C

3
REFRIGERANT PIPING LENGTH LIMITATIONS
Liquid Line Sizing and Maximum Total Equivalent Lengths{for Cooling Only Systems with PuronrRefrigerant:
The maximum allowable length of a residential split system depends on the liquid line diameter and vertical separation between indoor and
outdoor units.
See Table below for liquid line sizing and maximum lengths :
Maximum Total Equivalent Length
Outdoor Unit BELOW Indoor Unit
Size Liquid Line
Connection
Liquid
Line
Diam.
w/TXV
AC with Puron Refrigerant Maximum Total Equivalent Length{: Outdoor unit BELOW Indoor
Vertical Separation ft (m)
0 --- 5
(0---1.5)
6 --- 1 0
(1.8---3.0)
11---20
(3.4---6.1)
21---30
(6.4---9.1)
31---40
(9.4---12.2)
41---50
(12.5---15.2)
51---60
(15.5---18.3)
61---70
(18.6---21.3)
71---80
(21.6---24.4)
024
AC with
Puron
3/8
1/4 75 75 75 50 50 --- --- --- --- --- --- --- ---
5/16 250* 250* 250* 250* 250* 225* 175 125 100
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
036
AC with
Puron
3/8 5/16 175 150 150 100 100 100 75 --- --- --- ---
3/8 250* 250* 250* 250* 250* 250* 250* 250* 250*
048
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 230 160 --- ---
060
AC with
Puron
3/8 3/8 250* 250* 250* 225* 190 150 110 --- --- --- ---
* Maximum actual length not to exceed 200 ft (61 m)
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
--- --- = o u t s i d e a c c e p t a b l e r a n g e
Maximum Total Equivalent Length
Outdoor Unit ABOVE Indoor Unit
Size Liquid Line
Connection
Liquid
Line
Diam.
w/TXV
AC with Puron Refrigerant Maximum Total Equivalent Length{: Outdoor unit ABOVE Indoor
Vertical Separation ft (m)
25
(7.6)
26---50
(7.9---15.2)
51---75
(15.5---22.9)
76---100
(23.2---30.5)
101---125
(30.8---38.1)
126---150
(38.4---45.7)
151---175
(46.0---53.3)
176---200
(53.6---61.0)
024
AC with
Puron
3/8
1/4 100 125 175 200 225* 250* 250* 250*
5/16 250* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
036
AC with
Puron
3/8 5/16 225* 250* 250* 250* 250* 250* 250* 250*
3/8 250* 250* 250* 250* 250* 250* 250* 250*
048
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*
060
AC with
Puron
3/8 3/8 250* 250* 250* 250* 250* 250* 250* 250*
* Maximum actual length not to exceed 200 ft (61 m)
{Total equivalent length accounts for losses due to elbows or fitting. See the Long Line Guideline for details.
REFRIGERANT CHARGE ADJUSTMENTS
Liquid Line Size Puron Charge oz/ft (g/m)
3/8 0.60 (17.74)
(Factory charge for lineset = 9 oz / 266.16 g)
5/16 0.40 (11.83)
1/4 0.27 (7.98)
Units are factory charged for 15 ft (4.6 m) of 3/8” liquid line. The factory charge for 3/8” lineset 9 oz.(266.16 g).
When using other length or diameter liquid lines, charge adjustments are required per the chart above.
Charging Formula:
[(Lineset oz/ft x total length) – (factory charge for lineset)] = charge adjustment
Example 1: System has 15 ft of line set using existing 1/4“ liquid line. What charge adjustment is required?
Formula: (.27 oz/ft x 15ft) – (9 oz) = (-4.95) oz.
Net result is to remove 4.95 oz of refrigerant from the system
Example 2: System has 45 ft of existing 5/16” liquid line. What is the charge adjustment?
Formula: (.40 oz/ft. x 45ft) – (9 oz.) = 9 oz.
Net result is to add 9 oz of refrigerant to the system
24ANB7**C

4
LONG LINE APPLICATIONS
An application is considered Long Line, when the refrigerant level in the system requires the use of accessories to maintain acceptable
refrigerant management for systems reliability. See Accessory Usage Guideline table for required accessories. Defining a system as long line
depends on the liquid line diameter, actual length of the tubing, and vertical separation between the indoor and outdoor units.
For Air Conditioner systems, the chart below shows when an application is considered Long Line.
AC WITH PURONrREFRIGERANT LONG LINE DESCRIPTION ft (m)
Beyond these lengths, long line accessories are required
Liquid Line Size Units On Same Level Outdoor Below Indoor Outdoor Above Indoor
1/4 No accessories needed within allowed
lengths
No accessories needed within allowed
lengths 175 (53.3)
5/16 120 (36.6) 50 (15.2) vertical or 120 (36.6) total 120 (36.6)
3/8 80 (24.4) 35 (10.7) vertical or 80 24.4) total 80 (24.4)
Note: SeeLongLineGuidelinefordetails
VAPOR LINE SIZING AND COOLING CAPACITY LOSS
Acceptable vapor line diameters provide adequate oil return to the compressor while avoiding excessive capacity loss. The suction line
diameters shown in the chart below are acceptable for AC systems with Puron refrigerant:
Vapor Line Sizing and Cooling Capacity Losses — PuronrRefrigerant 2--Stage Air Conditioner Applications
Unit
Nominal
Size (Btuh)
Maximum
Liquid
Line
Diameters
(In. OD)
Vapor Line
Diameters
(In.) OD
Cooling Capacity Loss (%)
Total Equivalent Line Length ft. (m)
26 --- 50
(7.9---15.2)
51 --- 80
(15.5---24.4)
81 --- 100
(24.7---30.5)
101 --- 125
(30.8---38.1)
126 --- 150
(38.4---45.7)
151 --- 175
(46.0---50.3)
176 --- 200
(53.6---60.0)
201 --- 225
(61.3---68.6)
226 --- 250
(68.9---76.2)
024
2 --- S t a g e
Puron
AC
3/8
5/8 011233445
3/4 000011111
036
2 --- S t a g e
Puron
AC
3/8
5/8 124567910 11
3/4 001122334
7/8 000011112
048
2 --- S t a g e
Puron
AC
3/8
3/4 122345677
7/8 011222333
1 --- 1 / 8 0 0 — — — — — — —
060
2 --- S t a g e
Puron
AC
3/8
3/4 124567910 11
7/8 012234455
1 --- 1 / 8 000111111
Applications in this area may be long line and may have height restrictions. See the Residential Piping and Long Line Guideline.
— Applications in this area are not recommended due to insufficient oil return
PHYSICAL DATA
UNIT SIZE --- VOLTAGE, SERIES 24 --- 31 36 --- 31 48 --- 31 60 --- 31
Operating Weight lb (kg) 203 (92.1) 236 (107.0) 310 (140.6) 311 (141.1)
Shipping Weight lb (kg) 242 (109.8) 275 (124.7) 352 (159.7) 353 (160.1)
Compressor Type Ultratech 2---Stage Scroll
REFRIGERANT Puronr(R---410A)
Control TXV (Puron Hard Shutoff)
Charge lb (kg) 6.64 (3.01) 9.26 (4.20) 12.94 (5.87) 12.70 (5.76)
COND FAN Forward Swept Propeller Type, Direct Drive
Air Discharge Vertical
Air Qty (CFM) 2481 3068 4700 4700
Motor HP 1/12 1/10 1/4 1/4
Motor RPM 800 825 825 825
COND COIL
Face Area (Sq ft) 19.38 19.38 25.12 25.12
Fins per In. 25 20 20 20
Rows 1 2 2 2
Circuits 5 7 7 7
VALVECONNECT.(In.ID)
Vapor 3/4 7/8 7/8 7/8
Liquid 3/8
REFRIGERANT TUBES (In. OD)
Rated Vapor* 3/4 7/8 1 --- 1 / 8 1 --- 1 / 8
Liquid 3/8
*Units are rated with 25 ft (7.6 m) of lineset length. See Vapor Line Sizing and Cooling Capacity Loss table when using other sizes and lengths of lineset.
24ANB7**C

5
ELECTRICAL DATA
U n i t S i z e ---
Voltage,
Series
V/PH OPER VOLTS* COMPR FAN MCA
MIN
WIRE
SIZE{
MIN
WIRE
SIZE{
MAX
LENGTH
ft. (m)}
MAX
LENGTH
ft. (m)}
MAX
FUSE** or
CKT BRK
AMPS
MIN MAX LRA RLA FLA 60C75C60C75C
24 --- 31
208---230 ---1 197 253
58.3 11.1 0.6 14.5 14 14 54 (16.6) 52 (15.7) 20
36 --- 31 83.0 15.3 0.7 19.8 12 12 63 (19.2) 60 (18.3) 35
48 --- 31 104.0 21.2 1.3 27.8 10 10 72 (21.9) 68 (20.8) 40
60 --- 31 152.9 28.8 1.3 37.3 8 8 83 (25.4) 79 (24.2) 60
* Permissible limits of the voltage range at which the unit will operate satisfactorily
{If wire is applied at ambient greater than 30_C, consult table 310---16 of the NEC (NFPA 70). The ampacity of non ---metallic---sheathed cable (NM), trade
name ROMEX, shall be that of 60_C conditions, per the NEC (NFPA 70) Article 336---26. If other than uncoated (no---plated), 60 or 75_C insulation, copper
wire (solid wire for 10 AWG or smaller, stranded wire for larger than 10 AWG) is used, consult applicable tables of the NEC (NFPA 70).
}Length shown is as measured one way along wire path between unit and service panel for voltage drop not to exceed 2%.
* * T i m e --- D e l a y f u s e .
FLA --- F u l l L o a d A m p s
LRA --- L o c k e d R o t o r A m p s
MCA --- Minimum Circuit Amps
RLA ---RatedLoadAmps
NOTE: Control circuit is 24---V on all units and requires external power source. Copper wire must be used from service disconnect to unit.
All motors/compressors contain internal overload protection.
Complies with 2010 requirements of ASHRAE Standards 90.1
A--WEIGHTED SOUND POWER (dBA)
U n i t S i z e ---
Voltage, Series
Standard Rating
(dBA)
Typical Octave Band Spectrum (dBA, without tone adjustment)
125 250 500 1000 2000 4000 8000
24 --- 31 7 1 --- H i g h S t a g e 51.0 55.5 61.5 66.0 59.0 54.5 51.0
6 9 --- L o w S t a g e 49.5 55.5 61.0 64.0 59.5 54.5 49.0
36 --- 31 6 9 --- H i g h S t a g e 58.5 57.5 61.5 63.5 57.5 53.5 50.5
6 7 --- L o w S t a g e 57.0 58.0 62.0 61.5 57.5 53.5 49.0
48 --- 31 7 0 --- H i g h S t a g e 55.0 62.0 63.5 65.0 59.0 55.5 48.5
6 9 --- L o w S t a g e 54.5 61.5 63.5 63.5 59.0 56.0 49.5
60 --- 31 7 2 --- H i g h S t a g e 52.0 63.5 65.5 66.0 60.0 58.5 52.5
7 1 --- L o w S t a g e 53.5 63.5 65.5 65.0 60.5 58.5 54.5
NOTE: Tested in accordance with AHRI Standard 270 ---08. (Not listed with AHRI).
CHARGING SUBCOOLING (TXV--TYPE EXPANSION DEVICE)
UNIT SIZE --- VOLTAGE, SERIES REQUIRED SUBCOOLING _F(_C)
24 --- 31 10 (5.6)
36 --- 31 14 (7.8)
48 --- 31 13 (7.2)
60 --- 31 14 (7.8)
ACCESSORY CONTROLS
PART NUMBER DESCRIPTION
SYSTXCCITN01 Infinity Touch Control (non--- Wi--- Fi)
SYSTXCCITW01 Infinity Touch Control with Wi--- Fi & Wireless Access Point
SYSTXCCUID01 ---V Infinity Control Deluxe 7---Day Programmable (4--- Wire User Interface w/ multiple functionality)
SYSTXCCUIZ01---V Infinity Control Deluxe Zoning 7---Day Programmable (Wall--- mounted control for a multi---zone system. w/ mul-
tiple functionality)
SYSTXCCUID01 ---B Infinity Control Deluxe 7--- Day Programmable (Wall--- mounted system control.)
SYSTXCCUIZ01---B Infinity Control Deluxe Zoning 7---Day Programmable (Wall--- mounted control for a multi---zone system.)
SYSTXCC4ZC01 Infinity 4---Zone Damper Control Module (Wall--- mounted control for a four--- zone system.)
SYSTXCCSMS01 Infinity Smart Sensor (Optional wall control used to monitor temperature and/or fan control in an individual zone.)
SYSTXCCRRS01 Infinity Remote Room Sensor (Monitors temperature in an individual zone.)
SYSTXCCRCT01 or
SYSTXCCRWF01 Infinity System Remote Access Module (Hardware for wireless access and control via internet.)
SYSTXCCNIM01 Infinity Network Interface Module (Connects Heat Recovery and Energy Recovery Ventilators on non---zoning
applications.)
24ANB7**C

6
ACCESSORIES
ORDER NUMBER DESCRIPTION 24 --- 31 36 --- 31 48 --- 31 60 --- 31
KAACH2401AAA CRANKCASE HEATER X X S S
KSAHS2501AAA* HARD START KIT X X
KSAHS2801AAA* HARD START KIT X X
KAALS0201LLS SOLENOID VALVE X X X X
KSASF0101AAA SUPPORT FEET X X X X
x = Accessory S = Standard
* Not backward compatible to previous series.
ACCESSORY USAGE GUIDELINE
ACCESSORY
REQUIRED FOR
L O W --- A M B I E N T C O O L I N G
APPLICATIONS
(Below 55F/12.8_C)
REQUIRED FOR LONG LINE
APPLICATIONS*
REQUIRED FOR SEA COAST
APPLICATIONS
(Within 2 miles/3.22 km)
Compressor Start Assist Kit No No No
Crankcase Heater Ye s
(standard on some units)
Ye s
(standard on some units) No
Evaporator Freeze Protection Standard with Infinity Control No No
Liquid--- Line Solenoid Valve No No No
Low---Ambient Control Standard with Infinity Control No No
Puron Refrigerant Balance Port Hard ---
ShutOff TXV Ye s {Ye s{Ye s {
Support Feet Recommended No Recommended
Winter Start Control Standard with Infinity Control No No
* For tubing set lengths between 80 and 200 ft. (24.38 and 60.96 m) horizontal or 35 ft. (10.7 m) vertical differential (total equivalent length), refer to the Long
Line Guideline—Air Conditioners and Heat Pumps using Puron®Refrigerant.
{Required on all indoor units. Standard on all new Puron refrigerant fan coils and furnace coils.
Accessory Description and Usage (Listed Alphabetically)
1. Compressor Start Assist -- Capacitor and Relay
Start capacitor and relay gives a ”hard” boost to compressor
motor at each start up.
Usage Guideline:
Not required on this unit since compressor always starts
unloaded.
Available if required by local codes.
2. Crankcase Heater
An electric resistance heater which mounts to the base of the
compressor to keep the lubricant warm during off cycles.
Improves compressor lubrication on restart and minimizes the
chance of liquid slugging.
Usage Guideline:
Required in low ambient cooling applications.
Required in long line applications.
Suggested in all commercial applications.
3. Support Feet
Four stick--on plastic feet that raise the unit 4 in. (101.6 mm)
above the mounting pad. This allows sand, dirt, and other debris
to be flushed from the unit base, minimizing corrosion.
Usage Guideline:
Suggested in the following applications:
Coastal installations.
Windy areas or where debris is normally circulating.
Rooftop installations.
For improved sound ratings.
4. Thermostatic Expansion Valve (TXV)
A modulating flow--control valve which meters refrigerant liquid
flow rate into the evaporator in response to the superheat of the
refrigerant gas leaving the evaporator.
Kit includes valve, adapter tubes, and external equalizer tube.
Hard shut off types are available.
NOTE: When using a hard shut off TXV with single phase
reciprocating compressors, a Compressor Start Assist Capacitor
and Relay is required.
Usage Guideline:
Required to achieve AHRI ratings in certain equipment
combinations. Refer to combination ratings.
Hard shut off TXV or LLS required in air conditioner
long line applications.
24ANB7**C

7
DIMENSIONS -- ENGLISH
24ANB7**C

8
DIMENSIONS -- SI
24ANB7**C

9
CLEARANCES
Clearances (various examples)
Wall
Wall
Wall
Wall
24”
Service
6”
(152.4 mm)
24”
(609.6)
Service
24”
(609.6)
Service
24”
(609.6)
Service
24”
(609.6)
Service
24”
(609.6)
24”
(609.6)
24”
(609.6)
12”
(304.8)
12”
(304.8)
12”
(304.8)
12”
(304.8)
6”
(152.4)
Note: Numbers in ( ) = mm
IMPORTANT: When installing multiple units in an alcove, roof well, or partially enclosed area, ensure there is adequate ventilation to prevent re--circulation of discharge air.
A07833
24ANB7**C

10
TESTED AHRI COMBINATION RATINGS
NOTE: Ratings contained in this document are subject to change at any time.
For AHRI ratings certificates, please refer to the AHRI directory www.ahridirectory.org
Additional ratings and system combinations can be accessed via the Carrier database at: www.MyCarrierRatings.com
For performance data at specific application &/or design conditions with various indoor unit combinations, the
equipment performance calculator can be accessed at : http://rpmob.wrightsoft.com/
Model Number Indoor Coil Model
Number
AHRI STANDARD RATINGS
FURNACE MODEL
COOLING
CAPACITY SEER EER ID CFM
HIGH LOW HIGH LOW
24ANB7C24A**31 CNPV*3117A** 24,000 21,600 17.0 13.0 835 670 58CV(A,X)090---16
24ANB7C36A**31 CNPV*4821A** 36,000 29,400 17.0 13.0 1005 835 58CV(A,X)090---16
24ANB7C48A**31 CNPV*6124A** 48,000 40,000 17.0 13.0 1355 1010 58CV(A,X)135---22
24ANB7C60A**31 CNPV*6124A** 58,000 47,000 16.5 13.0 1685 1355 58CV(A,X)135---22
AHRI — Air Conditioning, Heating & Refrigeration Institute
EER — Energy Efficiency Ratio --- 80_F (26.6_C) indoor db/67_F(19.4_C) indoor wb & 95_F(35_C) outdoor wb.
SEER — Seasonal Energy Efficiency Ratio
TDR — Time---DelayRelay. Inmostcases,only1methodshouldbeusedtoachieveTDRfunction.Usingmorethan1methodinasystemmaycausedegradationinperformance.
Use either the accessory Time---Delay Relay KAATD0101TDR or a furnace equipped with TDR. Most Carrier furnaces are equipped with TDR.
NOTES:
1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air conditioners. Ratings for other combinations are determined under DOE
computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
4. Do not apply with capillary tube coils as performance and reliability are affected.
24ANB7

11
DETAILED COOLING CAPACITIES#
EVAPORATOR AIR CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM EWB
°F(°C)
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Tot al Sens‡ Tota l Sens‡ Tot al Sens‡ Tot a l Sens‡ Tot a l Sens‡ Tot al Sens‡
24ANB724C**31 Outdoor Section With CNPV*3117A**+58CV(A,X)090---16 Indoor Section --- High
600
57 (13.9) 24.35 24.35 1.59 21.95 21.95 1.68 19.59 19.59 1.78 17.29 17.29 1.90 15.06 15.06 2.03 12.92 12.92 2.18 62 (16.7) 25.97 21.39 1.60 23.22 19.39 1.69 20.53 17.42 1.79 17.94 15.51 1.90 15.45 13.65 2.03 13.09 11.86 2.18
63 (17.2)†† 26.50 17.74 1.60 23.69 16.00 1.69 20.94 14.30 1.79 18.29 12.65 1.91 15.74 11.06 2.03 13.32 9.54 2.18
67 (19.4) 28.68 18.42 1.61 25.64 16.63 1.71 22.68 14.88 1.80 19.82 13.18 1.92 17.07 11.54 2.04 14.47 9.98 2.19 72 (22.2) 31.66 15.36 1.63 28.31 13.79 1.72 25.04 12.27 1.82 21.89 10.80 1.93 18.87 9.39 2.06 16.01 8.05 2.21
650
57 (13.9) 25.14 25.14 1.60 22.64 22.64 1.69 20.19 20.19 1.80 17.81 17.81 1.91 15.50 15.50 2.04 13.29 13.29 2.18 62 (16.7) 26.46 22.38 1.61 23.65 20.29 1.70 20.90 18.25 1.80 18.25 16.26 1.91 15.71 14.32 2.04 13.33 13.26 2.19
63 (17.2)†† 26.98 18.42 1.61 24.11 16.62 1.70 21.29 14.87 1.80 18.57 13.16 1.92 15.98 11.52 2.04 13.51 9.95 2.19
67 (19.4) 29.19 19.14 1.63 26.08 17.29 1.72 23.05 15.48 1.81 20.12 13.72 1.93 17.32 12.03 2.05 14.66 10.41 2.20 72 (22.2) 32.19 15.83 1.64 28.75 14.22 1.73 25.41 12.65 1.83 22.20 11.14 1.94 19.12 9.70 2.07 16.20 8.32 2.21
700
57 (13.9) 25.85 25.85 1.61 23.27 23.27 1.71 20.74 20.74 1.81 18.28 18.28 1.92 15.90 15.90 2.05 13.62 13.62 2.19 62 (16.7) 26.90 23.34 1.62 24.03 21.18 1.71 21.23 19.06 1.81 18.53 16.98 1.92 15.97 15.81 2.05 13.65 13.65 2.20
63 (17.2)†† 27.40 19.08 1.62 24.46 17.23 1.71 21.59 15.42 1.81 18.83 13.66 1.92 16.18 11.97 2.05 13.67 10.34 2.20
67 (19.4) 29.63 19.84 1.64 26.45 17.93 1.73 23.35 16.07 1.82 20.38 14.26 1.93 17.52 12.51 2.06 14.82 10.84 2.21 72 (22.2) 32.64 16.28 1.65 29.13 14.63 1.74 25.73 13.02 1.84 22.46 11.48 1.95 19.33 10.00 2.08 16.37 8.58 2.22
750
57 (13.9) 26.50 26.50 1.63 23.85 23.85 1.72 21.24 21.24 1.82 18.71 18.71 1.93 16.26 16.26 2.06 13.93 13.93 2.20 62 (16.7) 27.30 24.28 1.63 24.37 22.04 1.72 21.53 19.84 1.82 18.80 17.68 1.93 16.29 16.29 2.06 13.95 13.95 2.20
63 (17.2)†† 27.76 19.72 1.63 24.77 17.82 1.72 21.86 15.96 1.82 19.04 14.15 1.93 16.35 12.41 2.06 13.82 10.73 2.20
67 (19.4) 30.00 20.53 1.65 26.77 18.56 1.73 23.63 16.64 1.83 20.59 14.78 1.94 17.70 12.98 2.07 14.96 11.25 2.21 72 (22.2) 33.03 16.71 1.66 29.46 15.02 1.75 26.01 13.38 1.85 22.68 11.80 1.96 19.51 10.29 2.08 16.51 8.84 2.23
800
57 (13.9) 27.10 27.10 1.64 24.38 24.38 1.73 21.70 21.70 1.83 19.10 19.10 1.94 16.60 16.60 2.07 14.20 14.20 2.21 62 (16.7) 27.65 25.20 1.64 24.69 22.88 1.73 21.82 20.59 1.83 19.13 19.13 1.94 16.62 16.62 2.07 14.22 14.22 2.21
63 (17.2)†† 28.08 20.35 1.64 25.05 18.40 1.73 22.09 16.49 1.83 19.23 14.63 1.94 16.51 12.83 2.07 13.94 11.11 2.21
67 (19.4) 30.34 21.20 1.66 27.05 19.18 1.74 23.86 17.21 1.84 20.78 15.29 1.95 17.85 13.44 2.08 15.08 11.66 2.22 72 (22.2) 33.37 17.13 1.67 29.75 15.40 1.76 26.25 13.73 1.85 22.88 12.12 1.96 19.67 10.57 2.09 16.63 9.09 2.24
835
57 (13.9) 27.50 27.50 1.65 24.72 24.72 1.74 22.00 22.00 1.83 19.36 19.36 1.95 16.81 16.81 2.07 14.38 14.38 2.22 62 (16.7) 27.89 25.83 1.65 24.90 23.45 1.74 22.03 22.03 1.83 19.39 19.39 1.95 16.84 16.84 2.07 14.40 14.40 2.22
63 (17.2)†† 28.29 20.79 1.65 25.22 18.80 1.74 22.23 16.85 1.84 19.35 14.96 1.95 16.61 13.13 2.07 14.02 11.38 2.22
67 (19.4) 30.54 21.66 1.66 27.22 19.61 1.75 24.00 17.60 1.85 20.90 15.65 1.96 17.95 13.76 2.08 15.16 11.94 2.23 72 (22.2) 33.58 17.41 1.68 29.93 15.67 1.76 26.39 13.97 1.86 23.00 12.33 1.97 19.77 10.77 2.10 16.70 9.27 2.24
900
57 (13.9) 28.17 28.17 1.66 25.31 25.31 1.75 22.51 22.51 1.85 19.79 19.79 1.96 17.18 17.18 2.08 14.67 14.67 2.23 62 (16.7) 28.32 26.95 1.66 25.34 25.34 1.75 22.55 22.55 1.85 19.82 19.82 1.96 17.20 17.20 2.08 14.70 14.70 2.23
63 (17.2)†† 28.63 21.58 1.66 25.50 19.52 1.75 22.47 17.51 1.85 19.55 15.56 1.96 16.77 13.67 2.08 14.15 11.85 2.23
67 (19.4) 30.88 22.51 1.68 27.51 20.38 1.76 24.24 18.31 1.86 21.10 16.29 1.97 18.11 14.34 2.09 15.28 12.46 2.24 72 (22.2) 33.93 17.93 1.69 30.22 16.14 1.78 26.64 14.41 1.87 23.20 12.73 1.98 19.92 11.12 2.11 16.82 9.58 2.25
See notes on page 16
24ANB7**C

12
DETAILED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM EWB
°F(°C)
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Tot al Sens‡ Tota l Sens‡ Tot al Sens‡ Tot a l Sens‡ Tot a l Sens‡ Tot al Sens‡
24ANB724C**31 Outdoor Section With CNPV*3117A**+58CV(A,X)090---16 Indoor Section --- Low
450
57 (13.9) 17.62 17.62 1.05 16.16 16.16 1.25 14.68 14.68 1.48 13.20 13.20 1.76 11.79 11.79 2.07 10.43 10.43 2.44 62 (16.7) 18.73 15.76 1.04 17.00 14.15 1.24 15.27 12.56 1.48 13.57 11.03 1.75 11.95 9.57 2.07 10.46 10.45 2.44
63 (17.2)†† 19.10 13.04 1.04 17.34 11.64 1.24 15.56 10.27 1.47 13.83 8.95 1.75 12.16 7.70 2.07 10.58 6.53 2.44
67 (19.4) 20.70 13.55 1.02 18.79 12.11 1.22 16.89 10.70 1.46 15.02 9.35 1.73 13.24 8.06 2.06 11.55 6.85 2.43 72 (22.2) 22.95 11.31 1.00 20.84 10.04 1.20 18.74 8.82 1.44 16.71 7.65 1.71 14.76 6.54 2.04 12.91 5.51 2.42
500
57 (13.9) 18.38 18.38 1.05 16.84 16.84 1.25 15.28 15.28 1.48 13.74 13.74 1.75 12.25 12.25 2.07 10.84 10.84 2.44 62 (16.7) 19.20 16.75 1.04 17.41 15.05 1.24 15.63 13.38 1.48 13.90 11.76 1.75 12.28 12.28 2.07 10.85 10.85 2.44
63 (17.2)†† 19.56 13.72 1.04 17.73 12.26 1.24 15.90 10.83 1.48 14.11 9.45 1.75 12.40 8.15 2.07 10.78 6.92 2.44
67 (19.4) 21.19 14.29 1.02 19.21 12.78 1.22 17.25 11.30 1.46 15.33 9.89 1.74 13.49 8.54 2.06 11.76 7.27 2.44 72 (22.2) 23.47 11.79 1.00 21.29 10.47 1.20 19.13 9.20 1.44 17.03 7.99 1.72 15.02 6.85 2.05 13.12 5.78 2.43
550
57 (13.9) 19.06 19.06 1.05 17.44 17.44 1.25 15.81 15.81 1.48 14.21 14.21 1.75 12.66 12.66 2.07 11.19 11.19 2.44 62 (16.7) 19.60 17.71 1.04 17.77 15.93 1.24 15.96 14.17 1.48 14.23 14.23 1.75 12.68 12.68 2.07 11.21 11.21 2.45
63 (17.2)†† 19.94 14.38 1.04 18.06 12.86 1.24 16.18 11.37 1.48 14.34 9.94 1.75 12.59 8.58 2.08 10.94 7.29 2.45
67 (19.4) 21.60 15.00 1.02 19.57 13.42 1.22 17.55 11.89 1.46 15.58 10.42 1.74 13.70 9.01 2.06 11.93 7.68 2.44 72 (22.2) 23.90 12.24 1.00 21.66 10.89 1.20 19.44 9.57 1.44 17.29 8.32 1.72 15.24 7.14 2.05 13.30 6.04 2.43
600
57 (13.9) 19.66 19.66 1.05 17.98 17.98 1.25 16.28 16.28 1.48 14.62 14.62 1.75 13.02 13.02 2.08 11.50 11.50 2.45 62 (16.7) 19.96 18.65 1.04 18.11 16.78 1.24 16.31 16.31 1.48 14.65 14.65 1.75 13.04 13.04 2.08 11.52 11.52 2.45
63 (17.2)†† 20.26 15.03 1.04 18.33 13.45 1.24 16.41 11.90 1.48 14.54 10.42 1.76 12.76 9.00 2.08 11.08 7.67 2.45
67 (19.4) 21.94 15.69 1.03 19.86 14.06 1.23 17.80 12.47 1.46 15.79 10.93 1.74 13.88 9.47 2.07 12.08 8.09 2.45 72 (22.2) 24.26 12.68 1.00 21.96 11.29 1.20 19.70 9.94 1.44 17.50 8.65 1.72 15.41 7.44 2.06 13.44 6.30 2.44
650
57 (13.9) 20.20 20.20 1.05 18.46 18.46 1.25 16.71 16.71 1.48 15.00 15.00 1.76 13.35 13.35 2.08 11.78 11.78 2.45 62 (16.7) 20.31 19.56 1.05 18.49 18.49 1.25 16.74 16.74 1.48 15.02 15.02 1.76 13.37 13.37 2.08 11.80 11.80 2.45
63 (17.2)†† 20.54 15.66 1.05 18.58 14.03 1.25 16.62 12.42 1.48 14.72 10.89 1.76 12.90 9.42 2.09 11.21 8.03 2.46
67 (19.4) 22.24 16.37 1.03 20.11 14.68 1.23 18.01 13.03 1.47 15.97 11.44 1.75 14.03 9.92 2.07 12.21 8.48 2.45 72 (22.2) 24.57 13.12 1.00 22.22 11.68 1.20 19.91 10.29 1.44 17.68 8.97 1.73 15.56 7.72 2.06 13.56 6.54 2.45
670
57 (13.9) 20.41 20.41 1.05 18.64 18.64 1.25 16.87 16.87 1.48 15.14 15.14 1.76 13.47 13.47 2.08 11.88 11.88 2.46 62 (16.7) 20.46 20.36 1.05 18.67 18.67 1.25 16.90 16.90 1.48 15.16 15.16 1.76 13.49 13.49 2.08 11.90 11.90 2.46
63 (17.2)†† 20.64 15.91 1.05 18.66 14.25 1.25 16.69 12.63 1.48 14.78 11.07 1.76 12.96 9.58 2.09 11.26 8.17 2.46
67 (19.4) 22.34 16.64 1.03 20.20 14.92 1.23 18.09 13.25 1.47 16.04 11.64 1.75 14.09 10.10 2.08 12.26 8.64 2.45 72 (22.2) 24.67 13.29 1.01 22.31 11.84 1.21 19.99 10.43 1.45 17.75 9.09 1.73 15.61 7.83 2.06 13.60 6.64 2.45
700
57 (13.9) 20.70 20.70 1.05 18.90 18.90 1.25 17.10 17.10 1.48 15.34 15.34 1.76 13.64 13.64 2.08 12.03 12.03 2.46 62 (16.7) 20.73 20.73 1.05 18.93 18.93 1.25 17.13 17.13 1.48 15.36 15.36 1.76 13.66 13.66 2.08 12.05 12.05 2.46
63 (17.2)†† 20.79 16.28 1.05 18.79 14.59 1.25 16.80 12.94 1.49 14.87 11.35 1.77 13.04 9.83 2.09 11.33 8.38 2.47
67 (19.4) 22.49 17.03 1.03 20.33 15.28 1.23 18.20 13.58 1.47 16.13 11.93 1.75 14.16 10.36 2.08 12.33 8.87 2.46 72 (22.2) 24.82 13.53 1.01 22.44 12.06 1.21 20.10 10.64 1.45 17.84 9.28 1.73 15.69 7.99 2.07 13.66 6.78 2.45
See notes on page 16
24ANB7**C

13
DETAILED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM EWB
°F(°C)
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Tot al Sens‡ Tota l Sens‡ Tot al Sens‡ Tot a l Sens‡ Tot a l Sens‡ Tot al Sens‡
24ANB736C**31 Outdoor Section With CNPV*4821A**+58CV(A,X)090---16 Indoor Section --- High
900
57 (13.9) 35.84 35.84 2.28 33.31 33.31 2.47 30.78 30.78 2.70 28.23 28.23 2.96 25.63 25.63 3.26 22.99 22.99 3.58 62 (16.7) 38.02 31.58 2.30 35.06 29.75 2.49 32.11 27.93 2.72 29.14 26.10 2.97 26.15 24.26 3.26 23.16 22.40 3.58
63 (17.2)†† 38.77 26.12 2.30 35.74 24.49 2.50 32.71 22.86 2.72 29.66 21.22 2.98 26.58 19.58 3.27 23.48 17.94 3.58
67 (19.4) 41.84 27.07 2.33 38.59 25.41 2.52 35.31 23.74 2.74 32.02 22.07 3.00 28.69 20.39 3.29 25.34 18.71 3.60 72 (22.2) 46.07 22.49 2.37 42.48 20.99 2.56 38.88 19.49 2.77 35.25 17.98 3.03 31.59 16.46 3.31 27.88 14.95 3.63
975
57 (13.9) 36.91 36.91 2.30 34.29 34.29 2.50 31.67 31.67 2.73 29.01 29.01 2.99 26.31 26.31 3.28 23.57 23.57 3.60 62 (16.7) 38.68 32.98 2.32 35.66 31.09 2.51 32.63 29.20 2.74 29.60 27.31 2.99 26.56 25.39 3.28 23.61 23.61 3.60
63 (17.2)†† 39.40 27.07 2.32 36.30 25.40 2.52 33.20 23.73 2.74 30.07 22.04 3.00 26.93 20.36 3.28 23.76 18.68 3.60
67 (19.4) 42.51 28.10 2.35 39.17 26.38 2.54 35.82 24.67 2.76 32.44 22.95 3.02 29.04 21.23 3.30 25.62 19.50 3.62 72 (22.2) 46.76 23.13 2.40 43.10 21.60 2.58 39.41 20.07 2.79 35.69 18.53 3.04 31.95 16.98 3.33 28.17 15.43 3.64
1005
57 (13.9) 37.31 37.31 2.31 34.65 34.65 2.51 31.99 31.99 2.74 29.30 29.30 2.99 26.56 26.56 3.28 23.78 23.78 3.60 62 (16.7) 38.93 33.53 2.33 35.87 31.61 2.52 32.83 29.70 2.74 29.77 27.78 3.00 26.72 25.82 3.29 23.82 23.82 3.60
63 (17.2)†† 39.63 27.45 2.33 36.51 25.76 2.52 33.38 24.06 2.75 30.22 22.37 3.00 27.05 20.67 3.29 23.85 18.96 3.60
67 (19.4) 42.75 28.49 2.36 39.37 26.76 2.55 36.00 25.03 2.77 32.59 23.29 3.02 29.17 21.56 3.31 25.71 19.81 3.62 72 (22.2) 47.01 23.39 2.40 43.32 21.84 2.58 39.60 20.29 2.80 35.85 18.74 3.05 32.08 17.18 3.34 28.27 15.62 3.65
1200
57 (13.9) 39.58 39.58 2.37 36.72 36.72 2.56 33.84 33.84 2.79 30.92 30.92 3.04 27.97 27.97 3.33 24.98 24.98 3.65 62 (16.7) 40.28 36.94 2.38 37.11 34.86 2.57 33.98 32.74 2.79 30.97 30.97 3.04 28.01 28.01 3.33 25.01 25.01 3.65
63 (17.2)†† 40.84 29.78 2.38 37.56 27.98 2.57 34.29 26.19 2.79 31.00 24.39 3.04 27.69 22.59 3.33 24.38 20.78 3.64
67 (19.4) 44.00 30.99 2.41 40.46 29.14 2.59 36.93 27.31 2.81 33.39 25.47 3.07 29.82 23.62 3.35 26.24 21.77 3.66 72 (22.2) 48.33 24.94 2.45 44.46 23.32 2.63 40.57 21.70 2.84 36.66 20.07 3.09 32.73 18.44 3.38 28.78 16.81 3.69
1350
57 (13.9) 41.01 41.01 2.41 38.01 38.01 2.60 34.98 34.98 2.82 31.93 31.93 3.08 28.84 28.84 3.37 25.70 25.70 3.68 62 (16.7) 41.19 39.34 2.41 38.05 38.05 2.60 35.03 35.03 2.82 31.97 31.97 3.08 28.88 28.88 3.37 25.73 25.73 3.68
63 (17.2)†† 41.54 31.48 2.42 38.18 29.61 2.60 34.82 27.74 2.82 31.44 25.87 3.07 28.06 23.99 3.36 24.68 22.09 3.67
67 (19.4) 44.70 32.80 2.45 41.09 30.89 2.63 37.47 28.98 2.85 33.83 27.06 3.10 30.19 25.13 3.38 26.53 23.19 3.69 72 (22.2) 49.07 26.06 2.49 45.10 24.39 2.67 41.11 22.71 2.88 37.11 21.04 3.12 33.08 19.36 3.41 29.04 17.68 3.72
24ANB736C**31 Outdoor Section With CNPV*4821A**+58CV(A,X)090---16 Indoor Section --- Low
720
57 (13.9) 26.16 26.16 1.51 24.56 24.56 1.75 22.93 22.93 2.02 21.26 21.26 2.34 19.53 19.53 2.71 17.74 17.74 3.15 62 (16.7) 27.22 23.86 1.51 25.33 21.80 1.74 23.44 19.77 2.02 21.51 17.78 2.34 19.57 19.55 2.71 17.77 17.77 3.15
63 (17.2)†† 27.75 19.50 1.50 25.81 17.73 1.74 23.86 15.99 2.01 21.86 14.30 2.34 19.80 12.63 2.71 17.68 11.01 3.15
67 (19.4) 30.15 20.35 1.48 28.03 18.51 1.72 25.90 16.71 2.00 23.75 14.95 2.32 21.53 13.24 2.70 19.24 11.56 3.13 72 (22.2) 33.42 16.77 1.46 31.06 15.17 1.70 28.71 13.59 1.98 26.32 12.07 2.30 23.88 10.60 2.67 21.37 9.16 3.10
780
57 (13.9) 26.97 26.97 1.52 25.30 25.30 1.75 23.60 23.60 2.02 21.87 21.87 2.34 20.07 20.07 2.72 18.21 18.21 3.15 62 (16.7) 27.71 25.00 1.51 25.78 22.85 1.75 23.85 20.74 2.02 21.92 21.84 2.34 20.11 20.11 2.72 18.24 18.24 3.15
63 (17.2)†† 28.20 20.29 1.51 26.21 18.45 1.74 24.21 16.66 2.02 22.17 14.90 2.34 20.07 13.18 2.72 17.90 11.50 3.16
67 (19.4) 30.62 21.18 1.49 28.44 19.28 1.73 26.27 17.42 2.00 24.06 15.60 2.33 21.79 13.82 2.70 19.46 12.09 3.13 72 (22.2) 33.92 17.30 1.46 31.51 15.64 1.70 29.09 14.04 1.98 26.65 12.48 2.31 24.16 10.96 2.68 21.60 9.49 3.11
835
57 (13.9) 27.64 27.64 1.52 25.91 25.91 1.75 24.16 24.16 2.03 22.37 22.37 2.35 20.52 20.52 2.72 18.59 18.59 3.15 62 (16.7) 28.12 26.02 1.51 26.16 23.78 1.75 24.23 24.10 2.03 22.41 22.41 2.35 20.55 20.55 2.72 18.62 18.62 3.15
63 (17.2)†† 28.57 20.99 1.51 26.54 19.10 1.75 24.49 17.26 2.02 22.41 15.45 2.35 20.28 13.68 2.72 18.08 11.95 3.16
67 (19.4) 30.99 21.93 1.49 28.78 19.97 1.73 26.56 18.06 2.01 24.30 16.19 2.33 22.00 14.36 2.71 19.64 12.57 3.14 72 (22.2) 34.32 17.77 1.47 31.86 16.08 1.71 29.39 14.44 1.99 26.91 12.85 2.31 24.38 11.29 2.68 21.77 9.79 3.11
960
57 (13.9) 28.98 28.98 1.52 27.13 27.13 1.76 25.27 25.27 2.03 23.35 23.35 2.35 21.38 21.38 2.73 19.34 19.34 3.16 62 (16.7) 29.01 29.01 1.52 27.17 27.17 1.76 25.30 25.30 2.03 23.39 23.39 2.35 21.41 21.41 2.73 19.37 19.37 3.16
63 (17.2)†† 29.25 22.53 1.52 27.14 20.52 1.76 25.03 18.57 2.04 22.87 16.64 2.36 20.67 14.76 2.74 18.42 12.92 3.17
67 (19.4) 31.69 23.58 1.50 29.39 21.49 1.74 27.09 19.46 2.02 24.76 17.47 2.34 22.39 15.52 2.72 19.97 13.62 3.15 72 (22.2) 35.05 18.80 1.48 32.49 17.03 1.72 29.94 15.32 2.00 27.37 13.65 2.32 24.76 12.02 2.70 22.08 10.44 3.13
1080
57 (13.9) 30.06 30.06 1.53 28.11 28.11 1.77 26.14 26.14 2.04 24.13 24.13 2.36 22.07 22.07 2.74 19.93 19.93 3.17 62 (16.7) 30.11 30.11 1.53 28.15 28.15 1.77 26.18 26.18 2.04 24.16 24.16 2.36 22.10 22.10 2.74 19.96 19.96 3.17
63 (17.2)†† 29.77 23.95 1.53 27.60 21.84 1.77 25.42 19.77 2.05 23.22 17.74 2.37 20.98 15.75 2.75 18.70 13.78 3.19
67 (19.4) 32.21 25.10 1.51 29.85 22.90 1.75 27.49 20.76 2.03 25.11 18.66 2.36 22.70 16.60 2.73 20.24 14.57 3.17 72 (22.2) 35.58 19.75 1.49 32.95 17.90 1.73 30.34 16.12 2.01 27.70 14.38 2.34 25.03 12.68 2.71 22.29 11.04 3.14
See notes on page 16
24ANB7**C

14
DETAILED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM EWB
°F(°C)
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Tot al Sens‡ Tota l Sens‡ Tot al Sens‡ Tot a l Sens‡ Tot a l Sens‡ Tot al Sens‡
24ANB748C**31 Outdoor Section With CNPV*6124A**+58CV(A,X)135---22 Indoor Section --- High
1200
57 (13.9) 47.30 47.30 2.91 44.22 44.22 3.23 41.02 41.02 3.61 37.80 37.80 4.04 34.62 34.62 4.56 31.52 31.52 5.16 62 (16.7) 50.25 41.83 2.93 46.59 39.45 3.25 42.79 37.01 3.62 39.01 34.60 4.05 35.32 32.24 4.56 31.77 29.95 5.17
63 (17.2)†† 51.23 34.57 2.93 47.48 32.43 3.25 43.59 30.24 3.63 39.71 28.08 4.06 35.92 25.98 4.57 32.25 23.96 5.17
67 (19.4) 55.28 35.82 2.95 51.21 33.62 3.27 47.04 31.41 3.65 42.87 29.21 4.09 38.78 27.06 4.60 34.83 25.00 5.21 72 (22.2) 60.74 29.68 2.97 56.26 27.68 3.30 51.68 25.68 3.68 47.07 23.68 4.12 42.67 21.79 4.65 37.97 19.81 5.24
1300
57 (13.9) 48.75 48.75 2.94 45.52 45.52 3.26 42.20 42.20 3.64 38.85 38.85 4.08 35.56 35.56 4.59 32.33 32.33 5.20 62 (16.7) 51.12 43.71 2.95 47.36 41.24 3.27 43.48 38.72 3.65 39.61 36.23 4.08 35.87 33.78 4.59 32.38 32.38 5.20
63 (17.2)†† 52.07 35.84 2.96 48.22 33.65 3.28 44.23 31.40 3.65 40.26 29.19 4.09 36.38 27.03 4.60 32.63 24.95 5.20
67 (19.4) 56.14 37.18 2.98 51.97 34.92 3.30 47.69 32.64 3.68 43.42 30.38 4.12 39.25 28.19 4.63 35.21 26.06 5.24 72 (22.2) 61.64 30.52 3.00 57.05 28.49 3.33 52.36 26.44 3.71 47.70 24.43 4.15 43.13 22.47 4.67 38.69 20.58 5.29
1355
57 (13.9) 49.48 49.48 2.96 46.20 46.20 3.28 42.80 42.80 3.66 39.39 39.39 4.09 36.03 36.03 4.61 32.74 32.74 5.22 62 (16.7) 51.56 44.72 2.97 47.74 42.20 3.29 43.82 39.65 3.66 39.92 37.10 4.10 36.17 34.58 4.61 32.79 32.79 5.22
63 (17.2)†† 52.48 36.53 2.97 48.57 34.30 3.30 44.54 32.02 3.67 40.53 29.78 4.10 36.60 27.60 4.62 32.81 25.49 5.22
67 (19.4) 56.56 37.91 2.99 52.33 35.62 3.32 48.00 33.31 3.69 43.69 31.01 4.13 39.47 28.79 4.65 35.39 26.63 5.26 72 (22.2) 62.08 30.97 3.01 57.42 28.92 3.34 52.68 26.85 3.72 47.97 24.82 4.17 43.35 22.84 4.69 38.88 20.92 5.31
1500
57 (13.9) 51.23 51.23 3.00 47.78 47.78 3.33 44.22 44.22 3.70 40.65 40.65 4.14 37.14 37.14 4.66 33.69 33.69 5.27 62 (16.7) 52.58 47.33 3.01 48.66 44.69 3.33 44.65 42.00 3.70 40.72 40.58 4.14 37.19 37.19 4.66 33.74 33.74 5.27
63 (17.2)†† 53.41 38.29 3.01 49.38 35.97 3.34 45.25 33.63 3.71 41.12 31.31 4.14 37.11 29.05 4.66 33.23 26.87 5.26
67 (19.4) 57.51 39.78 3.03 53.15 37.41 3.35 48.71 35.02 3.73 44.29 32.66 4.17 39.97 30.35 4.69 35.81 28.12 5.30 72 (22.2) 63.05 32.12 3.05 58.27 30.02 3.38 53.40 27.90 3.76 48.57 25.81 4.21 43.85 23.78 4.73 39.27 21.82 5.35
1600
57 (13.9) 52.31 52.31 3.03 48.75 48.75 3.35 45.10 45.10 3.73 41.42 41.42 4.17 37.81 37.81 4.69 34.28 34.28 5.30 62 (16.7) 53.20 49.06 3.03 49.23 46.33 3.36 45.22 44.88 3.73 41.48 41.48 4.17 37.86 37.86 4.69 34.32 34.32 5.30
63 (17.2)†† 53.95 39.47 3.04 49.85 37.11 3.36 45.65 34.71 3.73 41.47 32.34 4.17 37.40 30.03 4.68 33.47 27.80 5.29
67 (19.4) 58.05 41.04 3.05 53.63 38.62 3.38 49.12 36.18 3.76 44.64 33.76 4.20 40.26 31.41 4.72 36.04 29.12 5.33 72 (22.2) 63.61 32.89 3.07 58.75 30.75 3.40 53.81 28.60 3.79 48.91 26.48 4.23 44.12 24.41 4.76 39.49 22.42 5.38
1700
57 (13.9) 53.29 53.29 3.06 49.64 49.64 3.38 45.88 45.88 3.76 42.12 42.12 4.20 38.42 38.42 4.72 34.80 34.80 5.33 62 (16.7) 53.79 50.73 3.06 49.81 47.89 3.38 45.95 45.95 3.76 42.18 42.18 4.20 38.47 38.47 4.72 34.84 34.84 5.33
63 (17.2)†† 54.43 40.62 3.06 50.27 38.21 3.39 46.01 35.77 3.76 41.77 33.35 4.20 37.65 30.99 4.71 33.68 28.70 5.32
67 (19.4) 58.53 42.28 3.08 54.05 39.81 3.41 49.47 37.32 3.78 44.94 34.84 4.22 40.51 32.44 4.74 36.24 30.10 5.35 72 (22.2) 64.10 33.64 3.10 59.16 31.47 3.43 54.15 29.28 3.81 49.20 27.12 4.26 44.36 25.03 4.79 39.67 23.01 5.40
24ANB748C**31 Outdoor Section With CNPV*6124A**+58CV(A,X)135---22 Indoor Section --- Low
960
57 (13.9) 34.79 34.79 1.95 32.17 32.17 2.27 29.47 29.47 2.63 26.72 26.72 3.04 23.95 23.95 3.52 21.20 21.20 4.07 62 (16.7) 36.22 32.17 1.94 33.19 29.54 2.26 30.08 26.91 2.62 26.94 24.30 3.04 24.00 24.00 3.52 21.24 21.24 4.07
63 (17.2)†† 36.92 26.30 1.93 33.83 24.03 2.25 30.63 21.75 2.62 27.37 19.49 3.04 24.11 17.30 3.52 20.88 15.17 4.07
67 (19.4) 40.15 27.45 1.91 36.84 25.12 2.23 33.42 22.79 2.59 29.95 20.49 3.01 26.47 18.23 3.49 23.02 16.05 4.04 72 (22.2) 44.69 22.68 1.87 41.06 20.65 2.19 37.33 18.62 2.56 33.54 16.62 2.98 29.75 14.67 3.46 25.97 12.78 4.01
1010
57 (13.9) 35.48 35.48 1.95 32.81 32.81 2.27 30.04 30.04 2.63 27.23 27.23 3.05 24.40 24.40 3.52 21.59 21.59 4.07 62 (16.7) 36.64 33.15 1.94 33.58 30.45 2.26 30.44 27.75 2.63 27.30 27.20 3.04 24.45 24.45 3.52 21.63 21.63 4.07
63 (17.2)†† 37.32 26.98 1.94 34.18 24.66 2.26 30.94 22.33 2.62 27.63 20.03 3.04 24.33 17.79 3.52 21.07 15.62 4.08
67 (19.4) 40.58 28.18 1.91 37.22 25.80 2.23 33.76 23.42 2.60 30.24 21.06 3.02 26.71 18.76 3.50 23.22 16.53 4.05 72 (22.2) 45.14 23.15 1.87 41.47 21.09 2.20 37.68 19.02 2.57 33.84 16.99 2.99 29.99 15.01 3.47 26.17 13.10 4.02
1120
57 (13.9) 36.87 36.87 1.95 34.08 34.08 2.27 31.19 31.19 2.63 28.25 28.25 3.05 25.31 25.31 3.53 22.38 22.38 4.07 62 (16.7) 37.49 35.25 1.95 34.37 32.41 2.27 31.24 31.24 2.63 28.30 28.30 3.05 25.36 25.36 3.53 22.42 22.42 4.07
63 (17.2)†† 38.08 28.43 1.94 34.86 26.01 2.26 31.53 23.59 2.63 28.15 21.19 3.05 24.76 18.85 3.53 21.43 16.59 4.09
67 (19.4) 41.40 29.73 1.91 37.95 27.25 2.24 34.39 24.77 2.61 30.78 22.31 3.03 27.17 19.91 3.51 23.60 17.58 4.06 72 (22.2) 46.01 24.15 1.88 42.22 22.02 2.20 38.32 19.89 2.57 34.40 17.78 3.00 30.46 15.73 3.48 26.55 13.75 4.03
1280
57 (13.9) 38.62 38.62 1.96 35.67 35.67 2.28 32.63 32.63 2.64 29.54 29.54 3.06 26.44 26.44 3.53 23.35 23.35 4.08 62 (16.7) 38.70 38.62 1.95 35.73 35.73 2.27 32.68 32.68 2.64 29.59 29.59 3.06 26.48 26.48 3.53 23.39 23.39 4.08
63 (17.2)†† 38.98 30.46 1.95 35.66 27.91 2.28 32.23 25.35 2.64 28.75 22.82 3.07 25.29 20.35 3.55 21.88 17.94 4.10
67 (19.4) 42.34 31.94 1.93 38.79 29.29 2.25 35.13 26.67 2.62 31.42 24.07 3.04 27.71 21.52 3.52 24.06 19.04 4.07 72 (22.2) 47.00 25.53 1.89 43.09 23.30 2.22 39.09 21.07 2.59 35.04 18.88 3.01 30.99 16.73 3.49 26.97 14.66 4.04
1440
57 (13.9) 40.11 40.11 1.96 37.03 37.03 2.28 33.85 33.85 2.65 30.63 30.63 3.07 27.39 27.39 3.54 24.17 24.17 4.09 62 (16.7) 40.18 40.18 1.96 37.09 37.09 2.28 33.91 33.91 2.65 30.68 30.68 3.07 27.43 27.43 3.54 24.20 24.20 4.09
63 (17.2)†† 39.70 32.42 1.97 36.29 29.74 2.29 32.80 27.05 2.66 29.25 24.39 3.08 25.73 21.77 3.56 22.32 22.12 4.12
67 (19.4) 43.09 34.04 1.94 39.46 31.27 2.26 35.72 28.51 2.63 31.92 25.76 3.06 28.16 23.08 3.54 24.46 20.44 4.09 72 (22.2) 47.76 26.84 1.90 43.76 24.52 2.23 39.67 22.21 2.60 35.52 19.93 3.03 31.38 17.70 3.51 27.28 15.54 4.06
See notes on page 16
24ANB7**C

15
DETAILED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM EWB
°F(°C)
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Tot al Sens‡ Tota l Sens‡ Tot al Sens‡ Tot a l Sens‡ Tot a l Sens‡ Tot al Sens‡
24ANB760C**31 Outdoor Section With CNPV*6124A**+58CV(A,X)135---22 Indoor Section --- High
1500
57 (13.9) 53.72 53.72 3.55 52.08 52.08 3.91 50.28 50.28 4.33 48.30 48.30 4.81 46.01 46.01 5.36 43.38 43.38 5.99 62 (16.7) 56.39 48.10 3.57 54.23 47.06 3.93 51.92 45.97 4.34 49.38 44.79 4.82 46.54 43.46 5.37 43.43 43.39 5.99
63 (17.2)†† 57.44 39.42 3.58 55.21 38.38 3.94 52.82 37.28 4.35 50.17 36.09 4.83 47.21 34.79 5.38 43.85 33.34 6.00
67 (19.4) 62.03 40.93 3.63 59.60 39.87 3.98 57.01 38.77 4.40 54.12 37.57 4.87 50.90 36.25 5.42 47.27 34.80 6.04 72 (22.2) 68.33 33.67 3.69 65.64 32.60 4.04 62.75 31.47 4.46 59.55 30.25 4.94 55.98 28.93 5.49 51.96 27.46 6.11
1625
57 (13.9) 55.23 55.23 3.60 53.51 53.51 3.96 51.63 51.63 4.38 49.53 49.53 4.86 47.13 47.13 5.41 44.38 44.38 6.04 62 (16.7) 57.29 50.23 3.62 55.06 49.18 3.97 52.69 48.06 4.39 50.09 46.83 4.87 47.27 46.92 5.41 44.44 44.44 6.04
63 (17.2)†† 58.28 40.86 3.63 55.98 39.80 3.98 53.49 38.69 4.40 50.76 37.48 4.87 47.71 36.16 5.42 44.28 34.69 6.04
67 (19.4) 62.90 42.47 3.67 60.40 41.40 4.03 57.71 40.28 4.44 54.73 39.06 4.92 51.43 37.73 5.47 47.70 36.27 6.09 72 (22.2) 69.27 34.62 3.74 66.48 33.54 4.09 63.48 32.39 4.50 60.19 31.16 4.98 56.52 29.81 5.53 52.40 28.33 6.15
1685
57 (13.9) 55.91 55.91 3.62 54.14 54.14 3.98 52.22 52.22 4.40 50.07 50.07 4.88 47.62 47.62 5.44 44.81 44.81 6.07 62 (16.7) 57.68 51.23 3.64 55.44 50.17 4.00 53.03 49.03 4.41 50.43 47.77 4.89 47.70 47.70 5.44 44.88 44.88 6.07
63 (17.2)†† 58.64 41.54 3.65 56.29 40.47 4.00 53.77 39.34 4.42 51.02 38.14 4.89 47.93 36.81 5.44 44.47 35.33 6.06
67 (19.4) 63.28 43.19 3.70 60.74 42.12 4.05 58.00 40.99 4.46 54.99 39.76 4.94 51.65 38.43 5.49 47.88 36.95 6.11 72 (22.2) 69.67 35.07 3.76 66.84 33.98 4.11 63.79 32.82 4.52 60.46 31.59 5.00 56.74 30.23 5.55 52.59 28.75 6.18
1750
57 (13.9) 56.60 56.60 3.65 54.79 54.79 4.01 52.83 52.83 4.43 50.63 50.63 4.91 48.13 48.13 5.46 45.26 45.26 6.09 62 (16.7) 58.08 52.30 3.66 55.82 51.22 4.02 53.40 50.06 4.43 50.81 48.74 4.91 48.20 48.20 5.46 45.32 45.32 6.09
63 (17.2)†† 59.00 42.26 3.67 56.61 41.18 4.03 54.06 40.05 4.44 51.27 38.84 4.92 48.15 37.49 5.46 44.65 36.01 6.08
67 (19.4) 63.66 43.97 3.72 61.07 42.88 4.07 58.29 41.74 4.48 55.26 40.52 4.96 51.87 39.18 5.51 48.07 37.69 6.13 72 (22.2) 70.06 35.54 3.78 67.19 34.44 4.13 64.11 33.28 4.55 60.73 32.04 5.02 56.97 30.68 5.57 52.77 29.18 6.20
2000
57 (13.9) 58.97 58.97 3.74 57.00 57.00 4.10 54.88 54.88 4.52 52.51 52.51 5.00 49.82 49.82 5.56 46.74 46.74 6.19 62 (16.7) 59.49 56.22 3.75 57.21 55.01 4.11 54.96 54.96 4.52 52.59 52.59 5.01 49.88 49.88 5.56 46.80 46.80 6.19
63 (17.2)†† 60.13 44.93 3.75 57.65 43.84 4.11 54.99 42.69 4.52 52.08 41.43 5.00 48.84 40.07 5.55 45.22 38.55 6.17
67 (19.4) 64.83 46.84 3.80 62.13 45.74 4.16 59.24 44.58 4.57 56.07 43.33 5.04 52.56 41.96 5.59 48.64 40.44 6.22 72 (22.2) 71.31 37.29 3.87 68.31 36.17 4.22 65.08 34.98 4.63 61.55 33.71 5.11 57.65 32.34 5.66 53.29 30.81 6.28
2250
57 (13.9) 60.93 60.93 3.84 58.83 58.83 4.20 56.57 56.57 4.61 54.04 54.04 5.10 51.19 51.19 5.65 47.93 47.93 6.28 62 (16.7) 61.01 61.01 3.84 58.91 58.91 4.20 56.65 56.65 4.62 54.11 54.11 5.10 51.25 51.25 5.65 47.98 47.98 6.28
63 (17.2)†† 61.01 47.48 3.84 58.43 46.37 4.19 55.68 45.19 4.60 52.69 43.92 5.08 49.36 42.51 5.63 45.67 40.93 6.25
67 (19.4) 65.74 49.60 3.89 62.94 48.48 4.24 59.95 47.29 4.65 56.69 46.02 5.13 53.08 44.62 5.68 49.07 43.04 6.30 72 (22.2) 72.25 38.94 3.95 69.12 37.79 4.30 65.78 36.59 4.71 62.14 35.31 5.19 58.12 33.90 5.74 53.64 32.37 6.36
See notes on page 16
24ANB7**C

16
DETAILED COOLING CAPACITIES# (CONTINUED)
EVAPORATOR AIR CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
75 (23.9) 85 (29.4) 95 (35) 105 (40.6) 115 (46.1) 125 (51.7)
CFM EWB
°F(°C)
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Capacity MBtuh To t a l
Sys.
KW**
Tot al Sens‡ Tota l Sens‡ Tot al Sens‡ Tot a l Sens‡ Tot a l Sens‡ Tot al Sens‡
24ANB760C**31 Outdoor Section With CNPV*6124A**+58CV(A,X)135---22 Indoor Section --- Low
1200
57 (13.9) 41.88 41.88 2.45 38.97 38.97 2.83 35.87 35.87 3.26 32.67 32.67 3.76 29.44 29.44 4.32 26.21 26.21 4.96 62 (16.7) 43.21 38.96 2.44 39.82 35.81 2.82 36.26 32.65 3.26 32.73 32.73 3.76 29.50 29.50 4.32 26.26 26.26 4.96
63 (17.2)†† 44.00 31.63 2.44 40.50 28.92 2.82 36.83 26.20 3.26 33.04 23.50 3.76 29.23 20.88 4.32 25.45 18.35 4.97
67 (19.4) 47.74 33.00 2.41 43.97 30.21 2.79 40.03 27.42 3.23 35.98 24.66 3.73 31.92 21.98 4.30 27.89 19.39 4.95 72 (22.2) 52.84 26.95 2.37 48.70 24.52 2.76 44.39 22.08 3.20 39.99 19.69 3.71 35.56 17.38 4.28 31.15 15.16 4.92
1300
57 (13.9) 43.12 43.12 2.46 40.07 40.07 2.84 36.87 36.87 3.27 33.57 33.57 3.77 30.23 30.23 4.33 26.88 26.88 4.97 62 (16.7) 43.95 40.81 2.45 40.50 37.54 2.84 36.95 36.84 3.27 33.63 33.63 3.77 30.28 30.28 4.33 26.93 26.93 4.97
63 (17.2)†† 44.65 32.91 2.45 41.08 30.11 2.83 37.33 27.30 3.27 33.47 24.52 3.77 29.59 21.81 4.34 25.75 19.21 4.99
67 (19.4) 48.41 34.36 2.42 44.56 31.48 2.81 40.53 28.59 3.25 36.41 25.75 3.75 32.28 22.98 4.32 28.18 20.31 4.97 72 (22.2) 53.55 27.80 2.39 49.32 25.31 2.77 44.92 22.82 3.22 40.43 20.37 3.72 35.92 18.00 4.29 31.44 15.72 4.94
1355
57 (13.9) 43.74 43.74 2.46 40.64 40.64 2.84 37.38 37.38 3.28 34.03 34.03 3.78 30.62 30.62 4.34 27.22 27.22 4.98 62 (16.7) 44.33 41.81 2.46 40.87 38.45 2.84 37.45 37.45 3.28 34.08 34.08 3.78 30.67 30.67 4.34 27.26 27.26 4.98
63 (17.2)†† 44.98 33.60 2.46 41.36 30.75 2.84 37.57 27.89 3.28 33.68 25.07 3.78 29.76 22.31 4.35 25.89 19.67 5.00
67 (19.4) 48.74 35.09 2.43 44.85 32.16 2.82 40.78 29.23 3.26 36.63 26.34 3.76 32.45 23.52 4.33 28.33 20.81 4.98 72 (22.2) 53.90 28.26 2.39 49.62 25.74 2.78 45.17 23.21 3.23 40.64 20.73 3.73 36.09 18.33 4.30 31.57 16.03 4.95
1400
57 (13.9) 44.23 44.23 2.47 41.08 41.08 2.85 37.78 37.78 3.29 34.37 34.37 3.78 30.92 30.92 4.35 27.47 27.47 4.99 62 (16.7) 44.63 42.61 2.47 41.19 40.98 2.85 37.85 37.85 3.29 34.43 34.43 3.78 30.97 30.97 4.35 27.51 27.51 4.99
63 (17.2)†† 45.23 34.15 2.46 41.58 31.27 2.85 37.76 28.37 3.29 33.84 25.51 3.79 29.89 22.72 4.36 26.01 20.04 5.01
67 (19.4) 48.99 35.68 2.44 45.07 32.72 2.82 40.96 29.75 3.26 36.79 26.82 3.77 32.59 23.96 4.34 28.44 21.21 4.98 72 (22.2) 54.16 28.63 2.40 49.85 26.08 2.79 45.36 23.53 3.23 40.80 21.02 3.74 36.22 18.60 4.31 31.67 16.27 4.96
1600
57 (13.9) 46.15 46.15 2.49 42.82 42.82 2.87 39.32 39.32 3.31 35.73 35.73 3.81 32.10 32.10 4.38 28.47 28.47 5.02 62 (16.7) 46.22 46.22 2.49 42.88 42.88 2.87 39.38 39.38 3.31 35.78 35.78 3.81 32.14 32.14 4.38 28.51 28.51 5.02
63 (17.2)†† 46.15 36.54 2.49 42.39 33.50 2.88 38.45 30.44 3.32 34.43 27.43 3.82 30.42 24.48 4.40 26.50 21.58 5.04
67 (19.4) 49.93 38.25 2.46 45.88 35.12 2.85 41.67 31.99 3.30 37.38 28.88 3.80 33.10 25.86 4.37 28.89 22.91 5.02 72 (22.2) 55.12 30.20 2.43 50.68 27.55 2.82 46.06 24.90 3.27 41.37 22.28 3.77 36.68 19.76 4.35 32.02 17.33 5.00
1800
57 (13.9) 47.74 47.74 2.52 44.25 44.25 2.90 40.59 40.59 3.34 36.85 36.85 3.84 33.06 33.06 4.41 29.28 29.28 5.06 62 (16.7) 47.81 47.81 2.52 44.31 44.31 2.90 40.65 40.65 3.34 36.89 36.89 3.84 33.10 33.10 4.41 29.31 29.31 5.06
63 (17.2)†† 46.86 38.82 2.52 43.01 35.62 2.91 39.00 32.42 3.36 34.92 29.23 3.86 30.87 26.08 4.43 27.11 27.11 5.08
67 (19.4) 50.65 40.71 2.50 46.52 37.42 2.89 42.22 34.13 3.33 37.86 30.87 3.84 33.53 27.64 4.41 29.37 29.25 5.06 72 (22.2) 55.85 31.70 2.46 51.29 28.95 2.85 46.57 26.20 3.30 41.79 23.49 3.81 37.00 20.87 4.39 32.26 18.35 5.04
{Total and sensible capacities are net capacities. Blower motor heat has been subtracted. }Sensible capacities shown are based on 80_F(27_C) entering air at the indoor coil. For sensible capacities at other than 80_F(27_C), deduct 835 Btuh
(245 kW) per 1000 CFM (480 L/S) of indoor coil air for each degree below 80_F(27_C), or add 835 Btuh (245 kW) per 1000 CFM (480 L/S) of indoor coil air per degree above 80_F(27_C).
# Detailed cooling capacities are based on indoor and outdoor unit at the same elevation per AHRI standard 210/240---2008. If additional tubing length and/or indoor unit is located above outdoor unit, a slight variation in capacity
may occur.
** System kw is total of indoor and outdoor unit kilowatts. EWB — Entering Wet Bulb NOTE: When the required data fall between the published data, interpolation may be performed. Extrapolation is not an acceptable practice.
24ANB7**C

17
CONDENSER ONLY RATINGS*
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
24ANB724C**31 --- High
30
(---1.11)
TCG 28.00 25.00 21.90 18.90 16.00 13.30 10.70 8.50
SDT 71.60 81.50 91.40 101.20 111.00 120.80 130.80 140.90
KW 1.20 1.30 1.40 1.51 1.63 1.76 1.92 2.11
35
(1.67)
TCG 31.20 27.70 24.30 21.00 17.80 14.80 12.10 9.60
SDT 73.20 83.00 92.80 102.60 112.40 122.20 132.10 142.10
KW 1.23 1.33 1.43 1.53 1.65 1.79 1.95 2.14
40
(4.44)
TCG 34.60 30.70 26.90 23.20 19.80 16.50 13.50 10.70
SDT 74.80 84.60 94.40 104.10 113.90 123.50 133.40 143.30
KW 1.25 1.35 1.45 1.56 1.68 1.82 1.98 2.17
45
(7.22)
TCG 38.20 33.90 29.70 25.70 21.90 18.30 15.00 12.00
SDT 76.60 86.30 96.00 105.70 115.20 124.90 134.70 144.60
KW 1.28 1.38 1.48 1.58 1.70 1.84 2.01 2.20
50
(10.0)
TCG 42.00 37.30 32.60 28.30 24.10 20.20 16.60 13.40
SDT 78.40 88.00 97.60 107.10 116.70 126.30 136.00 145.90
KW 1.31 1.40 1.50 1.60 1.72 1.87 2.03 2.23
55
(12.78)
TCG 46.10 40.90 35.80 31.00 26.50 22.30 18.40 14.80
SDT 80.20 89.70 99.20 108.60 118.10 127.70 137.40 147.10
KW 1.34 1.43 1.52 1.63 1.75 1.89 2.06 2.26
60
(15.56)
TCG 50.50 44.70 39.20 33.90 29.00 24.40 20.20 16.30
SDT 82.00 91.40 100.80 110.20 119.70 129.20 138.80 148.40
KW 1.37 1.45 1.54 1.65 1.77 1.92 2.09 2.28
24ANB724C**31 --- Low
30
(---1.11)
TCG 13.50 13.60 13.30 12.80 12.20 11.30 10.40 9.40
SDT 66.80 76.80 86.70 96.50 106.30 116.00 125.70 135.70
KW 0.77 0.89 1.03 1.18 1.35 1.53 1.74 1.96
35
(1.67)
TCG 15.20 15.20 14.90 14.40 13.70 12.90 11.90 10.90
SDT 68.00 78.00 87.90 97.70 107.40 117.10 126.90 136.90
KW 0.77 0.89 1.02 1.17 1.34 1.53 1.74 1.98
40
(4.44)
TCG 16.90 16.90 16.60 16.00 15.30 14.50 13.50 12.50
SDT 69.30 79.30 89.00 98.80 108.50 118.20 128.10 138.10
KW 0.76 0.88 1.01 1.17 1.34 1.53 1.75 1.99
45
(7.22)
TCG 18.80 18.70 18.30 17.80 17.00 16.20 15.20 14.10
SDT 70.60 80.50 90.30 100.00 109.70 119.40 129.20 139.20
KW 0.75 0.87 1.00 1.16 1.33 1.53 1.76 2.01
50
(10.0)
TCG 20.80 20.60 20.20 19.60 18.90 18.00 17.00 15.90
SDT 72.00 81.80 91.50 101.20 110.80 120.50 130.40 140.30
KW 0.74 0.86 0.99 1.15 1.33 1.53 1.76 2.02
55
(12.78)
TCG 22.90 22.70 22.20 21.60 20.80 19.90 18.80 17.80
SDT 73.40 83.20 92.80 102.40 112.10 121.70 131.50 141.40
KW 0.73 0.84 0.98 1.14 1.32 1.53 1.77 2.03
60
(15.56)
TCG 25.10 24.80 24.30 23.70 22.80 21.90 20.80 19.70
SDT 74.90 84.60 94.10 103.70 113.30 122.90 132.60 142.40
KW 0.72 0.83 0.97 1.13 1.32 1.53 1.77 2.04
24ANB736C**31 --- High
30
(---1.11)
TCG 34.80 32.30 29.80 27.40 25.00 22.60 20.10 17.60
SDT 71.10 80.60 90.10 99.60 109.10 118.50 127.80 137.20
KW 1.72 1.87 2.04 2.25 2.47 2.72 3.00 3.29
35
(1.67)
TCG 38.50 35.70 33.10 30.40 27.80 25.10 22.40 19.60
SDT 72.60 82.00 91.50 100.90 110.30 119.70 128.90 138.20
KW 1.76 1.91 2.08 2.28 2.50 2.76 3.03 3.33
40
(4.44)
TCG 42.40 39.40 36.50 33.60 30.70 27.80 24.80 21.80
SDT 74.20 83.60 93.00 102.40 111.70 120.90 130.10 139.20
KW 1.81 1.95 2.11 2.31 2.53 2.79 3.06 3.37
45
(7.22)
TCG 46.50 43.30 40.20 37.00 33.90 30.70 27.50 24.20
SDT 75.90 85.20 94.50 103.80 113.00 122.20 131.30 140.30
KW 1.87 1.99 2.15 2.34 2.57 2.82 3.10 3.40
50
(10.0)
TCG 50.90 47.50 44.00 40.60 37.20 33.80 30.30 26.70
SDT 77.60 86.80 96.10 105.30 114.40 123.50 132.50 141.40
KW 1.92 2.04 2.19 2.38 2.60 2.85 3.13 3.44
55
(12.78)
TCG 55.50 51.80 48.10 44.50 40.80 37.00 33.20 29.40
SDT 79.40 88.50 97.70 106.80 115.90 124.90 133.80 142.60
KW 1.99 2.09 2.24 2.42 2.64 2.89 3.17 3.47
60
(15.56)
TCG 60.40 56.40 52.50 48.50 44.50 40.40 36.40 32.30
SDT 81.20 90.20 99.30 108.40 117.40 126.30 135.00 143.80
KW 2.05 2.15 2.29 2.47 2.68 2.93 3.20 3.51
See notes on page 19
24ANB7**C

18
CONDENSER ONLY RATINGS* CONTINUED
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
24ANB736C**31 --- Low
30
(---1.11)
TCG 20.70 20.10 19.50 18.80 18.00 16.90 15.60 14.10
SDT 65.70 75.40 85.10 94.80 104.50 114.10 123.60 133.10
KW 1.18 1.31 1.47 1.66 1.88 2.13 2.43 2.78
35
(1.67)
TCG 23.10 22.40 21.80 21.00 20.10 19.00 17.60 16.00
SDT 66.80 76.50 86.10 95.80 105.40 115.00 124.50 134.00
KW 1.16 1.30 1.46 1.65 1.87 2.12 2.42 2.76
40
(4.44)
TCG 25.60 25.00 24.20 23.40 22.40 21.20 19.80 18.10
SDT 68.00 77.60 87.30 96.90 106.50 116.00 125.40 134.90
KW 1.13 1.28 1.45 1.64 1.86 2.11 2.41 2.75
45
(7.22)
TCG 28.40 27.70 26.90 26.00 24.90 23.70 22.10 20.30
SDT 69.30 78.80 88.40 98.00 107.50 117.00 126.40 135.80
KW 1.11 1.26 1.43 1.63 1.85 2.10 2.40 2.73
50
(10.0)
TCG 31.40 30.60 29.70 28.70 27.60 26.20 24.60 22.70
SDT 70.60 80.10 89.60 99.20 108.60 118.00 127.40 136.70
KW 1.08 1.24 1.42 1.61 1.84 2.09 2.39 2.72
55
(12.78)
TCG 34.60 33.70 32.70 31.70 30.40 29.00 27.30 25.30
SDT 72.00 81.50 90.90 100.40 109.80 119.10 128.40 137.60
KW 1.06 1.22 1.40 1.60 1.83 2.08 2.38 2.71
60
(15.56)
TCG 38.10 37.00 36.00 34.80 33.50 31.90 30.10 28.00
SDT 73.50 82.90 92.30 101.60 111.00 120.20 129.40 138.60
KW 1.03 1.20 1.38 1.59 1.82 2.07 2.36 2.69
24ANB748C**31 --- High
30
(---1.11)
TCG 44.30 42.30 39.70 36.70 33.50 30.30 27.10 24.20
SDT 69.60 79.40 88.90 98.30 107.70 117.10 126.50 136.00
KW 2.00 2.27 2.56 2.88 3.24 3.67 4.16 4.76
35
(1.67)
TCG 49.40 47.10 44.10 40.80 37.30 33.80 30.40 27.20
SDT 71.20 80.80 90.30 99.60 108.90 118.20 127.60 137.00
KW 2.04 2.31 2.60 2.91 3.28 3.70 4.21 4.80
40
(4.44)
TCG 54.80 52.00 48.70 45.10 41.30 37.50 33.90 30.40
SDT 72.80 82.30 91.60 100.90 110.20 119.40 128.70 138.00
KW 2.08 2.35 2.63 2.95 3.32 3.75 4.25 4.86
45
(7.22)
TCG 60.40 57.20 53.50 49.60 45.50 41.40 37.50 33.80
SDT 74.40 83.80 93.00 102.20 111.40 120.60 129.80 139.10
KW 2.12 2.38 2.67 2.99 3.36 3.79 4.31 4.91
50
(10.0)
TCG 66.10 62.60 58.60 54.30 49.90 45.50 41.40 37.40
SDT 76.00 85.30 94.50 103.60 112.70 121.80 131.00 140.20
KW 2.15 2.41 2.70 3.02 3.40 3.84 4.36 4.98
55
(12.78)
TCG 72.10 68.10 63.80 59.10 54.40 49.80 45.30 41.10
SDT 77.60 86.80 95.90 105.00 114.00 123.10 132.10 141.30
KW 2.18 2.44 2.73 3.06 3.44 3.89 4.42 5.04
60
(15.56)
TCG 78.20 73.80 69.10 64.10 59.10 54.20 49.50 44.90
SDT 79.30 88.40 97.40 106.40 115.40 124.30 133.30 142.30
KW 2.20 2.46 2.76 3.09 3.48 3.94 4.48 5.11
24ANB748C**31 --- Low
30
(---1.11)
TCG 27.10 26.70 25.90 24.60 23.00 21.00 18.70 16.20
SDT 65.00 74.70 84.40 93.90 103.40 112.80 122.20 131.50
KW 1.44 1.66 1.90 2.18 2.49 2.84 3.25 3.71
35
(1.67)
TCG 30.20 29.70 28.80 27.50 25.90 23.80 21.50 18.80
SDT 66.00 75.70 85.30 94.80 104.30 113.70 123.10 132.40
KW 1.41 1.64 1.88 2.16 2.47 2.83 3.23 3.69
40
(4.44)
TCG 33.50 33.00 32.10 30.70 29.00 26.90 24.40 21.70
SDT 67.10 76.80 86.30 95.80 105.30 114.60 124.00 133.30
KW 1.38 1.61 1.86 2.14 2.45 2.81 3.22 3.68
45
(7.22)
TCG 37.00 36.50 35.60 34.20 32.40 30.20 27.70 24.80
SDT 68.30 77.90 87.40 96.90 106.30 115.60 124.90 134.10
KW 1.35 1.58 1.84 2.12 2.44 2.79 3.20 3.66
50
(10.0)
TCG 40.90 40.30 39.40 37.90 36.10 33.80 31.20 28.20
SDT 69.50 79.10 88.60 98.00 107.40 116.60 125.80 135.00
KW 1.32 1.56 1.81 2.10 2.42 2.78 3.18 3.64
55
(12.78)
TCG 45.00 44.50 43.50 42.00 40.10 37.80 35.00 31.90
SDT 70.90 80.40 89.80 99.20 108.50 117.70 126.90 136.00
KW 1.29 1.53 1.79 2.08 2.40 2.76 3.16 3.62
60
(15.56)
TCG 49.60 49.00 47.90 46.40 44.40 42.00 39.20 35.90
SDT 72.30 81.80 91.10 100.40 109.70 118.80 127.90 137.00
KW 1.26 1.50 1.77 2.06 2.38 2.74 3.15 3.60
See notes on page 19
24ANB7**C

19
CONDENSER ONLY RATINGS* CONTINUED
SST
°F(°C)
CONDENSER ENTERING AIR TEMPERATURES ° F (° C)
55 (12.78) 65 (18.33) 75 (23.89) 85 (29.44) 95 (35.0) 105 (40.56) 115 (46.11) 125 (51.67)
24ANB760C**31 --- High
30
(---1.11)
TCG 48.30 46.50 44.80 42.90 40.90 38.60 36.00 32.90
SDT 72.70 81.80 91.10 100.50 109.90 119.20 128.50 137.70
KW 2.40 2.67 2.98 3.33 3.74 4.20 4.73 5.32
35
(1.67)
TCG 53.20 51.30 49.50 47.50 45.30 42.80 40.00 36.70
SDT 74.30 83.40 92.60 101.90 111.20 120.40 129.60 138.80
KW 2.46 2.72 3.03 3.38 3.79 4.26 4.79 5.39
40
(4.44)
TCG 58.60 56.50 54.50 52.40 50.00 47.40 44.30 40.80
SDT 76.00 85.00 94.20 103.40 112.60 121.70 130.80 139.90
KW 2.52 2.78 3.08 3.44 3.85 4.32 4.86 5.47
45
(7.22)
TCG 64.30 62.10 59.90 57.60 55.10 52.20 48.90 45.20
SDT 77.80 86.70 95.80 104.90 114.00 123.10 132.10 141.10
KW 2.58 2.84 3.14 3.50 3.91 4.38 4.92 5.54
50
(10.0)
TCG 70.50 68.10 65.80 63.20 60.50 57.40 53.80 49.80
SDT 79.70 88.60 97.50 106.50 115.50 124.50 133.40 142.20
KW 2.66 2.91 3.21 3.56 3.97 4.45 4.99 5.61
55
(12.78)
TCG 77.10 74.60 72.00 69.30 66.30 62.90 59.10 54.80
SDT 81.80 90.50 99.40 108.30 117.10 126.00 134.80 143.50
KW 2.74 2.98 3.28 3.63 4.04 4.52 5.07 5.69
60
(15.56)
TCG 84.10 81.40 78.60 75.70 72.40 68.80 64.70 60.10
SDT 84.00 92.60 101.30 110.00 118.80 127.50 136.10 144.70
KW 2.82 3.06 3.35 3.71 4.12 4.60 5.15 5.77
24ANB760C**31 --- Low
30
(---1.11)
TCG 31.20 31.30 30.60 29.30 27.40 25.10 22.40 19.30
SDT 66.60 76.30 85.90 95.30 104.70 113.90 123.10 132.30
KW 1.31 1.68 2.12 2.66 3.29 4.03 4.91 5.94
35
(1.67)
TCG 35.00 34.90 34.20 32.90 31.00 28.60 25.80 22.60
SDT 67.80 77.50 87.10 96.50 105.70 115.00 124.10 133.30
KW 1.29 1.66 2.11 2.65 3.28 4.03 4.91 5.94
40
(4.44)
TCG 38.90 38.90 38.10 36.70 34.80 32.30 29.40 26.10
SDT 69.20 78.80 88.30 97.60 106.90 116.00 125.10 134.30
KW 1.27 1.65 2.10 2.63 3.27 4.02 4.90 5.94
45
(7.22)
TCG 43.20 43.10 42.30 40.80 38.80 36.30 33.30 29.90
SDT 70.60 80.20 89.50 98.80 108.00 117.10 126.20 135.20
KW 1.26 1.63 2.08 2.62 3.26 4.01 4.90 5.93
50
(10.0)
TCG 47.80 47.60 46.70 45.20 43.10 40.50 37.40 33.90
SDT 72.10 81.50 90.80 100.00 109.20 118.20 127.20 136.30
KW 1.24 1.61 2.06 2.60 3.24 4.00 4.89 5.93
55
(12.78)
TCG 52.60 52.30 51.40 49.80 47.70 45.00 41.80 38.20
SDT 73.60 83.00 92.20 101.30 110.40 119.40 128.40 137.30
KW 1.21 1.59 2.04 2.58 3.22 3.98 4.87 5.92
60
(15.56)
TCG 57.70 57.40 56.40 54.80 52.50 49.70 46.40 42.70
SDT 75.20 84.40 93.60 102.60 111.70 120.60 129.50 138.40
KW 1.19 1.56 2.01 2.56 3.20 3.96 4.86 5.90
* AHRI listing applies only to systems shown in Combination Ratings table.
KW --- Outdoor Unit Kilowatts Only.
SDT --- Saturated Temperature Leaving Compressor (° F)
SST --- Saturated Temperature Entering Compressor (° F/° C)
TCG --- Gross Cooling Capacity (1000 Btuh)
24ANB7**C

20
GUIDE SPECIFICATIONS
GENERAL
System Description
Outdoor--mounted, air--cooled, split--system air conditioner unit
suitableforground orrooftop installation.Unit consistsof ahermetic
compressor, an air--cooled coil, propeller--type condenser fan, and a
control box. Unit will discharge supply air upward as shown on
contract drawings. Unit will be used in a refrigeration circuit to match
up to a packaged fan coil or coil unit.
Quality Assurance
— Unit will be rated in accordance with the latest edition of
AHRI Standard 210.
— Unit will be certified for capacity and efficiency, and
listed in the latest AHRI directory.
— Unit construction will comply with latest edition of
ANSI/ ASHRAE and with NEC.
— Unit will be constructed in accordance with UL
standards and will carry the UL label of approval. Unit
will have c--UL approval.
— Unit cabinet will be capable of withstanding Federal Test
Method Standard No. 141 (Method 6061) 500--hr salt
spray test.
— Air--cooled condenser coils will be leak tested and
pressure tested.
— Unit constructed in ISO9001 approved facility.
Delivery, Storage, and Handling
— Unit will be shipped as single package only and is stored
and handled per unit manufacturer’s recommendations.
Warranty (for inclusion by specifying engineer)
— U.S. and Canada only.
PRODUCTS
Equipment
— Factory assembled, single piece, air--cooled air
conditioner unit. Contained within the unit enclosure is
all factory wiring, piping, controls, compressor,
refrigerant charge Puronr(R--410A), and special features
required prior to field start--up.
Unit Cabinet
— Unit cabinet, including louvered coil guard, will be
constructed of galvanized steel, bonderized, and coated
with a powder coat paint to both sides of the sheet metal
for enhanced sea coast corrosion resistance.
Fans
— Condenser fan will be direct--drive propeller type,
discharging air upward.
AIR--COOLED, SPLIT--SYSTEM AIR CONDITIONER
24ANB7*C
2 TO 5 NOMINAL TONS
— Condenser fan motors will be totally enclosed, 1--phase
type with class B insulation and permanently lubricated
bearings. Shafts will be corrosion resistant.
— Fan blades will be statically and dynamically balanced.
— Condenser fan openings will be equipped with coated
steel wire safety guards.
Compressor
— Compressor will be hermetically sealed.
— Compressor will be mounted on rubber vibration
isolators.
Condenser Coil
— Condenser coil will be air cooled.
— Coil will be constructed of aluminum fins with epoxy
phenolic thermoset coating specially designed to resist
coastal corrosion. Fins are mechanically bonded to
copper tubes which are then cleaned, dehydrated, and
sealed.
— ArmorPlate coating -- Aluminum fin material is
pre--coated on both sides with a corrosion protective
epoxy phenolic coating.
Refrigeration Components
— Refrigeration circuit components will include liquid--line
shutoff valve with sweat connections, vapor--line shutoff
valve with sweat connections, system charge of Puronr
(R--410A) refrigerant, and compressor oil.
— Unit will be equipped with high--pressure switch, low
pressure switch and filter drier for Puron refrigerant.
Operating Characteristics
— The capacity of the unit will meet or exceed _____ Btuh
at a suction temperature of _____ _F/_C. The power
consumption at full load will not exceed _____ kW.
— Combination of the unit and the evaporator or fan coil
unit will have a total net cooling capacity of _____ Btuh
or greater at conditions of _____ CFM entering air
temperature at the evaporator at _____ _F/_C wet bulb
and _____ _F/_C dry bulb, and air entering the unit at
_____ _F/_C.
— The system will have a SEER of _____ Btuh/watt or
greater at DOE conditions.
Electrical Requirements
— Nominal unit electrical characteristics will be _____ v,
single phase, 60 hz. The unit will be capable of
satisfactory operation within voltage limits of _____ v to
_____ v.
— Unit electrical power will be single point connection.
— Control circuit will be 24v.
Special Features
— Refer to section of this literature identifying accessories
and descriptions for specific features and available
enhancements.
24ANB7**C
